QuickSpecs
HP ProLiant ML110 Generation 5
Overview
Front View: |
Rear View: |
||
1. |
DVD-ROM Drive |
1. |
System fan |
2. |
Power LED |
2. |
PCI slot cover retainer |
3. |
Drive Activity LED |
3. |
PCI slot covers |
4. |
Front Bezel |
4. |
HP LO 100c Management Port (Optional) |
5. |
SAS cable (SAS model only) |
5. |
LAN Port (RJ-45) |
6. |
HDD controller card (Optional) |
6. |
Rear USB 2.0 Ports |
7. |
System Board |
7. |
Serial Ports |
8.HP LO 100c Management Card (Optional HP PL100 G5 8. VGA Port
|
Lights-Out 100c Kit ALL ) |
9. |
PS/2 Keyboard Port |
9. |
System Fan |
10. |
PS/2 Mouse Port |
10. |
365W Power Supply |
11. |
Power Supply Outlet |
|
|
12. |
Power supply unit (PSU) fan |
|
|
|
|
What's New
Support for Dual-Core Intel® Xeon® E3110 and Dual-Core Intel® Core 2 E4600 processors
Standard ProLiant Easy Set Up CD - simplifies deployment and installation process and has a SmartStart "like" look and feel for a consistent user experience across ProLiant servers
DA - 12867 Worldwide QuickSpecs — Version 10 — 4.18.2008 |
Page 1 |
QuickSpecs
HP ProLiant ML110 Generation 5
Overview
At A Glance
The HP ProLiant ML110 G5 server provides all the necessary server features in an affordable, functional package. The latest Intel processors, such as Intel Xeon and Pentium D processors, provide the necessary computing power, while a mix
of PCI and PCI-Express slots delivers the expandability for the future that small businesses require. Also, the ML110 G5 can be upgraded with the cost-effective HP Lights-Out 100c Remote Management Card (RMC) for remote sites or second offices. Like all HP ProLiant products, the ML110 G5 comes with ProLiant reliability. The ProLiant ML110 G5 is a valuepacked server with appropriate technology suitable for small to medium businesses.
Processor:
Quad-Core Intel® Xeon® processors 3200 sequence
Dual-Core Intel® Xeon® processors 3100 sequence
Dual-Core Intel® Xeon® processors 3000 sequence
Dual-Core Intel® Core 2 processors 4000 sequence
Dual-Core Intel® Pentium® processors 2000 sequence
Single-Core Intel® Celeron® processors 400 Sequence
Memory:
512 MB Standard (1GB on SAS Models) / 8 GB Maximum of PC6400 DDR2, Unbuffered ECC
Storage Controller:
SATA Models: Integrated 6 ports SATA controller with embedded RAID (4 ports available for Hard Disks)
SAS Models: HP SC40Ge Host Bus Adapter with RAID 0, 1, support
Internal Drive Support:
4 HDD Support:
2.0TB SATA max storage (4 x 500 GB CTO HDD) 1.2TB SAS max storage (4 x 300GB CTO HDD)
Network Controller:
Embedded NC105i PCI Express Gigabit Ethernet Server Adapter
Expansion Slots:
Slot 1: PCI 32-bit/33MHz at 3.3V
Slot 2: PCI-Express x8 connector with x1 link
Slot 3: PCI-Express x8 connector with x1 link
Slot 4: PCI-Express X8 connector with x8 link
USB Ports:
8 Total USB ports
2 Front
4 Rear
2 Internal (one for tape, one for standard USB device)
Management:
Standard Lights Out 100 IPMI 2.0 reporting
Optional HP ProLiant G5 Lights Out 100c Remote Management Card
Standard HP ProLiant ML110 G5 Easy Set-up CD
Form Factor:
Micro ATX tower (4U)
Warranty:
Protected by HP Services and a worldwide network of HP Authorized Channel Partners. Hardware diagnostic support and repair is available for one year from date of purchase. Support for software and initial setup is available for 90 days from date of purchase. Additional support may be covered under the warranty or available for an additional fee. Enhancements to warranty services are available through HP Care Pack services or customized service agreements SATA hard drives have a one year warranty.
DA - 12867 Worldwide QuickSpecs — Version 10 — 4.18.2008 |
Page 2 |
QuickSpecs
HP ProLiant ML110 Generation 5
Standard Features
NOTE: For a brief, printer friendly data sheet that describes this product and informs you of the essential capabilities and specifications, please visit: http://h71028.www7.hp.com/ERC/downloads/4AA1-5498ENW.pdf
Processor |
Quad-Core Intel® Xeon® Processor X3220 (2.40 GHz, 95W,1066 FSB,8M)* |
One of the following |
Quad-Core Intel® Xeon ® Processor X3210 (2.13 GHz, 95W,1066 FSB,8M)* |
depending on Model |
Dual-Core Intel® Xeon® Processor E3110 (3.00 GHz, 1333 FSB, 6M)* |
|
|
|
Dual-Core Intel® Xeon® Processor X3075 (2.66 GHz, 65W,1333 FSB, 4M)* |
|
Dual-Core Intel® Xeon® Processor X3065 (2.33 GHz, 65W,1333 FSB, 4M) |
|
Dual-Core Intel® Core 2 Processor E4600 (2.40 GHz, 800 FSB, 2M)* |
|
Dual-Core Intel® Pentium® Processor E2160 (1.80 GHz, 800FSB, 1M) |
|
Single-Core Intel® Celeron® Processor 440 (2.0 GHz, 800 FSB, 512K)* |
|
Single-Core Intel® Celeron® Processor 420 (1.6 GHz, 800 FSB, 512K)* |
|
* Available through Configure To Order only. See Factory Integration Models section for more |
|
details. |
|
|
Cache Memory
One of the following depending on Model
8 MB Level 2 cache (Intel® Xeon® 3200 sequence)
6 MB Level 2 cache (Intel® Xeon® 3320 sequence)
6 MB Level 2 cache (Intel® Xeon® 3110 sequence)
4 MB Level 2 cache (Intel® Xeon® 3000 sequence) 2 MB Level 2 cache (Intel® Core 2 4000 sequence)
1 MB Level 2 cache (Intel® Pentium® 2100 sequence) 512KB Level 2 cache (Intel® Celeron® D)
Chipset |
Intel® 3200 |
|
|
|
|
Memory Protection |
ECC |
|
|
|
|
Memory |
Type |
PC2-6400 unbuffered DDR2 ECC 800MHz |
|
Standard |
512 MB |
|
|
1GB (SAS Models) |
|
Maximum |
8 GB |
|
|
|
Network Controller |
Embedded NC105i PCI Express Gigabit Ethernet Server Adapter |
|
|
|
|
DA - 12867 Worldwide QuickSpecs — Version 10 — 4.18.2008 |
Page 3 |
QuickSpecs
HP ProLiant ML110 Generation 5
Standard Features
Expansion Slots # |
Technology |
Bus |
Connector |
Bus |
Device |
Form Factor |
Notes |
|
|
Width*** |
Width |
Number* |
Number** |
|
|
1 |
PCI (33MHZ |
32-bit |
N/A |
0 |
30 |
Full height |
|
|
/3.3Volt) |
|
|
|
|
slot |
|
2 |
PCIe |
X1 |
X8 |
0 |
28 |
Full height |
|
|
|
|
|
|
|
slot |
|
3 |
PCIe |
X1 |
X8 |
2 |
28 |
Full length, |
|
|
|
|
|
|
|
full height |
|
|
|
|
|
|
|
slot |
|
4 |
PCIe |
X8 |
X8 |
0 |
1 |
Full length, |
|
|
|
|
|
|
|
full height |
|
|
|
|
|
|
|
slot |
|
*Default bus assignment (in decimal). Inserting cards with PCI bridges may alter the actual bus assignment number.
**Slots are enumerated differently based on OS. MS OS's enumerate from lowest to highest Device ID by bus (starting with the lowest bus).
***Indicates the number of physical electrical lanes running to a PCI-e connector.
NOTE: PCI-X Interface (PCI 32bit/33MHz compatible)
Storage Controller |
SATA Models |
Integrated 6 ports SATA controller with embedded RAID (4 ports |
|
One of the following |
|
available for Hard Disks) |
|
depending on Model |
SAS Models |
HP SC40Ge Host Bus Adapter with RAID 0, 1 support |
|
|
|
|
|
Storage |
Optical Drive |
SATA DVD-ROM Drive |
|
|
Hard Drives |
SATA |
160GB SATA 7200 rpm Drive |
|
|
SAS |
72GB SAS 15,000 rpm Drive |
|
|
|
|
Maximum Internal |
Type |
|
|
Storage |
SAS |
1.2TB |
(4 x 300 GB) |
|
(Not-hot plug) |
|
|
|
SATA |
2TB |
(4 x 500 GB*) |
|
(Non-hot plug) |
|
|
|
*Offered through Configure-To-Order only. See Factory Integrated Models section for more details |
||
|
|
|
|
DA - 12867 Worldwide QuickSpecs — Version 10 — 4.18.2008 |
Page 4 |
QuickSpecs
HP ProLiant ML110 Generation 5
Standard Features |
|
|
|
|
|
Interfaces |
Parallel |
0 |
|
|
|
Serial |
1 |
|
|
|
Pointing Device (Mouse, |
1 |
|
|
|
PS2) |
|
|
|
|
Graphics |
1 |
|
|
|
Keyboard (PS2) |
1 |
|
|
|
USB 2.0 Ports |
8 total (4 rear, 2 front panel, 2 internal (one for USB Tape connectivity)) |
|
|
|
|
NOTE: Internal USB ports are optimal for the attachment of HP USB |
|
|
|
|
DAT Tape Drives |
|
|
|
|
NOTE: Please see the following URL for additional information |
|
|
|
|
regarding USB support: |
|
|
|
|
http://h18004.www1.hp.com/products/servers/platforms/usb- |
|
|
|
|
support.html |
|
|
|
Network RJ-45 |
1 |
|
|
|
(Ethernet) |
|
|
|
|
Management |
HP ProLiant G5 Lights-Out 100c Remote Management port (Optional) |
|
|
|
|
|
|
|
Graphics |
32MB shared supporting 1600 x 1200 x 16M resolution |
||
|
|
|
|
|
|
Form Factor |
Micro ATX Tower (4U) |
|
|
|
|
|
|
|
|
Remote Management |
Lights-Out 100c |
Lights Out LO100c is a Remote Management Card (RMC) for ProLiant |
|
|
|
|
100 series servers that do not have embedded LO100i. The LO100c |
|
|
|
|
has all the features of the LO100i Advanced license and allows |
|
|
|
|
customers, or their service providers, to remotely manage ProLiant |
|
|
|
|
servers over a LAN or the Internet from anywhere, anytime regardless |
|
|
|
|
whether the server is located in the same building, across town, or |
|
|
|
|
around the globe. |
|
|
|
|
With LO100c, users can acquire complete remote control with Virtual |
|
|
|
|
KVM (graphical hardware-based, remote console). Users can also |
|
|
|
|
access the server's serial console, control system power, update system |
|
|
|
|
firmware and software, as well as monitor system environmental |
|
|
|
|
conditions. The LO100c remote management card can be accessed |
|
|
|
|
from a web browser or command line interface. This virtual "at-the- |
|
|
|
|
server" functionality means administrators stay in control of remote HP |
|
|
|
|
ProLiant 100 series servers. |
|
|
|
|
The HP Lights-Out100c consists of a management processor and |
|
|
|
|
firmware that provides cost-effective, entry-level lights-out functionality, |
|
|
|
|
basic system board management functions, and diagnostics. |
|
|
|
|
NOTE: For more information, please refer to the QuickSpecs for the |
|
|
|
|
LO100c found at: http://h18004.www1.hp.com/products/servers/ |
|
|
|
|
management/remotemgmt/lightsout100/index.html |
|
|
|
|
|
|
DA - 12867 Worldwide QuickSpecs — Version 10 — 4.18.2008 |
Page 5 |
QuickSpecs
HP ProLiant ML110 Generation 5
Standard Features
Core Infrastructure |
HP ProLiant ML110 G5 |
The HP ProLiant Easy Set-up CDs optimize single-server setup, |
Management |
Easy Set-up CD |
providing a simple way to deploy reliable and consistent server |
|
|
configurations. The HP ProLiant 100 Series Easy Set-up CD ship |
|
|
standard with the ML110 G5. |
|
|
It offers essential single-server deployment tools for HP ProLiant 100 |
|
|
series servers that simplify HP entry server setup, providing a |
|
|
repeatable way to deploy reliable and consistent single-server |
|
|
configurations. The HP ProLiant Easy Set-up CDs assist with the OS |
|
|
installation process by preparing the system for installing "off-the-shelf" |
|
|
versions of Windows operating system software and automatically |
|
|
integrating optimized HP ProLiant server software drivers and utilities. |
|
|
Users enjoy the following benefits: |
|
|
An easy-to-use, intuitive graphical interface that guides you |
|
|
through preparing your system for the OS installation process. |
|
|
Integration of key server software drivers with assisted |
|
|
installation. |
|
|
Dependency and validity checks to ensure that all supported |
|
|
ProLiant software can be installed. |
|
|
NOTE: For the latest information about other related software; please |
|
|
visit the HP Insight Control Management Software Portfolio at: |
|
|
http://h18004.www1.hp.com/products/servers/management/ and the HP |
|
|
ProLiant Easy Set-up CD Web site at www.hp.com/servers/easysetup |
|
Subscriber's Choice |
Subscriber's Choice Driver and Support Alerts/Notifications is a web- |
|
|
based email subscription service that provides software and driver |
|
|
change notifications for ProLiant products. Sign up at: |
|
|
http://www.hp.com/go/subscriberschoice and customize your profile to |
|
|
receive various new alerts as they become available, on a weekly or |
|
|
monthly basis. |
|
ROMPaq software and |
The latest software, drivers, and firmware fully optimized and tested for |
|
latest drivers |
your ProLiant server and options, available through ProLiant Support |
|
|
Packs or downloaded from software and drivers download pages |
|
|
website at: http://www.hp.com/go/support. |
|
|
|
Industry Standard |
ACPI V3.0a Compliant |
|
Compliance |
PCI 2.3 Compliant |
|
|
PXE Support |
|
|
WOL Support |
|
|
IPMI 2.0 compliance |
|
|
|
|
Manageability |
Standard Lights Out 100 1PMI 2.0 reporting |
|
|
HP ProLiant G5 Lights-Out 100c Remote Management Card (Optional |
|
|
HP ProLiant ML110 G5 Easy Set-Up CD |
|
|
|
|
Security |
Power-on password |
|
|
Setup password |
|
|
|
|
Server Power Cords |
12' country specific, lowline NEMA power cord. |
|
|
|
|
DA - 12867 Worldwide QuickSpecs — Version 10 — 4.18.2008 |
Page 6 |
QuickSpecs
HP ProLiant ML110 Generation 5
Standard Features
Power Supply |
365 Watts |
|
|
|
|
System Fans |
1 – non-redundant system fan shipped standard |
|
|
1 – non-redundant CPU heatsink fan shipped standard |
|
|
|
|
OS Support |
Windows 2003/2003 R2 Web edition |
|
|
Windows 2003/2003 R2 Small Business edition |
|
|
Windows 2003/2003 R2 Standard Edition (x86 and x64) |
|
|
Windows 2003/2003 R2 Enterprise Edition (x86 and x64) |
|
|
Windows 2008 |
|
|
Red Hat Enterprise Linux 5 Update 1 (x86 and x64) |
|
|
SLES 10 SP1 (x86 and x64) |
|
|
Netware 6.5 SP7 |
|
|
NOTE: For more complete and up-to-date information of all supported OSes for ProLiants, |
|
|
certification information and how to buy server operating systems from HP please visit the OS |
|
|
products site at: |
|
|
http://h18004.www1.hp.com/products/servers/software/OEM.html. |
|
|
NOTE: For an up-to-date listing of the latest software and drivers available for your server, please |
|
|
select your server: |
|
|
http://h20000.www2.hp.com/bizsupport/TechSupport/Product.jsp?lang=en&cc=us&taskId=135& |
|
|
prodTypeId=15351&prodCatId=241435. |
|
|
NOTE: When installing a Windows OS Environment and configuring the embedded SATA RAID, |
|
|
AHCI, or SAS controllers, installation of a driver from a diskette device is required. The optional |
|
|
USB floppy drive (part number DC361B), or HP 256MB/1GB USB 2.0 Floppy Drive Key is required |
|
|
on the ML110 G5 to accomplish this operation. |
|
|
NOTE: For the installation of Windows and other OS's, a floppy drive or HP's USB floppy key |
|
|
(P/N: 442084-B21 or 442085-B21) may be required to complete driver installation. A USB drive |
|
|
key may not work to complete driver installation. |
|
|
NOTE: Netware 6.5 SP6 is not supported with the embedded SATA RAID controller. |
|
|
|
|
Factory Express |
HP Factory Express offers configuration, customization, integration and deployment services for |
|
Portfolio for Servers |
HP servers and/or storage products. Customers can choose how their factory solutions are built, |
|
and Storage |
tested, integrated, shipped and deployed. |
|
|
Factory Express offers service packages for simple configuration, racking, installation, complex |
|
|
configuration and design services as well as individual factory services, such as image loading, |
|
|
asset tagging and custom packaging HP products supported through Factory Express include a |
|
|
wide array of servers and storage: HP Integrity, HP ProLiant, HP ProLiant Server Blades, HP |
|
|
BladeSystem, HP 9000 servers, as well as, the MSA1000, VA7xxx, EVA, XP, rackable tape |
|
|
libraries and configurable network switches. |
|
|
For more information on Factory Express services for your specific server model please contact |
|
|
your sales representative or go to http://www.hp.com/go/factory-express. |
|
|
|
|
HP Enterprise |
The HP eCo-Enterprise Configurator now provides factory default racking for our HP hardware |
|
Configurator |
portfolio. This approach is aligned with our strategic direction to meet the needs and expectations |
|
|
of our valued customers. If you require "custom" rack configuration, please contact HP's Customer |
|
|
Business Center or an Authorized Partner for assistance. |
|
|
|
|
DA - 12867 Worldwide QuickSpecs — Version 10 — 4.18.2008 |
Page 7 |
QuickSpecs
HP ProLiant ML110 Generation 5
Standard Features
Service and Support This product is covered by a global limited warranty and supported by HP Services and a worldwide network of HP Authorized Channel Partners. Hardware diagnostic support and repair is available for one year from date of purchase. Support for software and initial setup is available for 90 days from date of purchase. Additional support may be covered under the warranty or available for an additional fee. Enhancements to warranty services are available through HP Care Pack services or customized service agreements.
HP Care Pack Services provide total care and support expertise with committed response designed to meet your IT and business needs.
HP Care Pack services include coverage for the HP branded hardware options qualified for the server that are purchased at the same time or afterward and internal to the enclosure. It also includes the 22" and smaller external monitors and tower UPS options up to 3kVA. These items will be covered at the same service level and for the same coverage period as the server. Coverage of UPS Battery is not included and standard warranty terms & conditions apply. For servers or storage systems installed within a rack, service also covers all HP qualified rack options installed within the same rack.
To fully capitalize on your HP ProLiant servers' capabilities requires a service partner who thoroughly understands your server technology and systems environment. HP Services, an industry leader in provision of multi vender support solutions provides a range of support services designed to meet the varying needs of business. Whether an SMB or large global corporation HP has a ProLiant server support offer to help you speedily deploy and maximize system uptime.
Recommended Service – Simplify ProLiant solution implementation, maintenance and management.
Support Service – 3 Year, 9x5 Next Business Day coverage, excluding HP holidays only
Deployment Service – Hardware Installation only
Enhanced Service – Optimize service level to increase IT performance and availability
Support Service – 3 Year 13x5 Same Business Day, 4-Hour response coverage
Deployment Service – Installation and Start-up only
Installation & Start-Up of a ProLiant server and Microsoft or Linux O/S per the Customer Description and/or Data Sheet. To be delivered on a scheduled basis 8am-5pm, M-F, excl. HP holidays.
For a complete listing of service offerings and information visit:
http://www.hp.com/services/proliantservices
http://www.hp.com/go/proliant/carepack
DA - 12867 Worldwide QuickSpecs — Version 10 — 4.18.2008 |
Page 8 |
QuickSpecs
HP ProLiant ML110 Generation 5
Models
NOTE: For the Standard Features shipped in the "Factory Integrated Models", please see "Configuration Information".
SATA Models
ML110 G5 Pentium |
Processor(s) |
One (1) Dual-Core Intel® Pentium® Processor E2160 (1.8GHz, 65W, |
E2160 NHP-SATA |
|
800 FSB, 1MB) |
444809-xx1 |
Cache Memory |
1 x 1MB Level 2 cache |
|
Memory |
512 MB PC2-6400 ECC (DDR2-800MHz) (1 x 512 MB) |
|
Storage Controller |
HP Embedded 6 Port SATA Controller with embedded RAID (4 ports for |
|
|
HDD) |
|
Hard Drive |
160 GB SATA HDD |
|
Internal Storage |
Maximum 2.0TB (4 x 500GB) SATA |
|
Optical Drive |
16x SATA DVD-ROM |
|
Form Factor |
Micro ATX Tower (4U) |
|
|
|
ML110 G5 Xeon 3065 |
Processor(s) |
One (1) Dual-Core Intel® Xeon® Processor 3065 (2.33GHz, 65W, 1333 |
NHP-SATA |
|
FSB, 4MB) |
444810-xx1 |
Cache Memory |
1 x 4 MB Level 2 cache |
|
Memory |
512 MB PC2-6400 ECC (DDR2-800MHz) (1 x 512 MB) |
|
Storage Controller |
HP Embedded 6 Port SATA Controller with embedded RAID (4 ports for |
|
|
HDD) |
|
Hard Drive |
160GB SATA HDD |
|
Internal Storage |
Maximum 2.0TB (4 x 500GB) SATA |
|
Optical Drive |
16x SATA DVD-ROM |
|
Form Factor |
Micro ATX Tower (4U) |
|
|
|
SAS Models
ML110 G5 XEON 3065 |
Processor(s) |
One (1) Dual-Core Intel® Xeon® Processor X3065 (2.33GHz, |
NHP-SAS |
|
65W,1333 FSB, 4MB) |
444811-xx1 |
Cache Memory |
1 x 4MB Level 2 cache |
|
Memory |
1 GB PC2-6400 ECC (DDR2-800MHz) (1 x 1GB) |
|
Storage Controller |
HP SC40Ge Host Bus Adapter with RAID 0, 1 support |
|
Hard Drive |
72GB SAS HDD |
|
Internal Storage |
Maximum 1.2TB (4 x 300GB) SAS |
|
Optical Drive |
16x SATA DVD-ROM |
|
Form Factor |
Micro ATX Tower (4U) |
|
|
|
Country Code Key |
XX=00 |
NA |
|
XX=01 |
Australia |
|
XX=03 |
UK |
|
XX=04 |
Germany |
|
XX=05 |
France |
|
XX=20 |
Brazil |
|
XX=29 |
Japan |
|
XX=37 |
AP |
|
XX=42 |
Euro |
|
XX=AA |
PRC |
DA - 12867 Worldwide QuickSpecs — Version 10 — 4.18.2008 |
Page 9 |
Loading...
