Page 1
KITCHEN TOOLS
6
Induction Hob SIKP 2000 B2
Induction Hob
Operating instructions
KOMPERNASS GMBH
BURGSTRASSE 21 · D-44867 BOCHUM
www.kompernass.com
ID-Nr.: SIKP 2000 B2-04/11-V2
IAN: 66570
Page 2
SIKP 2000 B2
e
w
1
2
q
3
4
0
9
8
7
6
5
Page 3
Index
Information for these operating instructions . . . . . . . . . . . . . . . . . . . . . . . . 2
Copyright . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Intended use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Safety instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Items supplied . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Disposal of the packaging . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Technical data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Description of appliance / attachments . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Manner of operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Suitable cookware . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Utilisation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Placing the cookware . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Switching on . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Switching off . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Heating up . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Countdown time (Timer) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Child protection system . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
GB
IE
Cleaning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
Disposal of the device . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Notes on the EC Declaration of Conformity . . . . . . . . . . . . . . . . . . . . . . . .14
Importer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Service . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
SIKP 2000 B2
1
Page 4
GB
IE
Information for these operating instructions
Congratulations on the purchase of your new appliance!
You have clearly decided in favour of a modern and high quality product. These
operating instructions are a component of this product. They contain important
information about the safety, operation and disposal of the appliance. Before
using this product familiarise yourself with all of these operating and safety instructions. Use this appliance only as described and only for the specifi ed areas
of application. Also, pass them on to whoever might acquire the appliance at a
future date.
Copyright
This documentation is copyright protected.
Any copying or reproduction of it, including as extracts, as well as the reproduction
of images, also in an altered state, is only permitted with the written authorisation
of the manufacturer.
Intended use
This appliance is intended for the heating up or keeping warm of foods in domestic
households and ONLY for use in dry accommodation.
It is NOT intended for the warming or heating of other materials, for industrial or
commercial applications or for use outdoors.
WARNING
Risks from unintended use!
Risks can be engendered by the appliance if it is used for purposes not intended
for it and/or for other types of use.
Use the appliance exclusively for its intended purposes.
►
Observe the procedures described in these operating instructions. ►
NOTICE
Risks can be engendered by the appliance if it is used for purposes not in- ►
tended for it and/or for other types of use. Use the appliance exclusively for
its intended purposes. Observe the procedures described in these operating
instructions. Claims of any kind for damage resulting from unintended use,
incompetent repairs, unauthorised modifi cation or the use of unauthorised
spare parts will not be accepted. The operator alone bears liability.
2
SIKP 2000 B2
Page 5
Safety instructions
RISK OF ELECTRIC SHOCK
Ensure that the power cable can never become wet or damp during opera- ►
tion. Lay the cable such that it cannot be pinched or otherwise damaged.
►
Should the cable or the electric plug become damaged, arrange for it to
be replaced by Customer Services before you continue to use the appliance.
Always remove the plug from the mains power socket after use. ►
Simply switching off the appliance is not suffi cient, because the appliance ►
continues to receive power for as long as the plug is connected to the
mains power socket.
Protect the cooking plate from damages: Do not burden it irregularly and do ►
not allow objects to fall onto it. The appliance may not be taken into use if
either the cooking plate or the housing is damaged. In this case, immediately remove the plug from the mains power socket and arrange for the
appliance to be repaired.
►
To avoid risks, arrange for defective plugs and/or cables to be replaced at
once by qualifi ed technicians or our Customer Services Department.
►
If the surface is cracked, switch off the appliance to avoid the possibility of
electric shock.
RISK OF ELECTRIC SHOCK
Ensure that the appliance, the cable and the plug are NEVER submersed in water or other fl uids.
GB
IE
SIKP 2000 B2
WARNING! RISK OF INJURY!
►
Do not touch the area on which hot cookware has just been standing.
Directly after cooking, this area could be very hot.
This appliance is not intended for use by individuals (including children) ►
with restricted physical, physiological or intellectual abilities or defi ciences
in experience and/or knowledge unless they are supervised by a person
responsible for their safety or receive from this person instruction in how the
appliance is to be used.
►
Children should be supervised to ensure that they do not play with the
appliance.
3
Page 6
GB
IE
WARNING! RISK OF INJURY!
Caution! Hot surfaces!
This symbol warns you not to touch the cooking area directly after
use. Risk of Burns!
WARNING! RISK OF FIRE!
►
Overheated foodstuff s could begin to burn! Never let the appliance be in
use without supervision.
Additionally, NEVER position the appliance below infl ammable objects, ►
especially not below curtains or drapes.
NEVER heat up a securely closed container. Through heat expansion it ►
could quickly cause an explosion.
►
NEVER heat up an empty container. This would very quickly overheat - presenting both the risk of fi re and of serious damage to the cooking area.
Do not place any metallic objects on the cooking area, such as kitchen ►
utensils or items of cutlery. They can become very hot in the energy area.
Be careful when heating small amounts of oil - do not set a high performance ►
level. If you do, the oil could ignite and catch fi re!
►
NEVER operate the appliance on a metal table or other metallic surface.
This may heat up and thereby lead to a fi re or the appliance itself could be
damaged beyond repair.
Do not operate the appliance via an external time-switch or a separate ►
remote control system.
To avoid the risks and dangers presented by electroma-
gnetic fi elds:
►
Maintain a minimum distance of 1 meter to appliances that are sensitive
to electromagnetic fi elds (e.g. computer screens, clocks, magnetic storage
media, electronic devices usw.).
Medical-technical devices such as heart pacemakers, hearing aids and ►
other appliances may possibly need to be kept at a greater distance. If in
doubt, consult the manufacturer of the appliance!
4
SIKP 2000 B2
Page 7
Items supplied
The appliance is delivered with the following components as standard:
Induction cooker plate
▯
Operating Instructions ▯
Remove all parts of the appliance and the operating instructions from the 1)
carton.
Remove all packing material. 2)
NOTICE
Check the contents to make sure everything is there and for visible dama- ►
ge.
If the delivery is not complete, or is damaged due to defective ►
packaging or through transportation, contact the Service
Hotline (see chapter Service).
Disposal of the packaging
The packaging protects the appliance from transport damage. The packaging
materials are selected from the point of view of their environmental friendliness
and disposal technology and are therefore recyclable.
The recirculation of packaging into the material circuit saves on raw material
and reduces generated waste. Dispose of packaging material that is no longer
needed as per the regionally established regulations.
NOTICE
If possible preserve the appliance's original packaging during the warranty ►
period so that in the case of a warranty claim you can package the appliance properly for return.
GB
IE
SIKP 2000 B2
5
Page 8
GB
IE
Technical data
Voltage 220 - 240 V ~, 50/60 Hz
Nominal power 2000 W
Protection class
Noise emission level < 70 dB (A)
II
Description of appliance / attachments
1 Cooking area
2 Cable with plug
3 Control lamp for Child Lock
4 Control lamp “Power”
5 On/Off button
6 Button for Child Lock
7 Button +
8 Display
9 Button ---
0 Button - Timer
q Button for Cooking
w Control lamp for Cooking
e Control lamp for Timer
6
SIKP 2000 B2
Page 9
Manner of operation
Whilst standard hotplates become warm themselves, in an induction cooker the
heat is created in the base of the cookware. The cooking area 1 itself is not
heated - it heats up itself only when something in a pan is heated on it and then
radiates heat back onto the cooking area 1. (Reverse heating).
For this, an energy fi eld generates heat which can only be created in magnetically
conductible materials, for example, pans made of ferric materials. In other materials, for example porcelain, glass or ceramic, the energy fi eld cannot create any
heating eff ect.
Suitable cookware
Use only cookware that is suitable for induction cookers:
■
Suitable are pots and pans with a base made of steel or cast iron. These are
recognisable either through the markings on the pan or if a magnet clings to
the base of the pan.
Unsuitable are all types of cookware made of metals to which a magnet
■
does not cling, for example aluminium, copper and stainless steel, as well as
non-metallic cookware made of porcelain, glass, ceramics and plastics etc.
Thin pan bottoms are better suited for induction cookers than thick sandwich
■
bottoms. The very short reaction times to setting adjustments (short pre-warm
time; fast metered roasting) are not possible with thick pan bases.
Only use cookware that is suitable for the size of the cooking area 1.
The diameter...
–
may not exceed 26 cm, so that the pan does not overhang,
and may not be less than 16 cm, so that the energy fi eld can actually –
work.
–
The base of the pan may not be uneven, rather, it must sit fl at.
Only then can the induction cooker function perfectly.
GB
IE
SIKP 2000 B2
7
Page 10
GB
IE
Setup
So as not to overheat, the appliance requires unrestricted ventilation. Therefore,
position the appliance such that ...
there is an all-round free space of minimum 10 cm, e.g. to the nearest
–
wall,
–
a free space directly above of minimum 60 cm, e.g. to a suspended wall
cabinet.
For cooling, the appliance draws in air through the openings on the underside.
■
Therefore, place it only on smooth surfaces, not on textiles or fl uff y surfaces,
such as tablecloths.
Do not place it adjacent to curtains, drapes or other textiles which, due to
■
the airfl ow, could press themselves against the appliance.
Utilisation
When you have unpacked and positioned the appliance as described above, it
is now ready for use.
Placing the cookware
Place the cookware in the middle of the cooking area ■ 1. This may ...
not project beyond the edge of the cooking area
– 1...
not weigh more than 10 kg (together with the content). –
Switching on
8
When cookware with content is standing on the hob ■ 1:
Insert the plug
– 2 into a mains power socket. A signal tone sounds and
„- L -“ appears on the display 8. The appliance is now ready for use.
Press the button On/Off – 5. The control lamp POWER 4 lights up,
the control lamp Cooking w blinks, the symbol
display 8 and „L5“ appears in the display 8. A signal tone sounds.
The appliance is now ready for use.
fl ashes below the
SIKP 2000 B2
Page 11
Switching off
The appliance switches off , ... ■
NOTICE
In standby mode, that is, after switching off or before switching on, an "- L-" ►
or an "- H -" appears in the display 8. This heat indicator means:
or
For safety reasons, the cookware recognition feature switches the appliance ■
off automatically when you ...
NOTICE
As soon as you take the cookware from the cooking area, "Err" fl ashes in ►
the display.
if, within 30 seconds of switching on, you do not select any further function, –
if you activate the button On/Off – 5 once again, also when it is in
actual use.
"- L -" = "Low" - Temperature the cooking area
– 1 <60°C
"- H -" = "High" - Temperature the cooking area
– 1 >60°C
remove the cookware from the cooking area
– 1 for longer than 15
seconds, or do not place one there..
–
Although the energy fi eld is immediately switched off with short-term
cookware removals - the selected function remains, however, active.
Around every 3 seconds a signal tone issues a reminder that, in roughly
15 seconds, the appliance will switch itself off automatically. If you replace
the cookware back onto the cooking area 1 within 15 seconds, the
selected function will continue on the same settings.
GB
IE
SIKP 2000 B2
■ 1 also switches itself off after 120 minutes of continuous
The cooking area
use, should you not have entered in any new settings in the meantime.
9
Page 12
GB
IE
Heating up
or:
NOTICE
NOTICE
After you have switched the appliance on ... ■
Using the buttons + – 7 and --- 9, select the desired power level (L1 -
L10). The default setting is a medium power level (L5).
Press the button Cooking
– q to be able to select the temperature. In the
display 8 appears „120“ and below the display 8 the symbol „°C „.
Using the buttons + 7 and --- 9 then select the desired temperature
(60 - 240°C). The default setting is a temperature of 120°C.
If you are using the setting "Temperature" for cooking, the appliance heats
►
the cookware to the selected temperature. If the set temperature should fall,
the appliance heats it up again. The temperature is maintained.
With the setting "Power level", the cookware is heated at diff erent rates. ►
The higher the selected power level, the faster the cookware is heated.
Warming up starts as soon as one of these buttons is activated. The setting ►
can be adjusted at any time during the current usage.
10
SIKP 2000 B2
Page 13
Countdown time (Timer)
You can pre-select a time period from 0 - 180 minutes after which the cooking
area 1 should switch itself off .
■
First start the warming-up, as described above.
Then press the button Timer ■ 0. The control lamp Timer e glows, „120 „
appears in the display 8 and „min“ appears below the display 8.
Using the buttons +
■ 7 and --- 9 you can select the desired countdown time
from 0 - 180 minutes ...
forward in 1-minute increments (if you press and hold the button +
– 7,
the time runs forward in 5 minute increments),
backward in 5 minute increments. –
When you have set the countdown time, and press no other button, the ■
countdown will start automatically. The set power level/temperature appears
alternately with the remaining countdown time in the display 8. If you have
set a countdown time of 0, the appliance switches off after 5 seconds.
Child protection system
To prevent unauthorised switching on or a changing of the settings, by children
for example, this appliance is fi tted with a childproof lock.
In the standy-by mode press and hold the button Child Lock
■ 6 until a signal
tone is heard and the control lamp Child Lock 3 glows. Now all the buttons,
except Child Lock 6, are blocked.
To release the child safety block, once again press and hold the button
■
Child Lock 6 until a signal tone is heard and the control lamp Child Lock 3
extinguishes. The buttons are now released.
GB
IE
SIKP 2000 B2
NOTICE
If the child safety block is enabled during operation, the button On/Off ► 5
for switching off and the button Child Lock 6 can still be activated.
11
Page 14
GB
IE
Cleaning
WARNING - RISK OF ELECTRIC SHOCK!
WARNING - RISK OF INJURY!
WARNING - PROPERTY DAMAGE!
► 2 from the mains power socket before you com-
Always remove the plug
mence cleaning the appliance.
► Under no circumstances may the appliance or parts of it be submersed
in liquids! This could result in you receiving a fatal electric shock and the
appliance could be damaged.
NEVER open the appliance housing. You could receive a potentially fatal ►
electric shock.
►
Let the appliance cool down before cleaning it. Risk of Burns!
Do not use solvents or abrasive cleaners. These could damage the cooking ►
area 1 and the areas made of synthetic materials.
Do not use abrasive, aggressive or chemical cleaning agents! They could ►
irreparably damage the upper surfaces!
■ 2 only with a lightly moistened cloth.
Clean all surfaces and the cable
In all cases, dry the appliance well before using it again.
■
Burnt-on soiling on the cooking area ■ 1 can be removed with a scraper suitable
for glass hobs, available in most household equipment shops.
Should soiling be visible in the area of the ventilation slots, you can attempt
■
to remove this from outside with a vacuum cleaner.
12
SIKP 2000 B2
Page 15
Troubleshooting
PROBLEM POSSIBLE CAUSE POSSIBLE SOLUTIONS
The appliance does not
function. The control lamp
“Power 4 does not glow.
The appliance does not
start the cooking process.
Shown in the display 8
is E01.
Shown in the display 8
is E02.
Shown in the display 8
is E03.
Shown in the display 8
is E05.
Shown in the display 8
is E06.
Shown in the display 8
is E07.
Shown in the display 8
is E08.
The plug 2 is not connected.
The appliance is damaged.
There is no cookware on the
cooking area 1.
The cookware is not suitable
for induction cooking areas.
The appliance is not being
supplied with enough voltage
(<160 V)..
The appliance is being supplied with too much voltage (>
270 V).
There is a short circuit inside
the appliance!
The appliance is too hot (in
power levels mode)!
The temperature sensor underneath the cooking area 1 is
defective or there is a short
circuit..
The appliance is too hot (in
Temperature-Mode)!
The temperature sensor is
defective.
Connect the appliance to a mains
power socket.
In this case, contact Customer
Services.
Place suitable cookware on the
cooking area 1.
Use suitable cookware (see chapter
"Suitable Cookware")
Check and ensure that the appliance is connected to a properly
installed mains power socket with
220 - 240V, 50 Hz.
Check and ensure that the appliance is connected to a properly
installed mains power socket with
220 - 240V, 50 Hz.
Immediately disconnect the plug
2 from the mains power socket
and contact the Customer Services
department!
Disconnect the plug 2 from the
mains power socket and wait until
the appliance has cooled down.
Disconnect the plug 2 from the
mains power socket and contact
the Customer Services department.
Disconnect the plug 2 from the
mains power socket and wait until
the appliance has cooled down.
Disconnect the plug 2 from the
mains power socket and contact
the Customer Services department.
GB
IE
SIKP 2000 B2
13
Page 16
GB
IE
There is no cookware on the
cooking area 1.
Place suitable cookware on the
cooking area 1.
Shown in the display 8
is Err.
There is unsuitable cookware
on the cooking area 1.
The cookware is not centered
on the cooking area 1.
Place suitable cookware on the
cooking area 1.
Place the cookware centrally on the
cooking area 1.
Disposal of the device
Do not dispose of this appliance in your normal domestic waste.
This product is subject to the provisions of European Directive
2002/96/EC.
Dispose of the appliance through an approved disposal centre or at your community waste facility. Pay heed to the currently applicable regulations. In case of
doubt, please contact your waste disposal centre.
Notes on the EC Declaration of Conformity
This appliance complies with, in regard to conformance with
the basic requirements and other relevent regulations, the
EMV Directive 2004/108/EC as well as the Directive for Low
Voltage Devices 2006/95/EC.
The complete original Declaration of Conformity can be
obtained from the importer.
Importer
14
KOMPERNASS GMBH
BURGSTRASSE 21
44867 BOCHUM, GERMANY
www.kompernass.com
SIKP 2000 B2
Page 17
Warranty
With this appliance you receive a warranty of 3 years from the date of purchase.
This appliance has been manufactured with care and meticulously examined
before delivery.
Please retain your receipt as proof of purchase. In the case of a warranty claim
please make contact by telephone with our Customer Service department. Only
in this way can a post-free despatch for your goods be assured.
NOTICE
This product is for domestic use only and is not intended for commercial applications. In the event of misuse and improper handling, use of force and interference
not carried out by our authorized service branch, the warranty will become void.
Your statutory rights are not restricted in any way by this warranty. The warranty
period is not extended by repairs made under the warranty. This applies also to
replaced and repaired parts.
Damages and defects extant at the time of purchase must be reported immediately after unpacking, resp. no later than two days after the date of purchase.
Repairs made after the lapse of the warranty period are subject to charge.
Service
GB
IE
The warranty is valid for material or manufacturing faults only, not for transport ►
damage, parts subject to wear or damage to fragile parts.
SIKP 2000 B2
Service Great Britain
Tel.: 0871 5000 720 (£ 0.10/Min.)
E-Mail: kompernass@lidl.gb
IAN 66570
Service Ireland
Tel.: 1890 930 034
(0,08 EUR/Min., (peak))
(0,06 EUR/Min., (off peak))
E-Mail: kompernass@lidl.ie
IAN 66570
15
Loading...
