SILVERCREST SEAS 20 A1 User manual [gb]

ELECTRIC ALL-PURPOSE SHARPENER SEAS 20 A1

ELECTRIC ALL-PURPOSE
SHARPENER

Operating instructios

ELEKTRISCHER ALLESSCHÄRFER

Bedienungsanleitung

IAN 103775

ΗΛΕΚΤΡΙΚΗ ΣΥΣΚΕΥΗ
ΑΚΟΝΙΣΜΑΤΟΣ ΓΕΝΙΚΗΣ
ΧΡΗΣΗΣ

Οδηүίες χρήσης

Before reading, unfold the page containing the illustrations and familiarise
yourself with all functions of the device.

Πριν ξεκινήσετε την ανάγνωση, ανοίξτε τις δυο σελίδες με τις εικόνες και
εξοικειωθείτε με όλες τις λειτουργίες της συσκευής.

Klappen Sie vor dem Lesen die Seite mit den Abbildungen aus und machen
Sie sich anschließend mit allen Funktionen des Gerätes vertraut.

GB / IE / CY Operating instructions Page 1
GR / CY Οδηүίες χρήσης Σελίδα 11
DE / AT / CH Bedienungsanleitung Seite 21

A

B

C

E

D

F

INDEX PAGE

Introduction 2

Intended use 2

Items supplied 2

Technical data 2

Appliance description 3

Safety instructions 3

Unpacking 5

Placement 5

Adjustment 5

Sharpening 6

Cleaning and Care 7

Maintenance 8

Disposal 9

Importer 9

Warranty and Service 9

- 1 -

Introduction

Congratulations on the purchase of your new appliance.
You have clearly decided in favour of a quality product. These operating
instructions are a part of this product. They contain important information in
regard to safety, use and disposal. Before using the product, familiarise
yourself with all of these operating and safety instructions. Use the product
only as described and only for the specified areas of application. In addition,
pass these documents on, together with the product, to any future owner.

Intended use

This appliance is intended for the sharpening of knives, screwdrivers and scissors
in domestic households. This appliance is not intended for commercial or in­dustrial applications.

Items supplied

1 x Electric All-Purpose Sharpener
1 x Operating Instructions

Technical data

Power consumption : 20 W max.
Mains voltage: 230 V ~, 50 Hz
Revolutions: 3000 min
Protection class: II
C.O. Time: 3 min.

-1

- 2 -

The C.O. Time (Continuous Operation) details how long an appliance may be
used without the motor overheating and being damaged. When the specified
C.O. Time has been reached, the appliance must be switched off until the
motor has cooled itself down to room temperature (approx. 30 minutes).

Appliance description

Function “Knife with smooth edge”

q

Function “Knife with serrated edge”

w

Function “Scissor sharpening”

e

Grinder openings for slot-screwdrivers

r

Grindstone

t

Function and protective cap

y

Abrade collector

u

Switch

i

Safety instructions

To avoid potentially fatal electric shocks:

• Protect the appliance against moisture. Use it only in
dry rooms, do not use it outdoors or in damp areas.

• Ensure that the power cable cannot be damaged when
the appliance is in use, particularly not by sharpened
knife or scissor blades.

• Arrange for defective power plugs and/or cables to be
replaced as soon as possible by a qualified technician
or by our Customer Service Department to avoid the
risk of injury.

• NEVER open any housing components, other than those
specified herein.

- 3 -

• After use or during extended absences, ALWAYS remove
the plug from the power socket. For as long as the plug
is inserted in the wall socket the appliance itself is under
electrical power.

• Ensure that the power plug is at all times easily accessible,
so that it can be quickly and easily removed in the
event of potential danger or risk.

To

avoid the risks of accidents and personal injuries:

• Always check to ensure that the appliance is in a service­able condition before taking it into use. If there is recognis­able damage to the appliance it may not be used. Arran­ge for it to be safety-checked by Customers Services
before using it again.

• Take steps to ensure that hair, loose clothing and parts
of the body do not come into contact with the revolving
grindstone t.

• Wear protective gloves so as to avoid injury from sharp
blades, or, if you are operating the knife sharpener with
the function and protective cap yremoved.

• This appliance may not be used by children.

• The appliance should always be disconnected from the
mains when not supervised and before assembly, disas­sembly or cleaning.

• The appliance and its connecting cable must be kept
away from children.

• Children must not play with the device.

- 4 -

• This appliance may be used by people with reduced
physical, sensory or mental capabilities or lack of
experience and/or knowledge if they are supervised
and have been instructed in how to use the appliance
safely and have understood the potential risks.

Unpacking

• Check that all items listed are available and that they show no signs of
visible damage.

• Remove all parts from the packaging and all packaging remnants from
the items.

• Retain the packaging, either for storing the appliance or for reuse in the
event of posting it to Customer Services for repair.

• Before the first usage thoroughly clean all component parts as described
in the section "Cleaning and care".

Placement

• Place the appliance on a stable and slip-free surface.

• Then insert the plug into the power socket.

Adjustment

• To select the required sharpening function
and protective cap

• In position
to the grinder opening (See Fig. C) – however, the cap engages at the
point at the end of the symbol.

• Hold the switch
ly until the switch

w

until the cap perceptibly engages.

y

"Knife with serrated edge", the corresponding symbol points

pressed down. The grindstone trevolves continuous-

i

is released.

i

q w e

- 5 -

, turn the function

Sharpening

• First present the blade when the grindstone tis revolving.

• Always draw the knife or scissors back, from the blade stop, in an even
movement, not in a repetitive back and forth movement – otherwise the
result will be an uneven sharpening.

• Do not apply any great pressure and always sharpen only clean blades,
so as to avoid a premature wearing-out of the grindstone.

• Always sharpen knives and scissors so that the blade is at an acute angle
to the grindstone (as alluded to in the shape of the opening). Sharpening
at the false angle can destroy any blade.

• After sharpening, remove any possible grinding remnants that may be on
the blade with a moist cloth.

Knife with smooth edge

If you have selected the setting "Knife with smooth edge" q (Fig. B):

• Always sharpen knives with a smooth edge on both sides – for this, left
and right side sharpening guides are available.

• In the left guide hold the knife inclined to the left, and in the right guide
inclined to the right, whilst drawing the blade through.

Knife with serrated edge

If you have selected the setting "Knife with serrated edge" w (Fig. C):

• Sharpen these only on the side with the serration – the draw through
direction for the knife is dependant on which side of the blade this is on.
The side with the serrated edge must be pointing in the direction of the
grindstone

• In general, serrated blades can only be sharpened up to a point. Knifes
with a fine sawtoothing (e.g. table knives) do not require sharpening.

during sharpening.

t

- 6 -

Scissor sharpening

If you have selected the setting "Scissor sharpening" e (Fig. D):

• Sharpen both scissor blades one after the other. For this, open the scissors
out and draw both blades, one after the other, through the guide.

Flat-head screwdriver

Should you wish to grind a slot-screwdriver rflat (Fig. E):

• This is possible in every position of the function and protective cap
Appropriate to its width, insert the screwdriver through one of the two grin­ding openings
end face of the screwdriver will now be ground level and flat.

on the front of the function cap (see fold-out side). The

r

y

.

Grinding directly on the grindstone

Certain edges can possibly be more easily sharpened directly on the grind­stone

, without the function and protective cap y: For these cases, the

t

function and protective cap

• Turn the function and protective cap
You can now take off the function and protective cap

• To replace the function and protective cap
is once again at the top. You can now push the function and protective
cap

on and secure it by turning it to the left or right.

y

is removable (Fig. F):

y

y

until the arrow is at the top.

.

y

, hold it so that the arrow

y

Cleaning and Care

To avoid risks of personal injury and damage:

• Before carrying out any maintenance work, first remove the plug from the
wall socket.

• NEVER submerse the appliance in water or other liquids! These could
damage the appliance. Additionally, there is a potentially fatal risk of
electric shock should moisture come into contact with electrical components.

- 7 -

Cleaning the appliance:

• Turn the function and protective cap
top. You can now remove the function and protective cap
the area around the grindstone

• Dismantle the abrade collector
necessary, a lightly moistened cloth.

• Clean the remaining parts of the appliance also with a lightly moistened
cloth, not with abrasive or aggressive detergents. They can damage the
surfaces.

• To replace the function and protective cap
is once again at the top. You can now push the function and protective cap
cap on and secure it by turning it to the left or right. To conclude, reassem­ble the abrade collector

into the appliance.

u

, until the arrow is at the

y

y

with a dry brush.

t

and clean it with a brush and, if

u

, hold it so that the arrow

y

and clean

y

Maintenance

• The appliance is maintenance-free. No form of maintenance, either on
or in the appliance, is intended for execution by the user. In the event of
malfunction or apparent damage, make contact with Customer Services.

• For storage, wrap the power cable around the appliance housing (Fig. A).
