DTC - List Modified for FSDS
Diagnosisand Fehlercodes
Referenced ECU Software |
|
|
P490_: 220, 310, |
501 |
P492_: 213 |
P491_: 220, 310, |
400, 501 |
P513_: 214, 300 |
Error Path |
DEUTZ |
SPN |
Blink |
|
|
Error Path |
DEUTZ |
SPN |
Blink |
|
|
Error Path |
DEUTZ |
SPN |
Blink |
AirFltSysReac |
11 |
107 |
1-3-6 |
|
|
CTLpCD |
54 |
704 |
1-2-3 |
|
|
FrmMngTOSwtOut |
117 |
523238 |
1-1-5 |
APP1 |
12 |
91 |
2-2-6 |
|
|
CTSCD |
55 |
110 |
2-2-5 |
|
|
FrmMngTOTCO1 |
118 |
523222 |
1-1-6 |
APPPwm |
14 |
91 |
2-2-2 |
|
|
CTSCDSysReac |
56 |
110 |
2-3-2 |
|
|
FrmMngTOTSC1AE |
120 |
523605 |
1-1-8 |
APPPwmPer |
15 |
91 |
2-2-2 |
|
|
Dummy1CD_Max |
57 |
701 |
1-0-0 |
|
|
FrmMngTOTSC1AR |
121 |
523606 |
1-1-9 |
APSCD |
16 |
108 |
2-9-2 |
|
|
Dummy1CD_Min |
58 |
701 |
1-0-0 |
|
|
FrmMngTOTSC1DE |
122 |
523607 |
1-1-8 |
ArHt1 |
17 |
729 |
2-6-3 |
|
|
Dummy1CD_SigNpl |
59 |
701 |
1-0-0 |
|
|
FrmMngTOTSC1DR |
123 |
523608 |
1-1-9 |
ArHt2 |
18 |
730 |
2-6-3 |
|
|
Dummy2CD_Max |
60 |
702 |
1-0-0 |
|
|
FrmMngTOTSC1PE |
124 |
523609 |
1-1-8 |
ArHtCD_NoLd |
19 |
676 |
2-6-3 |
|
|
Dummy2CD_Min |
61 |
702 |
1-0-0 |
|
|
FrmMngTOTSC1TE |
125 |
898 |
1-1-8 |
ArHtCD_RlyErr |
20 |
676 |
2-6-3 |
|
|
Dummy2CD_SigNpl |
62 |
702 |
1-0-0 |
|
|
FrmMngTOTSC1TR |
126 |
520 |
1-1-9 |
BattCD |
22 |
168 |
3-1-8 |
|
|
EGRCD_Max |
69 |
2791 |
4-1-4 |
|
|
FrmMngTOTSC1VE |
127 |
523610 |
1-1-8 |
BattCDSysReac |
23 |
168 |
3-1-8 |
|
|
EGRCD_Min |
70 |
2791 |
4-1-4 |
|
|
FrmMngTOTSC1VR |
128 |
523611 |
1-1-9 |
BIPCyl1 |
24 |
523561 |
5-3-1 |
|
|
EGRCD_SigNpl |
71 |
2791 |
4-1-5 |
|
|
FrmMngTxTO |
131 |
523500 |
2-7-1 |
BIPCyl2 |
25 |
523562 |
5-3-2 |
|
|
EGRCDIntEGR |
72 |
2791 |
4-1-6 |
|
|
FTSCD |
133 |
174 |
2-2-7 |
BIPCyl3 |
26 |
523563 |
5-3-3 |
|
|
EngCDTrqCalcOut |
74 |
923 |
5-5-5 |
|
|
FTSCDSysReac |
134 |
174 |
2-3-7 |
BIPCyl4 |
27 |
523564 |
5-3-4 |
|
|
EngMBackUp |
75 |
190 |
2-1-2 |
|
|
GOTSCD |
136 |
523618 |
1-3-3 |
BIPCyl5 |
28 |
523565 |
5-3-5 |
|
|
EngMCaS1 |
76 |
190 |
2-1-2 |
|
|
GOTSCDSysReac |
137 |
523619 |
1-3-3 |
BIPCyl6 |
29 |
523566 |
5-3-6 |
|
|
EngMCrS1 |
77 |
190 |
2-1-2 |
|
|
HdThrt |
138 |
29 |
1-2-6 |
BIPCyl7 |
30 |
523567 |
5-3-7 |
|
|
EngMOfsCaSCrS |
78 |
190 |
2-1-3 |
|
|
HOTSCD |
139 |
1638 |
3-1-4 |
BIPCyl8 |
31 |
523568 |
5-3-8 |
|
|
EngPrtSysReacFOC |
79 |
190 |
2-1-4 |
|
|
HOTSCDSysReac |
140 |
1638 |
3-1-4 |
BPSCD |
32 |
102 |
2-2-3 |
|
|
EngPrtSysReacORC |
80 |
190 |
2-1-4 |
|
|
HWEMonCom |
141 |
523617 |
5-5-5 |
BPSCDSysReac |
33 |
102 |
2-2-3 |
|
|
ESLpCD |
81 |
703 |
1-4-2 |
|
|
HWEMonEEPROM |
142 |
630 |
2-8-1 |
CLSCDSysReac |
37 |
111 |
2-3-5 |
|
|
ExFlCD |
82 |
1074 |
2-1-9 |
|
|
HWEMonRcyLocked |
143 |
523612 |
5-5-5 |
CmbChbMisfire1 |
38 |
1323 |
2-4-1 |
|
|
FanCD |
83 |
975 |
2-3-8 |
|
|
HWEMonRcySuppressed |
144 |
523612 |
5-5-5 |
CmbChbMisfire2 |
39 |
1324 |
2-4-1 |
|
|
FanCDEval |
85 |
1639 |
2-3-8 |
|
|
HWEMonRcyVisible |
145 |
523612 |
5-5-5 |
CmbChbMisfire3 |
40 |
1325 |
2-4-1 |
|
|
FanCDSysReac |
86 |
523602 |
2-3-8 |
|
|
HWEMonUMaxSupply |
146 |
523612 |
5-5-5 |
CmbChbMisfire4 |
41 |
1326 |
2-4-1 |
|
|
FlFCD |
87 |
97 |
2-2-8 |
|
|
HWEMonUMinSupply |
147 |
523612 |
5-5-5 |
CmbChbMisfire5 |
42 |
1327 |
2-4-1 |
|
|
FlFCD_WtLvl |
89 |
97 |
2-2-8 |
|
|
IATSCDk |
149 |
105 |
1-2-8 |
CmbChbMisfire6 |
43 |
1328 |
2-4-1 |
|
|
FlPSCD |
90 |
94 |
2-1-6 |
|
|
IATSCDSysReac |
150 |
105 |
2-3-3 |
CmbChbMisfire7 |
44 |
1450 |
2-4-1 |
|
|
FlPSCDSysReac |
91 |
94 |
2-1-6 |
|
|
InjVlvBnk1A |
153 |
523350 |
1-5-1 |
CmbChbMisfire8 |
45 |
1451 |
2-4-1 |
|
|
FrmMngDecV1 |
94 |
523239 |
5-2-6 |
|
|
InjVlvBnk1B |
154 |
523351 |
1-5-1 |
CmbChbMisfireMul |
46 |
1322 |
2-4-1 |
|
|
FrmMngFunModCtl |
95 |
523240 |
5-2-7 |
|
|
InjVlvCyl2A |
155 |
523352 |
1-5-2 |
CmbChbSysReac |
47 |
1346 |
2-4-1 |
|
|
FrmMngTOEngPrt |
106 |
523212 |
3-3-3 |
|
|
InjVlvBnk2B |
156 |
523353 |
1-5-2 |
CoEngShOffDemIgr |
48 |
1109 |
3-4-1 |
|
|
FrmMngTOPrHtEnCmd |
110 |
523216 |
3-3-7 |
|
|
InjVlvChipA |
157 |
523354 |
1-5-3 |
CRERCD |
52 |
1072 |
5-2-8 |
|
|
FrmMngTORxCCVS |
112 |
523218 |
1-1-1 |
|
|
InjVlvChipB |
158 |
523355 |
1-5-3 |
CSLpCD |
53 |
1081 |
3-2-8 |
|
|
FrmMngTORxEngTemp |
113 |
523604 |
1-1-2 |
|
|
InjVlvCyl1A |
159 |
651 |
1-5-4 |
DEUTZ AG, VS-TA, Fi, Su |
Page 1 von 67 |
Rev. 2.0 |
DTC - List
Diagnosisand Fehlercodes
Referenced ECU Software |
|
|
P490_: 220, 310, |
501 |
P492_: 213 |
P491_: 220, 310, |
400, 501 |
P513_: 214, 300 |
Error Path |
DEUTZ |
|
SPN |
|
Blink |
|
|
|
Error Path |
DEUTZ |
|
SPN |
|
Blink |
|
|
|
Error Path |
DEUTZ |
SPN |
Blink |
|
InjVlvCyl1B |
160 |
|
651 |
|
1-5-4 |
|
|
|
OPSCDSysReacHi |
198 |
|
100 |
|
2-3-1 |
|
|
|
RailMeUn8 |
245 |
523010 |
2-5-4 |
|
InjVlvCyl2A |
161 |
|
652 |
|
1-5-5 |
|
|
|
OPSCDSysReacLo |
199 |
|
100 |
|
2-3-1 |
|
|
|
FlSys_FLPFMSysReac |
246 |
523650 |
5-4-1 |
|
InjVlvCyl2B |
162 |
|
652 |
|
1-5-5 |
|
|
|
OSwCD |
200 |
|
1237 |
|
1-4-5 |
|
|
|
FlSys_FTSFMSysReac |
247 |
523651 |
5-4-2 |
|
InjVlvCyl3A |
163 |
|
653 |
|
1-5-6 |
|
|
|
OTSCD |
201 |
|
175 |
|
1-4-4 |
|
|
|
FlSys_FlushStateEngineOff |
248 |
523652 |
5-4-3 |
|
InjVlvCyl3B |
164 |
|
653 |
|
1-5-6 |
|
|
|
OTSCDSysReac |
203 |
|
175 |
|
1-4-4 |
|
|
|
FlSys_RapeOilHeatEx |
249 |
523653 |
5-4-4 |
|
InjVlvCyl4A |
165 |
|
654 |
|
1-6-1 |
|
|
|
PRVMon |
208 |
|
523470 |
|
1-4-6 |
|
|
|
FrmMngDieselLvl |
250 |
523654 |
5-4-5 |
|
InjVlvCyl4B |
166 |
|
654 |
|
1-6-1 |
|
|
|
RailCD |
209 |
|
157 |
|
1-4-7 |
|
|
|
FrmMngFuelTemp |
251 |
523655 |
5-4-6 |
|
InjVlvCyl5A |
167 |
|
655 |
|
1-6-2 |
|
|
|
RailCDOfsTst |
210 |
|
157 |
|
1-4-7 |
|
|
|
FrmMngLowPressureDiesel |
252 |
523656 |
5-4-7 |
|
InjVlvCyl5B |
168 |
|
655 |
|
1-6-2 |
|
|
|
RailMeUn0 |
211 |
|
523613 |
|
1-3-4 |
|
|
|
FrmMngRapeOilIn |
253 |
523657 |
5-6-1 |
|
InjVlvCyl6A |
169 |
|
656 |
|
1-6-3 |
|
|
|
RailMeUn1 |
212 |
|
523613 |
|
1-3-4 |
|
|
|
FrmMngRapeOilLvl |
254 |
523658 |
5-6-2 |
|
InjVlvCyl6B |
170 |
|
656 |
|
1-6-3 |
|
|
|
RailMeUn2 |
213 |
|
523613 |
|
1-3-4 |
|
|
|
FrmMngRapeOilVlv1 |
255 |
523659 |
5-6-3 |
|
InjVlvCyl7A |
171 |
|
657 |
|
1-6-4 |
|
|
|
RailMeUn3 |
214 |
|
523613 |
|
1-3-4 |
|
|
|
FrmMngRapeOilVlv2 |
256 |
523660 |
5-6-4 |
|
InjVlvCyl7B |
172 |
|
657 |
|
1-6-4 |
|
|
|
RailMeUn4 |
215 |
|
523613 |
|
1-3-4 |
|
|
|
FrmMngRapeOilVlv3 |
257 |
523661 |
5-6-5 |
|
InjVlvCyl8A |
173 |
|
658 |
|
1-6-5 |
|
|
|
RailMeUn7 |
216 |
|
523613 |
|
1-3-4 |
|
|
|
FrmMngRapeOilVlv4 |
258 |
523662 |
5-6-6 |
|
InjVlvCyl8B |
174 |
|
658 |
|
1-6-5 |
|
|
|
SOPTst |
218 |
|
523490 |
|
1-4-9 |
|
|
|
FrmMngRapeOilVlv5 |
259 |
523663 |
5-6-7 |
|
InjVlvErrDet |
175 |
|
523370 |
|
5-5-5 |
|
|
|
SSpMon1 |
219 |
|
1079 |
|
2-8-2 |
|
|
|
FrmMngSTIN1RX |
260 |
523664 |
5-6-8 |
|
MeUnCD_ADC |
176 |
|
523615 |
|
1-3-5 |
|
|
|
SSpMon2 |
221 |
|
1080 |
|
2-8-2 |
|
|
|
FrmMngStEKP |
261 |
523665 |
5-6-9 |
|
MeUnCDNoLoad |
177 |
|
523615 |
|
1-3-5 |
|
|
|
SSpMon3 |
222 |
|
523601 |
|
2-8-2 |
|
|
|
FrmMngStLmp |
262 |
523666 |
5-7-1 |
|
MeUnCDSCBat |
178 |
|
523615 |
|
1-3-5 |
|
|
|
StrtCDHS |
223 |
|
677 |
|
5-1-2 |
|
|
|
FrmMngStOutRx |
263 |
523667 |
5-7-2 |
|
MeUnCDSCGnd |
179 |
|
523615 |
|
1-3-5 |
|
|
|
StrtCDLS |
224 |
|
677 |
|
5-1-2 |
|
|
|
|
|
|
|
|
MnRly1_SCB |
182 |
|
2634 |
|
1-3-7 |
|
|
|
SysLamp |
225 |
|
624 |
|
5-1-3 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
||||||||
MnRly1_SCG |
183 |
|
2634 |
|
1-3-8 |
|
|
|
T15CD |
226 |
|
158 |
|
5-1-4 |
|
|
|
|
|
|
|
|
Montr |
184 |
|
523420 |
|
1-3-9 |
|
|
|
T50CD |
227 |
|
523550 |
|
5-1-5 |
|
|
|
|
|
|
|
|
MRlyCD |
186 |
|
2634 |
|
2-6-1 |
|
|
|
TPUMon |
228 |
|
523550 |
|
5-5-5 |
|
|
|
|
|
|
|
|
MRlyCDMnRly2 |
187 |
|
563 |
|
2-6-1 |
|
|
|
VSSCD1 |
232 |
|
84 |
|
5-2-1 |
|
|
|
|
|
|
|
|
MRlyCDMnRly3 |
188 |
|
2634 |
|
2-6-1 |
|
|
|
WdCom |
235 |
|
523600 |
|
5-5-5 |
|
|
|
|
|
|
|
|
MSSCD1 |
189 |
|
523450 |
|
1-4-3 |
|
|
|
PRVMonSysReac |
236 |
|
523470 |
|
1-4-6 |
|
|
|
|
|
|
|
|
MSSCD2 |
190 |
|
523451 |
|
1-4-3 |
|
|
|
APPCDSwtnSel |
237 |
|
523006 |
|
2-4-2 |
|
|
|
|
|
|
|
|
MSSCD3 |
191 |
|
523452 |
|
1-4-3 |
|
|
|
FrmMng_TORxEngPress |
238 |
|
523007 |
|
2-1-5 |
|
|
|
|
|
|
|
|
NetMngCANAOff |
192 |
|
639 |
|
2-7-1 |
|
|
|
MplCtl |
239 |
|
523008 |
|
4-2-4 |
|
|
|
|
|
|
|
|
NetMngCANBOff |
193 |
|
1231 |
|
2-7-1 |
|
|
|
OLSCD |
240 |
|
98 |
|
2-1-1 |
|
|
|
|
|
|
|
|
NetMngCANCOff |
194 |
|
1235 |
|
2-7-1 |
|
|
|
OLSCDSysReacHi |
241 |
|
98 |
|
2-5-1 |
|
|
|
|
|
|
|
|
OPLpCD |
195 |
|
705 |
|
1-3-5 |
|
|
|
ADPSCDAna |
242 |
|
107 |
|
1-3-6 |
|
|
|
|
|
|
|
|
OPSCD |
196 |
|
100 |
|
2-2-4 |
|
|
|
OLSCDSysReacLo |
243 |
|
98 |
|
2-5-2 |
|
|
|
|
|
|
|
|
OPSCD1 |
197 |
|
100 |
|
2-3-1 |
|
|
|
PrvMonWear |
244 |
|
523009 |
|
2-5-3 |
|
|
|
|
|
|
|
|
DEUTZ AG, VS-TA, Fi, Su |
Page 2 von 67 |
Rev. 2.0 |
DTC - List
Diagnosisand Fehlercodes
AirFltSysReac
Error Description
Air filter differential pressure: the pressure difference of the intake air between the filter inlet and outlet calculated by ECU is above the target range and the ECU activates a system reaction
Error Codes
DEUTZ: 11, Blink: 1-3-6, SPN: 107, FMI (Bit 0,1,2,3):
0: data valid, but above normal working area 11: Errormode not identifiable
11: Errormode not identifiable 11: Errormode not identifiable
Error Detection
Continuous light of the fault lamp, registered in the error memory of the ECU.
Possible Error Reason
Pressure loss above target range with system reaction, air filter clogged or defective, sensor not working, connection cable demaged
Corrective Action
Check airfilter and if necessary clean or renew it, check cabling, check air filter and if necessary replace the filter component, check sensor and if necessary replace it, check connection cable and if necessary repair or replace it
Others Error Properties
Priority 2, self healing, as measured value a current value will be showed.
Referenced ECU Software |
|
|
P490_: 220, 310, |
501 |
P492_: 213 |
P491_: 220, 310, |
400, 501 |
P513_: 214, 300 |
APP1
Error Description
Analog accelerator pedal sensor 1 or double accelerator pedal sensor: the voltage measured by ECU is out of the target range or the calculated pedal position is implausible compared with the position of the second pedal
Error Codes
DEUTZ: 12, Blink: 2-2-6, SPN: 91,
FMI (Bit 0,1,2,3):
3:Voltage to high or short circuit to +Ubatt
4:Voltage to low or short circuit to -Ubatt
11:Errormode not identifiable
2:data stream is defective
Error Detection
Continuous light of the fault lamp, registered in the error memory of the ECU.
Possible Error Reason
Voltage outside target range, signal implausible compared to signal of redundant pedal (analog pedal 1), sensor defective, connection cable demaged
Corrective Action
Check cabling, check accelator pedal sensor and if necessary replace it, check connection cable and if necessary repair or replace it
Others Error Properties
Priority 4, not self healing, as measured value a current value will be showed.
APPPwm
Error Description
Digital accelerator pedal sensor (PWM): the signal received by ECU is defective or implausible or the pulseduty factor is out of the target range
Error Codes
DEUTZ: 14, Blink: 2-2-2, SPN: 91, FMI (Bit 0,1,2,3):
8: unusual frequency, pulse or period. 8: unusual frequency, pulse or period. 2: data stream is defective
8: unusual frequency, pulse or period.
Error Detection
Continuous light of the fault lamp, registered in the error memory of the ECU.
Possible Error Reason
Duty cycle outside target range, signal erroneous or implausible (pedal 1), sensor defective, onnection cable demaged
Corrective Action
Check cabling, check accelator pedal sensor and if necessary replace it, check connection cable and if necessary repair or replace it
Others Error Properties
Priority 4, self healing, as measured value a current value will be showed.
To First Page
|
|
|
DEUTZ AG, VS-TA, Fi, Su |
Page 3 von 67 |
Rev. 2.0 |
DTC - List
Diagnosisand Fehlercodes
APPPwmPer
Error Description
digital accelerator pedal sensor (PWM): the frequence of the signal received by ECU is out of the target range
Error Codes
DEUTZ: 15, Blink: 2-2-2, SPN: 91, FMI (Bit 0,1,2,3):
8: unusual frequency, pulse or period. 8: unusual frequency, pulse or period. 11: Errormode not identifiable
11: Errormode not identifiable
Error Detection
Continuous light of the fault lamp, registered in the error memory of the ECU.
Possible Error Reason
Pulse frequency outside target range (pedal 1), sensor defective, connection cable demaged
Corrective Action
Check cabling, check accelator pedal sensor and if necessary replace it, check connection cable and if necessary repair or replace it
Others Error Properties
Priority 4, self healing, as measured value a current value will be showed.
Referenced ECU Software |
|
|
P490_: 220, 310, |
501 |
P492_: 213 |
P491_: 220, 310, |
400, 501 |
P513_: 214, 300 |
APSCD
Error Description
Ambient air pressure sensor (in ECU): the voltage measured by ECU is out of the target range or the calculated ambient air pressure is implausible compared with the charge air pressure
Error Codes
DEUTZ: 16, Blink: 2-9-2, SPN: 108,
FMI (Bit 0,1,2,3):
3:Voltage to high or short circuit to +Ubatt
4:Voltage to low or short circuit to -Ubatt
11:Errormode not identifiable
2:data stream is defective
Error Detection
Continuous light of the fault lamp, registered in the error memory of the ECU.
Possible Error Reason
Ambient air pressure sensor defective, ECU defective
Corrective Action
Change ECU
Others Error Properties
Priority 4, self healing, as measured value a default value will be showed.
ArHt1
Error Description
Air heater relay: the current drain measured by ECU is out of the target range
Error Codes
DEUTZ: 17, Blink: 2-6-3, SPN: 729,
FMI (Bit 0,1,2,3):
3:Voltage to high or short circuit to +Ubatt
4:Voltage to low or short circuit to -Ubatt
5:current to low or broken wire
11: Errormode not identifiable
Error Detection
Continuous light of the fault lamp, registered in the error memory of the ECU.
Possible Error Reason
Cable break or short circuit at EDC output, relay defective, connection cable demaged
Corrective Action
Check cabling, if sensor not working, check relay and if necessary replace it, check connection cable and if necessary repair or replace it
Others Error Properties
Priority 2, self healing, as measured value a shutoff value will be showed.
To First Page
|
|
|
DEUTZ AG, VS-TA, Fi, Su |
Page 4 von 67 |
Rev. 2.0 |
DTC - List
Diagnosisand Fehlercodes
ArHt2
Error Description
Air heater magnet valve: the current drain measured by ECU is out of the target range
Error Codes
DEUTZ: 18, Blink: 2-6-3, SPN: 730,
FMI (Bit 0,1,2,3):
3:Voltage to high or short circuit to +Ubatt
4:Voltage to low or short circuit to -Ubatt
5:current to low or broken wire
11: Errormode not identifiable
Error Detection
Continuous light of the fault lamp, registered in the error memory of the ECU.
Possible Error Reason
Cable break or short circuit, valve defective, connection cable demaged
Corrective Action
Check valve and if necessary replace it, check connection cable and if necessary repair or replace it
Others Error Properties
Priority 2, self healing, as measured value a shutoff value will be showed.
Referenced ECU Software |
|
|
P490_: 220, 310, |
501 |
P492_: 213 |
P491_: 220, 310, |
400, 501 |
P513_: 214, 300 |
ArHtCD_NoLd
Error Description
Air heater relay: the ECU detects no switching operation at the input of a readback process
Error Codes
DEUTZ: 19, Blink: 2-6-3, SPN: 676, FMI (Bit 0,1,2,3):
11: Errormode not identifiable
4: Voltage to low or short circuit to -Ubatt 11: Errormode not identifiable
11: Errormode not identifiable
Error Detection
Continuous light of the fault lamp, registered in the error memory of the ECU.
Possible Error Reason
Relay energized, but no feedback on sense line, relay defective or wrong wired, preheat component defective, connection cable demaged
Corrective Action
Check cabling of preheat component, if relay not working,check relay and if necessary replace it, check preheat component and if necessary replace it, check connection cable and if necessary repair or replace it
Others Error Properties
Priority 3, not self healing, as measured value a nominal value for output status will be showed.
ArHtCD_RlyErr
Error Description
Air heater relay: the ECU detects an implausible signal at the input of a readback process
Error Codes
DEUTZ: 20, Blink: 2-6-3, SPN: 676, FMI (Bit 0,1,2,3):
5: current to low or broken wire 2: data stream is defective
11: Errormode not identifiable 11: Errormode not identifiable
Error Detection
Continuous light of the fault lamp, registered in the error memory of the ECU.
Possible Error Reason
Relay not energized, but working voltage on sense line, relay defective (can not disconnect or switch off), preheat component defective, connection cable demaged
Corrective Action
Check cabling of preheat component, if relay not working,check relay and if necessary replace it, check preheat component and if necessary replace it, check connection cable and if necessary repair or replace it
Others Error Properties
Priority 3, not self healing, as measured value a nominal value for output status will be showed.
To First Page
DEUTZ AG, VS-TA, Fi, Su |
Page 5 von 67 |
Rev. 2.0 |
DTC - List
Diagnosisand Fehlercodes
BattCD
Error Description
Battery voltage: the voltage measured by ECU is out of the target range
Error Codes
DEUTZ: 22, Blink: 3-1-8, SPN: 168,
FMI (Bit 0,1,2,3):
0:data valid, but above normal working area
1:data valid, but below normal working area
11:Errormode not identifiable
11:Errormode not identifiable
Error Detection
Continuous light of the fault lamp, registered in the error memory of the ECU.
Possible Error Reason
Voltage below target range, battery defective, too high power supply voltage, too high contact resistance, wiring demaged, energie system overloaded, parametering inaccurate, ECU defective
Corrective Action
Check LIMA?, ECU, cabling, contact resistance, safety fuses, too high load in energy system, check battery and if necessary replace it, check battery pole and if necessary clean it, check connection cable and if necessary repair or replace it, check volta
Others Error Properties
Priority 3, self healing, as measured value a current value will be showed.
Referenced ECU Software |
|
|
P490_: 220, 310, |
501 |
P492_: 213 |
P491_: 220, 310, |
400, 501 |
P513_: 214, 300 |
BattCDSysReac
Error Description
Battery voltage: the voltage measured by ECU is out of the target range; the ECU activates a system reaction
Error Codes
DEUTZ: 23, Blink: 3-1-8, SPN: 168, FMI (Bit 0,1,2,3):
2: data stream is defective 2: data stream is defective
11: Errormode not identifiable 11: Errormode not identifiable
Error Detection
Continuous light of the fault lamp, registered in the error memory of the ECU.
Possible Error Reason
Above target range with system reaction, too high power supply voltage, parametering inaccurate, ECU defective
Corrective Action
Check dataset of calibration of working voltage for application, check LIMA? Check voltage of generator, check the parameters and if necessary correct them, replace ECU
Others Error Properties
Priority 4, self healing, as measured value a current value will be showed.
BIPCyl1
Error Description
Begin of injection of cylinder 1: the ECU can not identify the magnet valve or the injection pump with the measured value of current drain at the begin of the injection
Error Codes
DEUTZ: 24, Blink: 5-3-1, SPN: 523561, FMI (Bit 0,1,2,3):
2: data stream is defective 2: data stream is defective 2: data stream is defective 2: data stream is defective
Error Detection
Continuous light of the fault lamp, registered in the error memory of the ECU.
Possible Error Reason
Value outside target range or missing (cylinder 1), magnet valve or injection pump defective
Corrective Action
Check magnetic valve or injection pump and if necessary change them
Others Error Properties
Priority 3, self healing, as measured value a current value will be showed.
To First Page
|
|
|
DEUTZ AG, VS-TA, Fi, Su |
Page 6 von 67 |
Rev. 2.0 |
DTC - List
Diagnosisand Fehlercodes
BIPCyl2
Error Description
Begin of injection of cylinder 2: the ECU can not identify the magnet valve or the injection pump with the measured value of current drain at the begin of the injection
Error Codes
DEUTZ: 25, Blink: 5-3-2, SPN: 523562, FMI (Bit 0,1,2,3):
2: data stream is defective 2: data stream is defective 2: data stream is defective 2: data stream is defective
Error Detection
Continuous light of the fault lamp, registered in the error memory of the ECU.
Possible Error Reason
Value outside target range or missing (cylinder 2), magnet valve or injection pump defective
Corrective Action
Check magnetic valve or injection pump and if necessary change them
Others Error Properties
Priority 3, self healing, as measured value a current value will be showed.
Referenced ECU Software |
|
|
P490_: 220, 310, |
501 |
P492_: 213 |
P491_: 220, 310, |
400, 501 |
P513_: 214, 300 |
BIPCyl3
Error Description
Begin of injection of cylinder 3: the ECU can not identify the magnet valve or the injection pump with the measured value of current drain at the begin of the injection
Error Codes
DEUTZ: 26, Blink: 5-3-3, SPN: 523563, FMI (Bit 0,1,2,3):
2: data stream is defective 2: data stream is defective 2: data stream is defective 2: data stream is defective
Error Detection
Continuous light of the fault lamp, registered in the error memory of the ECU.
Possible Error Reason
Value outside target range or missing (cylinder 3), magnet valve or injection pump defective
Corrective Action
Check magnetic valve or injection pump and if necessary change them
Others Error Properties
Priority 3, self healing, as measured value a current value will be showed.
BIPCyl4
Error Description
Begin of injection of cylinder 4: the ECU can not identify the magnet valve or the injection pump with the measured value of current drain at the begin of the injection
Error Codes
DEUTZ: 27, Blink: 5-3-4, SPN: 523564, FMI (Bit 0,1,2,3):
2: data stream is defective 2: data stream is defective 2: data stream is defective 2: data stream is defective
Error Detection
Continuous light of the fault lamp, registered in the error memory of the ECU.
Possible Error Reason
Value outside target range or missing (cylinder 4), magnet valve or injection pump defective
Corrective Action
Check magnetic valve or injection pump and if necessary change them
Others Error Properties
Priority 3, self healing, as measured value a current value will be showed.
To First Page
DEUTZ AG, VS-TA, Fi, Su |
Page 7 von 67 |
Rev. 2.0 |
DTC - List
Diagnosisand Fehlercodes
BIPCyl5
Error Description
Begin of injection of cylinder 5: the ECU can not identify the magnet valve or the injection pump with the measured value of current drain at the begin of the injection
Error Codes
DEUTZ: 28, Blink: 5-3-5, SPN: 523565, FMI (Bit 0,1,2,3):
2: data stream is defective 2: data stream is defective 2: data stream is defective 2: data stream is defective
Error Detection
Continuous light of the fault lamp, registered in the error memory of the ECU.
Possible Error Reason
Value outside target range or missing (cylinder 5), magnet valve or injection pump defective
Corrective Action
Check magnetic valve or injection pump and if necessary change them
Others Error Properties
Priority 3, self healing, as measured value a current value will be showed.
Referenced ECU Software |
|
|
P490_: 220, 310, |
501 |
P492_: 213 |
P491_: 220, 310, |
400, 501 |
P513_: 214, 300 |
BIPCyl6
Error Description
Begin of injection of cylinder 6: the ECU can not identify the magnet valve or the injection pump with the measured value of current drain at the begin of the injection
Error Codes
DEUTZ: 29, Blink: 5-3-6, SPN: 523566, FMI (Bit 0,1,2,3):
2: data stream is defective 2: data stream is defective 2: data stream is defective 2: data stream is defective
Error Detection
Continuous light of the fault lamp, registered in the error memory of the ECU.
Possible Error Reason
Value outside target range or missing (cylinder 6), magnet valve or injection pump defective
Corrective Action
Check magnetic valve or injection pump and if necessary change them
Others Error Properties
Priority 3, self healing, as measured value a current value will be showed.
BIPCyl7
Error Description
Begin of injection of cylinder 7: the ECU can not identify the magnet valve or the injection pump with the measured value of current drain at the begin of the injection
Error Codes
DEUTZ: 30, Blink: 5-3-7, SPN: 523567, FMI (Bit 0,1,2,3):
2: data stream is defective 2: data stream is defective 2: data stream is defective 2: data stream is defective
Error Detection
Continuous light of the fault lamp, registered in the error memory of the ECU.
Possible Error Reason
Value outside target range or missing (cylinder 7), magnet valve or injection pump defective
Corrective Action
Check magnetic valve or injection pump and if necessary change them
Others Error Properties
Priority 3, self healing, as measured value a current value will be showed.
To First Page
DEUTZ AG, VS-TA, Fi, Su |
Page 8 von 67 |
Rev. 2.0 |
DTC - List
Diagnosisand Fehlercodes
BIPCyl8
Error Description
Begin of injection of cylinder 8: the ECU can not identify the magnet valve or the injection pump with the measured value of current drain at the begin of the injection
Error Codes
DEUTZ: 31, Blink: 5-3-8, SPN: 523568, FMI (Bit 0,1,2,3):
2: data stream is defective 2: data stream is defective 2: data stream is defective 2: data stream is defective
Error Detection
Continuous light of the fault lamp, registered in the error memory of the ECU.
Possible Error Reason
Value outside target range or missing (cylinder 8), magnet valve or injection pump defective
Corrective Action
Check magnetic valve or injection pump and if necessary change them
Others Error Properties
Priority 3, self healing, as measured value a current value will be showed.
Referenced ECU Software |
|
|
P490_: 220, 310, |
501 |
P492_: 213 |
P491_: 220, 310, |
400, 501 |
P513_: 214, 300 |
BPSCD
Error Description
Charge air pressure sensor: the measured voltage of sensor by ECU is out of the target range; the calculated charge air pressure is implausible or the received value via CAN is defective
Error Codes
DEUTZ: 32, Blink: 2-2-3, SPN: 102,
FMI (Bit 0,1,2,3):
3:Voltage to high or short circuit to +Ubatt
4:Voltage to low or short circuit to -Ubatt
2:data stream is defective
2:data stream is defective
Error Detection
Continuous light of the fault lamp, registered in the error memory of the ECU.
Possible Error Reason
Cable break or short circuit, sensor defective, onnection cable demaged
Corrective Action
Check cabling, if LDF6T sensor not working, check sensor and if necessary replace it, check connection cable and if necessary repair or replace it
Others Error Properties
Priority 4, self healing, as measured value a default value will be showed.
BPSCDSysReac
Error Description
Charge air pressure: the charge air pressure calculated by ECU is above the target range; the ECU activates a system reaction
Error Codes
DEUTZ: 33, Blink: 2-2-3, SPN: 102, FMI (Bit 0,1,2,3):
2: data stream is defective 2: data stream is defective
11: Errormode not identifiable 11: Errormode not identifiable
Error Detection
Continuous light or blink of the fault lamp, registered in the error memory of the ECU.
Possible Error Reason
Outside target range with system reaction, air system demaged, sensor defective, onnection cable demaged
Corrective Action
Check air system, inspect air system and if necessary repair it, check sensor and if necessary replace it, check connection cable and if necessary repair or replace it
Others Error Properties
Priority 4, self healing, as measured value a current value will be showed.
To First Page
DEUTZ AG, VS-TA, Fi, Su |
Page 9 von 67 |
Rev. 2.0 |
DTC - List
Diagnosisand Fehlercodes
CLSCDSysReac
Error Description
Coolant level: the coolant level calculated by ECU is underneath the allowed minimum
Error Codes
DEUTZ: 37, Blink: 2-3-5, SPN: 111, FMI (Bit 0,1,2,3):
1: data valid, but below normal working area 1: data valid, but below normal working area 11: Errormode not identifiable
11: Errormode not identifiable
Error Detection
Continuous light or blink of the fault lamp, registered in the error memory of the ECU.
Possible Error Reason
Outside target range with system reaction, cooling system untight, sensor defective, onnection cable demaged
Corrective Action
Check coolant level, check cabling, inspect cooling system and if necessary repair it, check sensor and if necessary replace it, check connection cable and if necessary repair or replace it
Others Error Properties
Priority 3, not self healing, as measured value a current value will be showed.
Referenced ECU Software |
|
|
P490_: 220, 310, |
501 |
P492_: 213 |
P491_: 220, 310, |
400, 501 |
P513_: 214, 300 |
CmbChbMisfire1
Error Description
Misfire at cylinder 1: the number of the misfire detected by ECU is out of the allowed limit value
Error Codes
DEUTZ: 38, Blink: 2-4-1, SPN: 1323, FMI (Bit 0,1,2,3):
12: Defective component
11: Errormode not identifiable 11: Errormode not identifiable 11: Errormode not identifiable
Error Detection
Continuous light of the fault lamp, registered in the error memory of the ECU.
Possible Error Reason
Misfire detected (cylinder 1), magnet valve or injection pump defective, fuel system defective, motor engineering demaged
Corrective Action
Check magnetic valve or injection pump and if necessary replace them, check fuel system and if necessary repair it, check motor engineering and if necessary repair it
Others Error Properties
Priority 0, not self healing, as measured value a current value will be showed.
CmbChbMisfire2
Error Description
Misfire at cylinder 2: the number of the misfire detected by ECU is out of the allowed limit value
Error Codes
DEUTZ: 39, Blink: 2-4-1, SPN: 1324, FMI (Bit 0,1,2,3):
12: Defective component
11: Errormode not identifiable 11: Errormode not identifiable 11: Errormode not identifiable
Error Detection
Continuous light of the fault lamp, registered in the error memory of the ECU.
Possible Error Reason
Misfire detected (cylinder 2), magnet valve or injection pump defective, fuel system defective, motor engineering demaged
Corrective Action
Check magnetic valve or injection pump and if necessary replace them, check fuel system and if necessary repair it, check motor engineering and if necessary repair it
Others Error Properties
Priority 0, not self healing, as measured value a current value will be showed.
To First Page
DEUTZ AG, VS-TA, Fi, Su |
Page 10 von 67 |
Rev. 2.0 |
DTC - List
Diagnosisand Fehlercodes
CmbChbMisfire3
Error Description
Misfire at cylinder 3: the number of the misfire detected by ECU is out of the allowed limit value
Error Codes
DEUTZ: 40, Blink: 2-4-1, SPN: 1325, FMI (Bit 0,1,2,3):
12: Defective component
11: Errormode not identifiable 11: Errormode not identifiable 11: Errormode not identifiable
Error Detection
Continuous light of the fault lamp, registered in the error memory of the ECU.
Possible Error Reason
Misfire detected (cylinder 3), magnet valve or injection pump defective, fuel system defective, motor engineering demaged
Corrective Action
Check magnetic valve or injection pump and if necessary replace them, check fuel system and if necessary repair it, check motor engineering and if necessary repair it
Others Error Properties
Priority 0, not self healing, as measured value a current value will be showed.
Referenced ECU Software |
|
|
P490_: 220, 310, |
501 |
P492_: 213 |
P491_: 220, 310, |
400, 501 |
P513_: 214, 300 |
CmbChbMisfire4
Error Description
Misfire at cylinder 4: the number of the misfire detected by ECU is out of the allowed limit value
Error Codes
DEUTZ: 41, Blink: 2-4-1, SPN: 1326, FMI (Bit 0,1,2,3):
12: Defective component
11: Errormode not identifiable 11: Errormode not identifiable 11: Errormode not identifiable
Error Detection
Continuous light of the fault lamp, registered in the error memory of the ECU.
Possible Error Reason
Misfire detected (cylinder 4), magnet valve or injection pump defective, fuel system defective, motor engineering demaged
Corrective Action
Check magnetic valve or injection pump and if necessary replace them, check fuel system and if necessary repair it, check motor engineering and if necessary repair it
Others Error Properties
Priority 0, not self healing, as measured value a current value will be showed.
CmbChbMisfire5
Error Description
Misfire at cylinder 5: the number of the misfire detected by ECU is out of the allowed limit value
Error Codes
DEUTZ: 42, Blink: 2-4-1, SPN: 1327, FMI (Bit 0,1,2,3):
12: Defective component
11: Errormode not identifiable 11: Errormode not identifiable 11: Errormode not identifiable
Error Detection
Continuous light of the fault lamp, registered in the error memory of the ECU.
Possible Error Reason
Misfire detected (cylinder 5), magnet valve or injection pump defective, fuel system defective, motor engineering demaged
Corrective Action
Check magnetic valve or injection pump and if necessary replace them, check fuel system and if necessary repair it, check motor engineering and if necessary repair it
Others Error Properties
Priority 0, not self healing, as measured value a current value will be showed.
To First Page
DEUTZ AG, VS-TA, Fi, Su |
Page 11 von 67 |
Rev. 2.0 |
DTC - List
Diagnosisand Fehlercodes
CmbChbMisfire6
Error Description
Misfire at cylinder 6: the number of the misfire detected by ECU is out of the allowed limit value
Error Codes
DEUTZ: 43, Blink: 2-4-1, SPN: 1328, FMI (Bit 0,1,2,3):
12: Defective component
11: Errormode not identifiable 11: Errormode not identifiable 11: Errormode not identifiable
Error Detection
Continuous light of the fault lamp, registered in the error memory of the ECU.
Possible Error Reason
Misfire detected (cylinder 6), magnet valve or injection pump defective, fuel system defective, motor engineering demaged
Corrective Action
Check magnetic valve or injection pump and if necessary replace them, check fuel system and if necessary repair it, check motor engineering and if necessary repair it
Others Error Properties
Priority 0, not self healing, as measured value a current value will be showed.
Referenced ECU Software |
|
|
P490_: 220, 310, |
501 |
P492_: 213 |
P491_: 220, 310, |
400, 501 |
P513_: 214, 300 |
CmbChbMisfire7
Error Description
Misfire at cylinder 7: the number of the misfire detected by ECU is out of the allowed limit value
Error Codes
DEUTZ: 44, Blink: 2-4-1, SPN: 1450, FMI (Bit 0,1,2,3):
12: Defective component
11: Errormode not identifiable 11: Errormode not identifiable 11: Errormode not identifiable
Error Detection
Continuous light of the fault lamp, registered in the error memory of the ECU.
Possible Error Reason
Misfire detected (cylinder 7), magnet valve or injection pump defective, fuel system defective, motor engineering demaged
Corrective Action
Check magnetic valve or injection pump and if necessary replace them, check fuel system and if necessary repair it, check motor engineering and if necessary repair it
Others Error Properties
Priority 0, not self healing, as measured value a current value will be showed.
CmbChbMisfire8
Error Description
Misfire at cylinder 8: the number of the misfire detected by ECU is out of the allowed limit value
Error Codes
DEUTZ: 45, Blink: 2-4-1, SPN: 1451, FMI (Bit 0,1,2,3):
12: Defective component
11: Errormode not identifiable 11: Errormode not identifiable 11: Errormode not identifiable
Error Detection
Continuous light of the fault lamp, registered in the error memory of the ECU.
Possible Error Reason
Misfire detected (cylinder 8), magnet valve or injection pump defective, fuel system defective, motor engineering demaged
Corrective Action
Check magnetic valve or injection pump and if necessary replace them, check fuel system and if necessary repair it, check motor engineering and if necessary repair it
Others Error Properties
Priority 0, not self healing, as measured value a current value will be showed.
To First Page
DEUTZ AG, VS-TA, Fi, Su |
Page 12 von 67 |
Rev. 2.0 |
DTC - List
Diagnosisand Fehlercodes
CmbChbMisfireMul
Error Description
Misfire at more cylinders: the number of the misfire detected by ECU is out of the allowed limit value
Error Codes
DEUTZ: 46, Blink: 2-4-1, SPN: 1322, FMI (Bit 0,1,2,3):
12: Defective component
11: Errormode not identifiable 11: Errormode not identifiable 11: Errormode not identifiable
Error Detection
Continuous light of the fault lamp, registered in the error memory of the ECU.
Possible Error Reason
Misfire detected, magnet valve or injection pump defective, fuel system defective, motor engineering demaged
Corrective Action
Check magnetic valve or injection pump and if necessary replace them, check fuel system and if necessary repair it, check motor engineering and if necessary repair it
Others Error Properties
Priority 0, not self healing, as measured value a current value will be showed.
Referenced ECU Software |
|
|
P490_: 220, 310, |
501 |
P492_: 213 |
P491_: 220, 310, |
400, 501 |
P513_: 214, 300 |
CmbChbSysReac
Error Description
Misfire at more cylinders: the number of the misfire detected by ECU is out of the allowed limit value; the ECU activates a system reaction
Error Codes
DEUTZ: 47, Blink: 2-4-1, SPN: 1346, FMI (Bit 0,1,2,3):
0: data valid, but above normal working area 11: Errormode not identifiable
11: Errormode not identifiable 11: Errormode not identifiable
Error Detection
Continuous light of the fault lamp, registered in the error memory of the ECU.
Possible Error Reason
Misfire detected with system reaction, magnet valve or injection pump defective, fuel system defective, motor engineering demaged
Corrective Action
Check magnetic valve or injection pump and if necessary replace them, check fuel system and if necessary repair it, check motor engineering and if necessary repair it
Others Error Properties
Priority 0, not self healing, as measured value a current value will be showed.
CoEngShOffDemIgr
Error Description
Request of engine off: the operator ignors the engine off request within an allowed period.
Error Codes
DEUTZ: 48, Blink: 3-4-1, SPN: 1109, FMI (Bit 0,1,2,3):
2: data stream is defective 11: Errormode not identifiable 11: Errormode not identifiable 11: Errormode not identifiable
Error Detection
Continuous light of the fault lamp, registered in the error memory of the ECU.
Possible Error Reason
Shut-off request ignored by operator
Corrective Action
Warranty relevant
Others Error Properties
Priority 4, not self healing, as measured value a current value will be showed.
To First Page
|
|
|
DEUTZ AG, VS-TA, Fi, Su |
Page 13 von 67 |
Rev. 2.0 |
DTC - List
Diagnosisand Fehlercodes
CRERCD
Error Description
Engine brake actuator (internal): the current drain measured by ECU is out of the target range or the maximum permissble temperature of the ECU component for power supply of the actuator is exceeded.
Error Codes
DEUTZ: 52, Blink: 5-2-8, SPN: 1072,
FMI (Bit 0,1,2,3):
3:Voltage to high or short circuit to +Ubatt
4:Voltage to low or short circuit to -Ubatt
5:current to low or broken wire
11: Errormode not identifiable
Error Detection
Continuous light of the fault lamp, registered in the error memory of the ECU.
Possible Error Reason
cable break or short circuit, sensor defective, connection cable demaged
Corrective Action
Check actuator and if necessary replace it, check connection cable and if necessary repaire or replace it
Others Error Properties
Priority 2, not self healing, as measured value a nominal value for output status will be showed.
Referenced ECU Software |
|
|
P490_: 220, 310, |
501 |
P492_: 213 |
P491_: 220, 310, |
400, 501 |
P513_: 214, 300 |
CSLpCD
Error Description
Indicator lamp of air heater relay: the current drain measured by ECU is out of the target range or the maximum permissble temperature of the ECU component for power supply of the lamp is exceeded
Error Codes
DEUTZ: 53, Blink: 3-2-8, SPN: 1081,
FMI (Bit 0,1,2,3):
3:Voltage to high or short circuit to +Ubatt
4:Voltage to low or short circuit to -Ubatt
5:current to low or broken wire
2: data stream is defective
Error Detection
Continuous light of the fault lamp, registered in the error memory of the ECU.
Possible Error Reason
Cable break or short circuit, lamp defective, connection cable demaged
Corrective Action
Check cabling and load, check lamp and if necessary replace it, check connection cable and if necessary repair or replace it
Others Error Properties
Priority 1, not self healing, as measured value a nominal value for output status will be showed.
CTLpCD
Error Description
Warning lamp for coolant temperature: the current drain measured by ECU is out of the target range or the maximum temperature of the ECU component for power supply of the lamp is exceeded
Error Codes
DEUTZ: 54, Blink: 1-2-3, SPN: 704, FMI (Bit 0,1,2,3):
11: Errormode not identifiable 11: Errormode not identifiable 11: Errormode not identifiable 11: Errormode not identifiable
Error Detection
Continuous light of the fault lamp, registered in the error memory of the ECU.
Possible Error Reason
Cable break or short circuit, lamp defective, connection cable demaged
Corrective Action
Check cabling and load, check lamp and if necessary replace it, check connection cable and if necessary repair or replace it
Others Error Properties
Priority 1, not self healing, as measured value a nominal value for output status will be showed.
To First Page
DEUTZ AG, VS-TA, Fi, Su |
Page 14 von 67 |
Rev. 2.0 |
DTC - List
Diagnosisand Fehlercodes
CTSCD
Error Description
Coolant temperature sensor: the voltage of the sensor measured by ECU is out of the target range; the coolant temperature calculated by ECU is implausible compared with the oil temperature or the received value via CAN is defective
Error Codes
DEUTZ: 55, Blink: 2-2-5, SPN: 110,
FMI (Bit 0,1,2,3):
3:Voltage to high or short circuit to +Ubatt
4:Voltage to low or short circuit to -Ubatt
2:data stream is defective
2:data stream is defective
Error Detection
Continuous light of the fault lamp, registered in the error memory of the ECU.
Possible Error Reason
Cable break or short circuit, lamp defective, connection cable demaged
Corrective Action
Check cabling, sensor defect, check sensor and if necessary replace it, check connection cable and if necessary repair or replace it
Others Error Properties
Priority 4, self healing, as measured value a default value will be showed.
Referenced ECU Software |
|
|
P490_: 220, 310, |
501 |
P492_: 213 |
P491_: 220, 310, |
400, 501 |
P513_: 214, 300 |
CTSCDSysReac
Error Description
Coolant temperature: the coolant temperature calculated by ECU is above the target range; the ECU activates a system reaction
Error Codes
DEUTZ: 56, Blink: 2-3-2, SPN: 110, FMI (Bit 0,1,2,3):
0: data valid, but above normal working area 0: data valid, but above normal working area 11: Errormode not identifiable
11: Errormode not identifiable
Error Detection
Continuous light or blink of the fault lamp, registered in the error memory of the ECU.
Possible Error Reason
Outside target range with system reaction, cooling system not enough to be filled, clogged or demaged, cooling compressor dropped out, sensor defective, onnection cable demaged
Corrective Action
Check cycle cooling system and compressor, inspect cooling system and if necessary repair it, check cooling compressor and if necessary replace it, check sensor and if necessary replace it, check connection cable and if necessary repair or replace it
Others Error Properties
Priority 4, self healing, as measured value a current value will be showed.
Dummy1CD_Max
Error Description
Reserve output 1: the ECU detects a short circuit to battery
Error Codes
DEUTZ: 57, Blink: 1-0-0, SPN: 701, FMI (Bit 0,1,2,3):
11: Errormode not identifiable 11: Errormode not identifiable 11: Errormode not identifiable 11: Errormode not identifiable
Error Detection
Continuous light of the fault lamp, registered in the error memory of the ECU.
Possible Error Reason
Short circuit to Ubatt (output 1), connection cable demaged
Corrective Action
Check connection cable and if necessary repair or replace it
Others Error Properties
Priority 1, not self healing, as measured value a shutoff value will be showed.
To First Page
|
|
|
DEUTZ AG, VS-TA, Fi, Su |
Page 15 von 67 |
Rev. 2.0 |
DTC - List
Diagnosisand Fehlercodes
Dummy1CD_Min
Error Description
Reserve output 1: the ECU detects a short circuit to ground
Error Codes
DEUTZ: 58, Blink: 1-0-0, SPN: 701, FMI (Bit 0,1,2,3):
11: Errormode not identifiable 11: Errormode not identifiable 11: Errormode not identifiable 11: Errormode not identifiable
Error Detection
Continuous light of the fault lamp, registered in the error memory of the ECU.
Possible Error Reason
Short circuit to ground (output 1), connection cable demaged
Corrective Action
Check connection cable and if necessary repair or replace it
Others Error Properties
Priority 1, not self healing, as measured value a shutoff value will be showed.
Referenced ECU Software |
|
|
P490_: 220, 310, |
501 |
P492_: 213 |
P491_: 220, 310, |
400, 501 |
P513_: 214, 300 |
Dummy1CD_SigNpl
Error Description
Reserve output 1: the ECU detects no load or excess temperature of the ECU component for power supply of the connected components
Error Codes
DEUTZ: 59, Blink: 1-0-0, SPN: 701, FMI (Bit 0,1,2,3):
11: Errormode not identifiable 11: Errormode not identifiable 11: Errormode not identifiable 11: Errormode not identifiable
Error Detection
Continuous light of the fault lamp, registered in the error memory of the ECU.
Possible Error Reason
Cable break or ECU internal error (output 1), connection cable demaged, connected components defective, parametering of the output inaccurate, ECU defective
Corrective Action
Check connection cable and if necessary repair or replace it, check parameters and if necessary correct it, replace ECU
Others Error Properties
Priority 1, not self healing, as measured value a shutoff value will be showed.
Dummy2CD_Max
Error Description
Reserve output 2: the ECU detects a short circuit to battery
Error Codes
DEUTZ: 60, Blink: 1-0-0, SPN: 702, FMI (Bit 0,1,2,3):
11: Errormode not identifiable 11: Errormode not identifiable 11: Errormode not identifiable 11: Errormode not identifiable
Error Detection
Continuous light of the fault lamp, registered in the error memory of the ECU.
Possible Error Reason
Short circuit to Ubatt (output 2), onnection cable demaged
Corrective Action
Check connection cable and if necessary repair or replace it
Others Error Properties
Priority 1, not self healing, as measured value a shutoff value will be showed.
To First Page
|
|
|
DEUTZ AG, VS-TA, Fi, Su |
Page 16 von 67 |
Rev. 2.0 |
DTC - List
Diagnosisand Fehlercodes
Dummy2CD_Min
Error Description
Reserve output 2: the ECU detects a short circuit to ground
Error Codes
DEUTZ: 61, Blink: 1-0-0, SPN: 702, FMI (Bit 0,1,2,3):
11: Errormode not identifiable 11: Errormode not identifiable 11: Errormode not identifiable 11: Errormode not identifiable
Error Detection
Continuous light of the fault lamp, registered in the error memory of the ECU.
Possible Error Reason
Short circuit to ground (output 2), connection cable demaged
Corrective Action
Check connection cable and if necessary repair or replace it
Others Error Properties
Priority 1, not self healing, as measured value a shutoff value will be showed.
Referenced ECU Software |
|
|
P490_: 220, 310, |
501 |
P492_: 213 |
P491_: 220, 310, |
400, 501 |
P513_: 214, 300 |
Dummy2CD_SigNpl
Error Description
Reserve output 2: the ECU detects no load or excess temperature of the ECU component for power supply of the connected components
Error Codes
DEUTZ: 62, Blink: 1-0-0, SPN: 702, FMI (Bit 0,1,2,3):
11: Errormode not identifiable 11: Errormode not identifiable 11: Errormode not identifiable 11: Errormode not identifiable
Error Detection
Continuous light of the fault lamp, registered in the error memory of the ECU.
Possible Error Reason
Cable break or ECU internal error (output 2), connection cable demaged, connected components defective, parametering of the output inaccurate, ECU defective
Corrective Action
Check connection cable and if necessary repair or replace it, check parameters and if necessary correct it, replace ECU
Others Error Properties
Priority 1, not self healing, as measured value a shutoff value will be showed.
EGRCD_Max
Error Description
Actuator of the external EGR valve: the ECU detects a short circuit to battery
Error Codes
DEUTZ: 69, Blink: 4-1-4, SPN: 2791, FMI (Bit 0,1,2,3):
3: Voltage to high or short circuit to +Ubatt 11: Errormode not identifiable
11: Errormode not identifiable 11: Errormode not identifiable
Error Detection
Continuous light of the fault lamp, registered in the error memory of the ECU.
Possible Error Reason
Short circuit to Ubatt, connection cable demaged
Corrective Action
Check cabling, sensor defect, check sensor and if necessary replace it, check connection cable and if necessary repair or replace it
Others Error Properties
Priority 3, not self healing, as measured value a shutoff value will be showed.
To First Page
|
|
|
DEUTZ AG, VS-TA, Fi, Su |
Page 17 von 67 |
Rev. 2.0 |
DTC - List
Diagnosisand Fehlercodes
EGRCD_Min
Error Description
Actuator of the external EGR valve: the ECU detects a short circuit to ground
Error Codes
DEUTZ: 70, Blink: 4-1-4, SPN: 2791, FMI (Bit 0,1,2,3):
11: Errormode not identifiable
4: Voltage to low or short circuit to -Ubatt 11: Errormode not identifiable
11: Errormode not identifiable
Error Detection
Continuous light of the fault lamp, registered in the error memory of the ECU.
Possible Error Reason
Short circuit to ground, connection cable demaged
Corrective Action
Check cabling, sensor defect, check sensor and if necessary replace it, check connection cable and if necessary repair or replace it
Others Error Properties
Priority 3, not self healing, as measured value a shutoff value will be showed.
Referenced ECU Software |
|
|
P490_: 220, 310, |
501 |
P492_: 213 |
P491_: 220, 310, |
400, 501 |
P513_: 214, 300 |
EGRCD_SigNpl
Error Description
Actuator of the external EGR valve: the ECU detects no load or excess temperature of the ECU component for power supply of the connected components
Error Codes
DEUTZ: 71, Blink: 4-1-5, SPN: 2791, FMI (Bit 0,1,2,3):
11: Errormode not identifiable 11: Errormode not identifiable 5: current to low or broken wire 2: data stream is defective
Error Detection
Continuous light of the fault lamp, registered in the error memory of the ECU.
Possible Error Reason
Cable break or excess temperature, sensor defective, connection cable demaged
Corrective Action
Check cabling, sensor defect, check sensor and if necessary replace it, check connection cable and if necessary repair or replace it
Others Error Properties
Priority 3, not self healing, as measured value a shutoff value will be showed.
EGRCDIntEGR
Error Description
Actuator of the internal EGR valve: the ECU detects no load or excess temperature of the ECU component for power supply of the actuator
Error Codes
DEUTZ: 72, Blink: 4-1-6, SPN: 2791,
FMI (Bit 0,1,2,3):
3:Voltage to high or short circuit to +Ubatt
4:Voltage to low or short circuit to -Ubatt
5:current to low or broken wire
2: data stream is defective
Error Detection
Continuous light of the fault lamp, registered in the error memory of the ECU.
Possible Error Reason
Cable break, short circuit or excess temperature, sensor defective, connection cable demaged
Corrective Action
Check cabling, sensor defect, check sensor and if necessary replace it, check connection cable and if necessary repair or replace it
Others Error Properties
Priority 3, not self healing, as measured value a shutoff value will be showed.
To First Page
DEUTZ AG, VS-TA, Fi, Su |
Page 18 von 67 |
Rev. 2.0 |
DTC - List
Diagnosisand Fehlercodes
EngCDTrqCalcOut
Error Description
Output with PWM signal of the engine power: the current drain measured by ECU is out of the target range or the maximum permissible temperature of the ECU component to control the output is exceeded
Error Codes
DEUTZ: 74, Blink: 5-5-5, SPN: 923,
FMI (Bit 0,1,2,3):
3:Voltage to high or short circuit to +Ubatt
4:Voltage to low or short circuit to -Ubatt
5:current to low or broken wire
2: data stream is defective
Error Detection
Continuous light of the fault lamp, registered in the error memory of the ECU.
Possible Error Reason
Engine Power output: cable break or short circuit, output defective, connection cable demaged
Corrective Action
Check cabling, sensor defect, check sensor and if necessary replace it, check connection cable and if necessary repair or replace it
Others Error Properties
Priority 1, not self healing, as measured value a shutoff value will be showed.
Referenced ECU Software |
|
|
P490_: 220, 310, |
501 |
P492_: 213 |
P491_: 220, 310, |
400, 501 |
P513_: 214, 300 |
EngMBackUp
Error Description
Crankschaft speed sensor: the ECU receives no signal and uses the signal from camschaft speed sensor as alternative to calculate the engine speed
Error Codes
DEUTZ: 75, Blink: 2-1-2, SPN: 190,
FMI (Bit 0,1,2,3):
11:Errormode not identifiable
12:Defective component
11: Errormode not identifiable 11: Errormode not identifiable
Error Detection
Continuous light of the fault lamp, registered in the error memory of the ECU.
Possible Error Reason
Engine running only with cam-shaft speed signal, transmitter defective, connection cable demaged
Corrective Action
Check cabling of crankschaft sensor, check crankschaft sensor and if necessary replace it, check connection cable and if necessary repair or replace it
Others Error Properties
Priority 3, self healing, as measured value a - will be showed.
EngMCaS1
Error Description
Camschaft speed sensor: the ECU receives no signal or the signal is defective
Error Codes
DEUTZ: 76, Blink: 2-1-2, SPN: 190, FMI (Bit 0,1,2,3):
12: Defective component
8: unusual frequency, pulse or period. 11: Errormode not identifiable
11: Errormode not identifiable
Error Detection
Continuous light of the fault lamp, registered in the error memory of the ECU.
Possible Error Reason
Speed signal from cam-shaft defectiveiv or missing, transmitter defective, connection cable demaged, parametering of the sensor wheel inaccurate
Corrective Action
Check cabling, check camschaft sensor and if necessary replace it, check configuration of sensor wheel, check connection cable and if necessary repair or replace it, check parameters and if necessary correct them
Others Error Properties
Priority 4, self healing, as measured value a 0 will be showed.
To First Page
DEUTZ AG, VS-TA, Fi, Su |
Page 19 von 67 |
Rev. 2.0 |
DTC - List
Diagnosisand Fehlercodes
EngMCrS1
Error Description
Crankschaft speed sensor: the ECU receives no signal or the signal is defective
Error Codes
DEUTZ: 77, Blink: 2-1-2, SPN: 190, FMI (Bit 0,1,2,3):
12: Defective component
8: unusual frequency, pulse or period. 11: Errormode not identifiable
11: Errormode not identifiable
Error Detection
Continuous light of the fault lamp, registered in the error memory of the ECU.
Possible Error Reason
Speed signal from crankshaft defectiveiv or missing, transmitter defective, connection cable demaged, sensor wheel installed inaccurately
Corrective Action
Check cabling, check camschaft sensor and if necessary replace it, check configuration of sensor wheel, check connection cable and if necessary repair or replace it, check the position of sensor wheel and if necessary correct it
Others Error Properties
Priority 4, self healing, as measured value a 0 will be showed.
Referenced ECU Software |
|
|
P490_: 220, 310, |
501 |
P492_: 213 |
P491_: 220, 310, |
400, 501 |
P513_: 214, 300 |
EngMOfsCaSCrS
Error Description
Speed sensor of crankschaft and camschaft: the received signals are out of phase
Error Codes
DEUTZ: 78, Blink: 2-1-3, SPN: 190, FMI (Bit 0,1,2,3):
2: data stream is defective 11: Errormode not identifiable 11: Errormode not identifiable 11: Errormode not identifiable
Error Detection
Continuous light of the fault lamp, registered in the error memory of the ECU.
Possible Error Reason
Speed signals of crank-shaft and cam-shaft are phaseshifted, sensor wheel installed in wrong position, sensor wrong wired
Corrective Action
Check position from crankschaft sensor wheel to camschaft sensor wheel, polarisation crankschaft or camschaft sensor, check position of sensor wheel and if necessary correct it, check cabling and if necessary correct it
Others Error Properties
Priority 4, not self healing, as measured value a - will be showed.
EngPrtSysReacFOC
Error Description
Engine speed: the engine speed calculated by ECU is above the target range; the ECU activates a system reaction
Error Codes
DEUTZ: 79, Blink: 2-1-4, SPN: 190, FMI (Bit 0,1,2,3):
0: data valid, but above normal working area 11: Errormode not identifiable
11: Errormode not identifiable 11: Errormode not identifiable
Error Detection
Blink of the fault lamp, registered in the error memory of the ECU.
Possible Error Reason
Engine overspeed detected with system reaction, maximum engine speed exceeded
Corrective Action
Others Error Properties
Priority 5, not self healing, as measured value a current value will be showed.
To First Page
|
|
|
|
DEUTZ AG, VS-TA, Fi, Su |
|
Page 20 von 67 |
Rev. 2.0 |
DTC - List
Diagnosisand Fehlercodes
EngPrtSysReacORC
Error Description
Engine speed: under overrun conditions, the engine speed calculated by ECU is above the target range; the ECU activates a system reaction
Error Codes
DEUTZ: 80, Blink: 2-1-4, SPN: 190, FMI (Bit 0,1,2,3):
14: Special Instructions
11: Errormode not identifiable 11: Errormode not identifiable 11: Errormode not identifiable
Error Detection
Continuous light of the fault lamp, registered in the error memory of the ECU.
Possible Error Reason
Overrun conditions detected with system reaction, maximum engine speed exceeded
Corrective Action
Others Error Properties
Priority 4, self healing, as measured value a current value will be showed.
Referenced ECU Software |
|
|
P490_: 220, 310, |
501 |
P492_: 213 |
P491_: 220, 310, |
400, 501 |
P513_: 214, 300 |
ESLpCD
Error Description
Indicator lamp for engine running: the current drain measured by ECU is out of the target range or the maximum permissible temperature of the ECU component for power supply of the lamp is exceeded
Error Codes
DEUTZ: 81, Blink: 1-4-2, SPN: 703,
FMI (Bit 0,1,2,3):
3:Voltage to high or short circuit to +Ubatt
4:Voltage to low or short circuit to -Ubatt
5:current to low or broken wire
2: data stream is defective
Error Detection
Continuous light of the fault lamp, registered in the error memory of the ECU.
Possible Error Reason
Cable break or internal ECU error, lamp defective, connection cable demaged
Corrective Action
Check cabling and load, check lamp and if necessary replace it, check connection cable and if necessary repair or replace it
Others Error Properties
Priority 1, not self healing, as measured value a shutoff value will be showed.
ExFlCD
Error Description
Engine brake flap actuator: the current drain measured by ECU is out of the target range or the maximum permissible temperature of the ECU component for power supply of the actuator is exceeded
Error Codes
DEUTZ: 82, Blink: 2-1-9, SPN: 1074,
FMI (Bit 0,1,2,3):
3:Voltage to high or short circuit to +Ubatt
4:Voltage to low or short circuit to -Ubatt
5:current to low or broken wire
11: Errormode not identifiable
Error Detection
Continuous light of the fault lamp, registered in the error memory of the ECU.
Possible Error Reason
Engine brake flap actuator: cable break or short circuit, sensor defective, connection cable demaged
Corrective Action
Check cabling, sensor defect, check sensor and if necessary replace it, check connection cable and if necessary repair or replace it
Others Error Properties
Priority 2, not self healing, as measured value a shutoff value will be showed.
To First Page
DEUTZ AG, VS-TA, Fi, Su |
Page 21 von 67 |
Rev. 2.0 |
