Electrical Connections
(In the UK Only)
Important The wires in this mains lead are coloured in accordance with the following code :
GREEN AND YELLOW : EARTH
BLUE : NEUTRAL
BROWN : LIVE
This appliance must be earthed
As the colours of the wires in the mains lead of this apparatus may not correspond with the coloured markings identifying the terminals in your plug, proceed as follows :
The wire which is coloured Green and Yellow must be connected to the terminal in the plug which is marked with the letter E or by the earth symbol(
) or coloured Green or Green and Yellow.
The wire which is coloured Blue must be connected to the terminal which is marked with the letter N or coloured Black.
The wire which is coloured Brown must be connected to the terminal which is marked with the letter L or coloured Red.
If a 13 amp(BS 1363) plug is used, fit a 13 amp BS 1362 fuse.
1
Introduction
Installation
Operation
Suggestion on food storage
Care and maintenance
2
Table of contents
Important safety instruction |
|
3 |
|
3 |
|
Identification of parts |
|
5 |
Where to install |
|
8 |
Door removal |
|
9 |
Door replacement |
|
10 |
Feed water pipe installation |
10 |
|
Height adjustment |
|
11 |
Starting |
|
12 |
Adjusting the temperatures and functions (Dispenser / Automatic ice maker) |
13 |
|
Refreshment center (Applicable to some models only) |
18 |
|
Shelf (Applicable to some models only) |
19 |
|
Wine holder (Applicable to some models only) |
19 |
|
Egg box (Applicable to some models only) |
19 |
|
Location of foods |
|
20 |
Storing foods |
|
21 |
How to dismantle parts |
|
22 |
General information |
|
24 |
Cleaning |
|
24 |
Trouble shooting |
|
25 |
This product is exclusive use at 230V/50Hz.
You should purchase transformer of more than 2.0KVA when you want to use it at the 110V area.
You can't use it anywhere except 50Hz area.
Introduction
Entry
The model and serial numbers are found on the inner case or back of refrigerator compartment of this unit. These numbers are unique to this unit and not available to others. You should record requested information here and retain this guide as a permanent record of your purchase. Staple your receipt here.
Date of purchase |
: |
Dealer purchased from |
: |
Dealer address |
: |
Dealer phone no. |
: |
Model no. |
: |
Serial no. |
: |
Important safety instruction
Before it is used, this refrigerator must be properly installed and located in accordance with the installation instructions in this document.
Never unplug your refrigerator by pulling on the power cord. Always grip plug firmly and pull it straight out from the outlet.
When moving your appliance away from the wall, be careful not to roll over the power cord or to damage it in any way.
After your refrigerator is in operation, do not touch the cold surfaces in the freezer compartment, particularly when your hands are damp or wet. Skin could adhere to these extremely cold surfaces.
Unplug the power cord from the power outlet for cleaning or other requirements. Never touch it with wet hands because you can get an electric shock or be hurt.
Never damage, process, severely bend, pull out, or twist the power cord because damage the power cord may cause a fire or electric shock. You have doubts on whether the appliance is properly grounded.
Never place glass products in the freezer because they may be broken due to expansion when their contents are frozen.
Never allow your hands within the ice storage bin of the automatic ice maker. You could be hurt by the operation of the automatic ice maker.
The appliance is not intended for use by young children or infirm persons without supervision.
Young children should be supervised to ensure that they do not play with the appliance.
Never allow anyone to climb, sit, stand or hang on the refreshment center door. These actions may damage the refrigerator and even tip it over, causing severe personal injury.
Don’t use an If possible, connect the refrigerator to its own individual electrical outlet to prevent it and
extension cord other appliances or household lights from causing an overload that could cause a power outage.
Accessibility of The refrigerator-freezer should be so positioned that the supply plug is accessible for Supply Plug quick disconnection when accident happens.
Supply Cord If the supply cord is damaged, it must be replaced by the manufacturer or its service Replacement agent or a similarly qualified person in order to avoid a hazard.
Warning |
Do not modify or extend the Power Cord length. |
|
It will cause electric shock or fire. |
3
|
Introduction |
Warning |
Keep ventilation openings, in the appliance enclosure or in the built-in structure, |
|
clear of obstruction. |
Do not use mechanical devices or other means to accelerate the defrosting process, other than those recommended by the manufacturer.
Do not damage the refrigerant circuit.
Do not use electrical appliances inside the food storage compartments of the appliance, unless they are of the type recommended by the manufacturer.
The refrigerant and insulation blowing gas used in the appliance require special disposal procedures. When disposal, please consult with service agent or a similarly qualified person.
This appliance contains a small amount of isobutane refrigerant (R600a), natural gas with high environmental compatibility, but it is also combustible. When transporting and installing the appliance, care should be taken to ensure that no parts of the refrigerating circuit are damaged. Refrigerant squirting out of the pipes could ignite or cause an eye injury. If a leak is detected, avoid any naked flames or potential sources of ignition and air the room in which the appliance is standing for several minutes.
In order to avoid the creation of a flammable gas air mixture if a leak in the refrigerating circuit occurs, the size of the room in which the appliance may be sited depends on the amount of refrigerant used. The room must be 1m2 in size for every 8g of R600a refrigerant inside the appliance. The amount of refrigerant in your particular appliance is shown on the identification plate inside the appliance. Never start up an appliance showing any signs of damage. If in doubt, consult your dealer.
4
|
|
|
|
|
|
|
|
|
|
|
Introduction |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Child entrapment |
DANGER: Risk of child entrapment. |
|
||
|
|
|
warning |
Before you throw away your old refrigerator or freezer: |
|
||
|
|
|
|
Take off the doors but leave the shelves in place so that children may not easily climb |
|
||
|
|
|
|
inside. |
|
||
|
|
|
|
The appliance is not intended for use by young children or infirm persons without |
|
||
|
|
|
|
supervision. |
|
||
|
|
|
|
Young children should be supervised to ensure that they do not play with the appliance. |
|
||
|
|
|
Don’t store |
Don’t store or use gasoline or other flammable vapor and liquids in the vicinity of this or |
|
||
|
|
|
warning |
any other appliance. |
|
||
Grounding (Earthing) In the event of an electric short circuit, grounding (earthing) reduces the risk of electric
warning shock by providing an escape wire for the electric current.
In order to prevent possible electric shock, this appliance must be grounded improper use of the grounding plug can result in an electric shock. Consult a qualified electrician or service person if the grounding instructions are not completely understood, or if you have doubts on whether the appliance is properly grounded.
Identification of parts |
|
*Non dispenser model |
|
Freezer |
Refrigerator |
compartment |
compartment |
|
Milk product corner |
Space plus |
Lamp |
|
|
Door rack |
Shelf |
Automatic |
|
ice maker |
Door rack |
Lamp |
|
|
Shelf |
Shelf |
Shelf (Folding or Normal) |
|
|
|
Shelf |
|
Door rack |
Door rack |
Vegetable drawer |
|
|
Drawer |
Door rack |
|
|
Door rack |
Shelf |
|
Conversion switch Lower cover (Meats/Vegetables)
(Optional)
NOTE
• Parts, features, and options vary by model. Your model may not include every option.
5
Introduction
*Dispenser model -Type1
Freezer Refrigerator compartment compartment
Space plus
Door rack
Automatic
ice maker
Lamp
Shelf
Door rack
Drawer
Door rack
Lower cover
Milk product corner
Lamp
Filter
(Internal filter model Only ) Shelf
Door rack
Shelf
Shelf (Folding or Normal)
Shelf
Door rack
Vegetable drawer
Door rack
Shelf
Conversion switch (Meats/Vegetables) (Optional)
NOTE
• Parts, features, and options vary by model. Your model may not include every option.
6
Introduction
*Dispenser model -Type2
Freezer Refrigerator compartment compartment
Space plus
Door rack
Automatic
ice maker
Lamp
Shelf
Door rack
Drawer
Door rack
Lower cover
Milk product corner
Lamp
Filter
(Internal filter model Only ) Shelf
Door rack
Shelf
Shelf (Folding or Normal) Guide Pitcher
Shelf
Door rack
Vegetable drawer
Door rack
Shelf
Conversion switch (Meats/Vegetables) (Optional)
NOTE
• Parts, features, and options vary by model. Your model may not include every option.
7
Installation
Where to Install
Select a good 1. Place your appliance where it is easy to use. location 2. Avoid placing the unit near heat sources, direct
sunlight or moisture.
3. To ensure proper air circulation around the fridge - freezer, please maintain sufficient space on both the sides as well as top and maintain at least
2 inches (5 cm) from the rear wall.
4. To avoid vibrations, the appliance must be leveled.
5. Don't install the appliance below 5°C. It may cause affect the performance.
Disposal of the |
This appliance contains fluid (refrigerant, lubricant)and is made of parts and materials |
old appliance |
which are reusable and/or recyclable. |
|
All the important materials should be sent to the collection center of waste material |
|
and can be reused after rework (recycling). For take back, please contact with the |
|
local agency. |
8
Installation
|
Door removal |
|
|
|
Warning |
Electric Shock Hazard |
|
|
|
|
Disconnect electrical supply to refrigerator before installing. |
|
|
|
|
Failure to do so could result in death or serious injury. |
|
|
|
|
If your access door is too narrow for the |
|
|
|
|
refrigerator to pass through, remove the |
|
|
|
Remove lower |
refrigerator door and pass the refrigerator laterally. |
|
Lower cover |
|
Remove the lower cover by lifting upward, and |
|
|
||
cover and |
remove clip, and then pull up the feed water tube |
|
|
|
then feed water |
while pressing area shown in the figure to the |
|
|
|
tube |
right. |
Feed water tube |
|
|
|
|
|||
|
NOTE |
|
|
|
|
• If a tube end is deformed or abraded, cut the part away. |
|
|
|
|
|
Hinge |
Connection |
|
|
|
cover |
||
Remove the |
1) Removing the hinge cover by loosening the |
wires |
||
|
||||
|
|
|||
freezer |
screws. Separate all connection wires except |
|
|
|
compartment |
for the earth line after. |
|
Earth line |
|
door |
Upper hinge |
|
||
|
|
|
Upper hinge
2) Remove the keeper by rotating it counter |
Keeper |
|
|
clockwise ( ) and then lifting the upper |
|
hinge up ( ).
NOTE
• When removing the upper hinge, be careful that the door does not fall forwards .
3) Remove the freezer compartment door by lifting it upward. This time, the door should be lifted
enough for the feed water pipe tube to be completely pulled out.
Lower hinge
NOTE
•Move the refrigerator compartment door passing through the access door and lay it down, but be careful not to damage the feed water pipe tube
Remove the |
1) Loosen the hinge cover screws and remove |
|
refrigerator |
the cover. Remove connection wire, if any, |
|
door |
except for the earth line. |
|
|
Connection |
|
|
wires |
|
|
Upper hinge |
Keeper |
|
2) Remove keeper by rotating it clockwise ( ) |
|
|
and then remove the upper hinge by lifting |
|
|
it up ( ). |
|
3) Remove the refrigerator compartment door by lifting it up.
9 |
Lower hinge |
|
