User’s Manual HEIDENHAIN Conversational Programming

iTNC 530

NC software 340 490-07 340 491-07 340 492-07 340 493-07 340 494-07

English (en) 12/2011

Controls of the TNC

100

F %

100

S %

Keys on visual display unit

Key Function

Split screen layout

Toggle the display between machining and programming modes

Soft keys for selecting functions on screen

Shifts between soft-key rows

Alphanumeric keyboard

Key Function

File names, comments

DIN/ISO programming

Machine operating modes

Key Function

Manual Operation

Electronic Handwheel

Program/file management, TNC functions

Key Function

Select or delete programs and files, external data transfer

Define program call, select datum and point tables

Select MOD functions

Display help text for NC error messages, call TNCguide

Display all current error messages

Show calculator

Navigation keys

Key Function

Move highlight

Go directly to blocks, cycles and parameter functions

Potentiometer for feed rate and spindle speed

Feed rate Spindle speed

Programming modes

Key Function

smarT.NC

Positioning with Manual Data Input

Program Run, Single Block

Program Run, Full Sequence

Programming and Editing

Test Run

Cycles, subprograms and program section repeats

Key Function

Define touch probe cycles

Define and call cycles

Enter and call labels for subprogramming and program section repeats

Program stop in a program

Tool functions

Key Function

Define tool data in the program

Coordinate axes and numbers: Entering and editing

Key Function

Select coordinate axes or enter them into the program

Call tool data

Programming path movements

Key Function

Approach/depart contour

FK free contour programming

Straight line

Circle center/pole for polar coordinates

Circle with center

Circle with radius

Circular arc with tangential connection

Chamfering/corner rounding

Numbers

Decimal point / Reverse algebraic sign

Polar coordinate input / Incremental values

Q-parameter programming / Q-parameter status

Save actual position or values from calculator

Skip dialog questions, delete words

Confirm entry and resume dialog

Conclude block and exit entry

Clear numerical entry or TNC error message

Abort dialog, delete program section

Special functions / smarT.NC

Key Function

Show special functions

smarT.NC: Select next tab on form

smarT.NC: Select first input field in previous/next frame

About this Manual

The symbols used in this manual are described below.

This symbol indicates that important information about the function described must be considered.

This symbol indicates that there is one or more of the following risks when using the described function:

 Danger to workpiece  Danger to fixtures  Danger to tool  Danger to machine  Danger to operator

This symbol indicates that the described function must be adapted by the machine tool builder. The function described may therefore vary depending on the machine.

This symbol indicates that you can find detailed information about a function in another manual.

About this Manual

Would you like any changes, or have you found any errors?

We are continuously striving to improve documentation for you. Please help us by sending your requests to the following e-mail address: tnc-userdoc@heidenhain.de.

HEIDENHAIN iTNC 530 5

TNC Model, Software and Features

This manual describes functions and features provided by TNCs as of the following NC software numbers.

TNC model NC software number

iTNC 530 340 490-07

iTNC 530 E 340 491-07

iTNC 530 340 492-07

iTNC 530 E 340 493-07

iTNC 530 programming station 340 494-07

The suffix E indicates the export version of the TNC. The export versions of the TNC have the following limitations:

 Simultaneous linear movement in up to 4 axes

The machine tool builder adapts the usable features of the TNC to his machine by setting machine parameters. Some of the functions described in this manual may therefore not be among the features provided by the TNC on your machine tool.

TNC Model, Software and Features

TNC functions that may not be available on your machine include:

 Tool measurement with the TT

Please contact your machine tool builder to become familiar with the features of your machine.

Many machine manufacturers, as well as HEIDENHAIN, offer programming courses for the TNCs. We recommend these courses as an effective way of improving your programming skill and sharing information and ideas with other TNC users.

User’s Manual for Cycle Programming:

All of the cycle functions (touch probe cycles and fixed cycles) are described in a separate manual. Please contact HEIDENHAIN if you require a copy of this User’s Manual. ID: 670 388-xx

smarT.NC user documentation:

The smarT.NC operating mode is described in a separate Pilot. Please contact HEIDENHAIN if you require a copy of this Pilot. ID: 533 191-xx.

TNC Model, Software and Features

HEIDENHAIN iTNC 530 7

Software options

The iTNC 530 features various software options that can be enabled by you or your machine tool builder. Each option is to be enabled separately and contains the following respective functions:

Software option 1

Cylinder surface interpolation (Cycles 27, 28, 29 and 39)

Feed rate in mm/min for rotary axes: M116

Tilting the machining plane (Cycle 19, PLANE function and 3-D ROT soft key in the Manual operating mode)

Circle in 3 axes with tilted working plane

Software option 2

5-axis interpolation

Spline interpolation

3-D machining:

 M114: Automatic compensation of machine geometry when

working with swivel axes

TNC Model, Software and Features

 M128: Maintaining the position of the tool tip when positioning

with tilted axes (TCPM)

 FUNCTION TCPM: Maintaining the position of the tool tip when

positioning with tilted axes (TCPM) in selectable modes

 M144: Compensating the machine’s kinematic configuration for

ACTUAL/NOMINAL positions at end of block

 Additional parameters for finishing/roughing and tolerance

for rotary axes in Cycle 32 (G62)

 LN blocks (3-D compensation)

DCM Collision software option Description

Function that monitors areas defined by the machine manufacturer to prevent collisions.

DXF Converter software option Description

Extract contours and machining positions from DXF files (R12 format).

Additional dialog language software option

Function for enabling the conversational languages Slovenian, Slovak, Norwegian, Latvian, Estonian, Korean, Turkish, Romanian, Lithuanian.

Page 394

Page 268

Description

Page 678

Global Program Settings software option Description

Function for superimposing coordinate transformations in the Program Run modes, handwheel superimposed traverse in virtual axis direction.

AFC software option Description

Function for adaptive feed-rate control for optimizing the machining conditions during series production.

KinematicsOpt software option Description

Touch-probe cycles for inspecting and optimizing the machine accuracy.

3D-ToolComp software option Description

3-D radius compensation depending on the tool’s contact angle for LN blocks.

Page 414

Page 425

User’s Manual for Cycles

Page 425

Extended Tool Management software option

Tool management that can be changed by the machine manufacturer using Python scripts.

Interpolation Turning software option Description

Interpolation turning of a shoulder with cycle

290.

Description

Page 200

User’s Manual for Cycles

TNC Model, Software and Features

HEIDENHAIN iTNC 530 9

Feature content level (upgrade functions)

Along with software options, significant further improvements of the TNC software are managed via the Feature Content Level (FCL) upgrade functions. Functions subject to the FCL are not available simply by updating the software on your TNC.

All upgrade functions are available to you without surcharge when you receive a new machine.

Upgrade functions are identified in the manual with FCL n, where n indicates the sequential number of the feature content level.

You can purchase a code number in order to permanently enable the FCL functions. For more information, contact your machine tool builder or HEIDENHAIN.

FCL 4 functions Description

Graphical depiction of the protected space when DCM collision monitoring is active

Page 398

Handwheel superimposition in stopped condition when DCM collision monitoring is active

TNC Model, Software and Features

3-D basic rotation (set-up compensation)

FCL 3 functions Description

Touch probe cycle for 3-D probing User’s Manual for

Touch probe cycles for automatic datum setting using the center of a slot/ridge

Feed-rate reduction for the machining of contour pockets with the tool being in full contact with the workpiece

PLANE function: Entry of axis angle Page 482

User documentation as a context-sensitive help system

smarT.NC: Programming of smarT.NC and machining can be carried out simultaneously

Page 397

Machine Manual

Cycles

User’s Manual for Cycles

Page 164

Page 129

FCL 3 functions Description

smarT.NC: Contour pocket on point pattern

smarT.NC Pilot

smarT.NC: Preview of contour programs in the file manager

smarT.NC: Positioning strategy for machining point patterns

FCL 2 functions Description

3-D line graphics Page 156

Virtual tool axis Page 594

USB support of block devices (memory sticks, hard disks, CD-ROM drives)

Filtering of externally created contours Page 439

Possibility of assigning different depths to each subcontour in the contour formula

DHCP dynamic IP-address management

Touch-probe cycle for global setting of touch-probe parameters

smarT.NC: Graphic support of block scan

smarT.NC Pilot

Page 139

User’s Manual for Cycles

Page 651

User’s Manual for Touch Probe Cycles

smarT.NC Pilot

TNC Model, Software and Features

smarT.NC: Coordinate transformation smarT.NC Pilot

smarT.NC: PLANE function smarT.NC Pilot

Intended place of operation

The TNC complies with the limits for a Class A device in accordance with the specifications in EN 55022, and is intended for use primarily in industrially-zoned areas.

Legal information

This product uses open source software. Further information is available on the control under

U Programming and Editing operating mode U MOD function U LEGAL INFORMATION soft key

HEIDENHAIN iTNC 530 11

New functions in 340 49x-01 since the predecessor versions 340 422-xx/340 423-xx

 A new form-based operating mode, smarT.NC, has been

introduced. These cycles are described in a separate user's document. In connection with this the TNC operating panel was enhanced. There are some new keys available for quicker navigation within smarT.NC.

 The single-processor versions supports pointing devices (mice) via

the USB interface.

 The tooth feed f

alternate feed entries.

340 422-xx/340 423-xx

 New cycle CENTERING (see User’s Manual for Cycles).  New M function M150 for suppressing limit switch messages (see

“Suppress limit switch message: M150” on page 386).

 M128 is now also permitted for mid-program startup (see “Mid-

program startup (block scan)” on page 625).

 The number of available Q parameters was expanded to 2000 (see

“Principle and Overview” on page 302).

 The number of available label numbers was expanded to 1000. Now

label names can be assigned as well (see “Labeling Subprograms and Program Section Repeats” on page 286).

 In the Q parameter functions FN9 to FN12 you can now also assign

label names as jump targets (see “If-Then Decisions with Q Parameters” on page 312).

 Selectively machine points from a point table (see User's Manual for

Cycles).

 The current time is also shown in the additional status display

window (see “General program information (PGM tab)” on page

92).

 Several columns were added to the tool table (see “Tool table:

Standard tool data” on page 176).

 The Test Run can now also be stopped and resumed within

machining cycles (see “Executing a test run” on page 615).

and feed per revolution fu can now be defined as

New functions in 340 49x-01 since the predecessor versions

New functions with 340 49x-02

 DXF files can be opened directly on the TNC, in order to extract

contours into a plain-language program (see “Processing DXF Files (Software Option)” on page 268).

 3-D line graphics are now available in the Programming and Editing

operating mode (see “3-D Line Graphics (FCL2 Function)” on page

156).

 The active tool-axis direction can now be set as the active machining

direction for manual operation (see “Setting the current tool-axis direction as the active machining direction (FCL 2 function)” on page

594).

 The machine manufacturer can now define any areas on the

machine for collision monitoring (see “Dynamic Collision Monitoring (Software Option)” on page 394).

 Instead of the spindle speed S you can now define the cutting speed

Vc in m/min (see “Calling tool data” on page 191).

 The TNC can now display freely definable tables in the familiar table

view or as forms.

 The function for converting FK programs to H was expanded.

Programs can now also be output in linearized format.

 You can filter contours that were created using external

programming systems.

 For contours which you connect via the contour formula, you can

now assign separate machining depths for each subcontour (see User's Manual for Cycles).

 The single-processor version now supports not only pointing

devices (mice), but also USB block devices (memory sticks, disk drives, hard disks, CD-ROM drives) (see “USB devices on the TNC (FCL 2 function)” on page 147).

New functions with 340 49x-02

HEIDENHAIN iTNC 530 13

New functions with 340 49x-03

 The Adaptive Feed Control (AFC) was introduced (see “Adaptive

Feed Control Software Option (AFC)” on page 425).

 The global parameter settings function makes it possible to set

various transformations and settings in the program run modes (see “Global Program Settings (Software Option)” on page 414).

 The TNC now features a context-sensitive help system, the

TNCguide (see “The Context-Sensitive Help System TNCguide (FCL3 Function)” on page 164).

 Now you can extract point files from DXF files(see “Selecting and

storing machining positions” on page 277).

 Now, in the DXF converter, you can divide or lengthen laterally

joined contour elements (see “Dividing, extending and shortening contour elements” on page 276).

 In the PLANE function the working plane can now also be defined

directly by its axis angle (see “Tilting the working plane through axis angle: PLANE AXIAL (FCL 3 function)” on page 482).

 In Cycle 22 ROUGH-OUT, you can define a feed-rate reduction if the

tool is cutting on its entire circumference (FCL3 function, see User's Manual for Cycles).

New functions with 340 49x-03

 In Cycle 208 BORE MILLING, you can now choose between climb or

up-cut milling (see User's Manual for Cycles).

 String processing has been introduced in Q parameter programming

(see “String Parameters” on page 340).

 A screen saver can be activated through machine parameter 7392

(see “General User Parameters” on page 678).

 The TNC now also supports a network connection over the NFS V3

protocol (see “Ethernet Interface” on page 643).

 The maximum manageable number of tools in a pocket table was

increased to 9999 (see “Pocket table for tool changer” on page

188).

 Parallel programming is possible with smarT.NC (see “Select

smarT.NC programs” on page 129).

 The system time can now be set through the MOD function (see

“Setting the System Time” on page 669).

New functions with 340 49x-04

 The global parameter settings function makes it possible to activate

handwheel superimposed traverse in the active tool axis direction (virtual axis) (see “Virtual axis VT” on page 424).

 Machining patterns can now easily be defined with PATTERN DEF

(see User's Manual for Cycles).

 Program defaults valid globally can now be defined for machining

cycles (see User's Manual for Cycles).

 Now, in Cycle 209 TAPPING WITH CHIP BREAKING, you can define a

factor for the retraction shaft speed, so that you can depart the hole faster (see User's Manual for Cycles).

 In Cycle 22 ROUGH-OUT, you can now define the fine-roughing

strategy (see User's Manual for Cycles).

 In the new Cycle 270 CONTOUR TRAIN DATA, you can define the type

of approach of Cycle 25 CONTOUR TRAIN (see User's Manual for Cycles).

 New Q-parameter function for reading a system datum was

introduced (see "Copying system data to a string parameter", page

345).

 New functions for copying, moving and deleting files from within

the NC program were introduced.

 DCM: Collision objects can now be shown three-dimensionally

during machining (see "Graphic depiction of the protected space (FCL4 function)", page 398).

 DXF converter: New settings possibility introduced, with which the

TNC automatically selects the circle center when loading points from circular elements (see "Basic settings", page 270).

 DXF converter: Element information is shown in an additional info

window (see "Selecting and saving a contour", page 274).

 AFC: A line diagram is now shown in the additional AFC status

display (see “Adaptive Feed Control (AFC tab, software option)” on page 98).

 AFC: Control settings parameters selectable by machine tool builder

(see “Adaptive Feed Control Software Option (AFC)” on page 425).

 AFC: The spindle reference load currently being taught is shown in

a pop-up window in the teach-in mode. In addition, the learning phase can be restarted at any time via soft key (see “Recording a teach-in cut” on page 429).

 AFC: The dependent file <name>.H.AFC.DEP can now also be

modified in the Programming and Editing operating mode (see “Recording a teach-in cut” on page 429).

New functions with 340 49x-04

HEIDENHAIN iTNC 530 15

 The maximum path permitted for LIFTOFF was increased to 30 mm

(see “Automatically retract tool from the contour at an NC stop: M148” on page 385).

 File management was adapted to the file management of smarT.NC

(see “Overview: Functions of the file manager” on page 124).

 New function for generating service files was introduced (see

“Generating service files” on page 163).

 A window manager was introduced (see “Window Manager” on

page 99).

 The new dialog languages Turkish and Romanian were introduced

(software option, Page 678).

New functions with 340 49x-04

New functions with 340 49x-05

 DCM: Integrated fixture management (see “Fixture Monitoring

(DCM Software Option)” on page 401)

 DCM: Collision checking in the Test Run mode (see “Collision

monitoring in the Test Run mode of operation” on page 399)

 DCM: Management of tool-carrier kinematics has been simplified

(see “Tool-carrier kinematics” on page 186)

 Processing DXF data: Fast point selection via mouse area (see

“Quick selection of hole positions in an area defined by the mouse” on page 279)

 Processing DXF data: Fast point selection via diameter input (see

“Quick selection of hole positions in an area defined by the mouse” on page 279)

 DXF data processing: Polyline support was integrated (see

“Processing DXF Files (Software Option)” on page 268)

 AFC: Smallest occurring feed rate will now also be saved in the log

file (see “Log file” on page 433)

 AFC: Monitoring for tool breakage/tool wear (see “Tool

breakage/tool wear monitoring” on page 435)

 AFC: Direct monitoring of spindle load (see “Spindle load

monitoring” on page 435)

 Global program settings: Function also partially effective with

M91/M92 blocks (see “Global Program Settings (Software Option)” on page 414)

 Pallet preset table added (see "Pallet datum management with the

pallet preset table", page 523 or see "Application", page 520 or see "Storing measured values in the pallet preset table", page 570 or see "Saving the basic rotation in the preset table", page 576)

 The additional status display now has an additional tab, i.e. PAL, on

which an active pallet preset is displayed (see “General pallet information (PAL tab)” on page 93)

 New tool management (see “Tool management (software option)”

on page 200)

 New column R2TOL in the tool table (see “Tool table: Tool data

required for automatic tool measurement” on page 180)

 Tools can now also be selected during tool call by soft key directly

from TOOL.T (see “Calling tool data” on page 191)

 TNCguide: Context sensitivity has been improved in that when the

cursor is engaged it jumps to the appropriate description (see “Calling the TNCguide” on page 165)

 Lithuanian dialog added, machine parameter 7230 (see “List of

general user parameters” on page 679)

 M116 allowed in combination with M128 (see “Feed rate in

mm/min on rotary axes A, B, C: M116 (software option 1)” on page

496)

 Introduction of local and nonvolatile Q parameters QL and QR (see

“Principle and Overview” on page 302)

 The MOD function can now test the data medium (see “Checking

the Data Carrier” on page 668)

New functions with 340 49x-05

HEIDENHAIN iTNC 530 17

 New Cycle 241 for Single-Fluted Deep-Hole Drilling (see User’s

Manual for Cycles)

 Touch probe cycle 404 (SET BASIC ROTATION) was expanded by

parameter Q305 (Number in table) in order to write basic rotations to the preset table (see User's Manual for Cycles)

 Touch probe cycles 408 to 419: The TNC now also writes to line 0

of the preset table when the display value is set (see User's Manual for Cycles).

 Touch probe cycle 416 (Datum on Circle Center) was expanded by

parameter Q320 (safety clearance) (see User's Manual for Cycles)

 Touch probe cycles 412, 413, 421 and 422: Additional parameter

Q365 (type of traverse) (see User's Manual for Cycles)

 Touch probe cycle 425 (Measure Slot) was expanded by parameters

Q301 (Move to clearance height) and Q320 (setup clearance) (see User's Manual for Cycles)

 Touch probe cycle 450 (Save Kinematics) was expanded by input

option 2 (Display saving status) in parameter Q410 (mode) (see User's Manual for Cycles)

 Touch probe cycle 451 (Measure Kinematics) was expanded by

parameters Q423 (number of circular measurements) and Q432 (set preset) (see User's Manual for Cycles)

New functions with 340 49x-05

 New touch probe cycle 452 (Preset Compensation) simplifies the

measurement of tool changer heads (see User's Manual for Cycles)

 New touch probe cycle 484 for calibrating the wireless TT 449 tool

touch probe (see User's Manual for Cycles)

New functions 340 49x-06

 The new HR 520 and HR 550 FS handwheels are supported (see

“Traversing with electronic handwheels” on page 546)

 New software option 3-D ToolComp: 3-D tool radius compensation

depending on the tool’s contact angle on blocks with surface normal vectors (LN blocks, see "3-D tool radius compensation depending on the tool’s contact angle (3D-ToolComp software option)", page 513)

 3-D line graphics is now also possible in full-screen mode (see “3-D

Line Graphics (FCL2 Function)” on page 156)

 A file selection dialog for selecting files in different NC functions and

in the table view of the pallet table is available now (see “Calling any program as a subprogram” on page 289)

 DCM: Saving and restoring of fixture situations  DCM: The form for test program generation now also contains icons

and tooltips (see “Check the position of the measured fixture” on page 406)

 DCM, FixtureWizard: Touch points and probing sequence are shown

more clearly now

 DCM, FixtureWizard: Designations, touch points and measuring

points can be shown or hidden as desired.(see “Operating FixtureWizard” on page 403)

 DCM, FixtureWizard: Chucking equipment and insertion points can

now also be selected by mouse click

 DCM: A library with standard chucking equipment is available now

(see “Fixture templates” on page 402)

 DCM: Tool carrier management (see “Tool Holder Management

(DCM Software Option)” on page 411)

 In the Test Run mode, the working plane can now by defined

manually (see “Setting a tilted working plane for the test run” on page 618)

 In Manual mode the RW-3D mode for position display is now also

available (see “Position Display Types” on page 660)

 Entries in the tool table TOOL.T (see “Tool table: Standard tool data”

on page 176)

 New DR2TABLE column for definition of a compensation table for

tool radius compensation depending on the tool’s contact angle

 New LAST_USE column, into which the TNC enters the date and

time of the last tool call

 Q parameter programming: QS string parameters can now also be

used for jump addresses of conditional jumps, subprograms or program section repeats (see "Calling a subprogram", page 287, see "Calling a program section repeat", page 288 and see "Programming If-Then decisions", page 313)

 The generation of tool usage lists in the Program Run modes can be

configured in a form (see “Settings for the tool usage test” on page

197)

 The behavior during deletion of tools from the tool table can now be

influenced via machine parameter 7263 see "Editing tool tables", page 183

New functions 340 49x-06

HEIDENHAIN iTNC 530 19

 In the positioning mode TURN of the PLANE function you can now

define a clearance height to which the tool is to be retracted before tilting to tool axis direction (see “Automatic positioning: MOVE/TURN/STAY (entry is mandatory)” on page 484)

 The following additional functions are now available in the expanded

tool management (see “Tool management (software option)” on page 200):

 Columns with special functions are also editable now  The form view of the tool data can now be exited with or without

saving changed values

 The table view now offers a search function  Indexed tools are now shown correctly in the form view  The tool sequence list includes more detailed information now  The loading and unloading list of the tool magazine can now be

loaded and unloaded by drag and drop

 Columns in the table view can be moved simply by drag and drop

 Several special functions (SPEC FCT) are now available in the MDI

New functions 340 49x-06

operating mode (see “Programming and Executing Simple Machining Operations” on page 596)

 There is a new manual probing cycle that can be used to

compensate workpiece misalignments by rotating the rotary table (see “Workpiece alignment using 2 points” on page 579)

 New touch probe cycle for calibrating a touch probe by means of a

calibration sphere (see User's Manual for Cycle Programming)

 KinematicsOpt: Better support for positioning of Hirth-coupled axes

(see User's Manual for Cycle Programming)

 KinematicsOpt: An additional parameter for determination of the

backlash in a rotary axis was introduced (see User's Manual for Cycle Programming)

 New Cycle 275 for Trochoidal Slot Milling (see User’s Manual for

Cycle Programming)

 In Cycle 241 "Single-Fluted Deep-Hole Drilling" it is now possible to

define a dwell depth (see User's Manual for Cycle Programming)

 The approach and departure behavior of Cycle 39 "Cylinder Surface

Contour" can now be adjusted (see User's Manual for Cycle Programming)

New Functions with 340 49x-07

 Improvement of Dynamic Collision Monitoring (DCM):

 Chucking equipment archives can now be activated (see “Loading

fixtures under program control” on page 410) and deactivated (see “Deactivating fixtures under program control” on page 410) under program control

 The display of stepped tools has been improved

 Extension of the functions for multiple axis machining:

 In manual mode, you can now also travel the axes again when

TCPM and Tilt Machining Plane are active at the same time

 You can now also change tools when M128/FUNCTION TCPM is active

 File management: archiving of files in ZIP archives (see "Archive

files" page 142)

 The nesting depth for program calls has been increased from 6 to 10

(see “Nesting depth” on page 291)

 smarT.NC-UNITs can now be inserted anywhere in plain-language

programs (see “smartWizard” on page 445)

 There is now a search function based on tool names available in the

tool selection pop-up window (see “Search for tool names in the selection window” on page 193)

 Improvements in pallet machining:

 The new column FIXTURE has been added to the pallet table to be

able to activate fixtures automatically (see "Pallet Operation with Tool-Oriented Machining" page 526)

 The new workpiece status SKIP has been added to the pallet table

(see "Setting up the pallet level" page 532)

 If a tool sequence list is created for a pallet table, the TNC now

also checks that all the NC programs of the pallet table are available (see “Calling tool management” on page 200)

 The new host computer operation was introduced (see “Host

computer operation” on page 672)

 Improvements to the DXF converter:

 Contours can now also be extracted from .H files (see “Data

transfer from plain-language programs” on page 284)

 Preselected contours can now also be selected in the tree

structure (see “Selecting and saving a contour” on page 274)

 A snap function facilitates contour selection  Extended status display (see “Basic settings” on page 270)  Adjustable background color (see “Basic settings” on page 270)  Display can be changed between 2-D and 3-D (see “Basic

settings” on page 270)

New Functions with 340 49x-07

HEIDENHAIN iTNC 530 21

 Improvements to the global program settings (GS):

 All the form data can now be set and reset under program control

(see “Technical prerequisites” on page 416)

 Handwheel superimposition value VT can be reset when tool is

changed (see “Virtual axis VT” on page 424)

 If the Swapping Axes function is active, it is now permitted to

position to machine-based positions on the axes that have not been swapped

 Using the new SEL PGM function you can assign variable program

names via QS string parameters call them with CALL SELECTED (see “Define program call” on page 444)

 Improvements to the tool table TOOL.T

 Using the FIND ACTIVE TOOL NAMES soft key you can check

whether identical tool names are defined in the tool table (see "Editing tool tables" page 183)

 The input range of the delta values DL, DR and DR2 have been

increased to 999.9999 mm (see "Tool table: Standard tool data" page 176)

 The following additional functions are now available in the expanded

tool management (see “Tool management (software option)” on page 200):

New Functions with 340 49x-07

 Importing of tool data in CSV format (see “Import tool data” on

page 205)

 Exporting of tool data in CSV format (see “Export the tool data”

on page 206)

 Marking and deleting of selectable tool data (see “Delete marked

tool data” on page 207)

 Inserting of tool indices (see “Operating the tool management”

on page 202)

 New cycle 225 Engraving (see User’s Manual for Cycle

Programming)

 New cycle 276 Contour Train (see User’s Manual for Cycle

Programming)

 New cycle 290 Interpolation Turning (software option, see User’s

Manual for Cycle Programming)

 In the thread milling cycles 26x a separate feed rate is now available

for tangential approach to the thread (see User’s Manual for Cycle Programming)

 The following improvements were made to the KinematicsOpt

cycles (see User’s Manual for Conversational Programming):

 Newer, faster optimization algorithm  It is no longer necessary to run a separate measurement series for

position optimization after angle optimization

 Return of the offset errors (change of machine datum) to the

parameters Q147-149

 More plane measuring points for ball measurement



Rotary axes that are not configured are ignored by TNC when executing the cycle

Changed functions in 340 49x-01 since the predecessor versions 340 422-xx/340 423-xx

 The layouts of the status display and additional status display were

redesigned (see “Status Displays” on page 89).

 Software 340 490 no longer supports the small resolution in

combination with the BC 120 screen (see “Visual display unit” on page 83)

 New key layout of the TE 530 B keyboard unit (see “Operating

panel” on page 85)

 The entry range for the EULPR precession angle in the PLANE EULER

function was expanded (see “Defining the machining plane with Euler angles: EULER PLANE” on page 475)

 The plane vector in the VECTOR PLANE function no longer has to be

entered in standardized form (see “Defining the working plane with two vectors: VECTOR PLANE” on page 477).

 Positioning behavior of the CYCL CALL PAT function has been

modified (see User's Manual for Cycles).

 The tool types available for selection in the tool table were increased

in preparation for future functions.

 Instead of the last 10, you can now choose from the last 15 selected

files (see “Choosing one of the last files selected” on page 134)

xx/340 423-xx

HEIDENHAIN iTNC 530 23

Changed functions in 340 49x-01 since the predecessor versions 340 422-

Functions changed in 340 49x-02

 Access to the preset table was simplified. There are also new

options for entering values in the preset table See table “Manually saving the datums in the preset table”

 In inch-programs, the function M136 (feed rate in 0.1 inch/rev) can

no longer be combined with the FU function.

 The feed-rate potentiometers of the HR 420 are no longer switched

over automatically when the handwheel is selected. The selection is made via soft key on the handwheel. In addition, the pop-up window for the active handwheel was made smaller, in order to improve the view of the display beneath it.

 The maximum number of contour elements for SL cycles was

increased to 8192, so that much more complex contours can be machined (see User's Manual for Cycles).

 FN16: F-PRINT: The maximum number of Q-parameter values that

can be output per line in the format description file was increased to

32.

 The soft keys START and START SINGLE BLOCK in the Program

Test mode of operation were switched, so that the soft-key alignment is the same in all modes of operation (Programming and Editing, smarT.NC, Test) (see “Executing a test run” on page 615)

Functions changed in 340 49x-02

 The design of the soft keys was revised completely.

Changed functions with 340 49x-03

 In Cycle 22 you can now define a tool name also for the coarse

roughing tool (see User's Manual Cycles).

 In the PLANE function, an FMAX can now be programmed for the

automatic rotary positioning (see “Automatic positioning: MOVE/TURN/STAY (entry is mandatory)” on page 484)

 When running programs in which non-controlled axes are

programmed, the TNC now interrupts the program run and displays a menu for returning to the programmed position (see “Programming of noncontrolled axes (counter axes)” on page 622)

 The tool usage file now also includes the total machining time,

which serves as the basis for the progress display in percent in the Program Run, Full Sequence mode.

 The TNC now also takes the dwell time into account when

calculating the machining time in the Test Run mode (see “Measuring the machining time” on page 611)

 Arcs that are not programmed in the active working plane can now

also be run as spatial arcs (see “Circular path C around circle center CC” on page 232)

 The EDIT OFF/ON soft key on the pocket table can be deactivated

by the machine tool builder (see “Pocket table for tool changer” on page 188)

 The additional status display has been revised. The following

improvements have been made (see “Additional status displays” on page 91):

 A new overview page with the most important status displays

was introduced.

 The individual status pages are now displayed as tabs (as in

smarT.NC). The individual tabs can be selected with the Page soft keys or with the mouse.

 The current run time of the program is shown in percent by a

progress bar.

 The tolerance values set in Cycle 32 are displayed.  Active global program settings are displayed, provided that this

software option was enabled.

 The status of the Adaptive Feed Control (AFC) is displayed,

provided that this software option was enabled.

Changed functions with 340 49x-03

HEIDENHAIN iTNC 530 25

Changed functions with 340 49x-04

 DCM: Retraction after collision simplified (see "Collision monitoring

in the manual operating modes", page 396)

 The input range for polar angles was increased (see “Circular path

CP around pole CC” on page 242)

 The value range for Q-parameter assignment was increased (see

"Programming notes", page 304)

 The pocket-, stud- and slot-milling cycles 210 to 214 were removed

from the standard soft-key row (CYCL DEF > POCKETS/STUDS/SLOTS). For reasons of compatibility, the cycles will still be available, and can be selected via the GOTO key.

 The soft-key rows in the Test Run operating mode were modified to

those of the smarT.NC operating mode.

 Windows XP is now used on the dual-processor version (see

“Introduction” on page 710)

 Conversion from FK to H was moved to the special functions (SPEC

FCT).

 Filtering of contours was moved to the special functions (SPEC

FCT).

 Loading of values from the pocket calculator was changed (see “To

transfer the calculated value into the program” on page 153)

Changed functions with 340 49x-04

Changed functions with 340 49x-05

 GS global program settings: Form was redesigned (see "Global

Program Settings (Software Option)", page 414)

 The menu for network configuration was revised (see “Configuring

the TNC” on page 646)

Changed functions with 340 49x-05

HEIDENHAIN iTNC 530 27

Changed functions 340 49x-06

 Q-parameter programming: In the FN20 function WAIT FOR you can

now enter 128 characters (see “FN 20: WAIT FOR: NC and PLC synchronization” on page 333)

 In the calibration menus for touch probe length and radius, the

number and name of the active tool are also displayed now (if the calibration data from the tool table are to be used, MP7411 = 1, see "Managing more than one block of calibrating data", page 573)

 During tilting in the Distance-To-Go mode, the PLANE function now

shows the angle actually left to be traversed until the target position (see “Position display” on page 469)

 The approach behavior during side finishing with Cycle 24 (DIN/ISO:

G124) was changed (see User's Manual for Cycle Programming).

Changed functions 340 49x-06

Changed functions with 340 49x-07

 Tool names can now be defined with 32 characters (see “Tool

numbers and tool names” on page 174)

 Improved and simplified operation by mouse and touchpad in all

graphics windows (see “Functions of the 3-D line graphics” on page

156)

 Various pop-up windows have been redesigned  If you do a Test Run without calculating the machining time, the TNC

generates a tool usage file nevertheless (see “Tool usage test” on page 197)

 The size of the Service ZIP files has been increased to 40 MB (see

“Generating service files” on page 163)

 M124 can now be deactivated by entering M124 without T (see “Do

not include points when executing non-compensated line blocks: M124” on page 372)

 The PRESET TABLE soft key has been renamed to DATUM

MANAGEMENT

 The SAVE PRESET soft key has been renamed to SAVE ACTIVE

PRESET

Changed functions with 340 49x-07

HEIDENHAIN iTNC 530 29

Changed functions with 340 49x-07

Table of Contents

First Steps with the iTNC 530

Introduction

Programming: Fundamentals, File Management

Programming: Programming Aids

Programming: Tools

Programming: Programming Contours

Programming: Data Transfer from DXF Files or Plain-language Contours

Programming: Subprograms and Program Section Repeats

Programming: Q-Parameters

Programming: Miscellaneous Functions

Programming: Special Functions

Programming: Multiple Axis Machining

Programming: Pallet Editor

Manual Operation and Setup

Positioning with Manual Data Input

Test Run and Program Run

MOD Functions

Tables and Overviews

iTNC 530 with Windows XP (Option)

HEIDENHAIN iTNC 530 31

1 First Steps with the iTNC 530 ..... 59

1.1 Overview ..... 60

1.2 Machine Switch-On ..... 61

Acknowledge the power interruption and move to the reference points ..... 61

1.3 Programming the First Part ..... 62

Select the correct operating mode ..... 62

The most important TNC keys ..... 62

Create a new program/file management ..... 63

Define a workpiece blank ..... 64

Program layout ..... 65

Program a simple contour ..... 66

Create a cycle program ..... 69

1.4 Graphically Testing the First Program ..... 72

Selecting the correct operating mode ..... 72

Select the tool table for the test run ..... 72

Choose the program you want to test ..... 73

Select the screen layout and the view ..... 73

Start the program test ..... 73

1.5 Tool Setup ..... 74

Selecting the correct operating mode ..... 74

Prepare and measure tools ..... 74

The tool table TOOL.T ..... 74

The pocket table TOOL_P.TCH ..... 75

1.6 Workpiece Setup ..... 76

Selecting the correct operating mode ..... 76

Clamp the workpiece ..... 76

Align the workpiece with a 3-D touch probe system ..... 77

Set the datum with a 3-D touch probe ..... 78

1.7 Running the First Program ..... 79

Selecting the correct operating mode ..... 79

Choose the program you want to run ..... 79

Start the program ..... 79

HEIDENHAIN iTNC 530 33

2 Introduction ..... 81

2.1 The iTNC 530 ..... 82

Programming: HEIDENHAIN conversational, smarT.NC and ISO formats ..... 82

Compatibility ..... 82

2.2 Visual Display Unit and Keyboard ..... 83

Visual display unit ..... 83

Sets the screen layout ..... 84

Operating panel ..... 85

2.3 Operating Modes ..... 86

Manual Operation and Electronic Handwheel ..... 86

Positioning with Manual Data Input ..... 86

Programming and Editing ..... 87

Test Run ..... 87

Program Run, Full Sequence and Program Run, Single Block ..... 88

2.4 Status Displays ..... 89

“General” status display ..... 89

Additional status displays ..... 91

2.5 Window Manager ..... 99

2.6 Accessories: HEIDENHAIN 3-D Touch Probes and Electronic Handwheels ..... 100

3-D touch probes ..... 100

HR electronic handwheels ..... 101

3 Programming: Fundamentals, File Management ..... 103

3.1 Fundamentals ..... 104

Position encoders and reference marks ..... 104

Reference system ..... 104

Reference system on milling machines ..... 105

Polar coordinates ..... 106

Absolute and incremental workpiece positions ..... 107

Setting the datum ..... 108

3.2 Creating and Writing Programs ..... 109

Organization of an NC program in HEIDENHAIN Conversational ..... 109

Define the blank: BLK FORM ..... 109

Creating a new part program ..... 110

Programming tool movements in conversational format ..... 112

Actual position capture ..... 114

Editing a program ..... 115

The TNC search function ..... 119

3.3 File Management: Fundamentals ..... 121

Files ..... 121

Data backup ..... 122

3.4 Working with the File Manager ..... 123

Directories ..... 123

Paths ..... 123

Overview: Functions of the file manager ..... 124

Calling the file manager ..... 126

Selecting drives, directories and files ..... 127

Creating a new directory (only possible on the drive TNC:\) ..... 130

Creating a new file (only possible on the drive TNC:\) ..... 130

Copying a single file ..... 131

Copying files into another directory ..... 132

Copying a table ..... 133

Copying a directory ..... 134

Choosing one of the last files selected ..... 134

Deleting a file ..... 135

Deleting a directory ..... 135

Marking files ..... 136

Renaming a file ..... 138

Additional functions ..... 139

Working with shortcuts ..... 141

Archive files ..... 142

Extract files from archive ..... 143

Data transfer to or from an external data medium ..... 144

The TNC in a network ..... 146

USB devices on the TNC (FCL 2 function) ..... 147

HEIDENHAIN iTNC 530 35

4 Programming: Programming Aids ..... 149

4.1 Adding Comments ..... 150

Function ..... 150

Entering comments during programming ..... 150

Inserting comments after program entry ..... 150

Entering a comment in a separate block ..... 150

Functions for editing of the comment ..... 151

4.2 Structuring Programs ..... 152

Definition and applications ..... 152

Displaying the program structure window / Changing the active window ..... 152

Inserting a structuring block in the (left) program window ..... 152

Selecting blocks in the program structure window ..... 152

4.3 Integrated Pocket Calculator ..... 153

Operation ..... 153

4.4 Programming Graphics ..... 154

Generating / not generating graphics during programming ..... 154

Generating a graphic for an existing program ..... 154

Block number display ON/OFF ..... 155

Erasing the graphic ..... 155

Magnifying or reducing a detail ..... 155

4.5 3-D Line Graphics (FCL2 Function) ..... 156

Function ..... 156

Functions of the 3-D line graphics ..... 156

Highlighting NC blocks in the graphics ..... 158

Block number display ON/OFF ..... 158

Erasing the graphic ..... 158

4.6 Immediate Help for NC Error Messages ..... 159

Displaying error messages ..... 159

Display HELP ..... 159

4.7 List of All Current Error Messages ..... 160

Function ..... 160

Show error list ..... 160

Window contents ..... 161

Calling the TNCguide help system ..... 162

Generating service files ..... 163

4.8 The Context-Sensitive Help System TNCguide (FCL3 Function) ..... 164

Function ..... 164

Working with the TNCguide ..... 165

Downloading current help files ..... 169

5 Programming: Tools ..... 171

5.1 Entering Tool-Related Data ..... 172

Feed rate F ..... 172

Spindle speed S ..... 173

5.2 Tool Data ..... 174

Requirements for tool compensation ..... 174

Tool numbers and tool names ..... 174

Tool length L ..... 174

Tool radius R ..... 174

Delta values for lengths and radii ..... 175

Entering tool data into the program ..... 175

Entering tool data in the table ..... 176

Tool-carrier kinematics ..... 186

Using an external PC to overwrite individual tool data ..... 187

Pocket table for tool changer ..... 188

Calling tool data ..... 191

Tool change ..... 194

Tool usage test ..... 197

Tool management (software option) ..... 200

5.3 Tool Compensation ..... 208

Introduction ..... 208

Tool length compensation ..... 208

Tool radius compensation ..... 209

HEIDENHAIN iTNC 530 37

6 Programming: Programming Contours ..... 213

6.1 Tool Movements ..... 214

Path functions ..... 214

FK free contour programming ..... 214

Miscellaneous functions M ..... 214

Subprograms and program section repeats ..... 214

Programming with Q parameters ..... 214

6.2 Fundamentals of Path Functions ..... 215

Programming tool movements for workpiece machining ..... 215

6.3 Contour Approach and Departure ..... 219

Overview: Types of paths for contour approach and departure ..... 219

Important positions for approach and departure ..... 220

Approaching on a straight line with tangential connection: APPR LT ..... 222

Approaching on a straight line perpendicular to the first contour point: APPR LN ..... 222

Approaching on a circular path with tangential connection: APPR CT ..... 223

Approaching on a circular arc with tangential connection from a straight line to the contour: APPR LCT ..... 224

Departing on a straight line with tangential connection: DEP LT ..... 225

Departing on a straight line perpendicular to the last contour point: DEP LN ..... 225

Departure on a circular path with tangential connection: DEP CT ..... 226

Departing on a circular arc tangentially connecting the contour and a straight line: DEP LCT ..... 226

6.4 Path Contours—Cartesian Coordinates ..... 227

Overview of path functions ..... 227

Straight line L ..... 228

Inserting a chamfer between two straight lines ..... 229

Corner rounding RND ..... 230

Circle center CCI ..... 231

Circular path C around circle center CC ..... 232

Circular path CR with defined radius ..... 233

Circular path CT with tangential connection ..... 235

6.5 Path Contours—Polar Coordinates ..... 240

Overview ..... 240

Zero point for polar coordinates: pole CC ..... 241

Straight line LP ..... 241

Circular path CP around pole CC ..... 242

Circular path CTP with tangential connection ..... 243

Helical interpolation ..... 244

6.6 Path Contours—FK Free Contour Programming ..... 248

Fundamentals ..... 248

Graphics during FK programming ..... 250

Converting FK programs into HEIDENHAIN conversational format ..... 251

Initiating the FK dialog ..... 252

Pole for FK programming ..... 253

Free programming of straight lines ..... 253

Free programming of circular arcs ..... 254

Input possibilities ..... 254

Auxiliary points ..... 258

Relative data ..... 259

HEIDENHAIN iTNC 530 39

7 Programming: Data Transfer from DXF Files or Plain-language Contours ..... 267

7.1 Processing DXF Files (Software Option) ..... 268

Function ..... 268

Opening a DXF file ..... 269

Basic settings ..... 270

Layer settings ..... 271

Specifying the reference point ..... 272

Selecting and saving a contour ..... 274

Selecting and storing machining positions ..... 277

Zoom function ..... 283

7.2 Data transfer from plain-language programs ..... 284

Application ..... 284

Open plain-language file ..... 284

Define a reference point; select and save contours ..... 284

8 Programming: Subprograms and Program Section Repeats ..... 285

8.1 Labeling Subprograms and Program Section Repeats ..... 286

Labels ..... 286

8.2 Subprograms ..... 287

Operating sequence ..... 287

Programming notes ..... 287

Programming a subprogram ..... 287

Calling a subprogram ..... 287

8.3 Program Section Repeats ..... 288

Label LBL ..... 288

Operating sequence ..... 288

Programming notes ..... 288

Programming a program section repeat ..... 288

Calling a program section repeat ..... 288

8.4 Separate Program as Subprogram ..... 289

Operating sequence ..... 289

Programming notes ..... 289

Calling any program as a subprogram ..... 289

8.5 Nesting ..... 291

Types of nesting ..... 291

Nesting depth ..... 291

Subprogram within a subprogram ..... 292

Repeating program section repeats ..... 293

Repeating a subprogram ..... 294

8.6 Programming Examples ..... 295

HEIDENHAIN iTNC 530 41

9 Programming: Q-Parameters ..... 301

9.1 Principle and Overview ..... 302

Programming notes ..... 304

Calling Q-parameter functions ..... 305

9.2 Part Families—Q Parameters in Place of Numerical Values ..... 306

Function ..... 306

9.3 Describing Contours through Mathematical Operations ..... 307

Function ..... 307

Overview ..... 307

Programming fundamental operations ..... 308

9.4 Trigonometric Functions ..... 309

Definitions ..... 309

Programming trigonometric functions ..... 310

9.5 Circle Calculations ..... 311

Function ..... 311

9.6 If-Then Decisions with Q Parameters ..... 312

Function ..... 312

Unconditional jumps ..... 312

Programming If-Then decisions ..... 313

Abbreviations used: ..... 313

9.7 Checking and Changing Q Parameters ..... 314

Procedure ..... 314

9.8 Additional Functions ..... 315

Overview ..... 315

FN 14: ERROR: Displaying error messages ..... 316

FN 15: PRINT: Output of texts or Q parameter values ..... 320

FN 16: F-PRINT: Formatted output of text and Q-parameter values ..... 321

FN 18: SYS-DATUM READ: Read system data ..... 325

FN 19: PLC: Transfer values to the PLC ..... 332

FN 20: WAIT FOR: NC and PLC synchronization ..... 333

FN 25: PRESET: Setting a new datum ..... 335

9.9 Entering Formulas Directly ..... 336

Entering formulas ..... 336

Rules for formulas ..... 338

Programming example ..... 339

9.10 String Parameters ..... 340

String processing functions ..... 340

Assigning string parameters ..... 341

Chain-linking string parameters ..... 342

Converting a numerical value to a string parameter ..... 343

Copying a substring from a string parameter ..... 344

Copying system data to a string parameter ..... 345

Converting a string parameter to a numerical value ..... 347

Checking a string parameter ..... 348

Finding the length of a string parameter ..... 349

Comparing alphabetic priority ..... 350

9.11 Preassigned Q Parameters ..... 351

Values from the PLC: Q100 to Q107 ..... 351

WMAT block: QS100 ..... 351

Active tool radius: Q108 ..... 351

Tool axis: Q109 ..... 352

Spindle status: Q110 ..... 352

Coolant on/off: Q111 ..... 352

Overlap factor: Q112 ..... 352

Unit of measurement for dimensions in the program: Q113 ..... 353

Tool length: Q114 ..... 353

Coordinates after probing during program run ..... 353

Deviation between actual value and nominal value during automatic tool measurement with the TT 130 ..... 354

Tilting the working plane with mathematical angles: rotary axis coordinates calculated by the TNC ..... 354

Measurement results from touch probe cycles (see also User’s Manual for Touch Probe Cycles) ..... 355

9.12 Programming Examples ..... 357

HEIDENHAIN iTNC 530 43

10 Programming: Miscellaneous Functions ..... 365

10.1 Entering Miscellaneous Functions M and STOP ..... 366

Fundamentals ..... 366

10.2 Miscellaneous Functions for Program Run Control, Spindle and Coolant ..... 367

Overview ..... 367

10.3 Miscellaneous Functions for Coordinate Data ..... 368

Programming machine-referenced coordinates: M91/M92 ..... 368

Activating the most recently entered datum: M104 ..... 370

Moving to positions in a non-tilted coordinate system with a tilted working plane: M130 ..... 370

10.4 Miscellaneous Functions for Contouring Behavior ..... 371

Smoothing corners: M90 ..... 371

Insert rounding arc between straight lines: M112 ..... 371

Do not include points when executing non-compensated line blocks: M124 ..... 372

Machining small contour steps: M97 ..... 373

Machining open contours corners: M98 ..... 375

Feed rate factor for plunging movements: M103 ..... 376

Feed rate in millimeters per spindle revolution: M136 ..... 377

Feed rate for circular arcs: M109/M110/M111 ..... 378

Calculating the radius-compensated path in advance (LOOK AHEAD): M120 ..... 379

Superimposing handwheel positioning during program run: M118 ..... 381

Retraction from the contour in the tool-axis direction: M140 ..... 382

Suppressing touch probe monitoring: M141 ..... 383

Delete modal program information: M142 ..... 384

Delete basic rotation: M143 ..... 384

Automatically retract tool from the contour at an NC stop: M148 ..... 385

Suppress limit switch message: M150 ..... 386

10.5 Miscellaneous Functions for Laser Cutting Machines ..... 387

Principle ..... 387

Output the programmed voltage directly: M200 ..... 387

Output voltage as a function of distance: M201 ..... 387

Output voltage as a function of speed: M202 ..... 388

Output voltage as a function of time (time-dependent ramp): M203 ..... 388

Output voltage as a function of time (time-dependent pulse): M204 ..... 388

11 Programming: Special Functions ..... 389

11.1 Overview of Special Functions ..... 390

Main menu for SPEC FCT special functions ..... 390

Program defaults menu ..... 391

Functions for contour and point machining menu ..... 391

Functions for contour and point machining menu ..... 392

Menu of various conversational functions ..... 392

Menu of programming aids ..... 393

11.2 Dynamic Collision Monitoring (Software Option) ..... 394

Function ..... 394

Collision monitoring in the manual operating modes ..... 396

Collision monitoring in Automatic operation ..... 397

Graphic depiction of the protected space (FCL4 function) ..... 398

Collision monitoring in the Test Run mode of operation ..... 399

11.3 Fixture Monitoring (DCM Software Option) ..... 401

Fundamentals ..... 401

Fixture templates ..... 402

Setting parameter values for the fixture: FixtureWizard ..... 402

Placing the fixture on the machine ..... 404

Editing fixtures ..... 405

Removing fixtures ..... 405

Check the position of the measured fixture ..... 406

Manage fixtures ..... 408

11.4 Tool Holder Management (DCM Software Option) ..... 411

Fundamentals ..... 411

Tool-holder templates ..... 411

Set the tool holder parameters: ToolHolderWizard ..... 412

Removing a tool holder ..... 413

11.5 Global Program Settings (Software Option) ..... 414

Application ..... 414

Technical prerequisites ..... 416

Activating/deactivating a function ..... 417

Basic rotation ..... 419

Swapping axes ..... 420

Superimposed mirroring ..... 421

Additional, additive datum shift ..... 421

Axis locking ..... 422

Superimposed rotation ..... 422

Feed rate override ..... 422

Handwheel superimposition ..... 423

HEIDENHAIN iTNC 530 45

11.6 Adaptive Feed Control Software Option (AFC) ..... 425

Application ..... 425

Defining the AFC basic settings ..... 427

Recording a teach-in cut ..... 429

Activating/deactivating AFC ..... 432

Log file ..... 433

Tool breakage/tool wear monitoring ..... 435

Spindle load monitoring ..... 435

11.7 Generate a Backward Program ..... 436

Function ..... 436

Prerequisites for the program to be converted ..... 437

Application example ..... 438

11.8 Filtering Contours (FCL 2 Function) ..... 439

Function ..... 439

11.9 File Functions ..... 440

Application ..... 440

Defining file functions ..... 440

11.10 Defining Coordinate Transformations ..... 441

Overview ..... 441

TRANS DATUM AXIS ..... 441

TRANS DATUM TABLE ..... 442

TRANS DATUM RESET ..... 443

Define program call ..... 444

11.11 smartWizard ..... 445

Application ..... 445

Insert UNIT ..... 446

Edit UNIT ..... 447

11.12 Creating Text Files ..... 448

Application ..... 448

Opening and exiting text files ..... 448

Editing texts ..... 449

Deleting and re-inserting characters, words and lines ..... 450

Editing text blocks ..... 451

Finding text sections ..... 452

11.13 Working with Cutting Data Tables ..... 453

Note ..... 453

Applications ..... 453

Table for workpiece materials ..... 454

Table for tool cutting materials ..... 455

Table for cutting data ..... 455

Data required for the tool table ..... 456

Working with automatic speed / feed rate calculation ..... 457

Data transfer from cutting data tables ..... 458

Configuration file TNC.SYS ..... 458

11.14 Freely Definable Tables ..... 459

Fundamentals ..... 459

Creating a freely definable table ..... 459

Editing the table format ..... 460

Switching between table and form view ..... 461

FN26: TABOPEN: Opening a freely definable table ..... 462

FN 27: TABWRITE: Writing to a freely definable table ..... 463

FN28: TABREAD: Reading a freely definable table ..... 464

HEIDENHAIN iTNC 530 47

12 Programming: Multiple Axis Machining ..... 465

12.1 Functions for Multiple Axis Machining ..... 466

12.2 The PLANE Function: Tilting the Working Plane (Software Option 1) ..... 467

Introduction ..... 467

Define the PLANE function ..... 469

Position display ..... 469

Reset the PLANE function ..... 470

Defining the machining plane with space angles: PLANE SPATIAL ..... 471

Defining the machining plane with projection angles: PROJECTED PLANE ..... 473

Defining the machining plane with Euler angles: EULER PLANE ..... 475

Defining the working plane with two vectors: VECTOR PLANE ..... 477

Defining the machining plane via three points: PLANE POINTS ..... 479

Defining the machining plane with a single, incremental spatial angle: PLANE RELATIVE ..... 481

Tilting the working plane through axis angle: PLANE AXIAL (FCL 3 function) ..... 482

Specifying the positioning behavior of the PLANE function ..... 484

12.3 Inclined-Tool Machining in the Tilted Plane ..... 489

Function ..... 489

Inclined-tool machining via incremental traverse of a rotary axis ..... 489

Inclined-tool machining via normal vectors ..... 490

12.4 TCPM FUNCTION (Software Option 2) ..... 491

Function ..... 491

Define TCPM FUNCTION ..... 492

Mode of action of the programmed feed rate ..... 492

Interpretation of the programmed rotary axis coordinates ..... 493

Type of interpolation between the starting and end position ..... 494

Reset TCPM FUNCTION ..... 495

12.5 Miscellaneous Functions for Rotary Axes ..... 496

Feed rate in mm/min on rotary axes A, B, C: M116 (software option 1) ..... 496

Shorter-path traverse of rotary axes: M126 ..... 497

Reducing display of a rotary axis to a value less than 360°: M94 ..... 498

Automatic compensation of machine geometry when working with tilted axes: M114 (software option 2) ..... 499

Maintaining the position of the tool tip when positioning with tilted axes (TCPM): M128 (software

option 2) ..... 501

Exact stop at corners with nontangential transitions: M134 ..... 504

Selecting tilting axes: M138 ..... 504

Compensating the machine’s kinematics configuration for ACTUAL/NOMINAL positions at end of block: M144

(software option 2) ..... 505

12.6 Three-Dimensional Tool Compensation (Software Option 2) ..... 506

Introduction ..... 506

Definition of a normalized vector ..... 507

Permissible tool forms ..... 508

Using other tools: Delta values ..... 508

3-D compensation without tool orientation ..... 509

Face milling: 3-D compensation with and without tool orientation ..... 509

Peripheral milling: 3-D radius compensation with workpiece orientation ..... 511

3-D tool radius compensation depending on the tool’s contact angle (3D-ToolComp software option) ..... 513

12.7 Contour Movements – Spline Interpolation (Software Option 2) ..... 517

Application ..... 517

HEIDENHAIN iTNC 530 49

13 Programming: Pallet Editor ..... 519

13.1 Pallet Editor ..... 520

Application ..... 520

Selecting a pallet table ..... 522

Leaving the pallet file ..... 522

Pallet datum management with the pallet preset table ..... 523

Executing the pallet file ..... 525

13.2 Pallet Operation with Tool-Oriented Machining ..... 526

Application ..... 526

Selecting a pallet file ..... 531

Setting up the pallet file with the entry form ..... 531

Sequence of tool-oriented machining ..... 536

Leaving the pallet file ..... 537

Executing the pallet file ..... 537

14 Manual Operation and Setup ..... 539

14.1 Switch-On, Switch-Off ..... 540

Switch-on ..... 540

Switch-off ..... 543

14.2 Moving the Machine Axes ..... 544

Note ..... 544

Moving the axis using the machine axis direction buttons ..... 544

Incremental jog positioning ..... 545

Traversing with electronic handwheels ..... 546

14.3 Spindle Speed S, Feed Rate F and Miscellaneous Functions M ..... 556

Function ..... 556

Entering values ..... 556

Changing the spindle speed and feed rate ..... 557

14.4 Datum Setting without a 3-D Touch Probe ..... 558

Note ..... 558

Preparation ..... 558

Workpiece presetting with axis keys ..... 559

Datum management with the preset table ..... 560

14.5 Using the 3-D Touch Probe ..... 566

Overview ..... 566

Selecting probe cycles ..... 567

Recording measured values from the touch-probe cycles ..... 567

Writing the measured values from touch probe cycles in datum tables ..... 568

Writing the measured values from touch probe cycles in the preset table ..... 569

Storing measured values in the pallet preset table ..... 570

14.6 Calibrating a 3-D Touch Probe ..... 571

Introduction ..... 571

Calibrating the effective length ..... 571

Calibrating the effective radius and compensating center misalignment ..... 572

Displaying calibration values ..... 573

Managing more than one block of calibrating data ..... 573

14.7 Compensating Workpiece Misalignment with a 3-D Touch Probe ..... 574

Introduction ..... 574

Basic rotation using 2 points: ..... 576

Determining basic rotation using 2 holes/studs: ..... 578

Workpiece alignment using 2 points ..... 579

HEIDENHAIN iTNC 530 51

14.8 Datum Setting with a 3-D Touch Probe ..... 580

Overview ..... 580

Datum setting in any axis ..... 580

Corner as datum – using points that were already probed for a basic rotation ..... 581

Corner as datum—without using points that were already probed for a basic rotation. ..... 581

Circle center as datum ..... 582

Center line as datum ..... 583

Setting datum points using holes/cylindrical studs ..... 584

Measuring workpieces with a 3-D touch probe ..... 585

Using touch probe functions with mechanical probes or dial gauges ..... 588

14.9 Tilting the Working Plane (Software Option 1) ..... 589

Application, function ..... 589

Traversing the reference points in tilted axes ..... 591

Setting the datum in a tilted coordinate system ..... 591

Datum setting on machines with rotary tables ..... 592

Datum setting on machines with spindle-head changing systems ..... 592

Position display in a tilted system ..... 592

Limitations on working with the tilting function ..... 592

Activating manual tilting ..... 593

Setting the current tool-axis direction as the active machining direction (FCL 2 function) ..... 594

15 Positioning with Manual Data Input ..... 595

15.1 Programming and Executing Simple Machining Operations ..... 596

Positioning with Manual Data Input (MDI) ..... 596

Protecting and erasing programs in $MDI ..... 599

HEIDENHAIN iTNC 530 53

16 Test Run and Program Run ..... 601

16.1 Graphics ..... 602

Application ..... 602

Overview of display modes ..... 604

Plan view ..... 604

Projection in 3 planes ..... 605

3-D view ..... 606

Magnifying details ..... 609

Repeating graphic simulation ..... 610

Displaying the tool ..... 610

Measuring the machining time ..... 611

16.2 Functions for Program Display ..... 612

Overview ..... 612

16.3 Test Run ..... 613

Application ..... 613

16.4 Program Run ..... 619

Application ..... 619

Running a part program ..... 620

Interrupting machining ..... 621

Moving the machine axes during an interruption ..... 623

Resuming program run after an interruption ..... 624

Mid-program startup (block scan) ..... 625

Returning to the contour ..... 628

16.5 Automatic Program Start ..... 629

Application ..... 629

16.6 Optional Block Skip ..... 630

Application ..... 630

Erasing the “/” character ..... 630

16.7 Optional Program-Run Interruption ..... 631

Application ..... 631

17 MOD Functions ..... 633

17.1 Selecting MOD Functions ..... 634

Selecting the MOD functions ..... 634

Changing the settings ..... 634

Exiting the MOD functions ..... 634

Overview of MOD functions ..... 635

17.2 Software Numbers ..... 636

Application ..... 636

17.3 Entering Code Numbers ..... 637

Application ..... 637

17.4 Loading Service Packs ..... 638

Application ..... 638

17.5 Setting the Data Interfaces ..... 639

Application ..... 639

Setting the RS-232 interface ..... 639

Setting the RS-422 interface ..... 639

Setting the OPERATING MODE of the external device ..... 639

Setting the baud rate ..... 639

Assignment ..... 640

Software for data transfer ..... 641

17.6 Ethernet Interface ..... 643

Introduction ..... 643

Connection possibilities ..... 643

Connecting the iTNC directly with a Windows PC ..... 644

Configuring the TNC ..... 646

17.7 Configuring PGM MGT ..... 654

Application ..... 654

Changing the PGM MGT setting ..... 654

Dependent files ..... 655

17.8 Machine-Specific User Parameters ..... 656

Application ..... 656

17.9 Showing the Workpiece in the Working Space ..... 657

Application ..... 657

Rotate the entire image ..... 659

17.10 Position Display Types ..... 660

Application ..... 660

17.11 Unit of Measurement ..... 661

Application ..... 661

17.12 Selecting the Programming Language for $MDI ..... 662

Application ..... 662

17.13 Selecting the Axes for Generating L Blocks ..... 663

Application ..... 663

HEIDENHAIN iTNC 530 55

17.14 Entering the Axis Traverse Limits, Datum Display ..... 664

Application ..... 664

Working without additional traverse limits ..... 664

Find and enter the maximum traverse ..... 664

Datum display ..... 665

17.15 Displaying HELP Files ..... 666

Application ..... 666

Selecting HELP files ..... 666

17.16 Displaying Operating Times ..... 667

Application ..... 667

17.17 Checking the Data Carrier ..... 668

Application ..... 668

Performing the data carrier check ..... 668

17.18 Setting the System Time ..... 669

Application ..... 669

Selecting appropriate settings ..... 669

17.19 TeleService ..... 670

Application ..... 670

Calling/exiting TeleService ..... 670

17.20 External Access ..... 671

Application ..... 671

17.21 Host computer operation ..... 672

Application ..... 672

17.22 Configuring the HR 550 FS Wireless Handwheel ..... 673

Application ..... 673

Assigning the handwheel to a specific handwheel holder ..... 673

Setting the transmission channel ..... 674

Selecting the transmitter power ..... 675

Statistics ..... 675

18 Tables and Overviews ..... 677

18.1 General User Parameters ..... 678

Input possibilities for machine parameters ..... 678

Selecting general user parameters ..... 678

List of general user parameters ..... 679

18.2 Pin Layouts and Connecting Cables for the Data Interfaces ..... 694

RS-232-C/V.24 interface for HEIDENHAIN devices ..... 694

Non-HEIDENHAIN devices ..... 695

RS-422/V.11 interface ..... 696

Ethernet interface RJ45 socket ..... 697

18.3 Technical Information ..... 698

18.4 Exchanging the Buffer Battery ..... 707

HEIDENHAIN iTNC 530 57

19 iTNC 530 with Windows XP (Option) ..... 709

19.1 Introduction ..... 710

End User License Agreement (EULA) for Windows XP ..... 710

General ..... 710

Changes in the pre-installed Windows system ..... 711

Specifications ..... 712

19.2 Starting an iTNC 530 Application ..... 713

Logging on to Windows ..... 713

19.3 Network settings ..... 715

Prerequisite ..... 715

Adjusting the network settings ..... 715

Controlling access ..... 716

19.4 Specifics About File Management ..... 717

The iTNC drive ..... 717

Data transfer to the iTNC 530 ..... 718

First Steps with the iTNC 530

1.1 Overview

This chapter is intended to help TNC beginners quickly learn to handle the most important procedures. For more information on a respective topic, see the section referred to in the text.

The following topics are included in this chapter

 Machine Switch-On

1.1 Overview

 Programming the First Part  Graphically Testing the Program  Tool Setup  Workpiece Setup  Running the First Program

60 First Steps with the iTNC 530

1.2 Machine Switch-On

Acknowledge the power interruption and move to the reference points

Switch-on and crossing the reference points can vary depending on the machine tool. Your machine manual provides more detailed information.

U Switch on the power supply for control and machine. The TNC starts

the operating system. This process may take several minutes. Then the TNC will display the message “Power interruption.”

U Press the CE key: The TNC converts the PLC

program

U Switch on the control voltage: The TNC checks

operation of the emergency stop circuit and goes into the reference run mode

U Cross the reference points manually in the displayed

sequence: For each axis press the machine START button. If you have absolute linear and angle encoders on your machine there is no need for a reference run

The TNC is now ready for operation in the Manual Operation mode.

Further information on this topic

 Traversing the reference marks: See “Switch-on” on page 540  Operating modes: See “Programming and Editing” on page 87

1.2 Machine Switch-On

HEIDENHAIN iTNC 530 61

1.3 Programming the First Part

Select the correct operating mode

You can write programs only in the Programming and Editing mode:

U Press the operating modes key: The TNC goes into

the Programming and Editing mode

Further information on this topic

 Operating modes: See “Programming and Editing” on page 87

The most important TNC keys

Functions for conversational guidance Key

Confirm entry and activate the next dialog prompt

Ignore the dialog question.

1.3 Programming the First Part

End the dialog immediately.

Abort dialog, discard entries.

Soft keys on the screen with which you select functions appropriate to the active state

Further information on this topic

 Writing and editing programs: See “Editing a program” on page 115  Overview of keys: See “Controls of the TNC” on page 2

62 First Steps with the iTNC 530

Create a new program/file management

U Press the PGM MGT key: the TNC displays the file

management. The file management of the TNC is arranged much like the file management on a PC with the Windows Explorer. The file management enables you to manipulate data on the TNC hard disk

U Use the arrow keys to select the folder in which you

want to open the new file

U Enter a file name with the extension .H: The TNC then

automatically opens a program and asks for the unit of measure for the new program. Please note the restrictions regarding special characters in the file name (see “File names” on page 122)

U To select the unit of measure, press the MM or INCH

soft key: The TNC automatically starts the workpiece blank definition (see “Define a workpiece blank” on page 64)

The TNC automatically generates the first and last blocks of the program. Afterwards you can no longer change these blocks.

Further information on this topic

 File management: See “Working with the File Manager” on page

123

 Creating a new program: See “Creating and Writing Programs” on

page 109

1.3 Programming the First Part

HEIDENHAIN iTNC 530 63

Define a workpiece blank

MAX

MIN

-40

100

Immediately after you have created a new program, the TNC starts the dialog for entering the workpiece blank definition. Always define the workpiece blank as a cuboid by entering the MIN and MAX points, each with reference to the selected reference point.

After you have created a new program, the TNC automatically initiates the workpiece blank definition and asks for the required data:

U Spindle axis Z?: Enter the active spindle axis. Z is saved as default

setting. Accept with the ENT key

U Def BLK FORM: Min-corner?: Smallest X coordinate of the workpiece

blank with respect to the reference point, e.g. 0. Confirm with the ENT key

U Def BLK FORM: Min-corner?: Smallest Y coordinate of the workpiece

blank with respect to the reference point, e.g. 0. Confirm with the ENT key

U Def BLK FORM: Min-corner?: Smallest Z coordinate of the workpiece

blank with respect to the reference point, e.g. -40. Confirm with the ENT key

U Def BLK FORM: Max-corner?: Largest X coordinate of the workpiece

1.3 Programming the First Part

blank with respect to the reference point, e.g. 100. Confirm with the ENT key

U Def BLK FORM: Max-corner?: Largest Y coordinate of the workpiece

blank with respect to the reference point, e.g. 100. Confirm with the ENT key

U Def BLK FORM: Max-corner?: Largest Z coordinate of the workpiece

blank with respect to the reference point, e.g. 0. Confirm with the ENT key

Example NC blocks

0 BEGIN PGM NEW MM 1 BLK FORM 0.1 Z X+0 Y+0 Z-40 2 BLK FORM 0.2 X+100 Y+100 Z+0 3 END PGM NEW MM

Further information on this topic

 Defining the workpiece blank: (see page 110)

64 First Steps with the iTNC 530

Program layout

NC programs should be arranged consistently in a similar manner. This makes it easier to find your place and reduces errors.

Recommended program layout for simple, conventional contour machining

1 Call tool, define tool axis 2 Retract the tool 3 Pre-position the tool in the working plane near the contour starting

point

4 In the tool axis, position the tool above the workpiece, or pre-

position immediately to workpiece depth. If required, switch on the spindle/coolant

5 Move to the contour 6 Machine the contour 7 Leave the contour 8 Retract the tool, end the program

Further information on this topic:

 Contour programming: See “Tool Movements” on page 214

Recommended program layout for simple cycle programs 1 Call tool, define tool axis 2 Retract the tool 3 Define the machining positions 4 Define the fixed cycle 5 Call the cycle, switch on the spindle/coolant 6 Retract the tool, end the program

Further information on this topic:

 Cycle programming: See User’s Manual for Cycles

Example: Layout of contour machining programs

0 BEGIN PGM BSPCONT MM 1 BLK FORM 0.1 Z X... Y... Z... 2 BLK FORM 0.2 X... Y... Z... 3 TOOL CALL 5 Z S5000 4 L Z+250 R0 FMAX 5 L X... Y... R0 FMAX 6 L Z+10 R0 F3000 M13 7 APPR ... RL F500 ... 16 DEP ... X... Y... F3000 M9 17 L Z+250 R0 FMAX M2 18 END PGM BSPCONT MM

Example: Cycle program layout

0 BEGIN PGM BSBCYC MM 1 BLK FORM 0.1 Z X... Y... Z... 2 BLK FORM 0.2 X... Y... Z... 3 TOOL CALL 5 Z S5000 4 L Z+250 R0 FMAX 5 PATTERN DEF POS1( X... Y... Z... ) ... 6 CYCL DEF... 7 CYCL CALL PAT FMAX M13 8 L Z+250 R0 FMAX M2 9 END PGM BSBCYC MM

1.3 Programming the First Part

HEIDENHAIN iTNC 530 65

Program a simple contour

The contour shown to the right is to be milled once to a depth of 5 mm. You have already defined the workpiece blank. After you have initiated a dialog through a function key, enter all the data requested by the TNC in the screen header.

U Call the tool: Enter the tool data. Confirm each of your

entries with the ENT key. Do not forget the tool axis

U Retract the tool: Press the orange axis key Z in order

to get clear in the tool axis, and enter the value for the position to be approached, e.g. 250. Confirm with the ENT key

U Confirm Radius comp.: RL/RR/no comp? by pressing

the ENT key: Do not activate the radius compensation

U Confirm Feed rate F=? with the ENT key: Move at

rapid traverse (FMAX)

U Confirm the Miscellaneous function M? with the

END key: The TNC saves the entered positioning block

1.3 Programming the First Part

U Preposition the tool in the working plane: Press the

orange X axis key and enter the value for the position to be approached, e.g. -20

U Press the orange Y axis key and enter the value for the

position to be approached, e.g. -20. Confirm with the ENT key

U Confirm Radius comp.: RL/RR/no comp? by pressing

the ENT key: Do not activate the radius compensation

U Confirm Feed rate F=? with the ENT key: Move at

rapid traverse (FMAX)

U Confirm the Miscellaneous function M? with the

END key: The TNC saves the entered positioning block

U Move the tool to workpiece depth: Press the orange Y

axis key and enter the value for the position to be approached, e.g. -5. Confirm with the ENT key

U Confirm Radius comp.: RL/RR/no comp? by pressing

the ENT key: Do not activate the radius compensation

U Feed rate F=? Enter the positioning feed rate, e.g.

3000 mm/min and confirm with the ENT key

U Miscellaneous function M? Switch on the spindle and

coolant, e.g. M13. Confirm with the END key: The TNC saves the entered positioning block

66 First Steps with the iTNC 530

U Move to the contour: Press the APPR/DEP key: The

TNC shows a soft-key row with approach and departure functions

U Select the approach function APPR CT: Enter the

coordinates of the contour starting point 1 in X and Y, e.g. 5/5. Confirm with the ENT key

U Center angle? Enter the approach angle, e.g.90°, and

confirm with the ENT key

U Circle radius? Enter the approach radius, e.g. 8 mm,

and confirm with the ENT key

U Confirm the Radius comp.: RL/RR/no comp? with the

RL soft key: Activate the radius compensation to the left of the programmed contour

U Feed rate F=? Enter the machining feed rate, e.g.

700 mm/min, and confirm your entry with the END key

U Machine the contour and move to contour point 2: You

only need to enter the information that changes. In other words, enter only the Y coordinate 95 and save your entry with the END key

U Move to contour point 3: Enter the X coordinate 95

and save your entry with the END key

U Define the chamfer at contour point 3: Enter the

chamfer width 10 mm and save with the END key

U Move to contour point 4: Enter the Y coordinate 5 and

save your entry with the END key

U Define the chamfer at contour point 4: Enter the

chamfer width 20 mm and save with the END key

U Move to contour point 1: Enter the X coordinate 5 and

save your entry with the END key

1.3 Programming the First Part

HEIDENHAIN iTNC 530 67

U Contour departure

U Select the departure function DEP CT U Center angle? Enter the departure angle, e.g. 90°, and

confirm with the ENT key

U Circle radius? Enter the departure radius, e.g. 8 mm,

and confirm with the ENT key

U Feed rate F=? Enter the positioning feed rate, e.g.

3000 mm/min and confirm with the ENT key

U Miscellaneous function M? Switch off the coolant,

e.g. M9, with the END key: The TNC saves the entered positioning block

U Retract the tool: Press the orange axis key Z in order

to get clear in the tool axis, and enter the value for the position to be approached, e.g. 250. Confirm with the ENT key

U Confirm Radius comp.: RL/RR/no comp? by pressing

the ENT key: Do not activate the radius compensation

1.3 Programming the First Part

U Confirm Feed rate F=? with the ENT key: Move at

rapid traverse (FMAX)

U Miscellaneous function M? Enter M2 to end the

program and confirm with the END key: The TNC saves the entered positioning block

Further information on this topic

 Complete example with NC blocks: See “Example: Linear

movements and chamfers with Cartesian coordinates” on page 236

 Creating a new program: See “Creating and Writing Programs” on

page 109

 Approaching/departing contours: See “Contour Approach and

Departure” on page 219

 Programming contours: See “Overview of path functions” on page

227

 Programmable feed rates: See “Possible feed rate input” on page

113

 Tool radius compensation: See “Tool radius compensation” on page

209

 Miscellaneous functions (M): See “Miscellaneous Functions for

Program Run Control, Spindle and Coolant” on page 367

68 First Steps with the iTNC 530

Create a cycle program

100

9080

The holes (depth of 20 mm) shown in the figure at right are to be drilled with a standard drilling cycle. You have already defined the workpiece blank.

U Call the tool: Enter the tool data. Confirm each of your

entries with the ENT key. Do not forget the tool axis

U Retract the tool: Press the orange axis key Z in order

to get clear in the tool axis, and enter the value for the position to be approached, e.g. 250. Confirm with the ENT key

U Confirm Radius comp.: RL/RR/no comp? by pressing

the ENT key: Do not activate the radius compensation

U Confirm Feed rate F=? with the ENT key: Move at

rapid traverse (FMAX)

U Confirm the Miscellaneous function M? with the

END key: The TNC saves the entered positioning block

U Call the cycle menu

U Display the drilling cycles

U Select the standard drilling cycle 200: The TNC starts

the dialog for cycle definition. Enter all parameters requested by the TNC step by step and conclude each entry with the ENT key. In the screen to the right, the TNC also displays a graphic showing the respective cycle parameter

1.3 Programming the First Part

HEIDENHAIN iTNC 530 69

U Call the menu for special functions

U Display the functions for point machining

U Select the pattern definition

U Select point entry: Enter the coordinates of the

4 points and confirm each with the ENT key. After entering the fourth point, save the block with the END key

U Display the menu for defining the cycle call

U Run the drilling cycle on the define pattern: U Confirm Feed rate F=? with the ENT key: Move at

rapid traverse (FMAX)

U Miscellaneous function M? Switch on the spindle and

coolant, e.g. M13. Confirm with the END key: The TNC saves the entered positioning block

U Retract the tool: Press the orange axis key Z in order

1.3 Programming the First Part

to get clear in the tool axis, and enter the value for the position to be approached, e.g. 250. Confirm with the ENT key

U Confirm Radius comp.: RL/RR/no comp? by pressing

the ENT key: Do not activate the radius compensation

U Confirm Feed rate F=? with the ENT key: Move at

rapid traverse (FMAX)

U Miscellaneous function M? Enter M2 to end the

program and confirm with the END key: The TNC saves the entered positioning block

70 First Steps with the iTNC 530

Example NC blocks

0 BEGIN PGM C200 MM 1 BLK FORM 0.1 Z X+0 Y+0 Z-40 2 BLK FORM 0.2 X+100 Y+100 Z+0 3 TOOL CALL 5 Z S4500 4 L Z+250 R0 FMAX 5 PATTERN DEF

POS1 (X+10 Y+10 Z+0) POS2 (X+10 Y+90 Z+0) POS3 (X+90 Y+90 Z+0) POS4 (X+90 Y+10 Z+0)

6 CYCL DEF 200 DRILLING

Q200=2 ;SETUP CLEARANCE Q201=-20 ;DEPTH Q206=250 ;FEED RATE FOR PLNGN Q202=5 ;PLUNGING DEPTH Q210=0 ;DWELL TIME AT TOP Q203=-10 ;SURFACE COORDINATE Q204=20 ;2ND SETUP CLEARANCE

Q211=0.2 ;DWELL TIME AT DEPTH 7 CYCL CALL PAT FMAX M13 8 L Z+250 R0 FMAX M2 9 END PGM C200 MM

Definition of workpiece blank

Tool call Retract the tool Define the machining positions.

Define the cycle

1.3 Programming the First Part

Spindle and coolant on, call cycle Retract in the tool axis, end program

Further information on this topic

 Creating a new program: See “Creating and Writing Programs” on

page 109

 Cycle programming: See User’s Manual for Cycles

HEIDENHAIN iTNC 530 71

1.4 Graphically Testing the First Program

Selecting the correct operating mode

You can test programs only in the Test Run mode:

U Press the operating modes key: The TNC goes into

the Test Run mode

Further information on this topic

 Operating modes of the TNC: See “Operating Modes” on page 86  Testing programs: See “Test Run” on page 613

Select the tool table for the test run

You only need to execute this step if you have not activated a tool table in the Test Run mode.

U Press the PGM MGT key: the TNC displays the file

management

U Press the SELECT TYPE soft key: The TNC shows a

soft-key menu for selection of the file type to be displayed

U Press the SHOW ALL soft key: The TNC shows all

saved files in the right window

1.4 Graphically Testing the First Program

U Move the highlight to the left onto the directories

U Move the highlight to the TNC:\ directory

U Move the highlight to the right onto the files

U Move the highlight to the file TOOL.T (active tool

table) and load with the ENT key: TOOL.T receives that status S and is therefore active for the Test Run

U Press the END key: Leave the file manager

Further information on this topic

 Tool management: See “Entering tool data in the table” on page 176  Testing programs: See “Test Run” on page 613

72 First Steps with the iTNC 530

Choose the program you want to test

U Press the PGM MGT key: The TNC displays the file

manager

U Press the LAST FILES soft key: The TNC opens a

pop-up window with the most recently selected files

U Use the arrow keys to select the program that you

want to test. Load with the ENT key

Further information on this topic

 Selecting a program: See “Working with the File Manager” on page

123

Select the screen layout and the view

U Press the key for selecting the screen layout. The TNC

shows all available alternatives in the soft-key row

U Press the PROGRAM + GRAPHICS soft key: In the

left half of the screen the TNC shows the program; in the right half it shows the workpiece blank

U Select the desired view via soft key U Plan view

U Projection in three planes

U 3-D view

Further information on this topic

 Graphic functions: See “Graphics” on page 602  Running a test run: See “Test Run” on page 613

Start the program test

U Press the RESET + START soft key: The TNC

simulates the active program up to a programmed break or to the program end

U While the simulation is running you can use the soft

keys to change views.

U Press the STOP soft key: The TNC interrupts the test

run

U Press the START soft key: The TNC resumes the test

run after a break

Further information on this topic

 Running a test run: See “Test Run” on page 613  Graphic functions: See “Graphics” on page 602  Adjusting the test speed:See “Setting the speed of the test run” on

page 603

1.4 Graphically Testing the First Program

HEIDENHAIN iTNC 530 73

1.5 Tool Setup

Selecting the correct operating mode

Tools are set up in the Manual Operation mode:

U Press the operating modes key: The TNC goes into

the Manual Operation mode

Further information on this topic

1.5 Tool Setup

 Operating modes of the TNC: See “Operating Modes” on page 86

Prepare and measure tools

U Clamp the required tools in their chucks U When measuring with an external tool presetter: Measure the tools,

note down the length and radius, or transfer them directly to the machine through a transfer program

U When measuring on the machine: Place the tools into the tool

changer (see page 75)

The tool table TOOL.T

In the tool table TOOL.T (permanently saved under TNC:\), save the tool data such as length and radius, but also further tool-specific information that the TNC needs to conduct its functions.

To enter tool data in the tool table TOOL.T, proceed as follows:

U Display the tool table U Edit the tool table: Set the EDITING soft key to ON U With the upward or downward arrow keys you can

select the tool number that you want to edit

U With the rightward or leftward arrow keys you can

select the tool data that you want to edit

U To leave the tool table, press the END key

Further information on this topic

 Operating modes of the TNC: See “Operating Modes” on page 86  Working with the tool table: See “Entering tool data in the table” on

page 176

74 First Steps with the iTNC 530

The pocket table TOOL_P.TCH

The function of the pocket table depends on the machine. Your machine manual provides more detailed information.

In the pocket table TOOL_P.TCH (permanently saved under TNC:\) you specify which tools your tool magazine contains.

To enter data in the pocket table TOOL_P.TCH, proceed as follows:

U Display the tool table U Display the pocket table U Edit the pocket table: Set the EDITING soft key to ON U With the upward or downward arrow keys you can

select the pocket number that you want to edit

U With the rightward or leftward arrow keys you can

select the data that you want to edit

U To leave the pocket table, press the END key

Further information on this topic

 Operating modes of the TNC: See “Operating Modes” on page 86  Working with the pocket table: See “Pocket table for tool changer”

on page 188

1.5 Tool Setup

HEIDENHAIN iTNC 530 75

1.6 Workpiece Setup

Selecting the correct operating mode

Workpieces are set up in the Manual Operation or Electronic Handwheel mode

U Press the Manual Operation operating mode key: the

TNC switches to that mode.

Further information on this topic

 Manual Operation mode: See “Moving the Machine Axes” on page

544

1.6 Workpiece Setup

Clamp the workpiece

Mount the workpiece with a fixture on the machine table. If you have a 3-D touch probe on your machine, then you do not need to clamp the workpiece parallel to the axes.

If you do not have a 3-D touch probe available, you have to align the workpiece so that it is fixed with its edges parallel to the machine axes.

76 First Steps with the iTNC 530

Align the workpiece with a 3-D touch probe system

U Insert the 3-D touch probe: In the Manual Data Input (MDI) operating

mode, run a TOOL CALL block containing the tool axis, and then return to the Manual Operation mode (in MDI mode you can run an individual NC block independently of the others)

U Select the probing functions: The TNC displays the

available functions in the soft-key row

U Measure the basic rotation: The TNC displays the

basic rotation menu. To identify the basic rotation, probe two points on a straight surface of the workpiece

U Use the axis-direction keys to pre-position the touch

probe to a position near the first contact point

U Select the probing direction via soft key U Press NC start: The touch probe moves in the defined

direction until it contacts the workpiece and then automatically returns to its starting point.

U Use the axis-direction keys to pre-position the touch

probe to a position near the second contact point

U Press NC start: The touch probe moves in the defined

direction until it contacts the workpiece and then automatically returns to its starting point

U Then the TNC shows the measured basic rotation U Press the END key to close the menu and then

answer the question of whether the basic rotation should be transferred to the preset table by pressing the NO ENT key (no transfer)

1.6 Workpiece Setup

Further information on this topic

 MDI operating mode: See “Programming and Executing Simple

Machining Operations” on page 596

 Workpiece alignment: See “Compensating Workpiece

Misalignment with a 3-D Touch Probe” on page 574

HEIDENHAIN iTNC 530 77

Set the datum with a 3-D touch probe

U Insert the 3-D touch probe: In the MDI mode, run a TOOL CALL block

containing the tool axis and then return to the Manual Operation mode

U Select the probing functions: The TNC displays the

available functions in the soft-key row

U Set the reference point at a workpiece corner, for

example: The TNC asks whether the prove points from the previously measured basic rotation should be loaded. Press the ENT key to load points

U Position the touch probe at a position near the first

touch point of the side that was not probed for basic

1.6 Workpiece Setup

rotation

U Select the probing direction via soft key U Press NC start: The touch probe moves in the defined

direction until it contacts the workpiece and then automatically returns to its starting point

U Use the axis-direction keys to pre-position the touch

probe to a position near the second contact point

U Press NC start: The touch probe moves in the defined

direction until it contacts the workpiece and then automatically returns to its starting point

U Then the TNC shows the coordinates of the measured

corner point

U Set to 0: Press the SET DATUM soft key U Press the END to close the menu

Further information on this topic

 Datum setting: See “Datum Setting with a 3-D Touch Probe” on

page 580

78 First Steps with the iTNC 530

1.7 Running the First Program

Selecting the correct operating mode

You can run programs either in the Single Block or the Full Sequence mode:

U Press the operating mode key: The TNC goes into the

Program Run, Single Block mode and the TNC executes the program block by block. You have to confirm each block with the NC key

U Press the operating mode key: The TNC goes into the

Program Run, Full Sequence mode and the TNC executes the program after NC start up to a program break or to the end of the program

Further information on this topic

 Operating modes of the TNC: See “Operating Modes” on page 86  Running programs: See “Program Run” on page 619

Choose the program you want to run

U Press the PGM MGT key: The TNC displays the file

manager

U Press the LAST FILES soft key: The TNC opens a pop-

up window with the most recently selected files

U If desired, use the arrow keys to select the program

that you want to run. Load with the ENT key

Further information on this topic

 File management: See “Working with the File Manager” on page

123

Start the program

U Press the NC start button: The TNC executes the

active program

Further information on this topic

 Running programs: See “Program Run” on page 619

1.7 Running the First Program

HEIDENHAIN iTNC 530 79

1.7 Running the First Program

80 First Steps with the iTNC 530

Introduction

2.1 The iTNC 530

HEIDENHAIN TNC controls are workshop-oriented contouring controls that enable you to program conventional machining operations right at the machine in an easy-to-use conversational programming language. They are designed for milling, drilling and boring machines, as well as for machining centers. The iTNC 530 can control up to 18 axes. You can also change the angular position of up to 2 spindles under program control.

An integrated hard disk provides storage for as many programs as you like, even if they were created off-line. For quick calculations you can

2.1 The iTNC 530

call up the on-screen pocket calculator at any time. Keyboard and screen layout are clearly arranged in such a way that the

functions are fast and easy to use.

Programming: HEIDENHAIN conversational, smarT.NC and ISO formats

The HEIDENHAIN conversational programming format is an especially easy method of writing programs. Interactive graphics illustrate the individual machining steps for programming the contour. If a production drawing is not dimensioned for NC, the FK free contour programming performs the necessary calculations automatically. Workpiece machining can be graphically simulated either during or before actual machining.

The smarT.NC operating mode offers TNC beginners an especially simple possibility to quickly and without much training create structured conversational dialog programs. Separate user documentation is available for smarT.NC.

It is also possible to program the TNCs in ISO format or DNC mode. You can also enter and test one program while the control is running

another.

Compatibility

The TNC can run all part programs that were written on HEIDENHAIN controls TNC 150 B and later. In as much as old TNC programs contain OEM cycles, the iTNC 530 must be adapted to them with the PC software CycleDesign. For more information, contact your machine tool builder or HEIDENHAIN.

82 Introduction

2.2 Visual Display Unit and

131

678

Keyboard

Visual display unit

The TNC is shipped with a 15-inch color flat-panel screen.

1 Header

When the TNC is on, the selected operating modes are shown in the screen header: the machining mode at the left and the programming mode at right. The currently active mode is displayed in the larger box, where the dialog prompts and TNC messages also appear (unless the TNC is showing only graphics).

2 Soft keys

In the footer the TNC indicates additional functions in a soft-key row. You can select these functions by pressing the keys immediately below them. The lines immediately above the softkey row indicate the number of soft-key rows that can be called with the black arrow keys to the right and left. The active soft-key row is indicated by brightened bar.

3 Soft-key selection keys 4 Shifts between soft-key rows 5 Setting the screen layout 6 Shift key for switchover between machining and programming

modes

7 Soft-key selection keys for machine tool builder soft keys 8 Switches soft-key rows for machine tool builders 9 USB connection

2.2 Visual Display Unit and Keyboard

HEIDENHAIN iTNC 530 83

Sets the screen layout

You select the screen layout yourself: In the PROGRAMMING AND EDITING mode of operation, for example, you can have the TNC show program blocks in the left window while the right window displays programming graphics. You could also display the program structure in the right window instead, or display only program blocks in one large window. The available screen windows depend on the selected operating mode.

To change the screen layout:

Press the SPLIT SCREEN key: The soft-key row shows the available layout options (see "Operating Modes", page 86)

Select the desired screen layout.

2.2 Visual Display Unit and Keyboard

84 Introduction

Operating panel

The TNC is delivered with different keyboards. The figure shows the controls and displays of the TE 730 keyboard unit.

1 Alphabetic keyboard for entering texts and file names, and for ISO

programming. Dual-processor version: Additional keys for Windows operation

2  File management

 Calculator  MOD function  HELP function

3 Programming modes 4 Machine operating modes 5 Initiation of programming dialog 6 Navigation keys and GOTO jump command 7 Numerical input and axis selection 8 Touchpad 9 smarT.NC navigation keys 10 USB connection

The functions of the individual keys are described on the inside front cover.

Some machine manufacturers do not use the standard operating panel from HEIDENHAIN. Please refer to your machine manual in these cases.

Machine panel buttons, e.g. NC START or NC STOP, are also described in the manual for your machine tool.

2.2 Visual Display Unit and Keyboard

HEIDENHAIN iTNC 530 85

2.3 Operating Modes

Manual Operation and Electronic Handwheel

The Manual Operation mode is required for setting up the machine tool. In this mode of operation, you can position the machine axes manually or by increments, set the datums, and tilt the working plane.

The Electronic Handwheel mode of operation allows you to move the machine axes manually with the HR electronic handwheel.

Soft keys for selecting the screen layout (select as described previously)

Window Soft key

2.3 Operating Modes

Positions

Left: positions, right: status display

Left: positions, right: active collision objects (FCL4 function).

Positioning with Manual Data Input

This mode of operation is used for programming simple traversing movements, such as for face milling or pre-positioning.

Soft keys for selecting the screen layout

Window Soft key

Program

Left: program blocks, right: status display

Left: program blocks, right: active collision objects (FCL4 function). If this view is selected, then the TNC indicates a collision with a red frame around the graphics window.

86 Introduction

Programming and Editing

In this mode of operation you can write your part programs. The FK free programming feature, the various cycles and the Q parameter functions help you with programming and add necessary information. If desired, the programming graphics or the 3-D line graphics (FCL 2 function) display the programmed traverse paths.

Soft keys for selecting the screen layout

Window Soft key

Program

Left: program, right: program structure

Left: program blocks, right: graphics

Left: program blocks, right: 3-D line graphics

3-D line graphics

Test Run

In the Test Run mode of operation, the TNC checks programs and program sections for errors, such as geometrical incompatibilities, missing or incorrect data within the program or violations of the work space. This simulation is supported graphically in different display modes.

With the dynamic collision monitoring (DCM) software option you can test the program for potential collisions. As during program run, the TNC takes into account all permanent machine components defined by the machine manufacturer as well as all measured fixtures.

Soft keys for selecting the screen layout: see "Program Run, Full Sequence and Program Run, Single Block", page 88.

2.3 Operating Modes

HEIDENHAIN iTNC 530 87

Program Run, Full Sequence and Program Run, Single Block

In the Program Run, Full Sequence mode of operation the TNC executes a part program continuously to its end or to a manual or programmed stop. You can resume program run after an interruption.

In the Program Run, Single Block mode of operation you execute each block separately by pressing the machine START button.

Soft keys for selecting the screen layout

Window Soft key

Program

2.3 Operating Modes

Left: program, right: program structure

Left: program, right: status

Left: program, right: graphics

Graphics

Left: program blocks, right: active collision objects (FCL4 function). If this view is selected, then the TNC indicates a collision with a red frame around the graphics window.

Active collision objects (FCL4 function). If this view is selected, then the TNC indicates a collision with a red frame around the graphics window.

Soft keys for selecting the screen layout for pallet tables

Window Soft key

Pallet table

Left: program blocks, right: pallet table

Left: pallet table, right: status

Left: pallet table, right: graphics

88 Introduction

2.4 Status Displays

ACTL.

X Y Z

F S M

“General” status display

The status display in the lower part of the screen informs you of the current state of the machine tool. It is displayed automatically in the following modes of operation:

 Program Run, Single Block and Program Run, Full Sequence, except

if the screen layout is set to display graphics only, and

 Positioning with Manual Data Input (MDI).

In the Manual mode and Electronic Handwheel mode the status display appears in the large window.

Information in the status display

Symbol Meaning

Actual or nominal coordinates of the current position

Machine axes; the TNC displays auxiliary axes in lower-case letters. The sequence and quantity of displayed axes is determined by the machine tool builder. Refer to your machine manual for more information.

The displayed feed rate in inches corresponds to one tenth of the effective value. Spindle speed S, feed rate F and active M functions.

2.4 Status Displays

Program run started.

Axis is locked.

Axis can be moved with the handwheel.

Axes are moving under a basic rotation.

Axes are moving in a tilted working plane.

The M128 function or TCPM FUNCTION is active.

HEIDENHAIN iTNC 530 89

Symbol Meaning

2.4 Status Displays

The Dynamic Collision Monitoring function (DCM) is active.

The Adaptive Feed Function (AFC) is active (software option).

One or more global program settings are active (software option)

Number of the active presets from the preset table. If the datum was set manually, the TNC displays the text MAN behind the symbol.

90 Introduction

Additional status displays

The additional status displays contain detailed information on the program run. They can be called in all operating modes except for the Programming and Editing mode of operation.

To switch on the additional status display:

Call the soft-key row for screen layout.

Screen layout with additional status display: In the right half of the screen, the TNC shows the Overview status form.

To select an additional status display:

Shift the soft-key rows until the STATUS soft keys appear.

Either select the additional status display, e.g. positions and coordinates, or

2.4 Status Displays

use the soft keys to select the desired view.

With the soft keys or switch-over soft keys, you can choose directly between the available status displays.

Please note that some of the status information described below is not available unless the associated software option is enabled on your TNC.

HEIDENHAIN iTNC 530 91

Overview

After switch-on, the TNC displays the Overview status form, provided that you have selected the PROGRAM+STATUS screen layout (or POSITION + STATUS). The overview form contains a summary of the most important status information, which you can also find on the various detail forms.

Soft key Meaning

Position display in up to 5 axes

Tool information

2.4 Status Displays

General program information (PGM tab)

Soft key Meaning

No direct selection possible

Active M functions

Active coordinate transformations

Active subprogram

Active program section repeat

Program called with PGM CALL

Current machining time

Name of the active main program

Circle center CC (pole)

Dwell time counter

Machining time when the program was completely simulated in the Test Run operating mode

Current machining time in percent

Current time

Current feed rate

Active programs

92 Introduction

General pallet information (PAL tab)

Soft key Meaning

No direct selection possible

Program section repeat/Subprograms (LBL tab)

Soft key Meaning

No direct selection possible

Information on standard cycles (CYC tab)

Soft key Meaning

No direct selection possible

Number of the active pallet preset

Active program section repeats with block number, label number, and number of programmed repeats/repeats yet to be run

Active subprogram numbers with block number in which the subprogram was called and the label number that was called

Active machining cycle

Active values of Cycle 32 Tolerance

2.4 Status Displays

HEIDENHAIN iTNC 530 93

Active miscellaneous functions M (M tab)

Soft key Meaning

No direct selection possible

List of the active M functions with fixed meaning

List of the active M functions that are adapted by your machine manufacturer

2.4 Status Displays

94 Introduction

Positions and coordinates (POS tab)

Soft key Meaning

Type of position display, e.g. actual position

Value traversed in virtual axis direction VT (only with “global program settings” software option)

Tilt angle of the working plane

Angle of a basic rotation

Information on tools (TOOL tab)

Soft key Meaning

 T: Tool number and name  RT: Number and name of a replacement tool

Tool axis

Tool lengths and radii

Oversizes (delta values) from the tool table (TAB) and the TOOL CALL (PGM)

Tool life, maximum tool life (TIME 1) and maximum tool life for TOOL CALL (TIME 2)

Display of the active tool and the (next) replacement tool

2.4 Status Displays

HEIDENHAIN iTNC 530 95

Tool measurement (TT tab)

The TNC only displays the TT tab if the function is active on your machine.

Soft key Meaning

No direct selection possible

Number of the tool to be measured

2.4 Status Displays

Coordinate transformations (TRANS tab)

Soft key Meaning

Display whether the tool radius or the tool length is being measured

MIN and MAX values of the individual cutting edges and the result of measuring the rotating tool (DYN = dynamic measurement)

Cutting edge number with the corresponding measured value. If the measured value is followed by an asterisk, the allowable tolerance in the tool table was exceeded The TNC displays the measured values of up to 24 teeth.

Name of the active datum table

Active datum number (#), comment from the active line of the active datum number (DOC) from Cycle 7

Active datum shift (Cycle 7); The TNC displays an active datum shift in up to 8 axes

Mirrored axes (Cycle 8)

Active basic rotation

Active rotation angle (Cycle 10)

Active scaling factor/factors (Cycles 11 / 26); The TNC displays an active scaling factor in up to 6 axes

Scaling datum

For further information, refer to the User's Manual for Cycles, "Coordinate Transformation Cycles."

96 Introduction

Global program settings 1 (GPS1 tab, software option)

The TNC only displays the tab if the function is active on your machine.

Soft key Meaning

No direct selection possible

Swapped axes

Superimposed datum shift

Superimposed mirroring

Global program settings 2 (GPS2 tab, software option)

The TNC only displays the tab if the function is active on your machine.

Soft key Meaning

No direct selection possible

Locked axes

Superimposed basic rotation

Superimposed rotation

Active feed rate factor

2.4 Status Displays

HEIDENHAIN iTNC 530 97

Adaptive Feed Control (AFC tab, software option)

The TNC only displays the AFC tab if the function is active on your machine.

Soft key Meaning

No direct selection possible

Active mode in which adaptive feed control is running

2.4 Status Displays

Active tool (number and name)

Cut number

Current factor of the feed potentiomenter in percent

Active spindle load in percent

Reference load of the spindle

Current spindle speed

Current deviation of the speed

Current machining time

Line diagram, in which the current spindle load and the value commanded by the TNC for the feed-rate override are shown

98 Introduction

2.5 Window Manager

The machine tool builder determines the scope of function and behavior of the window manager. The machine tool manual provides further information.

The TNC features the Xfce window manager. Xfce is a standard application for UNIX-based operating systems, and is used to manage graphical user interfaces. The following functions are possible with the window manager:

 Display a task bar for switching between various applications (user

interfaces).

 Manage an additional desktop, on which special applications from

your machine tool builder can run.

 Control the focus between NC-software applications and those of

the machine tool builder.

 The size and position of pop-up windows can be changed. It is also

possible to close, minimize and restore the pop-up windows.

The TNC shows a star in the upper left of the screen if an application of the window manager or the window manager itself has caused an error. In this case, switch to the window manager and correct the problem. If required, refer to your machine manual.

2.5 Window Manager

HEIDENHAIN iTNC 530 99

2.6 Accessories: HEIDENHAIN 3-D Touch Probes and Electronic Handwheels

3-D touch probes

With the various HEIDENHAIN 3-D touch probe systems you can:

 Automatically align workpieces  Quickly and precisely set datums  Measure the workpiece during program run  Measure and inspect tools

All of the touch probe functions are described in the User’s Manual for Cycles. Please contact HEIDENHAIN if you require a copy of this User’s Manual. ID: 670 388-xx.

Note that HEIDENHAIN generally does not accept liability for the function of the touch probe cycles unless you use HEIDENHAIN touch probes!

TS 220, TS 640 and TS 440 touch trigger probes

These touch probes are particularly effective for automatic workpiece alignment, datum setting and workpiece measurement. The TS 220 transmits the triggering signals to the TNC via cable and is a costeffective alternative for applications where digitizing is not frequently required.

The TS 640 (see figure) and the smaller TS 440 feature infrared transmission of the triggering signal to the TNC. This makes them highly convenient for use on machines with automatic tool changers.

Principle of operation: HEIDENHAIN triggering touch probes feature a wear resisting optical switch that generates an electrical signal as soon as the stylus is deflected. This signal is transmitted to the control, which stores the current position of the stylus as the actual value.

2.6 Accessories: HEIDENHAIN 3-D Touch Probes and Electronic Handwheels

100 Introduction

heidenhain iTNC 530 Programming Manual

Specifications and Main Features

Frequently Asked Questions

User Manual

Controls of the TNC

Keys on visual display unit

Alphanumeric keyboard

Machine operating modes

Program/file management, TNC functions

Navigation keys

Potentiometer for feed rate and spindle speed

Programming modes

Cycles, subprograms and program section repeats

Tool functions

Coordinate axes and numbers: Entering and editing

Programming path movements

Special functions / smarT.NC

About this Manual

Would you like any changes, or have you found any errors?

TNC Model, Software and Features

Software options

Feature content level (upgrade functions)

Intended place of operation

Legal information

New functions in 340 49x-01 since the predecessor versions 340 422-xx/340 423-xx

New functions with 340 49x-02

New functions with 340 49x-03

New functions with 340 49x-04

New functions with 340 49x-05

New functions 340 49x-06

New Functions with 340 49x-07

Changed functions in 340 49x-01 since the predecessor versions 340 422-xx/340 423-xx

Functions changed in 340 49x-02

Changed functions with 340 49x-03

Changed functions with 340 49x-04

Changed functions with 340 49x-05

Changed functions 340 49x-06

Changed functions with 340 49x-07

1 First Steps with the iTNC 530 ..... 59

2 Introduction ..... 81

3 Programming: Fundamentals, File Management ..... 103

4 Programming: Programming Aids ..... 149

5 Programming: Tools ..... 171

6 Programming: Programming Contours ..... 213

7 Programming: Data Transfer from DXF Files or Plain-language Contours ..... 267

8 Programming: Subprograms and Program Section Repeats ..... 285

9 Programming: Q-Parameters ..... 301

10 Programming: Miscellaneous Functions ..... 365

11 Programming: Special Functions ..... 389

12 Programming: Multiple Axis Machining ..... 465

13 Programming: Pallet Editor ..... 519

14 Manual Operation and Setup ..... 539

15 Positioning with Manual Data Input ..... 595

16 Test Run and Program Run ..... 601

17 MOD Functions ..... 633

18 Tables and Overviews ..... 677

19 iTNC 530 with Windows XP (Option) ..... 709

First Steps with the iTNC 530

1.1 Overview

Acknowledge the power interruption and move to the reference points

1.2 Machine Switch-On

Select the correct operating mode

The most important TNC keys

1.3 Programming the First Part

Create a new program/file management

Define a workpiece blank

Program layout

Program a simple contour

Create a cycle program

Selecting the correct operating mode

Select the tool table for the test run

1.4 Graphically Testing the First Program

Choose the program you want to test

Select the screen layout and the view

Start the program test

Selecting the correct operating mode

1.5 Tool Setup

Prepare and measure tools

The tool table TOOL.T

The pocket table TOOL_P.TCH
