NetworX™ Series
NX-148E LCD Keypad
User Manual
TABLE OF CONTENTS |
|
|
I. |
GLOSSARY OF TERMS...................................................................................................... |
3 |
II. |
UNDERSTANDING THE LIGHTS ..................................................................................... |
4 |
III. |
KEYPAD FUNCTIONS........................................................................................................ |
5 |
|
ARMING YOUR SYSTEM IN THE “AWAY” MODE..................................................................................... |
5 |
|
MAKING YOUR SYSTEM READY TO ARM................................................................................................. |
5 |
|
ARMING YOUR SYSTEM IN THE “STAY” MODE....................................................................................... |
6 |
|
USING THE QUICK ARM .......................................................................................................................... |
7 |
|
CHANGING MODES WHILE YOUR SYSTEM IS ARMED............................................................................ |
7 |
|
DISARMING YOUR SYSTEM ..................................................................................................................... |
7 |
|
CANCEL / ABORT FEATURE .................................................................................................................... |
8 |
|
BYPASSING ZONES.................................................................................................................................. |
8 |
|
GROUP BYPASS ....................................................................................................................................... |
9 |
|
UNBYPASSING......................................................................................................................................... |
9 |
|
EMERGENCY ACTIVATION KEYS.............................................................................................................. |
9 |
|
FUNCTION MENU................................................................................................................................. |
10 |
|
VIEW ZONE STATUS ............................................................................................................................. |
11 |
|
SETTING THE KEYPAD TONE ................................................................................................................ |
11 |
|
VIEW ALARM MEMORY......................................................................................................................... |
11 |
|
TEST FUNCTION .................................................................................................................................. |
11 |
|
DISPLAY TEST FUNCTION..................................................................................................................... |
12 |
|
LIGHT CONTROL FOR X-10 DEVICES ................................................................................................. |
12 |
|
CHANGE LANGUAGES.......................................................................................................................... |
12 |
|
CHANGING USER CODES..................................................................................................................... |
13 |
|
ASSIGNING USER CODE AUTHORITY LEVELS ...................................................................................... |
13 |
|
RESET FUNCTION ................................................................................................................................. |
14 |
|
READING THE EVENT LOG ................................................................................................................... |
15 |
|
ADJUSTING THE VIEW / BRIGHTNESS OF THE LCD............................................................................ |
15 |
|
SETTING THE SYSTEM CLOCK .............................................................................................................. |
16 |
|
USING THE DOOR CHIME FEATURE..................................................................................................... |
16 |
IV. |
PARTITIONED SYSTEMS OPERATION ........................................................................ |
17 |
|
LIGHTS IN PARTITIONING MASTER MODE ........................................................................................... |
17 |
|
DISPLAYS IN THE PARTITIONING MASTER MODE................................................................................ |
17 |
V. |
KEYPAD CONTROL TONES (BEEPS)............................................................................ |
20 |
VI. |
SERVICE DISPLAY........................................................................................................... |
21 |
VII. |
APPENDIX A - EVENT LOG ........................................................................................... |
23 |
VIII. |
EMERGENCY EVACUATION PLANS ............................................................................ |
25 |
NX-148E LCD Keypad |
1 |
|
THIS MANUAL IS FURNISHED TO HELP YOU UNDERSTAND YOUR SECURITY SYSTEM AND BECOME PROFICIENT IN ITS OPERATION. ALL USERS OF YOUR SECURITY SYSTEM SHOULD READ AND FOLLOW THE INSTRUCTIONS AND PRECAUTIONS IN THIS BOOKLET. FAILURE TO DO SO COULD RESULT IN THE SECURITY SYSTEM NOT WORKING PROPERLY. THIS BOOKLET SHOULD BE KEPT IN AN ACCESSIBLE LOCATION FOR THE LIFE OF THE SECURITY SYSTEM. IF YOU DO NOT UNDERSTAND ANY PART OF THIS MANUAL, YOU SHOULD NOTIFY YOUR INSTALLING COMPANY. READ THE ENTIRE MANUAL AND, IF POSSIBLE, PRACTICE ON THE KEYPAD CONTROL WHILE YOUR PROFESSIONAL INSTALLER IS ON SITE.
The SECURITY CONTROL can be turned on (ARMED) and off (DISARMED) by entering a 4 or 6 digit code into the Keypad Control, which is similar to a telephone keypad. If your Security Control has been so programmed, you may be able to turn on (ARM) your System by simply pressing the [STAY] or [EXIT] key. The system must always be Disarmed using a 4 or 6 digit code. The LCD keypad includes 9 lights and a 32-character liquid crystal display and a built-in electronic sounder. These provide specific information relating to the status of the security system which is described in the booklet. Understanding what the lights and sounds mean will help you to easily operate your system.
KEEP IN MIND, THE LEVEL OF SECURITY YOU WILL OBTAIN WITH THIS SYSTEM RELATES SPECIFICALLY WITH TWO MAJOR FACTORS:
1.The quantity, quality, and placement of security devices attached to this system.
2.The knowledge you have of the security system and how that knowledge is utilized in a weekly test of the complete system.
YOU SHOULD BE AWARE OF THE FOLLOWING FACTS WHEN PREPARING A SAFETY/SECURITY PLAN FOR YOUR HOME/BUSINESS.
1.Your security system is an electronic device and is subject to failure or malfunction. Do not rely on it as your single source of security.
2.Your system should be tested weekly.
3.Your system will not work without power.
4.Warning devices will need to be loud enough, wired correctly, and properly placed to provide notification of an alarm event.
5.Smoke and heat detectors may not detect heat and smoke in all situations.
6.Use qualified security professionals to install and maintain your security system.
7.It may be possible to arm the security system without the backup battery connected. Your periodic test should be done with A.C. Power removed to verify the battery is connected and adequately charged.
8.Care should be taken to plug in and restrain the A.C. Transformer after testing.
PLEASE READ THE FOLLOWING INFORMATION AND INSTRUCTIONS CAREFULLY BEFORE OPERATING YOUR SECURITY CONTROL SYSTEM. IF YOU DO NOT UNDERSTAND ANY PORTION OF THIS MANUAL, OR IF YOU HAVE ANY QUESTIONS ABOUT YOUR SYSTEM, CONTACT THE INSTALLING COMPANY.
2 |
NX-148E LCD Keypad |
I.GLOSSARY OF TERMS
Abort Delay: An option that allows a delay in reporting to the central station.
Authority Level: The level of access an individual has when using an alarm panel.
Central Station: Location where alarm data is sent during an alarm report.
Chime Feature: An option that allows the keypad to sound a ding-dong whenever an entry/exit door is opened.
Codes: Can be either User Codes (relating to a person) or Function Codes (a toggle switch to turn specific functions on/off).
NOTE: A system may have either four (4) digit codes or six
(6) digit codes, but not a mixture of the two.
Duress Code: An option that allows a special code to be sent to the central station that indicates the alarm system is being operated under duress.
Forced Arming: An option that allows the system to be turned on (ARMED) with one or more zones open. A system that is ready to be “force armed” will flash the ready light. NOTE: Those zones that are not ready will not create an alarm.
Function Code: A Function Code is either a four (4) or six (6) digit code that has been programmed by the installer to operate a device.
Group Bypass: An option that allows the user to bypass multiple zones with a single operation.
Instant/Delay: An option that allows an instant alarm condition for Entry/Exit doors, or grants a delay to allow someone to enter/exit the building without an alarm or before entering a user code to disarm.
Master Code: A master arm/disarm code that can program other user codes.
Partitioned System: A system divided into multiple areas in which its own user or users control each area.
Perimeter: The outer edge of the protected area.
Quick Arm: An option that allows you to turn on (ARM) the security system by pressing either the [STAY] or [EXIT] key on the keypad control (for ARMING only) as programmed by the installing company.
User Code: A four (4) or six (6) digit entry used to arm or disarm the system.
NX-148E LCD Keypad |
3 |
II.UNDERSTANDING THE LIGHTS
Armed Light |
The armed light is “on” when the system is armed. The armed |
|
light is “off” when it is disarmed. The armed light will flash when |
|
there has been an alarm during the previous arm cycle. |
Bypass Light |
The bypass light is “on” when any zone in this keypad’s partition |
|
is bypassed. If the bypass light is “off”, no zones are bypassed. |
Cancel Light |
The cancel light will flash during an abort delay time. Entering a |
|
code followed by the [CANCEL] key during or after an alarm |
|
report to the central station will cause the cancel light to come |
|
on. It will stay on until the central station has received the |
|
cancel report. NOTE: The cancel feature must be enabled. (See |
|
"Cancel/Abort Feature" on page 8.) |
Chime Light |
The chime light is “on” when the chime feature is “on”; “off” |
|
otherwise. |
Exit Light |
The exit light is “on” during the exit delay. Please note that the |
|
light will flash during the last 10 seconds of the exit delay as a |
|
warning that the time is running out. (The user may want to |
|
disarm the system if the exit light is flashing in order to prevent |
|
an alarm. The user may then re-arm the system and exit before |
|
the delay expires.) |
Fire Light |
A steady fire light means a fire zone has been faulted. A rapidly |
|
flashing fire light means that a fire zone is in a trouble condition. |
Power Light |
The power light is on if the primary power is on. The power light |
|
will flash if the system has a low battery condition. |
Ready Light |
The ready light is “on” when the system is ready to arm and |
|
“flashes” if ready to force arm. The ready light is “off” when the |
|
system is not ready to arm because of a zone(s) being faulted. |
Stay Light |
The stay light is illuminated when all interior zones are bypassed. |
Instant Message The LCD display will read “Instant“ when the entry/exit door(s) have no delay. (See “Arming System in Stay Mode”, page 6.) The doors can be changed from instant to delay (toggled) by pressing the [STAY] key when the system is armed.
4 |
NX-148E LCD Keypad |
III.KEYPAD FUNCTIONS
ARMING YOUR SYSTEM IN THE “AWAY” MODE
AWAY is utilized when the user is going away from the premise and wants the interior protected. Listed below are the steps to arm in the AWAY Mode:
Step 1 Close all protected doors and windows.Ready light will be on or flashing
when all protected zones and sensors are secure. NOTE: If any zones are bypassed, a sensor in that zone can be
violated without affecting the ready light.
The security system will not arm if the ready light is off. Refer to "Making Your System Ready to Arm".
System Not Ready For help, press º
If the power light is off, you
have no AC power. Restore power if possible. If not, contact the installing company.
Step 2 Enter your 4 or 6 digit user code to arm the system.
The armed and exit lights will illuminate.
You may now leave the building.
System Armed
All Zones Secure
IMPORTANT!
The exit light will flash rapidly for the last 10 seconds of the exit delay as a warning to the user that the exit time is about to expire. The user may wish to disarm and rearm the system if more time is needed.
MAKING YOUR SYSTEM READY TO ARM
If the ready light is not on or if it is flashing, a zone is not secure. To identify this zone, use the scroll keys
•
–
to the right of the display to browse through the zones
that are not normal. If you wish to bypass or unbypass one of these zones, press the [BYPASS] key while that zone is being displayed. When finished viewing the zones, press the # key to return to the code entry screen.
NX-148E LCD Keypad |
5 |
ARMING YOUR SYSTEM IN THE “STAY” MODE
STAY is utilized when the user is inside the premise and wants protection around the perimeter. The steps to arm in the STAY Mode are as follows:
Step 1 Close all protected doors and windows.
Ready light must be on or flashing (force armed) when all protected zones and sensors are secure. NOTE: If any zones are bypassed, a sensor in that zone can be violated without affecting the ready light.
The security system will not arm if the ready light is not on or flashing.
If the power light is off, you have no AC power. Restore power if possible. If not, contact the installing company for service.
System Ready
Type code to arm
Step 2 Enter your 4 or 6 digit user code. (Optional, if programmed.)
If “Auto Bypass” is enabled, all interior zones will be bypassed if you do not leave through a designated entry/exit door. If Auto Bypass is enabled, omit Step 3.
When “Auto Instant” is enabled, if you do not leave through a designated entry/exit door, the display will read “Instant”, indicating that the entry/exit doors no longer have an entry delay. If “Auto Instant” is enabled, omit Step 4.
Step 3 Press the [STAY] key.
The stay light will illuminate indicating that all interior zones are bypassed. (All interior devices will bypass automatically, giving the user freedom of movement within the interior area.)
The bypass light will illuminate if any zone(s) are bypassed. If any zone (s) have been bypassed previously by the user, the light(s) corresponding to the bypassed zone(s) will illuminate, alerting the user that a zone(s) may be unprotected and can be faulted without an alarm.
Step 4 To toggle from a “delayed entry” mode to an “Instant” mode, press the [STAY] key again.
The LCD display will read “Instant” meaning the entry/exit doors do NOT have an entry delay.
6 |
NX-148E LCD Keypad |
USING THE QUICK ARM
The Quick Arm feature may be used if it is enabled. Quick Arm will allow the user to arm the security system in the AWAY mode by pressing the [EXIT] key. The system can be quick armed in the STAY mode by pressing the [STAY] key. This feature is used for ARMING ONLY, and will not disarm the security system. This is ideal for a maid or baby sitter code, etc.
CHANGING MODES WHILE YOUR SYSTEM IS ARMED
Step 1 Pressing the [STAY] key will turn on/off (toggle) a delay on Entry/Exit doors. The “Instant” message will toggle on the LCD display.
Step 2 (Optional, if programmed.) Press the [BYPASS] key at this time to turn on/off (toggle) all designated interior zones. If all interior zones are not bypassed, the stay light will extinguish.
Step 3 (Optional, if programmed.) When armed, pressing the [EXIT] key will start the Exit delay, enabling you to leave the building.
IMPORTANT!
An alarm will be created if the “Instant” message is ON at this time and you re-enter the building. You may re-initiate an entry/exit delay by pressing the [STAY] key again. The “Instant” message will disappear.
DISARMING YOUR SYSTEM
When you enter the protected area through one of the designated Entry/Exit doors, the keypad control will sound a continuous tone for the duration of the entry delay time, or until you enter a valid code.
Step 1 |
Enter a valid user code. |
|
|
|
|
|
Type code |
to |
|||
|
|
|
|||
Step 2 |
The red armed light will go off and |
|
Disarm |
|
|
the tone will stop. The security
system is now DISARMED. If a valid code is not entered before the end of the entry delay, an alarm will occur. NOTE: If the red armed light is flashing during the entry delay, the alarm system has been activated in your absence. Leave the building immediately and call your alarm company and/or the police from a safe location.
NX-148E LCD Keypad |
7 |
