LC-42/46D85U
SERVICE MANUAL
No. S98Q9LC42D85U
LCD COLOR TELEVISION
LC-42D85U
MODELS LC-46D85U
In the interests of user-safety (Required by safety regulations in some countries) the set should be restored to its original condition and only parts identical to those specified should be used.
OUTLINE
This model is based on the LC-52D85U and is changed some parts. This Service Manual covers the modifications alone. For the other points, refer to the LC-52D85U (No. S88N8LC52D85U) Service Manual.
CONTENTS
OUTLINE AND DIFFERENCES FROM BASE MODEL |
|
|
|
OUTLINE.................................................................... |
i |
|
DIFFERENCES FROM BASE MODEL...................... |
i |
SAFETY PRECAUTION |
|
|
|
IMPORTANT SERVICE SAFETY |
|
|
PRECAUTION........................................................... |
ii |
|
PRECAUTIONS A PRENDRE LORS DE LA |
|
|
REPARATION ........................................................... |
iii |
|
PRECAUTIONS FOR USING LEAD-FREE |
|
|
SOLDER .................................................................. |
iv |
|
PRECAUTIONS IN SERVICING THE HDCP- |
|
|
KEY ROM.................................................................. |
v |
CHAPTER 1. SPECIFICATIONS |
1-1 |
|
[1] |
SPECIFICATIONS ................................................. |
|
CHAPTER 2. OPERATION MANUAL |
2-1 |
|
[1] |
OPERATION MANUAL .......................................... |
|
CHAPTER 3. DIMENSIONS |
3-1 |
|
[1] |
DIMENSIONS ........................................................ |
|
CHAPTER 4. REMOVING OF MAJOR PARTS |
4-1 |
|
[1] REMOVING OF MAJOR PARTS (LC-42D85U) ..... |
||
[2] REMOVING OF MAJOR PARTS (LC-46D85U) ..... |
4-7 |
|
CHAPTER 5. ADJUSTMENT |
5-1 |
|
[1] |
ADJUSTMENT PROCEDURE ............................... |
|
CHAPTER 6. OVERALL WIRING DIAGRAM |
6-1 |
|
[1] OVERALL WIRING DIAGRAM (LC-42D85U) ........ |
||
[2] |
OVERALL WIRING DIAGRAM (LC-46D85U) ........ |
6-2 |
Parts Guide
Parts marked with "
" are important for maintaining the safety of the set. Be sure to replace these parts with specified ones for maintaining the safety and performance of the set.
This document has been published to be used for after sales service only.
The contents are subject to change without notice.
LC-42/46D85U
OUTLINE AND DIFFERENCES FROM BASE MODEL
OUTLINE
This model is based on the LC-52D85U and is changed some parts. This Service Manual covers the modifications alone. For the other points, refer to the LC-52D85U (No. S88N8LC52D85U) Service Manual.
DIFFERENCES FROM BASE MODEL
LIST OF CHANGED PARTS
Ref. No. |
Description |
LC-52D85U |
LC-42/46D85U |
Note |
|
(No. S88N8LC52D85U) |
(No. S98Q9LC42D85U) |
||||
|
|
|
|||
PRINTED WIRING BOARD ASSEMBLIES |
|
|
|
||
|
KEY Unit |
DUNTKE266FM02 |
← |
— |
|
|
MAIN Unit |
DUNTKE716FM01 |
← |
Some parts changed |
|
|
R/C, LED Unit |
DUNTKE868FM01 |
← |
— |
|
|
POWER Unit |
RDENCA295WJQZ |
RDENCA310WJQZ (LC-42D85U) |
— |
|
|
← (LC-46D85U) |
— |
|||
|
|
|
|||
|
|
|
|
|
|
LCD PANEL |
|
|
|
|
|
|
42”LCD Panel Module Unit |
— |
R1LK420D3LW50Z (LC-42D85U) |
Add |
|
|
46”LCD Panel Module Unit |
— |
R1LK460D3LW50Z (LC-46D85U) |
Add |
|
|
52”LCD Panel Module Unit |
R1LK520D3LW50Z |
— |
Delete |
|
|
|
|
|
|
|
MAIN Unit |
|
|
|
|
|
D1306 |
Photo Diode |
VHPGPFSV51V-1 |
VHPGPFSV51M-1 |
Change |
|
R601 |
Resistor |
VRS-CZ1JF000JY |
VRS-CZ1JF470JY |
Change |
|
R602 |
Resistor |
VRS-CZ1JF000JY |
VRS-CZ1JF470JY |
Change |
|
|
|
|
|
|
|
CABINET AND MECHANICAL PARTS
Please refer to a Parts list
PACKING PARTS AND ACCESSORIES
Please refer to a Parts list
i
LC-42/46D85U
SAFETY PRECAUTION
IMPORTANT SERVICE SAFETY PRECAUTION
Service work should be performed only by qualified service technicians who are thoroughly familiar with all safety checks and the servicing guidelines which follow:
WARNING
1.For continued safety, no modification of any circuit should be attempted.
2.Disconnect AC power before servicing.
•Using two clip leads, connect a 1.5k ohm, 10 watt resistor paralleled by a 0.15µF capacitor in series with all exposed metal cabinet parts and a known earth ground, such as electrical conduit or electrical ground connected to an earth ground.
•Use an AC voltmeter having with 5000 ohm per volt, or higher, sensitivity or measure the AC voltage drop across the resistor.
CAUTION: FOR CONTINUED PROTECTION AGAINST A RISK OF FIRE REPLACE ONLY WITH SAME TYPE FUSE.
F7000 (250V T6.3AH) (LC-46D85U)
F7000 (250V T5AH) (LC-42D85U)
•Connect the resistor connection to all exposed metal parts having a return to the chassis (antenna, metal cabinet, screw heads, knobs and control shafts, escutcheon, etc.) and measure the AC voltage drop across the resistor.
All checks must be repeated with the AC cord plug connection reversed. (If necessary, a nonpolarized adaptor plug must be used only for the purpose of completing these checks.)
Any reading of 0.75 Vrms (this corresponds to 0.5 mA rms AC.) or more is excessive and indicates a potential shock hazard which must be corrected before returning the monitor to the owner.
BEFORE RETURNING THE RECEIVER (Fire &
Shock Hazard)
Before returning the receiver to the user, perform the following safety checks:
3.Inspect all lead dress to make certain that leads are not pinched, and check that hardware is not lodged between the chassis and other metal parts in the receiver.
4.Inspect all protective devices such as non-metallic control knobs, insulation materials, cabinet backs, adjustment and compartment covers or shields, isolation resistor-capacitor networks, mechanical insulators, etc.
DVM
AC SCALE
1.5k ohm
10W
0.15 µF
5. |
To be sure that no shock hazard exists, check for leakage current |
|
TEST PROBE |
|
in the following manner. |
|
|
• |
Plug the AC cord directly into a 120 volt AC outlet. |
|
|
|
(for North America) |
|
|
• |
Plug the AC cord directly into a 110-240 volt AC outlet. |
TO EXPOSED |
CONNECT TO |
|
(for Others) |
||
|
METAL PARTS |
KNOWN EARTH |
|
|
|
|
GROUND |
///////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////
SAFETY NOTICE
Many electrical and mechanical parts in LCD color television have special safety-related characteristics.
These characteristics are often not evident from visual inspection, nor can protection afforded by them be necessarily increased by using replacement components rated for higher voltage, wattage, etc.
Replacement parts which have these special safety characteristics are identified in this manual; electrical components having such features
are identified by "
" and shaded areas in the Replacement Parts List and Schematic Diagrams.
For continued protection, replacement parts must be identical to those used in the original circuit.
The use of a substitute replacement parts which do not have the same safety characteristics as the factory recommended replacement parts shown in this service manual, may create shock, fire or other hazards.
///////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////
ii
LC-42/46D85U
PRECAUTIONS A PRENDRE LORS DE LA REPARATION
Ne peut effectuer la réparation qu' un technicien spécialisé qui s'est parfaitement accoutumé à toute vérification de sécurité et aux conseils suivants.
AVERTISSEMENT
1.N'entreprendre aucune modification de tout circuit. C'est dangereux.
2.Débrancher le récepteur avant toute réparation.
PRECAUTION: POUR LA PROTECTION CONTINUE CONTRE LES RISQUES D'INCENDIE, REMPLACER LE FUSIBLE
F7000 (250V T6.3AH) (LC-46D85U)
F7000 (250V T5AH) (LC-42D85U)
VERIFICATIONS CONTRE L'INCEN-DIE ET LE CHOC ELECTRIQUE
Avant de rendre le récepteur à l'utilisateur, effectuer les vérifications suivantes.
3.Inspecter tous les faisceaux de câbles pour s'assurer que les fils ne soient pas pincés ou qu'un outil ne soit pas placé entre le châssis et les autres pièces métalliques du récepteur.
4.Inspecter tous les dispositifs de protection comme les boutons de commande non-métalliques, les isolants, le dos du coffret, les couvercles ou blindages de réglage et de compartiment, les réseaux de résistancecapacité, les isolateurs mécaniques, etc.
5.S'assurer qu'il n'y ait pas de danger d'électrocution en vérifiant la fuite de courant, de la facon suivante:
•Brancher le cordon d'alimentation directem-ent à une prise de courant de 120V. (Ne pas utiliser de transformateur d'isolation pour cet essai). (pour l'Amérique du Nord)
•Brancher le cordon d'alimentation directem-ent à une prise de courant de 110-240V. (Ne pas utiliser de transformateur d'isolation pour cet essai). (pour les autres régions)
•A l'aide de deux fils à pinces, brancher une résistance de 1.5 kΩ 10 watts en parallèle avec un condensateur de 0.15µF en série avec toutes les pièces métalliques exposées du coffret et une terre connue comme une conduite électrique ou une prise de terre branchée à la terre.
•Utiliser un voltmètre CA d'une sensibilité d'au moins 5000Ω/V pour mesurer la chute de tension en travers de la résistance.
•Toucher avec la sonde d'essai les pièces métalliques exposées qui présentent une voie de retour au châssis (antenne, coffret métallique, tête des vis, arbres de commande et des boutons, écusson, etc.) et mesurer la chute de tension CA en-travers de la résistance. Toutes les vérifications doivent être refaites après avoir inversé la fiche du cordon d'alimentation. (Si nécessaire, une prise d'adpatation non polarisée peut être utilisée dans le but de terminer ces vérifications.)
La tension de pointe mesurèe ne doit pas dépasser 0.75V (correspondante au courant CA de pointe de 0.5mA).
Dans le cas contraire, il y a une possibilité de choc électrique qui doit être supprimée avant de rendre le récepteur au client.
DVM
ECHELLE CA
1.5k ohm
10W
0.15 µF SONDE D'ESSAI
AUX PIECES |
BRANCHER A UNE |
|
METALLIQUES |
||
TERRE CONNUE |
||
EXPOSEES |
||
|
/////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////
AVIS POUR LA SECURITE
De nombreuses pièces, électriques et mécaniques, dans les téléviseur ACL présentent des caractéristiques spéciales relatives à la sécurité, qui ne sont souvent pas évidentes à vue. Le degré de protection ne peut pas être nécessairement augmentée en utilisant des pièces de remplacement étalonnées pour haute tension, puissance, etc.
Les pièces de remplacement qui présentent ces caractéristiques sont identifiées dans ce manuel; les pièces électriques qui présentent ces particularités sont identifiées par la marque "
" et hachurées dans la liste des pièces de remplacement et les diagrammes schématiques.
Pour assurer la protection, ces pièces doivent être identiques à celles utilisées dans le circuit d'origine. L'utilisation de pièces qui n'ont pas les mêmes caractéristiques que les pièces recommandées par l'usine, indiquées dans ce manuel, peut provoquer des électrocutions, incendies, radiations X ou autres accidents.
/////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////
iii
LC-42/46D85U
PRECAUTIONS FOR USING LEAD-FREE SOLDER
Employing lead-free solder
•“PWBs” of this model employs lead-free solder. The LF symbol indicates lead-free solder, and is attached on the PWBs and service manuals. The alphabetical character following LF shows the type of lead-free solder.
Example:
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Indicates lead-free solder of tin, silver and copper. |
Indicates lead-free solder of tin, silver and copper. |
||||||||||
Using lead-free wire solder
•When fixing the PWB soldered with the lead-free solder, apply lead-free wire solder. Repairing with conventional lead wire solder may cause damage or accident due to cracks.
As the melting point of lead-free solder (Sn-Ag-Cu) is higher than the lead wire solder by 40 °C, we recommend you to use a dedicated soldering bit, if you are not familiar with how to obtain lead-free wire solder or soldering bit, contact our service station or service branch in your area.
Soldering
•As the melting point of lead-free solder (Sn-Ag-Cu) is about 220 °C which is higher than the conventional lead solder by 40 °C, and as it has poor solder wettability, you may be apt to keep the soldering bit in contact with the PWB for extended period of time. However, Since the land may be peeled off or the maximum heat-resistance temperature of parts may be exceeded, remove the bit from the PWB as soon as you confirm the steady soldering condition.
Lead-free solder contains more tin, and the end of the soldering bit may be easily corroded. Make sure to turn on and off the power of the bit as required.
If a different type of solder stays on the tip of the soldering bit, it is alloyed with lead-free solder. Clean the bit after every use of it. When the tip of the soldering bit is blackened during use, file it with steel wool or fine sandpaper.
•Be careful when replacing parts with polarity indication on the PWB silk.
Lead-free wire solder for servicing
PARTS CODE |
PRICE |
PART |
DESCRIPTION |
|
RANK |
DELIVERY |
|||
|
|
|||
ZHNDAi123250E |
BL |
J |
φ0.3mm 250g (1roll) |
|
ZHNDAi126500E |
BK |
J |
φ0.6mm 500g (1roll) |
|
ZHNDAi12801KE |
BM |
J |
φ1.0mm 1kg (1roll) |
iv
LC-42/46D85U
PRECAUTIONS IN SERVICING THE HDCP-KEY ROM
Applied part: HDCP-KEY ROM
IC8451 RH-IXC318WJQZY (updated ROM)
The HDCP-KEY ROM shall be protected and managed for its information inside. In servicing this ROM, therefore, take the following information protection/management measures.
1)When disposing of the component parts and PWBs, destruct the IC itself in a proper way. (For repairing or replacing the component parts and PWBs as well as clearing those in stock)
2)In storing the component parts, protect and manage them against theft and disclosure. (For storing the service parts, service units, etc.)
v
LC-42/46D85U
CHAPTER 1. SPECIFICATIONS
[1] SPECIFICATIONS
|
Item |
|
|
|
|
Model: LC-42D85U |
|
|
|
|
Model: LC-46D85U |
||||||||||||
|
|
|
|
|
|
|
|||||||||||||||||
LCD panel |
|
|
|
42" Class (421/64 " Diagonal) |
|
46" Class (4563/64 " Diagonal) |
|||||||||||||||||
|
|
|
Advanced Super View & BLACK TFT LCD |
|
Advanced Super View & BLACK TFT LCD |
||||||||||||||||||
|
|
|
|
|
|||||||||||||||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
||||||||
Resolution |
|
|
|
2,073,600 pixels (1,920 |
1,080) |
|
|
|
|
|
|
|
|
|
|
||||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
||||||||||
|
TV-standard (CCIR) |
American TV Standard ATSC/NTSC System |
|
|
|
|
|
|
|
|
|||||||||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|||||||||
|
|
|
VHF/UHF |
VHF 2-13ch, UHF 14-69ch |
|
|
|
|
|
|
|
|
|
||||||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|||||||||
|
|
|
CATV |
1-135ch (non-scrambled channel only) |
|
|
|
|
|
|
|
|
|
||||||||||
TV |
Receiving |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Digital Terrestrial |
2-69ch |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|||||
Function |
Channel |
Broadcast (8VSB) |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Digital cable*1 |
1-135ch (non-scrambled channel only) |
|
|
|
|
|
|
|
|
|
||||||||||
|
|
|
(64/256 QAM) |
|
|
|
|
|
|
|
|
|
|||||||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|||||
|
Audio multiplex |
BTSC System |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
||
Audio out |
|
|
|
10W |
2 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|||||||||
|
|
INPUT 1 |
AV in, COMPONENT in |
|
|
|
|
|
|
|
|
|
|
|
|||||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
||||||||||
|
|
INPUT 2 |
COMPONENT in, S-VIDEO in |
|
|
|
|
|
|
|
|
|
|||||||||||
|
|
|
|
|
|||||||||||||||||||
|
|
INPUT 4 |
ANALOG RGB (PC) in (15-pin mini D-sub female connector), Audio in (Ø 3.5 mm jack) |
||||||||||||||||||||
|
|
|
|
|
|
|
|
|
|
|
|
||||||||||||
|
|
INPUT 6 |
HDMI in with HDCP, Audio in (Ø 3.5 mm jack) |
|
|
|
|
|
|
|
|||||||||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|||||||
|
|
INPUT 7 |
HDMI in with HDCP |
|
|
|
|
|
|
|
|
|
|
|
|
|
|||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|||||||
|
Rear |
INPUT 8 |
HDMI in with HDCP |
|
|
|
|
|
|
|
|
|
|
|
|
|
|||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
||||||||
|
INPUT 9 |
HDMI in with HDCP |
|
|
|
|
|
|
|
|
|
|
|
|
|
||||||||
|
|
|
|
|
|
|
|
||||||||||||||||
Terminals |
|
ANT/CABLE |
75 |
|
Unbalance, F Type |
1 for Analog (VHF/UHF/CATV) and Digital (AIR/CABLE) |
|||||||||||||||||
|
|
AUDIO |
Audio in (Ø 3.5 mm jack) |
|
|
|
|
|
|
|
|
|
|
|
|||||||||
|
|
|
|
|
|
|
|
|
|
|
|||||||||||||
|
|
DIGITAL AUDIO OUTPUT |
Optical Digital audio output 1 (PCM/Dolby Digital) |
|
|
|
|
|
|
||||||||||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
||||
|
|
OUTPUT |
Audio out |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
||||||||||
|
|
RS-232C |
9-pin D-sub male connector |
|
|
|
|
|
|
|
|
|
|||||||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|||
|
|
INPUT 3 |
AV in |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|||||||
|
Side |
INPUT 5 |
HDMI in with HDCP |
|
|
|
|
|
|
|
|
|
|
|
|
|
|||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
||||||
|
|
SERVICE |
Software update |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
||||||||
OSD language |
|
|
English/French/Spanish |
|
|
|
|
|
|
|
|
|
|
|
|||||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
||||||||||
Power Requirement |
|
AC 120 V, 60 Hz (FOR NORTH AMERICA) |
|
|
|
|
|
|
|
|
|||||||||||||
|
AC 110-240 V, 50/60 Hz (FOR OTHERS) |
|
|
|
|
|
|
|
|
|
|||||||||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|||||||||||
|
|
|
|
|
|||||||||||||||||||
Power Consumption |
|
225 W (0.4 W Standby with AC 120 V) |
|
256 W (0.4 W Standby with AC 120 V) |
|||||||||||||||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|||||||||||
Weight |
|
TV + stand |
46.3 lbs./21.0 kg |
|
|
|
|
|
51.8 lbs./23.5 kg |
|
|
|
|||||||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
TV only |
39.7 lbs./18.0 kg |
|
|
|
|
|
41.9 lbs./19.0 kg |
|
|
|
||||||||||||
|
|
|
|
|
|
|
|
|
|
||||||||||||||
|
|
|
|
|
|
|
|
|
|
||||||||||||||
Dimension*2 |
|
TV + stand |
40 11/64 |
27 9/16 |
12 61/64 inch |
|
43 53/64 |
29 45/64 |
12 61/64 inch |
||||||||||||||
(W H D) |
TV only |
40 |
11 |
/64 |
25 |
9 |
/16 |
3 |
25 |
/32 |
inch |
|
43 |
53 |
/64 |
27 |
47 |
/64 |
3 |
29 |
/32 inch |
||
|
|
|
|
|
|
|
|
|
|||||||||||||||
Operating temperature |
|
+ 32°F to + 104°F (0°C to + 40°C) |
|
|
|
|
|
|
|
|
|
||||||||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
*1
*2
Emergency alert messages via Cable are unreceivable.
The dimensional drawings are shown on the inside back cover.
As part of policy of continuous improvement, SHARP reserves the right to make design and specification changes for product improvement without prior notice. The performance specification figures indicated are nominal values of production units. There may be some deviations from these values in individual units.
1 – 1
LC-42/46D85U
CHAPTER 2. OPERATION MANUAL
[1] OPERATION MANUAL
Part Names
TV (Front)
Remote control sensor
OPC sensor *
POWER indicator
OPC indicator
* OPC: Optical Picture Control
TV (Rear/Side)
POWER button
MENU button
INPUT button
Channel buttons (CH
/
)
Volume buttons (VOL
/ )
INPUT 5 terminal (HDMI)
INPUT 3 terminals
SERVICE terminal
AC INPUT terminal
INPUT 7 terminal (HDMI)
INPUT 9 terminal (HDMI)
INPUT 8 terminal (HDMI)
DIGITAL AUDIO OUTPUT terminal AUDIO OUTPUT terminals
Antenna/Cable in
INPUT 1 terminals
INPUT 2 terminals
RS-232C terminal
INPUT 4 terminal (PC-IN)
AUDIO terminal (shared for INPUT 4 and INPUT 6)
INPUT 6 terminal (HDMI)
The illustrations in this operation manual are for explanation purposes and may vary slightly from the actual operations.
The examples used throughout this manual are based on the LC-42D85U model.
2 – 1
|
|
|
LC-42/46D85U |
||
Part Names |
|
|
|
|
|
|
|
|
|
||
|
|
|
|
|
|
Remote Control Unit |
1 |
TV POWER: Switch the TV power on or enters standby. |
|||
|
|
|
|||
1 |
17 |
2 |
DISPLAY: Display the channel information. |
||
3 |
SOURCE POWER: Turns the power of the external equipment |
||||
|
|
||||
|
|
|
on and off. |
||
4External equipment operational buttons: Operate the external
|
|
|
equipment. |
2 |
|
5 |
0_9: Set the channel. |
|
|
|
|
3 |
18 |
6 |
(DOT): |
|
|
7INPUT: Select a TV input source. (TV, INPUT 1, INPUT 2, INPUT 3,
INPUT 4, INPUT 5, INPUT 6, INPUT 7, INPUT 8, INPUT 9)
4
|
19 |
5 |
|
6 |
20 |
7 |
21 |
8 |
22 |
9 |
23 |
10 |
24 |
|
25 |
11 |
26 |
12 |
27 |
|
|
13 |
28 |
14 |
29 |
|
30 |
15 |
|
16 |
|
8VOL
/ : Set the volume.
9POWER SAVING:Select Power Saving settings.
10FREEZE: Set the still image. Press again to return to normal screen.
11EXIT: Turn off the menu screen.
12OPTION: Display the AQUOS LINK MENU screen. This button will function only when AQUOS LINK is used.
13REC STOP: Stops one touch recording. This button will function only when AQUOS LINK is used.
14SLEEP:Set the sleep timer.
15SURROUND: Select Surround settings.
16AUDIO: Selects the MTS/SAP or the audio mode during multichannel audio broadcasts.
17FUNCTION: Switches the remote control for TV, CBL/SAT, VCR, DVD and AUDIO operation. Indicator lights up for the current mode.
* To enter the code registration mode, you need to press FUNCTION and DISPLAY at the same time.
18LIGHT
: When this button is pressed, some buttons (for example,VOL
/ and CH
/
) on the remote control unit will light. The lighting will turn off if no operations are performed within
about 5 seconds. This button is used for performing operations in low-light situations.
19VIEW MODE: Select the screen size.
20ENT: Jumps to a channel after selecting with the 0_9 buttons.
21FLASHBACK:Return to the previous channel or external input mode.
22CH
/
: Select the channel.
23MUTE: Mute the sound.
24MENU: Display the menu screen.
25
/
/
/
,ENTER: Select a desired item on the screen.
26RETURN: Return to the previous menu screen.
27FAVORITE CH
A, B, C, D: Select 4 preset favorite channels in 4 different categories.
When using the remote control unit, point it at the TV.
While watching, you can toggle the selected channels by pressing A, B, C and D.
28FAVORITE:Set the favorite channels.
29CC: Display captions from a closed-caption source.
30AV MODE: Select an audio or video setting.
(When the input source is TV, INPUT 1, 2 or 3: STANDARD, MOVIE, GAME, USER, DYNAMIC (Fixed), DYNAMIC. When the input source is INPUT 4, 5, 6, 7, 8 or 9: STANDARD, MOVIE, GAME, PC, USER, DYNAMIC (Fixed), DYNAMIC)
2 – 2
LC-42/46D85U
QUICK REFERENCE
Attaching the Stand
Before attaching (or detaching) the stand, unplug the AC cord from the AC INPUT terminal.
Before performing work spread cushioning over the base area to lay the TV on. This will prevent it from being damaged.
CAUTION
Attach the stand in the correct direction.
Do not remove the stand from the TV unless using an optional wall mount bracket to mount it.
Be sure to follow the instructions. Incorrect installation of the stand may result in the TV falling over.
1Confirm that there are 8 screws (4 short screws and 4 long screws) and a hex key supplied with the stand unit.
2Attach the supporting post for the stand unit onto the base using the box for the stand unit as shown below.
The supporting post attaches to the base at an off-centered location on the base. Be sure to attach the supporting post in the direction indicated below and attach the stand to the TV with the wider side of the base facing forward.
Hex key
Long screws
Forward
3Insert the stand into the openings on the bottom of the TV.
Insert and tighten the 4 short screws into the 4 holes on the rear of the TV.
|
Hex key |
|
2 |
Short screws |
2 |
|
Soft cushion
1
1
To detach the stand, perform the steps in reverse order.
2 – 3
LC-42/46D85U
Appendix
Removing the Stand
Before detaching (or attaching) the stand, unplug the AC cord from the AC INPUT terminal.
CAUTION
Do not remove the stand from the TV unless using an optional wall mount bracket to mount it.
Before attaching/detaching the stand
Before performing work, make sure to turn off the TV.
Before performing work spread cushioning over the base area to lay the TV on. This will prevent it from being damaged.
1
Hex key
Unfasten the four screws used to secure the stand in place.
2
Detach the stand from the TV. (Hold the stand so it will not drop from the edge of the base area.)
To attach the stand, perform the above steps in reverse order.
Setting the TV on the Wall
CAUTION
This TV should be mounted on the wall only with the wall mount bracket AN-52AG4 (SHARP). The use of other wall mount brackets may result in an unstable installation and may cause serious injuries.
Installing the TV requires special skill that should only be performed by qualified service personnel. Customers should not attempt to do the work themselves. SHARP bears no responsibility for improper mounting or mounting that results in accident or injury.
Using an optional bracket to mount the TV
You can ask a qualified service professional about using an optional AN-52AG4 bracket to mount the TV on the wall.
Carefully read the instructions that come with the bracket before beginning work.
Hanging on the wall
AN-52AG4 wall mount bracket.
(See the bracket instructions for details.)
About setting the TV angle
0/5 |
/15/20 |
° |
The " b" position is at the |
|
|||
/10 |
|
|
|
|
|
|
center of the display. |
|
|
|
Refer to the operation |
|
|
|
manual of AN-52AG4 for |
|
|
|
details. |
Vertical mounting Angular mounting
Detach the cable clamp on the rear of the TV when using the optional mount bracket.
To use this TV mounted on a wall, remove the covers at the 4 locations on the rear of the TV, and then use the screws supplied with the wall mount bracket to secure the bracket to the rear of the TV.
2 – 4
LC-42/46D85U
Appendix
Troubleshooting
Problem |
Possible Solution |
||
|
|
|
|
No power |
Check if you pressedTV POWER on the remote control unit. |
||
|
If the indicator on the TV does not light up, press POWER on the TV. |
||
|
Is the AC cord disconnected? |
||
|
Has the power been turned on? |
||
|
|
|
|
Unit cannot be operated. |
External influences such as lightning, static electricity, may cause improper operation. |
||
|
In this case, operate the unit after first turning off the power of the TV or unplugging |
||
|
the AC cord and replugging it in after 1 or 2 minutes. |
||
|
|
|
|
Remote control unit does not |
Is the FUNCTION set correctly? Set it to the TV setting position. |
||
operate. |
Are batteries inserted with polarity ( , |
|
) aligned? |
|
|||
|
Are batteries worn out? (Replace with new batteries.) |
||
|
Are you using it under strong or fluorescent lighting? |
||
|
Is a fluorescent light illuminated near the remote control sensor? |
||
|
|
|
|
Picture is cut off/with sidebar |
Is the image position correct? |
||
screen. |
Are screen mode adjustments such as picture size made correctly? |
||
|
|
|
|
Strange color, light color, or color |
Adjust the picture tone. |
||
misalignment |
Is the room too bright? The picture may look dark in a room that is too bright. |
||
|
Check the input signal setting. |
||
|
|
|
|
Power is suddenly turned off. |
Is the sleep timer set? |
||
|
Check the power control settings. |
||
|
The unit's internal temperature has increased. Remove any objects blocking vent or |
||
|
clean. |
||
|
|
|
|
No picture |
Is connection to other components correct? |
||
|
Is correct input signal source selected after connection? |
||
|
Is the correct input selected? |
||
|
Is picture adjustment correct? |
||
|
Is "On" selected in "Audio Only"? |
||
|
Is a non-compatible signal being input? |
||
|
|
|
|
No sound |
Is the volume too low? |
||
|
Is "Variable" selected in "Output Select"? |
||
|
Have you pressed MUTE on the remote control unit? |
||
|
|
|
|
The TV sometimes makes a |
This is not a malfunction. This happens when the cabinet slightly expands and |
||
cracking sound. |
contracts according to change in temperature. This does not affect the TV's |
||
|
performance. |
||
|
|
|
|
Troubleshooting-Digital Broadcasting
The error message about reception of broadcast
The example of an error message |
Error code |
Possible Solution |
|
displayed on a screen |
|||
|
|
||
|
|
|
|
Failed to receive broadcast. |
E202 |
Check the antenna cable. Check that the antenna is correctly |
|
setup. |
|||
|
|
||
|
|
|
|
No broadcast now. |
E203 |
Check the broadcast time in the program guide. |
|
|
|
|
Cautions regarding use in high and low temperature environments
When the unit is used in a low temperature space (e.g. room, office), the picture may leave trails or appear slightly delayed. This is not a malfunction, and the unit will recover when the temperature returns to normal.
Do not leave the unit in a hot or cold location. Also, do not leave the unit in a location exposed to direct sunlight or near a heater, as this may cause the cabinet to deform and the Liquid Crystal panel to malfunction.
Storage temperature: 4°F to
140°F ( 20°C to
60°C)
2 – 5
LC-42/46D85U
On-Screen Display Menu
Menu Items
For TV/INPUT 1/2/3 Mode |
For HDMI/PC-IN Mode |
Picture Menu |
Picture Menu |
OPC |
OPC |
Backlight |
Backlight |
Contrast |
Contrast |
Brightness |
Brightness |
Color |
Color |
Tint |
Tint |
Sharpness |
Sharpness |
Advanced |
Advanced |
C.M.S.-Hue |
C.M.S.-Hue |
C.M.S.-Saturation |
C.M.S.-Saturation |
Color Temp. |
Color Temp. |
Active Contrast |
Active Contrast |
Fine Motion Enhanced |
Fine Motion Enhanced |
I/P Setting |
I/P Setting |
Film Mode |
Film Mode |
Digital Noise Reduction |
Digital Noise Reduction |
3D-Y/C |
Monochrome |
Monochrome |
Range of OPC |
Range of OPC |
Reset |
Reset |
|
Audio Menu |
Audio Menu |
Treble |
Treble |
Bass |
Bass |
Balance |
Balance |
Surround |
Surround |
Bass Enhancer |
Bass Enhancer |
Reset |
Reset |
Power Control Menu |
Power Control Menu |
Power Saving |
Power Saving |
No Signal Off |
No Signal Off |
No Operation Off |
No Operation Off |
Setup Menu |
Setup Menu |
EZ Setup |
Input Skip |
CH Setup |
Input Signal |
Antenna Setup-DIGITAL |
Auto Sync. |
Input Skip |
Input Label |
Input Label |
Fine Sync. |
Parental CTRL |
Position |
Position |
Language |
Language |
Reset |
Reset |
|
Option Menu |
Option Menu |
AQUOS LINK Setup |
AQUOS LINK Setup |
Audio Only |
Audio Only |
Input Select |
HDMI Setup |
PC Audio Select |
PC Audio Select |
Output Select |
Output Select |
Color System |
Game Play Time |
Caption Setup |
Operation Lock Out |
Digital Caption Info. . |
Demo Mode |
Program Title Display |
|
Favorite CH |
|
Game Play Time |
|
Operation Lock Out |
|
Demo Mode |
|
Digital Setup Menu |
Digital Setup Menu |
Audio Setup |
Software Update |
Identification |
|
Software Update |
|
|
|
Some menu items may not be displayed depending on the selected input source.
2 – 6
Loading...
