SERVICE MANUAL
Level 1&2
RM-237
Transceiver characteristics:
Band: Tri-band phone for EGSM 900/1800/1900MHz Display: Active TFT color display with 262.144 colors, resolution 128 x 160 pixel
Camera: Integrated: 1.3 Megapixel camera with 8x digital zoom
Operating System: Series 40
Bluetooth IRDA
FM radio
Connector: mini USB Connector
Memory Card: microSD™
Transceiver with BL-5c Li-Ion battery pack
Talk time |
Standby |
Note |
|
|
|
|
|
up to 4h |
up to 16,5days |
Depends on network |
|
parameters |
|||
|
|
||
|
|
|
Environmental characteristics:
• Lead-free soldered
Service Manual 3110c RM-237 |
Copyright © 2007 NOKIA Corporation. All rights reserved. |
|
|
Page |
(37) |
Approved 2.0 |
CMO Operations & Logistics |
|
|
MGR |
|
Training and Vendor Development |
|
|
16.Mrz.2007 |
|
Multimedia Creation & Support |
COMPANY CONFIDENTIAL |
|||
TABLE OF CONTENTS |
|
|
Page |
|
1. |
INTRODUCTION |
|
|
3 |
2. |
GENERAL REPAIR INFORMATION |
|
|
4 |
3. |
PATHFINDER FOR WORKSHOP STAFF |
|
5 |
|
4. |
EXPLODED VIEW |
|
|
6 |
5. |
SPARE PARTS OVERVIEW |
|
|
7 |
6. |
GENERAL RECYCLING RECOMMENDATION |
|
8 |
|
7. |
LEVEL 2 SOLDER COMPONENTS |
|
|
9 |
8. |
NOKIA ONLINE (NOL) |
|
|
10 |
9. |
SERVICE TOOLS |
|
|
11 |
10. |
SW-UPDATE |
|
|
13 |
11. |
DISASSEMBLY INSTRUCTION |
|
|
14 |
12. |
ASSEMBLY HINTS |
|
|
21 |
13. |
DOME SHEET ALIGNMENT INSTRUCTION |
|
24 |
|
14. |
LEGEND FOR QUICK TROUBLE SHOOTER |
|
25 |
|
15. |
QUICK TROUBLE SHOOTER - POWER ON |
|
26 |
|
16. |
QUICK TROUBLE SHOOTER - CHARGING |
|
27 |
|
17. |
QUICK TROUBLE SHOOTER - NO SERVICE |
|
28 |
|
18. |
QUICK TROUBLE SHOOTER - EARPIECE |
|
29 |
|
19. |
QUICK TROUBLE SHOOTER - IHF SPEAKER |
|
30 |
|
20. |
QUICK TROUBLE SHOOTER - DISPLAY |
|
31 |
|
21. |
QUICK TROUBLE SHOOTER - MICROPHONE |
|
32 |
|
22. |
QUICK TROUBLE SHOOTER - KEYMAT |
|
33 |
|
23. |
QUICK TROUBLE SHOOTER - AV CONNECTOR |
|
34 |
|
24. |
QUICK TROUBLE SHOOTER - VOLUME KEYS |
|
35 |
|
25. |
QUICK TROUBLE SHOOTER - CARD READER |
|
36 |
|
26. |
QUICK TROUBLE SHOOTER - CAMERA |
|
37 |
|
|
|
|
CHANGE HISTORY |
|
|
|
|
Status |
Version No. |
Date |
Comments |
Draft |
0.1 |
03.Jan.2007 |
Initial draft |
|
|
|
|
Approved |
1.0 |
06.Mrz.2007 |
Approval |
Approved |
2.0 |
16.Mrz.2007 |
Disassembly/Assembly Hints updated |
|
|
|
|
Service Manual 3110c RM-237 |
Copyright © 2007 NOKIA Corporation. All rights reserved. |
|
Page |
(37) |
Approved 2.0 |
CMO Operations & Logistics |
|
|
MGR |
Training and Vendor Development |
|
|
16.Mrz.2007 |
Multimedia Creation & Support |
COMPANY CONFIDENTIAL |
||
1. INTRODUCTION
The purpose of this document is to help NOKIA service levels 1 and 2 workshop technicians to carry out service to NOKIA products. This Service Manual is to be used only by authorized NOKIA service suppliers, and the content of it is confidential. Please note that NOKIA provides also other guidance documents (e.g. Service Bulletins) for service suppliers, follow these regularly and comply with the given instructions.
While every endeavor has been made to ensure the accuracy of this document, some errors may exist. If you find any errors or if you have further suggestions, please notify NOKIA using the address below:
mailto:cc-ts-rc.documentation@nokia.com
Please keep in mind also that this documentation is continuously being updated and modified, so watch always out for the newest version.
Warnings and Cautions
Please refer to the phone’s user guide for instructions relating to operation, care and maintenance including important safety information. Note also the following:
Warnings:
1.CARE MUST BE TAKEN ON INSTALLATION IN VEHICLES FITTED WITH ELECTRONIC ENGINE MANAGEMENT SYSTEMS AND ANTI–SKID BRAKING SYSTEMS. UNDER CERTAIN FAULT CONDITIONS, EMITTED RF ENERGY CAN AFFECT THEIR OPERATION. IF NECESSARY, CONSULT THE VEHICLE DEALER/MANUFACTURER TO DETERMINE THE IMMUNITY OF VEHICLE ELECTRONIC SYSTEMS TO RF ENERGY.
2.THE HANDPORTABLE TELEPHONE MUST NOT BE OPERATED IN AREAS LIKELY TO CONTAIN POTENTIALLY EXPLOSIVE ATMOSPHERES, EG PETROL STATIONS (SERVICE STATIONS), BLASTING AREAS ETC.
3.OPERATION OF ANY RADIO TRANSMITTING EQUIPMENT, INCLUDING CELLULAR TELEPHONES, MAY INTERFERE WITH THE FUNCTIONALITY OF INADEQUATELY PROTECTED MEDICAL DEVICES. CONSULT A PHYSICIAN OR THE MANUFACTURER OF THE MEDICAL DEVICE IF YOU HAVE ANY QUESTIONS. OTHER ELECTRONIC EQUIPMENT MAY ALSO BE SUBJECT TO INTERFERENCE.
Cautions:
1.Servicing and alignment must be undertaken by qualified personnel only.
2.Ensure all work is carried out at an anti–static workstation and that an anti–static wrist strap is worn.
3.Use only approved components as specified in the parts list.
4.Ensure all components, modules screws and insulators are correctly re–fitted after servicing and alignment.
5.Ensure all cables and wires are repositioned correctly.
Electrostatic discharge can easily damage the sensitive components of electronic products. Therefore every Service Supplier has to take care of all precautions, which are mentioned in the service level related “Service Partner Requirements”, available on NOKIA Online. Also see ESD Protection Requirements in this Service Manual.
Service Manual 3110c RM-237 |
Copyright © 2007 NOKIA Corporation. All rights reserved. |
|
Page |
(37) |
Approved 2.0 |
CMO Operations & Logistics |
|
|
MGR |
Training and Vendor Development |
|
|
16.Mrz.2007 |
Multimedia Creation & Support |
COMPANY CONFIDENTIAL |
||
2. GENERAL REPAIR INFORMATION
In this section the technician will get some general hints how to carry out repairs:
•To familiarize oneself with NOKIA product read the tutorials or user guide on www.nokia.com -->Support--> Phones, by selecting the Phone Model.
•Before starting the repair you must take care of ESD precautions like being in your ESD Protected Area and connecting your wristband.
•Use gloves to avoid corrosion and fingerprints.
•Protect windows and displays with a film to avoid dust and scratches.
•When cleaning the LCD Module any lint-free cloth can be used (e.g. Micro-Fibre cloth).
•When cleaning the pads you have to use a soft cloth/ESD brush and Isopropanol. It is not allowed to use a glass fiber pencil because it scratches the surface and will lead later on to corrosion.
•Mechanical parts (except shielding lids and bent parts), which didn’t repair the failure, can be reused, if they are not soldered.
•When removing the shielding lids make sure to replace them with new ones, otherwise the high-frequency leakage can have an influence on the device.
•Always use original NOKIA spare parts.
•Check the soldering joints of the parts, which are concerned regarding the indicated error (e.g. soldered connectors or switches) and resolder them if necessary (Level 2 only).
•Remove redundant soldering flux after repair.
•Meet the torque requirements when assembling the unit (see also the document “torques for transceiver assembly” on NOKIA Partner Web Site/NOKIA Online).
•Always use your own equipment for testing where you are sure that it works. E.g. if the customer complains about charger function, please test the phone with your own charger to be sure if phone or charger causes the malfunction.
•A SIM card is needed for all GoNoGo tests.
•When doing the fault log entries, always note the Item code, which caused the malfunction. Also, fill in the appropriate part code from the assembly, if needed.
•Please be aware that some malfunctions could be software related and solved by an update.
•There are several documents available on NOL, which have to be followed:
•
•First, take care for the latest content pages of Service Bulletins, which are always available for each folder on NOKIA Online. This is also important to recognize, if existing documents have become invalid.
•
• The service level indicator at the bottom of each document tells the appropriate destination.
Downloads > Support Library >
1.Instructions
2.General Service Bulletins
3.Product related documents
4.Spare Part Service Bulletins
5.Service Tools Service Bulletins
6.Common Software Service Bulletins etc,…
Use General SB-217 as a reference or overview.
Please also check NOKIA Online (NOL) for latest news and files on a regular basis.
Service Manual 3110c RM-237 |
Copyright © 2007 NOKIA Corporation. All rights reserved. |
|
Page |
(37) |
Approved 2.0 |
CMO Operations & Logistics |
|
|
MGR |
Training and Vendor Development |
|
|
16.Mrz.2007 |
Multimedia Creation & Support |
COMPANY CONFIDENTIAL |
||
3. PATHFINDER FOR WORKSHOP STAFF
This is the NOL page (NOKIA Online) which is currently available in Europa, Middle East and Africa only!
In addition to the information in this Service Manual, there are several instructions and information, which have to be followed. Main documentation database is NOKIA Online with the purpose of serving different multimedia content, like video clips or interactive tutorials.
It is mandatory to watch for newest technical and organizational information on a daily basis to be updated as required (see “Latest files in Support Library”). Every new information has to be processed and implemented as soon as possible.
When logged into NOL you can also find needed information in different folder like:
Support Library
Phones
Service Manuals
Service Bulletins
Software
Repair Information
Level 1&2 e-learning (former NOKIA CarePoint) on NOKIA Online
Former NOKIA CarePoint |
• |
Online Troubleshooting |
can be found on |
|
• |
Product information |
|||
content, such as |
NOKIA Online |
|||
• |
Videos – Disassembly/Assembly |
|||
|
|
|||
|
|
|
NOKIA Online |
Care Services
Training
Phone Models
Level 1&2 e-learning courses offer a quick overview of the NOKIA phone and support for how to repair and use the phone:
Overview & Guides |
Disassembly & Assembly |
Troubleshooting |
Basic information about the phone, |
Instructions how to disassemble and |
Step-by-step instructions on how to |
features and technologies |
assemble the phone |
locate and repair the most common |
|
|
problems with the phone |
To reduce the server traffic it is recommended to download newest version of huge files like videos, Phoenix packages or Service Manuals only once and distribute it internally for further use.
Service Manual 3110c RM-237 |
Copyright © 2007 NOKIA Corporation. All rights reserved. |
|
Page |
(37) |
Approved 2.0 |
CMO Operations & Logistics |
|
|
MGR |
Training and Vendor Development |
|
|
16.Mrz.2007 |
Multimedia Creation & Support |
COMPANY CONFIDENTIAL |
||
4. EXPLODED VIEW
See corresponding ITEM/CIRCUIT REF in the Spare Parts Service Bulletins on NOL.
Service Manual 3110c RM-237 |
Copyright © 2007 NOKIA Corporation. All rights reserved. |
|
Page |
(37) |
Approved 2.0 |
CMO Operations & Logistics |
|
|
MGR |
Training and Vendor Development |
|
|
16.Mrz.2007 |
Multimedia Creation & Support |
COMPANY CONFIDENTIAL |
||
5. SPARE PARTS OVERVIEW
Service Manual 3110c RM-237 |
Copyright © 2007 NOKIA Corporation. All rights reserved. |
|
Page |
(37) |
Approved 2.0 |
CMO Operations & Logistics |
|
|
MGR |
Training and Vendor Development |
|
|
16.Mrz.2007 |
Multimedia Creation & Support |
COMPANY CONFIDENTIAL |
||
6. GENERAL RECYCLING RECOMMENDATION
Service Manual 3110c RM-237 |
Copyright © 2007 NOKIA Corporation. All rights reserved. |
|
Page |
(37) |
Approved 2.0 |
CMO Operations & Logistics |
|
|
MGR |
Training and Vendor Development |
|
|
16.Mrz.2007 |
Multimedia Creation & Support |
COMPANY CONFIDENTIAL |
||
7. LEVEL 2 SOLDER COMPONENTS
Service Manual 3110c RM-237 |
Copyright © 2007 NOKIA Corporation. All rights reserved. |
|
Page 10 (37) |
Approved 2.0 |
CMO Operations & Logistics |
|
MGR |
Training and Vendor Development |
|
16.Mrz.2007 |
Multimedia Creation & Support |
COMPANY CONFIDENTIAL |
8. NOKIA ONLINE (NOL)
NOL is the database where you can find the latest corresponding Service Bulletins (spare parts, SWAP units and service tools).
This will ensure, that you are using up-to-date order codes only.
Therefore Service Bulletins have to be checked from NOL on daily basis.
Service Manual 3110c RM-237 |
Copyright © 2007 NOKIA Corporation. All rights reserved. |
|
Page 11 (37) |
Approved 2.0 |
CMO Operations & Logistics |
|
MGR |
Training and Vendor Development |
|
16.Mrz.2007 |
Multimedia Creation & Support |
COMPANY CONFIDENTIAL |
9. SERVICE TOOLS
FLS-5 incl. ACF-8, Driver and User Guide
Dongle and flash device incorporated into one package, developed specifically for POS use.
ACF-8
Universal Power Supply is used to power FLS-4S.
Travel Charger AC-4
Small and lightweight charger for fast charging of your phone battery.
Internal Battery BL-5c
Inserted under the back cover, this Li-Ion battery provides power in a lightweight package.
SS-45
Camera removal tool. One side is for disassembly, the other side for assembly.
DKE-2
Service Cable to connect the PC with the mini USB connector.
Service Manual 3110c RM-237 |
Copyright © 2007 NOKIA Corporation. All rights reserved. |
|
Page 12 (37) |
Approved 2.0 |
CMO Operations & Logistics |
|
MGR |
Training and Vendor Development |
|
16.Mrz.2007 |
Multimedia Creation & Support |
COMPANY CONFIDENTIAL |
RJ-148
Soldering Jig
Lead-free Solder Wire
Mandatory for lead-free products (Level 2 only).
0772040 NMP Standard Toolkit (V2)
For more informations refer to the Service Bulletin (SB-011) on
NOKIA Online.
Supplier or manufacturer contacts for tool re-order can be found in “Recommended service equipment” document on NOKIA Online.
