HW-Q90R

Imagine the possibilities

Thank you fo r purchasing this Samsung product.

To receive more complete service, please register

your product at www.samsung.com/register

SAFETY INFORMATION

SAFETY WARNINGS

TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE THE COVER (OR BACK). NO USER-SERVICEABLE PARTS ARE INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. Refer to the table below for an explanation of symbols which may be on your Samsung product.

CAUTION

RISK OF E LECTRIC S HOCK.

DO NOT OP EN.

This symbol indicates that high voltage is present inside. It is dangerous to make any kind of contact with any internal part of this product.

This symbol indicates that this product has included important literature concerning operation and maintenance.

Class II product : This symbol indicates that it does not require a safety connection to electrical earth (ground).

If this symbol is not present on a product with a power cord, the product MUST have a reliable connection to protective earth (ground).

AC voltage : This symbol indicates that the rated voltage marked with the symbol is AC voltage.

DC voltage : This symbol indicates that the rated voltage marked with the symbol is DC voltage.

Caution, Consult instructions for use : This symbol instructs the user to consult the user manual for further safety related information.

WARNING

• To reduce the risk of re or electric shock, do not expose this appliance to rain or moisture.

• To prevent injury, this apparatus must be

securely attached to the oor/wall in

accordance with the installation instructions.

CAUTION

• Do not expose this apparatus to dripping or splashing. Do not put objects lled with

liquids, such as vases, on the apparatus.

• To turn this apparatus off completely, you must pull the power plug out of the wall socket. Consequently, the power plug must be easily and readily accessible at all times.

CAUTION (for Canada)

This device contains licence-exempt transmitter(s)/receiver(s) that comply with Innovation, Science and Economic Development Canada’s licence-exempt RSS(s). Operation is subject to the following two conditions: (1) This device may not cause interference. (2) This device must accept any interference, including interference that may cause undesired operation of the device. This device and its antenna(s) must not be colocated or operation in conjunction with any other antenna or transmitter. This device may automatically discontinue transmission if there is no information to transmit, or an operational failure. Note that this is not intended to prohibit the transmission of control or signaling information or the use of repetitive codes where required by the technology.

This Class B digital apparatus complies with Canadian ICES-003.

ENG - ii

Radiation Exposure Statement

This equipment complies with IC RSS-102 radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20 cm between the radiator & your body.

Important Safety Instructions

Read these operating instructions carefully before using the unit. Follow all the safety instructions listed below. Keep these operating instructions handy for future reference.

1. Read these instructions.

2. Keep these Instructions.

3. Heed all warnings.

4. Follow all instructions.

5. Do not use this apparatus near water.

6. Clean only with dry cloth.

7. Do not block any ventilation openings.

Install in accordance with the manufacturer’s instructions.

8. Do not install near any heat sources such as radiators, heat registers, stoves, or other

apparatus (including ampliers) that produce

heat.

9. Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has two blades with one wider than the other. A grounding type plug has two blades and a third grounding prong. The wide blade or the third prong are provided for your safety. If the provided plug

does not t into your outlet, consult an

electrician for replacement of the obsolete outlet.

10. Protect the power cord from being walked on or pinched particularly at plugs, convenience receptacles, and the point where they exit from the apparatus.

11. Only use attachments/accessories specied

by the manufacturer.

12. Use only with the cart, stand, tripod, bracket, or table

specied by the manufacturer,

or sold with the apparatus. When a cart is used, use caution when moving the cart/apparatus combination to avoid injury from tip-over.

13. Unplug this apparatus during lightning storms or when unused for long periods of time.

14. Refer all servicing to qualied service

personnel. Servicing is required when the apparatus has been damaged in any way, such as power-supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped.

ENG - iii

PRECAUTIONS

1. Ensure that the AC power supply in your

house complies with the power

requirements listed on the identication

sticker located on the bottom of your product. Install your product horizontally, on a suitable base (furniture), with enough space around it for ventilation (3~4 inches). Make sure the ventilation slots are not

covered. Do not place the unit on ampliers

or other equipment which may become hot. This unit is designed for continuous use. To fully turn off the unit, disconnect the AC plug from the wall outlet. Unplug the unit if you intend to leave it unused for a long period of time.

2. During thunderstorms, disconnect the AC plug from the wall outlet. Voltage peaks due to lightning could damage the unit.

3. Do not expose the unit to direct sunlight or other heat sources. This could lead to overheating and cause the unit to malfunction.

4. Protect the product from moisture (i.e.

vases), and excess heat (e.g. a replace) or

equipment creating strong magnetic or

electric elds. Unplug the power cable from

the AC wall socket if the unit malfunctions. Your product is not intended for industrial use. It is for personal use only. Condensation may occur if your product has been stored in cold temperatures. If transporting the unit during the winter, wait approximately 2 hours until the unit has reached room temperature before using.

5. The battery used with this product contains chemicals that are harmful to the environment. Do not dispose of the battery in the general household trash. Do not expose the battery to excess heat, direct

sunlight, or re. Do not short circuit,

disassemble, or overheat the battery. Danger of explosion if the battery is replaced incorrectly. Replace only with the same or equivalent type.

ENG - iv

ABOUT THIS MANUAL

The user manual has two parts: this simple paper USER MANUAL and a detailed FULL MANUAL you can download.

USER MANUAL

See this manual for safety instructions, product installation,

components, connections, and product specications.

FULL MANUAL

You can access the FULL MANUAL on Samsung’s on-line customer support center by scanning the QR code on the left. To see the manual on your PC or mobile device, download the manual in document format from Samsung’s website. (http://www.samsung.com/support)

Design, specications, and App screen are subject to change without prior notice.

ENG - v

CONTENTS

01 Checking the Components 2

Inserting Batteries before using the Remote Control (AA batteries X 2) ------------------------- 2

02 Product Overview 3

Front Panel / Top Panel of the Soundbar ------------------------- 3

Bottom Panel of the Soundbar ------------------------- 4

03 Connecting the Soundbar 5

Connecting Electrical Power

Connecting the Soundbar to the Subwoofer and Surround Speakers

–

Recommended Speaker Layout ------------------------- 6

– Automatic connection between the Subwoofer or Surround Speakers

and the Soundbar

– Manually connecting the Subwoofer or Surround Speakers if

automatic connection fails

-------------------------

04 Connecting to your TV 9

Method 1. Connecting with a Cable

– Connecting a TV using an HDMI Cable – Connecting using an Optical Cable

Method 2. Connecting Wirelessly

– Connecting a TV via Bluetooth – Connecting via Wi-Fi

-------------------------

05 Connecting an External Device 15

Connecting using an HDMI Cable (Capable of Dolby Atmos decoding and playback)

Connecting using an HDMI Cable

Connecting using an Optical Cable

-------------------------

06 Connecting a Mobile Device 18

Connecting via Bluetooth

Connecting via Wi-Fi (Wireless Network)

-------------------------

ENG - vi

07 Connecting an Amazon product 23

Connect and use with an Amazon product (Amazon Echo) ------------------------- 23 Use voice commands to control the Soundbar

-------------------------

08 Using the Remote Control 26

How to Use the Remote Control

Adjusting the Soundbar volume with a TV remote control

Using the Hidden Buttons (Buttons with more than one function)

Output specications for the different sound effect modes

-------------------------

09 Installing the Wall Mount 31

Installation Precautions

Wallmount Components

Installing the Surround Speakers on a Wall (Sold Separately)

-------------------------

10 Installing the Soundbar above a TV Stand 34

Component

-------------------------

11 Software Update 34

12 Troubleshooting 35

13 License 36

14 Open Source License Notice 37

15 Important Notes About Service 37

16 SpecicationsandGuide 38

Specications

-------------------------

ENG - vii

01 CHECKING THE COMPONENTS

POWER

PAIR

SOUND MODE

VOL WOOFER

SOUNDBAR

Soundbar Main Unit Remote Control

/ Bat teries

1 2 3

Subwoofer Surround Speaker

x 2

(Lef t / Right)

x 2

Power Cord

(Subwoofer)

Power Cord

(Surround Speaker)

Power Cord

(Main Unit)

x 2

HDMI Cable Bracket-Wall

Mount

x 2

x 4

(M4 x L10)

Wall Mount Guide Holder-Screw Screw Rubber-Foot

• For more information about the power supply and power consumption, refer to the label attached to the product. (Label: Bottom of the Soundbar Main Unit)

• The power components are labelled (1, 2, 3). For more information about power connections, see page 5.

• To distinguish the left surround speaker from the right, check the label on the rear of each speaker.

• To purchase additional components or optional cables, contact a Samsung Service Center or Samsung Customer Care.

• The appearance of the accessories may differ slightly from the illustrations above.

Inserting Batteries before using the Remote Control (AA batteries X 2)

Slide the battery cover in the direction of the arrow until it is completely removed. Insert 2 AA batteries (1.5V) oriented so that their polarity is correct. Slide the battery cover back into position.

ENG - 2

02 PRODUCT OVERVIEW

Front Panel / Top Panel of the Soundbar

Position the product so that the "Samsung Harman Kardon" logo is located on the top.

(Power) Button

Turns the power on and off.

• Auto Power Down Function

󱂓

The unit turns off automatically in the following situations:

– In D.IN / HDMI 1 / HDMI 2 / WIF I / BT mode if there is no audio signal for 18 minutes.

(Source) But ton

Selects the source input mode.

Optical Digital input D.IN

󱂔

ARC (HDMI OUT) input D.IN  TV ARC (Auto conversion)

BLUETOOTH mode BT

Input mode Display

HDMI input HDMI 1 / HDMI 2

Wi-Fi mode WIFI

Top

Panel

󱂓 󱂔 󱂕

󱂖

-/+ (Volume) But ton

Adjusts the volume.

󱂕

• When adjusted, the volume level appears on the Soundbar’s front display.

Display

󱂖

Displays the produc t’s status and current mode.

• When you plug in the AC cord, the power button will begin working in 4 to 6 seconds.

• When you turn on this unit, there will be a 4 to 5 second delay before it produces sound.

• If you want to enjoy sound only from the Soundbar, you must turn off the TV’s speakers in the Audio Setup menu of your TV. Refer to the owner’s manual supplied with your TV.

ENG - 3

Bottom Panel of the Soundbar

SERVICE

NETWORK

ID SET (WOOFER/REAR)

DIGITAL AUDIO IN

(OPTICAL)

HDMI IN 1

HDMI IN 2

HDMI OUT (TV-ARC)

DIGITAL AUDIO IN

(OPTICAL)

HDMI IN 1

HDMI IN 2

HDMI OUT

(TV-ARC)

POWER

SERVICE

NETWORK

ID SET (WOOFER/REAR)

DIGITAL AUDIO IN

(OPTICAL)

HDMI IN 1

HDMI IN 2

HDMI OUT (TV-ARC)

DIGITAL AUDIO IN

(OPTICAL)

HDMI IN 1

HDMI IN 2

HDMI OUT

(TV-ARC)

SERVICE

NETWORK

ID SET (WOOFER/REAR)

󱂕󱂔 󱂖

POWER

ID SET (WOOFER/REAR)

󱂓

POWER

󱂓

Connect the Soundbar's AC power cord.

POWER

NETWORK

ID SET (WOOFER/REAR)

Press to connect the Soundbar to surround speakers and a subwoofer wirelessly.

󱂔

• Press and hold the Up button on the remote for 5 seconds to complete ID SET.

NETWORK

󱂕

Press to connect to a wireless network (Wi-Fi) via the SmartThings app.

SERVICE

󱂖

Connect a USB storage device to upgrade the product's software.

DIGITAL AUD IO IN (OPTIC AL)

󱂗

Connect to the digital (optical) output of an external device.

SERVICE

ID SET (WOOFER/REAR)

NETWORK

DIGITAL AUDIO IN

(OPTICAL)

HDMI IN 1

HDMI IN 2

HDMI OUT

(TV-ARC)

(OPTICAL)

HDMI IN 1

HDMI IN 2

HDMI OUT (TV-ARC)

󱂗

󱂘

󱂙

HDMI IN 1 / HD MI IN 2

Inputs digital video and audio signals simultaneously using an HDMI cable.

󱂘

Connect to the HDMI output of an external device.

HDMI OUT (TV-ARC)

󱂙

Connect to the HDMI (ARC) jack on a TV.

• When disconnecting the power cord from a wall outlet, pull the plug. Do not pull the cable.

• Do not connect this unit or other components to an AC outlet until all connections between components are complete.

ENG - 4

03 CONNECTING THE SOUNDBAR

SERVICE

NETWORK

ID SET (WOOFER/REAR)

DIGITAL AUDIO IN

(OPTICAL)

HDMI IN 1

HDMI IN 2

HDMI OUT

(TV-ARC)

Connecting Electrical Power

Use the power components (1, 2 electrical outlet in the following order:

, 3

) to connect the Subwoofer, Surround Speaker, and Soundbar to an

1 Connect the power cord to the Subwoofer. 2 Connect the power cord to the Left and Right Surround Speakers.

Connect the power cord to the Soundbar.

See the illustrations below.

• For more information about the required electrical power and power consumption, refer to the label attached to the product. (Label: Bottom of the Soundbar Main Unit)

2 Power Cord

Connecting

Electric al Power

POWER

Rear of Subwoofer

1 Power Cord

Connecting

Electric al Power

POWER

Bott oms of the Lef t and Right Surround

Speakers

POWER

Bott om of the Soundba r

Main Unit

POWER

3 Power Cord

Connecting Ele ctrical Power

ENG - 5

Connecting the Soundbar to the Subwoofer and Surround Speakers

When the Subwoofer is connected, you can enjoy rich bass sound.

Recommended Speaker Layout

CAUTION

Soundbar

Subwoofer

135° 135°

Surround Speaker L Surround Speaker R

0°

150° 150°

• Wireless receiving antennas are built into the wireless subwoofer and surround speakers. Keep the units away from water and moisture.

• For optimal listening performance, make sure that the areas around the wireless subwoofer and surround speakers locations are clear of any obstructions.

Automatic connection between the Subwoofer or Surround Speakers and the Soundbar

The subwoofer and/or Surround speakers will connect to the Soundbar automatically if they are plugged in to electrical outlets.

• When auto pairing is complete, the blue indicators at the rear of the Subwoofer or Surround Speaker turn on.

LED Indicator Lights on the Rear of Subwoofer and Surround Speakers

LED Status Description Resolution

Successfully connected (normal operation)

Standby (with the Soundbar main unit turned off)

Connection failed

Check if the power cable attached to the main Soundbar unit is connected properly or wait about 5 minutes. If blinking persists, try manually connecting the subwoofer. See page 7.

Check if the power cable attached to the main Soundbar unit is connected properly.

Connect again. See the instructions for manual connection on page 7.

See the contact information for the Samsung Service Center in this manual.

Blue

Red On

Red and

blue

Blinking Recovering the connection

Blinking Malfunction

ENG - 6

Manually connecting the Subwoofer or Surround Speakers if automatic connection fails

POWER

Before per forming the manual connection procedure below:

• Check whether the power cables for the Soundbar and subwoofer or Surround Speakers are connected properly.

• Make sure that the Soundbar is turned on.

1. Press and hold ID SET on the rear of the subwoofer and surround speakers for at least 5 seconds.

• The red indicator at the rear of each speaker turns off and the blue indicator blinks.

5 Sec

Rear of Subwoofer

5 Sec

Blue LED B linking Fast

x 2

Rear of th e Left and Righ t Surround Speaker s

2. Press and hold the Up button on the remote control for at least 5 seconds.

• The ID SET message appears on the display of the Soundbar for a moment, and then it disappears.

• The Soundbar will automatically power on when ID SET is complete.

PAIR

5 Sec

“Sam sung Harman Kard on” logo is on the top

ENG - 7

ID SET

3. Check if the LINK LED is solid blue (connection complete).

LINK LED - B lue is On

When the connection is successfully established, the blue indicators on the rear of the subwoofer and surround speakers turn on without blinking.

NOTES

• Do not connect the power cord of this product or your TV to a wall outlet until all connections between components are complete.

• Before moving or installing this product, be sure to turn off the power and disconnect the power cord.

• If the main unit is powered off, the wireless subwoofer will go into stand-by mode and the STANDBY LED on the rear of the sub-woofer will turn red after blinking in blue several times.

• If you use a device that uses the same frequency (5.8GHz) as the Soundbar near the Soundbar, interference may cause some sound interruption.

• The maximum transmission distance of the main unit’s wireless signal is about 32.8 ft, but may vary depending on your operating environment. If a steel-concrete or metallic wall is between the main unit and the wireless subwoofer, the system may not operate at all because the wireless signal cannot penetrate metal.

PRECAUTIONS

• Wireless receiving antennas are built into the wireless subwoofer. Keep the unit away from water and moisture.

• For optimal listening performance, make sure that the area around the wireless subwoofer and surround speakers location is clear of any obstructions.

ENG - 8

04 CONNECTING TO YOUR TV

Hear TV sound from your Soundbar through wired or wireless connections.

• When the Soundbar is connected to selected Samsung TVs, the Soundbar can be controlled using the TV’s remote control.

– This feature is available on 2017 and later Samsung Smart TVs that support Bluetooth when

the Soundbar is connected to the TV using an optical cable.

– This function also allows you to use the TV menu to adjust the sound eld and various settings

as well as the volume and mute.

Method 1. Connecting with a Cable

When the audio in a broadcast is encoded in Dolby Digital and the “Digital Output Audio Format” on your TV is set to PCM, we recommend that you change the setting to Dolby Digital. When the setting on the TV is changed, you will experience better sound quality. (The TV menu may use different words for Dolby Digital and PCM depending on the TV manufacturer.)

Connecting a TV using an HDMI Cable

Connec t to the HDMI IN

(ARC) p ort of your T V.

HDMI Cable

Bott om of the Soundba r

󱂓

HDMI IN

(ARC)

Connec t to the HDMI OUT ( TV-ARC)

port o f the Soundbar mai n unit.

Top of the Soun dbar

HDMI OUT

(TV-ARC)

󱂔

TV ARC

1. With the Soundbar and TV turned on, connect the HDMI cable as shown in the gure.

2. “TV ARC” appears in the display window of the Soundbar main unit and the Soundbar plays TV

sound.

• If TV sound is inaudible, press the (Source) button on the remote control or on the top of the Soundbar to switch to “D.IN” mode. The screen displays “D.IN” and “TV ARC” in sequence, and TV sound is played.

ENG - 9

• If “T V ARC” does not appear in the display window of the Soundbar main unit, conrm that the HDMI cable is connected to the correct port.

• Use the volume buttons on the TV’s remote control to change the volume on the Soundbar.

NOTES

• HDMI is an interface that enables the digital transmission of video and audio data with just a single connector.

• If the TV provides an ARC port, connect the HDMI cable to the HDMI IN (ARC) port.

• We recommend you use a coreless HDMI cable if possible. If you use a cored HDMI cable, use one whose diameter is less than 0.55 inches (14 mm).

• Anynet+ must be turned on.

• This function is not available if the HDMI cable does not support ARC.

Connecting using an Optical Cable

Optic al Cable (not supplied)

󱂓

OPTICAL OUT

Top of the Soun dbar

Bott om of the Soundba r

DIGITAL AUDIO IN

(OPTICAL)

󱂔

D.IN

1. Connect the DIGITAL AUDIO IN (OP TICAL) jack on the Soundbar to the OPTICAL OUT jack of the TV

with a digital optical cable (not supplied).

2. Press the (Source) button on the top panel or on the remote control, and then select the “D.IN” mode.

ENG - 10

Auto Power Link

Auto Power Link automatically turns on the Soundbar when the TV is turned on.

1. Connect the Soundbar and a TV with a digital optical cable (not supplied).

2. Press the Left button on the remote control for 5 seconds to turn Auto Power

Link on or off.

• Auto Power Link is set to ON by default. (To turn off this function, press the Left button on the remote for 5 seconds.)

• Depending on the connected device, Auto Power Link may not function.

• This function is only available in the “D.IN” mode.

Method 2. Connecting Wirelessly

Connecting a TV via Bluetooth

When a TV is connected using Bluetooth, you can hear stereo sound without the hassle of cabling.

• Only one TV can be connected at a time.

Top of the Soun dbar

PAIR

The initial connection

1. Press the PAIR button on the remote control to enter the “BT PAIRING” mode.

(OR)

a. Press the (Source) button on the top panel and then select “BT”.

“BT” changes to “BT READY” in a few seconds automatically if there is no Bluetooth device connected to the Soundbar.

b. When “BT READY” appears, press and hold the (Source) button on the top panel of the

Soundbar for more than 5 seconds to display “BT PAIRING”.

2. Select Bluetooth mode on the TV. (For more information, see the TV’s manual.)

3. Select “[AV] Samsung Soundbar Q90R” from the list on TV’s screen.

An available Soundbar is indicated with “Need Pairing” or “Paired” on the TV’s Bluetooth device list. To connect the TV to the Soundbar, select the message, and then establish a connection.

• When the TV is connected, [T V Name] → “BT” appears on the Soundbar’s front display.

4. You can now hear TV sound from the Soundbar.

ENG - 11

If the device fails to connect

• If a previously connected Soundbar (e.g. “[AV] Samsung Soundbar Q90R”) appears in the list, delete it.

• Then repeat steps 1 through 3.

NOTE

• After you have connected the Soundbar to your TV the rst time, use the “BT READY” mode to reconnect.

Disconnecting the Soundbar from the TV

Press the (Source) button on the top panel or on the remote control and switch to any mode but “BT”.

• Disconnecting takes time because the TV must receive a response from the Soundbar. (The time required may differ, depending on the TV model.)

• To cancel the automatic Bluetooth connection between the Soundbar and TV, press the p (Play/Pause) button on the remote control for 5 seconds with the Soundbar in “BT READY” status.

(Toggle On → Off)

What is the difference between BT READY and BT PAIRING?

• BT READY : In this mode, you can search for previously connected TVs or connect a previously connected mobile device to the Soundbar.

• BT PAIRING : In this mode, you can connect a new device to the Soundbar. (Press the PAIR button on the remote control or press and hold the (Source) button on the top of the Soundbar for more than 5 seconds while the Soundbar is in “BT” mode.)

NOTES

• If asked for a PIN code when connecting a Bluetooth device, enter <0000>.

• In Bluetooth connection mode, the Bluetooth connection will be lost if the distance between the Soundbar and the Bluetooth device exceeds 32.8 ft (10 m).

• The Soundbar automatically turns off after 18 minutes in the Ready state.

• The Soundbar may not perform Bluetooth search or connection correctly under the following circumstances:

– If there is a strong electrical eld around the Soundbar. – If several Bluetooth devices are simultaneously paired with the Soundbar. – If the Bluetooth device is turned off, not in place, or malfunctions.

• Electronic devices may cause radio interference. Devices that generate electromagnetic waves must be kept away from the Soundbar main unit - e.g., microwaves, wireless LAN devices, etc.

ENG - 12

Connecting via Wi-Fi

Pre-connection Checklist

1. Conrm that your Samsung Smart TV was released af ter 2013. This function is compatible only

with Samsung Smart TVs released after 2013.

2. Make sure your Wireless router (Wi-Fi) is ready and working.

3. Make sure that the TV is connected to the Wireless router (your Wi-Fi network).

Top of the Soun dbar

Mobile device

Step 1 : Connecting the Soundbar to Wi-Fi

1. Press the (Source) button on the top of the Soundbar or on the remote control to select “WIFI”

mode.

• When using selected Samsung TVs (2016 ~ 2018 Samsung Smart TVs that support Bluetooth.) – If you select “WIFI” mode when the TV is turned on, the TV screen displays a pop-up

window providing instructions on how to automatically connect the Soundbar to a wireless router (Wi-Fi). Refer to the instructions in the pop-up window of the TV.

Top of the Soun dbar

WIFI

2. Connect your mobile device (smartphone, tablet, etc.) to the Wi-Fi network the TV is connected to.

3. Install and launch the SmartThings app on your mobile device (smartphone, tablet, etc.).

iOSAndroid

4. Follow the instructions in the app screen on the mobile device to connect the Soundbar to your Wi-Fi network.

ENG - 13

SmartThings app

Step2:ConguringSettingsontheTV

• If the TV disconnects from your wireless network after you change the input source to the Soundbar, use the TV menu to connect the TV to the network again.

For TVs released in 2019 Home ( )  Settings ( )  Sound  Sound Output  [AV] Samsung Soundbar Q90R (Wi-Fi)

For TVs released in 2018 Home ( )  Settings ( )  Sound  Sound Output  [AV] Samsung Soundbar Q90R (Wi-Fi)

For TVs released in 2017 Home ( )  Settings ( )  Sound  Sound Output  [AV] Samsung Soundbar Q90R (Wi-Fi)

For TVs released in 2016 Home ( )  Settings ( )  Sound  Select Speaker  [AV] Samsung Soundbar Q90R (Wi-Fi)

For TVs released in 2015

Menu  Sound  Speaker List

For TVs released in 2014

Menu  Sound  Speaker Settings  Multiroom Link - Settings

NOTES

• The TV and Soundbar must be connected to the same wireless network (Wi-Fi).

• If your wireless router (Wi-Fi) uses a DFS channel, you will not be able to establish a Wi-Fi connection between the TV and Soundbar. Contact your Internet service provider for details.

• If the 5GHz Wi-Fi connection is not smooth, use the 2.4GHz bandwidth.

• Because the menus may differ depending on the year of manufacture, refer to your TV manual.

ENG - 14

05 CONNECTING AN EXTERNAL DEVICE

DIGITAL AUDIO IN

(OPTICAL)

Connect to an external device via a wired or wireless network to play the external device’s sound through the Soundbar.

Connecting using an HDMI Cable (Capable of Dolby Atmos decoding and playback)

• When you use Dolby Atmos®: If the input source is Dolby Atmos®, 7.1.4 channels are outputted. When Dolby Atmos® is active, the Soundbar’s sound effect modes controlled by the SOUND MODE button are not available.

• Important: This product supports Dolby Atmos® only in HDMI mode.

Top of the Soun dbar

HDMI 1

HDMI 2

HDMI Cable

󱂓

HDMI OUT

External Dev ice

󱂔

HDMI IN

(ARC)

1. Connect an HDMI cable from the HDMI IN 1 or HDMI IN 2 jack on the bottom of the Soundbar to the HDMI OUT jack on your digital device.

2. Connect an HDMI cable from the HDMI OUT (TV-ARC) jack on the bottom of the Soundbar to the HDMI IN jack on your TV.

3. Press the (Source) button on the top panel or on the remote control, and then select “HDMI 1” or “HDMI 2”.

4. “HDMI 1” or “HDMI 2” mode is displayed on the Soundbar display panel and sound plays.

HDMI Cable

ENG - 15

HDMI IN 1

HDMI IN 2

HDMI OUT

(TV-ARC)

Bott om of the Soundba r

NOTE

DIGITAL AUDIO IN

(OPTICAL)

• When Dolby Atmos® is activated, “DOLBY ATMOS” appears in the front display.

ConguringDolbyAtmos®onyourBDplayerorotherdevice.

• Open the audio output options on the settings menu of your BD player or other device and make sure that “No Encoding” is selected for Bitstream. For example, on a Samsung BD Player, go to

Home Menu → Sound → Digital Output and then select Bitstream (unprocessed).

• If the Audio Output options include Secondary Audio, make sure Secondary Audio is set to Off.

• Make sure that the content supports Dolby Atmos®.

Connecting using an HDMI Cable

Top of the Soun dbar

HDMI 1

HDMI 2

HDMI IN 1

HDMI IN 2

HDMI OUT

(TV-ARC)

Bott om of the Soundba r

External Dev ice

HDMI OUT

HDMI IN

(ARC)

HDMI Cable

󱂓

HDMI Cable

󱂔

1. Connect an HDMI cable from the HDMI IN 1 or HDMI IN 2 jack on the bottom of the Soundbar to the HDMI OUT jack on your digital device.

2. Connect an HDMI cable from the HDMI OUT (TV-ARC) jack on the bottom of the Soundbar to the HDMI IN jack on your TV.

3. Press the (Source) button on the top panel or on the remote control, and then select “HDMI 1” or “HDMI 2”.

4. “HDMI 1” or “HDMI 2” mode is displayed on the Soundbar display panel and sound plays.

ENG - 16

Connecting using an Optical Cable

Top of the Soun dbar

BD / DVD play er / Set-top box /

Game cons ole

󱂔

D.IN

󱂓

OPTICAL OUT

1. Connect DIGITAL AUDIO IN (OPTICAL) on the main unit to the OPTICAL OUT jack of the Source Device using a digital optical cable (not supplied).

2. Select “D.IN” mode by pressing the (Source) button on the top panel or on the remote control.

Optic al Cable

(not supplied)

DIGITAL AUDIO IN

(OPTICAL)

Bott om of the Soundba r

ENG - 17

06 CONNECTING A MOBILE DEVICE

Connecting via Bluetooth

When a mobile device is connected using Bluetooth, you can hear stereo sound without the hassle of cabling.

• You cannot connect more than one Bluetooth device at a time.

Top of the Soun dbar

PAIR

Bluetooth device

The initial connection

1. Press the PAIR button on the remote control to enter the “BT PAIRING” mode.

(OR)

a. Press the (Source) button on the top panel and then select “BT”.

“BT” changes to “BT READY” in a few seconds automatically if there is no Bluetooth device connected to the Soundbar.

b. When “BT READY” appears, press and hold the (Source) button on the top panel of the

Soundbar for more than 5 seconds to display “BT PAIRING”.

2. On your device, select “[ AV] Samsung Soundbar Q90R” from the list that appears.

• When the Soundbar is connected to the Bluetooth device, [Bluetooth Device Name] → “BT” appears in the front display.

3. Play music les from the device connected via Bluetooth through the Soundbar.

If the device fails to connect

• If a previously connected Soundbar (e.g. “[AV] Samsung Soundbar Q90R”) appears in the list, delete it.

• Then repeat steps 1 and 2.

NOTE

• After you have connected the Soundbar to your mobile device the rst time, use the “BT READY” mode to reconnect.

ENG - 18

What is the difference between BT READY and BT PAIRING?

• BT READY : In this mode, you can search for previously connected TVs or connect a previously connected mobile device to the Soundbar.

NOTES

• If asked for a PIN code when connecting a Bluetooth device, enter <0000>.

• In Bluetooth connection mode, the Bluetooth connection will be lost if the distance between the Soundbar and the Bluetooth device exceeds 32.8 ft (10 m).

• The Soundbar automatically turns off after 18 minutes in the Ready state.

• The Soundbar may not perform Bluetooth search or connection correctly under the following circumstances:

• Electronic devices may cause radio interference. Devices that generate electromagnetic waves must be kept away from the Soundbar main unit - e.g., microwaves, wireless LAN devices, etc.

• The Soundbar supports SBC data (44.1kHz, 48kHz).

• Connect only to a Bluetooth device that supports the A2DP (AV) function.

• You cannot connect the Soundbar to a Bluetooth device that supports only the HF (Hands Free) function.

• Once you have paired the Soundbar to a Bluetooth device, selecting “[AV] Samsung Soundbar Q90R” from the device’s scanned devices list will automatically change the Soundbar to “BT” mode.

– Available only if the Soundbar is listed among the Bluetooth device’s paired devices.

(The Bluetooth device and the Soundbar must have been previously paired at least once.)

• The Soundbar will appear in the Bluetooth device’s searched devices list only when the Soundbar is displaying “BT READY”.

• The Soundbar cannot be paired to another Bluetooth device if already in Bluetooth mode and paired to a Bluetooth device.

ENG - 19

Disconnecting the Bluetooth device from a Soundbar

You can disconnect a Bluetooth device from the Soundbar. For instructions, see the Bluetooth device’s user manual.

• The Soundbar will be disconnected.

• When the Soundbar is disconnected from the Bluetooth device, the Soundbar will display “BT DISCONNECTED” on the front display.

Disconnecting the Soundbar from the Bluetooth device

Press the (Source) button on the top panel or on the remote control, and then change to any mode except “BT”.

• Disconnecting takes time because the Bluetooth device must receive a response from the Soundbar. (Disconnection time may differ, depending on the Bluetooth device)

• When the Soundbar is disconnected from the Bluetooth device, the Soundbar will display “BT DISCONNECTED” on the front display.

NOTES

• In Bluetooth connection mode, the Bluetooth connection will be lost if the distance between the Soundbar and the Bluetooth device exceeds 32.8 ft (10 m).

• The Soundbar automatically turns off after 18 minutes in the Ready state.

More About Bluetooth

Bluetooth is a technology that enables Bluetooth-compliant devices to interconnect easily with each other using a short wireless connection.

• A Bluetooth device may cause noise or malfunction, depending on usage, if:

– A part of your body is in contact with the receiving/transmitting system of the Bluetooth

device or the Soundbar. – It is subject to electrical variation from obstructions caused by a wall, corner, or ofce partition. – It is exposed to electrical interference from same frequency-band devices including medical

equipment, microwave ovens, and wireless LANs.

• Pair the Soundbar with the Bluetooth device while they are close together.

• The further the distance between the Soundbar and Bluetooth device, the worse the quality is. If the distance exceeds the Bluetooth operational range, the connection is lost.

• In poor reception areas, the Bluetooth connection may not work properly.

• The Bluetooth connection only works when it is close to the unit. The connection will be automatically cut off if the Bluetooth device is out of range. Even within range, the sound quality may be degraded by obstacles such as walls or doors.

• This wireless device may cause electric interference during its operation.

ENG - 20

Connecting via Wi-Fi (Wireless Network)

• Connect a single Soundbar to Wi-Fi to access a variety of music streaming services and Internet radio. Connect multiple Soundbars to Wi-Fi to use grouped playback or the stereo sound mode.

• To connect a Soundbar to a mobile device via a wireless network (Wi-Fi), the SmartThings app is required.

Top of the Soun dbar

Mobile device

The initial connection

1. Press the (Source) button on the top of the Soundbar or on the remote control to select “WIFI”

mode.

Top of the Soun dbar

WIFI

2. Install and launch the SmartThings app on your mobile device (e.g. smartphone or tablet).

iOSAndroid

ENG - 21

SmartThings app

3. Launch the app, and then follow the instructions on the screen to register (add) your Soundbar in

the app.

• The automatic pop-up (the third illustration below) may not be available on some mobile devices. If this is the case, select and complete “Add device” from the app menu. Your Soundbar is now added to the app.

Launch App Add speakersAuto pop-up

ENG - 22

+ 64 hidden pages
