USER MANUAL
GETTING STARTED? EASY.
ZDT26050FA
EN |
User Manual |
2 |
DE |
Dishwasher |
|
Benutzerinformation |
19 |
|
|
Geschirrspüler |
|
SAFETY INFORMATION
Before the installation and use of the appliance, carefully read the supplied instructions. The manufacturer is not responsible for any injuries or damages that are the result of incorrect installation or usage. Always keep the instructions in a safe and accessible location for future reference.
CHILDREN AND VULNERABLE PEOPLE SAFETY
•This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning the use of the appliance in a safe way and understand the hazards involved.
•Do not let children play with the appliance.
•Keep detergents away from children.
•Keep children and pets away from the appliance when the door is open.
•Children shall not carry out cleaning and user maintenance of the appliance without supervision.
GENERAL SAFETY
•This appliance is intended to be used in household and similar applications such as:
–farm houses; staff kitchen areas in shops, offices and other working environments;
–by clients in hotels, motels, bed & breakfast and other residential type environments.
•Do not change the specification of this appliance.
•The operating water pressure (minimum and maximum) must be between 0.5 (0.05) / 8 (0.8) bar (MPa)
•Obey the maximum number of 13 place settings.
•If the supply cord is damaged, it must be replaced by the manufacturer, its Authorised Service Centre or similarly qualified persons in order to avoid a hazard.
2
•Put the cutlery in the cutlery basket with the sharp ends pointing down or put them in the cutlery drawer in a horizontal position with the sharp edges down.
•Do not leave the appliance with the open door unattended to avoid stepping accidentally onto it.
•Before any maintenance operation, deactivate the appliance and disconnect the mains plug from the socket.
•Do not use high pressure water sprays and/or steam to clean the appliance.
•If the appliance has ventilation openings in the base, they must not be covered e.g. by a carpet.
•The appliance is to be connected to the water mains using the new supplied hose-sets. Old hose sets must not be reused.
SAFETY INSTRUCTIONS
INSTALLATION
WARNING! Only a qualified person must install this appliance.
•Remove all the packaging.
•Do not install or use a damaged appliance.
•Do not install or use the appliance where the temperature is less than 0 °C.
•Follow the installation instruction supplied with the appliance.
•Always take care when moving the appliance as it is heavy. Always use safety gloves and enclosed footwear.
•Make sure that the appliance is installed below and adjacent to safe structures.
ELECTRICAL CONNECTION
WARNING! Risk of fire and electrical shock.
•The appliance must be earthed.
•Make sure that the parameters on the rating plate are compatible with the electrical ratings of the mains power supply.
•Always use a correctly installed shockproof socket.
•Do not use multi-plug adapters and extension cables.
•Make sure not to cause damage to the mains plug and to the mains cable. Should the mains cable need to be replaced, this must be carried out by our Authorised Service Centre.
•Connect the mains plug to the mains socket only at the end of the installation. Make sure that there is access to the mains plug after the installation.
•Do not pull the mains cable to disconnect the appliance. Always pull the mains plug.
•This appliance complies with the E.E.C. Directives.
•UK and Ireland only. This appliance is fitted with a 13 A mains plug. If it is necessary to change the mains plug fuse, use only a 13 A ASTA (BS 1362) fuse.
WATER CONNECTION
•Do not cause damage to the water hoses.
•Before connection to new pipes, pipes not used for a long time, where repair work has been carried out or new devices fitted (water meters, etc.), let the water flow until it is clean and clear.
•Ensure that there are no visible water leaks during and after the first use of the appliance.
•The water inlet hose has a safety valve and a sheath with an inner mains cable.
3
• Remove the door catch to prevent children and pets to get closed in the appliance.
WARNING! Dangerous voltage.
•If the water inlet hose is damaged, immediately close the water tap and disconnect the mains plug from the mains socket. Contact the Authorised Service Centre to replace the water inlet hose.
USE
•Do not sit or stand on the open door.
•Dishwasher detergents are dangerous. Obey the safety instructions on the detergent packaging.
•Do not drink and play with the water in the appliance.
•Do not remove the dishes from the appliance until the programme is complete. Some detergent may remain on the dishes.
•The appliance can release hot steam if you open the door while a programme operates.
•Do not put flammable products or items that are wet with flammable products in, near or on the appliance.
SERVICE
•Contact the Authorised Service Centre to repair the appliance. We recommend only the use of original spare parts.
•When you contact the Authorised Service Centre, ensure that you have the following information that is available on the rating plate. Model :
PNC :
Serial Number :
DISPOSAL
WARNING! Risk of injury or suffocation.
•Disconnect the appliance from the mains supply.
•Cut off the mains cable and discard it.
4
EASY START
|
1 |
|
|
|
2 |
|
3 |
|
4 |
|
5 |
|
6 |
|
7 |
|
8 |
|
|||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
On/off button |
|
XtraDry button |
|
|
||
|
Display |
|
RESET button |
|
|
||
|
Delay button |
|
Indicators |
|
|
||
|
Programme buttons |
|
|
|
|
|
|
|
TimeSaver button |
|
|
|
|
|
INDICATORS
Salt indicator. It is always off while the programme operates. Rinse aid indicator. It is always off while the programme operates.
PROGRAMMES
|
|
|
|
|
Consumption values |
|
||
|
|
|
|
|
|
1) |
|
|
Programme |
Degree of soil |
Programme phases |
|
|
|
|
||
Type of load |
|
|
|
|
||||
|
|
|
|
|
|
|
||
|
|
|
|
|
Duration |
Energy |
Water |
|
|
|
|
|
|
(min) |
(kWh) |
(l) |
|
|
|
|
|
|
|
|
|
|
P1 |
• |
Normal soil |
• |
Prewash |
10.5 |
0.932 |
232 |
|
ECONOMY |
• |
Crockery |
• |
Wash 50 °C |
|
|
|
|
2) |
|
and cutlery |
• |
Rinses |
|
|
|
|
|
|
|
• |
Dry |
|
|
|
|
|
|
|
|
|
|
|
|
|
P2 |
• |
All |
• |
Prewash |
7 - 15 |
0.6 - 1.7 |
40 - 170 |
|
AUTOMATIC 3) |
• |
Crockery, |
• |
Wash from 45 |
|
|
|
|
|
|
cutlery, pots |
|
°C to 70 °C |
|
|
|
|
|
|
and pans |
• |
Rinses |
|
|
|
|
|
|
|
• |
Dry |
|
|
|
|
|
|
|
|
|
|
|
|
|
P3 |
• |
Heavy soil |
• |
Prewash |
12.5 - |
1.4 - 1.7 |
170 - |
|
Intensive |
• |
Crockery, |
• |
Wash 70 °C |
14.5 |
|
190 |
|
|
|
cutlery, pots |
• |
Rinses |
|
|
|
|
|
|
and pans |
• |
Dry |
|
|
|
|
|
|
|
|
|
|
|
|
|
5
|
|
|
|
|
Consumption values |
|
||
|
|
|
|
|
|
1) |
|
|
Programme |
Degree of soil |
Programme phases |
|
|
|
|
||
Type of load |
|
|
|
|
||||
|
|
|
|
|
|
|
||
|
|
|
|
|
Duration |
Energy |
Water |
|
|
|
|
|
|
(min) |
(kWh) |
(l) |
|
|
|
|
|
|
|
|
|
|
P5 |
• |
Normal or |
• |
Wash 45 °C |
12 - 14 |
0.7 - 0.9 |
82 - 92 |
|
Delicate |
|
light soil |
• |
Rinses |
|
|
|
|
|
• |
Delicate |
• |
Dry |
|
|
|
|
|
|
crockery and |
|
|
|
|
|
|
|
|
glassware |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
P4 |
• |
Fresh soil |
• |
Wash 60 °C |
10 |
0.9 |
30 |
|
Quick 30 Min 4) |
• |
Crockery |
• |
Rinses |
|
|
|
|
|
|
and cutlery |
|
|
|
|
|
|
1)The pressure and the temperature of the water, the variations of the mains supply, the options and the quantity of dishes can change the values.
2)With this programme, you have the most efficient use of water and energy consumption for crockery and cutlery with normal soil. This is the standard programme for test institutes.
3)The appliance senses the degree of soil and the quantity of items in the baskets . It automatically adjusts the temperature and the quantity of water, the energy consumption and the programme duration.
4)With this programme, you can wash a half-load dishwasher with fresh soil. It gives good washing results in a short time.
SETTINGS
PROGRAMME SELECTION MODE
In the programme selection mode, it is possible to set a washing programme and to enter the user mode to change the appliance settings.
To enter the programme selection mode: Press on/off button.
•The display shows the number of the programme ECONOMY .
•After a few seconds the display shows the programme duration.
If the control panel does not indicate that the appliance is in the programme selection mode, follow the RESET procedure.
RESET PROCEDURE
Use RESET to:
•Cancel a currently running programme.
•Stop the countdown of Delay option.
•Bring the appliance back to the programme selection mode.
To RESET:
Press and hold RESET until the control panel indicates the appliance is in the programme selection mode.
USER MODE
Settings available in the user mode:
•The level of the water softener according to the water hardness.
•Activation or deactivation of the rinse aid empty notification.
•The level of rinse aid according to the required dosage.
•Activation or deactivation of the acoustic signal indicating the end of a programme.
•Activation or deactivation of AirDry.
Before entering the user mode, make sure the appliance is in the programme selection mode.
To enter the user mode:
Press and hold simultaneously
and
for at least 3 seconds.
The indicators:
,
,
,
and
start flashing.
As the appliance stores the saved settings, there is no need to configure it before every cycle.
ADJUSTING THE WATER SOFTENER
Make sure the appliance is in user mode.
6
1.Press
.
•The indicators
,
,
and
are off.
•The indicator
still flashes.
•The display shows the current setting: e.g.
= level 5.
2.Press
to change the setting. Each pressing
of the button
increases the level number by one. After reaching level 10, the count starts again from level 1.
3.Press the on/off button to confirm the setting.
THE WATER HARDNESS TABLE
If you use multi-tablets containing salt and the hardness of your water is lower than 21°dH, you can set the lowest water softener level. It deactivates the salt refill indicator.
If you use standard detergent or multitablets without salt, set the proper water hardness level to keep the salt refill indicator active.
German degrees |
French degrees |
mmol/l |
Clarke degrees |
Water softener |
|
(°dH) |
(°fH) |
level |
|
||
|
|
|
|||
|
|
|
|
|
|
47 -50 |
84 - 90 |
8.4 - 9.0 |
58 - 63 |
10 |
|
|
|
|
|
|
|
43 - 46 |
76 - 83 |
7.6 - 8.3 |
53 - 57 |
9 |
|
|
|
|
|
|
|
37 - 42 |
65 - 75 |
6.5 - 7.5 |
46 - 52 |
8 |
|
|
|
|
|
|
|
29 - 36 |
51 - 64 |
5.1 - 6.4 |
36 - 45 |
7 |
|
|
|
|
|
|
|
23 - 28 |
40 - 50 |
4.0 - 5.0 |
28 - 35 |
6 |
|
|
|
|
|
|
|
19 - 22 |
33 - 39 |
3.3 - 3.9 |
23 - 27 |
5 1) |
|
15 - 18 |
26 - 32 |
2.6 - 3.2 |
18 - 22 |
4 |
|
|
|
|
|
|
|
11 - 14 |
19 - 25 |
1.9 - 2.5 |
13 - 17 |
3 |
|
|
|
|
|
|
|
4 - 10 |
7 - 18 |
0.7 - 1.8 |
5 - 12 |
2 |
|
|
|
|
|
|
|
<4 |
<7 |
<0.7 |
< 5 |
1 2) |
|
1)Factory setting
2)Do not use salt at this level.
DEACTIVATING THE RINSE AID EMPTY NOTIFICATION
Make sure the appliance is in user mode.
1.Press
.
•The indicators
,
,
and
are off.
•The indicator
still flashes.
•The display shows the current setting:
–
= the rinse aid empty notification is activated.
–
= the rinse aid empty notification is deactivated.
When rinse aid chamber is empty, the rinse aid indicator is turned on notifying to refill rinse aid. If the drying results are satisfactory while using multi-tablets only, it is possible to deactivate the notification for refilling rinse aid. However, for the best drying performance, always use rinse aid.
If standard detergent or multi-tablets without rinse aid are used, activate the notification to keep the rinse aid refill indicator active.
2. |
Press |
to change the setting. |
HOW TO SET THE RINSE AID LEVEL |
3. |
Press on/off button to confirm the setting. |
Make sure the appliance is in user mode. |
|
7
1.Press
.
•The indicators
,
,
and
are off.
•The indicator
still flashes.
•The display shows the current setting: e.g.
= level 4.
–The levels of rinse aid range from 0A to 6A.
–Level 0A means no rinse aid is used.
2.Press
repeatedly to change the setting.
3.Press on/off to confirm the setting.
HOW TO ACTIVATE THE ACOUSTIC SIGNAL FOR THE END OF PROGRAMME
Make sure the appliance is in user mode.
1.Press
•The indicators
,
,
and
are off.
•The indicator
still flashes.
•The display shows the current setting.
–
= the acoustic signal is activated.
–
= the acoustic signal is deactivated.
2.Press
to change the setting.
3.Press on/off to confirm the setting.
HOW TO DEACTIVATE AIRDRY
AirDry improves the drying results with less energy consumption.
During the drying phase, the door opens automatically and remains ajar.
AirDry is automatically activated with all programmes excluding Rinse & Hold (if applicable). It is possible to deactivate it.
Make sure the appliance is in user mode. 1. Press
.
The indicators:
,
,
and
are off. The
indicator
still flashes.
The display shows the current setting.
•
= AirDry is activated.
•
= AirDry is deactivated.
2.Press
to change the setting.
3.Press on/off to confirm and save the setting.
CAUTION! If children have access to the appliance, it is advised to deactivate AirDry as opening the door may pose a danger.
BEFORE FIRST USE
1.Make sure that the current level of the water softener agrees with the hardness of the water supply. If not, adjust the level of the water softener.
2.Fill the salt container.
3.Fill the rinse aid dispenser.
4.Open the water tap.
5.Start a programme to remove any processing residuals that can still be inside the appliance. Do not use detergent and do not load the baskets.
After starting a programme, it may take up to 5 minutes for the appliance to recharge the resin in the water softener. It seems that the appliance is not working. The washing phase starts only after this procedure is completed. The procedure is repeated periodically.
8
THE SALT CONTAINER
CAUTION! Use rough salt designed for dishwashers only. Fine salt increases the risk of corrosion.
Adding salt
The salt is used to recharge the resin in the water softener and to assure good washing results in daily use.
Before the first use, put one litre of water in the salt container.
CAUTION! Water and salt can come out of the salt container during filling. To prevent corrosion, start a programme immediately after filling the salt container.
ADDING RINSE AID
A
The rinse aid helps to dry dishes without streaks ans stains. It is automatically released during the hot rinse phase.
•Fill the rinse aid dispenser until the rinse aid dispenser reaches the marking "MAX".
•Remove the spilled rinse aid with an absorbent cloth to prevent too much foam.
•Fill the rinse aid dispenser when the indicator (A) becomes clear.
DAILY USE
1.Open the water tap.
2.Press the on/off button to activate the appliance.
Make sure that the appliance is in programme selection mode.
•If the salt indicator is on, fill the salt container.
•If the rinse aid indicator is on, fill the rinse aid dispenser.
3.Load the baskets.
4.Add the detergent.
5.Set and start the correct programme for the type of load and the degree of soil.
9
ADDING DETERGENT
1
30
30 |
2
If the programme has a prewash phase, put a small quantity of detergent on the inner part of the appliance door.
ADDING MULTI-TABLETS
1
30
30
2
•Do not fill the salt container and the rinse aid dispenser.
•Adjust the water softener to the lowest level.
•Set the rinse aid dispenser to the lowest position.
SETTING AND STARTING A PROGRAMME
The AUTO OFF function
This function decreases energy consumption by deactivating automatically the appliance when it is not operating.
The function comes into operation:
•5 minutes after the completion of the programme.
•After 5 minutes if the programme has not started.
Starting a programme
1.Keep the appliance door ajar.
2.Press the on/off button to activate the appliance. Make sure that the appliance is in programme selection mode.
3.Press one of the programme buttons until the display shows the number of the desired programme. The display shows the programme duration after some seconds.
4.Set the applicable options.
5.Close the appliance door to start the programme.
Options
Desired options must be activated every time before you start a programme.
It is not possible to activate or deactivate options while a programme is running.
Not all options are compatible with each other. If you select non compatible options, the appliance automatically deactivates one or more of them. Only the indicators of the still active options are on.
Option Delay
1.Set a programme.
2.Press
until the display shows the delay time you want to set (1-24h).
The delay time flashes in the display.
3.Close the appliance door. The countdown starts to decrease by 1 hour.
When the countdown is complete the programme starts.
10
Option TimeSaver
This option increases the pressure and the temperature of the water. The washing and the drying phases are shorter.
The total programme duration decreases by approximately 50%.
The washing results are the same as with the normal programme duration. The drying results can decrease.
If the option is not applicable to the programme, the related indicator does not turn on or it flashes quickly for a few seconds and then turns off.
Opening the door while the appliance operates
Opening the door while a programme is running stops the appliance. It may affect the energy consumption and the programme duration. After closing the door, the appliance continues from the point of interruption.
If the door is opened during the drying phase, before AirDry automatically opens it, the programme ends after 30 seconds.
How to activate TimeSaver
1.Set a programme.
2.Press TimeSaver. The related indicator is on.
The display shows the updated programme duration.
Option XtraDry
Activate this option to boost the drying performance. With XtraDry on, the duration of some programmes, water consumption and the last rinse temperature can be affected.
XtraDry is a permanent option for all programmes other than ECONOMY and need not to be selected at every cycle.
In the other programmes the setting of XtraDry is permanent and it is automatically used in next cycles. This configuration can be changed at any time
How to activate XtraDry
1.Set a programme.
2.Press
. The related indicator is on.
The display shows the updated programme duration.
HINTS AND TIPS
If the door is closed after it is opened automatically by AirDry in the drying phase, the programme ends after 3 minutes.
Do not try to close the appliance door within 2 minutes after AirDry automatically opens it, as this may cause damage to the appliance.
End of the programme
When the programme is completed the display shows 0:00.
All buttons are inactive except for the on/off button.
1.Press the on/off button or wait for the AUTO OFF function to automatically deactivate the appliance.
If you open the door before the activation of AUTO OFF, the appliance is automatically deactivated.
2.Close the water tap.
GENERAL
The following hints will ensure optimal cleaning and drying results in daily use and also help to protect the environment.
•Remove larger residues of food from the dishes into the waste bin.
•Do not pre-rinse dishes by hand. When needed, use the prewash programme (if available) or select a programme with a prewash phase.
•Always use the whole space of the baskets.
•When loading the appliance, make sure that the dishes can be completely reached and washed by the water released from the spray arm
nozzles. Make sure that items do not touch or cover each other.
•You can use dishwasher detergent, rinse aid and salt separately or you can use the multitablets (e.g. ''3in1'', ''4in1'', ''All in 1''). Follow the instructions written on the packaging.
•Select the programme according to the type of load and degree of soil. With the ECO programme you have the most efficient use of water and energy consumption for crockery and cutlery with normal soil.
11
USING SALT, RINSE AID AND DETERGENT
•Only use salt, rinse aid and detergent for dishwasher. Other products can cause damage to the appliance.
•In areas with hard and very hard water we recommend to use plain dishwasher detergent (powder, gel, tablets containing no additional agents), rinse aid and salt separately for optimal cleaning and drying results.
•At least once a month run the appliance with the use of appliance cleaner which is particularly suitable for this purpose.
•Detergent tablets do not fully dissolve with short programmes. To prevent detergent residues on the tableware, we recommend that you use the tablets with long programmes.
•Do not use more than the correct quantity of detergent. Refer to the instructions on the detergent packaging.
WHAT TO DO IF YOU WANT TO STOP USING MULTI-TABLETS
Before you start to use separately detergent, salt and rinse aid do the following procedure.
1.Set the highest level of the water softener.
2.Make sure that the salt and rinse aid containers are full.
3.Start the shortest programme with a rinsing phase. Do not add detergent and do not load the baskets.
4.When the programme is completed, adjust the water softener according to the water hardness in your area.
5.Adjust the released quantity of rinse aid.
6.Activate the rinse aid empty notification.
LOADING THE BASKETS
•Only use the appliance to wash items that are dishwasher-safe.
•Do not put in the appliance items made of wood, horn, aluminium, pewter and copper.
CARE AND CLEANING
•Do not put in the appliance items that can absorb water (sponges, household cloths).
•Remove larger residues of food from the dishes into the waste bin.
•Make soft the remaining burned food on the items.
•Put hollow items (cups, glasses and pans) with the opening down.
•Make sure that glasses do not touch other glasses.
•Put cutlery and small items in the cutlery basket.
•Put light items in the upper basket. Make sure that the items do not move.
•Make sure that the spray arms can move freely before you start a programme.
BEFORE STARTING A PROGRAMME
Make sure that:
•The filters are clean and correctly installed.
•The cap of the salt container is tight.
•The spray arms are not clogged.
•There is dishwasher salt and rinse aid (unless you use multitablets).
•The position of the items in the baskets is correct.
•The programme is applicable for the type of load and for the degree of soil.
•The correct quantity of detergent is used.
UNLOADING THE BASKETS
1.Let the tableware cool down before you remove it from the appliance. Hot items can be easily damaged.
2.First remove items from the lower basket, then from the upper basket.
At the end of the program water can still remain on the sides and on the door of the appliance.
WARNING! Before maintenance, deactivate the appliance and disconnect the mains plug from the main socket.
Dirty filters and clogged spray arms decrease the washing results. Make a check regularly and, if necessary, clean them.
12
Loading...
