CDR Mini Hi-Fi System
FW-R55
México
Es necesario que lea cuidadosamente su instructivo de manejo.
PRECAUCIÓN - ADVERTENCIA
No abrir, riesgo de choque eléctrico
ATENCIÓN
Verifique que el voltaje de alimentación sea el requerido para su aparato
Para evitar el riesgo de choque eléctrico, no quite la tapa.
En caso de requerir servicio, dirijase al personal calificado.
Descripción: |
Minisistema CDR de Audio |
Modelo: |
FW-R55/21 |
Alimentación: |
120–240 V / 50–60 Hz |
Consumo: |
90 W |
Importador: |
Philips Mexicana, S.A. de C.V. |
Domicilio: |
Norte 45, # 669, |
|
Col. Industrial Vallejo |
Localidad y Tel.: |
C.P. 02300 México D.F., |
|
Tel. 5728 4200 |
Exportador: |
Philips Electronics HK Ltd. |
País de Origen: |
China |
Nº de Serie: |
_______________________ |
LEA CUIDADOSAMENTE ESTE INSTRUCTIVO
ANTES DE USAR SU APARATO.
2
English _________________________________________________________ 4
Français _______________________________________________________ 28
Español ________________________________________________________ 52
∑ ____________________________________________________________ 76
Guarantees ___________________________________________________ 100
Español Français English
Guarantees ∑
3
English
Contents
Technical data _______________________________ 5
General information
Environmental information _____________________ 5 Supplied accessories __________________________ 6 Setup information ___________________________ 6 Maintenance ________________________________ 6
Disc handling _______________________________ 6
Discs for recording ___________________________ 6 Discs for playback ____________________________ 6
MP3
Some words about MP3 ______________________ 7
Installation
Speaker connections _________________________ 8 Antenna connections _________________________ 8
Mains _____________________________________ 8 Plug and Play _______________________________ 8
Analogue audio connections ___________________ 9 Digital audio connections ______________________ 9 Connecting a subwoofer ______________________ 9
Controls and connections
On the back _______________________________ 10 On the front _______________________________ 11
Remote control
Remote control keys ________________________ 12 Remote control usage _______________________ 13
Sound control ______________________________ 13
Basic functions
Switching to standby ________________________ 14 Demonstration mode _______________________ 14 Loading the CDC and CDR ___________________ 14 Playback __________________________________ 15
Selecting and searching _______________________ 15 SHUFFLE and REPEAT _______________________ 16 Microphone mixing _________________________ 16 CD text display ____________________________ 16 ID3-tag ___________________________________ 16
Program
Programming track numbers __________________ 17 Erasing a track from the program _______________ 17 Clearing the program ________________________ 17 Making a program for recording ________________ 17
About recording
Basic information ___________________________ 18 Direct Line Recording (DLR) __________________ 18 Auto Level Control (ALC) ____________________ 18 Adjusting the record level ____________________ 18
Internal recording
Recording a single track ______________________ 19 Recording an entire CD ______________________ 19 Recording a program ________________________ 19 Recording from the tuner _____________________ 20 Further recording possibilities _________________ 20
External recording
Analogue or digital recording? _________________ 21 Automatic track increment ____________________ 21 Recording with automatic start ________________ 21 Manual recording ___________________________ 21
Recording the microphone ____________________ 22
(Un)finalizing, erasing
Finalizing CDR(W) discs ______________________ 23 Unfinalizing CDRW discs _____________________ 23 Erasing from a CDRW disc ____________________ 23
Features
CD text editing (on CD recorder only) __________ 24
Tuner
Tuning to radio stations ______________________ 25 Storing radio stations ________________________ 25 Tuning to preset stations _____________________ 25 Switchable tuning grid _______________________ 25
Clock and timer
Clock setting ______________________________ 26 Timer functions ____________________________ 26
Troubleshooting ____________________________ 27
4
Technical data/General information
Subject to modification without notice.
General
AC Power __________ 110–127 V/220–240 V / 50–60 Hz
Power consumption
Active _________________________________ 90 W Standby ______________________________ < 17 W
Economy power save mode _______________ < 1 W Dimensions, w × h × d ___________ 265 × 310 × 411 mm Weight (without speakers) ____________________ 7.6 kg
Amplifier
Output power ________ 2 × 120 W MPO, 2 × 60 W RMS,
6 Ω, 1 kHz,THD 10%
Frequency response _____________ 20–20,000 Hz, ±3 dB S/N ratio __________________________ ≥ 85 dBA (IEC)
Input sensitivity
AUX/CDR IN L/R (standard level) ________ 1,000 mV AUX/CDR IN L/R (low level) _____________ 500 mV MIC ___________________________________ 1 mV
DIGITAL IN __________ 500 mVpp (75 Ω)/12–96 kHz
Output
Impedance speakers ______________________ ≥ 6 Ω Impedance headphones ______________ 32 Ω–600 Ω LINE OUT L/R ________________________ 500 mV SUBWOOFER OUT ______________________ 2.3 V
CD changer and CD recorder
Number of programmable tracks _________________ 99
Playback
Frequency range _____________ 20–20,000 Hz, ±3 dB S/N ratio ____________________________ ≥ 98 dBA Cross talk _____________________ ≤ -75 dB (1 kHz) Total harmonic distortion _________ ≤ -80 dB (1 kHz)
Digital recording ____________________ equal to source
Analogue recording
Frequency range _____________ 20–20,000 Hz, ±3 dB S/N ratio playback _____________________ ≥ 88 dBA Cross talk _____________________ ≤ -65 dB (1 kHz) Total harmonic distortion _________ ≤ -78 dB (1 kHz)
Laser (CD recorder)
Type ___________________ Semiconductor laser GaAIAs Wave length ___________________ 775–795 nm (at 25°) Output power ________ 2.5 mW (Read), 35 mW (Write) Beam divergence ________________________ 60 degree
Tuner
Wave range
FM ___________________________ 87.5–108.0 MHz MW, Grid 9 _____________________ 531–1,602 kHz MW, Grid 10 ____________________ 530–1,700 kHz
Speakers
System __________________________ 3 way bass reflex Impedance __________________________________ 6 Ω
Woofers
Woofer ______________________________ 1 × 51/4"
wOOx woofer __________________________ 1 × 6" Tweeter ___________________ 1 × 2", Ferro fluid cooled Tweeter __________________________ 1 × 1", Polydome
Dimensions, w × h × d ___________ 240 × 350 × 290 mm Weight _______________________________ 3.9 kg/each
CAUTION
INVISIBLE LASER RADIATION WHEN OPEN.
AVOID EXPOSURE TO BEAM.
Note:This warning is located inside the enclosure.
English
5
English
General information
Supplied accessories
–2 loudspeakers including 2 speaker cables
–Remote control
–2 batteries for the remote control, size AA
–AM (MW) loop antenna
–FM wire antenna
–Mains cable
Setup information
Place the set on a flat, hard and stable surface. Make sure to leave at least 3.5 cm free around the set to prevent overheating. Active mobile phones near to the set may cause malfunctions.
Maintenance
Clean the set with a soft,
slightly dampened, lint-free cloth. Do not use any cleaning agents as they may have a corrosive effect.
Do not expose the set, batteries or discs to humidity, rain, sand or excessive heat (caused by heating equipment or direct sunlight).
Disc handling
If the CDR Mini Hi-Fi system fails to read discs correctly use a commonly available cleaning-CD to clean the lenses before submitting the set to repair. Other cleaning methods may destroy the lenses. Always keep the trays closed to avoid dust on the lenses.
The lenses may cloud over when the set is suddenly moved from cold to warm surroundings. Playing a disc is not possible then. Leave the set in a warm environment until the moisture evaporates.
To take a disc out of its box
easily, press the centre spindle while lifting the CD(RW). Always pick up a CD(RW) by the edge and put it back in its box after use.
Never write on a CD or attach a
sticker to it.Write only on the printed side of a CDR or CDRW, and only with a soft felt-tipped pen.
To clean a disc, wipe it in a straight line from the centre towards the edge using a soft, lint-free cloth.
A cleaning agent may damage the disc!
Discs for recording
For recording, make sure to use special audio discs only. These discs are marked with “Digital Audio” and the logos shown below.
There are two different types of audio discs for the use on this CD recorder:
– CD-Audio Recordable (CDR) discs can be recorded on once and
played on all standard CD players and CD recorders, when finalized.
– CD-Audio ReWritable (CDRW) discs can be recorded on, erased and re-recorded many times and played on CDRW compatible CD players and CD recorders, when finalized.
All Philips CD players and CD recorders with this sticker are CDRW compatible.
To ensure proper working of the set we recommend
the use of Philips audio CDR and audio CDRW discs only.
Note: Do not use a computer CDR or CDRW as recording will not work properly!
Recording is permissable insofar as copyright or other rights of third parties are not infringed upon.
In some countries the use of the Philips CDR Mini Hi-Fi system as shown or suggested in this user manual may require the authorization of copyright holders.
Discs for playback
For playback on this CD changer and CD recorder you can use following discs:
–All pre-recorded audio CDs
–All audio CDR and audio CDRW discs
–MP3-CDs (CD-ROMs with MP3 tracks) – Make sure filename ends with .mp3
Note: Not finalized CDR(W) discs can only be played on the CD recorder.
6
Some words about MP3
The revolutionary new music compression technology MP3 (MPEG Audio Layer-3) enables shrinking down of original digital audio sound data with a factor of up to 10 without losing significant sound quality.This allows you to record up to 10 hours of CD-like quality music on a single CD-ROM.
Making your own MP3-CD
Basically there are two sources for MP3 music on CD.You can either transfer music from your own digital audio CDs via CD-ROM drive onto your PC and encode it into MP3 format (“rip”) or download legal MP3 music from the Internet.
Record (“burn”) the music from your hard disc on CD-ROM with your home PC (make sure filename ends with .mp3). Once finished, you can play your MP3-CD on this CDR Mini Hi-Fi system and enjoy the music.
Data rate
The data rate is of great importance with MP3. It indicates how fast bits are transfered.
Stereo music on a CD shows a data rate of about
1,400 kilobits per second (kbps). To achieve a good MP3 quality a bit rate of 128 kbps is recommended. As the encoding rate is user-selectable, make sure to reach this data rate for MP3 as recordings less than 128 kbps will suffer from a degradation in sound quality.
Recording
Downloading MP3 files from the Internet or ripping songs from your own digital audio CDs is a delicate process, also influenced by the quality of the encoder program and speed of your PC.This may sometimes result in “drop-outs” which you may experience while listening to your MP3-CD.
In any case make sure to use a recording speed not faster than indicated on the CD-ROM and avoid running other programs simultaneously on your PC during the recording process.
In compliance with the SDMI (Secure Digital Music Initiative) this CDR Mini Hi-Fi system has no digital output.
It is not possible to “burn” an MP3-CD on this CDR Mini Hi-Fi system.
It is not possible to record from an MP3-CD.
Supported formats
Following formats are supported on this CDR Mini Hi-Fi system:
–Disc format: ISO 9660 or Joliet
–Filename: .mp3 (tracks), .m3u or .pls (playlists)
–Bit rate: 32–320 kbps (128 kbps advised) or variable
bit rate
Use ISO 9660 disc format when burning the CD-ROM.
UDF disc format (e. g.“DirectCD” or “WinOnCD”) is not supported.
MP3
English
7
|
Installation |
||||||||||||||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
English |
|
Speaker connections |
|||||||||||||||||
|
as shown below. |
||||||||||||||||||
|
|
The speaker connections are click-fit connectors. Use them |
|||||||||||||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
1Connect the coloured (or marked) wire to the red terminal and the black (or unmarked) wire to the black terminal.
2Connect:
–Left speaker to L (red and black)
–Right speaker to R (red and black)
Antenna connections
AM antenna
The loop antenna supplied is for indoor use only.
1Fit the plug of the loop antenna to AM ANTENNA as shown below.
2Position the antenna as far away as possible from the TV, a VCR and other radiation sources.
3Turn the antenna for optimum reception.
|
FM ANTENNA |
AM |
ANTENNA |
|
FM antenna
The wire antenna supplied can only be used to receive nearby stations. For better reception we recommend using a cable antenna system or an outdoor antenna.
1Fit the supplied wire antenna to FM ANTENNA as shown below.
2Move the antenna in different positions for optimum reception.
0If you are using a cable antenna system or an outdoor antenna, fit the antenna plug to FM ANTENNA instead of
the wire antenna.
TENNA |
FM ANTENNA |
FM ANTENNA |
|
ANTENNA |
Mains
The type plate is located on the rear of the set.
1If your set is equipped with a VOLTAGE SELECTOR, set this selector to your local mains voltage if necessary.
2Make sure all connections have been made before switching on the mains supply.
3Connect the mains cable supplied to AC MAINS ~ and to the wall socket.This switches on the mains supply.
When the set is switched to standby, it is still consuming some power. To disconnect the set from the mains completely, remove the mains plug from the wall socket.
To avoid overheating of the set a safety circuit has been built in.Therefore your set may disconnect under extreme conditions. If this happens, switch the set off and let it cool down before reusing it.
Plug and Play
This function allows you to store all available radio stations automatically.
First setup
1When you switch on the mains supply AUTO INSTALL - PRESS PLAY will be scrolled.
2Press ÉÅ to start storing.
INSTALL is displayed, followed by TUNER and AUTO.
PROG starts flashing.
All FM stations, followed by all other stations of other wavebands with sufficient signal strength, will be stored.
Note: If no stereo signal is detected CHECK ANTENNA will be displayed. Check antenna connection or turn the antenna for optimum reception.
3When all available radio stations are stored or the memory for 40 presets is full, storing will be stopped and the last stored radio station will be played.
0To exit the automatic storing press Ç.
Note: If you exit automatic storing before completion, the function will be restarted when switching on the mains supply again.
Restarting Plug and Play
1Press ÉÅ for minimum 5 seconds in standby or demonstration mode.
AUTO INSTALL - PRESS PLAY will be scrolled.
2Press ÉÅ to restart storing.
INSTALL is displayed, followed by TUNER and AUTO.
PROG starts flashing.
All previously stored stations will be replaced.
8
Installation
English
TAPE RECORDER |
CD PLAYER |
|
DIGITAL |
|
IN |
R |
L |
|
LINE |
|
OUT |
|
AUX/ |
|
CDR |
|
IN |
|
AM ANTENNA FM ANTENNA |
|
SUBWOOFER |
|
OUT |
|
AC |
|
MAINS |
|
~ |
|
VOLTAGE |
|
SELECTOR |
|
110V- |
|
127V |
|
220V- |
|
240V |
SUBWOOFER |
NOT FOR ALL |
VERSIONS |
|
|
SPEAKERS 6 Ω |
Analogue audio connections |
Digital audio connections |
AUX/CDR IN L/R
It is possible to use an additional appliance, e.g. tape recorder,TV or VCR, with the set.
1 |
Connect the red plug of a cinch cable to the red socket |
1 |
|
AUX/CDR IN R and the white plug to the white socket |
|
|
AUX/CDR IN L. |
|
2 |
Connect the other end of the cinch cable to the audio |
2 |
|
outputs of the additional appliance. |
|
3 |
Press AUX repeatedly to select the analogue input for the |
3 |
|
appliance. |
|
|
AUX ANALOG H: for standard level input sources |
|
|
AUX ANALOG L: for low level input sources (when |
|
|
sound of external source is too low compared to the |
|
|
internal tuner or CD changer) |
|
4 |
Operate your appliance as usual and adjust volume and |
1 |
|
sound with the set. |
|
|
It is not possible to connect a turntable directly to |
2 |
|
AUX/CDR IN L/R. If you wish to use a turntable |
|
|
with the set, you have to connect an amplifier to |
|
|
AUX/CDR IN L/R on the set.Then connect the |
|
|
turntable to the amplifier. |
|
LINE OUT L/R
You can use these outputs for playback or recording on any analogue audio equipment, e.g. amplifier or tape recorder.
Use a cinch cable to connect the analogue audio inputs of the additional appliance with LINE OUT L/R on the set and operate your appliance as usual.
DIGITAL IN
You can use this coaxial input for recordings from any digital audio equipment with a digital coaxial output e.g. CD player or DVD player.
Use a coaxial cable to connect the coaxial output of the additional appliance with DIGITAL IN on the set.
Press AUX repeatedly to select the digital input for the appliance.
AUX DIGITAL is displayed.
Operate your appliance as usual.
Connecting a subwoofer
A subwoofer can be used to enhance the bass performance of your set dramatically.
Use a cinch cable to connect the input of the subwoofer with SUBWOOFER OUT on the set.
Follow the instructions supplied with the subwoofer.
9
Controls and connections
* & ^% $ # @ ! 0 987 65
CD CHANGE
OPEN•CLOSE
STANDBY•ON
ECO POWER
DISPLAY
CDR
CD1 |
CD2 |
CD3 |
|
CLOCK•TIMER
SOURCE
TUNER
AUX
|
R |
L |
|
|
|
LINE |
|
|
|
OUT |
|
|
|
AUX/ |
|
|
|
CDR |
|
|
|
IN |
|
|
|
AM ANTENNA |
FM ANTENNA |
|
|
|
|
ON•OFF |
LEVEL |
|
|
|
|
SUBWOOFER |
|
|
|
OUT |
|
CD |
|
|
|
RECORDER |
|
|
|
CDR OPEN•CLOSE |
JOG |
|
|
CONTROL |
|
|
|
|
MASTER |
|
|
VOLUME |
|
COPY |
COMPILE |
|
CD |
|
|
|
CD |
|
RECORD |
|
|
|
MIC/ |
|
|
LEVEL |
FINALIZE |
CD |
ERASE |
|
||
|
|
MIC |
( ) ¡ ™£≤∞ § ≥ •ªº 1
43
DIGITAL
IN
AC
MAINS ~
VOLTAGE
SELECTOR
110V127V
220V240V
NOT FOR ALL
VERSIONS
2
On the back
1SPEAKERS 6 Ω L/R
connect to the supplied speakers
2VOLTAGE SELECTOR 110V–127V, 220V–240V
(Not on all versions.) Set this selector to the local mains voltage. Disconnect the mains lead before resetting this selector.
3AC MAINS ~
After all other connections have been made, connect the mains lead to the wall socket.
4DIGITAL IN
connect to the coaxial output of a digital appliance
5FM ANTENNA
connect the supplied wire antenna here
6AM ANTENNA
connect the supplied loop antenna here
7LINE OUT R/L
connect to the analogue audio input of an additional appliance
8AUX/CDR IN R/L
connect to the analogue audio output of an additional appliance
9SUBWOOFER OUT
connect to the input of a subwoofer
10
Controls and connections
On the front
0wOOx LEVEL
selects the desired wOOx level 1, 2 or 3
!wOOx ON·OFF
switches the wOOx effect on/off
@OPEN·CLOSE
opens/closes the CD changer drawer
#CLOCK·TIMER
selects the clock or timer functions
$ display
%DISPLAY
CDC, CDR: selects display information/text
^CD CHANGE
opens the CD changer drawer, rotates the tray once
&2 STANDBY·ON switches the set to standby
*ECO POWER
switches the set to eco-standby
(p
3.5 mm headphone socket
Note: Connecting the headphones will switch off the speakers.
)Source selection – SOURCE CDR
selects the CD recorder
CD1, CD2, CD3
selects the CD changer, switches to CD 1, CD 2 or CD 3
TUNER selects the tuner
AUX
selects the input for an additional appliance
¡Multiple function control – rotary control: í JOG CONTROL ë
selects the previous/next menu item CDC, CDR: selects the previous/next track
TUNER: selects the previous/next preset tuner station
Multiple function control – keys to press: à SEARCH
CDC, CDR: searches backward, reviews the tracks in a program
TUNER: tunes to a lower radio frequency
á SEARCH
CDC, CDR: searches forward, reviews the tracks in a program
TUNER: tunes to a higher radio frequency
YES/ENTER
confirms a selection
ÉÅ
starts/interrupts playback
REC LEVEL
activates the rotary control for record level adjustment
CD TEXT/EDIT
switches through CD text information, enters/exits the text edit menu
PROG
enters/exits the program menu
Ç
stops playback/recording
NO/CANCEL cancels a selection
™COPY CD
selects high speed recording and automatic finalizing of current CD
COMPILE CD
selects high speed recording and automatic finalizing of current program
£FINALIZE CD
finalizes/unfinalizes recordings
≤RECORD
enters the recording menu
∞ERASE CD
enters the erasing menu
§Sound control – rotary control: MASTER VOLUME
adjusts the volume
Sound control – keys to press: DSC
selects predefined sound settings
VAC
selects predefined surround sound settings
INCREDIBLE SURROUND creates an incredibly wide stereo effect
≥MIC
microphone socket
•MIC LEVEL
adjusts the microphone volume
ªCD RECORDER
CD recorder drawer
º/ CDR OPEN·CLOSE opens/closes the CD recorder drawer
English
11
English
Remote control
|
|
|
|
|
|
8 PROGRAM |
|
|
|
|
|
|
|
enters/exits the program menu |
|
|
CDR |
|
|
|
1 |
9 REPEAT |
|
|
|
|
|
|
repeats a track, an entire CD(RW) or a program |
||
|
|
|
|
|
|
||
|
CD1 |
CD2 |
CD3 |
TUNER |
2 |
0 SHUFFLE |
|
|
|
plays tracks in random order |
|||||
|
|
|
|
|
3 |
||
|
|
|
|
|
|
||
|
AUX |
|
SLEEP |
TIMER ON/OFF |
4 |
! DIM |
|
|
|
|
|
|
controls brightness of display |
||
|
|
|
|
|
5 |
||
6 |
TRACK INCR. |
CD TEXT/edit |
DISPLAY |
@ MUTE |
|||
|
|||||||
|
|
|
|
|
|
||
7 |
|
|
|
|
|
switches the sound off/on |
|
PROGRAM |
REPEAT |
SHUFFLE |
|
|
|||
|
0 |
# INCR. SURR. |
|||||
8 |
|
|
|
|
|||
|
|
|
|
! |
switches incredibly wide stereo effect on/off |
||
|
INCR.SURR. |
|
MUTE |
DIM |
|||
|
|
|
|||||
9 |
|
|
$ -VOLUME |
||||
|
|
|
|
@ |
|||
|
|
VOLUME |
|
decreases the volume |
|||
# |
|
|
|
|
% |
% +VOLUME |
|
$ |
|
|
|
|
increases the volume |
||
|
|
|
|
|
|||
* |
|
|
|
|
^ |
^ É |
|
|
|
|
|
& |
starts playback |
||
|
|
|
|
|
|
||
( |
|
|
|
|
|
& ë |
|
) |
|
|
|
|
¡ |
selects the next menu item |
|
|
|
|
|
CDC, CDR: selects the next track |
|||
|
NO |
PAUSE |
YES |
™ |
TUNER: selects the next preset tuner station |
||
|
|
|
|
|
|
||
≤ |
|
|
|
|
£ |
* í |
|
|
|
|
|
selects the previous menu item |
|||
|
|
|
|
|
|||
∞ |
WOOX |
|
|
WOOX |
|
CDC, CDR: selects the previous track |
|
|
|
§ |
TUNER: selects the previous preset tuner station |
||||
|
ON/OFF |
DSC |
VAC |
LEVEL |
|||
• |
|
|
|
|
≥ |
( Ç |
|
|
|
|
|
|
stops playback |
||
|
|
) à |
|
|
CDC, CDR: searches backward |
|
|
TUNER: tunes to a lower radio frequency |
|
|
¡ á |
|
|
CDC, CDR: searches forward |
|
Remote control keys |
|
|
TUNER: tunes to a higher radio frequency |
|
|
|
|
1 2 |
™ Å PAUSE |
|
|
switches the set to standby |
|
|
interrupts playback/recording |
|
|
|
|
2 CDR, CD1, CD2, CD3, TUNER, AUX |
£ YES |
|
select the sources |
||
confirms a selection |
||
|
||
3 SLEEP |
≤ NO |
|
activates the sleep timer |
||
cancels a selection |
||
|
||
4 TIMER ON/OFF |
∞ WOOX ON/OFF |
|
activates/deactivates the timer |
||
switches the wOOx effect on/off |
||
|
||
5 DISPLAY |
§ WOOX LEVEL |
|
selects display information/text |
||
selects the desired wOOx level 1, 2 or 3 |
||
|
||
6 CD TEXT/edit |
≥ VAC |
|
switches through CD text information, enters/exits the text |
||
selects predefined surround sound settings |
||
edit menu |
||
|
||
7 TRACK INCR. |
• DSC |
|
selects predefined sound settings |
||
selects automatic or manual increment of a track |
||
|
12
Remote control/Sound control
Remote control usage
Open the battery compartment of the remote control and insert 2 alkaline batteries, type AA (R06, UM-3).
Do not use old and new or different types of batteries in combination.
Remove batteries if they are empty or if the remote control will not be used for a long time.
Batteries contain chemical substances, so they should be disposed of properly.
The buttons on the remote control work the same way as the corresponding ones on the set.
Note: Always press the source key of the source you wish to
control (e.g. CD1) before selecting the desired function key (e.g. ÉÅ).
Sound control
MASTER
VOLUME
COMPILE |
|
|
CD |
CORD |
|
|
MIC/ |
|
LEVEL |
D |
ERASE |
|
|
|
MIC |
Volume adjustment
Adjust the volume by using MASTER VOLUME.The current volume level is displayed.
Incredible Surround
Stereo sound is determined by the distance between the front speakers. Incredible Surround enables you to enjoy an incredibly wide stereo effect, regardless of the speakers’ distance.
Press INCREDIBLE SURROUND to switch the surround sound effect either on or off.
INCREDIBLE SURROUND is displayed if the surround sound effect is on.
Note:The effect of Incredible Surround may vary with different types of music.
Optimal Sound
For optimal sound listening, you can adjust only one of the following sound controls at a time: DSC or VAC.
DSC
Digital Sound Control enables you to select predefined sound settings.
Press DSC repeatedly to select the desired sound setting.
Either DIGITAL, ROCK, POP, NEW AGE, CLASSIC or
ELECTRIC is displayed.
Note: For a neutral sound select CLASSIC.
VAC
Virtual Ambience Control enables you to select predefined surround sound settings.
Press VAC repeatedly to select the desired surround sound setting.
Either HALL, CINEMA, ARCADE, CONCERT, DISCO or
CYBER is displayed.
wOOx
ON•OFF |
LEVEL |
AUX
This feature enables you to select a deep and powerful bass.
Press wOOx ON·OFF repeatedly to switch the wOOx effect either on or off:
WOOX OFF: the wOOx effect is switched off.
WOOX LEVEL 1 (or 2, 3): the wOOx effect is switched on and the current level is displayed.
0To select another of the 3 possible wOOx levels press wOOx LEVEL repeatedly until the desired level is displayed:
Either WOOX LEVEL 1, WOOX LEVEL 2 or
WOOX LEVEL 3 is displayed.
MUTE
This feature allows you to temporarily switch off the sound without switching off the set.
1Press MUTE on the remote control to switch off the sound.
MUTE is displayed and playback/recording will be continued without sound.
2Press MUTE on the remote control again to switch on the
sound again.
English
13
English
Basic functions
CD CHANGE |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
OPEN•CLOSE |
|
STANDBY•ON |
|
|
|
|
|
|
|
|
ECO POWER |
|
|
|
|
|
|
|
|
DISPLAY |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
ON•OFF |
LEVEL |
|
|
|
|
|
CLOCK•TIMER |
|
|
|
CDR |
CD1 |
|
|
|
|
|
|
|
|
CD2 |
|
CD3 |
SOURCE |
|
|
|
|
|
|
|
TUNER |
AUX |
|
|||
|
|
|
|
|
|
|||
|
|
|
CD |
|
|
|
|
|
|
|
|
|
RECORDER |
|
|
|
|
|
|
|
|
|
|
|
CDR OPEN•CLOSE |
|
JOG |
|
|
|
|
|
|
|
|
CONTROL |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
MASTER |
|
|
|
|
|
|
|
|
VOLUME |
|
|
|
|
|
COPY |
COMPILE |
|
|
|
|
|
|
|
CD |
|
|
|
|
|
|
|
|
|
CD |
|
|
|
|
|
|
|
RECORD |
|
|
|
|
|
|
|
|
|
|
|
|
MIC/ |
|
|
|
|
|
|
|
|
LEVEL |
|
|
FINALIZE |
CD |
ERASE |
|
|
|
|
|
|
|
|
|
|
|
||
|
|
|
|
|
|
|
|
MIC |
Switching to standby
To switch the set on press 2STANDBY·ON on the set.
To switch the set to standby press 2 STANDBY·ON again.
The set is switched to standby and the time is displayed.
To switch the set to eco-standby press ECO POWER on the set (or 2 on the remote control for 3 seconds).
Demonstration mode
The demonstration mode displays various features of the set and will start automatically.
To cancel the demonstration mode keep Ç on the set pressed for at least 5 seconds.
The demo mode is cancelled permanently.The set
switches to standby.
Loading the CDC and CDR
Important!
1)This system is designed for regular CD(RW)s. Therefore, do not use any accessories such as disc stabilizer rings or CD treatment sheets, etc. as offered on the market, because they may cause jamming of the changer mechanism.
2)Do not load more than one disc into one disc
tray.
1CD changer: Press OPEN·CLOSE to open the CD changer drawer.
OPEN CHANGER is displayed, the drawer is opened and the tray rotates once.
CD recorder: Press / CDR OPEN·CLOSE to open the CD recorder drawer.
OPEN CDR is displayed and the drawer is opened.
Note: Opening the CD changer or CD recorder clears any program.
2CD changer: You can load up to 3 discs. Insert a disc (printed side up) in the right tray.
0 You can load another disc in the left tray.
0To insert a third disc press CD CHANGE on the set.The CD carousel will rotate once.
CD recorder: Insert a disc (printed side up) in the tray.
3CD changer: Press OPEN·CLOSE again to close the drawer.
The drawer is closed and READING is displayed.
CD, the disc tray number, the total number of tracks and the total playing time of the disc in the last selected tray are displayed.
CD recorder: Press / CDR OPEN·CLOSE to close the drawer.
The drawer is closed and READING is displayed.
If an unfinalized disc is loaded, INITIALIZING will be displayed.
CDR, the total number of tracks and the total playing time of the disc are displayed.
MP3-CD only:
READING MP3 is displayed. MP3 is shown.
The first album name is displayed.
14
DISPLAY |
|
|
|
|
|
|
|
|
|
|
|
|
|
ON•OFF |
LEVEL |
|
|
|
|
CLOCK•TIMER |
|
|
|
CDR |
CD1 |
|
|
|
|
|
|
|
CD2 |
CD3 |
SOURCE |
|
AUX |
|
|
|
|
TUNER |
|
CD |
|
|
|
RECORDER |
|
|
|
CDR OPEN•CLOSE |
JOG |
|
|
CONTROL |
|
|
|
|
MASTER |
|
|
VOLUME |
|
COPY |
COMPILE |
|
CD |
|
|
|
CD |
|
RECORD |
|
|
|
MIC/ |
|
|
LEVEL |
FINALIZE |
CD |
ERASE |
|
||
|
|
MIC |
Playback
1Press either CD1, CD2, CD3 or CDR to select a particular disc.
2Press ÉÅ to start playback.
CD1 (or 2,3) or CDR, the current track number and elapsed playing time are displayed.
0To switch through the following information press DISPLAY repeatedly on the set:
track number, remaining playing time of current track
track number, remaining playing time of disc
track number, actual playing time of current track
3Press Ç to stop playback.
CD1 (or 2,3) or CDR, the total number of tracks and the total playing time of the disc are displayed.
0You can interrupt playback by pressing ÉÅ.
The time where playback was interrupted blinks.
0To resume playback press ÉÅ again.
Selecting and searching
Selecting a track when playback is stopped (on all discs except MP3-CDs)
1Rotate í JOG CONTROL ë to skip to the desired track number.
2Press ÉÅ to start playback.
Playback starts with the selected track.
Selecting an album and/or a track when playback is stopped (on MP3-CDs only)
1Insert an MP3-CD (printed side up) in the CD changer or recorder.
READING MP3 is displayed. MP3 is shown.
The first album name is displayed.
Basic functions
2Rotate í JOG CONTROL ë to skip to the album number you wish to select.
ALBUM is shown and the album number is displayed.
3As soon as the desired album number is displayed, stop rotating í JOG CONTROL ë.
The album name is scrolled.
4If you want to start playback of the entire album:
Press ÉÅ.
Playback of the entire album starts.
If you want to enter the album:
Press YES.
Rotate í JOG CONTROL ë to skip to the track number you wish to select.
TRACK is shown and the track number is displayed.
As soon as the desired track number is displayed, stop rotating í JOG CONTROL ë.
The track name is scrolled.
Press ÉÅ to start playback.
Playback starts with the selected track.
To exit the album and to return to the album selection press NO.
Notes:
At the end of your album selection you will recognize an album called VARIOUS.This album contains all tracks which were not saved in an album when making the MP3-CD.
If you want to play a playlist which you created on your MP3-CD when making it, you have to select it directly by rotating í JOG CONTROL ë and pressing ÉÅ then.
Selecting a track during playback
Rotate í JOG CONTROL ë to skip to the beginning of the previous or next track on the selected disc.
Playback continues with the selected track.
Searching for a passage during playback
1Keep à SEARCH or á SEARCH pressed to find a particular passage in backward or forward direction.
Searching is started and playback continues at a low volume. After 5 seconds the search speeds up with volume muted.
2Release the key at the desired passage.
Normal playback continues.
English
15
English
Basic functions
SHUFFLE and REPEAT
Repeating a track, a disc or a program
1Press REPEAT repeatedly on the remote control during playback to select either:
REP TRACK:The current track is played repeatedly.
REP DISC:The entire selected disc is played repeatedly.
REP ALL: All discs in the set (or the program) are (is)
played repeatedly.
Notes:
REP DISC is not possible during SHUFFLE or while playing a program.
REP TRACK is not possible during SHUFFLE.
2 Playback starts in the chosen mode.
0To return to normal playback press REPEAT on the remote control until the display indication disappears.
Playing tracks in random order
Press SHUFFLE on the remote control during playback.
SHUFFLE is shown and either all tracks of the program or
of all loaded disc(s) in the CD changer and CD recorder are played in random order.
0To return to normal playback press SHUFFLE on the remote control again.
Microphone mixing
DISPLAY |
|
|
|
|
|
|
|
|
|
|
|
|
|
ON•OFF |
LEVEL |
|
|
|
|
CLOCK•TIMER |
|
|
|
CDR |
CD1 |
|
|
|
|
|
|
|
CD2 |
CD3 |
SOURCE |
|
|
|
|
|
|
TUNER |
AUX |
|
|||
|
|
|
|
|
CD |
|
|
|
RECORDER |
|
|
|
CDR OPEN•CLOSE |
JOG |
|
|
CONTROL |
|
|
|
|
MASTER |
|
|
VOLUME |
|
COPY |
COMPILE |
|
CD |
|
|
|
CD |
|
RECORD |
|
|
|
MIC/ |
|
|
LEVEL |
FINALIZE |
CD |
ERASE |
|
||
|
|
MIC |
1Set MIC LEVEL to the minimum level to prevent acoustic feedback (i.e. a loud howling sound) before you connect the microphone.
2Connect a microphone to MIC.
3Press CD1, CD2, CD3, CDR,TUNER or AUX to select the source you wish to mix the microphone with.
4Play the selected source.
5Adjust the volume by using MASTER VOLUME.
6Adjust the desired mixing level between source and microphone by turning MIC LEVEL.
7Start singing or talking through the microphone.
Note: Keep the microphone away from the speakers to prevent
a howling sound.
CD text display
JOG
CONTROL
COPY |
COMPILE |
||
CD |
|
||
|
|
|
CD |
|
RECORD |
|
|
FINALIZE |
|
CD |
ERASE |
|
|
|
|
This feature allows you to display information such as album title or track title contained on a specially encoded CD.
Make sure to insert a CD with CD text.
CD TEXT is shown and the album title and album artist’s
name is scrolled once.
CD text when playback is stopped
Press CD TEXT/EDIT to see the following information, which will be scrolled once (if available):
–Album artist’s name
–Album title
CD text during playback
Press CD TEXT/EDIT to see the following information, which will be scrolled once (if available):
–Track artist’s name
–Track title
ID3-tag
This feature allows you to display information such as album title or track title contained on an MP3-track.
If you created an ID3-tag on your MP3-CD, press
CD TEXT/EDIT during playback to show the following ID3-tag information:
Album title
Track artist’s name
Track title
16
Programming track numbers
DISPLAY |
|
|
|
|
|
|
|
|
|
|
|
|
|
ON•OFF |
LEVEL |
|
|
|
|
CLOCK•TIMER |
|
|
|
CDR |
CD1 |
|
|
|
|
|
|
|
CD2 |
CD3 |
SOURCE |
|
AUX |
|
|
|
|
TUNER |
|
||||
|
|
|
|
|
CD |
|
|
|
RECORDER |
|
|
|
CDR OPEN•CLOSE |
JOG |
|
|
CONTROL |
|
|
|
|
MASTER |
|
|
VOLUME |
|
COPY |
COMPILE |
|
CD |
|
|
|
CD |
|
RECORD |
|
|
|
MIC/ |
|
|
LEVEL |
FINALIZE |
CD |
ERASE |
|
||
|
|
MIC |
You can select up to 99 tracks and store them in the memory. It is possible to store any track more than once.
1Load the desired disc(s) in the disc tray(s).
2Press either CD1, CD2, CD3 or CDR to select a disc.
3Press PROG to enter the program menu.
PROG starts blinking and PROGRAM is displayed.
4Rotate í JOG CONTROL ë to select either:
CD1 (or 2, 3) and track number or CDR and track number:
The track number of CD1 (or 2, 3) or the track number of the disc in the CD recorder will be programmed.
or (for audio CD(RW)´s only):
CD1 (or 2, 3) ALL or CDR ALL:All tracks of CD1 (or 2, 3) or all tracks of the disc in the CD recorder will be programmed.
5Press YES to store your selection in the memory.
The number of programmed tracks (STEP), PROG and the total program time are displayed.
6Select and store all desired tracks in this way.
7Press PROG to end up programming.
PROG stays shown and the program is currently available.
Notes:
If you try to store more than 99 tracks, PROGRAM FULL will be displayed.
A program with MP3 tracks can only be created from one MP3-CD.
Program
Erasing a track from the program
1If necessary press Ç to stop playback.
2Press either CD1, CD2, CD3 or CDR to select a disc.
3Press PROG, followed by à SEARCH or á SEARCH to move through the program steps.
The track number at the selected step and the total program time are displayed.
4Press NO to remove the track from the program.
CLEARED is displayed briefly.
The next programmed track number will move up to this position and is displayed together with the step number and the remaining total program time.
Clearing the program
1If necessary press Ç to stop playback.
2Press NO.
CLEAR PROG? is displayed.
3Press YES to clear the program.
PROG CLEARED is displayed and PROG goes off.
Making a program for recording
1Select and store all desired tracks from the CD changer (see “Programming track numbers”).
2Enter the recording menu (see “Internal recording”).
0If the total time of the program is of bigger size than the remaining recording time of the CDR(W):
DOES NOT FIT will be displayed briefly, followed by the remaining recording time and RECORD PROG?.
If you nevertheless start recording, only those tracks of the program that fit onto the CDR(W) will be recorded in their entirety.
0To change the program press NO.
PROGRAM will be displayed briefly, PROG and the total playing time of the program will start blinking. Now you can change the program (see “Programming track numbers”,“Erasing a track from the program” and “Clearing the program”).
Note: If you try to use a program for recording which contains tracks from the CD changer and CD recorder 4 DISC PROG and CLEAR PROG? will be displayed. Press either NO to exit or YES to clear the current program and prepare a new one.
English
17
English
About recording
Basic information
The CD recorder deck offers you 3 main functions:
–Recording from the internal CD changer and tuner or from a selected external source
–Finalizing your CDR(W) discs and unfinalizing your CDRW discs
–Erasing a CDRW disc
The recording procedure is the same for CDR and CDRW discs. Make sure the CDR(W) is absolutely free of scratches and dust particles.
For recordings, the minimum track length is 4 seconds.You can record up to a maximum of 99 tracks on a disc.The minimum of recording time left on the disc is 7 seconds. Otherwise DISC FULL is displayed and you cannot enter the record mode.
Do not forget to finalize! Finalizing a CDR(W) disc is a simple procedure, necessary to:
–play a recorded CDR on a standard CD player, or
–play a recorded CDRW on a CDRW compatible
CD player and CD recorder.
Copyright protection
The Serial Copy Management System (SCMS) prevents the making of a digital copy from a digital copy.The system allows making a digital recording from the original, however, in some countries this may require the authorization of copyright holders.
When you try to record copy protected material from an external source, COPY PROTECT will be displayed. No further digital recording is possible then.
When you try to record copy protected material from the internal CD changer no digital recording is possible, however, the CD recorder will automatically switch to analogue recording. It is not possible to copy an MP3-CD.
Recording CD text
If the original CD has CD text, this text will be recorded automatically, provided that the CD text is not copy protected. In that case, recording of CD text will not be possible then and TEXT PROTECT will be displayed.
Direct Line Recording (DLR)
The CD recorder is equipped with the high-performance Direct Line Recording technique. It ensures a perfect recording of the source material, meaning a true “bit for bit” recording. DLR will not become active when ALC is being used or the record level is adjusted.
Auto Level Control (ALC)
Auto Level Control ensures that the tracks on the recorded disc have a similar volume level. At all times the already recorded tracks of the CDR(W) disc will be taken as reference for the volume level of the following recordings.
Auto level control becomes active, when:
–COMPILE CD is being used,
–a disc, a track or a track edit is being high speed recorded and the CDR(W) has recordings on it, or
–a program (consisting of more than one disc) from the CD changer is being high speed recorded.
Auto level control will not become active, when:
–using COPY CD,
–making recordings from the FM tuner,
–making recordings from an external source, or
–making normal recordings in listen mode.
Switching ALC permanently off
1If necessary, press Ç to stop playback.
2Press CDR to select the CD recorder.
3Press REC LEVEL to select:
ALC OFF: ALC is permanently switched off.
0To enable ALC press REC LEVEL again to select:ALC ON: ALC is enabled.
Adjusting the record level
DISPLAY |
|
|
|
|
|
|
|
|
|
|
|
|
|
ON•OFF |
LEVEL |
|
|
|
|
CLOCK•TIMER |
|
|
|
CDR |
CD1 |
|
|
|
|
|
|
|
CD2 |
CD3 |
SOURCE |
|
|
|
|
|
|
TUNER |
AUX |
|
CD |
|
|
|
RECORDER |
|
|
|
CDR OPEN•CLOSE |
JOG |
|
|
CONTROL |
|
|
|
|
MASTER |
|
|
VOLUME |
|
COPY |
COMPILE |
|
CD |
|
|
|
CD |
|
RECORD |
|
|
|
MIC/ |
|
|
LEVEL |
FINALIZE |
CD |
ERASE |
|
||
|
|
MIC |
You can adjust the reference record level for recordings from the internal CD changer or from an additional appliance.This is also possible when ALC is active.This feature can be used for fading your recordings in or out. However, adjusting the record level from the CD changer only works during recording.
1Press CD1, CD2 or CD3 during recording to select the CD changer, or press AUX repeatedly to select the input of the additional appliance:
AUX DIGITAL: the digital input is selected.
AUX ANALOG H: the analogue input for a standard level source is selected.
AUX ANALOG L: the analogue input for a low level source is selected.
2Press REC LEVEL on the set to enable the rotary control to adjust the desired record level.
3Turn the rotary control to the left to adjust the desired record level.The loudest sounds in the material to be recorded should not reach the red levels of the level bar.
The actual record level (in dB) will be displayed.
18
For internal recordings you can record from the internal CD changer or tuner.
Recording a single track
CON JOG
TROL
|
COPY |
COMPILE |
||
|
CD |
|
||
|
|
|
CD |
|
|
|
|
|
|
|
|
RECORD |
|
|
FINALIZE |
|
|
CD |
ERASE |
|
|
|
||
Recording a single track during playback
1Insert a CDR(W) which is absolutely free of scratches and dust particles in the CD recorder tray.
2Play your desired track on the CD changer.
3Press RECORD on the set to enter the recording menu.
REC TR and the tracknumber are displayed.
4Press either:
YES to start recording,
The arrow lights, RECORDING IN SESSION is shown, playback and recording start from the beginning of the selected track and the actual recording time left starts to count down.
or
NO to continue playback.
Recording an entire CD
DISPLAY |
|
|
|
|
|
|
|
|
|
|
|
|
|
ON•OFF |
LEVEL |
|
|
|
|
CLOCK•TIMER |
|
|
|
CDR |
CD1 |
|
|
|
|
|
|
|
CD2 |
CD3 |
SOURCE |
|
|
|
|
|
|
TUNER |
AUX |
|
CD |
|
|
|
RECORDER |
|
|
|
CDR OPEN•CLOSE |
JOG |
|
|
CONTROL |
|
|
|
|
MASTER |
|
|
VOLUME |
|
COPY |
COMPILE |
|
CD |
|
|
|
CD |
|
RECORD |
|
|
|
MIC/ |
|
|
LEVEL |
FINALIZE |
CD |
ERASE |
|
||
|
|
MIC |
High speed recording and automatic finalizing of the current disc
1Insert a CDR(W) which is absolutely free of scratches and dust particles in the CD recorder tray.
2Press either CD1, CD2 or CD3 to select the disc you wish to copy.
3Press COPY CD on the set to enter the recording menu.
The arrow starts blinking.The remaining recording time of the CDR(W), the total playing time of the source CD
and RECORD CD1 (or 2, 3)? are displayed.
Internal recording
4Press YES to start recording and finalizing.
The arrow lights, RECORDING IN SESSION is shown, high speed recording at a low volume and finalizing start and the actual recording time left starts to count down.
Note: If a program was already available before pressing COPY CD, this will be ignored. PROG goes off and the current disc will be recorded. After finishing the recording, PROG is shown and the program is available again.
Recording a program
JOG |
|
|
CON |
|
|
TROL |
|
|
COPY |
COMPILE |
|
CD |
||
|
|
CD |
RECORD |
|
|
FINALIZE |
CD |
ERASE |
|
||
High speed recording and automatic finalizing
(optional) of the current program
1Insert a CDR(W) which is absolutely free of scratches and dust particles in the CD recorder tray.
2Press COMPILE CD on the set to enter the recording menu.
The arrow starts blinking.The remaining recording time of the CDR(W), the total playing time of the source CD and RECORD PROG? are displayed.
Note: If no program is available and you press COMPILE CD, you will enter immediately the program menu. Start your programming and return to the recording menu by pressing
PROG or COMPILE CD.
3Press either: YES to confirm, or
NO to change the program.
PROG starts blinking. Now you can change the program
(see “Program”) and return to the recording menu by pressing COMPILE CD.
4AUTO FINAL? is displayed. Press either:
YES, if the CDR(W) is to be finalized after recording, or
NO, if the CDR(W) is not to be finalized after recording.
The arrow lights, RECORDING IN SESSION is shown, high speed recording and finalizing (if selected) start and the
actual recording time left starts to count down.
English
19
English
Internal recording
Recording from the tuner
DISPLAY |
|
|
|
|
|
|
|
|
|
|
|
|
|
ON•OFF |
LEVEL |
|
|
|
|
CLOCK•TIMER |
|
|
|
CDR |
CD1 |
|
|
|
|
|
|
|
CD2 |
CD3 |
SOURCE |
|
AUX |
|
|
|
|
TUNER |
|
||||
|
|
|
|
|
CD |
|
|
|
RECORDER |
|
|
|
CDR OPEN•CLOSE |
JOG |
|
|
CONTROL |
|
|
|
|
MASTER |
|
|
VOLUME |
|
COPY |
COMPILE |
|
CD |
|
|
|
CD |
|
RECORD |
|
|
|
MIC/ |
|
|
LEVEL |
FINALIZE |
CD |
ERASE |
|
||
|
|
MIC |
1Insert a CDR(W) which is absolutely free of scratches and dust particles in the CD recorder tray.
2Press TUNER repeatedly to select the FM tuner.Then select the desired radio station (see “Tuning to radio stations”).
3Press RECORD on the set to enter the recording menu.
REC FM TUNER is displayed.
4Press YES to confirm.
PREPARING and RECORD? are displayed.
5Press YES to start recording.
The arrow lights, RECORDING IN SESSION is shown, recording starts and the actual recording time left starts to count down.
6Press Ç to stop recording.
Further recording possibilities
High speed recording of an entire disc, a track or a program
1Insert a CDR(W) which is absolutely free of scratches and dust particles in the CD recorder tray.
2Press either CD1, CD2 or CD3 to select the disc you wish to record from.
3Press RECORD on the set to enter the recording menu.
4Rotate í JOG CONTROL ë to select one of the following high speed recording modes:
If a disc from the CD changer is selected:
REC CD1 (or 2,3) FAST?: for high speed recording of CD1 (or 2, 3)
Continue with step 5.
REC TR FAST?: for high speed recording of a track Press YES to confirm.
Rotate íJOG CONTROL ëto select the desired track.
REC TR and the track number is displayed. Continue with step 6.
If a program is available:
PROG FAST?: for high speed recording of the program
5Press YES to confirm your selection.
The arrow starts blinking.The remaining recording time of the CDR(W), the total recording time of the CDR(W) and RECORD? are displayed.
Note: If the CDR(W) already contains a recording, ALC will also become active.
6Press YES to start high speed recording.
The arrow lights, RECORDING IN SESSION is shown, high speed recording starts and the actual recording time left starts to count down.
0To stop recording press Ç on the set.
Normal recording while listening to an entire disc, a track or a program
1Insert a CDR(W) which is absolutely free of scratches and dust particles in the CD recorder tray.
2Press either CD1, CD2 or CD3 to select the disc you wish to record from.
3Press RECORD on the set to enter the recording menu.
4Rotate í JOG CONTROL ë to select one of the following normal recording modes:
If CD changer is selected:
RECORD CD1 (or 2,3)?: for listening to CD1 (or 2, 3) during normal recording
REC TRACK?: for listening to the track during normal recording
Press YES to confirm.
Rotate íJOG CONTROL ëto select the desired track.REC TR and the track number are displayed.
Press YES to start normal recording.
If a program is available:
REC PROG?: for listening to the program during normal recording
5Press YES to confirm your selection.
The arrow starts blinking.The remaining recording time of the CDR(W), the total recording time of the CDR(W) and RECORD? are displayed.
6Press YES to start normal recording.
The arrow lights, RECORDING IN SESSION is shown, normal recording starts and the actual recording time left starts to count down.
0To stop recording press Ç on the set.
Do not forget to finalize! Finalizing a CDR(W) disc is a simple procedure, necessary to:
–play a recorded CDR on a standard CD player, or
–play a recorded CDRW on a CDRW compatible CD player and CD recorder.
20
External recording
Analogue or digital recording?
When making recordings from an external source, we recommend doing analogue recording only if digital recording is not possible. Digital recording will usually result in better sound quality.
Automatic track increment
When the digital input for recording from a digital source (e.g. CD player) is used, tracks will be incremented automatically such that the track numbers are positioned on the same position as on the original.When the analogue input for recording from a digital or analogue source is used, track increment will not take place automatically unless one of the following settings is selected.Track increments may not always be positioned correctly, depending on the quality of the source material.
Press TRACK INCR. as often as necessary on the remote control during stop to switch through the following automatic track increment functions:
MANUAL: for switching the function off
TURNTABLE: for optimal recording from noisy sources like turntables (It is not possible to connect a turntable directly to AUX/CDR IN L/R – see “Analogue audio connections”.)
TAPE/TUNER: for optimal recording from a tape
CD/DVD: for optimal recording from high quality sources like DAT, DCC or DVD
Notes:
Track numbers can be incremented manually by pressing TRACK INCR. on the remote control during recording.The minimum track length is 4 seconds.
Track numbers cannot be changed after recording.
Recording with automatic start
Recording of an entire disc or a track
1Insert a CDR(W) which is absolutely free of scratches and dust particles in the CD recorder tray.
2Press AUX repeatedly to select the input for the external source you want to record from.
AUX DIGITAL: the digital input is selected.
AUX ANALOG H: the analogue input for a standard level source is selected.
AUX ANALOG L: the analogue input for a low level source is selected.
3Press RECORD on the set to enter the recording menu.
4Rotate í JOG CONTROL ë to select either:
AUX CD?: for recording with synchronised start of an entire disc
AUX TRACK?: for recording with synchronised start of a single track
5Press YES to confirm your selection.
PRESS PLAY ON EXTERNAL SOURCE is scrolled.
6Start playback on the external source you want to record from.The CD recorder starts to record simultaneously and
RECORDING IN SESSION is shown.The remaining recording time on the CDR(W) is displayed.
Note: If you start playback on the selected source within a track, recording will start at the beginning of the next track.
7If a digital source is selected:
After the recording process, the CD recorder stops automatically.
Note: Recordings from DAT, DCC or DVD will automatically stop after 20 seconds of silence.
If an analogue source is selected:
At the end of the recording process, the CD recorder stops after a silence of 20 seconds on the source material.
To stop recording manually press Ç on the set.
RECORDING IN SESSION goes off.
Manual recording
Recording from an external source
1Insert a CDR(W) which is absolutely free of scratches and dust particles in the CD recorder tray.
2Press repeatedly AUX to select the input for the external source you want to record from.
AUX DIGITAL: the digital input is selected.
AUX ANALOG H: the analogue input for a standard level source is selected.
AUX ANALOG L: the analogue input for a low level source is selected.
3Press RECORD on the set to enter the recording menu.
4Rotate íJOG CONTROL ëto select the type of recording:
AUX MANUAL?: for manual start of recording
5Press YES to confirm your selection.
PREPARING is displayed.
RECORD?, AUX and the remaining recording time of the CDR(W) are displayed.
6Start playback on the external source in order to set the optimal recording level on the CD recorder (see “Adjusting the record level”).
7Stop playback on the external source.
8Go to the beginning of the desired track.
9Press YES on the set and simultaneously start playback on the external source.
The CD recorder starts to record and RECORDING IN SESSION is shown.The remaining recording time of the CDR(W) is displayed.
Note: If CHECK INPUT is flashing, check the digital connection.
10Press Ç on the set to stop recording.
UPDATE is displayed and RECORDING IN SESSION goes off.
English
English
External recording
Recording the microphone
DISPLAY |
|
|
|
|
|
|
|
|
|
|
|
|
|
ON•OFF |
LEVEL |
|
|
|
|
CLOCK•TIMER |
|
|
|
CDR |
CD1 |
|
|
|
|
|
|
|
CD2 |
CD3 |
SOURCE |
|
AUX |
|
|
|
|
|
TUNER |
|
CD |
|
|
|
RECORDER |
|
|
|
CDR OPEN•CLOSE |
JOG |
|
|
CONTROL |
|
|
|
|
MASTER |
|
|
VOLUME |
|
COPY |
COMPILE |
|
CD |
|
|
|
CD |
|
RECORD |
|
|
|
MIC/ |
|
|
LEVEL |
FINALIZE |
CD |
ERASE |
|
||
|
|
MIC |
1Insert a CDR(W) which is absolutely free of scratches and dust particles in the CD recorder tray.
2Set MIC LEVEL to the minimum level to prevent acoustic feedback (i.e. a loud howling sound) before you connect the microphone.
3Connect a microphone to MIC.
4Press AUX repeatedly to select any external source you like.
AUX DIGITAL is displayed if the digital input is selected.
AUX ANALOG H is displayed if the analogue input for a standard level source is selected.
AUX ANALOG L is displayed if the analogue input for a low level source is selected.
5Press RECORD on the set to enter the recording menu.
6Rotate í JOG CONTROL ë to select MIC ONLY.
The microphone will be recorded.
7Press YES to confirm your selection.
PREPARING is displayed.
RECORD?, AUX and the remaining recording time of the CDR(W) are displayed.
8Set the optimal recording level on the CD recorder (see “Adjusting the record level”).
0In addition you can also set the optimal recording level of the microphone by turning MIC LEVEL.
9Press YES on the set to start recording.
The CD recorder starts to record and RECORDING IN SESSION is shown.The remaining recording time of the CDR(W) is displayed.
10Press Ç on the set to stop recording.
UPDATE is displayed and RECORDING IN SESSION goes off.
22
DISPLAY |
|
|
|
|
|
|
|
|
|
|
|
|
|
ON•OFF |
LEVEL |
|
|
|
|
CLOCK•TIMER |
|
|
|
CDR |
CD1 |
|
|
|
|
|
|
|
CD2 |
CD3 |
SOURCE |
|
AUX |
|
|
|
|
TUNER |
|
CD |
|
|
|
RECORDER |
|
|
|
CDR OPEN•CLOSE |
JOG |
|
|
CONTROL |
|
|
|
|
MASTER |
|
|
VOLUME |
|
COPY |
COMPILE |
|
CD |
|
|
|
CD |
|
RECORD |
|
|
|
MIC/ |
|
|
LEVEL |
FINALIZE |
CD |
ERASE |
|
||
|
|
MIC |
Finalizing CDR(W) discs
Finalizing a CDR(W) disc is a simple procedure, necessary to:
–play a recorded CDR on a standard CD player,
–play a recorded CDRW on a CDRW compatible CD player and CD recorder,
–avoid further unwanted recordings on a disc, or
–avoid accidental erasure of tracks on a CDRW.
Notes:
Finalizing will take about 2 minutes.
During finalization no other operating commands can be executed.
After finalization of the CDR(W), CDRW changes to CD on the display.
Auto finalizing
When using either COPY CD or COMPILE CD, your recordings will be finalized automatically (see “High speed recording and automatic finalizing”).
Manual finalizing when recording is in progress
1Press FINALIZE CD on the set during recording.
AUTO FINAL? is displayed.
2Press YES to confirm.
FINALIZE is shown.The finalization will start after recording and the actual finalizing time remaining will start to count down.
Manual finalizing when recording is stopped
1Insert the CDR(W) you want to finalize in the CD recorder tray.
2Press CDR to select the CD recorder.
3Press FINALIZE CD on the set.
FINALIZE? is displayed.
4Press YES to start finalizing.
FINALIZE is shown. FINAL is displayed and the actual finalizing time remaining starts to count down.
(Un)finalizing, erasing
Unfinalizing CDRW discs
If you want to record (or erase) on (from) a finalized CDRW, you have to unfinalize it first.
Notes:
Unfinalizing will take approximately 2 minutes.
After unfinalizing of the CDRW, CD changes to CDRW on the display.
1Insert the CDRW you want to unfinalize in the CD recorder tray.
2Press CDR to select the CD recorder.
3Press FINALIZE CD on the set.
UNFINALIZE? is displayed.
4Press YES to start unfinalizing.
UNFINAL is displayed and the operation time remaining starts to count down.
Erasing from a CDRW disc
It is possible to erase one or more tracks (starting from the end of the last track) or the entire CDRW.
Erasing an entire CDRW
1Insert the CDRW you want to erase in the CD recorder tray.
2Press CDR to select the CD recorder.
3Press ERASE CD to enter the erasing menu.
4Rotate í JOG CONTROL ë to select:
ERASE DISC?: for erasing the entire disc
5Press YES to confirm your selection.
ERASE? is displayed.
6Press YES to start erasing.
ERASE is displayed and the operation time left starts to count down.
Erasing one or more tracks
1Follow steps 1–3 of “Erasing an entire CDRW”.
2Rotate í JOG CONTROL ë to select the track number(s) you wish to erase.
ERASE and the track number (e.g. 10+)? are displayed.
0To select more tracks to be erased repeat step 2.
Note:When erasing several tracks, the tracks to be erased must be selected in sequence, starting from the last recorded track. Example:The CDRW has 5 tracks recorded on it. Now, you can erase tracks 5 and 4.You can also erase tracks 5, 4 and 3, but you cannot erase tracks 5 and 3!
3Press YES to confirm your selection.
ERASE? is displayed.
4Press YES to start erasing.
ERASE is displayed and the operation time left starts to count down.
English
23
English
Features
DISPLAY |
|
|
|
|
|
|
|
|
|
|
|
|
|
ON•OFF |
LEVEL |
|
|
|
|
CLOCK•TIMER |
|
|
|
CDR |
CD1 |
|
|
|
|
|
|
|
CD2 |
CD3 |
SOURCE |
|
AUX |
|
|
|
|
TUNER |
|
CD |
|
|
|
RECORDER |
|
|
|
CDR OPEN•CLOSE |
JOG |
|
|
CONTROL |
|
|
|
|
MASTER |
|
|
VOLUME |
|
COPY |
COMPILE |
|
CD |
|
|
|
CD |
|
RECORD |
|
|
|
MIC/ |
|
|
LEVEL |
FINALIZE |
CD |
ERASE |
|
||
|
|
MIC |
CD text editing (on CD recorder only)
Storing text during stop mode
After you have recorded your CDR(W) you can enter a text, e.g. names to discs and tracks.This text will be displayed during playback on this set, but also on other sets equipped with the CD text feature.You can enter up to 60 characters per text field. Only use an unfinalized CDR or CDRW (finalized CDRW must be unfinalized first).
1If necessary press Ç to stop playback.
2Press CDR to select the CD recorder.
3Press CD TEXT/EDIT to enter the text edit menu.
CD TEXT EDIT is blinking. TEXT EDIT is displayed.
4Rotate í JOG CONTROL ë to select either:
ALBUM ARTIST: for editing the CD artist
ALBUM TITLE: for editing the CD title
ARTIST TR |
1 (or 2, 3,…): for editing the artist of track |
1 (or 2, 3,…) |
|
TITLE TR 1 (or 2, 3,…): for editing the title of track 1 (or 2, 3,…)
5Press YES to confirm the selection.
6Rotate í JOG CONTROL ë to select a character.
After selecting a character, the cursor moves automatically to the next character space.
7Repeat step 6 for adding further characters.
8Press YES to save the characters that have been selected and to exit to the last position in the text editing menu.
UPDATE is displayed.
Auto copied text
When an artist’s name has been stored for a track, it will be copied automatically into the next track.
Press either:
YES to confirm the copied text, or
NO to delete the copied text and to enter a new one.
Inserting a space
1Press à SEARCH or á SEARCH to move to the position where the space is to be inserted.
The position starts blinking.
2Press YES to confirm the position of the insert character.
A space will be inserted after the cursor.
Deleting and substituting a character
1Press à SEARCH or á SEARCH to move to the character’s position to be deleted or substituted.
The character starts blinking.
2If you want to delete the character:
Press NO.
The character is deleted and the text is shifted one position to the left.
If you want to substitute the character:
Rotate í JOG CONTROL ë to select a new character.
0To change another character press à SEARCH or á SEARCH.
Erasing text
1Press CD TEXT/EDIT to enter the text edit menu.
CD TEXT EDIT is blinking. TEXT EDIT is displayed.
2Rotate íJOG CONTROL ëto select the text erase menu:
ERASE TEXT is displayed.
3Press YES to confirm.
4Rotate í JOG CONTROL ë to select one of the following:
ALL TEXT CD: All text of the selected disc is chosen to
be erased in one step.
ALL TEXT TR1 (or 2, 3,…): All text of track 1 (or 2, 3,…) is chosen to be erased.
CD TITLE: CD artist’s name and CD title are chosen to be erased.
5Press YES to start erasing.
The chosen text will be erased.
Erasing from the memory
When the text memory of your CD recorder is almost full, the messages MEMORY FULL and FINALIZE DISC will be displayed. If you still want to add a new disc to the text memory, you have to finalize another disc.
24
Loading...
