User’s Guide
LG TONE PLATINUM™
Bluetooth® Wireless Stereo Headset
Rev 2.0 US
All rights reserved. © 2016 LG Electronics Inc.
Please read the Important Safety Information for the proper use of this product. After reading, store this User’s Guide in an easily accessible place for all users.
NOTE: Please read all information carefully prior to using the HBS-1100 in order to enjoy the best performance and prevent damage to the product.
WARNING: This product contains chemicals known to the State of California to cause cancer and birth defects or other reproductive harm. Call (800) 243-0000 for more information.
Wash hands after handling.
HBS-1100 |
www.lg.com |
ENGLISH
Contents |
|
Safety Cautions......................................................................................................................................... |
1 |
HD Speaker.................................................................................................................................................. |
2 |
Qualcomm® aptX™ / Qualcomm® aptX™ HD audio.............................................................. |
2 |
Product Components............................................................................................................................. |
2 |
Product Description................................................................................................................................. |
3 |
Battery Charging and Alerts............................................................................................................... |
4 |
HBS-1100 Pairing and Connecting................................................................................................ |
4 |
Indicator Lamp............................................................................................................................................ |
6 |
Mobile Calling Functions....................................................................................................................... |
7 |
Playing Music.............................................................................................................................................. |
8 |
Vibration Alert Settings........................................................................................................................ |
8 |
Out of Range............................................................................................................................................... |
9 |
Find Me (Find my phone)...................................................................................................................... |
9 |
Voice Command...................................................................................................................................... |
10 |
LG Tone & Talk™...................................................................................................................................... |
10 |
Summary of HBS-1100 Functions............................................................................................... |
11 |
Troubleshooting...................................................................................................................................... |
13 |
Specifications and Features............................................................................................................. |
13 |
Declaration of Confirmation............................................................................................................ |
14 |
Additional Information........................................................................................................................ |
15 |
Limited Warranty................................................................................................................................... |
17 |
Important Safety Information......................................................................................................... |
18 |
The LG TONE PLATINUM (HBS-1100) is a lightweight wireless headset that uses Bluetooth technology.
This product can be used as an audio accessory for devices supporting either the A2DP or Hands-Free
Bluetooth Profile.
Safety Cautions
!CAUTION
Do not disassemble, adjust, or repair the product arbitrarily.
Do not place the product near excessive heat or flammable material.
Do not arbitrarily replace the battery as it may explode.
The product may be damaged if an incompatible recharger is used.
Make sure that any infant or child does not swallow a magnet or a small component of the product.
Make sure that foreign objects do not enter the charger’s connectors (charging port and power plug).
Failing to do so may result in fire or electric shock.
For your safety, do not wear the product while it is being charged.
If you have a medical device implanted, contact your doctor before use. Do not pull the earphone cable with excessive force.
For your safety, do not remove the battery incorporated in the product. Lithium-ion polymer Battery is hazardous component which can cause injury.
Battery replacement by non-qualified professional can cause damage to your device.
The battery should be recycled or disposed separately from household wastes.
!WARNING
Do not drop the product from a high place.
Make sure there is no water, alcohol, or benzene in contact with the product. Do not store the product in a wet or dusty place.
Do not place any heavy objects on the product.
This product is not waterproof. Avoid humidity and water.
!NOTE
If the product is exposed to excessive sweat, clean the product. Keep the earbud of the earphone always clean.
ENGLISH
1
ENGLISH
HD Speaker
If the communication network of the device you are connecting to supports HD Voice Calling, you can enjoy making voice calls and listening to music in high definition.
Qualcomm® aptX™ / Qualcomm® aptX™ HD audio
LG HBS-1100 is powered by Qualcomm aptX / Qualcomm aptX HD audio. Qualcomm aptX / Qualcomm aptX HD audio is Bluetooth wireless technology that provides clearer audio for listening to music and watching movies.
Qualcomm aptX / Qualcomm aptX HD audio is automatically enabled when a mobile phone or audio device supports it.
Qualcomm aptX HD audio supports 24-bit audio, so you can wirelessly enjoy studio-quality sound.
Product Components
TONE PLATINUM HBS-1100 |
Extra Ear Gels |
Micro USB Charging Cable |
User’s Guide |
(Medium ear gels installed) |
(small & large) |
|
|
Warranty Card |
Quick Start Guide |
NFC Card |
NOTE: Actual product design may differ from images shown in manual.
2
! CAUTION
Make sure authentic LG Electronics components are used. Using a non-authentic component may damage the product and thus void the warranty.
Product Description
ENGLISH
Indicator lamp |
Power switch |
|
|
OFF |
ON |
|
Volume jog switch |
|
Retractable button |
|
Microphone |
Charging port |
Call button |
|
|
|
Microphone |
Previous/Next jog switch
Retractable earbuds (left/right)
Play/Pause/Stop button
NOTE: When you control the volume (level 16), you will hear a control sound two times or as a long sound from volume level 6 and higher.
3
ENGLISH
Battery Charging and Alerts
Open the Charging port cover and connect the charger to the Charging port.
Indicator Lamp |
Red |
Purple |
Blue |
|
|
|
|
Battery Status |
Charging |
80 % |
Completed |
|
|
|
|
If the charging cable is removed while the Power switch is ON, the power turns on and the product automatically connects to the device whose connection settings have been completed.
Slide and hold the Volume jog switch in the volume down (-) direction for 1 second to check the Indicator lamp and battery level by voice.
Battery Status |
Sufficient |
Normal |
Insufficient |
|
|
|
|
Indicator Lamp |
Blue flashes three times |
Purple flashes three times |
Red flashes three times |
|
|
|
|
HBS-1100 Pairing and Connecting
If you start the process after putting in your earbuds, you can easily pair and connect following the voice prompts.
NOTE: If you are prompted for the authorization code (PIN Code), type 0000.
If you hear that the battery is insufficient, recharge the battery before proceeding with pairing.
If pairing is not completed within 3 minutes, the power automatically turns off. When the power automatically turns off, slide the
Power switch from the OFF to the ON position to turn the power on.
4
Connecting Quickly
OFF |
ON |
OFF |
ON |
|
ON |
|
ON |
1Slide the Power switch towards the ON position to turn on the power.
2The blue Indicator lamp turns on and the HBS-1100 switches to Search mode.
3From the mobile phone or device list, select LG HBS1100 to connect.
4A voice message will indicate that the connection is completed.
5Use the same process to pair the HBS-1100 with other devices.
Connecting Manually
1Press and hold the Call button and slide the Power switch to the ON position to turn it on.
2The blue Indicator lamp turns on and the HBS-1100 switches to Search mode.
3Select LG HBS1100 from the device list to connect.
Multiple Connections
The HBS-1100 can be connected to a mobile phone and a PC simultaneously.
NOTE: If simultaneously connected to two devices, the main functions work based on the “Main Connected Device.”
1Press and hold the Call button and slide the Power switch to the ON position to turn it on.
2Perform Steps 2 to 4 in “Connecting Quickly.” This device becomes the “Main Connected Device.”
3Try to connect to HBS-1100 using a previously connected device. This device becomes the “Sub Connected Device.”
ENGLISH
5
NFC Connection (When the device to be connected supports NFC)
|
1 |
Activate the Read NFC Tag mode and Bluetooth function of the device to be connected. |
|
2 |
Press and hold the Call button and slide the Power switch to the ON position to turn on the power. |
ENGLISH |
3 |
The blue status Indicator lamp turns on, and the product switches to Search mode. |
4 |
Place the tag of the NFC card to the NFC antenna area of the device to be connected. |
|
|
|
(The location of the NFC antenna may differ depending on the product.) |
|
5 |
In the notification window of the device, press “Yes” to connect the product to the device. |
|
|
NOTE: If you place the NFC tag of the product against the NFC antenna of the connected |
|
|
device, the connection is lost. If the connection is lost, place the NFC tag against the |
|
|
NFC antenna again. |
|
6 |
Repeat the procedure to connect to another device. |
Automatic Reconnection
If you turn on the product, it automatically searches for and connects to the devices
(“Main Connected Device” and “Sub Connected Device”) to which it was previously connected.
(If the product cannot find the device to which it was connected last time, the product switches to Search mode.)
If the product does not automatically connect to the device you want, search for your product in the device you want to connect to and connect it manually.
Indicator Lamp
HBS-1100 Status |
Description |
|
|
|
|
Power On |
The blueIndicator lamp flashes four times. |
|
|
|
|
Power Off |
The blueIndicator lamp flashes four times. |
|
|
|
|
Search Mode |
The blue Indicator lamp is on. |
|
|
|
|
Headset/Hands-free |
The blueIndicator lamp flashes once every 5 seconds. |
|
Profile Connected |
||
|
||
|
|
|
Call Connected |
The blueIndicator lamp flashes once every 5 seconds. |
|
|
|
6
Mobile Calling Functions
Functions |
Description |
|
|
|
|
|
|
Receiving a Call/ |
Briefly press the Call button. |
|
|
If you want to turn off the Vibration function of the product, briefly slide the |
|||
Hanging Up |
|||
|
Volume jog switch in the volume down (-) direction. |
||
|
If you make a call using a mobile phone, the call is automatically connected to |
||
Making a Call |
the HBS-1100. |
|
|
On some mobile phones, you should briefly press thePlay/Pause/Stop button |
|||
|
|||
|
two times to switch calls. |
|
|
|
|
||
Redial |
Press and hold the Call button for more than 1 second to place a call to the last |
||
number you called. |
|
||
|
|
||
|
|
|
|
|
Briefly press the Call button. |
|
|
Voice Dial |
If the mobile phone does not support the Voice Dial function, you can use the |
||
|
Redial function. |
|
|
|
|
||
|
Briefly press the Play/Pause/Stop button two times during a call. |
||
Switching Calls |
(Every time you press one of these buttons, the call switches to the mobile phone |
||
|
or the HBS-1100.) |
|
|
|
|
||
|
You can receive another call while on the phone by pressing and holding the |
||
|
Call button for 1 second. |
|
|
Receiving a Call |
The existing call switches to a call waiting status. Press and hold the Call button |
||
While on the |
again for 1 second to switch back to the previous call. |
||
Phone |
Briefly press the Call button to hang up in the middle of a call or to hang up |
||
|
|||
|
both calls. |
|
|
|
(It works differently depending on the mobile phone settings.) |
||
|
|
|
|
Rejecting a Call |
Press and hold the Call button for 2 seconds. |
|
|
|
|
||
Enabling/ |
Simultaneously slide and hold the Volume jog switch in the volume up (+) direction, |
||
Disabling Mute |
and slide the Previous/Next jog switch in the |
position for 1 second. |
|
|
|
|
|
CAUTION: Do not disable/enable the mute while driving, as you need to use both hands.
NOTE: The Voice Dial and Redial functions work on the Main Connected Device or on the device on which you made the last call. (The Voice Dial and Redial functions may work differently
depending on the mobile phone being used.)
ENGLISH
7
Playing Music
ENGLISH
Functions |
Description |
|
|
|
|
|
|
|
|
|
|
Play |
Briefly press the Play/Pause/Stop button. |
|
|
|
|
Music will play from the activated player of the connected device. |
|||||
|
|||||
|
|
|
|
|
|
Pause |
Briefly press the Play/Pause/Stop button. |
|
|
|
|
|
|
|
|||
Stop |
Press and hold the Play/Pause/Stop button for 1 second. |
|
|||
|
|
|
|
|
|
Play Previous/ |
Briefly slide the Previous/Next jog switch in the |
or |
position. |
||
Next Song |
|||||
|
|
|
|
||
|
|
|
|
||
Fast Rewind/Forward |
Slide the Previous/Next jog switch in the |
or |
direction until you reach |
||
the desired section of the track. |
|
|
|
||
|
|
|
|
||
|
|
||||
|
Briefly press the Play/Pause/Stop button twice. Changes modes with a |
||||
|
beeping sound in the following order: Bass Boost (default) > Tone Platinum |
||||
Change Equalizer Mode |
> Treble Boost. |
|
|
|
|
|
|
|
|
||
|
NOTE: The Tone Platinum mode is an EQ mode optimized for the BA unit |
||||
|
used in HBS-1100. |
|
|
|
|
|
|
|
|
|
|
Switching Music Players
If you stop in the middle of playback and then play music on either of the two connected devices, the HBS-1100’s music playback and control changes to that device.
Vibration Alert Settings
Slide and hold the Volume jog switch in the volume up (+) direction for 2 seconds when the HBS-1100 is not in use.
If you turn off the vibration alerts, it will not vibrate even when a call is being received or you are out of communication range.
NOTE: The vibration alert is automatically set to the ON when you turn on the power.
8
Out of Range
If the device connected to the product is out of effective communication range (33 feet / 10 meters), the communication signal becomes weak and the communication is lost.
If the device comes back within effective communication range, the product automatically reconnects to the device. If the device is not automatically reconnected, press the Call button on the product
to connect to it manually.
If a device that is not in use goes out of communication range when multiple devices are connected, the product vibrates and a voice message indicates that the connection is lost.
In this case, the automatic reconnection function is not supported.
ENGLISH
Find Me (Find my phone)
To find handset, simultaneously slide and hold theVolume jog switch and the Previous/Next jog switch in the same direction for 1 second as shown in figures 1 and 2.
For example,
1Simultaneously slide and hold the Volume jog switch in the volume up (+) direction and the Previous/Next jog switch in the
position for 1 second.
2Simultaneously slide and hold the Volume jog switch in the volume down (-) direction and the Previous/Next jog switch in the
position for 1 second.
9
ENGLISH
Voice Command
When there is an incoming call, you can accept or reject the call by saying “answer” or “ignore”. (English Only)
To activate or deactivate device Voice Command, simultaneously press and hold the Call button and Play/Pause/Stop button for 1 second. You will hear “Voice Command on” or “Voice Command off” when it is activated or deactivated. Default is off.
NOTE: Voice Command will not work while the headset is vibrating for an incoming call.
LG Tone & Talk
Tone & Talk supports various functions including text and voice directions, and calling. Search for “LG Tone & Talk” in the Google Play™ store (Android™ OS) or in the App Store® (iOS) to install Tone & Talk. You can scan the QR code on the right to install Tone & Talk.
NOTE: Some features in Tone & Talk may not be |
|
|
|
||
activated on iOS devices. |
Google Play |
|
App Store |
||
|
|
|
|
|
|
Function |
Action |
|
|
|
|
Current Time Alert |
1. Go to Tone & Talk and select Current time alert. |
|
|
||
2. Slide and hold the Previous/Next jog switch to the |
position for 1 second. |
||||
|
|||||
|
|
|
|
||
|
1. Go to Tone & Talk and select Voice memo. |
|
|
||
Voice Memo |
2. Slide and hold the Previous/Next jog switch to the |
position for 1 second. |
|||
|
(This feature may not be supported on some devices.) |
|
|
||
Reading Recent |
Slide and hold the Previous/Next jog switch in the |
position for 1 second. |
|||
Messages |
|||||
|
|
|
|
||
Find Me |
Simultaneously slide and hold the Volume jog switch and |
|
|||
(Find my phone) |
Previous/Next jog switch in the same direction for 1 second. |
|
|||
Using Speed Dial to |
1. Go to Tone & Talk and select a speed dial contact. |
|
|
||
2. Briefly press the Call button two times. |
|
|
|||
Make a Call |
|
|
|||
(The number should be specified in theTone &Talk app.) |
|
||||
|
|
||||
|
|
|
|
||
|
1. Go to Tone & Talk and select a favorite contact. |
|
|
||
Using Favorites to |
2. Briefly press the Call button two times. |
|
|
||
3. Slide and hold the Previous/Next jog switch to the |
or |
position for |
|||
Make a Call |
|||||
1 second to select a number. |
|
|
|
||
|
|
|
|
||
|
4. Briefly press the Call button two times. |
|
|
||
10
Loading...
