HP Pavilion 13z-p100 User Manual

User Guide

© Copyright 2013 Hewlett-Packard
Development Company, L.P.

Bluetooth is a trademark owned by its
proprietor and used by Hewlett-Packard
Company under license. Microsoft and
Windows are U.S. registered trademarks of
Microsoft Corporation. SD Logo is a
trademark of its proprietor.

The information contained herein is subject
to change without notice. The only
warranties for HP products and services are
set forth in the express warranty statements
accompanying such products and services.
Nothing herein should be construed as
constituting an additional warranty. HP shall
not be liable for technical or editorial errors
or omissions contained herein.

First Edition: October 2013

Document Part Number: 741675-001

Product notice

This guide describes features that are
common to most models. Some features
may not be available on your computer.

Not all features are available in all editions
of Windows. This computer may require
upgraded and/or separately purchased
hardware, drivers and/or software to take
full advantage of Windows functionality.
See

http://www.microsoft.com for details.

To obtain the latest user guides, contact
support. For U.S. support, go to

http://www.hp.com/go/contactHP. For

worldwide support, go to

http://welcome.hp.com/country/us/en/
wwcontact_us.html.

Software terms

By installing, copying, downloading, or
otherwise using any software product
preinstalled on this computer, you agree to
be bound by the terms of the HP End User
License Agreement (EULA). If you do not
accept these license terms, your sole
remedy is to return the entire unused
product (hardware and software) within 14
days for a refund subject to the refund
policy of your place of purchase.

For any further information or to request a
full refund of the computer, please contact
your local point of sale (the seller).

Safety warning notice

WARNING! To reduce the possibility of heat-related injuries or of overheating the computer, do not

place the computer directly on your lap or obstruct the computer air vents. Use the computer only on
a hard, flat surface. Do not allow another hard surface, such as an adjoining optional printer, or a soft
surface, such as pillows or rugs or clothing, to block airflow. Also, do not allow the AC adapter to
come into contact with the skin or a soft surface, such as pillows or rugs or clothing, during operation.
The computer and the AC adapter comply with the user-accessible surface temperature limits defined
by the International Standard for Safety of Information Technology Equipment (IEC 60950).

iii

iv Safety warning notice

Table of contents

1 Starting right ................................................................................................................................................... 1

Revert to the familiar Start screen (select models only) ....................................................................... 1

Visit the HP Apps Store ........................................................................................................................ 1

Best practices ....................................................................................................................................... 1

Fun things to do .................................................................................................................................... 2

More HP resources .............................................................................................................................. 3

2 Getting to know your computer ..................................................................................................................... 4

Finding your hardware and software information ................................................................................. 4

Locating hardware ............................................................................................................... 4

Locating software ................................................................................................................. 4

Tablet edge components ...................................................................................................................... 4

Display .................................................................................................................................................. 7

Keyboard dock ..................................................................................................................................... 9

Top ....................................................................................................................................... 9

TouchPad .......................................................................................................................... 10

Lights ................................................................................................................................. 11

Keys ................................................................................................................................... 12

Right side ........................................................................................................................... 13

Left side ............................................................................................................................. 14

Releasing the tablet from the keyboard dock .................................................................... 15

Locating system information ............................................................................................................... 15

Changing your tablet's settings .......................................................................................................... 16

Changing your tablet's view ............................................................................................... 16

Adjusting your tablet's autorotate lock ............................................................... 16

Adjusting your tablet's screen brightness .......................................................... 16

Using touch screen gestures .............................................................................................................. 17

One-finger slide ................................................................................................................. 17

Tapping .............................................................................................................................. 18

Pinching/stretching ............................................................................................................ 18

Rotating (select models only) ............................................................................................ 19

Edge swipes ...................................................................................................................... 19

Right-edge swipe .............................................................................................. 19

Left-edge swipe ................................................................................................. 20

Top or bottom-edge swipe ................................................................................ 20

Setting touch screen preferences ....................................................................................................... 21

v

Using the on-screen keyboard ........................................................................................................... 21

3 Connecting to a network .............................................................................................................................. 22

Connecting to a wireless network ....................................................................................................... 22

Using the wireless controls ................................................................................................ 22

Using the wireless button .................................................................................. 22

Using operating system controls ....................................................................... 22

Sharing data and drives and accessing software .............................................................. 23

Using a WLAN ................................................................................................................... 23

Using an Internet service provider .................................................................... 24

Setting up a WLAN ............................................................................................ 25

Configuring a wireless router ............................................................................ 25

Protecting your WLAN ....................................................................................... 25

Connecting to a WLAN ...................................................................................... 26

Using Bluetooth wireless devices ...................................................................................... 26

4 Enjoying entertainment features ................................................................................................................. 27

Multimedia features ............................................................................................................................ 27

Using the webcam .............................................................................................................................. 30

Using audio ........................................................................................................................................ 30

Connecting speakers ......................................................................................................... 31

Connecting headphones and microphones ....................................................................... 31

Testing your audio features ............................................................................................... 31

Using video ......................................................................................................................................... 32

Connecting video devices by using an HDMI cable ........................................................... 32

Setting up HDMI audio ...................................................................................... 33

Camera .............................................................................................................................. 34

Discovering and connecting to Miracast-compatible wireless displays (select models only) ............. 34

5 Navigating the screen ................................................................................................................................... 35

Using the TouchPad ........................................................................................................................... 35

Using TouchPad gestures .................................................................................................................. 35

Tapping .............................................................................................................................. 36

Scrolling ............................................................................................................................. 36

Pinching/zooming .............................................................................................................. 37

Rotating (select models only) ............................................................................................ 37

Flicking (select models only) .............................................................................................. 38

Edge swipes ...................................................................................................................... 38

Right-edge swipe .............................................................................................. 39

Top-edge swipe ................................................................................................. 39

vi

Left-edge swipe ................................................................................................. 40

Using the keyboard and mouse .......................................................................................................... 40

Using the keys ................................................................................................................... 40

Using the action keys ........................................................................................ 40

Using Windows shortcut keys ........................................................................... 42

Using the hot keys ............................................................................................. 42

6 Managing power ............................................................................................................................................ 43

Initiating Sleep and Hibernation ......................................................................................................... 43

Intel Rapid Start Technology (select models only) ............................................................ 43

Initiating and exiting Sleep ................................................................................................. 44

Enabling and exiting Hibernation (select models only) ...................................................... 44

Setting password protection on wakeup ............................................................................................. 45

Using the power meter and power settings ........................................................................................ 45

Running on battery power .................................................................................................................. 45

Factory-sealed battery ....................................................................................................... 45

Finding battery information ................................................................................................ 46

Conserving battery power .................................................................................................. 46

Identifying low battery levels .............................................................................................. 46

Resolving a low battery level ............................................................................................. 47

Resolving a low battery level when external power is available ........................ 47

Resolving a low battery level when no power source is available ..................... 47

Resolving a low battery level when the computer cannot exit Hibernation ....... 47

Running on external AC power .......................................................................................................... 47

Troubleshooting power problems ....................................................................................................... 48

HP CoolSense (select models only) ................................................................................................... 48

Refreshing your software content with Intel Smart Connect Technology (select models only) .......... 48

Shutting down (turning off) the computer ........................................................................................... 49

7 Managing and sharing information ............................................................................................................. 50

Using a USB device ........................................................................................................................... 50

Connecting a USB device .................................................................................................. 50

Removing a USB device .................................................................................................... 51

Connecting a powered USB device ................................................................................... 51

Inserting and removing a memory card .............................................................................................. 52

8 Maintaining your computer .......................................................................................................................... 53

Improving performance ...................................................................................................................... 53

Using Disk Defragmenter ................................................................................................... 53

Using Disk Cleanup ........................................................................................................... 53

vii

Updating programs and drivers .......................................................................................................... 54

Cleaning your computer ..................................................................................................................... 54

Cleaning products .............................................................................................................. 54

Cleaning procedures .......................................................................................................... 54

Cleaning the display .......................................................................................... 55

Cleaning the sides and cover ............................................................................ 55

Cleaning the TouchPad, keyboard, or mouse ................................................... 55

Traveling with or shipping your computer ........................................................................................... 55

9 Securing your computer and information .................................................................................................. 57

Using passwords ................................................................................................................................ 57

Setting Windows passwords .............................................................................................. 58

Setting Setup Utility (BIOS) passwords ............................................................................. 58

Using Internet security software ......................................................................................................... 58

Using antivirus software ..................................................................................................... 59

Using firewall software ....................................................................................................... 59

Installing software updates ................................................................................................................. 59

Installing critical security updates ...................................................................................... 59

Installing Windows updates ............................................................................................... 59

Installing HP and third-party software updates ................................................................................... 60

Securing your wireless network .......................................................................................................... 60

Backing up your software applications and information ..................................................................... 60

10 Using Setup Utility (BIOS), MultiBoot, and HP PC Hardware Diagnostics (UEFI) ................................ 61

Starting Setup Utility (BIOS) ............................................................................................................... 61

Updating the BIOS ............................................................................................................................. 61

Determining the BIOS version ........................................................................................... 61

Downloading a BIOS update ............................................................................................. 62

Using HP PC Hardware Diagnostics (UEFI) ...................................................................................... 62

Downloading HP PC Hardware Diagnostics (UEFI) to a USB device ............................... 63

11 Backing up, restoring, and recovering ..................................................................................................... 64

Creating recovery media and backups ............................................................................................... 64

Restore and recovery ......................................................................................................................... 64

Recovering using HP Recovery Manager .......................................................................... 65

What you need to know ..................................................................................... 65

Using HP Recovery media to recover ............................................................... 65

Changing the computer boot order ................................................................... 66

viii

12 Specifications .............................................................................................................................................. 67

Input power ......................................................................................................................................... 67

Operating environment ....................................................................................................................... 67

13 Electrostatic Discharge .............................................................................................................................. 68

Index ................................................................................................................................................................... 69

ix

x

1 Starting right

This computer is a powerful tool designed to enhance your work and entertainment. Read this
chapter to learn about best practices after you set up your computer, fun things to do with your
computer, and where to find additional HP resources.

Revert to the familiar Start screen (select models only)

HP Quick Start gives you the option to use the familiar Start menu from the Windows desktop. Quick
Start functions like the traditional Windows Start menu and enables you to conveniently open files
and programs using the Windows desktop.

●

To open HP Quick Start, go the Windows desktop, and then click the HP Quick Start

on the taskbar.

Visit the HP Apps Store

The HP Apps Store offers a wide choice of popular games, entertainment and music apps,
productivity apps, and apps exclusive to HP that you can download to the Start screen. The selection
is updated regularly and includes regional content and country-specific offers. Be sure to check the
HP Apps Store frequently for new and updated features.

IMPORTANT: You must be connected to the Internet to access the HP Apps Store.

To view and download an app:

1. From the Start screen, select the Store app.

2. Select HP Picks to view all the available apps.

3. Select the app you want to download, and then follow the on-screen instructions. When the

download is complete, the app appears on the Start screen.

Best practices

To get the most out of your smart investment, after you set up and register the computer, we
recommend the following steps:

icon

If you haven’t already done so, connect to a wireless network. See details in

●

network on page 22

Take a minute to browse the printed Windows Basics guide to explore the new Windows®

●

features.

TIP: To quickly return to the computer Start screen from an open app or the Windows desktop,

press the Windows button on the tablet or the Windows key

the Windows button or key again will return you to the previous screen.

● Become familiar with the computer hardware and software. For more information, see Finding

your hardware and software information on page 4.

Revert to the familiar Start screen (select models only) 1

on your keyboard. Pressing

Connecting to a

Update or purchase antivirus software. Learn more at

●

on page 58.

Using Internet security software

Back up your hard drive by creating a recovery flash drive. See

●

backups on page 64

Fun things to do

You know that you can watch a YouTube video on the computer. But did you know that you can

●

also connect your computer to a television or gaming console? For more information, see

Connecting video devices by using an HDMI cable on page 32.

You know you can listen to music on the computer. But did you know that you can also stream

●

live radio to the computer and listen to music or talk radio from all over the world? See

entertainment features on page 27.

Use the TouchPad and the new Windows touch gestures for smooth control of images and

●

pages of text. See

on page 17.

Creating recovery media and

Enjoying

Using TouchPad gestures on page 35 and Using touch screen gestures

2 Chapter 1 Starting right

More HP resources

You have already used Setup Instructions to turn on the computer and locate this guide. To locate
resources that provide product details, how-to information, and more, use the information in this table.

Resource Contents

Setup Instructions

Windows Basics guide

Help and Support

To access Help and Support, from the Start screen,
type help, and then from the Search window, select
Help and Support. For U.S. support, go to

http://www.hp.com/go/contactHP. For worldwide

support, go to

wwcontact_us.html.

Safety & Comfort Guide

To access this guide, from the Start screen, type
support, select the HP Support Assistant app,
select My computer, and then select User guides, or

http://www.hp.com/ergo.

go to

Worldwide support web page

To get support in your language, go to

http://welcome.hp.com/country/us/en/
wwcontact_us.html.

Regulatory, Safety and Environmental Notices

To access this guide, from the Start screen, type
support, select the HP Support Assistant app,
select My computer, and then select User guides.

http://welcome.hp.com/country/us/en/

Overview of computer setup and features

●

Overview of using Windows®

●

● A broad range of how-to information and troubleshooting tips

● Proper workstation setup

Guidelines for posture and work habits that increase your

●

comfort and decrease your risk of injury

Electrical and mechanical safety information

●

● Online chat with an HP technician

Email support

●

Support telephone numbers

●

● HP service center locations

Important regulatory notices, including proper battery disposal

●

information

Limited Warranty*

To access this guide, from the Start screen, type
support, select the HP Support Assistant app,
select My computer, and then select Warranty and
services, or go to

orderdocuments.

*You can find the expressly provided HP Limited Warranty applicable to your product located with the user guides on your
computer and/or on the CD/DVD provided in the box. In some countries/regions, HP may provide a printed HP Limited
Warranty in the box. For countries/regions where the warranty is not provided in printed format, you may request a printed
copy from

● North America: Hewlett-Packard, MS POD, 11311 Chinden Blvd., Boise, ID 83714, USA

Europe, Middle East, Africa: Hewlett-Packard, POD, Via G. Di Vittorio, 9, 20063, Cernusco s/Naviglio (MI), Italy

●

Asia Pacific: Hewlett-Packard, POD, P.O. Box 200, Alexandra Post Office, Singapore 911507

●

When you request a printed copy of your warranty, please include your product number, warranty period (found on your
service label), name, and postal address.

IMPORTANT: Do NOT return your HP product to the addresses above. For U.S. support, go to

contactHP. For worldwide support, go to http://welcome.hp.com/country/us/en/wwcontact_us.html.

http://www.hp.com/go/

http://www.hp.com/go/orderdocuments or write to:

Specific warranty information about this computer

●

http://www.hp.com/go/

More HP resources 3

2 Getting to know your computer

Finding your hardware and software information

Locating hardware

To find out what hardware is installed on your computer:

1. From the Start screen, type c, and then select Control Panel.

2. Select System and Security, and then in the System area, click Device Manager.

A list reveals all the devices installed on your computer.

To find out information about system hardware components and the system BIOS version number,
press fn+esc.

Locating software

To find out what software is installed on your computer:

1. From the Start screen, right-click using the mouse

– or –

Swipe from the top of the TouchPad to reveal all apps.

2. Select the All apps icon.

Tablet edge components

4 Chapter 2 Getting to know your computer

Components Description

(1)

Power button

When the computer is off, press the button to turn on

●

the tablet.

When the computer is on, press the button briefly to

●

initiate Sleep.

When the computer is in the Sleep state, press the

●

button briefly to exit Sleep.

CAUTION: Pressing and holding down the power button

results in the loss of unsaved information.

NOTE: If the computer has stopped responding and

Microsoft® Windows® shutdown procedures are
ineffective, press and hold the power button down for at
least 5 seconds to turn off the tablet.

To learn more about your power settings, see

your power options. Swipe from the right edge of the
TouchPad or touch screen to display the charms, tap
Search, and then tap the search box. In the search box,
type power, tap Settings, and then tap Power options,

Managing power on page 43.

or see

– or –

On the Start screen, type power, select Power

and sleep settings, and then select Power and sleep
from the list of applications.

(2) Alignment post connectors (2) Align and attach the tablet to the keyboard dock.

(3)

(4) AC adapter/battery light ● White: The AC adapter is connected and the battery

(5) Docking port Connects the tablet to the keyboard dock.

Power connector Connects an AC adapter.

is charged.

Blinking white: The battery has reached a low battery

●

level.

● Amber: The AC adapter is connected and the battery

is charging.

Off: The computer is using DC power.

●

Tablet edge components 5

Components Description

(6)

(7)

(8) Vents Enable airflow to cool internal components.

(9) Volume button Controls speaker volume on the tablet.

Audio-out (headphone) jack/Audio-in
(microphone) jack

Micro memory card reader Supports micro Secure Digital (SD) memory cards.

Connects optional powered stereo speakers, headphones,
earbuds, a headset, or a television audio cable.

WARNING! To reduce the risk of personal injury, adjust

the volume before using headphones, earbuds, or a
headset. For additional safety information, see the
Regulatory, Safety and Environmental Notices.

NOTE: When a device is connected to the jack, the

computer speakers are disabled.

NOTE: Be sure that the device cable has a 4-conductor

connector that supports both audio-out (headphone) and
audio-in (microphone).

NOTE: Stand-alone microphones and headphones with

separate microphone jacks are not supported.

NOTE: The computer fan starts up automatically to cool

internal components and prevent overheating. It is normal
for the internal fan to cycle on and off during routine
operation.

To increase speaker volume, press the + edge of the

●

button.

● To decrease speaker volume, press the – edge of the

button.

6 Chapter 2 Getting to know your computer

Display

Component Description

(1) Internal microphones (2) Record audio, automatically filtering out the noise around you and

(2) Webcam light On: The webcam is on.

(3) Webcam Records video and captures photographs. Some models may allow

(4) Ambient light sensor Automatically adjusts the display brightness based on the lighting

(5) WLAN antenna* Sends and receives wireless signals to communicate with wireless

(6) Speakers (2) Produce sound.

cancelling echoes.

you to video conference and chat online using streaming video.

Swipe from the right edge of the TouchPad or touch screen

to display the charms, tap Search, and then tap the search box. Type
camera, and then tap Camera from the list of applications.

– or –

From the Start screen, type camera, and then select

Camera from the list of applications.

conditions in your environment.

local area networks (WLANs).

Display 7

Component Description

(7)

*The antenna is not visible from the outside of the computer. For optimal transmission, keep the areas immediately around
the antenna free from obstructions. For wireless regulatory notices, see the section of the Regulatory, Safety, and
Environmental Notices that applies to your country or region.

Windows button Returns you to the Start screen from an open app or the Windows

desktop.

NOTE: Pressing the Windows button again returns you to the

previous screen.

8 Chapter 2 Getting to know your computer

Keyboard dock

Top

Component Description

(1) Alignment posts Align and attach the tablet to the keyboard dock.

(2) Release latch Releases the tablet from the keyboard dock. To

(3) Docking connector Connects the tablet to the keyboard dock.

release the tablet, slide the release latch to the left.

Keyboard dock 9

TouchPad

Component Description

(1) TouchPad zone Reads your finger gesture to move the pointer or activate

(2) Left TouchPad button Functions like the left button of an external mouse.

(3) Right TouchPad button Functions like the right button on an external mouse.

items on the screen.

NOTE: The TouchPad also supports edge-swipe gestures.

For more information, see

on page 35.

Using TouchPad gestures

10 Chapter 2 Getting to know your computer

Lights

Component Description

(1) Caps lock light

(2)

(3)

Mute light

Wireless light

White: Caps lock is on, which switches the keys to all

●

capital letters.

Off: Caps lock is off.

●

Amber: Computer sound is off.

●

Off: Computer sound is on.

●

White: An integrated wireless device, such as a

●

wireless local area network (WLAN) device and/or a
Bluetooth® device, is on.

● Amber: All wireless devices are off.

Keyboard dock 11

Keys

Component Description

(1) esc key Displays system information when pressed in combination with the

(2) fn key Displays system information when pressed in combination with the

(3)

(4) Action keys Execute frequently used system functions.

Windows key Returns you to the Start screen from an open app or the Windows

fn key.

esc key.

desktop.

NOTE: Pressing the Windows key again returns you to the

previous screen.

NOTE: Action keys do not display or function from the on-screen

tablet keyboard.

12 Chapter 2 Getting to know your computer

Right side

Component Description

(1)

(2)

(3)

(4) AC adapter/battery light

USB 3.0 port Connect optional USB 3.0 devices and provide enhanced USB

HDMI port Connects an optional video or audio device, such as a high-

Power connector Connects an AC adapter.

power performance.

NOTE: For details about different types of USB ports, see

a USB device on page 50.

definition television, any compatible digital or audio component, or
a high-speed HDMI device.

White: The AC adapter is connected and the battery is

●

charged.

Blinking white: The battery has reached a low battery level.

●

● Amber: The AC adapter is connected and the battery is

charging.

Off: The computer is using battery power.

●

Using

Keyboard dock 13

Left side

Component Description

(1)

(2)

(3)

USB 2.0 port Connects an optional USB device.

NOTE: For details about different types of USB ports, see

Using a USB device on page 50.

Audio-out (headphone) jack/Audio-in
(microphone) jack

Memory card reader Reads data from and writes data to memory cards such as SD.

Connects optional powered stereo speakers, headphones,
earbuds, a headset, or a television audio cable. Also connects
an optional headset microphone.

WARNING! To reduce the risk of personal injury, adjust the

volume before using headphones, earbuds, or a headset. For
additional safety information, see the Regulatory, Safety and
Environmental Notices.

NOTE: When a device is connected to the jack, the computer

speakers are disabled.

NOTE: Be sure that the device cable has a 4-conductor

connector that supports both audio-out (headphone) and audio­in (microphone).

NOTE: Stand-alone microphones and headphones with

separate microphone jacks are not supported.

14 Chapter 2 Getting to know your computer

Releasing the tablet from the keyboard dock

To release the tablet from the keyboard dock, follow these steps:

1. Slide the release latch on the keyboard dock to the left (1).

2. Lift and remove the tablet (2).

Locating system information

Important system information is located on the bottom edge of the tablet. You may need the
information when travelling internationally or when you contact support:

Serial number

●

Product number

●

Warranty period

●

Regulatory and wireless certification information

●

Using Windows, briefly press the fn+esc key combination to display the System Information screen,
which provides the product name and serial number of your computer, as well as information about
the memory, processor, BIOS, and keyboard.

Locating system information 15

Changing your tablet's settings

You can change view and screen brightness.

Changing your tablet's view

Your tablet's orientation, or view, changes automatically from landscape to portrait view, or from
portrait to landscape view.

1. To change the view of your tablet from landscape view to portrait view:

Hold the tablet vertically, and then turn it 90 degrees to the right (in a clockwise direction).

2. To change the view of your tablet from portrait view to landscape view:

Hold the tablet vertically, and then turn it 90 degrees to the left (in a counter-clockwise direction).

Adjusting your tablet's autorotate lock

To adjust your tablet's autorotate lock when the tablet is undocked:

1. Swipe from the right edge of the TouchPad or touch screen to display the charms, and then tap

Settings.

2. Tap the Screen icon at the bottom right. Tap the Autorotate Lock icon to lock your current

tablet screen in place and to prevent rotation. The icon displays a lock symbol when autorotate
lock is active. To turn off the autorotate lock, tap the Autorotate Lock icon again.

Adjusting your tablet's screen brightness

To adjust the screen brightness:

1. Swipe from the right edge of the TouchPad or touch screen to display the charms, and then tap

Settings.

2. Tap the Screen icon at the bottom right. A vertical slider displays that controls the screen

brightness.

NOTE: From the Windows desktop, you can also tap the Power Meter icon in the notification area

at the far right of the taskbar, tap Adjust screen brightness, and then move the slider next to
Screen brightness at the bottom of the screen.

16 Chapter 2 Getting to know your computer

Using touch screen gestures

A touch screen computer allows you to control items on the screen directly with your fingers.

TIP: On touch screen computers, you can perform the gestures on the screen or on the TouchPad.

You can also perform on-screen actions with the keyboard and mouse.

One-finger slide

The one-finger slide is mostly used to pan or scroll through lists and pages, but you can use it for
other interactions, too, such as moving an object.

To scroll across the screen, lightly slide one finger across the screen in the direction you want to

●

move.

NOTE: When many apps are displayed on the Start screen, you can slide your finger to move

the screen left or right.

● To drag, press and hold an object, and then drag the object to move it.

Using touch screen gestures 17

Tapping

To make an on-screen selection, use the tap function.

●

Use one finger to tap an object on the screen to make a selection. Double-tap an item to open it.

NOTE: Press and hold your finger on an object to open a help screen that provides information

about the object.

Pinching/stretching

Pinching and stretching allows you to zoom out or in on images or text.

Zoom in by placing two fingers together on the display and then move your fingers apart.

●

● Zoom out by placing two fingers apart on the display and then move your fingers together.

18 Chapter 2 Getting to know your computer

Rotating (select models only)

Rotating allows you to turn items such as photos.

Anchor the forefinger of your left hand on the object you want to rotate. Using your right hand,

●

slide your forefinger around in a sweeping motion from 12 o’clock to 3 o’clock. To reverse the
rotation, move your forefinger from 3 o’clock to 12 o’clock.

NOTE: Rotate is intended for specific apps where you can manipulate an object or image. Rotate

may not be functional for all apps.

Edge swipes

With edge swipes you can perform tasks such as changing settings and finding or using apps.

Right-edge swipe

The right-edge swipe reveals the charms, which let you search, share, start apps, access devices, or
change settings.

Gently swipe your finger inward from the right edge of the display bezel onto the screen to

●

display the charms.

Using touch screen gestures 19

Left-edge swipe

The left-edge swipe accesses your recently opened apps so that you can switch between them
quickly.

Gently swipe your finger inward from the left edge of the display bezel to switch between

●

recently-opened apps.

Without lifting your finger, swipe back toward the left edge to display all recently opened apps.

●

Top or bottom-edge swipe

The top or bottom-edge swipe displays app command options that allow you to customize apps.

IMPORTANT: When an app is open, the top or bottom-edge gesture varies depending on the app.

Gently swipe your finger from the top or bottom edge to reveal the app command options.

▲

20 Chapter 2 Getting to know your computer

Setting touch screen preferences

Mode Steps

1. Swipe from the right edge of the TouchPad or touch screen to display the charms, tap

Search, and then tap the search box.

2. Type c, tap Control Panel, tap Hardware and Sound, tap Pen and Touch, and then follow

the on-screen instructions.

1. On the Start screen, type c, and then select Control Panel.

2. Select Hardware and Sound, select Pen and Touch, and then follow the on-screen

instructions.

These preferences are specific to the touch screen and the computer.

Using the on-screen keyboard

You may want to enter data into a data field. This may be required when you set up a wireless
network configuration or a weather reporting location, or when you access user accounts on Internet
sites. The computer has an on-screen keyboard that is displayed when you need to enter such
information.

1. To display the keyboard, tap in the first data field. Tap the small keyboard icon that is displayed.

– or –

Tap the keyboard icon on the right side of the notification area.

2. To enlarge the size of the on-screen keyboard, tap the lower-right corner and drag it to the

desired size.

3. Tap each character, continuing until you have spelled out the name or word that you are

entering into the data field.

NOTE: Action keys do not display or function on the on-screen keyboard.

NOTE: Suggested words may be displayed at the top of the on-screen keyboard. If an

appropriate word is displayed, tap it to select it.

4. Tap enter on the keyboard.

Setting touch screen preferences 21

3 Connecting to a network

Your computer can travel with you wherever you go. But even at home, you can explore the globe
and access information from millions of websites using your computer and a wired or wireless
network connection. This chapter will help you get connected to that world.

Connecting to a wireless network

Wireless technology transfers data across radio waves instead of wires. Your computer may be
equipped with one or more of the following wireless devices:

Wireless local area network (WLAN) device—Connects the computer to wireless local area

●

networks (commonly referred to as Wi-Fi networks, wireless LANs, or WLANs) in corporate
offices, your home, and public places such as airports, restaurants, coffee shops, hotels, and
universities. In a WLAN, the mobile wireless device in your computer communicates with a
wireless router or a wireless access point.

Bluetooth device—Creates a personal area network (PAN) to connect to other Bluetooth-

●

enabled devices such as computers, phones, printers, headsets, speakers, and cameras. In a
PAN, each device communicates directly with other devices, and devices must be relatively
close together—typically within 10 meters (approximately 33 feet) of each other.

For more information about wireless technology, see the information and website links provided in
Help and Support. From the Start screen, type help, and then select Help and Support.

Using the wireless controls

You can control the wireless devices in your computer using these features:

● Wireless button, wireless switch, or wireless key (referred to in this chapter as the wireless

button) (select models only)

Operating system controls

●

Using the wireless button

The computer has a wireless button, one or more wireless devices, and one or two wireless lights,
depending on the model. All of the wireless devices on your computer are enabled at the factory, so
the wireless light is on (white) when you turn on the computer.

The wireless light indicates the overall power state of your wireless devices, not the status of
individual devices. If the wireless light is white, at least one wireless device is on. If the wireless light
is off, all wireless devices are off.

NOTE: On some models, the wireless light is amber when all wireless devices are off.

Because the wireless devices are enabled at the factory, you can use the wireless button to turn on or
turn off the wireless devices simultaneously.

Using operating system controls

The Network and Sharing Center allows you to set up a connection or network, connect to a network,
and diagnose and repair network problems.

22 Chapter 3 Connecting to a network

To use operating system controls:

Mode Steps

1. Swipe from the right edge of the TouchPad or touch screen to display the charms, tap

Search, and then tap the search box.

2. Type control panel in the search box, and then tap Control Panel.

3. Tap Network and Internet, and then tap Network and Sharing Center.

1. From the Start screen, type control panel, and then select Control Panel.

2. Select Network and Internet, and then select Network and Sharing Center.

For more information, from the Start screen, type help, and then select Help and Support.

Sharing data and drives and accessing software

When your computer is part of a network, you are not limited to using only the information that is
stored in your computer. Network computers can exchange software and data with each other.

NOTE: When a disc like a DVD movie or game is copy-protected, it cannot be shared.

To share folders or content on the same network:

1. From the Windows desktop, open File Explorer.

2. From This PC, click a folder with content you want to share. Select Share from the navigation

bar at the top of the window, and then click Specific people.

3. Type a name in the File Sharing box, and then click Add.

4. Click Share and then follow the on-screen instructions.

To share drives on the same network:

1. From the Windows desktop, right-click the network status icon in the notification area, at the far

right of the taskbar.

2. Select Open Network and Sharing Center.

3. Under View your active networks, select an active network.

4. Select Change advanced sharing settings to set sharing options for privacy, network

discovery, file and printer sharing or other network options.

Using a WLAN

With a WLAN device, you can access a wireless local area network (WLAN), which is composed of
other devices and accessories that are linked by a wireless router or a wireless access point.

Connecting to a wireless network 23

NOTE: The terms wireless router and wireless access point are often used interchangeably.

● A large-scale WLAN, such as a corporate or public WLAN, typically uses wireless access points

that can accommodate a large number of devices and accessories and can separate critical
network functions.

A home or small office WLAN typically uses a wireless router, which allows several wireless and

●

wired devices to share an Internet connection, a printer, and files without requiring additional
pieces of hardware or software.

To use the WLAN device in your computer, you must connect to a WLAN infrastructure (provided
through a service provider or a public or corporate network).

Using an Internet service provider

When you are setting up Internet access in your home, you must establish an account with an
Internet service provider (ISP). To purchase Internet service and a modem, contact a local ISP. The
ISP will help set up the modem, install a network cable to connect your wireless router to the modem,
and test the Internet service.

NOTE: Your ISP will give you a user ID and a password to use for Internet access. Record this

information and store it in a safe place.

24 Chapter 3 Connecting to a network

Setting up a WLAN

To set up a WLAN and connect to the Internet, you need the following equipment:

● A broadband modem (either DSL or cable) (1) and high-speed Internet service purchased from

an Internet service provider

A wireless router (2) (purchased separately)

●

A wireless computer (3)

●

NOTE: Some modems have a built-in wireless router. Check with your ISP to determine what type

of modem you have.

The illustration below shows an example of a wireless network installation that is connected to the
Internet.

As your network grows, additional wireless and wired devices can be connected to the network to
access the Internet.

For help in setting up your WLAN, see the information provided by your router manufacturer or your
ISP.

Configuring a wireless router

For help in setting up a WLAN, see the information provided by your router manufacturer or your ISP.

NOTE: It is recommended that you initially connect your new wireless device to the router by using

the network cable provided with the router. When the device successfully connects to the Internet,
disconnect the cable, and access the Internet through your wireless network.

Protecting your WLAN

When you set up a WLAN or access an existing WLAN, always enable security features to protect
your network from unauthorized access. WLANs in public areas (hotspots) like coffee shops and
airports may not provide any security. If you are concerned about the security of your device when
connected to a hotspot, limit your network activities to email that is not confidential and basic Internet
surfing.

Wireless radio signals travel outside the network, so other WLAN devices can pick up unprotected
signals. Take the following precautions to protect your WLAN:

● Use a firewall.

A firewall checks both data and requests for data that are sent to your network, and discards any
suspicious items. Firewalls are available in both software and hardware. Some networks use a
combination of both types.

Use wireless encryption.

●

Wireless encryption uses security settings to encrypt and decrypt data that is transmitted over
the network. For more information, from the Start screen, type help, and then select Help and
Support.

Connecting to a wireless network 25

Connecting to a WLAN

To connect to the WLAN, follow these steps:

1. Be sure that the WLAN device is on.

2. From the Windows desktop, tap or click the network status icon in the notification area, at the far

right of the taskbar.

3. Select your WLAN from the list.

4. Click Connect.

5. If the WLAN is a security-enabled WLAN, you are prompted to enter a security code. Type the

code, and then click OK to complete the connection.

NOTE: If no WLANs are listed, you may be out of range of a wireless router or access point.

NOTE: If you do not see the WLAN you want to connect to, from the Windows desktop, right-

click the network status icon, and then select Open Network and Sharing Center. Click Set up
a new connection or network. A list of options is displayed, allowing you to manually search

for and connect to a network or to create a new network connection.

After the connection is made, place the mouse pointer over the network status icon in the notification
area, at the far right of the taskbar, to verify the name and status of the connection.

NOTE: The functional range (how far your wireless signals travel) depends on WLAN

implementation, router manufacturer, and interference from other electronic devices or structural
barriers such as walls and floors.

Using Bluetooth wireless devices

A Bluetooth device provides short-range wireless communications that replace the physical cable
connections that traditionally link electronic devices such as the following:

Computers (desktop, notebook, PDA)

●

Phones (cellular, cordless, smart phone)

●

Imaging devices (printer, camera)

●

Audio devices (headset, speakers)

●

Mouse

●

Bluetooth devices provide peer-to-peer capability that allows you to set up a personal area network
(PAN) of Bluetooth devices. For information about configuring and using Bluetooth devices, see the
Bluetooth software Help.

26 Chapter 3 Connecting to a network

4 Enjoying entertainment features

Use your HP computer as an entertainment hub to socialize via the webcam, enjoy and manage your
music, and download and watch movies. Or, to make your computer an even more powerful
entertainment center, connect external devices like a monitor, projector, or television, or speakers
and headphones.

Multimedia features

Here are some of the entertainment features on your computer.

Multimedia features 27

Component Description

(1)

(2) Volume button Controls speaker volume.

Audio-out (headphone) jack/Audio-in
(microphone) jack

Connects optional powered stereo
speakers, headphones, earbuds, a
headset, or a television audio cable.
Also connects an optional headset
microphone.

WARNING! To reduce the risk of

personal injury, adjust the volume before
using headphones, earbuds, or a
headset. For additional safety
information, see the Regulatory, Safety
and Environmental Notices.

NOTE: When a device is connected to

the jack, the computer speakers are
disabled.

NOTE: Be sure that the device cable

has a 4-conductor connector that
supports both audio-out (headphone)
and audio-in (microphone).

NOTE: Stand-alone microphones and

headphones with separate microphone
jacks are not supported.

To increase speaker volume, press

●

the + edge of the button.

To decrease speaker volume, press

●

the – edge of the button.

28 Chapter 4 Enjoying entertainment features

Component Description

(1) Internal microphones (2) Record sound.

(2) Webcam light On: The webcam is in use.

(3) Webcam Records video and captures photographs.

(4) Ambient light sensor Automatically adjusts the display brightness

(5) Speakers (2) Produce sound.

(6)

HDMI port Connects an optional video or audio device,

Some models may allow you to video
conference and chat online using streaming
video.

Swipe from the right edge of the

TouchPad or touch screen to display the
charms, tap Search, and then tap the
search box. type camera, and then tap
Camera from the list of applications.

– or –

From the Start screen, type

camera, and then select Camera from the
list of applications.

based on the lighting conditions in your
environment.

such as a high-definition television, any
compatible digital or audio component, or a
high-speed HDMI device.

(7)

USB 3.0 port Connects optional USB 3.0 devices and

provide enhanced USB power performance.

NOTE: For details about different types of

USB ports, see

on page 50.

Using a USB device

Multimedia features 29

Component Description

(8)

(9)

Using the webcam

Audio-out (headphone) jack/Audio-in
(microphone) jack

USB 2.0 port Connects an optional USB device.

Connects optional powered stereo
speakers, headphones, earbuds, a headset,
or a television audio cable. Also connects an
optional headset microphone.

WARNING! To reduce the risk of personal

injury, adjust the volume before using
headphones, earbuds, or a headset. For
additional safety information, see the

Regulatory, Safety and Environmental
Notices.

NOTE: When a device is connected to the

jack, the computer speakers are disabled.

NOTE: Be sure that the device cable has a

4-conductor connector that supports both
audio-out (headphone) and audio-in
(microphone).

NOTE: Stand-alone microphones and

headphones with separate microphone
jacks are not supported.

The computer has an integrated webcam that records video and captures photographs. Some models
may allow you to video conference and chat online using streaming video.

To start the webcam:

Mode Steps

For details about using the webcam, go to Help and Support. From the Start screen, type h, and then
select Help and Support.

Using audio

On your computer, you can play music CDs, download and listen to music, stream audio content from
the web (including radio), record audio, or mix audio and video to create multimedia. To enhance your
listening enjoyment, attach external audio devices such as speakers or headphones.

1. Swipe from the right edge of the TouchPad or touch screen to display the charms, tap

Search, and then tap the search box.

2. Type camera, and then tap Camera from the list of applications.

From the Start screen, type camera, and then select Camera from the list of applications.

30 Chapter 4 Enjoying entertainment features

Connecting speakers

You can attach wired speakers to your computer by connecting them to a USB port or to the audio­out (headphone) jack on your computer or on a docking station.

To connect wireless speakers to your computer, follow the device manufacturer's instructions. To
connect high-definition speakers to the computer, see
connecting speakers, lower the volume setting.

Connecting headphones and microphones

You can connect wired headphones or headsets to the audio-out (headphone)/audio-in (microphone)
jack on your computer. Many headsets with integrated microphones are commercially available.

To connect wireless headphones or headsets to your computer, follow the device manufacturer's
instructions.

WARNING! To reduce the risk of personal injury, lower the volume setting before putting on

headphones, earbuds, or a headset. For additional safety information, see the Regulatory, Safety and
Environmental Notices. To access this guide, from the Start screen, type support, select the HP

Support Assistant app, select My computer, and then select User guides.

Testing your audio features

To check the audio functions on your computer, follow these steps:

Setting up HDMI audio on page 33. Before

Mode Steps

1. Swipe from the right edge of the TouchPad or touch screen to display the charms, tap

Search, and then tap the search box.

2. Type c, tap Control Panel, tap Hardware and Sound, and then tap Sound.

3. When the Sound window opens, tap the Sounds tab. Under Program Events, tap any sound

event, such as a beep or alarm, and then tap Test.

1. On the Start screen, type c, and then select Control Panel from the list of applications.

2. Select Hardware and Sound, and then select Sound.

3. When the Sound window opens, select the Sounds tab. Under Program Events, select any

sound event, such as a beep or alarm, and then click Test.

You should hear sound through the speakers or through connected headphones.

To check the recording functions on your computer, follow these steps:

Using audio 31

Mode Steps

1. Swipe from the right edge of the TouchPad or touch screen to display the charms, tap

Search, and then tap the search box.

2. Type s, and then tap Sound Recorder.

3. Tap Start Recording and speak into the microphone. Save the file to your desktop.

4. Open a multimedia program and play the recording.

1. From the Start screen, type s, and then select Sound Recorder.

2. Click Start Recording and speak into the microphone. Save the file to your desktop.

3. Open a multimedia program and play the recording.

To confirm or change the audio settings on your computer:

Mode Steps

1. Swipe from the right edge of the TouchPad or touch screen to display the charms, tap

Search, and then tap the search box.

2. Type c, and then tap Control Panel from the list of applications.

3. Tap Hardware and Sound, and then tap Sound.

1. From the Start screen, type c, and then select Control Panel from the list of applications.

2. Select Hardware and Sound, and then select Sound.

Using video

Your computer is a powerful video device that enables you to watch streaming video from your
favorite websites and download video and movies to watch on your computer without needing to
connect to a network.

To enhance your viewing enjoyment, use one of the video ports on the keyboard dock to connect an
external monitor, projector, or television. Your computer has a high-definition multimedia interface
(HDMI) port, which allows you to connect a high-definition monitor or television.

IMPORTANT: Be sure that the external device is connected to the correct port on the computer,

using the correct cable. Check the device manufacturer's instructions if you have questions.

Connecting video devices by using an HDMI cable

NOTE: To connect an HDMI device to your keyboard dock, you need an HDMI cable, sold

separately.

32 Chapter 4 Enjoying entertainment features

To see the computer screen image on a high-definition television or monitor, connect the high­definition device according to the following instructions.

1. Connect one end of the HDMI cable to the HDMI port on the computer.

2. Connect the other end of the cable to the high-definition television or monitor.

3. Press f4 on the computer to alternate the computer screen image between 4 display states:

PC screen only: View the screen image on the computer only.

●

Duplicate: View the screen image simultaneously on both the computer and external

●

device.

Extend: View the screen image extended across both the computer and external device.

●

Second screen only: View the screen image on the external device only.

●

Each time you press f4 on the computer, the display state changes.

NOTE: Adjust the screen resolution of the external device, especially if you choose the

“Extend” option. From the Start screen on the keyboard dock, type control panel, and then
select Control Panel from the list of applications. Select Appearance and Personalization.
Under Display, select Adjust screen resolution for best results.

Setting up HDMI audio

HDMI is the only video interface that supports high-definition video and audio. After you connect an
HDMI television to the computer, you can then turn on HDMI audio by following these steps:

1. From the Windows desktop, right-click the Speakers icon in the notification area, at the far right

of the taskbar, and then select Playback devices.

2. On the Playback tab, select the name of the digital output device.

3. Click Set Default, and then click OK.

To return the audio stream to the computer speakers:

1. From the Windows desktop, right-click the Speakers icon in the notification area, at the far right

of the taskbar, and then click Playback devices.

2. On the Playback tab, click Speakers.

3. Click Set Default, and then click OK.

Using video 33

Camera

Your tablet includes an integrated webcam which is an input device that allows you to record video
and take photos.

Discovering and connecting to Miracast-compatible wireless displays (select models only)

To discover and connect to Miracast-compatible wireless displays without leaving your current apps,
follow the steps below.

Action Using a keyboard and mouse Using touch gestures

Discover and connect to Miracast­compatible wireless displays

Point to the upper-right or lower-right
corner of the Start screen to display the
charms, click Devices, click Project,
and then follow the on-screen
instructions.

Swipe from the right edge of the Start
screen to display the charms, tap
Devices, tap Project, and then follow
the on-screen instructions.

34 Chapter 4 Enjoying entertainment features

5 Navigating the screen

Your computer allows navigation using touch gestures in addition to the keyboard and mouse. Touch
gestures can be used on your computer's TouchPad or on a touch screen.

NOTE: An external USB mouse (purchased separately) can be connected to one of the USB ports

on the keyboard dock.

Review the Windows Basics guide included with your computer. The guide provides information on
common tasks using the TouchPad, touch screen, or the keyboard.

Action keys do not display or function on the on-screen keyboard of the tablet. Tablet models have
special hot key functions on the keyboard to perform routine tasks.

Using the TouchPad

The TouchPad allows you to navigate the computer screen by using simple finger movements.

You can customize the touch gestures by changing settings, button configurations, click speed, and
pointer options. From the Start screen, type c, select Control Panel, and then select Hardware and

Sound. Under Devices and Printers, select Mouse.

Using TouchPad gestures

TIP: Use the left and right buttons on the TouchPad as you would use the corresponding buttons on

an external mouse.

NOTE: TouchPad gestures are not supported in all apps.

Using the TouchPad 35

Tapping

To make an on-screen selection, use the Tap function on the TouchPad.

●

NOTE: Press and hold on the TouchPad to open a help screen that provides information about the

selected item.

Point to an item on the screen, and then tap one finger on the TouchPad zone to make a
selection. Double-tap an item to open it.

Scrolling

Scrolling is useful for moving up, down, or sideways on a page or image.

●

Place two fingers slightly apart on the TouchPad zone and then drag them up, down, left, or
right.

36 Chapter 5 Navigating the screen

Pinching/zooming

Pinching and zooming allow you to zoom out or in on images or text.

Zoom in by placing two fingers together on the TouchPad zone and then moving your fingers

●

apart.

● Zoom out by placing two fingers apart on the TouchPad zone and then moving your fingers

together.

Rotating (select models only)

Rotating allows you to turn items such as photos.

Point to an object, then anchor the forefinger of your left hand in the TouchPad zone. Using your

●

right hand, slide your forefinger in a sweeping motion from 12 o’clock to 3 o’clock. To reverse the
rotation, move your forefinger from 3 o’clock to 12 o’clock.

NOTE: Rotate is intended for specific apps where you can manipulate an object or image. It may

not be functional for all apps.

Using TouchPad gestures 37

Flicking (select models only)

Flicking allows you to navigate through screens or quickly scroll through documents.

Place three fingers on the TouchPad zone and flick your fingers in a light, quick motion up,

●

down, left or right.

Edge swipes

Edge swipes allow you to access toolbars on your computer for tasks such as changing settings and
finding or using apps.

38 Chapter 5 Navigating the screen

Right-edge swipe

The right-edge swipe accesses the charms, which let you search, share, start apps, access devices,
or change settings.

Swipe your finger gently from the right edge to display the charms.

●

Top-edge swipe

The top-edge swipe displays app command options that allow you to customize apps.

IMPORTANT: When an app is open, the top-edge gesture varies depending on the app.

Gently swipe your finger from the top edge to reveal the app command options.

●

Using TouchPad gestures 39

Left-edge swipe

The left-edge swipe accesses your recently opened apps so that you can switch between them
quickly.

Swipe your finger gently from the left edge of the TouchPad to switch between recently opened

●

apps.

Using the keyboard and mouse

The keyboard and mouse allow you to type, select items, scroll and perform the same functions as
using touch gestures. The keyboard dock allows you to use special action keys and hot keys to
perform specific functions.

NOTE: Action keys do not display or function on the on-screen keyboard of the tablet.

TIP: The Windows key on the keyboard allows you to quickly return to the Start screen from

an open app or the Windows desktop. Pressing the Windows key again returns you to the previous
screen.

NOTE: Depending on the country or region, your keyboard may have different keys and keyboard

functions than those discussed in this section.

Using the keys

Your computer has different ways to quickly access information or perform functions with certain key
combinations.

Using the action keys

NOTE: Action keys do not display or function on the on-screen keyboard of the tablet.

An action key on the keyboard dock performs an assigned function. The icon on each of the f1
through f4 and f6 through f12 keys illustrates the assigned function for that key.

40 Chapter 5 Navigating the screen

To use an action key function, press and hold the key.

CAUTION: Use extreme care when making changes in Setup Utility (BIOS). Errors can prevent the

computer from operating properly.

The keyboard dock action key feature is enabled at the factory. You can disable this feature in Setup
Utility (BIOS). See

Using Setup Utility (BIOS), MultiBoot, and HP PC Hardware Diagnostics (UEFI)
on page 61 for instructions on opening Setup Utility (BIOS), and then follow the instructions at the

bottom of the screen.

To activate the assigned function after disabling the action key feature on the keyboard dock, you
must press the fn key in combination with the appropriate action key.

Icon Key Description

f1 Opens Help and Support, which provides tutorials, information about the Windows

operating system and your computer, answers to questions, and updates to your
computer.

Help and Support also provides automated troubleshooting tools and access to
support.

f2 Decreases the screen brightness incrementally as long as you hold down the key.

f3 Increases the screen brightness incrementally as long as you hold down the key.

f4 Switches the screen image between display devices connected to the system. For

example, if a monitor is connected to the computer, pressing this key alternates the
screen image from the computer display to the monitor display to a simultaneous
display on both the computer and the monitor.

This action key can also alternate images among other devices that are receiving
video information from the computer.

f6 Mutes or restores speaker sound.

f7 Decreases speaker volume incrementally as long as you hold down the key.

f8 Increases speaker volume incrementally as long as you hold down the key.

f9 Plays the previous track of an audio CD or the previous section of a DVD or a BD.

f10 Begins, pauses, or resumes playback of an audio CD, a DVD, or a BD.

f11 Plays the next track of an audio CD or the next section of a DVD or a BD.

f12 Turns the wireless feature on or off.

NOTE: A wireless network must be set up before a wireless connection is possible.

Using the keyboard and mouse 41

Using Windows shortcut keys

Microsoft Windows 8 provides shortcuts to perform actions quickly. Press the Windows key in

combination with a designated key in the table to perform the action.

For additional information on Windows shortcut keys, go to Help and Support. From the Start
screen, type help, and then select Help and Support.

NOTE: Action keys do not display or function from the on-screen keyboard of the tablet.

For commonly used shortcuts, use the Windows Basics guide.

Using the hot keys

A hot key is a combination of the fn key and the esc key.

To use a hot key:

Briefly press the fn key, and then briefly press the second key of the combination.

▲

Function Hot key Description

Display system information. fn+esc Displays information about system hardware components and the

system BIOS version number.

42 Chapter 5 Navigating the screen

6 Managing power

Your computer can operate on either battery power or external power. When the computer is only
running on battery power and an AC power source is not available to charge the battery, it is
important to monitor and conserve the battery charge. Your computer supports an optimal power plan
to manage how your computer uses and conserves power so that computer performance can be
balanced with power conservation.

Initiating Sleep and Hibernation

Microsoft Windows has two power-saving states, Sleep and Hibernation.

Sleep–The Sleep state is automatically initiated after a period of inactivity when running on

●

battery power or on external power. Your work is saved to memory, allowing you to resume your
work very quickly. You can also initiate Sleep manually. For more information, see

exiting Sleep on page 44.

Hibernation–The Hibernation state is automatically initiated if the battery reaches a critical level.

●

In the Hibernation state, your work is saved to a hibernation file and the computer powers down.

NOTE: If you want to initiate Hibernation manually, you can enable Hibernation using Power

Options. For more information, see

on page 44.

Enabling and exiting Hibernation (select models only)

Initiating and

CAUTION: To reduce the risk of possible audio and video degradation, loss of audio or video

playback functionality, or loss of information, do not initiate Sleep while reading from or writing to a
disc or an external media card.

NOTE: You cannot initiate any type of networking connection or perform any computer functions

while the computer is in the Sleep state or in Hibernation.

Intel Rapid Start Technology (select models only)

For select models, the Intel Rapid Start Technology (RST) feature is enabled by default. Rapid Start
Technology allows your computer to resume quickly from inactivity.

Rapid Start Technology manages your power-saving options as follows:

● Sleep—Rapid Start Technology allows you to select the Sleep state. To exit from Sleep, press

any key, activate the TouchPad, or press the power button briefly.

Hibernation—Rapid Start Technology initiates Hibernation after a period of inactivity while in the

●

Sleep state when running on battery power or on external power or when the battery reaches a
critical level. After Hibernation is initiated, press the power button to resume your work.

NOTE: Rapid Start Technology can be disabled in Setup Utility (BIOS). If you want to be able to

initiate the Hibernation state, you must enable user-initiated Hibernation using Power Options. See

Enabling and exiting Hibernation (select models only) on page 44.

Initiating Sleep and Hibernation 43

Initiating and exiting Sleep

With the computer on, you can initiate Sleep in the following ways:

Briefly press the power button.

●

●

Swipe from the right edge of the TouchPad or touch screen to display the charms, tap

Settings, tap the Power icon, and then tap Sleep.

– or –

From the Start screen, point to the upper-right or lower-right corner of the screen. When

the charms list opens, select Settings, select the Power icon, and then select Sleep.

To exit Sleep:

Press the Windows key.

●

Briefly press the power button.

●

If the display is closed, and the tablet is connected to the keyboard dock, open the display.

●

Press a key on the keyboard.

●

● Tap or swipe the TouchPad.

When the computer exits Sleep, the power lights turn on and the computer returns to the screen
where you stopped working.

NOTE: If you have set a password to be required on wakeup, you must enter your Windows

password before the computer will return to the screen.

Enabling and exiting Hibernation (select models only)

You can enable user-initiated Hibernation and change other power settings and timeouts using Power
Options:

1. From the Start screen, type power, select Settings, and then select Power Options from the

list of applications.

2. In the left pane, click Choose what the power button does.

3. Click Change Settings that are currently unavailable.

4. In the When I press the power button area, select Hibernate.

5. Click Save changes.

When the computer exits Hibernation, the power lights turn on and your work returns to the screen.

NOTE: If you have set a password to be required on wakeup, you must enter your Windows

password before your work will return to the screen.

44 Chapter 6 Managing power

Setting password protection on wakeup

To set the computer to prompt for a password when the computer exits Sleep or Hibernation, follow
these steps:

1. From the Start screen, type power, select Settings, and then select Power Options from the

list of applications.

2. In the left pane, click Require a password on wakeup.

3. Click Change Settings that are currently unavailable.

4. Click Require a password (recommended).

NOTE: If you need to create a user account password or change your current user account

password, click Create or change your user account password, and then follow the on-
screen instructions. If you do not need to create or change a user account password, go to step

5.

5. Click Save changes.

Using the power meter and power settings

The power meter is located on the Windows desktop. The power meter allows you to quickly access
power settings and view the remaining battery charge.

To display the percentage of remaining battery charge and the current power plan, on the

●

Windows desktop, point over the power meter icon.

To use Power Options, click the power meter icon and select an item from the list. From the

●

Start screen, type power, select Settings, and then select Power Options.

Different power meter icons indicate whether the computer is running on battery or external power.
The icon also displays a message if the battery has reached a low or critical battery level.

Running on battery power

When a charged battery is in the tablet and the tablet is not plugged into external power, the tablet
runs on battery power. If the tablet has a charged battery installed and the AC adapter is
disconnected from the tablet, the tablet automatically switches to battery power and the display
brightness decreases to conserve battery life. The battery in the tablet slowly discharges when the
tablet is off and unplugged from external power. When the tablet is attached to the keyboard dock,
the system is powered by the keyboard dock’s battery until the battery reaches a critical level in the
keyboard dock. At that time, the system switches to the tablet’s battery.

Computer battery life varies, depending on power management settings, programs running on the
computer, display brightness, external devices connected to the tablet, and other factors.

NOTE: There is a secondary battery in the keyboard dock. When the tablet is attached to the

keyboard dock, the system is powered by the keyboard dock's battery.

Factory-sealed battery

To monitor the status of your battery, or if the battery is no longer holding a charge, run Battery Check
in HP Support Assistant. To access battery information, from the Start screen, type support, select
the HP Support Assistant app, and then select Battery and performance. If Battery Check
indicates that your battery should be replaced, contact support.

Setting password protection on wakeup 45

Do not attempt to remove or replace the factory-sealed battery. Removing or replacing the battery
could affect your warranty coverage. If the battery is no longer holding a charge, contact support.

When a battery has reached the end of its useful life, do not dispose of the battery in general
household waste. Follow the local laws and regulations in your area for battery disposal.

Finding battery information

To monitor the status of your battery, or if the battery is no longer holding a charge, run Battery Check
in HP Support Assistant. To access battery information, from the Start screen, type support, select
the HP Support Assistant app, and then select Battery and performance.

HP Support Assistant provides the following tools and information about the battery:

Battery test

●

● Information on battery types, specifications, life cycles, and capacity

Conserving battery power

Tips for conserving battery power and maximizing battery life:

Lower the brightness on the display.

●

Select the Power saver setting in Power Options.

●

Turn off wireless when you are not using them.

●

Disconnect unused external devices that are not plugged into an external power source, such as

●

an external hard drive connected to a USB port.

Stop, disable, or remove any external media cards that you are not using.

●

Before you leave your work, initiate Sleep or shut down the computer.

●

Identifying low battery levels

When a battery that is the sole power source for the computer reaches a low or critical battery level,
the following behavior occurs:

The battery light (select models only) indicates a low or critical battery level.

●

– or –

The power meter icon on the Windows desktop shows a low or critical battery notification.

●

NOTE: For additional information about the power meter, see Using the power meter and

power settings on page 45.

The computer takes the following actions for a critical battery level:

If Hibernation is disabled and the computer is on or in the Sleep state, the computer remains

●

briefly in the Sleep state, and then shuts down and loses any unsaved information.

If Hibernation is enabled and the computer is on or in the Sleep state, the computer initiates

●

Hibernation.

46 Chapter 6 Managing power

Resolving a low battery level

Resolving a low battery level when external power is available

Connect an AC adapter.

●

Connect the keyboard dock to the tablet.

●

Connect an optional power adapter purchased as an accessory from HP.

●

Resolving a low battery level when no power source is available

● Initiate Hibernation (see Enabling and exiting Hibernation (select models only) on page 44).

● Save your work and shut down the computer.

Resolving a low battery level when the computer cannot exit Hibernation

When the computer lacks sufficient power to exit Hibernation, follow these steps:

1. Connect the AC adapter to the computer and to external power.

2. Exit Hibernation by pressing the power button.

Running on external AC power

For information on connecting to AC power, refer to the Setup Instructions poster provided in the
computer box.

The computer does not use battery power when the computer is connected to AC external power with
an approved AC adapter or an optional docking/expansion device.

WARNING! To reduce potential safety issues, use only the AC adapter provided with the computer,

a replacement AC adapter provided by HP, or a compatible AC adapter purchased from HP
specifically for this system.

CAUTION: To prevent damage to your system, do not use AC adapters from other tablets or

computers.

Connect the computer to external AC power under any of the following conditions:

WARNING! Do not charge the computer battery while you are onboard aircraft.

When charging or calibrating a battery

●

When installing or modifying system software

●

When writing information to a disc (select models only)

●

When performing a backup or recovery

●

When you connect the computer to external AC power:

The battery begins to charge.

●

The display brightness increases.

●

The power meter icon on the Windows desktop changes appearance.

●

Running on external AC power 47

When you disconnect external AC power, the following events occur:

● The computer switches to battery power.

The display brightness automatically decreases to save battery life.

●

The power meter icon on the Windows desktop changes appearance.

●

Troubleshooting power problems

Test the AC adapter if the computer exhibits any of the following symptoms when it is connected to
AC power:

The computer does not turn on.

●

The display does not turn on.

●

The power lights are off.

●

To test the AC adapter:

1. Shut down the computer.

2. Connect the AC adapter to the computer, and then plug it into an AC outlet.

3. Turn on the computer.

● If the power lights turn on, the AC adapter is working properly.

If the power lights remain off, check the connection from the AC adapter to the computer

●

and the connection from the AC adapter to the AC outlet to be sure that the connections
are secure.

If the connections are secure and the power lights remain off, the AC adapter is not

●

functioning and should be replaced.

Contact support for information about obtaining a replacement AC power adapter.

HP CoolSense (select models only)

HP CoolSense automatically detects when the computer is not in a stationary position and

adjusts performance and fan settings to keep the surface temperature of your computer at the
optimum level of comfort.

When HP CoolSense is off, the position of the computer is not detected and the performance and fan
options remain at the factory setting. As a result, the surface temperature of the computer may be
higher than it would be with HP CoolSense on.

To turn CoolSense off or on, follow these steps:

From the Start screen, type cool, select Settings, and then select HP CoolSense.

▲

Refreshing your software content with Intel Smart Connect Technology (select models only)

When the computer is in the Sleep state, Intel® Smart Connect Technology periodically causes the
computer to exit Sleep. Smart Connect then updates the content for certain open applications. As a

48 Chapter 6 Managing power

result, your work is immediately available to you as soon as you exit Sleep. You do not have to wait
while updates are downloaded.

To enable this feature or manually adjust the settings, from the Start screen, type smart, and

▲

then select Intel® Smart Connect Technology.

Shutting down (turning off) the computer

CAUTION: Unsaved information is lost when the computer shuts down. Be sure to save your work

before shutting down the computer.

The Shut down command closes all open programs, including the operating system, and then turns
off the display and computer.

Shut down the computer under any of the following conditions:

When you are connecting an external hardware device that does not connect to a USB or video

●

port

When the computer will be unused and disconnected from external power for an extended

●

period

To shut down the tablet when it is not connected to the keyboard dock:

Press the Windows key and the power button at the same time, and then tap Shut down.

▲

Although you can turn off the computer by holding down the power button, the recommended
procedure to shut down computer is to use the Windows Shut down command.

NOTE: If the computer is in the Sleep state or in Hibernation, you must first exit Sleep or

Hibernation before shutdown is possible by briefly pressing the power button.

1. Save your work and close all open programs.

2. Swipe from the right edge of the TouchPad or touch screen to display the charms, tap Settings,

tap the Power icon, and then tap Shut down.

– or –

From the Start screen, point to the upper-right or lower-right corner of the screen.

3. When the charms list opens, click Settings, click the Power icon, and then click Shut down.

If the computer is unresponsive and you are unable to use the preceding shutdown procedures, try
the following emergency procedures in the sequence provided:

To shut down the unresponsive tablet:

▲ Press both the Windows key and the power button at the same time.

To shut down the unresponsive tablet when it is connected to the keyboard dock:

Press ctrl+alt+delete, click the Power icon, and then select Shut down.

●

Press and hold the power button for at least 5 seconds.

●

● Disconnect the computer from external power.

Shutting down (turning off) the computer 49

7 Managing and sharing information

Drives are digital storage devices that help you store, manage, share, and access information. Your
computer has a solid state drive that stores your computer's software, operating system, and also
provides storage for all of your personal files.

For added capacity or functionality, connect an external drive (purchased separately), such as an
optical drive or hard drive, or insert a memory card directly from your phone or camera. A USB flash
drive, connected to the Universal Serial Bus (USB) port on your computer, also allows quick data
transfer. Some devices use the computer's power to run; others have their own power source. Some
devices come with software that must be installed.

NOTE: For information about connecting external wireless devices, see Connecting to a network

on page 22.

NOTE: For more information about required software and drivers, or to learn which computer port to

use, see the manufacturer's instructions.

Using a USB device

Most computers have more than one USB port, because this versatile interface allows you to connect
numerous kinds of external devices—such as a USB keyboard, mouse, external drive, printer,
scanner, or USB hub—to your computer.

NOTE: Some USB devices may not be supported when the computer is running on AC or battery

power if they do not have their own AC adapters. More than one USB device may not be supported
simultaneously when the computer is running on AC or battery power.

Type Description

USB 2.0 Transfers data at 60 MB/s.

USB 3.0 Transfers data at 640 MB/s. USB 3.0 ports, also known as

Connecting a USB device

CAUTION: To reduce the risk of damage to a USB connector, use minimal force to connect the

device.

SuperSpeed ports, are also compatible with USB 1.0 and 2.0
devices.

50 Chapter 7 Managing and sharing information

Connect the USB cable for the device to the USB port.

▲

NOTE: The USB port on your computer may look slightly different from the illustration in this

section.

A sound indicates that the device has been detected.

NOTE: The first time you connect a USB device, a message displays on the Windows desktop and

an icon appears in the notification area, letting you know that the device is recognized by the
computer.

Removing a USB device

CAUTION: To reduce the risk of damage to a USB connector, do not pull on the cable to remove

the USB device.

CAUTION: To reduce the risk of loss of information or an unresponsive system, use the following

procedure to safely remove the USB device.

1. Save your information and close all programs associated with the device.

2. From the Windows desktop, tap or click the hardware icon in the notification area, at the far right of

the taskbar. A message, Safely remove hardware and eject media is revealed. Follow the on­screen instructions.

Connecting a powered USB device

CAUTION: To reduce the risk of damage to the equipment when connecting a powered device, be

sure that the device is turned off and its AC power cord is unplugged.

1. Connect the device to the computer.

2. Plug the device power cord into a grounded AC outlet.

3. Turn on the device.

To disconnect an unpowered external device, stop the device, and then disconnect it from the
computer. To disconnect a powered external device, turn off the device, disconnect it from the
computer, and then unplug the AC power cord.

Using a USB device 51

Inserting and removing a memory card

To insert a memory card:

CAUTION: To reduce the risk of damage to the memory card connectors, use minimal force to

insert a memory card.

1. Hold the card label-side up, with the connectors facing the computer.

2. Insert the card into the memory card reader, and then press in on the card until it is firmly

seated.

A sound indicates that the device has been detected.

To remove a memory card:

CAUTION: To reduce the risk of loss of data or an unresponsive system, use the following

procedure to safely remove the memory card.

1. Save your information and close all programs associated with the memory card.

2. From the Windows desktop, tap or click the remove hardware icon in the notification area, at the

far right of the taskbar. Then, follow the on-screen instructions.

3. Press in on the card (1), and then remove it from the slot (2).

NOTE: If the card is not ejected, pull the card out of the slot.

52 Chapter 7 Managing and sharing information

8 Maintaining your computer

It is important to perform regular maintenance to keep your computer in optimal condition. This
chapter provides information about improving the performance of your computer by running tools
such as Disk Defragmenter and Disk Cleanup. It also provides information about updating your
programs and drivers, instructions for cleaning your computer, and tips for traveling with your
computer.

Improving performance

Everyone wants a fast computer and by performing regular maintenance tasks, using tools such as
Disk Defragmenter and Disk Cleanup, you can drastically improve the performance of your computer.
Also, as your computer gets older, you might consider installing larger drives and adding more
memory.

Using Disk Defragmenter

As you use your computer over time, the files on the hard drive become fragmented. A fragmented
drive means data on your drive is not contiguous (sequential) and, because of this, the hard drive
works harder to locate files, thus slowing down the computer. Disk Defragmenter consolidates (or
physically reorganizes) the fragmented files and folders on the hard drive so that the system can run
more efficiently.

NOTE: It is not necessary to run Disk Defragmenter on solid-state drives.

After you start Disk Defragmenter, it works without supervision. However, depending on the size of
your hard drive and the number of fragmented files, Disk Defragmenter may take more than an hour
to complete.

HP recommends defragmenting your hard drive at least once a month. You may set Disk
Defragmenter to run on a monthly schedule, but you can defragment your computer manually at any
time.

To run Disk Defragmenter:

1. Connect the computer to AC power.

2. From the Start screen, type d, and then type disk in the search box. Select Settings, and then

select Defragment and optimize your drives.

3. Follow the on-screen instructions.

For additional information, access the Disk Defragmenter software Help.

Using Disk Cleanup

Disk Cleanup searches the hard drive for unnecessary files that you can safely delete to free up disk
space and help the computer run more efficiently.

Improving performance 53

To run Disk Cleanup:

1. From the Start screen, type disk, select Settings, and then select Free up disk space by

deleting unnecessary files.

2. Follow the on-screen instructions.

Updating programs and drivers

HP recommends that you update your programs and drivers on a regular basis to the latest versions.
Updates can resolve issues and bring new features and options to your computer. Technology is
always changing, and updating programs and drivers allows your computer to run the latest
technology available. For example, older graphics components might not work well with the most
recent gaming software. Without the latest driver, you would not be getting the most out of your
equipment.

http://www.hp.com/support to download the latest versions of HP programs and drivers. In

Go to
addition, register to receive automatic update notifications when they become available.

Cleaning your computer

Cleaning products

Use the following products to safely clean your computer:

Dimethyl benzyl ammonium chloride 0.3 percent maximum concentration (For example:

●

disposable wipes. These wipes come in a variety of brand names.)

Alcohol-free glass cleaning fluid

●

Water with mild soap solution

●

Dry microfiber cleaning cloth or a chamois (static-free cloth without oil)

●

Static-free cloth wipes

●

CAUTION: Avoid strong cleaning solvents that can permanently damage your computer. If you are

not sure that a cleaning product is safe for your computer, check the product contents to make sure
that ingredients such as alcohol, acetone, ammonium chloride, methylene chloride, and hydrocarbons
are not included in the product.

Fibrous materials, such as paper towels, which can scratch the computer. Over time, dirt particles
and cleaning agents can get trapped in the scratches.

Cleaning procedures

Follow the procedures in this section to safely clean your computer.

WARNING! To prevent electric shock or damage to components, do not attempt to clean your

computer while it is turned on:

Turn off the computer.

Disconnect external power.

Disconnect all powered external devices.

CAUTION: To prevent damage to internal components, do not spray cleaning agents or liquids

directly on any computer surface. Liquids dripped on the surface can permanently damage internal
components.

54 Chapter 8 Maintaining your computer

Cleaning the display

Gently wipe the display using a soft, lint-free cloth moistened with an alcohol-free glass cleaner. Be
sure that the display is dry before closing the display.

Cleaning the sides and cover

To clean the sides and cover, use a soft microfiber cloth or chamois moistened with one of the
cleaning solutions listed previously or use an acceptable disposable wipe.

NOTE: When cleaning the cover of the computer, use a circular motion to aid in removing dirt and

debris.

Cleaning the TouchPad, keyboard, or mouse

WARNING! To reduce the risk of electric shock or damage to internal components, do not use a

vacuum cleaner attachment to clean the keyboard. A vacuum cleaner can deposit household debris
on the keyboard surface.

CAUTION: To prevent damage to internal components, do not allow liquids to drip between the

keys.

To clean the TouchPad, keyboard. or mouse, use a soft microfiber cloth or chamois moistened

●

with one of the cleaning solutions listed previously or use an acceptable disposable wipe.

To prevent keys from sticking and to remove dust, lint, and particles from the keyboard, use a

●

can of compressed air with a straw extension.

Traveling with or shipping your computer

If you have to travel with or ship your computer, here are some tips to keep in mind to keep your
equipment safe.

Prepare the computer for traveling or shipping:

●

Attach the tablet to the keyboard dock to protect the tablet screen.

◦

Back up your information to an external drive.

◦

Remove all discs and all external media cards, such as memory cards, from the computer.

◦

Turn off, and then disconnect all external devices.

◦

Shut down the computer.

◦

Take along a backup of your information. Keep the backup separate from the computer.

●

When traveling by air, carry the computer as hand luggage; do not check it in with the rest of

●

your luggage.

CAUTION: Avoid exposing a drive to magnetic fields. Security devices with magnetic fields

include airport walk-through devices and security wands. Airport conveyer belts and similar
security devices that check carry-on baggage use X-rays instead of magnetism and do not
damage drives.

If you plan to use the computer during a flight, listen for the in-flight announcement that tells you

●

when you are allowed to use your computer. In-flight computer use is at the discretion of the
airline.

If you are shipping the computer or a drive, use suitable protective packaging and label the

●

package “FRAGILE.”

Traveling with or shipping your computer 55

If the computer has a wireless device installed, the use of these devices may be restricted in

●

some environments. Such restrictions may apply onboard aircraft, in hospitals, near explosives,
and in hazardous locations. If you are uncertain of the policy that applies to the use of a
particular device, ask for authorization to use your computer before you turn it on.

● If you are traveling internationally, follow these suggestions:

Check the computer-related customs regulations for each country or region on your

◦

itinerary.

Check the power cord and adapter requirements for each location in which you plan to use

◦

the computer. Voltage, frequency, and plug configurations vary.

WARNING! To reduce the risk of electric shock, fire, or damage to the equipment, do not

attempt to power the computer with a voltage converter kit sold for appliances.

56 Chapter 8 Maintaining your computer

9 Securing your computer and

information

Tablet security is essential for protecting the confidentiality, integrity, and availability of your
information. Standard security solutions provided by the Windows operating system, HP applications,
the non-Windows Setup Utility (BIOS), and other third-party software can help protect your computer
from a variety of risks, such as viruses, worms, and other types of malicious code.

IMPORTANT: Some security features listed in this chapter may not be available on your computer.

Tablet risk Security feature

Unauthorized use of the computer Power-on password

Computer viruses Antivirus software

Unauthorized access to data Firewall software

Unauthorized access to Setup Utility (BIOS) settings and
other system identification information

Ongoing or future threats to the computer Software updates

Unauthorized access to a Windows user account User password

Using passwords

A password is a group of characters that you choose to secure your computer information and to
protect online transactions. Several types of passwords can be set. For example, when you set up
your computer for the first time, you were asked to create a user password to secure your computer.
Additional passwords can be set in Windows or in the HP Setup Utility (BIOS) that is preinstalled on
your computer.

You may find it helpful to use the same password for a Setup Utility (BIOS) feature and for a Windows
security feature.

Use the following tips for creating and saving passwords:

To reduce the risk of being locked out of the computer, record each password and store it in a

●

secure place away from the computer. Do not store passwords in a file on the computer.

When creating passwords, follow requirements set by the program.

●

Change your passwords at least every three months.

●

Administrator password

An ideal password is long and has letters, punctuation, symbols, and numbers.

●

● Before you send your computer for service, back up your files, delete confidential files, and then

remove all password settings.

For additional information about Windows passwords, such as screen-saver passwords, from the
Start screen, type support, and then select the HP Support Assistant app.

Using passwords 57

Setting Windows passwords

Password Function

User password Protects access to a Windows user account. You may also

Administrator password Protects administrator-level access to computer contents.

Setting Setup Utility (BIOS) passwords

Password Function

Administrator password

set up your computer to require the user password to exit
Sleep. See

on page 45 for more information.

NOTE: This password cannot be used to access Setup

Utility (BIOS) contents.

●

●

NOTE: The administrator password can be used in place of

the power-on password.

NOTE: Your administrator password is not interchangeable

with an administrator password set in Windows, nor is it
displayed as it is set, entered, changed, or deleted.

NOTE: If you enter the power-on password at the first

password check before the “Press the ESC key for Startup
Menu” message is displayed, you must enter the
administrator password to access Setup Utility (BIOS).

Setting password protection on wakeup

Must be entered each time you access Setup Utility
(BIOS).

If you forget your administrator password, you cannot
access Setup Utility (BIOS).

Power-on password ● Must be entered each time you turn on or restart the

To set, change, or delete an administrator or power-on password in Setup Utility (BIOS):

1. To start Setup Utility (BIOS), turn on or restart the computer, quickly press esc, and then press
f10.

2. Use the arrow keys to select Security, and then follow the on-screen instructions.

Your changes take effect when the computer restarts.

Using Internet security software

When you use your computer to access email, a network, or the Internet, you potentially expose your
computer to computer viruses, spyware, and other online threats. An antivirus program may be

computer.

If you forget your power-on password, you cannot turn

●

on or restart the computer.

NOTE: The administrator password can be used in place of

the power-on password.

NOTE: A power-on password is not displayed as it is set,

entered, changed, or deleted.

58 Chapter 9 Securing your computer and information

preinstalled on your computer. It is strongly recommended that you use an antivirus program of your
choice in order to fully protect your computer.

Using antivirus software

Computer viruses can disable programs, utilities, or the operating system, or cause them to function
abnormally. Antivirus software can detect most viruses, destroy them, and in most cases, repair any
damage they have caused.

To provide ongoing protection against newly discovered viruses, antivirus software must be kept up to
date.

An antivirus program may be preinstalled on your computer. It is strongly recommended that you use
the antivirus program of your choice in order to fully protect your computer.

For more information about computer viruses, from the Start screen, type support, and then select
the HP Support Assistant app.

Using firewall software

Firewalls are designed to prevent unauthorized access to a system or network. A firewall can be
software you install on your computer and/or network, or it can be a combination of both hardware
and software.

There are two types of firewalls to consider:

Host-based firewalls—Software that protects only the computer it is installed on.

●

● Network-based firewalls—Installed between your DSL or cable modem and your home network

to protect all the computers on the network.

When a firewall is installed on a system, all data sent to and from the system is monitored and
compared with a set of user-defined security criteria. Any data that does not meet those criteria is
blocked.

Installing software updates

HP, Microsoft Windows, and third-party software installed on your computer should be regularly
updated to correct security problems and improve software performance. For more information, see

Updating programs and drivers on page 54.

Installing critical security updates

CAUTION: Microsoft sends out alerts regarding critical updates. To protect the computer from

security breaches and computer viruses, insall all critical updates from Microsoft as soon as you
receive an alert.

You can choose whether updates are installed automatically. To change the settings, from the Start
screen, type c, and then select Control Panel. Select System and security, select Windows

Update, select Change settings, and then follow the on-screen instructions.

Installing Windows updates

Updates to the operating system and other software may have become available after the computer
left the factory. Microsoft sends out alerts regarding critical updates. To protect the computer from
security breaches and viruses, install all critical updates from Microsoft as soon as you receive an
alert.

Installing software updates 59

To be sure that all available updates are installed on the computer, observe these guidelines:

● Run Windows Update as soon as possible after you set up your computer. From the Start

screen, type w, select Settings, and then select Windows Update.

Run Windows Update monthly thereafter.

●

Obtain updates to Windows and other Microsoft programs, as they are released, from the

●

Microsoft website and through the updates link in Help and Support.

Installing HP and third-party software updates

HP recommends that you regularly update the software and drivers that were originally installed on
your computer. To download the latest versions, go to
you can also register to receive automatic update notifications when they become available.

If you have installed third-party software after you purchased your computer, regularly update the
software. Software companies provide software updates to their products to correct security problems
and improve functionality of the software.

http://www.hp.com/support. At this location,

Securing your wireless network

When you set up your wireless network, always enable security features. For more information, see

Protecting your WLAN on page 25.

Backing up your software applications and information

Regularly back up your software applications and information to protect them from being permanently
lost or damaged through a virus attack or a software or hardware failure. For more information, see

Backing up, restoring, and recovering on page 64.

60 Chapter 9 Securing your computer and information

10 Using Setup Utility (BIOS), MultiBoot,

and HP PC Hardware Diagnostics
(UEFI)

Setup Utility, or Basic Input/Output System (BIOS), controls communication between all the input and
output devices on the system (such as disk drives, display, keyboard, mouse, and printer). Setup
Utility (BIOS) includes settings for the types of devices installed, the startup sequence of the
computer, and the amount of system and extended memory.

Starting Setup Utility (BIOS)

To start Setup Utility (BIOS), turn on or restart the computer, quickly press esc, and then press f10.

Information about how to navigate in Setup Utility (BIOS) is located at the bottom of the screen.

NOTE: Use extreme care when making changes in Setup Utility (BIOS). Errors can prevent the

computer from operating properly.

Updating the BIOS

Updated versions of the BIOS may be available on the HP website.

Most BIOS updates on the HP website are packaged in compressed files called SoftPaqs.

Some download packages contain a file named Readme.txt, which contains information regarding
installing and troubleshooting the file.

Determining the BIOS version

To determine whether available BIOS updates contain later BIOS versions than those currently
installed on the computer, you need to know the version of the system BIOS currently installed.

BIOS version information (also known as ROM date and System BIOS) can be displayed by pressing

fn+esc (if you are already in Windows) or by using Setup Utility (BIOS).

1. Start Setup Utility (BIOS) see

2. Use the arrow keys to select Main.

3. To exit Setup Utility (BIOS) without saving your changes, use the arrow keys to select Exit,

select Exit Discarding Changes, and then press enter.

4. Click Yes.

Starting Setup Utility (BIOS) on page 61.

Starting Setup Utility (BIOS) 61

Downloading a BIOS update

CAUTION: To reduce the risk of damage to the computer or an unsuccessful installation, download

and install a BIOS update only when the computer is connected to reliable external power using the
AC adapter. Do not download or install a BIOS update while the computer is running on battery power
or connected to an optional power source. During the download and installation, follow these
instructions:

Do not disconnect power from the computer by unplugging the power cord from the AC outlet.

Do not shut down the computer or initiate Sleep.

Do not insert, remove, connect, or disconnect any device, cable, or cord.

1. From the Start screen, type support, and then select the HP Support Assistant app.

2. Click Updates and tune-ups, and then click Check for HP updates now.

3. Follow the on-screen instructions.

4. At the download area, follow these steps:

a. Identify the most recent BIOS update and compare it to the BIOS version currently installed

on your computer. If the update is more recent than your BIOS, make a note of the date,
name, or other identifier. You may need this information to locate the update later, after it
has been downloaded to your hard drive.

b. Follow the on-screen instructions to download your selection to the hard drive.

If the update is more recent than your BIOS, make a note of the path to the location on your
hard drive where the BIOS update is downloaded. You will need to access this path when
you are ready to install the update.

NOTE: If you connect your computer to a network, consult the network administrator before

installing any software updates, especially system BIOS updates.

BIOS installation procedures vary. Follow any instructions that are displayed on the screen after the
download is complete. If no instructions are displayed, follow these steps:

1. From the Start screen, type e, and then select File Explorer.

2. Click your hard drive designation. The hard drive designation is typically Local Disk (C:).

3. Using the hard drive path you recorded earlier, open the folder on your hard drive that contains

the update.

4. Double-click the file that has an .exe extension (for example, filename.exe).

The BIOS installation begins.

5. Complete the installation by following the on-screen instructions.

NOTE: After a message on the screen reports a successful installation, you can delete the

downloaded file from your hard drive.

Using HP PC Hardware Diagnostics (UEFI)

HP PC Hardware Diagnostics is a Unified Extensible Firmware Interface (UEFI) that allows you to run
diagnostic tests to determine whether the computer hardware is functioning properly. The tool runs
outside the operating system so that it can isolate hardware failures from issues that are caused by
the operating system or other software components.

62 Chapter 10 Using Setup Utility (BIOS), MultiBoot, and HP PC Hardware Diagnostics (UEFI)

To start HP PC Hardware Diagnostics UEFI:

1. Turn on or restart the computer, quickly press esc, and then press f2.

The BIOS searches three places for the HP PC Hardware Diagnostics (UEFI) tools in the
following order:

a. Connected USB drive

NOTE: To download the HP PC Hardware Diagnostics (UEFI) tool to a USB drive, see

Downloading HP PC Hardware Diagnostics (UEFI) to a USB device on page 63.

b. Hard drive

c. BIOS

2. When the diagnostic tool opens, click the type of diagnostic test you want to run, and then follow

the on-screen instructions.

NOTE: If you need to stop a diagnostic test, press esc.

Downloading HP PC Hardware Diagnostics (UEFI) to a USB device

NOTE: The HP PC Hardware Diagnostics (UEFI) download instructions are provided in English

only.

1. Go to http://www.hp.com.

2. Click Support & Drivers, and then click the Drivers & Software tab.

3. Enter the product name in the text box, and then click Search.

4. Select your computer model, and then select your operating system.

5. In the Diagnostic section, click HP UEFI Support Environment.

– or –

Click Download, and then select Run.

Using HP PC Hardware Diagnostics (UEFI) 63

11 Backing up, restoring, and recovering

Your computer includes tools provided by HP and Windows to help you safeguard your information
and retrieve it if you ever need to. These tools will help you return your computer to a proper working
state or even back to the original factory state, all with simple steps.

This chapter provides information about the following processes:

Creating recovery media and backups

●

Restoring and recovering your system

●

NOTE: This chapter describes an overview of backing up, restoring and recovering options. For

more details about the tools provided, see the HP Support Assistant. To access the HP Support
Assistant, from the Start screen, select the HP Support Assistant app. Use the search field to
access information about backup, restore, refresh, and other recovery topics, and then follow the
information provided.

Creating recovery media and backups

Recovery after a system failure is only as good as your most recent backup.

▲ Use the Windows tools to create system restore points and create backups of personal

information. For more information and steps, see HP Support Assistant. To access HP Support
Assistant, from the Start screen, select the HP Support Assistant app. Use the search field to
access information about restore.

Restore and recovery

There are several options for recovering your system. Choose the method that best matches your
situation and level of expertise:

Windows offers several options for restoring from backup, refreshing the computer, and resetting

●

the computer to its original state. For more information and steps, see Help and Support. From
the Start screen, type h, and then select Help and Support.

If you need to correct a problem with a preinstalled application or driver, use the Drivers and

●

Applications Reinstall option of HP Recovery Manager to reinstall the individual application or
driver.

From the Start screen, type recovery, select HP Recovery Manager, select Drivers and
Applications Reinstall, and then follow the on-screen instructions.

If you want to restore the system to a previous state without losing any personal information,

●

Windows System Restore is an option. System Restore allows you to restore without the
requirements of Windows Refresh or a reinstallation. Windows creates system restore points
automatically during a Windows update and other system maintenance events. Even if you did
not manually create a restore point, you can choose to restore to an automatically created

64 Chapter 11 Backing up, restoring, and recovering

restore point. For more information and steps for using Windows System Restore, see Help and
Support. From the Start screen, type h, and then select Help and Support.

● If you have replaced the hard drive, you can use the Factory Reset option of HP Recovery

media to restore the factory image to the replacement drive. For more information, see

Recovering using HP Recovery Manager on page 65.

Recovering using HP Recovery Manager

HP Recovery Manager software allows you to recover the computer to its original factory state by
using the HP Recovery media you created. You can choose from one of the following recovery
options:

System Recovery—Reinstalls the original operating system, and then configures the settings for

●

the programs that were installed at the factory.

Minimized Image Recovery—Reinstalls the operating system and all hardware-related drivers

●

and software, but not other software applications.

● Factory Reset—Restores the computer to its original factory state by deleting all information

from the hard drive and re-creating the partitions. Then it reinstalls the operating system and the
software that was installed at the factory.

What you need to know

HP Recovery media must be used if the computer hard drive fails. If you have not already

●

created recovery media, see .

Creating recovery media and backups on page 64

To use the Factory Reset option, you must use HP Recovery media. If you have not already

●

created recovery media, see

If the HP Recovery media does not work, you can obtain recovery media for your system from

●

support. See the Worldwide Telephone Numbers booklet included with the computer. You can
also find contact information from the HP website. Go to
country or region, and follow the on-screen instructions.

IMPORTANT: HP Recovery Manager does not automatically provide backups of your personal

data. Before beginning recovery, back up any personal data you wish to retain.

Creating recovery media and backups on page 64.

Using HP Recovery media to recover

You can use HP Recovery media to recover the original system. This method can be used if your
system does not have an HP Recovery partition or if the hard drive is not working properly.

1. If possible, back up all personal files.

2. Insert the first HP Recovery media that you created, and then restart the computer.

– or –

Insert the HP Recovery USB flash drive you created into a USB port on your computer, and then
restart the computer.

NOTE: If the computer does not automatically restart in HP Recovery Manager, change the

computer boot order. See

Changing the computer boot order on page 66.

http://www.hp.com/support, select your

3. Follow the on-screen instructions.

Restore and recovery 65

Changing the computer boot order

If computer does not restart in HP Recovery Manager, you can change the computer boot order,
which is the order of devices listed in BIOS where the computer looks for startup information. You can
change the selection for an optical drive or a USB flash drive.

To change the boot order:

1. Insert the HP Recovery media you created.

2. Restart the computer.

3. Press and hold esc while the computer is restarting, and then press f9 for boot options.

4. Select the optical drive or USB flash drive you want to boot from.

5. Follow the on-screen instructions.

66 Chapter 11 Backing up, restoring, and recovering

12 Specifications

Input power

The power information in this section may be helpful if you plan to travel internationally with the
computer.

The computer operates on DC power, which can be supplied by an AC or a DC power source. The
AC power source must be rated at 100–240 V, 50–60 Hz. Although the computer can be powered
from a standalone DC power source, it should be powered only with an AC adapter or a DC power
source supplied and approved by HP for use with this computer.

The computer can operate on DC power within the following specifications. Operating voltage and
current varies by platform.

Input power Rating

Operating voltage and current 19.5 V dc @ 2.31 A - 45 W

DC plug of external HP power supply

19.5 V dc @ 3.33 A - 65 W

NOTE: This product is designed for IT power systems in Norway with phase-to-phase voltage not

exceeding 240 V rms.

NOTE: The computer operating voltage and current can be found on the system regulatory label.

Operating environment

Factor Metric U.S.

Temperature

Operating 5°C to 35°C 41°F to 95°F

Nonoperating -20°C to 60°C -4°F to 140°F

Relative humidity (noncondensing)

Operating 10% to 90% 10% to 90%

Nonoperating 5% to 95% 5% to 95%

Maximum altitude (unpressurized)

Operating -15 m to 3,048 m -50 ft to 10,000 ft

Nonoperating -15 m to 12,192 m -50 ft to 40,000 ft

Input power 67

13 Electrostatic Discharge

Electrostatic discharge is the release of static electricity when two objects come into contact—for
example, the shock you receive when you walk across the carpet and touch a metal door knob.

A discharge of static electricity from fingers or other electrostatic conductors may damage electronic
components. To prevent damage to the computer, damage to a drive, or loss of information, observe
these precautions:

If removal or installation instructions direct you to unplug the computer, first make sure that it is

●

properly grounded, and then remove the cover.

Keep components in their electrostatic-safe containers until you are ready to install them.

●

Avoid touching pins, leads, and circuitry. Handle electronic components as little as possible.

●

Use nonmagnetic tools.

●

● Before handling components, discharge static electricity by touching an unpainted metal surface

of the component.

If you remove a component, place it in an electrostatic-safe container.

●

If you need more information about static electricity or assistance with component removal or
installation, contact support.

68 Chapter 13 Electrostatic Discharge

Index

A

AC adapter light 5, 13
AC adapter, testing 48
action keys

decrease screen brightness

41
Help and Support 41
identifying 12
increase screen brightness 41
next track or section 41
play, pause, resume 41
previous track or section 41
switch screen image 41
volume down 41
volume mute 41
volume up 41

alignment post connectors,

identifying 5
alignment posts, identifying 9
ambient light sensor, identifying

7, 29
antivirus software, using 59
audio features, testing 31
audio-out (headphone) jacks 6,

14, 28, 30
autorotate lock

adjusting 16

B

backing up software and

information 60
backups 64
battery

discharging 46

low battery levels 46
battery information, finding 46
battery light 5, 13
battery power 45
BIOS

determining version 61

downloading an update 62

updating 61
Bluetooth device 22, 26

boot order

changing HP Recovery

Manager 66

bottom-edge swipe

Touch screen 20

brightness

adjusting 16

buttons

left TouchPad 10
power 5
right TouchPad 10
volume 6, 28
Windows 8

C

cables

USB 51
caps lock light, identifying 11
caring for your computer 54
cleaning your computer 54
components

display 7

left-side 14

right-side 13

top 9
configuring audio for HDMI 33
connecting to a WLAN 26
connector

alignment post 5

power 5, 13
corporate WLAN connection 26
critical battery level 46
critical security updates,

installing 59

D

deleted files, restoring 64
Disk Cleanup software 53
Disk Defragmenter software 53
docking connector, identifying 9
docking port, identifying 5

E

edge swipe gestures 19

bottom-edge swipe 20

left-edge swipe 20, 40
right-edge swipe 19, 39

top-edge swipe 20, 39
electrostatic discharge 68
esc key, identifying 12
external AC power, using 47
external devices 51

F

firewall software 59
flicking TouchPad gesture 38
fn key, identifying 12, 42
fun things to do 2

H

HDMI

configuring audio 33
HDMI port

connecting 32

identifying 13, 29
headphones and microphones,

connecting 31

Hibernation

exiting 44

initiated during critical battery

level 46

initiating 44
high-definition devices,

connecting 32

hot keys

description 42

display system information 42

using 42
HP and third-party software

updates, installing 60

HP PC Hardware Diagnostics

(UEFI)

using 62
HP Quick Start 1
HP Recovery Manager 65

correcting boot problems 66
HP Recovery media

recovery 65
hubs 50

I

input power 67
installing

critical security updates 59
critical updates 59

integrated webcam, identifying 7,

29

internal microphones, identifying

7, 29
Internet connection setup 25
Internet security software, using

58

J

jacks

audio-out (headphone) 6, 14,

28, 30

K

keyboard dock

identifying 9

releasing the tablet 15
keyboard hot keys, identifying 42
keys

action 12

esc 12

fn 12

Windows 12

L

labels

serial number 15
left-edge swipe

Touch screen 20

TouchPad 40
lights

AC adapter 5, 13

battery 5, 13

caps lock 11

mute 11

wireless 11
low battery level 46

M

maintenance

Disk Cleanup 53

Disk Defragmenter 53
memory card

inserting 52
memory card reader, identifying

14

micro memory card reader,

identifying 6

minimized image

creating 65

mouse, external

setting preferences 35

mute light, identifying 11

O

operating environment 67
optional external devices, using

51

original system recovery 65

P

passwords

Setup Utility (BIOS) 58
Windows 58

pinching

Touch screen 18
TouchPad 37

ports

HDMI 13, 29, 32
USB 13, 14, 29, 30

power

battery 45
power button, identifying 5
power connector, identifying 5,

13

product name and number,

computer 15

public WLAN connection 26

R

recovery

discs 65

HP Recovery Manager 65

media 65

system 65

USB flash drive 65
regulatory information 15
release latch, identifying 9
restore, Windows File History 64
right-edge swipe

Touch screen 19

TouchPad 39
rotating

Touch screen 19

TouchPad 37

S

scrolling

TouchPad 36
security, wireless 25
serial number 15
serial number, computer 15
setting password protection on

wakeup 45

settings

autorotate lock 16

brightness 16

changing 16

landscape view 16

portrait view 16

tablet orientation 16
setup of WLAN 25
Setup Utility (BIOS) passwords

58
shipping the computer 55
shutdown 49
Sleep

exiting 44
initiating 44

slots

memory card reader 14

software

Disk Cleanup 53

Disk Defragmenter 53
software updates, installing 59
speakers

connecting 31

identifying 7, 29
stretching

Touch screen 18
system information

hot key 42

locating 15
system recovery 65
system restore point

creating 64

restoring 65

T

tapping

Touch screen 18

TouchPad 36
testing an AC adapter 48
testing audio features 31

top-edge swipe

Touch screen 20
TouchPad 39

Touch screen gestures 19

edge swipe gestures 19, 20
one-finger slide 17
pinching 18
rotating 19
stretching 18
tapping 18
using 17

TouchPad

buttons 10
identifying 10

TouchPad gestures

edge swipe gestures 38, 39,

40
flicking 38
pinching 37
rotating 37
scrolling 36
tapping 36
using 35
zooming 37

TouchPad zone, identifying 10
traveling with the computer 55
turning off the computer 49

U

unresponsive system 49
USB cable, connecting 51
USB devices

connecting 50
description 50
removing 51

USB hubs 50
USB ports, identifying 13, 14, 29,

30
using external AC power 47
using passwords 57

webcam

using 30
webcam light, identifying 7, 29
Windows

File History 64

restoring files 64

system restore point 64, 65
Windows button, identifying 8
Windows key, identifying 12
Windows passwords 58
Windows updates, installing 59
wireless certification information

15

wireless controls

operating system 22
wireless light 11
wireless network (WLAN)

connecting 26

corporate WLAN connection

26
equipment needed 25
functional range 26
public WLAN connection 26
securing 60
security 25
using 23

WLAN antenna, identifying 7
WLAN device 23

Z

zooming

TouchPad 37

V

vent, identifying 6
video 32
volume button, identifying 6, 28

W

warranty period 15
Webcam

using 30
