HP 2520 User Manual

4.5 (2)

HP ProCurve Switch Software

Management and Configuration Guide

2520 Switches

Software version S.14.03 November 2009

HP ProCurve 2520 Switches

November 2009

S.14.03

Management and Configuration

Guide

This document contains proprietary information, which is protected by copyright. No part of this document may be photocopied, reproduced, or translated into another language without the prior written consent of HewlettPackard.

Publication Number

5992-4947 June 2009

Applicable Products

HP ProCurve 2520-8-PoE Switch	J9137A
HP ProCurve 2520-24-PoE Switch	J9138A

Trademark Credits

Microsoft, Windows, and Microsoft Windows NT are US registered trademarks of Microsoft Corporation. Java™ is a US trademark of Sun Microsystems, Inc.

Disclaimer

The information contained in this document is subject to change without notice.

HEWLETT-PACKARD COMPANY MAKES NO WARRANTY OF ANY KIND WITH REGARD TO THIS MATERIAL, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE. Hewlett-Packard shall not be liable for errors contained herein or for incidental or consequential damages in connection with the furnishing, performance, or use of this material.

The only warranties for HP products and services are set forth in the express warranty statements accompanying such products and services. Nothing herein should be construed as constituting an additional warranty. HP shall not be liable for technical or editorial errors or omissions contained herein.

Hewlett-Packard assumes no responsibility for the use or reliability of its software on equipment that is not furnished by Hewlett-Packard.

Warranty

See the Customer Support/Warranty booklet included with the product.

A copy of the specific warranty terms applicable to your Hewlett-Packard products and replacement parts can be obtained from your HP Sales and Service Office or authorized dealer.

Hewlett-Packard Company

8000 Foothills Boulevard, m/s 5551 Roseville, California 95747-5551

http://www.procurve.com

Product Documentation

About Your Switch Manual Set . . . . . . . . . . . . . . . . . . . . . . . . . . . . xix

Printed Publications. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xix Electronic Publications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xix

Software Feature Index. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xx

1 Getting Started

Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-1

Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-2

Conventions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-2

Configuration and Operation Examples . . . . . . . . . . . . . . . . . . . . . . . . . 1-2

Protocol Acronyms . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-2

Command Syntax and Displayed Information . . . . . . . . . . . . . . . . . . . . 1-2

Command Syntax Statements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-2

Command Prompts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-3

Screen Simulations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-3

Keys . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-4

Sources for More Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-4 Getting Documentation From the Web . . . . . . . . . . . . . . . . . . . . . . . . . 1-6 Online Help . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-6 Menu Interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-6 Command Line Interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-7 Web Browser Interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-7

Need Only a Quick Start? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-8

IP Addressing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-8

To Set Up and Install the Switch in Your Network . . . . . . . . . . . . . . . 1-8 Physical Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-8

iii

2 Selecting a Management Interface

Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-1

Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-2

Understanding Management Interfaces . . . . . . . . . . . . . . . . . . . . . . . . . 2-2

Advantages of Using the Menu Interface . . . . . . . . . . . . . . . . . . . . . . . . 2-3

Advantages of Using the CLI . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-4 General Benefits . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-4 Information on Using the CLI . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-4

Advantages of Using the Web Browser Interface . . . . . . . . . . . . . . . . 2-5

Advantages of Using ProCurve Manager

or ProCurve Manager Plus . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-6

Custom Login Banners for the Console

and Web Browser Interfaces . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-8 Banner Operation with Telnet, Serial, or SSHv2 Access . . . . . . . . 2-8 Banner Operation with Web Browser Access . . . . . . . . . . . . . . . . 2-8 Configuring and Displaying a Non-Default Banner . . . . . . . . . . . . 2-9 Example of Configuring and Displaying a Banner . . . . . . . . . . . . . 2-9 Operating Notes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-12

3 Using the Menu Interface

Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-1

Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-2

Starting and Ending a Menu Session . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-3 How To Start a Menu Interface Session . . . . . . . . . . . . . . . . . . . . . . . . . 3-4 How To End a Menu Session and Exit from the Console: . . . . . . . . . . 3-5

Main Menu Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-7

Screen Structure and Navigation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-9

Rebooting the Switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-12

Menu Features List . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-14

Where To Go From Here . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-15

4 Using the Command Line Interface (CLI)

Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-1

Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-2

Accessing the CLI . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-2

Using the CLI . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-2

Privilege Levels at Logon . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-3

Privilege Level Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-4

Operator Privileges . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-4

Manager Privileges . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-5

How To Move Between Levels . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-7

Listing Commands and Command Options . . . . . . . . . . . . . . . . . . . . . . 4-8

Listing Commands Available at Any Privilege Level . . . . . . . . . . . 4-8

Listing Command Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-10

Displaying CLI “Help” . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-11

Configuration Commands and the Context Configuration Modes . . 4-13

CLI Control and Editing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-16

Executing a Prior Command—Redo . . . . . . . . . . . . . . . . . . . . . . . . . . 4-16

Repeating Execution of a Command . . . . . . . . . . . . . . . . . . . . . . . . . . 4-16

Using a Command Alias . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-18

CLI Editing Shortcuts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-21

5 Using the ProCurve Web Browser Interface

Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-1

Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-2

General Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-3

Starting a Web Browser

Interface Session with the Switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-4 Using a Standalone Web Browser in a PC or UNIX Workstation . . . . 5-4

Using ProCurve Manager (PCM) or

ProCurve Manager Plus (PCM+) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-5

Tasks for Your First ProCurve Web Browser Interface Session . . 5-7 Viewing the “First Time Install” Window . . . . . . . . . . . . . . . . . . . . . . . . 5-7

Security: Creating Usernames and Passwords

in the Browser Interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-8 Entering a User Name and Password . . . . . . . . . . . . . . . . . . . . . . 5-10 Using a User Name . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-10 If You Lose the Password . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-10

Online Help for the Web Browser Interface . . . . . . . . . . . . . . . . . . . . 5-11

Support/Mgmt URLs Feature . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-12 Support URL . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-13 Help and the Management Server URL . . . . . . . . . . . . . . . . . . . . . . . . 5-13 Using the PCM Server for Switch Web Help . . . . . . . . . . . . . . . . . . . . 5-14

Status Reporting Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-16

The Overview Window . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-16

The Port Utilization and Status Displays . . . . . . . . . . . . . . . . . . . . . . . 5-17

Port Utilization . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-17

Port Status . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-19

The Alert Log . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-20

Sorting the Alert Log Entries . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-20

Alert Types and Detailed Views . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-21

Setting Fault Detection Policy . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-23

6 Switch Memory and Configuration

Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-1

Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-3

Configuration File Management . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-3

Using the CLI To Implement Configuration Changes . . . . . . . . . . . . 6-6

Using the Menu and Web Browser Interfaces To Implement Configuration Changes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-9

Menu: Implementing Configuration Changes . . . . . . . . . . . . . . . . . . . 6-10 Using Save and Cancel in the Menu Interface . . . . . . . . . . . . . . . 6-10 Rebooting from the Menu Interface . . . . . . . . . . . . . . . . . . . . . . . 6-11 Web: Implementing Configuration Changes . . . . . . . . . . . . . . . . . . . . 6-12

Using Primary and Secondary Flash Image Options . . . . . . . . . . . . . 6-13 Displaying the Current Flash Image Data . . . . . . . . . . . . . . . . . . . . . . 6-13 Switch Software Downloads . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-15

Local Switch Software Replacement and Removal . . . . . . . . . . . . . . 6-16 Rebooting the Switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-18 Operating Notes about Booting . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-18 Boot and Reload Command Comparison . . . . . . . . . . . . . . . . . . . 6-19 Setting the Default Flash . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-20 Booting from the Default Flash (Primary or Secondary) . . . . . . 6-20 Booting from a Specified Flash . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-20 Using Reload . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-21

Multiple Configuration Files . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-23 General Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-24 Transitioning to Multiple Configuration Files . . . . . . . . . . . . . . . . . . . 6-26 Listing and Displaying Startup-Config Files . . . . . . . . . . . . . . . . . . . . . 6-27

Viewing the Startup-Config File Status with Multiple

Configuration Enabled . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-27 Displaying the Content of A Specific Startup-Config File . . . . . . 6-28 Changing or Overriding the Reboot Configuration Policy . . . . . . . . . 6-28 Managing Startup-Config Files in the Switch . . . . . . . . . . . . . . . . . . . 6-30 Renaming an Existing Startup-Config File . . . . . . . . . . . . . . . . . . 6-31 Creating a New Startup-Config File . . . . . . . . . . . . . . . . . . . . . . . . 6-31 Erasing a Startup-Config File . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-32

Using the Clear + Reset Button Combination To Reset the

Switch to Its Default Configuration . . . . . . . . . . . . . . . . . . . . . . . . 6-34 Transferring Startup-Config Files To or From a Remote Server . . . . 6-35 TFTP: Copying a Configuration File to a Remote Host . . . . . . . . 6-35 TFTP: Copying a Configuration File from a Remote Host . . . . . 6-36

Xmodem: Copying a Configuration File to a Serially

Connected Host . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-36

Xmodem: Copying a Configuration from a Serially

Connected Host . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-37 Operating Notes for Multiple Configuration Files . . . . . . . . . . . . 6-37

Automatic Configuration Update with DHCP Option 66 . . . . . . . . 6-37 CLI Command . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-38 Possible Scenarios for Updating the Configuration File . . . . . . . . . . 6-38 Operating Notes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-39 Log Messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-39

vii

7 Interface Access and System Information

Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-1

Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-2

Interface Access: Console/Serial Link, Web, and Inbound Telnet . 7-3 Menu: Modifying the Interface Access . . . . . . . . . . . . . . . . . . . . . . . . . . 7-4 CLI: Modifying the Interface Access . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-5

Denying Interface Access by Terminating Remote Management Sessions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-9

System Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-11 Menu: Viewing and Configuring System Information . . . . . . . . . . . . . 7-12 CLI: Viewing and Configuring System Information . . . . . . . . . . . . . . 7-13 Web: Configuring System Parameters . . . . . . . . . . . . . . . . . . . . . . . . . 7-17

8 Configuring IP Addressing

Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-1

Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-2

IP Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-2 Just Want a Quick Start with IP Addressing? . . . . . . . . . . . . . . . . . . . . 8-3 IP Addressing with Multiple VLANs . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-4 Menu: Configuring IP Address, Gateway, and Time-To-Live (TTL) . . 8-5 CLI: Configuring IP Address, Gateway, and Time-To-Live (TTL) . . . . 8-6 Web: Configuring IP Addressing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-10 How IP Addressing Affects Switch Operation . . . . . . . . . . . . . . . . . . . 8-11

DHCP/Bootp Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-12 Network Preparations for Configuring DHCP/Bootp . . . . . . . . . 8-14

IP Preserve: Retaining VLAN-1 IP

Addressing Across Configuration File Downloads . . . . . . . . . . . . . . 8-16

Operating Rules for IP Preserve . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-16

Enabling IP Preserve . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-16

viii

9 Time Protocols

Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-1

Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-2

TimeP Time Synchronization . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-2

SNTP Time Synchronization . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-2

Selecting a Time Synchronization Protocol or Turning Off Time Protocol Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-3

General Steps for Running a Time Protocol on the Switch: . . . . . . . . 9-3 Disabling Time Synchronization . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-3

SNTP: Viewing, Selecting, and Configuring . . . . . . . . . . . . . . . . . . . . . 9-4 Menu: Viewing and Configuring SNTP . . . . . . . . . . . . . . . . . . . . . . . . . . 9-5 CLI: Viewing and Configuring SNTP . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-8 Viewing the Current SNTP Configuration . . . . . . . . . . . . . . . . . . . . 9-8 Configuring (Enabling or Disabling) the SNTP Mode . . . . . . . . . 9-10

TimeP: Viewing, Selecting, and Configuring . . . . . . . . . . . . . . . . . . . . 9-16 Menu: Viewing and Configuring TimeP . . . . . . . . . . . . . . . . . . . . . . . . 9-17 CLI: Viewing and Configuring TimeP . . . . . . . . . . . . . . . . . . . . . . . . . . 9-18 Viewing the Current TimeP Configuration . . . . . . . . . . . . . . . . . . 9-19 Configuring (Enabling or Disabling) the TimeP Mode . . . . . . . . 9-20

SNTP Unicast Time Polling with Multiple SNTP Servers . . . . . . . . 9-25 Displaying All SNTP Server Addresses Configured on the Switch . . 9-25 Adding and Deleting SNTP Server Addresses . . . . . . . . . . . . . . . . . . . 9-26

Menu: Operation with Multiple SNTP Server Addresses

Configured . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-26

SNTP Messages in the Event Log . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-26

10 Port Status and Configuration

Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10-1

Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10-3

Viewing Port Status and Configuring Port Parameters . . . . . . . . . . 10-3

Menu: Port Status and Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . 10-4

Port Type . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10-4

Status of Ports . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10-5

Flow Control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10-5

Broadcast Limit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10-5

Modes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10-6

Configuring Ports . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10-7

CLI: Viewing Port Status and Configuring Port Parameters . . . . . . . 10-8

Viewing Port Status and Configuration . . . . . . . . . . . . . . . . . . . . . 10-9

Customizing the Show Interfaces Command . . . . . . . . . . . . . . . . . . . 10-11

Error Messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10-13

Note on Using Pattern Matching with the

“Show Interfaces Custom” Command . . . . . . . . . . . . . . . . . . . . . 10-13 Viewing Port Utilization Statistics . . . . . . . . . . . . . . . . . . . . . . . . . . . 10-14 Viewing Transceiver Status . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10-14 Enabling or Disabling Ports and Configuring Port Mode . . . . . . . . . 10-16 Enabling or Disabling Flow Control . . . . . . . . . . . . . . . . . . . . . . . . . . 10-17 Configuring a Broadcast Limit on the Switch . . . . . . . . . . . . . . . . . . 10-19 Configuring ProCurve Auto-MDIX . . . . . . . . . . . . . . . . . . . . . . . . . . . 10-19 Web: Viewing Port Status and Configuring Port Parameters . . . . . 10-22

Using Friendly (Optional) Port Names . . . . . . . . . . . . . . . . . . . . . . . 10-23 Configuring and Operating Rules for Friendly Port Names . . . . . . . 10-23 Configuring Friendly Port Names . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10-24 Displaying Friendly Port Names with Other Port Data . . . . . . . . . . 10-25

Configuring Transceivers and Modules That Haven’t

Been Inserted . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10-28

Transceivers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10-28

11 Power Over Ethernet (PoE) Operation

Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11-1

Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11-2

Configuration Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11-2

Related Publications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11-3

Terminology . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11-3

PoE Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11-4

Powered Device (PD) Support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11-4

Power Priority Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11-5

When Is Power Allocation Prioritized? . . . . . . . . . . . . . . . . . . . . . 11-5

How Is Power Allocation Prioritized? . . . . . . . . . . . . . . . . . . . . . . 11-5

Configuring PoE Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11-6 Disabling or Re-Enabling PoE Port Operation . . . . . . . . . . . . . . . . . . 11-6 Enabling Support for Pre-Standard Devices . . . . . . . . . . . . . . . . . . . . 11-6 Configuring the PoE Port Priority Level . . . . . . . . . . . . . . . . . . . . . . . 11-8 Controlling PoE Allocation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11-9 Manually Configuring PoE Power Levels . . . . . . . . . . . . . . . . . . . . . . 11-10 Changing the Threshold for Generating a Power Notice . . . . . . . . . 11-12 Cycling Power on a Port . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11-13

PoE/PoE+ Allocation Using LLDP Information . . . . . . . . . . . . . . . . 11-14

LLDP with PoE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11-14

Viewing PoE Configuration and Status . . . . . . . . . . . . . . . . . . . . . . . 11-15 Displaying the Switch’s Global PoE Power Status . . . . . . . . . . . . . . 11-15 Displaying an Overview of PoE Status on All Ports . . . . . . . . . . . . . 11-16 Displaying the PoE Status on Specific Ports . . . . . . . . . . . . . . . . . . . 11-18

Planning and Implementing a PoE Configuration . . . . . . . . . . . . . . 11-20 Assigning PoE Ports to VLANs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11-20 Applying Security Features to PoE Configurations . . . . . . . . . . . . . 11-20

PoE Event Log Messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11-21

12 Port Trunking

Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12-1

Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12-2

Port Trunk Features and Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . 12-4

Trunk Configuration Methods . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12-4

Menu: Viewing and Configuring a Static Trunk Group . . . . . . . . . . 12-9

CLI: Viewing and Configuring Port Trunk Groups . . . . . . . . . . . . . 12-11 Using the CLI To View Port Trunks . . . . . . . . . . . . . . . . . . . . . . . . . . 12-11 Using the CLI To Configure a Static or Dynamic Trunk Group . . . 12-14

Web: Viewing Existing Port Trunk Groups . . . . . . . . . . . . . . . . . . . .	12-17
Trunk Group Operation Using LACP . . . . . . . . . . . . . . . . . . . . . . . . .	12-18
Default Port Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .	12-21
LACP Notes and Restrictions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .	12-22

Trunk Group Operation Using the “Trunk” Option . . . . . . . . . . . . 12-26

How the Switch Lists Trunk Data . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12-27

Outbound Traffic Distribution Across Trunked Links . . . . . . . . . 12-27

13 Configuring for Network Management Applications

Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13-1

Using SNMP Tools To Manage the Switch . . . . . . . . . . . . . . . . . . . . . . 13-3 Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13-3 SNMP Management Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13-4 Configuring for SNMP version 1 and 2c Access to the Switch . . . . . 13-4 Configuring for SNMP Version 3 Access to the Switch . . . . . . . . . . . 13-5 SNMP Version 3 Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13-6

Enabling SNMPv3 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13-7

SNMPv3 Users . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13-7

Group Access Levels . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13-11

SNMPv3 Communities . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13-11

Menu: Viewing and Configuring non-SNMP version 3

Communities . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13-13 CLI: Viewing and Configuring SNMP Community Names . . . . 13-15 SNMP Notifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13-17 Supported Notifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13-17 General Steps for Configuring SNMP Notifications . . . . . . . . . 13-18 SNMPv1 and SNMPv2c Traps . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13-19 Configuring an SNMP Trap Receiver . . . . . . . . . . . . . . . . . . . . . . 13-19 Enabling SNMPv2c Informs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13-21 Configuring SNMPv3 Notifications . . . . . . . . . . . . . . . . . . . . . . . 13-23 Managing Network Security Notifications . . . . . . . . . . . . . . . . . 13-26 Enabling Link-Change Traps . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13-28 Configuring the Source IP Address for SNMP Notifications . . 13-29 Displaying SNMP Notification Configuration . . . . . . . . . . . . . . . 13-31 Advanced Management: RMON . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13-33

LLDP (Link-Layer Discovery Protocol) . . . . . . . . . . . . . . . . . . . . . . . 13-34

Terminology . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13-35

General LLDP Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13-37

xii

LLDP-MED . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13-37 Packet Boundaries in a Network Topology . . . . . . . . . . . . . . . . . . . . 13-37 Configuration Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13-38 Options for Reading LLDP Information Collected by the Switch . . 13-40 LLDP and LLDP-MED Standards Compatibility . . . . . . . . . . . . . . . . 13-41 LLDP Operating Rules . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13-41 Configuring LLDP Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13-42

Viewing the Current Configuration . . . . . . . . . . . . . . . . . . . . . . . 13-43 Configuring Global LLDP Packet Controls . . . . . . . . . . . . . . . . . 13-44 Configuring SNMP Notification Support . . . . . . . . . . . . . . . . . . . 13-48 Configuring Per-Port Transmit and Receive Modes . . . . . . . . . 13-49 Configuring Basic LLDP Per-Port Advertisement Content . . . . 13-50

Configuring Support for Port Speed and Duplex

Advertisements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13-52 LLDP-MED (Media-Endpoint-Discovery) . . . . . . . . . . . . . . . . . . . . . 13-53 LLDP-MED Topology Change Notification . . . . . . . . . . . . . . . . . 13-56 LLDP-MED Fast Start Control . . . . . . . . . . . . . . . . . . . . . . . . . . . 13-58

Advertising Device Capability, Network Policy, PoE Status

and Location Data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13-58 Configuring Location Data for LLDP-MED Devices . . . . . . . . . 13-62 Displaying Advertisement Data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13-67

Displaying Switch Information Available for Outbound Advertisements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13-68

Displaying LLDP Statistics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13-72

LLDP Operating Notes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13-74

LLDP and CDP Data Management . . . . . . . . . . . . . . . . . . . . . . . . . . . 13-76

LLDP and CDP Neighbor Data . . . . . . . . . . . . . . . . . . . . . . . . . . . 13-76

CDP Operation and Commands . . . . . . . . . . . . . . . . . . . . . . . . . . 13-78

A File Transfers

Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-1

Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

A-3

Downloading Switch Software . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-3 General Software Download Rules . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-3 Using TFTP To Download Switch Software from a Server . . . . . . . . A-4

xiii

Menu: TFTP Download from a Server to Primary Flash . . . . . . . A-4 CLI: TFTP Download from a Server to Flash . . . . . . . . . . . . . . . . A-7 Using Secure Copy and SFTP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-9 How It Works . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-10 The SCP/SFTP Process . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-10 Disable TFTP and Auto-TFTP for Enhanced Security . . . . . . . A-11 Command Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-13 Authentication . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-14 SCP/SFTP Operating Notes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-14 Troubleshooting SSH, SFTP, and SCP Operations . . . . . . . . . . A-16

Using Xmodem to Download Switch Software From

a PC or UNIX Workstation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-17 Menu: Xmodem Download to Primary Flash . . . . . . . . . . . . . . . A-17

CLI: Xmodem Download from a PC or UNIX Workstation to Primary or Secondary Flash . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-18

Switch-to-Switch Download . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-19 Menu: Switch-to-Switch Download to Primary Flash . . . . . . . . A-19 CLI: Switch-To-Switch Downloads . . . . . . . . . . . . . . . . . . . . . . . A-20 Using PCM+ to Update Switch Software . . . . . . . . . . . . . . . . . . . . . . A-22

Copying Software Images . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-22 TFTP: Copying a Software Image to a Remote Host . . . . . . . . . A-22

Xmodem: Copying a Software Image from the Switch to a

Serially Connected PC or UNIX Workstation . . . . . . . . . . . . . . . A-23

Transferring Switch Configurations . . . . . . . . . . . . . . . . . . . . . . . . . . A-23 TFTP: Copying a Configuration File to a Remote Host . . . . . . . A-24 TFTP: Copying a Configuration File from a Remote Host . . . . A-24 TFTP: Copying a Customized Command File to a Switch . . . . A-25

Xmodem: Copying a Configuration File to a Serially

Connected PC or UNIX Workstation . . . . . . . . . . . . . . . . . . . . . . A-26

Xmodem: Copying a Configuration File from a Serially

Connected PC or UNIX Workstation . . . . . . . . . . . . . . . . . . . . . . A-26

Copying Diagnostic Data to a Remote

Host, PC or UNIX Workstation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-28 Copying Command Output to a Destination Device . . . . . . . . . A-28 Copying Event Log Output to a Destination Device . . . . . . . . . A-29

xiv

Copying Crash Data Content to a Destination Device . . . . . . . A-29 Copying Crash Log Data Content to a Destination Device . . . . A-30

B Monitoring and Analyzing Switch Operation

Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . B-1

Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .	B-3
Status and Counters Data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .	B-4
Menu Access To Status and Counters . . . . . . . . . . . . . . . . . . . . . . . . .	B-5
General System Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .	B-6
Menu Access . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .	B-6
CLI Access to System Information . . . . . . . . . . . . . . . . . . . . . . . .	B-7
Task Monitor—Collecting Processor Data . . . . . . . . . . . . . . . . . . . . .	B-7
Switch Management Address Information . . . . . . . . . . . . . . . . . . . . . .	B-8
Menu Access . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .	B-8
CLI Access . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .	B-9
Port Status . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .	B-10
Menu: Displaying Port Status . . . . . . . . . . . . . . . . . . . . . . . . . . . .	B-10
CLI Access . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .	B-10
Web Access . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .	B-10
Viewing Port and Trunk Group Statistics and Flow Control Status	B-11
Menu Access to Port and Trunk Statistics . . . . . . . . . . . . . . . . .	B-12
CLI Access To Port and Trunk Group Statistics . . . . . . . . . . . .	B-13
Web Browser Access To View Port and Trunk
Group Statistics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .	B-13
Viewing the Switch’s MAC Address Tables . . . . . . . . . . . . . . . . . . . .	B-14
Menu Access to the MAC Address Views and Searches . . . . . .	B-14
CLI Access for MAC Address Views and Searches . . . . . . . . . .	B-17
Spanning Tree Protocol (MSTP) Information . . . . . . . . . . . . . . . . . .	B-18
CLI Access to MSTP Data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .	B-18
Internet Group Management Protocol (IGMP) Status . . . . . . . . . . .	B-19
VLAN Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .	B-20
Web Browser Interface Status Information . . . . . . . . . . . . . . . . . . . .	B-22
Interface Monitoring Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .	B-23
Menu: Configuring Port and Static Trunk Monitoring . . . . . . . . . . .	B-24
CLI: Configuring Port and Static Trunk Monitoring . . . . . . . . . . . . .	B-25

Web: Configuring Port Monitoring . . . . . . . . . . . . . . . . . . . . . . . . . . . B-28

Locating a Device . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

B-28

C Troubleshooting

Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . C-1

Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

C-4

Troubleshooting Approaches . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . C-5

Browser or Telnet Access Problems . . . . . . . . . . . . . . . . . . . . . . . . . . . C-6

Unusual Network Activity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . C-8 General Problems . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . C-8 802.1Q Prioritization Problems . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . C-9 IGMP-Related Problems . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . C-9 LACP-Related Problems . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . C-10 Port-Based Access Control (802.1X)-Related Problems . . . . . . . . . C-10 QoS-Related Problems . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . C-13 Radius-Related Problems . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . C-14 Spanning-Tree Protocol (MSTP) and Fast-Uplink Problems . . . . . . C-15 SSH-Related Problems . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . C-16 TACACS-Related Problems . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . C-17 TimeP, SNTP, or Gateway Problems . . . . . . . . . . . . . . . . . . . . . . . . . C-19 VLAN-Related Problems . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . C-19 Fan Failure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . C-21

Using the Event Log for Troubleshooting Switch Problems . . . . C-22 Event Log Entries . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . C-22 Menu: Displaying and Navigating in the Event Log . . . . . . . . . . . . . C-28 CLI: Displaying the Event Log . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . C-29 CLI: Clearing Event Log Entries . . . . . . . . . . . . . . . . . . . . . . . . . . . . . C-29 CLI: Turning Event Numbering On . . . . . . . . . . . . . . . . . . . . . . . . . . . C-30

Using Log Throttling to Reduce Duplicate

Event Log and SNMP Messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . C-30 Log Throttle Periods . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . C-31 Example of Event Counter Operation . . . . . . . . . . . . . . . . . . . . . C-31

Debug/Syslog Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . C-32

Debug/Syslog Messaging . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . C-32

xvi

Debug/Syslog Destination Devices . . . . . . . . . . . . . . . . . . . . . . . . . . .	C-32
Debug/Syslog Configuration Commands . . . . . . . . . . . . . . . . . . . . . .	C-33
Configuring Debug/Syslog Operation . . . . . . . . . . . . . . . . . . . . . . . . .	C-35
Displaying a Debug/Syslog Configuration . . . . . . . . . . . . . . . . . .	C-36
Debug Command . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .	C-38
Debug Messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .	C-38
Debug Destinations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .	C-40
Logging Command . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .	C-41
Configuring a Syslog Server . . . . . . . . . . . . . . . . . . . . . . . . . . . . .	C-41
Adding a Description for a Syslog Server . . . . . . . . . . . . . . . . . . . . . .	C-44
Adding a Priority Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .	C-45
Configuring the Severity Level for Event Log
Messages Sent to a Syslog Server . . . . . . . . . . . . . . . . . . . . . . . . . . . .	C-46
Configuring the System Module Used to Select the Event Log
Messages Sent to a Syslog Server . . . . . . . . . . . . . . . . . . . . . . . .	C-47
Operating Notes for Debug and Syslog . . . . . . . . . . . . . . . . . . . . . . .	C-47
Diagnostic Tools . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .	C-49
Port Auto-Negotiation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .	C-50
Ping and Link Tests . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .	C-50
Web: Executing Ping or Link Tests . . . . . . . . . . . . . . . . . . . . . . .	C-51
CLI: Ping Test . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .	C-52
Link Tests . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .	C-53
Traceroute Command . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .	C-54
Viewing Switch Configuration and Operation . . . . . . . . . . . . . . . . .	C-58
CLI: Viewing the Startup or Running Configuration File . . . . . . . . .	C-58
Web: Viewing the Configuration File . . . . . . . . . . . . . . . . . . . . . . . . .	C-58
CLI: Viewing a Summary of Switch Operational Data . . . . . . . . . . .	C-59
Saving show tech Command Output to a Text File . . . . . . . . . .	C-60
CLI: Viewing More Information on Switch Operation . . . . . . . . . . .	C-62
Pattern Matching When Using the Show Command . . . . . . . . .	C-63
CLI: Useful Commands for Troubleshooting Sessions . . . . . . . . . . .	C-66
Restoring the Factory-Default Configuration . . . . . . . . . . . . . . . . .	C-67
CLI: Resetting to the Factory-Default Configuration . . . . . . . . . . . .	C-67
Clear/Reset: Resetting to the Factory-Default Configuration . . . . .	C-67
Restoring a Flash Image . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .	C-68

xvii

DNS Resolver . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . C-71

Terminology . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . C-71

Basic Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . C-71

Configuring and Using DNS Resolution

with DNS-Compatible Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . C-73 Configuring a DNS Entry . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . C-74 Example Using DNS Names with Ping and Traceroute . . . . . . . . . . C-75 Viewing the Current DNS Configuration . . . . . . . . . . . . . . . . . . . . . . C-77 Operating Notes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . C-78 Event Log Messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . C-79

D MAC Address Management

Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . D-1

Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

D-2

Determining MAC Addresses . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . D-3 Menu: Viewing the Switch’s MAC Addresses . . . . . . . . . . . . . . . . . . . . D-4 CLI: Viewing the Port and VLAN MAC Addresses . . . . . . . . . . . . . . . . D-5

Viewing the MAC Addresses of Connected Devices . . . . . . . . . . . . . D-6

EDaylight Savings Time on ProCurve Switches

FPower-Saving Features

Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . F-1

Configuring Power-Saving for LEDs . . . . . . . . . . . . . . . . . . . . . . . . . . . . F-2 Show Savepower Status . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . F-2

xviii

Product Documentation

About Your Switch Manual Set

N o t e	For the latest version of all ProCurve switch documentation, including
	Release Notes covering recently added features, please visit the ProCurve
	Networking Web site at www.procurve.com, click on Support, and then click on
	Manuals.

Printed Publications

The publications listed below are printed and shipped with your switch. The latest version is also available in PDF format on the ProCurve Web site, as described in the Note at the top of this page.

■ Read Me First—Provides software update information, product notes, and other information.

■ HP ProCurve Switch Quick Setup—Provides quick start installation instructions. See the Installation and Getting Started Guide for more detailed information.

Electronic Publications

The latest version of each of the publications listed below is available in PDF format on the ProCurve Web site, as described in the Note at the top of this page.

■ Installation and Getting Started Guide—Explains how to prepare for and perform the physical installation and connect the switch to your network.

■ Management and Configuration Guide—Describes how to configure, manage, and monitor basic switch operation.

■ Advanced Traffic Management Guide—Explains how to configure traffic management features such as VLANs, MSTP, and QoS.

■ Access Security Guide—Explains how to configure access security fea tures and user authentication on the switch.

■ IPv6 Configuration Guide—Describes the IPv6 protocol operations that are supported on the switch.

■ Release Notes—Describe new features, fixes, and enhancements that become available between revisions of the main product guide.

xix

Software Feature Index

For the software manual set supporting your series 2520 switch models, this feature index indicates which manual to consult for information on a given software feature.

Feature	Management and	Advanced Traffic	Access Security
	Configuration	Management	Guide

802.1Q VLAN Tagging	-	X	-

802.1p Priority	X	-	-

802.1X Authentication	-	-	X

AAA Authentication			X

Authorized IP Managers	-	-	X

Auto MDIX Configuration	X

BOOTP	X

Config File	X	-	-

Console Access	X

Copy Command	X	-	-

Debug	X	-	-

DHCP Configuration	-	X	-

DHCP/Bootp Operation	X	-	-

Diagnostic Tools	X	-	-

Downloading Software	X	-	-

Eavesdrop Protection			X

Event Log	X	-	-

Factory Default Settings	X	-	-

File Management	X	-	-

Feature	Management and	Advanced Traffic	Access Security
	Configuration	Management	Guide

File Transfers	X	-	-

Friendly Port Names	X

GVRP	-	X	-

IGMP	-	X	-

Interface Access (Telnet, Console/Serial, Web)	X	-	-

IP Addressing	X	-	-

LACP	X	-	-

Link	X	-	-

LLDP	X	-	-

LLDP-MED	X

Loop Protection		X

MAC Address Management	X	-	-

MAC Lockdown	-	-	X

MAC Lockout	-	-	X

MAC-based Authentication	-	-	X

Monitoring and Analysis	X	-	-

Multicast Filtering	-	X	-

Network Management Applications (LLDP, SNMP)	X	-	-

Passwords	-	-	X

Ping	X	-	-

Port Configuration	X	-	-

Port Security	-	-	X

Port Status	X	-

Port Trunking (LACP)	X	-

Port-Based Access Control (802.1X)	-	-	X

Port-Based Priority (802.1Q)	X	-

xxi

Feature	Management and	Advanced Traffic	Access Security
	Configuration	Management	Guide

Power over Ethernet (PoE)

Quality of Service (QoS)	-	X	-

RADIUS Authentication and Accounting	-	-	X

Secure Copy	X	-	-

SFTP	X	-	-

SNMP	X	-	-

Software Downloads (SCP/SFTP, TFTP, Xmodem)	X	-	-

Spanning Tree (MSTP)	-	X	-

SSH (Secure Shell) Encryption	-	-	X

SSL (Secure Socket Layer)	-	-	X

Stack Management (Stacking)	-	X	-

Syslog	X	-	-

System Information	X	-	-

TACACS+ Authentication	-	-	X

Telnet Access	X	-	-

TFTP	X	-	-

Time Protocols (TimeP, SNTP)	X	-	-

Troubleshooting	X	-	-

VLANs	-	X	-

Web-based Authentication	-	-	X

Web UI	X

Xmodem	X	-	-

xxii

Getting Started

Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-2

Conventions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-2

Command Syntax Statements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-2

Command Prompts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-3

Screen Simulations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-3

Configuration and Operation Examples . . . . . . . . . . . . . . . . . . . . . . . . . 1-3

Keys . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-3

Need Only a Quick Start? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-8

IP Addressing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-8

To Set Up and Install the Switch in Your Network . . . . . . . . . . . . . . . 1-8 Physical Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-8

1-1

Getting Started

Introduction

This guide is intended for use with the following switches:

■HP ProCurve 2520-8-PoE Switch

■HP ProCurve 2520-24-PoE Switch

It describes how to use the command line interface (CLI), Menu interface, and web browser to configure, manage, monitor, and troubleshoot switch opera tion. For an overview of other product documentation for the above switches, refer to “Product Documentation” on page xi. You can download documenta tion from the ProCurve Networking web site, www.procurve.com.

Conventions

Configuration and Operation Examples

Unless otherwise noted, examples using a particular switch model apply to all switch models covered by this guide.

Protocol Acronyms

IP Refers to the IPv4 protocol unless otherwise noted.

IPv6 Refers to the IPv6 protocol.

Command Syntax and Displayed Information

Command Syntax Statements

Syntax: ip < default-gateway < ip-addr >> | routing >

Syntax: show interfaces [port-list ]

■Vertical bars ( | ) separate alternative, mutually exclusive elements.

■Square brackets ( [ ] ) indicate optional elements.

■Braces ( < > ) enclose required elements.

1-2

Getting Started

Conventions

■Braces within square brackets ( [ < > ] ) indicate a required element within an optional choice.

■Boldface indicates use of a CLI command, part of a CLI command syntax, or other displayed element in general text. For example:

“Use the copy tftp command to download the key from a TFTP server.”

■Italics indicate variables for which you must supply a value when execut ing the command. For example, in this command syntax, you must provide one or more port numbers:

Syntax: aaa port-access authenticator < port-list >

Command Prompts

In the default configuration, your switch displays a CLI prompt similar to the following example:

ProCurve 2520-8-PoE#

To simplify recognition, this guide uses ProCurve to represent command prompts for all switch models. For example:

ProCurve#

(You can use the hostname command to change the text in the CLI prompt.)

Screen Simulations

Displayed Text. Figures containing simulated screen text and command output look like this:

ProCurve> show version

Image stamp: /sw/code/build/info November 6, 2008 13:43:13 S.14.02

139 Boot Image: Primary

ProCurve>

Figure 1-1. Example of a Figure Showing a Simulated Screen

In some cases, brief command-output sequences appear without figure iden tification. For example:

ProCurve(config)# clear public-key ProCurve(config)# show ip client-public-key show_client_public_key: cannot stat keyfile

1-3

Getting Started

Sources for More Information

Keys

Simulations of actual keys use a bold, sans-serif typeface with square brackets. For example, the Tab key appears as [Tab] and the “Y” key appears as [Y].

N o t e

Sources for More Information

For information about switch operation and features not covered in this guide, consult the following sources:

■Feature Index—For information on which manual to consult for a given software feature, refer to the “Software Feature Index” on page xii.

For the latest version of all ProCurve switch documentation referred to below, including Release Notes covering recently added features, visit the ProCurve Networking web site at www.procurve.com, click on Support, and then click on Manuals.

■Software Release Notes—Release Notes are posted on the ProCurve Networking web site and provide information on new software updates:

•new features and how to configure and use them

•software management, including downloading software to the switch

•software fixes addressed in current and previous releases

■Product Notes and Software Update Information—The printed Read Me First shipped with your switch provides software update information, product notes, and other information.

■Installation and Getting Started Guide—Use the Installation and Get ting Started Guide to prepare for and perform the physical installation. This guide also steps you through connecting the switch to your network and assigning IP addressing, as well as describing the LED indications for correct operation and trouble analysis.

■Management and Configuration Guide—Use this guide for information on topics such as:

•various interfaces available on the switch

•memory and configuration operation

•interface access

•IP addressing

•time protocols

1-4

Getting Started

Sources for More Information

•port configuration, trunking, traffic control, and PoE operation

•SNMP, LLDP, and other network management topics

•file transfers, switch monitoring, troubleshooting, and MAC address management

■Advanced Traffic Management Guide—Use this guide for information on topics such as:

•VLANs: Static port-based and protocol VLANs, and dynamic GVRP VLANs

•spanning-Tree: 802.1D (STP), 802.1w (RSTP), and 802.1s (MSTP)

•Quality-of-Service (QoS)

•IGMP

■Access Security Guide—Use this guide for information on topics such as:

•Local username and password security

•Web-Based and MAC-based authentication

•RADIUS and TACACS+ authentication

•SSH (Secure Shell) and SSL (Secure Socket Layer) operation

•802.1X access control

•Port security operation with MAC-based control

•Authorized IP Manager security

•Key Management System (KMS)

■IPv6 Configuration Guide—Use this guide for information on topics such as:

•Overview of IPv6 operation and features

•Configuring IPv6 addressing

•Using IPv6 management, security, and troubleshooting features

1-5

Getting Started

Sources for More Information

Getting Documentation From the Web

To obtain the latest versions of documentation and release notes for your switch:

1.Go to the ProCurve Networking web site at www.procurve.com

2.Click on Support.

3.Click on Manuals.

4.Click on the product for which you want to view or download a manual.

If you need further information on ProCurve switch technology, visit the

ProCurve Networking web site at:

www.procurve.com

Online Help

Menu Interface

If you need information on specific parameters in the menu interface, refer to the online help provided in the interface. For example:

Online Help for Menu

Figure 1-2. Online Help for Menu Interface

1-6

+ 514 hidden pages
