Philips FW768P User Manual

FW768P

mini hifi system

6 speaker dolby pro logic

Toll Free Help Line

Ligne d'assistance en service libre

Linea de ayuada telefónica sin cargo

800-531-0039

Return your Warranty Registration card today to ensure you receive all the benefits you’re entitled to.

•Once your Philips Magnavox purchase is registered, you’re eligible to receive all the privileges of owning a Philips Magnavox product.

•So complete and return the Warranty Registration Card enclosed with your purchase at once. And take advantage of these important benefits.

Warranty

Verification

Registering your product within 10 days confirms your right to maximum protection under the terms and conditions of your Philips Magnavox warranty.

Owner

Confirmation

Your completed Warranty Registration Card serves as verification of ownership in the event of product theft or loss.

Model

Registration

Returning your Warranty Registration Card right away guarantees you’ll receive all

the information and special offers which you qualify for as the owner of your model.

Know these

safety symbols

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.

For Customer Use

Enter below the Serial No. which is located on the rear of the cabinet. Retain this information for future reference.

Model No. _______________________________

Serial No. ________________________________

	This “bolt of lightning” indicates uninsulated material with-
	in your unit may cause an electrical shock. For the safety
	tof everyone in your household, please do not remove
	product covering.
	The “exclamation point” calls attention to features for
	which you should read the enclosed literature closely to
2	sprevent operating and maintenance problems.

WARNING: TO PREVENT FIRE OR SHOCK HAZARD, DO NOT EXPOSE THIS EQUIPMENT TO RAIN OR MOISTURE.

CAUTION: To prevent electric shock, match wide blade of plug to wide slot, and fully insert.

MAC5097

Visit our World Wide Web Site at http://www.philipsmagnavox.com

Congratulations on your purchase, and welcome to the “family!”

Dear Philips Magnavox product owner:

Thank you for your confidence in Philips Magnavox.You’ve selected one of the best-built, best-backed products available today.And we’ll do everything in our power to keep you happy with your purchase for many years to come.

As a member of the Philips Magnavox “family,” you’re entitled to protection by one of the most comprehensive warranties and outstanding service networks in the industry.

What’s more, your purchase guarantees you’ll receive all the information and special offers for which you qualify, plus easy access to accessories from our convenient home shopping network.

		RA			T	I O		N
		T
		S						N
	G	I
E										E
									E
R										D
AHurry!
•										E
S
Y										D
		D						I	W
		0
			1				T
				N I			H

And most importantly you can count

on our uncompromising commitment to your total satisfaction.

All of this is our way of saying welcome–and thanks for investing in a Philips Magnavox product.

Sincerely,

Robert Minkhorst

President and Chief Executive Officer

P.S. Remember, to get the most from your Philips Magnavox product, you must return your Warranty Registration Card within 10 days. So please mail it to us right now!

3

English

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK,

DO NOT REMOVE COVER (OR BACK).

NO USER-SERVICEABLE PARTS INSIDE.

REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.

This symbol warns the user that uninsulated voltage within the unit may have sufficient magnitude to cause electric shock. Therefore, it is dangerous to make

any kind of contact with any inside part of this unit.

This symbol alerts the user that important literature concerning the operation and maintenance of this unit has been included. Therefore, it should be read carefully in order to avoid any problems.

AVIS

RISQUE DE CHOCS ÉLECTRIQUES

NE PAS OUVRIR

Attention: Afin de prévenir le risque de chocs électriques, ne pas retirer les vis.

Toute réparation devrait être confiée à un personnel qualifié.

Ce symbole indique la présence d’une tension suffisamment élevée pour engendrer un risque de chocs électriques.

Ce symbole indique que le manuel d’installation fourni avec l’appareil contient d’importantes recommandations quant au fonctionnement et à l’entretien de ce dernier.

AVISO

RIESGO DE CHOQUE ELÉCTRICO

NO ABRIR

Atención: Para reducir el riesgo de choque elécrico, no quite la tapa (o el panel posterior).

En su interior no hay piezas que el usuario pueda reparar. Para servicio dirijase a personal calificado.

Este símbolo tiene por finalidad advertir al usuario de la presencia de tensión peligrosa no aislada dentro de la caja del aparato, que puede ser lo suficientemente fuerte para constituir un peligro de choque eléctrico.

Este símbolo sirve para advertir al usuario de la presencia de instrucciones de manejo y mantenimiento (servicio) importantes en el manual que acompaña al aparato.

WARNING

To reduce the risk of fire or electric shock, do not expose this appliance to rain or moisture.

CAUTION

Use of controls or adjustments or performance of procedures other than herein may result in hazardous radiation exposure.

The set complies with the FCC-Rules, Part 15 and with 21 CFR 1040.10.

Canada

This digital apparatus does not exceed the Class B limits for radio noise emissions from digital apparatus as set out in the Radio Interference Regulations of the Canadian Department of Communications.

4

AVIS

Afin de réduire tout risque d’incendie ou de choc électrique, il ne faut pas exposer cet appareil à la pluie ou à l’humidité.

ATTENTION

L'utilisation des commandes ou réglages ou le nonrespect des procédures ci-incluses peuvent se traduire par une exposition dangereuse à l'irradiation.

L'appareil répond aux normes FCC, Part 15 et 21 CFR 1040.10.

Canada

Cet appareil numérique n'emet pas de bruits radioélectriques dépassant les limites applicables aux appareils numériques de Class B prescrites dans le Règlement sur le Brouillage Radioélectrique édicté par le Ministère des Communications du Canada.

AVISO

Para reducir el riesgo de fuego o choque eléctrico, no exponga el aparato a la lluvia o humedad.

ATENCIÓN

El uso de mando o ajustes o la ejecucción de métodos que no sean los aquí descritos puede ocasionar peligro de exposición a radiación.

El aparato cumple las normas FCC, Parte 15 y 21 CFR 1040.10.

	INDEX
English .....................................	6
Français .................................	34
Español ..................................	62

CLASS 1

LASER PRODUCT

Español Français English

5

AC Polarized

Plug

English

SAFETY INSTRUCTIONS – Read before operating equipment

This product was designed and manufactured to meet strict quality and safety standards. There are, however, some installation and operation precautions which you should be particularly aware of.

1.Read Instructions - All the safety and operating instructions should be read before the appliance is operated.

2.Retain Instructions - The safety and operating instructions should be retained for future reference.

3.Heed Warnings - All warnings on the appliance and in the operating instructions should be adhered to.

4.Follow Instructions - All operating and use instructions should be followed.

5.Water and Moisture - The appliance should not be used near water - for example, near a bathtub, washbowl, kitchen sink, laundry tub or swimming pool, or in a wet basement.

6.Carts and Stands - The appliance should be used only with a cart or stand that is recommended by the manufacturer.

6A. An appliance and cart combination should be moved with care. Quick

stops, excessive force, and uneven surfaces may cause the appliance and cart combination to overturn.

7.Wall or Ceiling Mounting - The appliance should be mounted to a wall or ceiling only as recommended by the manufacturer.

8.Ventilation - The appliance should be situated so that its location or position does not interfere with its proper ventilation. For example, the appliance should not be situated on a bed, sofa, rug, or similar surface that may block the ventilation openings; or, placed in a built-in installation, such as a bookcase or cabinet that may impede the flow of air through the ventilation openings.

9.Heat - The appliance should be situated away from heat sources such as radiators, heat registers, stoves, or other appliances (including amplifiers) that produce heat.

10.Power Sources - The appliance should be connected to a power supply only of the type described in the operating instructions or as marked on the appliance.

11.Grounding or Polarization - Precautions should be taken so that the grounding or polarization means of an appliance is not defeated.

CAUTION: To prevent electric shock, match the wide blade of this plug to the wide slot and fully insert. Do not use this (polarized) plug with an extension cord, receptacle or other outlet unless the blades can be fully inserted to prevent blade exposure.

12.Power Cord Protection - Power supply cords should be routed so that they are not likely to be walked on or pinched by items placed upon or against them, paying particular attention to cords and plugs, convenience receptacles, and the point where they exit from the appliance.

13.Cleaning - The appliance should be cleaned only as recommended by the manufacturer.

14.Power Lines - An outdoor antenna should be located away from power lines.

15.Outdoor Antenna Grounding - If an outside antenna is connected to the receiver, be sure the antenna system is grounded so as to provide some protection against voltage surges and built up static charges.

Section 810 of the National Electrical Code, ANSI/NFPA No. 70-1984, provides information with respect to proper grounding of the mast and supporting structure, grounding of the lead-in wire to an antenna discharge unit, size of grounding connectors, location of antenna-discharge unit, connection to grounding electrodes, and requirements for the grounding electrode. See figure on page 7.

16.Non-use Periods - The power cord of the appliance should be unplugged from the outlet when left unused for a long period of time.

17.Object and Liquid Entry - Care should be taken so that objects do not fall and liquids are not spilled into the enclosure through openings.

18.Damage Requiring Service - The appliance should be serviced by qualified service personnel when:

A.The power supply cord or the plug has been damaged; or

B.Objects have fallen, or liquid has spilled into the appliance; or

C.The appliance has been exposed to rain; or

D.The appliance does not appear to operate normally or exhibits a marked change in performance; or

E.The appliance has been dropped, or the enclosure damaged.

19.Servicing - The user should not attempt to service the appliance beyond that described in the operating instructions. All other servicing should be referred to qualified service personnel.

6

SAFETY INSTRUCTIONS

Note to the Cable TV system installer

This reminder is provided to call the Cable TV system installer's attention to Article 820-40 of the NEC that provides guidelines for proper grounding and, in particular, specifies that the cable ground shall be connected to the grounding system of the building, as close to the point of cable entry as practical.

English

Example of Antenna Grounding as per NEC - National Electrical Code

Ground Clamp

Antenna Lead-in Wire

Antenna Discharge Unit

(NEC Section 810-20)

Grounding Conductors

(NEC Section 810-21)

Ground Clamps

Electric Service Equipment				Power Service Grounding Electrode System
				(NEC Art. 250, Part H)

92/11	EL 4562-1
	7

AUDIO SYSTEM

One Year Free Labor

One Year Free Service on Parts

This product must be carried in for repair.

WHO IS COVERED?

You must have proof of purchase to receive warranty service.A sales receipt or other document showing that you purchased the product is considered proof of purchase.

WHAT IS COVERED?

Warranty coverage begins the day you buy your product. For one year thereafter, all parts will be repaired or replaced, and labor is free.After one year from the day of purchase, you pay for the replacement or repair of all parts, and for all labor charges.

All parts, including repaired and replaced parts, are covered only for the original warranty period.When the warranty on the product expires, the warranty on all replaced and repaired parts also expires.

WHAT IS EXCLUDED?

Your warranty does not cover:

•labor charges for installation or setup of the product, adjustment of customer controls on the product, and installation or repair of antenna systems outside of the product.

•product repair and/or part replacement because of misuse, accident, unauthorized repair or other cause not within the control of Philips Consumer Electronics Company.

•reception problems caused by signal conditions or cable or antenna systems outside the unit.

•a product that requires modification or adaptation to enable it to operate in any country other than the country for which it was designed, manufactured, approved and/or authorized, or repair of products damaged by these modifications.

•incidental or consequential damages resulting from the product. (Some states do not allow the exclusion of incidental or consequential damages, so the above exclusion may not apply to you.This includes, but is not

limited to, prerecorded material, whether copyrighted or 8 not copyrighted.)

LIMITED WARRANTY

•a product that is used for commercial or institutional purposes.

WHERE IS SERVICE AVAILABLE?

Warranty service is available in all countries where the product is officially distributed by Philips Consumer Electronics Company. In countries where Philips Consumer Electronics Company does not distribute the product, the local Philips service organization will attempt to provide service (although there may be a delay if the appropriate spare parts and technical manual(s) are not readily available).

MAKE SURE YOU KEEP...

Please keep your sales receipt or other document showing proof of purchase.Attach it to this owner’s manual and keep both nearby.Also keep the original box and packing material in case you need to return your product.

BEFORE REQUESTING SERVICE...

Please check your owner’s manual before requesting service.Adjustments of the controls discussed there may save you a service call.

TO GET WARRANTY SERVICE IN U.S.A., PUERTO RICO OR U.S. VIRGIN ISLANDS...

Take the product to a Philips factory service center (see enclosed list) or authorized service center for repair.When the product has been repaired, you must pick up the unit at the center. Centers may keep defective parts.

(In U.S.A., Puerto Rico and U.S.Virgin Islands, all implied warranties, including implied warranties of merchantability and fitness for a particular purpose, are limited in duration to the duration of this express warranty. But, because some states do not allow limitations on how long an implied warranty may last, this limitation may not apply to you.)

TO GET WARRANTY SERVICE IN CANADA...

Please contact Philips at:

1-800-661-6162 (French Speaking)

1-800-363-7278 (English Speaking)

(In Canada, this warranty is given in lieu of all other warranties. No other warranties are expressed or implied, including any implied warranties of merchantability or fitness for a particular purpose. Philips is not liable under any circumstances for any direct, indirect, special, incidental or consequential damages, howsoever incurred, even if notified of the possibility of such damages.)

REMEMBER...

Please record the model and serial numbers found on the product below.Also, please fill out and mail your warranty registration card promptly. It will be easier for us to notify you if necessary.

MODEL # ____________________________________

SERIAL # ____________________________________

This warranty gives you specific legal rights.You may have other rights which vary from state/province to state/province.

Philips Service Solutions Group, P.O. Box 2976, Longview,Texas 75606, USA, [phone]

EL4965E006 / MAC 4110 / 12-98

CONTENTS
General Information ..........................	9
Safety Information .............................	9
Preparation ...............................	10 - 11
Controls .....................................	12 - 14
Operating The System ............	14 - 16
Dolby Pro Logic ........................	17 - 18
Subwoofer .........................................	19
CD ...............................................	20 - 22
Tuner ..........................................	22 - 23
Tape ............................................	24 - 25
AUX/CDR ............................................	25
Recording ..................................	26 - 27
Clock ..................................................	27
Timer ..................................................	28
Sleeptimer .........................................	28
Specifications ..................................	29
Maintenance ....................................	30
Troubleshooting .......................	30 - 31

GENERAL INFORMATION

General Information

•The typeplate (which contains the serial number) is located at the rear of the system.

•Recording is permissible if copyright or other rights of third parties are not infringed.

•This device complies with part 15 of the Federal Communications Commission (FCC) rules. Operation is subjected to the following two conditions:

–This device may not cause harmful interference, and

–This device must accept any interference received, including interference that may cause undesired operation.

Environmental Information

All unnecessary packaging has been omitted. We have tried to make the packaging easy to separate into three materials: cardboard (box), polystyrene foam (buffer) and polyethylene (bags, protective foam sheet).

Your system consists of materials which can be recycled and reused if disassembled by a specialized company. Please observe the local regulations regarding the disposal of packaging materials, exhausted batteries and old equipment.

Acknowledgement

Dolby Pro-Logic and the double-D symbol d are trademarks of Dolby Laboratories Licensing Corporation.

Manufactured under license from Dolby Laboratories Licensing Corporation.

Accessories (Supplied)

–Remote control

–Batteries (two AA size) for remote control

–AM loop antenna

–FM wire antenna

–AC power cord

–FB3 speaker package (includes one pair of surround speakers and one center speaker)

–SW 030 Active Subwoofer

Safety Information

•Before operating the system, check that the operating voltage indicated on the typeplate (or the voltage indication beside the voltage selector) of your system is identical with the voltage of your local power supply. If not, please consult your dealer. The typeplate is located at the rear of your system.

•When the system is switched on, do not move it around.

	SAFETY INFORMATION
•	Place the system on a solid base (e.g. a	English
	cabinet).
•	Place the system in a location with
	adequate ventilation to prevent internal
	heat build-up in the system.
•	The system incorporates a built-in
	safety feature that prevents
	overheating.
•	Do not expose the system to excessive
	moisture, rain, sand or heat sources.
•	Under no circumstances should you
	repair the system yourself, as this will
	invalidate the warranty!
•	If the system is brought directly from a
	cold to a warm location, or is placed in a
	very damp room, moisture may
	condense on the lens of the CD unit
	inside the system. Should this occur, the
	CD player will not operate normally.
	Leave the power on for about one hour
	with no disc in the system until normal
	playback is possible.
•	Electrostatic discharge may cause
	unexpected problems. See whether
	these problems disappear if you unplug
	the AC power cord and plug it in again
	after a few seconds.
•	To disconnect the system from the
	power supply completely, remove
	the AC power plug from the wall
	socket.
		9

PREPARATION

English	Rear Connections

surr.	surr.	G	AUDIO OUT
L	R		I

F

			SURROUND	SUB-	L R	L R
	A		OUT	WOOFER
				OUT	AUX/CDR IN	LINE OUT
		AC	AM ANTENNA		FM ANTENNA 300Ω
		MAINS
		~
J			CENTER
			+
			–
			REAR			FRONT
			SURROUND			+
			+			L
			L
						–
			–			–
			–			R
			R			+
			+
L	R				CENTER
surr.	surr.	D

E

H

AUDIO IN

B

L R

C

10
