California Emission Control System Limited Warranty PZEV* . . . . ............. 25
What is not covered ...............................................27
General .......................................................27
California Emission Warranty Parts List ..................................28
2014 BMW i3 Models covered in this Booklet
BMW i3
BMW i3 with Range Extender
Introduction (for BMW i3 with
Range Extender only)
The 2014 BMW i3 with Range Extender is
certified to California’s stringent Super Ultra Low
Emission Vehicle (SULEV) standards and also
qualifies as a Type II Zero Emission Vehicle with
Range Extender (Type IIx ZEV) under the
California Air Resources Board Zero Emission
Vehicle program. In addition to very low tailpipe
and zero-evaporative emissions, this certification
includes a unique Partial Zero Emission Vehicle
(PZEV) warranty when the vehicle is registered in
California and certain other states, as indicated in
the PZEV section beginning on page 24. PZEV
models registered in Delaware, Oregon,
Pennsylvania and Washington are covered by the
California Emission Warranty beginning on
page 25.
The emission certification standard can be
verified on the Vehicle Emission Control
Information label located on the underside
surface of the tailgate. A representative label is
shown below; the Type IIx ZEV certification is
stated after the word “California.”
2014
LI+, gasoline
SULEV (PZEV) PC
EBMXV00.6I3R
EBMXR0035I3R
WU-TWC, A/F-Sensor,
H02S, SFI
LI+, gasoline
8 642 359
BMW Ultimate Service™
BMW Ultimate Service leads the industry in
providing owners with incredible value and peace
of mind. This service includes:
䉯 The BMW Maintenance Program: No cost
factory-recommended maintenance for
4 years/50,000 miles from the original
in-service date, whichever comes first.
䉯 BMW Roadside Assistance: No-cost 24/7
on-the-road assistance for 4 years/unlimited
miles from the original in-service date. Also
includes trip-interruption benefits as well as
trip routing services.
䉯 New Vehicle Limited Warranty: Limited
coverage for defects in materials and
workmanship for 4 years/50,000 miles from
the original in-service date, whichever comes
first. Repairs will only be made at authorized
BMW centers using Original BMW Parts.
The BMW Maintenance Program
The BMW Maintenance Program is a benefit
designed to help reduce the cost of ownership.
This program has been devised with the
following objectives: to maximize vehicle safety,
reliability, and resale value by minimizing
breakdowns resulting from wear, and minimizing
cost and inconvenience by computing
maintenance intervals based upon the specific
manner in which each individual vehicle is driven.
A 2014 BMW i3 vehicle purchased from an
authorized BMW center in the United States
(including Puerto Rico) is covered by the BMW
Maintenance Program for 48 months or
50,000 miles, whichever occurs first. Coverage
begins on the date of first retail sale or the date
the vehicle is first placed into service as a sales
demonstrator, Aftersales Mobility Program (AMP)
Vehicle or BMW Group company vehicle,
whichever is earlier.
Any authorized BMW center in the United States
(including Puerto Rico) will perform the
scheduled and/or additional maintenance
services on your vehicle at no expense to you so
long as your vehicle qualifies for coverage under
the BMW Maintenance Program.
1
Coverage
Maintenance Upgrade Option
The BMW Maintenance Program covers all
factory recommended maintenance, as
determined by the Condition Based Service
(CBS) system. Additional specific items that
need replacement due to normal wear and tear,
and that are not covered by the original New
Vehicle Limited Warranty - such as brake pads,
brake rotors, and wiper blade inserts - are
included, provided wear and tear exceeds BMW
wear limits. Any applicable adjustments required
due to normal operating conditions are also
included. See pages 5-6 of this Booklet for
additional information.
Exclusions from coverage include the following:
䉯 Items reimbursable under your New Vehicle
Limited Warranty
䉯 Windshield washer additive (except when in
conjunction with scheduled maintenance)
䉯 Tires, wheel alignment, tire balance and
rotation
䉯 Parking brake shoes/linings
䉯 Reset Tire Pressure Monitor
䉯 Wear and tear of soft trim items, such as:
seats, carpets, moldings, headliner, door
panels and all chrome trim
䉯 Damage, including consequential, which
results from negligence, improper operation of
the vehicle, wear and tear or deterioration due
to driving habits or conditions, improper repair,
environmental influences, flood, accident or
fire damage, road salt corrosion, alteration or
installation of non-genuine BMW accessories
䉯 Altered or unreadable Vehicle Identification
Number (VIN) or odometer irregularities or
vehicles where the true mileage cannot be
determined
䉯 Maintenance or repair after the vehicle is
deemed a total loss
䉯 Maintenance or repairs performed by other
than an authorized BMW center within the
United States (including Puerto Rico)
䉯 Vehicles used in competitive events
Please contact your authorized BMW center for
information regarding the purchase of optional
Maintenance Program Upgrades. Eligibility and
coverage exclusions may apply.
Intervals
Time intervals should be followed using the
maintenance intervals as indicated by the BMW
Condition Based Service.
Maintenance intervals on motor vehicles have
conventionally been specified based upon
accumulated mileage. However, driving
conditions have a major influence on routine
maintenance requirements; distance traveled is
only one of the significant factors.
The advanced technologies at BMW have led to
the development of the unique BMW Condition
Based Service (CBS) system which computes
the actual optimum maintenance requirements
based not only upon the accumulated mileage,
but taking into account important factors such as
high or low engine speeds, and short or long trip
driving.
Condition Based Service (CBS)
CBS is a further development of the Service
Interval Indicator System.
The remaining times for selected maintenance
tasks as well as any legally prescribed dates are
displayed to you individually:
*As of 7/14 production.
CBS thus determines the current and future
maintenance requirements. This data can also be
read from the vehicle key by your BMW Service
Advisor and used to propose the optimum scope
of maintenance.
2
BMW recommends that you have maintenance
and repair work performed by your authorized
BMW center.
Disconnecting the battery during periods of
long-term storage will interrupt the
calculation of time-based services. BMW
recommends that you have all items requiring
time-based maintenance, such as brake fluid and
microfilter, brought up to date by your authorized
BMW center.
Service Required Display
5. If necessary, move the highlight marker. Turn
the controller until “Service required” is
selected and press the controller.
Vehicle status
Service required
Info Display screen contents
Total
00162
Service
mi
07/2016
OFF
The date when your next service is due briefly
appears when you switch on the ignition.
For certain maintenance operations, you can
view the respective distance remaining or due
date individually in the Control Display (see
below).
009.6
Trip
mi
mi
68
Control Display screen contents
The current Status of Service items determined
by the CBS are shown in the Control Display,
located in the center of the instrument panel.
You can also view additional information on the
service and maintenance requirements.
1. Open the start menu.
2. Press the controller to open the i-menu.
3. Select “Vehicle info” and press the controller.
4. Select “Vehicle status” and press the
controller.
A list of selected maintenance operations and, if
applicable, inspections required by law is
displayed.
Service required
OK
Brake fluid
OK
Vehicle check
S
Emission inspection
OK
S
S
Vehicle inspection
OK
S
07/2016
You can request more detailed information on
every entry.
Select the entry and press the controller.
Service requirement details
Vehicle check
Next vehicle check due after
the specified distance or
date.
07/2016
To exit from the menu:
Select the
arrow and press the controller.
3
Symbols
No service is currently required.
The deadline for service or a state
inspection is approaching. Please contact
your authorized BMW center for an
appointment.
The service deadline has already passed.
Service required
Brake fluid
OK
Vehicle check
OK
S
Emission inspection
OK
S
S
Vehicle inspection
OK
S
07/2016
You can request more detailed information on
every entry.
Turn the controller to scroll through the list, then
confirm the selected entry.
Confirm to exit the list.
The current service status is automatically saved
in the vehicle’s key. The Service Advisor at your
authorized BMW center has a device called a key
reader. When your Service Advisor inserts your
key into the key reader, all pertinent vehicle and
servicing data will be available, and a customized
maintenance checklist is printed out based on
the specific operations called for by the
Condition Based Service.
Special Note — Maintenance
Intervals
The maintenance requirements for your vehicle
are determined dynamically by the Condition
Based Service (CBS) system. The maintenance
items stated herein reflect the latest information
available at the time of the printing of this
Booklet, and are subject to change.
The completion of certain subsequent
maintenance items or services, as required to
properly maintain your vehicle, will be specified
at intervals computed by the BMW Condition
Based Service system as follows:
The Brake Fluid Service must be performed
when required as indicated by the following as
applicable:
䉯 The specified CBS service counter interval
䉯 The time interval (the first occurrence based
on the vehicle’s production date)
䉯 The stated mileage for a “non-connected”
maintenance service
Refer to pages5-6foradditional information.
For your convenience, you may also wish to have
your authorized BMW center perform any
necessary operations to fulfill any state
inspection requirements in your area, concurrent
with the maintenance services specified above
during other repairs. Should you request more
frequent maintenance service, the cost of
these services will not be covered by the
Maintenance Program.
BMW has applied the most modern
technological advances not only to the design
and production of your vehicle, but also to
computing of the optimum maintenance interval
for your type of operations and driving style. Your
authorized BMW center has made a substantial
investment in unique BMW special service tools
to enable BMW factory trained service
technicians to perform quality repairs on your
BMW in minimal time, to help maximize your
satisfaction with your BMW, its longevity, and
resale value.
BMW i3 with Range Extender
The small gasoline-powered internalcombustion engine which serves as a generator
to the high-voltage (HV) battery does not propel
the vehicle directly.This range-extending engine
is thereby not subjected to the typical speed
ranges and loads as an engine which does propel
an automobile. The two spark plugs and the
intake air filter are rated for extended life.
4
BMW recommends the use of BMW fully
synthetic oil, viscosity range 5W-30 of the
long-life rating LL01 (API rating SL). If this is not
available, be sure to use another synthetic oil that
meets the same viscosity range and long-life
rating.
The oil level can be checked with a dipstick,
accessed from the cargo compartment floor. If
the oil level is at or beneath the lower mark on the
dipstick, have your authorized BMW center fill the
engine oil. There is no oil filler cap which can be
accessed by the driver.
The Range Extender engine’s oil must be
changed every 12 months.
Quality Certification I
For a detailed list of items inspected, refer to the
Quality Certification I form provided to the Owner
at time of delivery. A copy of the form is on file at
the selling authorized BMW center.
Maintenance Service Summary
The Condition Based Service (CBS) system will
determine the requirement for performing the
maintenance services described in this section,
ending on page 6 (excluding items noted as “not
shown in CBS”). These services may be required
either individually or in conjunction with other
maintenance services.
Maintenance services are performed as outlined
in this section, based on intervals of either time,
mileage or after performing a specified number
of previous services. These intervals correspond
to the latest information available when this
Booklet was printed. Maintenance intervals are
subject to change with newer vehicles or may
also apply retroactively. Your authorized BMW
center will be able to advise and perform
maintenance services as required by the most
recent information that applies to your vehicle.
Standard operations
Maintenance work:
䉯 Verify Check Control messages.
䉯 Check indicator and warning lights.
䉯 Reset CBS display.
䉯 Inspect tires, adjust tire pressures and reset
Tire Pressure Monitor.
䉯 Check parking brake functionality while the
vehicle is being driven into the workshop.
䉯 Check thickness of all brake pads using
special tool.
HV battery:
䉯 Check and record the customer’s charge
setting in the central display.
䉯 Charge the HV battery.
Tires:
䉯 Check and adjust inflation pressure if needed:
Refer to the door edge label or the “Wheel and
Tire” section in the Owner’s Manual.
䉯 Check tire size: Refer to the door edge label or
the “Wheel and Tire” section in the Owner’s
Manual.
Test Drive:
䉯 Apply service brakes as needed to clean any
surface corrosion off the brake discs.
Maintenance services connected to a
specific service*
*This additional connected service will not be
shown in the vehicle’s CBS display.
Maintenance work:
䉯 Replace ventilation microfilter every 2 years
based on the vehicle production date, or in
connection with scheduled brake fluid change.
Maintenance services that display in
CBS
Engine Oil (BMW i3 with Range
Extender only; as of 7/2014
production)
Maintenance work:
䉯 Change the engine oil and oil filter. We
recommend BMW High Performance 5W-30
Synthetic Oil P/N 07 51 0 017 866.
5
Vehicle check
Maintenance work:
䉯 Check operation of horn, headlight flasher and
䉯 Safety belts: Check condition and function.
䉯 Check windshield wiper and washer jet
positions.
䉯 Mobility Kit: Check expiration date on sealant
container. Replace container if expired.
䉯 Tires: Check tread depth, wear pattern, outer
condition, inflation pressure. If necessary,
correct pressure.
䉯 Reset Tire Pressure Monitor.
䉯 Power steering: Check function.
䉯 Visually inspect all SRS airbag units for torn
covers, obvious damage or attachment of
stickers.
䉯 Rear-view mirrors.
䉯 Retorque the bolt for the door stop mechanism
at each front and rear door pillar.
䉯 Windshield washer and intensive cleaning
systems: Check protection level, fluid level; top
up if necessary.
䉯 Check the coolant level and anti-freeze
concentration for the drive circuit (underhood).
䉯 Check the coolant level and anti-freeze
concentration for the vehicle interior heating
circuit (underhood; uses a different coolant
fluid than for the drive coolant circuit).
䉯 Range Extender: Check the coolant level and
anti-freeze concentration (underfloor).
䉯 Brake system connections and lines: Check
for leaks, damage and correct positioning.
䉯 Underbody, incl. all visible parts (i.e.,
transmission, rear axle): Check for damage,
leaks and corrosion.
䉯 Check the occasional use charging cable for
damage (cuts, breakage, deformation),
corrosion and wear.
䉯 Steering components: Check for clearance,
leaks, damage and wear.
䉯 Final Inspection: Road test with check of:
–Brakes
– Steering
– Shock absorbers (visual)
Brake fluid
Maintenance work:
䉯 Replace brake fluid.
Maintenance services that display in
CBS (as of 7/14 production)
Front brakes
Maintenance work:
䉯 Replace brake pads and the brake wear
sensor; clean brake pad contact points in
calipers.
䉯 Lightly grease the wheel hub contact points to
prevent corrosion.
䉯 Brake discs: Check surface and thickness;
replace as necessary.
Rear brakes
Maintenance work:
䉯 Replace brake pads and brake wear sensor;
clean brake pad contact points in calipers.
䉯 Lightly grease the wheel hub contact points to
prevent corrosion.
䉯 Brake discs: Check surface and thickness;
replace as necessary.
䉯 Parking brake: Repair or replace parking brake
shoes/linings only if a reduction in the brake’s
effectiveness is noted. When fitted, parking
brake shoes/linings are excluded from
coverage under the BMW Maintenance
Program.
6
High-Voltage Lithium-Ion Battery
Care and Repairs
The BMW i3 and BMW i3 with Range Extender
are powered by a high-voltage lithium-ion battery
enclosed in a self-contained system. Opening or
removing the self-contained system creates a
genuine risk of severe damage to the highvoltage lithium-ion battery as well as personal
injury, including fatal electrocution.
The high-voltage lithium-ion battery requires no
maintenance except for keeping the vehicle’s
high-voltage lithium-ion battery charged to
proper specifications; refer to the Owner’s
Manual.
For the entire duration of the high-voltage
lithium-ion battery Limited Warranty and the
high-voltage lithium-ion battery Capacity
Coverage, repairs performed according to limited
warranties and capacity coverage are provided
without charge. The vehicle should be taken to
an authorized BMW center to have these repairs
performed by specially trained personnel under
the terms of the high-voltage lithium-ion battery
Limited Warranty and the high-voltage lithiumion battery Capacity Coverage.
Restoring corrosion protection
Please take care that anti-corrosion material is
replaced when your car is repaired after body or
chassis damage.
BMW will not accept any liability for repair of,
or damage caused by, any parts and
accessories not approved by BMW.
BMW Roadside Assistance
The BMW Roadside Assistance Program
reflects BMW’s commitment to your
complete satisfaction with the BMW
ownership experience.
It’s available for U.S. version BMWs in all
50 states, Canada, and Puerto Rico 24 hours a
day, 365 days a year.
It’s a valuable benefit provided to you at no
additional cost. (Subject to certain limitations and
exclusions noted on page 10.)
The BMW Roadside Assistance Program is not a
warranty and does not affect your rights under
the New Vehicle Limited Warranty.
Services provided by a third-party business partner.
Corrosion Protection
Extensive corrosion protection measures
implemented by BMW now make it possible to
offer a 12-year unlimited mileage anti-corrosion
warranty against rust perforation on your vehicle
provided that the vehicle is properly maintained.
Information on proper maintenance is available in
this Booklet and your vehicle’s Owner’s Manual.
Body parts are designed to provide optimum
corrosion protection.
During manufacture, metal exterior body parts
receive an additional corrosion protection coat.
Corrosion protection materials tested over many
years are applied to the surfaces of cavities and
to the entire underside of the vehicle during and
after assembly.
For additional information on the 12-year
unlimited mileage anti-corrosion warranty, see
the Warranty Section of this Booklet (page 19).
BMW Roadside Assistance
Smartphone Application
The free BMW Roadside Assistance Smartphone
App dispatches fast, reliable service to your
BMW. For more details and to download the App
for your iPhone®, Android™ or Windows
Mobile® Smartphone, visit
http://roadsidemobile.com/bmw
Owner’s Eligibility
You are covered if your vehicle is:
䉯 A new BMW automobile, distributed by
BMW NA, and purchased at an authorized
BMW center, OR;
䉯 A new BMW automobile, purchased under the
BMW NA European Delivery Plan, OR;
䉯 A new, U.S. version, BMW automobile
purchased under the Diplomatic or Military
Sales programs, operated in any of the
50 states, Canada and Puerto Rico.
7
The vehicle itself is covered when driven by any
authorized driver.
Protection:
New BMWs — Protection is provided for
4 years/unlimited miles. NOTE: This does not
affect warranty coverage which remains at
4 years/50,000 miles.
Certified Pre-Owned BMWs — 6 years/unlimited
miles from the original in-service date.
Getting Started
For your convenience, a decal showing Roadside
Assistance information has been affixed on the
driver’s side of the windshield and in the rear
compartment area.
Calling For Assistance
The toll-free BMW Roadside Assistance number
(1 800 497-9940) is answered by a BMW
Roadside Assistance service representative. In
order for you to receive quick and reliable
services, it is essential that you provide detailed
and accurate information to the service
representative.
Be prepared to give:
䉯 Your name.
䉯 Your complete Vehicle Identification Number
(found on your vehicle registration, or on the
bottom driver’s side of your windshield).
䉯 Model description of your vehicle.
䉯 License plate number of your vehicle.
䉯 Vehicle location (including nearby crossroads/
intersections, highway mile markers, street
numbers, landmarks, etc.)
䉯 Location you are calling from (including a
telephone number where you can be reached).
If you are calling from a public phone, wait
there for the return call. Do not leave this
location without informing the Roadside
Assistance service representative.
䉯 A description of your vehicle’s problem.
Specific and accurate information will enable
the Roadside Assistance service
representative to provide the proper help.
Note: If you are using the free BMW Roadside
Assistance Smartphone App, the information
above is not required.
Emergency Valet Service. Should there be a
need beyond BMW Roadside Assistance,
Emergency Valet service will provide a personal
assistant who will help in every way to get you to
your final destination. Emergency Valet service
will help you locate a rental car or taxi agency,
hotel or even help procure airline reservations. In
the event of an emergency, this service will assist
you in getting information out to the proper party,
whether it is business or personal. If we are
unable to contact one of your party, the message
relay service will document the information, and
will make reasonable efforts to deliver the
message to the message recipient.
Personal Trip Routing. Leave the planning to
us. Simply give one of our Roadside Assistance
service representatives a call, and we will provide
you with a detailed, easy to read, computerized
trip itinerary and companion map package.
Please allow up to two weeks to process your
request.
Services
From the information you provide, the BMW
Roadside Assistance service representative will
determine the type of help required.
Dispatch Service
A service provider will be dispatched to the site
of your disabled vehicle.
On-Site Assistance
On-site service for vehicle disablements such as
flat tires is provided up to a maximum of $100.00
per incident by BMW Roadside Assistance.
The cost for parts, when used on-site, are the
responsibility of the owner/driver. The New
Vehicle Limited Warranty does not cover any of
the above on-site services.
8
Loading...
+ 26 hidden pages
You need points to download manuals.
1 point = 1 manual.
You can buy points or you can get point for every manual you upload.
