HW-J560
HW-J561
User manual
Wireless Audio - Soundbar
Imagine the possibilities
Thank you for purchasing this Samsung product.
To receive more complete service, please register your product at
www.samsung.com/register
FEATURES
TV SoundConnect
TV SoundConnect lets you listen to audio from your TV on your Soundbar via a Bluetooth connection and lets you control the sound.
HDMI
HDMI transmits video and audio signals simultaneously, and provides a clearer picture.
The unit is also equipped with the ARC function which lets you listen to sound from your TV through the Soundbar via an HDMI cable. This function is only available if you connect the unit to an ARC compliant TV.
SURROUND SOUND
The SURROUND SOUND feature adds depth and spaciousness to your listening experience.
Wireless Subwoofer
Samsung’s wireless module does away with cables running between the main unit and the subwoofer. Instead, the subwoofer connects to a compact wireless module that communicates with the main unit.
Special Sound Effects
You can select different Sound Effects - STANDARD (Original Sound)/MUSIC / VOICE / SPORTS / CINEMA / NIGHT MODE - depending on the type of content you want to enjoy.
Multi-function Remote Control
You can use the supplied remote control to control various operations with the simple press of a button.
USB Host Support
You can connect and play music files from external USB storage devices such as MP3 players, USB flash memory, etc. using the Soundbar's USB HOST function.
Bluetooth Function
You can connect a Bluetooth device to the Soundbar and enjoy music with high quality stereo sound, all without wires!
Using the Samsung Audio Remote App
To control the product with your Smart Device via the Samsung Audio Remote app, download the Samsung Audio Remote App by accessing the app through Google Play store.
Manufactured under license from Dolby Laboratories. Dolby and the double-D symbol are trademarks of Dolby Laboratories.
For DTS patents, see http://patents.dts.com. Manufactured under license from DTS Licensing Limited. DTS, the Symbol, & DTS and the Symbol together are registered trademarks, and DTS 2.0 Channel is a trademark of DTS, Inc. © DTS, Inc. All Rights Reserved.
The terms HDMI and HDMI High-Definition Multimedia Interface, and the HDMI Logo are trademarks or registered trademarks of HDMI Licensing LLC in the United States and other countries.
2
SAFETY INFORMATION
TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE THE COVER (OR BACK).
NO USER-SERVICEABLE PARTS ARE INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
|
|
|
|
|
|
CAUTION |
|
|
The lighting flash and arrowhead within the triangle |
|
RISK OF ELECTRIC SHOCK. |
|
|
indicates that there is dangerous voltage Inside the |
|
|
|
product. |
|
|
DO NOT OPEN. |
|
|
|
|
|
|
|
|
|
|
|
|
|
CAUTION: TO REDUCE THE RISK OF ELECTRIC |
|
The explanation point within the triangle indicates |
||
SHOCK, DO NOT REMOVE THE COVER (OR BACK). |
|
|||
|
that there are important instructions accompanying |
|||
NO USER SERVICEABLE PARTS INSIDE. REFER |
|
|||
|
the product. |
|||
SERVICING TO QUALIFIED SERVICE PERSONNEL. |
|
|||
|
|
|||
|
|
|
|
|
WARNING
•To reduce the risk of fire or electric shock, do not expose this appliance to rain or moisture.
•To prevent injury, this apparatus must be securely attached to the floor/wall in accordance with the installation instructions.
•This product contains chemicals known to the State of California to cause cancer and reproductive toxicity.
CAUTION
•Do not expose this apparatus to dripping or splashing. Do not put objects filled with liquids, such as vases on the apparatus.
•To turn this apparatus off completely, you must pull the power plug out of the wall socket. Consequently, the power plug must be easily and readily accessible at all times.
ENG
3
SAFETY INFORMATION
SAFETY INFORMATION
PRECAUTIONS |
|
|
68.6mm |
99.1mm |
|
99.1mm |
99.1mm |
Ensure that the AC power supply in your house complies with the power requirements listed on the identification sticker located on the back of your product. Install your product horizontally, on a suitable base (furniture), with enough space around it for ventilation (3~4 inches, 7~10 cm). Make sure the ventilation slots are not covered. Do not place the unit on amplifiers or other equipment which may become hot. This unit is designed for continuous use. To fully turn off the unit, disconnect the AC plug from the wall outlet. Unplug the unit if you intend to leave it unused for a long period of time.
During thunderstorms, disconnect the AC plug from the wall outlet. Voltage peaks due to lightning could damage the unit.
Protect the product from moisture (i.e. vases), and excess heat (e.g. a fireplace) or equipment creating strong magnetic or electric fields. Unplug the power cable from the AC wall socket if the unit malfunctions. Your product is not intended for industrial use. It is for personal use only. Condensation may occur if your product has been stored in cold temperatures. If transporting the unit during the winter, wait approximately 2 hours until the unit has reached room temperature before using.
Do not expose the unit to direct sunlight or other heat sources. This could lead to overheating and cause the unit to malfunction.
The battery used with this product contains chemicals that are harmful to the environment. Do not dispose of battery in the general household trash. Do not expose the battery to excess heat, direct sunlight, or fire. Do not short circuit, disassemble, or overheat the battery. Danger of explosion if the battery is replaced incorrectly. Replace only with the same or equivalent type.
4
2 FEATURES
2Licenses
3SAFETY INFORMATION
3Safety Warnings
4Precautions
6 GETTING STARTED
6Before reading the User’s Manual
6What’s Included
7DESCRIPTIONS
7Top/Front Panel
8Rear Panel
9REMOTE CONTROL
9 Remote Control Buttons and Functions
11 CONNECTIONS
11Installing the Wall Mount
12Detaching the Wall Mount
12Installing the bracket without referring to the Wall-mount Installation Guide
13Connecting the Wireless Subwoofer
15Connecting an External Device using an HDMI cable
16Connecting an External Device using Audio (analog) cable or Optical (digital) cable
CONTENTS
ENG
17 FUNCTIONS
17 Input mode
17ARC (HDMI OUT)
18Bluetooth
20Using The Samsung Audio Remote App
21TV SoundConnect
22USB
23Software Update
24TROUBLESHOOTING
25APPENDIX
25 Specifications
●●Figures and illustrations in this User Manual are provided for reference only and may differ from actual product appearance.
●●An administration fee may be charged if either
(a)An engineer is called out at your request and there is no defect with the product (i.e. where the user manual has not been read).
(b)You bring the unit to a repair centre and there is no defect with the product (i.e. where the user manual has not been read).
●●You will be informed of the administration fee amount before a technician visits.
5
GETTING STARTED
Note the following terms before reading the user manual.
Icons used in this manual
Icon |
Term |
Definition |
Caution Indicates a situation where a function does not operate or settings may be canceled.
Note Indicates tips or instructions on the page that help you operate a function.
Safety Instructions and Troubleshooting
1)Be sure to familiarize yourself with the Safety Instructions before using this product. (See page 3)
2)If a problem occurs, check Troubleshooting. (See page 24)
Copyright
©2015 Samsung Electronics Co.,Ltd.
All rights reserved; no part of this user’s manual may be reproduced or copied without the prior written permission of Samsung Electronics Co.,Ltd.
Check for the supplied accessories shown below.
|
|
(Wall Mount L: 1EA) |
|
Remote Control / Lithium Battery |
|
(Wall Mount R: 1EA) |
|
User Manual |
Bracket-Wall Mount |
||
(3V : CR2032) |
|||
|
|
||
|
(Holder-screw1: 2EA) |
|
|
|
(Holder-screw2: 2EA) |
|
|
Wall Mount Guide |
Holder-screw |
Power Cord:2EA |
|
DC Adapter |
Optical cable |
USB Cable |
●● |
The appearance of the accessories may differ slightly from the illustrations above. |
|
|
●● |
Use the dedicated USB cable to connect external USB devices to the unit. |
|
|
|
|
|
|
6
(Power) Button
Turns the power on and off.
DESCRIPTIONS
ENG
VOL -/+
Controls the volume level.
The numeric value of the volume level appears in the front panel display.
Display
Displays the current mode.
●●If there is no input from the product or remote control for 25 seconds, the display will turn off automatically.
●●The display will not turn off automatically in the BT READY, SEARCH, or TV REQUEST modes.
(SOURCE) Button
Selects the D.IN, AUX, HDMI, BT, TV, USB input.
●●While the unit is powered on, pressing the ( ) button for more than 3 seconds sets the button to act as the MUTE button. To cancel MUTE button
setup, press the ( ) button for more than 3 seconds again.
●●When you turn on this unit, there will be a 4 to 5 second delay before it produces sound.
●●If you want to enjoy sound only from the Soundbar, you must turn off the TV's speakers in the Audio Setup menu of your TV. Refer to the owner's manual supplied with your TV.
7
DESCRIPTIONS
DESCRIPTIONS
HDMI IN
Inputs digital video and audio signals simultaneously using an HDMI cable. Use when connecting a supported external device.
AUX IN
Connect to the Analog output of an external device.
IN AUX |
IN HDMI |
(USB Port)
Connect USB devices such as MP3 players here to play files on the devices.
DC 24V (Power Supply In)
Connect the DC power adaptor to the power supply jack, and then connect the AC power adaptor plug to a wall outlet.
HDMI OUT(TV) OPTICAL IN
OPTICAL IN
Connect to the digital (optical) output of an external device.
HDMI OUT (TV-ARC)
Outputs digital video and audio signals simultaneously using an HDMI cable.
●●When disconnecting the power cable of the AC power adaptor from the wall outlet, pull the plug. Do not pull the cable.
●●Do not connect this unit or other components to an AC outlet until all connections between components are complete.
8
