Philips FW-C577/30, FW-C577/21, FW-C577/19 User Manual

Mini Hi-Fi System

FW-

C577

FW-

C577

visit our website

www.audio.philips.com

to download latest UPDATES of USB PC Link Driver

MusicMatch Jukebox softwares and FAQs.

1

México

Es necesario que lea cuidadosamente su instructivo de manejo.

PRECAUCIÓN - ADVERTENCIA

No abrir, riesgo de choque eléctrico

Verifique que el voltaje de alimentación

sea el requerido para su aparato

Para evitar el riesgo de choque eléctrico, no quite la tapa.

En caso de requerir servicio, dirijase al personal calificado.

Descripción: Minisistema de Audio
Modelo : FW-C577/21
Alimentación: 110–127 / 220–240V~; 50–60 Hz
Consumo: 175 W
Importador: Philips Mexicana, S.A. de C.V.
Domicilio: Av. La Palma No. 6

Localidad y Tel: Edo. de México C.P. 52784

Exportador: Philips Electronics HK, Ltd.
País de Origen: China
Nº de Serie: ______________________________

ATENCIÓN

Col. San Fernando La Herradura
Huixquilucan

Tel. [phone]

LEA CUIDADOSAMENTE ESTE INSTRUCTIVO

ANTES DE USAR SU APARATO.

AVISO IMPORTANTE

Philips Mexicana, S.A. de C.V.no se hace

responsable por daños o desperfectos causados por:

– Maltrato, descuido o mal uso, presencia de

insectos o roedores (cucarachas, ratones etc.).

– Cuando el aparato no haya sido operarado

de acuerdo con el instructivo del uso, fuera
de los valores nominales y tolerancias de las
tensiones (voltaje), frecuencia (ciclaje) de
alimentación eléctrica y las características
que deben reunir las instalaciones auxiliares.

– Por fenómenos naturales tales como:

temblores, inundaciones, incendios, descargas
eléctricas, rayos etc. o delitos causados por
terceros (choques asaltos, riñas, etc.).

2

CAUTION

Use of controls or adjustments
or performance of procedures
other than herein may result in
hazardous radiation exposure
or other unsafe operation.

D

ISC 5

DISC 1

DISC 2

DISC 3

DISC 4

DISC

DISC

DISC

D

ISC

DISC

CD

CD-R

CD-R

W

OMP

TIBLE

IR

DSC

DBB

TUNER

GAME

UX

USB

PC LINK

MODE

GAMESOUND

MA

X

SOUND

DSC

P1

D

I

SC

1

D

ISC

2

D

I

SC

3

D

ISC

4

D

ISC

D
ISC

D

ISC

D

ISC

D

ISC

C

D

C

D

-R

C

D

-R

W

C

O

M

P

TI

B

L

E

D

IS

C 1

CD TUNER

USB PC LINK

CD1 CD2 CD3

CD4 CD5

VOL

TITLE

ALBUM

REPEAT PROGRAM SHUFFLE DISPLAY

DIM SLEEP CLK/TIMER TIMER

DSC MUTEVAC

GAME

GAME

MIX-ITSOUND

P3

AUX/GAME

➠

ON/OFF

MAX ON/OFF

☞

P4

P2

2

C

D

/

C

D

-

R

/

C

D

-

R

W

C

O

M

P

AT

I

B

L

D

I

S

C

1

D

I

S

C

2

D

I

S

C

3

D

I

S

C

4

D

I

S

C

5

D

I

S

C

1

D

I

S

C

2

D

I

S

C

3

D

D

I

I

S

S

C

C

4

C

D

/C

D

-

R

/C

D

-

R

W

CO

M

P

AT

I

B

L

E

D

I

S

C

1

D

I

S

C
2

D

I

S

C

3

D

I

S

C

4

D

I

S

C

5

1

C

S

I

D

2

I

S

D

C

3

C

S

I

D

4

I

D

C

S

5

I

D

C

S

S

T

M

E

S

Y

I

N

M

I

T

R

P

O

ME

A

G

R

I

S

E

N

S

O

R

O

E

C

R

E

W

O

P

L

L

E

E

N

N

N

N

A

Y

B

D

N

A

T

S

A

H

H

C

C

T

T

H

N

O

F

G

E

I

L

R

D

D

R

R

R

R

I

I

V

V

E

E

E

E

V

V

O

O

D

S

C

1
D
C

L

A

M

I

T

P

O

Z

Z

A

J

K

C

O

R

P

O

P
M

I

D

S

W

E

N

P

E

E

L

S

2

D

B

L

A

X

I

M

M

F

W

M

E

L

T

I

T

M

A

M

P

C

C

D

3

F

U

H

S

C

G

O

R

P

P

E

R

K

R

T

C

S

I

D

L

L

A

D

4

C

C

.

.

T

T

T

T

R

R

S

I

E

E

R

E

B

Y

C

L

L

A

H

O

O

O

O

U

U

U

U

U

U

S

S

I

I

B

B

B

B

R

R

R

R

T

R

E

C

N

O

C

E

D

A

C

R

A

A

M

E

N

I

C

C
D
5

VAC

D

I

M

K

O

C

L

C

•

M

T

I

R

E

O

R

P

G

S

B

U

E

M

U

L

CD

T

U

R

E

N

L

P

C

K

N

I

G

M

A

E

•

AU

X

O

V

N

R

E

X

E

T

T

•

T

E

P

S

S

R

E

E

A

R

S

P

E

•

M

T

V

E

R

P

P

O

T

B

B

D

D

S

C

VAC

S

P

L

O

A

Y

M

E

•

D

P

•

A

P

U

S

O

E

T

S

M

A

X

S

O

U

N

D

S

G

E

N

A

I

R

N

C

U

T

H

•

O

E

D

I

V

E

M

U

L

X

M

I

-

T

I

O

V

E

M

A

G

L

E

F

O

T

I

D

U

A

G

A

M

E

S

O

U

N

D

R

S

P

E

E

D

I

P

U

N

C

H
B

L

A

S

T

G

H

T

O

I

E

D

O

M

D

U

A

M

X

A

S

U

O

D

N
D

A

G

I

L

S

T

I

U

O

D

N

•

C

O

T

N

R

L

O
V

R

I

A

T

L

A

U

M

I

B

N

E

C

O

E

T

C

N

R

O

L

•

D

Y

A

N

M

C

I

A

B

S

S

B

O

O

S

T

1 3

,

1

E

3

3

4

Index

English ------------------------------------------------ 6

Français -------------------------------------------- 27

Español --------------------------------------------- 48

-------------------------------------------------------- 69

English

Français

Español

Energy Star

As an ENERGY STARR Partner,
Philips has determined that this
product meets the ENERGY
STARR guidelines for energy efficiency.

5

Contents

English

General Information

Supplied accessories ............................................ 7

Environmental information ................................ 7

Care and safety information .............................. 7

Functional Overview

Main unit and remote control ....................... 8–9

Control buttons available on the

remote only ........................................................ 9

Connections

Step 1: Connecting FM/AM antennas ............ 11

Step 2: Connecting the speakers .................... 11

Step 3: Connecting to PC ................................. 11

Step 4: Connecting to game console ............. 11

Step 5: Connecting the AC power cord........ 12

Step 6: Inserting batteries into the remote

control .................................................................. 12

Using the remote control to operate

the system ........................................................ 12

Gameport Operations

About Gameport ............................................... 13

Preparation before use ..................................... 13

Start operating .................................................... 13

USB PC Link

Quick Setup Guide ............................................ 14

PC system requirement ................................. 14

Install MusicMatch software ......................... 14

Enable digital CD audio output ................... 15

Connecting USB PC Link ................................. 15

Disc Operations

Playable discs ....................................................... 18

Loading discs ....................................................... 18

Basic playback controls .............................. 18–19

Repeat and Shuffle .............................................. 19

Repeat play ....................................................... 19

Random play ..................................................... 19

Programming the disc tracks ........................... 19

Checking the programme ............................. 20

Playing a disc without clearing the

programme ....................................................... 20

Clearing the programme ............................... 20

Tuner Operations

Tuning to radio stations .................................... 21

Presetting radio stations ................................... 21

Using the Plug and Play .................................. 21

Automatic presetting ..................................... 21

Manual presetting ............................................ 21

Selecting a preset radio station ....................... 21

Deleting a preset radio station .................... 21

Changing tuning grid .......................................... 22

Timer Operations

Timer setting ....................................................... 23

Activating/Deactivating the timer ............... 23

Sleep timer setting ............................................. 24

Other Connection

Listening to an external source ...................... 24

Specifications ........................................... 25

Basic Operations

Switching on/off ................................................. 16

Switching to active mode .............................. 16

Switching to Eco Power standby mode ..... 16

Switching to standby mode (view clock) ... 16

Demonstration mode ........................................ 16

Setting the clock ................................................. 16

Dimming system’s display screen .................... 17

Volume control ................................................... 17

Sound control ..................................................... 17

MAX sound ...................................................... 17

Digital Sound Control .................................... 17

Virtual Ambience Control ............................. 17

Dynamic Bass Boost ....................................... 17

6

Troubleshooting .................................... 26

General Information

Refer to the type plate on the rear or
bottom of the system for identification
and supply ratings.

Supplied accessories (page 3 – P1)

– USB PC LINK software installer CD-ROM
– USB cable
– Remote control and two AA batteries.
– AM loop antenna
– FM wire antenna
– Video cinch cable (yellow)
– Mains plug adaptor (for version /21 only)
– AC power cord

Environmental information

All unnecessary packaging has been omitted.
We have tried to make the packaging easy to
separate into three materials: cardboard (box),
polystyrene foam (buffer) and polyethylene
(bags, protective foam sheet).

Your system consists of materials which can be
recycled and reused if disassembled by a
specialised company. Please observe the local
regulations regarding the disposal of packaging
materials, exhausted batteries and old
equipment.

Care and safety information

(page 3 – P2)

Avoid high temperatures, moisture,
water and dust

– Do not expose the system, batteries or discs
to humidity, rain, sand or excessive heat (caused
by heating equipment or direct sunlight). Always
keep the disc tray closed to avoid dust on the
lens.

Avoid condensation problem

– The lens may cloud over when the system is
suddenly moved from cold to warm
surroundings, making it impossible to play a disc.
Leave the system in the warm environment until
the moisture evaporates.

Do not block the vents

– In a cabinet, allows about 10cm (4 inches) of
free space all around the system for adequate
ventilation.

Care of disc

– To clean a CD, wipe it in a straight line from
the centre towards the edge using a soft, lint-free
cloth. A cleaning agent may damage the disc!
– Write only on the printed side of a CDR(W)
and only with a soft felt-tipped pen.
– Handle the disc by its edge, do not touch the
surface.

Care of the cabinet

– Use a soft cloth slightly moistened with a mild
detergent solution. Do not use a solution
containing alcohol, spirits, ammonia or abrasives.

Finding a suitable location

– Place the system on a flat, hard, and stable
surface.

Built-in safety circuit

– Under extreme conditions, this system may
switch to standby mode automatically. If this
happens, let the system cool down before
reusing it.

Power saving

– This system is designed to use less than 1W
of electricity when switches to Eco Power
standby. Disconnect the AC power cord from
the power outlet when not in use.

English

7

CD

CD-R

CD-RW

COMP

TIBLE

IR

DSC

AC

#
$

∞

Functional Overview

English

≤

/C

D

-

R

/

AT

I

B

L

E

£

™

¡

)
(

*

&

6

*
7

8
9

0

§
(
5
≥
&

#

CD TUNER

REPEAT PROGRAM SHUFFLE DISPLAY

USB PC LINK

CD1 CD2 CD3

CD4 CD5

VOL

TITLE

ALBUM

DIM SLEEP CLK/TIMER TIMER

DSC MUTEVAC

GAME

GAME

MIX-ITSOUND

AUX/GAME

MAX ON/OFF

¤

⁄
º

ON/OFF

ª
4
!

•
@

^

1
2

3

4

5
6

7
8

9
0
!
@

STANDBY

D

I

M MODE

M

E

C

D

C

D

-

R

W

CO

M

D

IS

C

1

D

ISC

2

D

IS

C

3

D

ISC

4

D

IS

C

5

D

I

S

C

1

D

I

S

C

2

D

I

S

C

3

D

I

S

C

4

D

I

S

C

T

IMER

CD

P

L

A

Y

•

P

A

U

S

E

SPEED

N

D

•

D

IG

I

AMB

I

E

N

C

L

C

DB

B

PUNCH

T

AL

SOU

N

D

C

ON

T

R

E C

ON

TROL• D

Y

5

GAMEPORT

MINI SYSTEM

L

E

N

N

A

H

C

T

F

E

D

R

R

I

E

V

V

E

O

T

T

R

E

O

O

U

U

U

S

I

B

B

R

R

U

SB

TUNE

R A

P

C

LINK

D

S

C

MAX SOUND

MIX-IT

BL

AS

T

MODE

OL
N

AMIC B

AS

S

B

O

O

ST

H

G

I

R

C

R

U

P

R

OG

UX

•GAME

A

M

VAC

ECO
POW

E

R

O

N

DSC

CD1

O

PT

I

M

A

LJAZ

ZROCKP

O

P

DI

M

NE

W

S

S

L

E

E

P

A

L

BMIX

F

MMW

T

I

T

L

E

AM P

M

CD2

CD

3

CD4

R

OGSHU F

R

E

P

TRKP

D

I

SC A L

L

.

.

I

S

CYB

E

R

HA

L

L

CONCERT

A

R

CA

DE CI

NEM

A

CD5

VAC

C

L

OCK•

N

E

T

X

E

T

S

•

E

P

R

R

P

•

V

E

R

P

P

O

T

S

O

D

•

P

O

T

S

E

S

E

T

G

S

E

N

I

A

N

R

U

C

T

H

•

MAX

SOU

V

IRTUAL

P

I

R

S
E

N

S
O

R

L

E

N

N

A

H

C

T

D

R

R

I

E

V

V

E

O

T

T

E

O

O

U

U

S

I

B

B

R

R

V

O

R

L

E

U

T

S

M

E

O

E

D

I

V

.

L

O

I

D

U

A

.

R

O

I

D

U

A

%

Main unit and remote control

6 CD / TUNER / USB PC LINK /

AUX•GAME

1 ECO POWER indicator

– Lights up when the system is in Eco Power

standby mode.

2 STANDBY ON B

– Switches to Eco Power standby mode or turns

on the system.

– *Switches to standby mode.

3 Display screen

4 CLOCK • TIMER (CLK/TIMER)

– *Enters clock or timer setting mode.

5 DIM MODE (DIM)

– Turns on/off the dim mode.

– Selects the relevant active mode.
– CD: toggles between DISC 1~5.
– TUNER: toggles between FM and MW band.
– AUX • GAME: toggles between AUX and

GAMEPORT mode.

7 PREV•PRESET 4 (í) /

NEXT•PRESET 3 (ë)

– CD: selects a track.
– TUNER: selects a preset r adio station.
– CLOCK: sets the minutes.
– USB PC LINK: selects a track from the playlist.

8 STOP• DEMO STOP Ç

– Exits an operation.
– CD: stops playback or clears a programme.
– TUNER: *erases a preset radio station.
– USB PC LINK: stops playback.

(only on the main unit)

– *Turns on/off the demonstration mode.

* = Press and hold the button for more than two seconds.

8

Functional Overview

9 PLAY•PAUSE ÉÅ

– CD: star ts / pauses playback.
– USB PC LINK: star ts / pauses playback.

(only on the main unit)

TUNER: *enters Plug & Play mode and / or star ts
preset radio station installation.

0 SEARCH•TUNING (à á)

– CD: *searches backward / forward.
– TUNER: tunes the radio frequency up/ down.
– CLOCK: sets the hours.
– USB PC LINK: *searches backward / forward.

! MAX SOUND (MAX ON / OFF)

– Turns on/off the optimal mix of various sound

features.

@ MIX IT (GAME MIX IT)

– Mixes the game sound with your favourite music

from one of these music source (CD, TUNER,
USB PC LINK or AUX).

# MODE (GAME SOUND)

– Selects different type of equaliser setting for

Gameport (SPEED, PUNCH or BLAST).

$ Connect the USB cable between the system and

PC’s USB port.

% GAME VOLUME

– Adjusts the game’s output volume level.

^ VIDEO

– Use a video cable to connect to your game

console’s video output.

AUDIO L. / AUDIO R.

– Use a audio cable to connect to your game

console’s left/ right audio output.

& DBB

– Selects different type of bass boost level settings

(DBB 1, DBB 2, DBB 3 or DBB OFF).

DSC

– Selects different type of preset sound equaliser

settings (OPTIMAL, JAZZ, ROCK or POP).

VAC

– Selects different type of environment ambience-

based equaliser settings (HALL, CINEMA,
CONCERT, CYBER or ARCADE).

* MASTER VOLUME (VOL +-)

– Adjusts the volume level.

( PROG (PROGRAM)

– CD: starts or confirms tracks programming.
– TUNER: starts *automatic /manual preset

programming.

– CLOCK: selects 12- or 24-hour clock display.

) n

– Plug in the headphones jack. The speakers

output will be cancelled.

¡ VU meters

– Indicates signal strength of left/right channel.

™ iR SENSOR

– Point the remote control towards this sensor.

£ Disc trays (1~5)

≤ OPEN • CLOSE 0 (DISC 1~5)

– Opens/closes the individual disc tray.

Control buttons available on the
remote only

∞ CD 1~5

– Selects a disc tray to playback.

§ REPEAT

– Repeats a track / disc / all discs / all programmed

tracks.

≥ SLEEP

– Sets the sleep timer function.

• MUTE

– Mutes or restores the volume.

ª TIMER ON / OFF

– Turns on/ off the timer function.

º SHUFFLE

– Turns on/ off the random play mode.

⁄ DISPLAY

– Displays disc remaining playback time.

¤ B

– Switches to Eco Power standby mode.
– *Switches to standby mode.

English

* = Press and hold the button for more than two seconds.

9

Connections

English

VOLTAGE
SELECTOR

110V­127V

220V­240V

10

Game console

Connections

WARNING!

– Please note that the voltage selector
located at the rear of this system is
preset at 220V from the factory. For
countries that operate at 110V-127V,
please adjust to 110V-127V before you
switch on the system.
– Use only the supplied speakers. The
combination of the main unit and
speakers provide the best sound. Using
other speakers can damage the unit and
sound quality will be negatively affected.
– Never make or change connections
with the power switched on.
– Connect the AC power cord to the
power outlet only after you have finished
hooking up everything.

Step 1: Connecting FM/ AM

antennas

– Place the AM loop antenna on a shelf or
attach it to a stand or wall.
– Extend the FM antenna and fix its ends to the
wall.
– Adjust the position of the antennas for
optimal reception.
– Position the antennas as far as possible from a
TV, VCR or other radiation source to prevent
unwanted noise.
– For better FM stereo reception, connect
external FM antenna.

Step 2: Connecting the

speakers

Connect the speaker wires to the SPEAKERS
terminals, right speaker to "R" and left speaker to
"L", coloured (marked) wire to "+" and black
(unmarked) wire to "-". Fully insert the
stripped portion of the speaker wire into the
terminal as shown.

Notes:
– Ensure that the speaker cables are correctly
connected. Improper connections may damage the
system due to short-circuit.
– Do not connect more than one speaker to any
one pair of +/- speaker terminals.

Step 3: Connecting to PC

Use the supplied USB cable to connect the
system to your personal computer’s USB port.
After installed the USB PC LINK application
software onto your PC, you are able to playback
your music collection via the system (refer to
“USB PC Link”).

Step 4: Connecting to game

console

IMPORTANT!

Gameport inputs are solely for game
console only.

a. Use the game console’s video cable (not

supplied) to connect its video output to the
GAMEPORT-VIDEO terminal.

b. Use the game console’s audio cables (not

supplied) to connect its audio outputs to the
GAMEPORT-AUDIO L. / AUDIO R.
terminals.

c. Use a video cable (yellow) to connect the

VIDEO OUT terminal to the video input on
the TV for viewing.

Notes:
– On the TV, the Video Input jack is usually yellow
and might be labeled A/ V In, CVBS, Composite or
Baseband.
– To avoid magnetic interference, do not position
the front speakers too close to your TV.

Helpful Hint:

For optimal enjoyment of your Gaming
Experience, it is advisable that you avoid
connecting the TV’s AUDIO OUT to the audio
system’s AUX IN (R/L) terminals.

If you wish to listen to your favorite movies/TV
programmes through the Philips Mini System,
please disconnect the Game Console
connection on the front of the set to avoid
experiencing any unwanted noise.

English

11

Connections

English

Step 5: Connecting the AC

power cord

"AUTO INSTALL – PRESS PLAY" may appear
on the display panel when the AC power cord is
plugged into the power outlet for the first time.
Press ÉÅ on the main unit to store all available
radio stations (page 3 – P3) or press Ç to exit
(refer to “Tuner Operations”).

Step 6: Inserting batteries into

the remote control

3

1

2

1 Open the battery compar tment cover.
2 Inser t two batteries type R06 or AA, following

the indications (+-) inside the
compartment.

3 Close the cover.

Using the remote control to operate
the system

1 Aim the remote control directly at the

remote sensor (iR) on the main unit.

2 Select the source you wish to control by

pressing one of the source select keys on the
remote control (for example CD, TUNER).

3 Then select the desired function (for example

í,

ÉÅ,

ë).

CAUTION!

– Remove batteries if they are exhausted
or will not be used for a long time.
– Do not use old and new or different
types of batteries in combination.
– Batteries contain chemical substances,
so they should be disposed of properly.

12

Gameport Operations

MO

DE

G

AM

E

SOUN

D

GAM

E

A

U

X

About Gameport

Gameport allows you to connect your game
console to this mini system which enables you to
enjoy a total game immersion experience by
having powerful sound output.

Preparation before use

rear panel

2

3

1

G

AME

•A
U

5

7

6

X

O

E

D

I

V

E

M

U

L

O

V

E

M

A

.

L

G

O

I

D

U

A

M

IX

-

I

T

GA

ME SOUND

.

S

R

P

E

E

D

P

U

O

N

C

H

B

L

A

ST

I

D

U

M

O

D

E

A

front panel

Game console

1 Connect your game console’s video and audio

output to the GAMEPORT video and audio
inputs respectively (refer to “Connections –
Connecting to game console).

2 Connect your TV’s video input to the VIDEO

OUT (CVBS) on the rear panel.

3 Connect all the AC power cord to the power

outlet.

Start operating

4 Turn on the TV and set to the correct

video-in channel.

The TV’s video input channel may be called
AUX(iliary) IN, AUDIO/VIDEO (A/V) IN, EXT 1,
etc. These channels are often near channel 00
on your TV. Or, your TV remote control may
have a button or switch that chooses different
video modes. See your TV manual for details.

5 Press AUX•GAME until “GAMEPORT” is

displayed.

6 Press MODE (or GAME SOUND on

remote) to select the type of sound setting
that best suit the game : SPEED, PUNCH,
BLAST or OFF.

7 If you like to mix your game sound to your

favourite music, press MIX-IT to select the
desired music source : CD, TUNER,
USB PC LINK, AUX or OFF.

CD ™ “MIX-CD"
TUNER ™ “MIX-TU"
USB PC LINK ™ “MIX-USB"
AUX ™ “MIX-AUX"
OFF ™ “MIX-OFF"

8 If necessar y, start playback your chosen mixer

source.

9 Star t playing your favourite game.

To adjust the game console’s volume
level

● Adjust GAME VOLUME.

To change the mixer source

● Press MIX-IT.

To control the current active mixer
source

● Press the respective source button (for

example, CD, TUNER) on the remote control,
then select the desired function (for example

í,

ë).

É,

For example, if CD is the mixer source and to
change the disc tray, you have to press CD, then
press CD 1~5 to select the desired disc tray.

Notes:
– You can only activate GAME VOLUME and
MIX-IT while in game source mode.
– If your game console is switched on, the video
image will always appear on the TV even though
you are not in the gameport mode.

English

13

USB PC Link

English

Quick Setup Guide

PC system requirement

– Windows 98 (SE)/ ME /2000 /XP
– Intel Pentium MMX200 or higher
– CD-ROM drive
– USB port
– Free hard disk space : 15 MB for the

software

Install MusicMatch software

1

P
O
W
E
R

O
N
/
O
F

F

3

1 Use the supplied USB cable to connect the

audio system to your personal computer’s
USB port.

2 Press USB PC LINK.
3 Turn on the PC and insert the USB PC LINK

installer disc (which comes with this product)
onto the PC’s CD-ROM drive.

This application software can also be downloaded
from “http://www.audio.philips.com”.

IMPORTANT!

Please use this customised MusicMatch
software for your USB PC Link
application. Remember to un-install all
other MusicMatch jukebox software first
from your PC system (if available).

4 The installation guide will appear automatically. If

it does not, go to the CD-ROM drive in
Windows Explorer and double click on the
“USBPCLINK.exe”. Then perform the following
steps:
– First, select your desired language from the list.
– Then, select “installer driver” and follow by

“installer MusicMatch jukebox”.

– Select other options (Tutorial, Free goodies,

FAQ).

Note:
– You are advised to read the MusicMatch tutorial
before using it for the first time. Make sure the
mute function on the PC is deactivated in order to
ensure sound output from the Audio System.
For optimum performance, the equaliser function in
MusicMatch should be set to a low level.

2

5

5 Launch the “MUSICMATCH JUKEBOX” and

choose to do one of the followings :

To create a “Playlist”

Select “Open” button on the MusicMatch
Jukebox and simply drag/drop the music tracks
from anywhere on your PC into the “Playlist”
window. Remember to save this “Playlist” for
future use.

To create a music library

A music library of all stored music files available
on your PC can be setup by simply select “add”
function on the MusicMatch Jukebox.
Once created, you may then choose to drag /
drop any music tracks from this library to a
“Playlist” for music playback.

Note:
– It is not possible to create a playlist from the
system’s 5 CD changer. If you encounter problem
using USB PC LINK, please refer to the FAQ
(Frequently Asked Questions) stored in your USB PC
LINK installer disc or visit “www.audio.philips.com”
for latest update on FAQ.

14

USB PC Link

Enable digital CD audio output

Before playing the CD through your PC’s
CD-ROM drive, it is necessary to configure your
PC’s hardware as follows:

For Windows ME / 2000/ XP

1 Enter the system control panel menu and

select :
“SYSTEM ™ HARDWARE ™
DEVICE MANAGER ™ CD-ROM DRIVES ™
ACTION–PROPERTIES ™ PROPERTIES”.

OR

For Windows 98 (SE)

Enter the system control panel menu and
select “MULTIMEDIA” and “CD MUSIC”.

2 Check the ‘Enable digital CD audio for this

CD-ROM device’ setting option is selected
(enabled).

Note:
– You may need to refer to your PC’s manual for
correct configuration.

Connecting to USB PC LINK

USB PC LINK allows you to playback your music
collection from the PC via the powerful amplifier
and speakers of this system.

IMPORTANT!

Make sure the MusicMatch software has
been installed. Refer to “Quick Setup
Guide” for USB PC Link.

USB PC LINK

VOL

TITLE

ALBUM

REPEAT SHUFFLE

ON/OFF

1

DIM SLEEP CLK/TIMER TIMER

1 Turn on your computer and launch the

“MUSICMATCH JUKEBOX”.

➜ The volume level of PC should not be put

into mute.

2 Press USB PC LINK.

➜ If the audio streaming is detected,

“CONNECTING” is displayed and the USB
indicator will be flashing.

➜ If “NO CONNECTION” is displayed, check the

connection between your PC and mini system.

3 Press í or ë until the desired track in the

playlist is highlighted.

4 Press ÉÅ to start playback.

➜ The track information will appear on the

display. The display only supports English
characters.

During playback,
– Press SHUFFLE to play all available tracks in
the playlist in random order.
– Press REPEAT to repeat playback of all the
tracks in the playlist.

5 To exit, select another active mode or

press Ç.

English

2

3

4

5

15

Basic Operations

CLK/TIMER

(00:00 î 12:00AM)

(

00

:00 / 12:00AM)

(00:

00

/ 12:00AM)

5

4

3

1 2

,

6

,

2

English

Switching on/off

Switching to active mode

● Press CD, TUNER, USB PC LINK or

AUX•GAME.

Switching to Eco Power standby mode

● Press B.

➜ ECO POWER button lights up.
➜ The display screen will go blank.

Switching to standby mode (view
clock)

● Press and hold B.

➜ The clock is displayed.
➜ While in standby mode, pressing

CLOCK•TIMER button will switch the system to
Eco Power standby mode.

Note:
– Before switching the system to Eco Power
standby or standby mode, make sure the
demonstration mode has been deactivated.

Demonstration mode

If the demonstration mode is active, whenever
you switch the system to Eco Power standby or
standby mode, it will begin showing the various
features offered by the system.

To activate the demonstration

● In Eco Power standby/standby mode,

press and hold Ç on the main unit until
"DEMO ON" is displayed.

To deactivate the demonstration

● Press and hold Ç on the main unit until

"DEMO OFF" is displayed.

Setting the clock

The clock can be set in either 12-hour or
24-hour mode ("11:59 PM" or "23:59" for
example).

1 Press and hold CLK /TIMER (or

CLOCK•TIMER on main unit) until

"SELECT CLOCK OR TIMER" is displayed.

2 Press ë to change the display to "CLOCK"

and press CLK / TIMER (CLOCK•TIMER)
again to confirm.

3 Press PROGRAM (PROG) repeatedly to

change between 12-hour and 24-hour clock
mode.

4 Press à or á repeatedly to set the hour.
5 Press í or ë repeatedly to set the minute.
6 Press CLK / TIMER (CLOCK •TIMER) to

store the setting.

➜ The clock will start working.

To view the clock time in any active
mode

● Press CLK / TIMER (CLOCK• TIMER)

once.

➜ The clock is displayed for a few seconds.

Notes:
– The clock setting will be erased when the system
is disconnected from the power supply.
– The system will exit clock setting mode if no
button is pressed within 90 seconds.

16

Basic Operations

Dimming system’s display screen

You can select the desired brightness for the
display panel.

● In any active mode, press DIM MODE (or

DIM on remote) repeatedly to turn on/ off

dim mode.

➜ DIM is shown, except for DIM OFF mode.

Volume control

● Adjust MASTER VOLUME (or press

VOL +/- on remote) to increase or

decrease the sound level.

➜ "VOL MIN" is the minimum volume level and

"VOL MAX" is the maximum volume level.

To switch off the volume temporarily

● Press MUTE on the remote.

➜ Playback will continue without sound and

"MUTE" is displayed.

➜ To restore the volume, press MUTE again or

increase the volume level.

Sound control

MAX sound, DSC and VAC sound features
cannot be activated on the same time.
While in game mode, all the sound control
features are not available for selection, except
DBB and Game Sound control.

MAX sound

MAX sound provides the best mixture of
various sound features (DSC, VAC for example).

● Press MAX SOUND (or MAX ON/OFF

on remote).

➜ If activated, the MAX SOUND button lights

up. All other sound effects (DSC, VAC or DBB)
will be switched off automatically

Digital Sound Control

DSC provides a different type of preset sound
equaliser setting.

● Press DSC repeatedly to select : OPTIMAL,

JAZZ, ROCK or POP.

Virtual Ambience Control

VAC provides a different type of environment­based equaliser setting.

● Press VAC repeatedly to select : HALL,

CINEMA, CONCERT, CYBER or ARCADE.

English

Dynamic Bass Boost

DBB enhances the bass response.

● Press DBB repeatedly to select : DBB 1,

DBB 2, DBB 3 or DBB OFF.

➜ Some discs might be recorded in high

modulation, which causes a distortion at high
volume. If this occurs, switch off DBB or reduce
the volume.

Automatic DSC-DBB and VAC-DBB
selection

The best DBB setting is generated automatically
for each DSC, VAC or Game Sound selection.
You can manually select the DBB setting that
best suits your listening environment.

17

Disc Operations

English

IMPORTANT!

– This system is designed for regular
discs. Therefore, do not use any
accessories such as disc stabiliser rings or
disc treatment sheets, etc., as offered on
the market, because they may jam the
changer mechanism.
– Do not load more than one disc onto
each tray.

Playable discs

This system is able to play :
– All pre-recorded audio CDs
– All finalised audio CDR and audio CDRW

discs

Loading discs (page 3 – P4)

1 Press OPEN • CLOSE 0 DISC 1 button

on top of the main unit to open disc tray 1.

2 Load a disc with the label side facing up. For

double-sided discs, load the side you want to
play facing up.

3 Press OPEN • CLOSE 0 DISC 1 button

again to close the disc tray.

➜ “READING“ is displayed. The selected disc

tray, total number of tracks and the playing time
will appear on the display.

4 Repeat steps 1~3 for loading discs onto the

disc trays 2~5.

Notes:
– To ensure good system performance, wait until
the disc trays completely read the disc(s) before
proceeding.
– Only one tray can be opened at each time. If
you open the second tray before closing the first
tray, the first tray will automatically close before the
second tray opens.

Basic playback controls

Load discs (page 3 – P4)

To play all discs on the disc trays

● Press ÉÅ.

OR

In stop mode, press CD to select a disc tray
to begin, then press ÉÅ.

➜ All the available discs will play once, then stop.

To play the selected disc only

● Press one of the CD 1~5 on remote.

➜ The selected disc will play once, then stop.

To select a desired track

● Press í or ë repeatedly until the desired

track is displayed.

➜ To skip to the beginning of the current track

during playback, press í once.

➜ During random play (shuffle mode),

pressingí will cause the player to skip only to
the beginning of the current track.

To search for a particular passage
during playback

● Press and hold à or á and release it when

the desired passage is located.

➜ During searching, the volume will be reduced.

To replace discs without interrupting
playback

● Press OPEN•CLOSE 0 buttons of the

inactive disc trays (refer to “Loading discs”).

For example, if currently disc tray 1 is playing,
you can replace the discs on disc tray 2~5.

To check the disc remaining playing
time

● Press DISPLAY on the remote.

➜ During random play or programme play, the

total remaining time will not be shown.

➜ To restore the display for elapsed playing

time, repeat the above.

18

D

I

S

C

1

D

I

SC

1

D

I

S

C

2

D

I

SC

2

D

I

S

C

3

D

I

SC

3

D

I

S

C

4

D

I

SC

4

D

I

S

C

D

ISC

3

D

I

S

C

D

ISC

4

D

I

S

C

D

I

S

C

5

D

I

S

C

D

IS

C

2

D

I

S

C

D

ISC

1

CDC

D

/

C

D

-

R

C

D

-R

/

C

D

-

R

W

C

D

-R

W

C

O

M

P

C

O

M

P

AT

I

B

L

E

TI

B

L

E

D

IS

C

1

DISC

1

3

4

6

7

2 5

,

1

Disc Operations

To interrupt playback

● Press ÉÅ.

➜ To resume normal playback, repeat the

above.

To stop playback

● Press Ç.

➜ If the system remains in stop mode for 30

minutes, it will switch to Eco Power standby
mode.

Repeat and Shuffle

You can select and change the various play
modes before or during playback.

Repeat play

1 Press REPEAT on the remote repeatedly to

select :

D
E

A
B
C

A – to repeat playback of the current track.
B – to repeat playback of the current disc.
C – to repeat playback of all available discs.
D – to repeat playback of the current

programmed track (only if the programme
mode is active)

E – to repeat playback of all the programmed

tracks (only if the programme mode is
active)

2 To resume normal playback, press REPEAT

until "OFF" is displayed.

Random play

● Press SHUFFLE on the remote to turn

on/off the shuffling mode.

➜ If activated, SHUF is shown and the repeat

mode (if any) will be cancelled.

➜ All the available discs or programmed tracks

(if programme is active) will be played in random
order.

Note:
– Pressing the OPEN•CLOSE button will cancel all
repeat and shuffling modes.

Programming the disc tracks

Programming tracks is possible when playback is
stopped. Up to 40 tracks can be stored in the
memory in any order.

1 Load the desired discs on the disc trays (refer

to “Loading discs”).

2 Press PROGRAM (PROG) to start

programming.

➜ PROG starts flashing.

3 Press CD or one of the CD 1~5 buttons to

select a disc.

4 Press í or ë repeatedly to select the

desired track.

5 Press PROGRAM (PROG) to store.

● Repeat steps 3–5 to select other discs and

store the tracks.

➜ Skip step 3 if you are selecting tracks from

the same disc.

➜ If you attempt to programme more than 40

tracks, "PROGRAM FULL" is displayed.

6 To start programme play, press ÉÅ.
7 To stop playback or to end the programming,

press Ç once.

➜ PROG stays and the programme mode

remains active.

Notes:
– If the total playing time reached 100 minutes or
if one of the programmed tracks has a number
greater than 30, then "--:--" is displayed instead
of the total playing time.
– The system will exit programming mode if no
button is pressed within 20 seconds.

English

19

Disc Operations

English

Checking the programme

1 Stop playback and press í or ë repeatedly.
2 Press Ç to exit.

OR

Press ÉÅ to start playback from the current
programmed track

Playing a disc without clearing the
programme

● Press one of the CD 1~5 buttons on the

remote to select a disc for playback.

➜ After the selected disc has been played, the

programme mode will resume.

Clearing the programme

● Stop playback, then press Ç to clear the

programme.

OR

Press the OPEN• CLOSE 0 button of the
programmed disc tray.

➜ PROG disappears and "PROGRAM CLEARED"

is displayed.

Note:
– The programme will be erased if the system is
disconnected from the power supply.

20

Tuner Operations

IMPORTANT!
Make sure the FM and MW antennas are
connected.

Tuning to radio stations

1 Press TUNER to enter tuner mode.

To select another waveband (FM or MW),
press TUNER again.

2 Press and hold à or á until the frequency

indication starts to change, then release.

➜ The system automatically tunes to the next

strong signal radio reception.

➜ lights up for FM stereo reception.

For tuning to a weak signal station,

● Press à or á briefly and repeatedly until an

optimal reception is found.

Presetting radio stations

You can store up to 40 preset radio stations in
the memory, starting from FM and followed by
MW bands.

Notes:
– The system will exit presetting mode if no button
is pressed within 20 seconds.
– If no stereo frequency is detected during Plug
and Play, "CHECK ANTENNA" is displayed.

Automatic presetting

You can start the automatic presetting from a
selected preset number.

1 In tuner mode, press í or ë to select a

preset number.

2 Press and hold PROGRAM (PROG) until

"AUTO" is displayed.

➜ If a radio station has been stored in one of

the presets, it will not be stored again under
another preset number.

➜ If no preset number is selected, automatic

preset will begin from preset (1) and all your
former presets will be overridden.

Manual presetting

You can choose to store only the favourite radio
stations.

1 Tune to your desired radio station (refer to

“Tuning to radio stations”).

2 Press PROGRAM (PROG).

➜ The preset number starts flashing. If you want

to store the radio station in another preset
number, press í or ë.

3 Press PROGRAM (PROG) again to store.

● Repeat steps 1–3 to store other radio

stations.

English

Using the Plug and Play (page 3 - P3)

Plug and Play allows you to store all available
radio stations automatically.

1 Connect the system to the power supply,

"AUTO INSTALL - PRESS PLAY" is
displayed.

OR

In Eco Power standby/ standby mode,

press and hold ÉÅ on the main unit until
"AUTO INSTALL - PRESS PLAY" is
displayed.

2 Press ÉÅ on the main unit to start

installation.

➜ "INSTALL TUNER" is displayed.
➜ All previously stored radio stations will be

replaced.

➜ Once completed, the last tuned radio station

will be played.

Selecting a preset radio station

● In tuner mode, press í or ë.

➜ The preset number, radio frequency, and

waveband are displayed.

Deleting a preset radio station

● Press and hold Ç until “PRESET DELETED”

is displayed.

➜ The current preset radio station will be

deleted.

➜ All other preset radio stations with higher

numbers are decreased by one.

21

Tuner Operations

English

Changing tuning grid (not available for

all versions)

In North and South America, the frequency step
between adjacent channels in the MW band is
10 kHz (9 kHz in some areas). The preset
frequency step in the factory is 9 kHz.

IMPORTANT!

Changing the tuning grid will erase all
previously stored preset radio stations.

➠

1

➠

2

➠

➠

1 Disconnect the system from the AC power

supply (pull out the AC power cord).

2 While holding down TUNER and á on the

main unit, reconnect the system to the AC
power supply.

➜ The display will show "GRID 9" or

"GRID 10".

2

Notes:
– GRID 9 and GRID 10 indicate that the tuning
grid is in step of 9 kHz and 10 kHz respectively.
– The FM tuning grid also will be changed from
50 kHz to 100 kHz or vice versa.

22

Timer Operations

Timer setting

The system can switch on to CD, TUNER or
USB PC LINK mode automatically at a preset
time, serving as an alarm to wake you up.

IMPORTANT!

– Before setting the timer, ensure that
the clock is set correctly.
– The volume of the timer will increase
gradually to the last tuned volume level.
If the last tuned volume level is too low,
the set will then increase to a
predetermined minimum audible level.

3

(CD / TUNER / USB PC LINK)

4

(00:

00 / 12:00AM)

4

(00:00 / 12:00AM)

CLK/TIMER TIMER ON/OFF

2

1 2

,

5

,

1 Press and hold CLK / TIMER (or

CLOCK•TIMER on main unit) until

"SELECT CLOCK OR TIMER" is displayed.

2 Press ë to change the display to "TIMER"

and press CLK/ TIMER again to confirm.

3 Press CD or TUNER or USB PC LINK to

select the wake-up source.

CD ™ “CD XX:XX"
TUNER ™ “TU XX:XX”
USB PC LINK ™ “USB XX:XX”

4 Press à or á (for hours) and í or ë

(for minutes) repeatedly to set the wake up
time.

5 Press CLK / TIMER to store the setting.

➜ The timer will always be switched on after it

has been set.

➜ icon remains on the display. It indicates the

timer is activated.

● At the preset time, the selected sound

source will be played for 30 minutes
before it switches to Eco Power standby
mode (if no button is being pressed within the
time frame).

➜ CD – playing the first track of the last

selected disc or programmed track (if
programme mode is active). If the last selected
disc tray is empty, it will switch to the next
available disc. If all the disc trays are not
available, it will switch to Tuner mode.

➜ TUNER – playing the last tuned radio station.
➜ USB PC LINK – playing the last selected

playlist. If the connection fails, it will switch to
Tuner mode. Refer to “USB PC Link” for proper
connection and setup before use.

Activating/Deactivating the timer

● Press TIMER ON/OFF on the remote to

turn off the timer or turn on to the last
setting again.

➜ If activated, the timer information will display

for a few seconds, then the system resumes to
the last active source or stays in standby mode.

➜ If deactivated, “OFF” is displayed.

Note:
– The system will exit timer setting mode if no
button is pressed within 90 seconds.

English

23

Timer Operations Other Connection

L

R

AUDIO OUT

LR

AUX

IN

PLAY

VOL

ALBUM

TITLE

USB PC LINK

CD TUNER

AUX/GAME

CD1 CD2 CD3

CD4 CD5

AUX/GAME

AUX

➠

1

3

2

English

Sleep timer setting

The sleep timer enables the system to switch to
Eco Power standby mode automatically at a
preset time.

1 Press SLEEP repeatedly until it reaches the

desired preset turn-off time.

➜ The selections are as follows (time in

minutes):

15 ™ 30 ™ 45 ™ 60 ™ 90 ™ 120 ™
OFF ™ 15 …

➜ SLEEP is shown, except for "OFF" mode.
➜ To view or change the setting, repeat the

above.

2 Before the system switches to Eco Power

standby mode, a countdown of 10 seconds is
displayed.

"SLEEP 10" ™ "SLEEP 9".... ™ "SLEEP 1"

™ "SLEEP"

To cancel the sleep timer function

● Press SLEEP repeatedly until "OFF" is

displayed, or press the STANDBY ON B
button.

Listening to an external source

You can listen to the sound of the connected
external device through your system’s speakers.

1 Use the red / white audio cables to connect

the system’s AUX IN (R/ L) terminals to the
AUDIO OUT terminals on the other
audio/ visual device (such as a TV, VCR, Laser
Disc player, DVD player or CD recorder)

➜ If the connecting device has only a a single

audio out terminal, connect it to the AUX IN left
terminal. Alternatively, you can use a “single to
double” cinch cable, but the output sounds still
remain mono.

2 Press AUX / GAME until “AUX” is displayed.
3 Press PLAY on the connected device to start

playback.

Notes:
– All the sound control features (DSC, VAC for
example) are available for selection.
– Always refer to the owner’s manual of the other
equipment for complete connection and use details.

24

Specifications

AMPLIFIER

Output power 5500 W PMPO
Signal-to-noise ratio ≥ 75 dBA (IEC)

Frequency response 50 – 18000 Hz, –3 dB
Input sensitivity

AUX In 640 m V
Gameport 310 mV

Output

Speakers ≥ 6 Ω
Headphones 32 Ω – 1000 Ω

(1) (6 Ω, 1 kHz, 10% THD)

DISC PLAYER

Programmable tracks 40
Frequency response 20 – 20000 Hz, –3 dB
Signal-to-noise ratio ≥ 76 dBA
Channel separation ≥ 60 dB (1 kHz)

USB

Frequency response 20 – 20000 Hz, –3 dB
Signal-to-noise ratio ≥ 75 dBA
Channel separation ≥ 40 dB (1 kHz)
Total harmonic distortion < 0.3% (1 kHz)

TUNER

FM wave range 87.5 – 108 MHz
MW wave range (9 kHz) 531 – 1602 kHz
MW wave range (10 kHz) 530 – 1700 kHz
Number of presets 40
Antenna

FM 75 Ω wire
AM Loop antenna

2 x 165 W RMS

(1)

GENERAL

Material/finish Polystyrene/Metal
AC Pow er

For Version /21-21M 110 – 127 / 220 – 240 V;

50/60 Hz Switchable

For Version /30 230 – 240 V; 50 Hz

Power Consumption

Active 175 W
Standby < 25 W

Eco Power Standby < 1 W
Dimensions (w x h x d) 265 x 322 x 390 (mm)
Weight (without speakers) 8.6 kg

Specifications and external appearance are subject
to change without notice.

English

SPEAKERS

System 3 way, Bass reflex
Impedance 6 Ω
Woofer 1 x 6.5"
Tweeter 1 x 2" Ferrofluid cooled
Dimensions (w x h x d) 348 x 322 x 245 (mm)
Weight 4.35 kg each

25

Troubleshooting

English

WARNING

Under no circumstances should you try to repair the system yourself, as this will invalidate the
warranty. Do not open the system as there is a risk of electric shock.

If a fault occurs, first check the points listed below before taking the system for repair. If you
are unable to remedy a problem by following these hints, consult your dealer or Philips for
help.

Problem

When in USB PC LINK mode, “NO
CONNECTION” is displayed.

Radio reception is poor.

“NO DISC” is displayed or the disc cannot
be played.

“DISC NOT FINALIZED” is displayed.

The system does not react when buttons are
pressed.

Sound cannot be heard or is of poor quality.

✔ Check the connection between your PC and the

system and the inital setup required, see “Connections”
and “USB PC Link”.

✔ Make sure the connected PC is tur ned on.

✔ If the signal is too weak, adjust the antenna or connect

an external antenna for better reception.

✔ Increase the distance between the system and your TV

or VCR.

✔ Inser t a disc.
✔ Load in the disc with label facing r ight.
✔ Replace or clean the disc , see “Care and safety

information”.

✔ Use a finalised CD-R(W) or a correct format disc.

✔ Remove and reconnect the AC power cord and switch

on the system again.

✔ Adjust the volume.
✔ Disconnect the headphones.
✔ Check that the speaker s are connected correctly.
✔ Check that the AC power cord is connected properly.
✔ When in USB PC LINK mode , check that the PC’s

volume is not put into mute.

✔ When playing CD from PC’s CD drive, refer to

“USB PC Link - Enable digital CD audio output“.

Solution

The remote control does not function
properly.

The timer is not working.

The system displays features automatically and
buttons start flashing.

Refer to the FAQ (Frequently Asked Questions) on the supplied CD-ROM or visit our website

“www.audio.philips.com” for latest update on FAQ.

26

✔ Select the source (CD or TUNER, for example) before

pressing the function button (ÉÅ, S ,

✔ Reduce the distance between the remote control and

the system.

✔ Replace the batter y.
✔ Point the remote control directly toward the IR sensor.

✔ Set the clock cor rectly.
✔ Press TIMER ON/OFF to switch on the timer.

✔ Press and hold DEMO STOP on the main unit to switch

off the demonstration mode.

T).
