DUAL HOTPLATE SDK 2100 A1
DUAL HOTPLATE
Operating instructions
DOPPELKOCHPLATTE
Bedienungsanleitung
IAN 339256_1910
ΜΑΓΕΙΡΙΚΗ ΕΣΤΙΑ ΔΙΠΛΗ
Οδηүίες χρήσης
Before reading, unfold the page containing the illustrations and familiarise yourself with all functions of
the device.
Πριν ξεκινήσετε την ανάγνωση, ανοίξτε τη σελίδα με τις εικόνες και εξοικειωθείτε με όλες τις λειτουργίες
της συσκευής.
Klappen Sie vor dem Lesen die Seite mit den Abbildungen aus und machen Sie sich anschließend mit allen
Funktionen des Gerätes vertraut.
GB / IE / NI / CY Operating instructions Page 1
GR / CY Οδηүίες χρήσης Σελίδα 13
DE / AT / CH Bedienungsanleitung Seite 25
Table of Contents
Introduction .........................................................2
Copyright ......................................................................2
Limitation of liability ..............................................................2
Intended use ...................................................................2
Package contents ....................................................2
Disposal of packaging ............................................................3
Appliance description .................................................3
Technical details .....................................................3
Energy consumption .................................................4
Safety instructions ...................................................5
Setting up and connecting .............................................6
Energy-efficient cooking ...............................................7
Operation ..........................................................7
Cleaning and care ....................................................8
Storage .......................................................................8
Fault rectification .....................................................9
Disposal ............................................................9
Kompernass Handels GmbH warranty ..................................10
Service .......................................................................11
Importer ......................................................................11
SDK 2100 A1
GB│IE│NI│CY
│
1 ■
Introduction
Congratulations on the purchase of your new appliance!
You have clearly decided in favour of a modern, high-quality product. These operating
instructions are a constituent of this product. They contain important information on safety,
use and disposal. Before using the product, familiarise yourself with all operating and
safety instructions. This appliance must only be used as described and for the purposes
indicated. Please also pass these operating instructions on to any future owner(s).
Copyright
This documentation is subject to copyright protection.
Any copying or reproduction, including extracts thereof, and the reproduction of
images (even in a modified state), is only permitted with the written authorisation
of the manufacturer.
Limitation of liability
All technical information, data and information for installation, connection and operation
contained in these operating instructions correspond to the latest state at time of printing
and, to the best of our knowledge, take into account our previous experience and
know-how.
No claims can be derived from the details, illustrations and descriptions in these instructions.
The manufacturer assumes no responsibility for damage caused by failure to observe
these instructions, improper use, incompetent repairs, making unauthorised modifications
or for using unapproved replacement parts.
Intended use
This appliance is intended exclusively for heating food up.
The appliance is intended exclusively for use in domestic households. Not for
commercial use!
Package contents
This appliance is supplied with the following components as standard:
▯ Dual Hotplate
▯ Operating instructions
1) Remove all parts of the appliance and the operating instructions from the box.
2) Remove all packaging materials as well as foils and stickers.
3) Clean all parts of the appliance as described in the section “Cleaning and care”.
NOTE
► Check the delivery for completeness and for signs of visible damage.
► If the delivery is not complete or has been damaged due to defective packaging
or transportation, contact the Service Hotline (see section Service).
■ 2 │ GB
│IE│NI│
CY
SDK 2100 A1
Disposal of packaging
The packaging protects the appliance from transport damage. The packaging materials
have been selected in accordance with their environmental friendliness and disposal
attributes, and are therefore recyclable.
Returning the packaging to the material cycle conserves raw materials and reduces
the amount of waste that is generated. Dispose of packaging material that is no longer
needed in accordance with applicable local regulations.
Dispose of the packaging in an environmentally friendly manner. Note the labelling
on the packaging and separate the packaging material components for disposal if
necessary. The packaging material is labelled with abbreviations (a) and numbers (b)
with the following meanings: 1–7: plastics, 20–22: paper and cardboard,
80–98: Composites
NOTE
► If possible, keep the appliance's original packaging during the warranty period so that
the appliance can be packed properly for returning in the event of a warranty claim.
Appliance description
Large hob
Small hob
On/Off switch
Indicator lamp small hob
Thermostat small cooking plate
Thermostat large hob
Indicator lamp large hob
Technical details
Appliance
Voltage
Power consumption 2100 ‒ 2500 W
Energy consumption 191.38 Wh/kg
Large hob
Power consumption large hob 1250 - 1500 W
Diameter of large hob 18 cm
Energy consumption of large hob 193.98 Wh/kg
Small hob
Power consumption small hob 850 - 1000 W
Diameter of small hob 15 cm
Energy consumption of small hob 188.79 Wh/kg
SDK 2100 A1
220 ‒ 240 V ∼ (alternating current),
50-60 Hz
GB│IE│NI│CY
│
3 ■
Energy consumption
(tested in accordance with Regulation (EU) No. 66/2014, Annex I, sections 2 and 2.2)
Symbol Value Unit
Model designation SDK 2100 A1
Hotplate type - Household hotplate -
Number of hobs and/
or cooking areas
Heating technology
(induction hobs and
areas, radiant heat
hobs, cooking plates)
In the case of circular
cooking plates or areas:
diameter of effective
area per hob, rounded
up to the next 5 mm
In the case of non-circular hobs or cooking
areas: length and
width of effective area
per electrically-heated
hob or cooking area
rounded up to the next
5 mm
Energy consumption per
hob or cooking area,
calculated per kg
Hob energy consumption per kg
-2-
- Hotplates -
Ø 18 15 cm
L N/A cm
B N/A cm
EC
electric cookers
EC
hob
193.98 188.79 Wh/kg
191.38 Wh/kg
■ 4 │ GB
│IE│NI│
CY
SDK 2100 A1
Safety instructions
RISK OF ELECTRIC SHOCK
► To avoid risks, arrange for defective plugs and/or power cables
to be replaced at once by qualified technicians or our Customer
Service Department.
► Never hold the appliance, power cable or power plug with wet
hands. There is the risk of receiving an electric shock.
► Do not fold or crush the power cable.
► To disconnect, always remove the power plug itself from the mains
power socket, do not pull on the power cable.
► The appliance must only be connected to a correctly installed and
easily accessible mains power socket. Ensure that the rating of the
local power supply corresponds with the details on the rating plate of
the appliance.
► Do not use the appliance in the close vicinity of a bathtub/shower
or a sink filled with water. The proximity of moisture presents a
danger even when the appliance is switched off.
► The appliance is suitable for use only in dry areas.
NEVER submerse the appliance in water or other liquids.
WARNING! RISK OF INJURY!
► This appliance may be used by children aged 8 or over and by
persons with reduced physical, sensory or mental capabilities or
lack of experience and knowledge, provided that they are under
supervision or have been told how to use of the appliance safely
and are aware of the potential risks.
► Children younger than 8 years of age must be kept away from the
appliance and the power cable.
► Children must not play with the appliance.
► Cleaning and user maintenance must not be performed by chil-
dren unless they are older than 8 years of age and are supervised.
► After use, allow the appliance to cool down before transporting it.
SDK 2100 A1
GB│IE│NI│CY
│
5 ■
WARNING! RISK OF INJURY!
► Route the power cable in such a way that no one can tread on or
trip over it.
► Never touch the cooking plates during use as these become very
hot.
► Do not use extension cables. The plug must be quickly accessible
in an emergency.
► Do not use an external timing switch or a separate remote control
system to operate the appliance.
Caution! Hot surfaces.
CAUTION - RISK OF FIRE!
► Never leave the appliance unattended while it is being used.
► When the appliance is in use ensure that there are no easily inflamma-
ble materials close to it (e.g. dishcloths, oven cloths etc.).
► If you do not intend to use the appliance for an extended period,
you must disconnect it from the power source. The appliance is
only completely without current when the power plug has been
pulled out of the socket.
Setting up and connecting
1) Place the appliance on a stable, level and heat-resistant surface.
2) Insert the plug into a mains power socket.
3) Switch the appliance on by switching the On/Off switch to the position “I”.
4) Set the two thermostats / to MAX and allow the hobs / to heat up for
about 3 minutes without any pan on them.
This can cause slight smoke development since the protective coating which has
been applied will burn in. Ensure there is sufficient ventilation. For example, open
a window.
5) Switch off the hobs / after 3 minutes.
■ 6 │ GB
│IE│NI│
CY
SDK 2100 A1
Energy-efficient cooking
■ Use cooking pots with the same diameter as the respective hob /. If you use
particularly small pots that do not cover the whole hob /, a great deal of
energy is simply wasted.
■ Ensure that the pots/pans rest flat on the hobs /. Dented or uneven bottoms
prevent optimum heat conduction.
■ To save energy, you can turn off the hob / before you have completely
finished cooking. The residual heat of the hob / is usually sufficient to finish
cooking the food.
Operation
NOTE
► Use cooking utensils with flat, even bases for better thermal transfer.
► If possible, use cooking utensils which match the cooking plate sizes.
1) Place the filled saucepan on the required hob /.
2) Switch the appliance on by sliding the On/Off switch to the position “I”.
3) Turn the relevant thermostat / to the required setting:
▯ 0: switched off
▯
▯ 4–MAX: fast cooking
The relevant indicator lamp
- 4: slow cooking
/
for the
hob /
you have switched on illuminates.
If you do not intend to use the appliance for an extended period, remove the plug from
the power socket.
SDK 2100 A1
NOTE
► The control lamp / remains lit while the hob / is heating up. As soon
as the selected temperature has been reached, the control lamp / goes
off. During operation, it is possible that the control lamp / switches on and
off. This is not a malfunction of the appliance, merely an indication that the hob
/is reheating occasionally to maintain the temperature.
4) Once the cooking process has finished, adjust thermostat / back to 0.
The indicator lamp / goes out.
5) Turn the On/Off switch to “O”.
GB│IE│NI│CY
│
7 ■
Cleaning and care
RISK OF ELECTRIC SHOCK
► Before cleaning, ALWAYS remove the plug from the mains power socket.
Never submerse the appliance in water or other liquids.
WARNING! RISK OF INJURY!
► Allow the appliance to cool down before cleaning it!
CAUTION - PROPERTY DAMAGE!
► Do not use abrasive, chemical or caustic cleaning agents to clean this appliance!
These can damage the appliance.
■ Wipe the appliance with a damp cloth. For stubborn soiling use a mild detergent
on the cloth.
Ensure that you remove all detergent residues with a moist cloth afterwards.
■ Please wait until the appliance is completely dry before using it again.
Storage
■ Store the appliance in a dry and dust-free place.
■ Wind the cable around the cable retainer on the underside of the appliance and
fasten the end with the cable clip.
■ 8 │ GB
│IE│NI│
CY
SDK 2100 A1
Fault rectification
Disposal
Malfunction
The plug is not inserted into
a mains power socket.
The appliance is
not working.
Never dispose of the appliance in the normal domestic waste.
This product is subject to the provisions of European Directive
2012/19/EU (Waste Electrical and Electronic Equipment).
Dispose of the appliance through an approved disposal centre or at your community
waste facility. Please observe the currently applicable regulations. Please contact your
waste disposal centre should you be in any doubt.
Your local community or municipal authorities can provide information on how to
dispose of the product.
The appliance is defective.
The appliance is not
switched on.
Cause Solution
Connect the plug to the power
supply.
In this case, contact the Customer Service.
Switch the appliance on using
the On/Off switch .
SDK 2100 A1
GB│IE│NI│CY
│
9 ■
Loading...
