FTOS Command Line
Reference Guide
FTOS 8.4.2.6
E-Series TeraScale, C-Series,
S-Series (S50/S25)
Notes, Cautions, and Warnings
NOTE: A NOTE indicates important information that helps you make better use of your computer.
CAUTION: A CAUTION indicates potential damage to hardware or loss of data if instructions are not followed. WARNING: A WARNING indicates a potential for property damage, personal injury, or death.
Information in this publication is subject to change without notice. © 2012 Dell Force10. All rights reserved.
Reproduction of these materials in any manner whatsoever without the written permission of Dell Inc. is strictly forbidden.
Trademarks used in this text: Dell™, the DELL logo, Dell Precision™, OptiPlex™, Latitude™, PowerEdge™, PowerVault™, PowerConnect™, OpenManage™, EqualLogic™, KACE™, FlexAddress™ and Vostro™ are trademarks of Dell Inc. Intel®, Pentium®, Xeon®, Core™ and Celeron® are registered trademarks of Intel Corporation in the U.S. and other countries. AMD® is a registered trademark and AMD Opteron™, AMD Phenom™, and AMD Sempron™ are trademarks of Advanced Micro Devices, Inc. Microsoft®, Windows®, Windows Server®, MS-DOS® and Windows Vista® are either trademarks or registered trademarks of Microsoft Corporation in the United States and/or other countries. Red Hat Enterprise Linux® and Enterprise Linux® are registered trademarks of Red Hat, Inc. in the United States and/or other countries. Novell® is a registered trademark and SUSE ™ is a trademark of Novell Inc. in the United States and other countries. Oracle® is a registered trademark of Oracle Corporation and/or its affiliates. Citrix®, Xen®, XenServer® and XenMotion® are either registered trademarks or trademarks of Citrix Systems, Inc. in the United States and/or other countries. VMware®, Virtual SMP®, vMotion®, vCenter®, and vSphere® are registered trademarks or trademarks of VMWare, Inc. in the United States or other countries.
Other trademarks and trade names may be used in this publication to refer to either the entities claiming the marks and names or their products. Dell Inc. disclaims any proprietary interest in trademarks and trade names other than its own.
January 2012
Table of Contents
1 Preface
Objectives . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
Audience . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
Conventions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
Information Symbols . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14
Related Documents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14
2 CLI Basics
Accessing the Command Line . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15 Multiple Configuration Users . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16 Navigating the Command Line Interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16 Obtaining Help . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17 Using the Keyword No . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19 Filtering show Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19
Displaying All Output . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20 Filtering Command Output Multiple Times . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20 Command Modes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20 EXEC Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21 EXEC Privilege Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21 CONFIGURATION Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21 INTERFACE Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21 LINE Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .22 TRACE-LIST Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .22 MAC ACCESS LIST Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .22 IP ACCESS LIST Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .23 ROUTE-MAP Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .23 PREFIX-LIST Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .23 AS-PATH ACL Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .23 IP COMMUNITY LIST Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .24 REDIRECT-LIST Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .24 SPANNING TREE Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .24 Per-VLAN SPANNING TREE Plus Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .24 RAPID SPANNING TREE Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .25 MULTIPLE SPANNING TREE Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .25 PROTOCOL GVRP Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .25 ROUTER OSPF Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .25 ROUTER RIP Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .26 ROUTER ISIS Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .26 ROUTER BGP Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .26
Determining the Chassis Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .26
Table of Contents | 3
w w w . d e l l . c o m | s u p p o r t . d e l l . c o m
3 File Management
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .27
Basic File Management Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .27
Upgrading the C-Series FPGA . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .56
4 BOOT_USER Mode
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .59
Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .59
5 Control and Monitoring
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .73
Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .73
6 802.1ag
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .159 Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .159
7 802.3ah
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .171 Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .171
8 802.1X
Important Points to Remember . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .183
9 Access Control Lists (ACL) |
|
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
199 |
Commands Common to all ACL Types . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
199 |
Common IP ACL Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
201 |
Standard IP ACL Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
205 |
Extended IP ACL Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
212 |
Common MAC Access List Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
243 |
Standard MAC ACL Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
246 |
Extended MAC ACL Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
251 |
IP Prefix List Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
256 |
Route Map Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
262 |
AS-Path Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
279 |
IP Community List Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
282 |
10 ACL VLAN Group
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .287
Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .287
4 |
| |
Table of Contents |
11 Bidirectional Forwarding Detection (BFD)
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .293
Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .293
12 Border Gateway Protocol IPv4 (BGPv4)
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .307
BGPv4 Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .307
MBGP Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .383
BGP Extended Communities (RFC 4360) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .410
13 Content Addressable Memory (CAM) for ExaScale
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .419 Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .419 Important Points to Remember . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .420
14 Content Addressable Memory (CAM) |
|
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
427 |
CAM Profile Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
427 |
Important Points to Remember . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
428 |
CAM IPv4flow Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
439 |
CAM Layer 2 ACL Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
442 |
15 Configuration Rollback
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .445
Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .445
16 Dynamic Host Configuration Protocol (DHCP)
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .455 Commands to Configure the System to be a DHCP Server . . . . . . . . . . . . . . . . . . . . .455 Commands to Configure Secure DHCP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .463
17 Equal Cost Multi-Path
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .471
Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .471
18 Far-End Failure Detection (FEFD)
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .477
Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .477
19 Force10 Resilient Ring Protocol (FRRP)
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .483
Table of Contents | 5
w w w . d e l l . c o m | s u p p o r t . d e l l . c o m
Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .483
Important Points to Remember . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .483
20 Force10 Service Agent
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .491
Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .491
21 GARP VLAN Registration (GVRP)
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .523
Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .523
Important Points to Remember . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .524
22 High Availability (HA)
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .533
Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .533
23 Internet Group Management Protocol (IGMP)
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .543
IGMP Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .543
Important Points to Remember . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .543
IGMP Snooping Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .553
Important Points to Remember for IGMP Snooping . . . . . . . . . . . . . . . . . . . . . . . .553
Important Points to Remember for IGMP Querier . . . . . . . . . . . . . . . . . . . . . . . . . .554
24 Interfaces
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .559
Basic Interface Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .559
Port Channel Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .614
Time Domain Reflectometer (TDR) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .624
Important Points to Remember . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .624
UDP Broadcast . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .625
Important Points to Remember . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .626
25 IPv4 Routing
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .629
Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .629
26 IPv6 Access Control Lists (IPv6 ACLs) |
|
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
681 |
Important Points to Remember . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
681 |
IPv6 ACL Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
682 |
6 |
| |
Table of Contents |
IPv6 Route Map Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .708
27 IPv6 Basics
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .713
Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .713
28 IPv6 Border Gateway Protocol (IPv6 BGP)
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .731
IPv6 BGP Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .731
IPv6 MBGP Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .793
29 Intermediate System to Intermediate System (IS-IS)
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .817 Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .817
30 Link Aggregation Control Protocol (LACP)
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .859
Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .859
31 Layer 2
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .865
MAC Addressing Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .865
Virtual LAN (VLAN) Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .884
32 Link Layer Detection Protocol (LLDP)
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .893
Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .893
LLDP-MED Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .902
33 Multicast Listener Discovery (MLD)
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 911
MLD Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 911
MLD Snooping Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .918
34 Multicast Source Discovery Protocol (MSDP)
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .923
Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .923
35 Multiple Spanning Tree Protocol (MSTP)
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .933
Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .933
Table of Contents | 7
w w w . d e l l . c o m | s u p p o r t . d e l l . c o m
36 |
Multicast |
|
|
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
.949 |
|
IPv4 Multicast Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
.949 |
|
IPv6 Multicast Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
.966 |
37 |
Neighbor Discovery Protocol (NDP) |
|
|
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
.973 |
|
Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
.973 |
38 |
Object Tracking |
|
|
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
.981 |
|
IPv4 Object Tracking Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
.981 |
|
IPv6 Object Tracking Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
.995 |
39 |
Open Shortest Path First (OSPFv2 and OSPFv3) |
|
|
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
1001 |
|
OSPFv2 Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
1001 |
|
OSPFv3 Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
1059 |
40 |
Policy-based Routing (PBR) |
|
|
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
1081 |
|
Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
1081 |
41 |
PIM-Dense Mode (PIM-DM) |
|
|
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
1091 |
|
IPv4 PIM-Dense Mode Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
1091 |
42 |
PIM-Sparse Mode (PIM-SM) |
|
|
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
1093 |
|
IPv4 PIM-Sparse Mode Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
1093 |
|
IPv6 PIM-Sparse Mode Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
1116 |
43 |
PIM-Source Specific Mode (PIM-SSM) |
|
|
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
1127 |
|
IPv4 PIM Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
1127 |
|
IPv4 PIM-Source Specific Mode Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
1127 |
|
IPv6 PIM Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
1129 |
|
IPv6 PIM-Source Specific Mode Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
1129 |
44 |
Power over Ethernet (PoE) |
|
|
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
1131 |
8 |
| |
Table of Contents |
Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1131
45 Port Monitoring
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1137
Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1137
Important Points to Remember . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1138
46 Private VLAN (PVLAN)
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1151
Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1151
Private VLAN Concepts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1151
47 Per-VLAN Spanning Tree plus (PVST+)
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1161 Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1161
48 Quality of Service (QoS)
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1175
Global Configuration Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1175
Per-Port QoS Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1176
Policy-Based QoS Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1184
Important Points to Remember—multicast-bandwidth option . . . . . . . . . . . . . . . . 1197
Queue-Level Debugging . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1220
49 Router Information Protocol (RIP)
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1231
Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1231
50 Remote Monitoring (RMON)
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1249
Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1249
51 Rapid Spanning Tree Protocol (RSTP)
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1261
Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1261
52 Security |
|
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
1273 |
Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
1273 |
AAA Accounting Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
1273 |
Authorization and Privilege Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
1276 |
Table of Contents | 9
w w w . d e l l . c o m | s u p p o r t . d e l l . c o m
Authentication and Password Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1280
RADIUS Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1291
TACACS+ Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1296
Port Authentication (802.1X) Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1299
Important Points to Remember . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1299
SSH Server and SCP Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1306
Trace List Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1318
Secure DHCP Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1328
53 Service Provider Bridging
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1333
Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1333
Important Points to Remember . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1333
54 sFlow
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1339 Important Points to Remember . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1339 Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1340
55 SNMP and Syslog
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1351
SNMP Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1351
Important Points to Remember . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1352
Syslog Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1367
56 SONET
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1379
Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1379
57 S-Series Stacking Commands
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1397
Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1397
58 Storm Control
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1405
Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1405
Important Points to Remember . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1405
59 Spanning Tree Protocol (STP)
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1413
Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1413
10 |
| |
Table of Contents |
60 Time and Network Time Protocol (NTP)
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1425
Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1425
61 Uplink Failure Detection (UFD)
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1441
Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1441
62 VLAN Stacking
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1451
Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1451
Important Points to Remember . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1451
63 Virtual Routing and Forwarding (VRF)
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1461
Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1461
64 Virtual Router Redundancy Protocol (VRRP)
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1471
IPv4 VRRP Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1471
IPv6 VRRP Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1485
65 C-Series Diagnostics and Debugging
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1491
Inter-process Communication Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1491
RPM Management Port Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1497
Data Path Debugging Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1499
Interface Troubleshooting Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1502
Advanced ASIC Debugging Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1506
ACL and System-Flow Debug Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1510
Interface Management Debug Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1512
Layer 2 Debug Command . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1514
Trace Logging Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1515
Offline Diagnostic Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1521
PoE Hardware Status Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1523
Buffer Tuning Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1524
66 E-Series ExaScale Debugging and Diagnostics
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1531
Diagnostics and Monitoring Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1531
Important Points to Remember . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1532
Table of Contents | 11
w w w . d e l l . c o m | s u p p o r t . d e l l . c o m
Offline Diagnostic Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1549
Hardware Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1552
67 E-Series Debugging and Diagnostics
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1575
Diagnostics and Monitoring Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1575
Important Points to Remember . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1576
Offline Diagnostic Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1596
Hardware Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1598
68 S-Series Debugging and Diagnostics
Offline Diagnostic Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1615
Important Points to Remember . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1615
Buffer Tuning Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1617
Hardware Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1622
AICMP Message Types
BSNMP Traps Index Command Index
12 |
| |
Table of Contents |
1
This book provides information on the FTOS Command Line Interface (CLI). It includes some information on the protocols and features found in FTOS and on the Dell Force10 systems supported by FTOS (C-Series c, E-Series e, and S-Series s).
This chapter includes:
•Objectives
•Audience
•Conventions
•Related Documents
This document is intended as a reference guide for the FTOS command line interface (CLI) commands, with detailed syntax statements, along with usage information and sample output.
For details on when to use the commands, refer to the FTOS Configuration Guide. That guide contains an Appendix with a list of the RFCs and MIBs (management information base files) supported.
This document is intended for system administrators who are responsible for configuring or maintaining networks. This guide assumes you are knowledgeable in Layer 2 and Layer 3 networking technologies.
|
This document uses the following conventions to describe command syntax: |
|
|
Convention |
Description |
|
|
keyword |
Keywords are in bold and should be entered in the CLI as listed. |
|
|
parameter |
Parameters are in italics and require a number or word to be entered in the CLI. |
|
|
Preface | 13
w w w . d e l l . c o m | s u p p o r t . d e l l . c o m
{X} |
Keywords and parameters within braces must be entered in the CLI. |
[X] |
Keywords and parameters within brackets are optional. |
|
|
x | y |
Keywords and parameters separated by bar require you to choose one. |
|
|
x||y |
Keywords and parameters separated by a double bar enables you to choose any or all of them. |
|
|
Table 1-1 describes symbols contained in this guide.
Table 1-1. Information Symbols
Symbol |
Brief |
Description |
|
|
|
|
Note |
This symbol signals important operational information. |
|
|
|
|
Caution |
This symbol signals information about situations that could result in equipment damage or loss |
|
|
of data. |
|
|
|
|
Warning |
This symbol signals information about hardware handling that could result in injury. |
|
|
|
|
|
|
c |
C-Series |
This symbol indicates that the selected feature is supported on the C-Series. |
|
|
|
e |
E-Series |
This symbol indicates that the selected feature is supported on the E-Series TeraScale AND |
|
|
E-Series ExaScale. |
|
|
|
et |
E-Series |
This symbol indicates that the selected feature is supported on the E-Series TeraScale platform |
|
TeraScale |
only. |
|
|
|
ex |
E-Series |
This symbol indicates that the selected feature is supported on the E-Series ExaScale platform |
|
ExaScale |
only. |
|
|
|
s |
S-Series |
This symbol indicates that the selected feature is supported on the S-Series. |
|
|
|
For more information about the system, refer to the following documents:
•FTOS Configuration Guide
•Installation and maintenance guides for your system
•Release Notes for your system and FTOS version
14 | Preface
2
This chapter describes the command structure and command modes. FTOS commands are in a text-based interface that allows you to use launch commands, change the command modes, and configure interfaces and protocols.
This chapter covers the following topics:
•Accessing the Command Line
•Multiple Configuration Users
•Navigating the Command Line Interface
•Obtaining Help
•Using the Keyword No
•Filtering show Commands
•Command Modes
When the system boots successfully, you are positioned on the command line in the EXEC mode and not prompted to log in. You can access the commands through a serial console port or a Telnet session. When you Telnet into the switch, you are prompted to enter a login name and password.
Figure 2-1 is an example of a successful Telnet login session.
Figure 2-1. Login Example
telnet 172.31.1.53 Trying 172.31.1.53...
Connected to 172.31.1.53. Escape character is '^]'. Login: username
Password:
Force10>
Once you log into the switch, the prompt provides you with current command-level information (refer to Table 2-1).
CLI Basics | 15
w w w . d e l l . c o m | s u p p o r t . d e l l . c o m
When a user enters the CONFIGURATION mode and another user(s) is already in that configuration mode, FTOS generates an alert warning message similar to the following:
Figure 2-2. Configuration Mode User Alert
Force10#conf
% Warning: The following users are currently configuring the system:
User "" on line console0
User "admin" on line vty0 ( 123.12.1.123 )
User "admin" on line vty1 ( 123.12.1.123 )
User "Irene" on line vty3 ( 123.12.1.321 )
Force10(conf)#Force10#
When another user enters the CONFIGURATION mode, FTOS sends a message similar to the following, where the user in this case is “admin” on vty2:
% Warning: User “admin” on line vty2 “172.16.1.210” is in configuration
The Command Line Interface (CLI) prompt displayed by FTOS is comprised of:
•“hostname”— the initial part of the prompt, “Force10” by default. You can change it with the hostname command, as described in hostname.
•The second part of the prompt, reflecting the current CLI mode, as shown in Table 2-1.
The CLI prompt changes as you move up and down the levels of the command structure. Table 2-1 lists the prompts and their corresponding command levels, called modes. Starting with the CONFIGURATION mode, the command prompt adds modifiers to further identify the mode. The command modes are explained in Command Modes.
Note: Some of the following modes are not available on C-Series or S-Series.
Table 2-1. Command Prompt and Corresponding Command Mode
Prompt |
CLI Command Mode |
|
|
Force10> |
EXEC |
|
|
Force10# |
EXEC Privilege |
|
|
Force10(conf)# |
CONFIGURATION |
|
|
16 |
| |
CLI Basics |
Table 2-1. Command Prompt and Corresponding Command Mode
Prompt |
CLI Command Mode |
|
|
Force10(conf-if)# |
INTERFACE |
Force10(conf-if-gi-0/0)# |
|
Force10(conf-if-te-0/0)# |
|
Force10(conf-if-lo-0)# |
|
Force10(conf-if-nu-0)# |
|
Force10(conf-if-po-0)# |
|
Force10(conf-if-vl-0)# |
|
Force10(conf-if-so-0/0)# |
|
Force10(conf-if-ma-0/0)# |
|
Force10(conf-if-range)# |
|
|
|
Force10(config-ext-nacl)# |
IP ACCESS LIST |
Force10(config-std-nacl)# |
|
|
|
Force10(config-line-aux)# |
LINE |
Force10(config-line-console)# |
|
Force10(config-line-vty)# |
|
|
|
Force10(config-ext-macl)# |
MAC ACCESS LIST |
Force10(config-std-macl)# |
|
|
|
Force10(config-mon-sess)# |
MONITOR SESSION |
|
|
Force10(config-span)# |
STP |
|
|
Force10(config-mstp)# |
MULTIPLE SPANNING TREE |
|
|
Force10(config-pvst)# |
Per-VLAN SPANNING TREE Plus |
|
|
Force10(config-rstp)# |
RAPID SPANNING TREE |
|
|
Force10(config-gvrp)# |
PROTOCOL GVRP |
|
|
Force10(config-route-map)# |
ROUTE-MAP |
|
|
Force10(conf-nprefixl)# |
PREFIX-LIST |
|
|
Force10(conf-router_rip)# |
ROUTER RIP |
|
|
Force10(conf-redirect-list)# |
REDIRECT |
|
|
Force10(conf-router_bgp)# |
ROUTER BGP |
|
|
Force10(conf-router_ospf)# |
ROUTER OSPF |
|
|
Force10(conf-router_isis)# |
ROUTER ISIS |
|
|
Force10(conf-trace-acl)# |
TRACE-LIST |
|
|
As soon as you are in a command mode there are several ways to access help.
•To obtain a list of keywords at any command mode, do the following:
—Enter a ? at the prompt or after a keyword. There must always be a space before the ?.
•To obtain a list of keywords with a brief functional description, do the following:
—Enter help at the prompt.
•To obtain a list of available options, do the following:
CLI Basics | 17
w w w . d e l l . c o m | s u p p o r t . d e l l . c o m
—Type a keyword followed by a space and a ?
•Type a partial keyword followed by a ?
—A display of keywords beginning with the partial keyword is listed.
Figure 2-3 illustrates the results of entering ip ? at the prompt.
Figure 2-3. Partial Keyword Example
Force10(conf)#ip ? |
Named access-list |
access-list |
|
as-path |
BGP autonomous system path filter |
community-list |
Add a community list entry |
domain-list |
Domain name to complete unqualified host name |
domain-lookup |
Enable IP Domain Name System hostname translation |
domain-name |
Define the default domain name |
fib |
FIB configuration commands |
ftp |
FTP configuration commands |
host |
Add an entry to the ip hostname table |
max-frag-count |
Max. fragmented packets allowed in IP re-assembly |
multicast-routing |
Enable IP multicast forwarding |
name-server |
Specify addess of name server to use |
pim |
Protocol Independent Multicast |
prefix-list |
Build a prefix list |
radius |
Interface configuration for RADIUS |
redirect-list |
Named redirect-list |
route |
Establish static routes |
scp |
SCP configuration commands |
source-route |
Process packets with source routing header options |
ssh |
SSH configuration commands |
tacacs |
Interface configuration for TACACS+ |
telnet |
Specify telnet options |
tftp |
TFTP configuration commands |
trace-group |
Named trace-list |
trace-list |
Named trace-list |
Force10(conf)#ip |
|
When entering commands, you can take advantage of the following timesaving features:
•The commands are not case sensitive.
•You can enter partial (truncated) command keywords. For example, you can enter int gig int
interface for the interface gigabitethernet interface command.
•Use the TAB key to complete keywords in commands.
•Use the up arrow key to display the last enabled command.
•Use either the Backspace key or the Delete key to erase the previous character.
18 |
| |
CLI Basics |
Use the left and right arrow keys to navigate left or right in the FTOS command line. Table 2-2 defines the key combinations valid at the FTOS command line.
Table 2-2. Short-cut Keys and their Actions
Key |
|
Combination |
Action |
|
|
CNTL-A |
Moves the cursor to the beginning of the command line. |
|
|
CNTL-B |
Moves the cursor back one character. |
|
|
CNTL-D |
Deletes character at cursor. |
|
|
CNTL-E |
Moves the cursor to the end of the line. |
|
|
CNTL-F |
Moves the cursor forward one character. |
|
|
CNTL-I |
Completes a keyword. |
|
|
CNTL-K |
Deletes all characters from the cursor to the end of the command line. |
|
|
CNTL-L |
Re-enters the previous command. |
|
|
CNTL-N |
Return to more recent commands in the history buffer after recalling commands with Ctrl-P |
|
or the up arrow key |
|
|
CNTL-P |
Recalls commands, beginning with the last command |
|
|
CNTL-R |
Re-enters the previous command. |
|
|
CNTL-U |
Deletes the line. |
|
|
CNTL-W |
Deletes the previous word. |
|
|
CNTL-X |
Deletes the line. |
|
|
CNTL-Z |
Ends continuous scrolling of command outputs. |
|
|
Esc B |
Moves the cursor back one word. |
|
|
Esc F |
Moves the cursor forward one word. |
|
|
Esc D |
Deletes all characters from the cursor to the end of the word. |
|
|
To disable, delete, or return to default values, use the no form of the commands. For most commands, if you type the keyword no in front of the command, you will disable that command or delete it from the running configuration. In this document, the no form of the command is discussed in the Command Syntax portion of the command description.
You can filter the display output of a show command to find specific information, to display certain information only, or to begin the command output at the first instance of a regular expression or phrase.
When you execute a show command, followed by a pipe ( | ) and one of the parameters listed below and a regular expression, the resulting output either excludes or includes those parameters, as defined by the parameter:
•display — display additional configuration information
CLI Basics | 19
w w w . d e l l . c o m | s u p p o r t . d e l l . c o m
•except— display only text that does not match the pattern (or regular expression)
•find — search for the first occurrence of a pattern
•grep — display text that matches a pattern
•no-more — do not paginate the display output
•save - copy output to a file for future use
Note: FTOS accepts a space before or after the pipe, no space before or after the pipe, or any
combination. For example:
Force10#command | grep gigabit |except regular-expression | find regular-expression
The grep command option has an ignore-case sub-option that makes the search case-insensitive. For example, the commands:
•show run | grep Ethernet would return a search result with instances containing a capitalized
“Ethernet,” such as interface GigabitEthernet 0/0.
•show run | grep ethernet would not return the search result, above, because it only searches for instances containing a non-capitalized “ethernet.”
Executing the command show run | grep Ethernet ignore-case would return instances containing both “Ethernet” and “ethernet.”
To display the output all at once (not one screen at a time), use the no-more after the pipe. This is similar to the terminal length screen-length command except that the no-more option affects the output of just the specified command.For example:
Force10#show running-config | no-more
You can filter a single command output multiple times. Place the save option as the last filter. For example:
Force10# command | grep regular-expression | except regular-expression | grep other-regular-expression | find regular-expression | no-more | save
To navigate to various CLI modes, you need to use specific commands to launch each mode.
Navigation to these modes is discussed in the following sections.
Note: Some of the following modes are not available on C-Series or S-Series.
20 |
| |
CLI Basics |
When you initially log in to the switch, by default, you are logged into the EXEC mode. This mode allows you to view settings and to enter the EXEC Privilege mode to configure the device. While you are in the EXEC mode, the > prompt is displayed following the “hostname” prompt, as described above. which is “Force10” by default. You can change it with the hostname command. See the command hostname. Each mode prompt is preceded by the hostname.
The enable command accesses the EXEC Privilege mode. If an administrator has configured an “Enable” password, you will be prompted to enter it here.
The EXEC Privilege mode allows you to access all commands accessible in EXEC mode, plus other commands, such as to clear ARP entries and IP addresses. In addition, you can access the CONFIGURATION mode to configure interfaces, routes, and protocols on the switch. While you are logged in to the EXEC Privilege mode, the # prompt is displayed.
In the EXEC Privilege mode, use the configure command to enter the CONFIGURATION mode and configure routing protocols and access interfaces.
To enter the CONFIGURATION mode:
1.Verify that you are logged in to the EXEC Privilege mode.
2.Enter the configure command. The prompt changes to include (conf).
From this mode, you can enter INTERFACE by using the interface command.
Use the INTERFACE mode to configure interfaces or IP services on those interfaces. An interface can be physical (for example, a Gigabit Ethernet port) or virtual (for example, the Null interface).
To enter INTERFACE mode:
1.Verify that you are logged into the CONFIGURATION mode.
2.Enter the interface command followed by an interface type and interface number that is available on the switch.
3.The prompt changes to include the designated interface and slot/port number, as outlined in Table 2-3.
Table 2-3. Interface prompts
Prompt |
Interface Type |
|
|
Force10(conf-if)# |
INTERFACE mode |
|
|
Force10(conf-if-gi-0/0)# |
Gigabit Ethernet interface followed by slot/port information |
|
|
Force10(conf-if-te-0/0)# |
Ten Gigabit Ethernet interface followed by slot/port information |
|
|
Force10(conf-if-lo-0)# |
Loopback interface number. |
|
|
CLI Basics | 21
w w w . d e l l . c o m | s u p p o r t . d e l l . c o m
Table 2-3. Interface prompts
Prompt |
Interface Type |
|
|
Force10(conf-if-nu-0)# |
Null Interface followed by zero |
|
|
Force10(conf-if-po-0)# |
Port-channel interface number |
|
|
Force10(conf-if-vl-0)# |
VLAN Interface followed by VLAN number (range 1 to 4094) |
|
|
Force10(conf-if-so-0/0)# |
SONET interface followed by slot/port information. |
|
|
Force10(conf-if-ma-0/0)# |
Management Ethernet interface followed by slot/port information |
|
|
Force10(conf-if-range)# |
Designated interface range (used for bulk configuration; see interface range). |
|
|
Use the LINE mode to configure console or virtual terminal parameters.
To enter LINE mode:
1.Verify that you are logged in to the CONFIGURATION mode.
2.Enter the line command. You must include the keywords console or vty and their line number available on the switch.The prompt changes to include (config-line-console) or (config-line-vty).
You can exit this mode by using the exit command.
When in the CONFIGURATION mode, use the trace-list command to enter the TRACE-LIST mode and configure a Trace list.
1.Verify that you are logged in to the CONFIGURATION mode.
2.Enter the ip trace-list command. You must include the name of the Trace list. The prompt change to include (conf-trace-acl).
You can exit this mode by using the exit command.
While in the CONFIGURATION mode, use the mac access-list standard or mac access-list extended command to enter the MAC ACCESS LIST mode and configure either standard or extended access control lists (ACL).
To enter MAC ACCESS LIST mode:
1.Verify that you are logged in to the CONFIGURATION mode.
2.Use the mac access-list standard or mac access-list extended command. You must include a name for the ACL.The prompt changes to include (conf-std-macl) or (conf-ext-macl).
You can return to the CONFIGURATION mode by entering the exit command.
22 |
| |
CLI Basics |
While in the CONFIGURATION mode, use the ip access-list standard or ip access-list extended command to enter the IP ACCESS LIST mode and configure either standard or extended access control lists (ACL).
To enter IP ACCESS LIST mode:
1.Verify that you are logged in to the CONFIGURATION mode.
2.Use the ip access-list standard or ip access-list extended command. You must include a name for the ACL.The prompt changes to include (conf-std-nacl) or (conf-ext-nacl).
You can return to the CONFIGURATION mode by entering the exit command.
While in the CONFIGURATION mode, use the route-map command to enter the ROUTE-MAP mode and configure a route map.
To enter ROUTE-MAP mode:
1.Verify that you are logged in to the CONFIGURATION mode.
2.Use the route-map map-name [permit | deny] [sequence-number] command. The prompt changes to include (route-map).
You can return to the CONFIGURATION mode by entering the exit command.
While in the CONFIGURATION mode, use the ip prefix-list command to enter the PREFIX-LIST mode and configure a prefix list.
To enter PREFIX-LIST mode:
1.Verify that you are logged in to the CONFIGURATION mode.
2.Enter the ip prefix-list command. You must include a name for the prefix list.The prompt changes to include (conf-nprefixl).
You can return to the CONFIGURATION mode by entering the exit command.
Use the AS-PATH ACL mode to configure an AS-PATH Access Control List (ACL) on the E-Series. See Chapter 9, Access Control Lists (ACL).
To enter AS-PATH ACL mode:
1.Verify that you are logged in to the CONFIGURATION mode.
2.Enter the ip as-path access-list command. You must include a name for the AS-PATH ACL.The prompt changes to include (config-as-path).
You can return to the CONFIGURATION mode by entering the exit command.
CLI Basics | 23
w w w . d e l l . c o m | s u p p o r t . d e l l . c o m
Use the IP COMMUNITY LIST mode to configure an IP Community ACL on the E-Series. See Chapter 9, Access Control Lists (ACL).
To enter IP COMMUNITY LIST mode:
1.Verify that you are logged in to the CONFIGURATION mode.
2.Enter the ip community-list command. You must include a name for the Community list.The prompt changes to include (config-community-list).
You can return to the CONFIGURATION mode by entering the exit command.
Use the REDIRECT-LIST mode to configure a Redirect list on the E-Series, as described in Chapter 40, Policy-based Routing (PBR).
To enter REDIRECT-LIST mode:
1.Verify that you are logged in to the CONFIGURATION mode.
2.Use the ip redirect-list command. You must include a name for the Redirect-list.The prompt changes to include (conf-redirect-list).
You can return to the CONFIGURATION mode by entering the exit command.
Use the STP mode to enable and configure the Spanning Tree protocol, as described in Chapter 59, Spanning Tree Protocol (STP).
To enter STP mode:
1.Verify that you are logged into the CONFIGURATION mode.
2.Enter the protocol spanning-tree stp-id command.
You can return to the CONFIGURATION mode by entering the exit command.
Use PVST+ mode to enable and configure the Per-VLAN Spanning Tree (PVST+) protocol, as described in Chapter 47, Per-VLAN Spanning Tree plus (PVST+).
Note: The protocol is PVST+, but the plus sign is dropped at the CLI prompt
To enter PVST+ mode:
1.Verify that you are logged into the CONFIGURATION mode.
2.Enter the protocol spanning-tree pvst command.
You can return to the CONFIGURATION mode by entering the exit command.
24 |
| |
CLI Basics |
Use PVST+ mode to enable and configure the RSTP protocol, as described in Chapter 51, Rapid Spanning Tree Protocol (RSTP).
To enter RSTP mode:
1.Verify that you are logged into the CONFIGURATION mode.
2.Enter the protocol spanning-tree rstp command.
You can return to the CONFIGURATION mode by entering the exit command.
Use MULTIPLE SPANNING TREE mode to enable and configure the Multiple Spanning Tree protocol, as described in Chapter 35, Multiple Spanning Tree Protocol (MSTP).
To enter MULTIPLE SPANNING TREE mode:
1.Verify that you are logged into the CONFIGURATION mode.
2.Enter the protocol spanning-tree mstp command.
You can return to the CONFIGURATION mode by entering the exit command.
Use the PROTOCOL GVRP mode to enable and configure GARP VLAN Registration Protocol (GVRP), as described in Chapter 21, GARP VLAN Registration (GVRP).
To enter PROTOCOL GVRP mode:
1.Verify that you are logged into the CONFIGURATION mode.
2.Enter the protocol gvrp command syntax.
You can return to the CONFIGURATION mode by entering the exit command.
Use the ROUTER OSPF mode to configure OSPF, as described in Chapter 39, Open Shortest Path First (OSPFv2 and OSPFv3).
To enter ROUTER OSPF mode:
1.Verify that you are logged into the CONFIGURATION mode.
2.Use the router ospf {process-id} command.The prompt changes to include (conf-router_ospf-id).
You can switch to the INTERFACE mode by using the interface command or you can switch to the ROUTER RIP mode by using the router rip command.
CLI Basics | 25
w w w . d e l l . c o m | s u p p o r t . d e l l . c o m
Use the ROUTER RIP mode to configure RIP on the C-Series or E-Series, as described in Chapter 49, Router Information Protocol (RIP).
To enter ROUTER RIP mode:
1.Verify that you are logged into the CONFIGURATION mode.
2.Enter the router rip command.The prompt changes to include (conf-router_rip).
You can switch to the INTERFACE mode by using the interface command or you can switch to the ROUTER OSPF mode by using the router ospf command.
Use the ROUTER ISIS mode to configure ISIS on the E-Series, as described in Intermediate System to Intermediate System (IS-IS).
To enter ROUTER ISIS mode:
1.Verify that you are logged into the CONFIGURATION mode.
2.Enter the router isis [tag] command.The prompt changes to include (conf-router_isis).
You can switch to the INTERFACE mode by using the interface command or you can switch to the ROUTER RIP mode by using the router rip command.
Use the ROUTER BGP mode to configure BGP on the C-Series or E-Series, as described in
Chapter 12, Border Gateway Protocol IPv4 (BGPv4).
To enter ROUTER BGP mode:
1.Verify that you are logged into the CONFIGURATION mode.
2.Enter the router bgp as-number command.The prompt changes to include (conf-router_bgp).
You can return to the CONFIGURATION mode by entering the exit command.
The chassis mode in FTOS determines which hardware is being supported in an E-Series chassis. The chassis mode is programmed into an EEPROM on the backplane of the chassis and the change takes place only after the chassis is rebooted. Configuring the appropriate chassis mode enables the system to use all the ports on the card and recognize all software features.
26 |
| |
CLI Basics |
3
This chapter contains commands needed to manage the configuration files and includes other file management commands found in FTOS. This chapter contains these sections:
•Basic File Management Commands
•Upgrading the C-Series FPGA
The commands included in this chapter are:
•boot config
•boot host
•boot network
•boot system
•boot system gateway
•cd
•change bootflash-image
•copy
•copy (Streamline Upgrade)
•copy running-config startup-config
•delete
•dir
•download alt-boot-image
•download alt-full-image
•download alt-system-image
•format (C-Series and E-Series)
•format flash (S-Series)
•logging coredump
•logging coredump server
•pwd
•rename
•boot system
•show bootvar
•show file
File Management | 27
w w w . d e l l . c o m | s u p p o r t . d e l l . c o m
•show file-systems
•show linecard
•show os-version
•show running-config
•show startup-config
•show version
•upgrade (E-Series version)
•upgrade (C-Series version)
•upgrade (S-Series management unit) on page 55
•upgrade fpga-image
boot config
ce
Syntax
Parameters
Set the location and name of the configuration file that is loaded at system start-up (or reload) instead of the default startup-configuration.
boot config {remote-first | rpm0 file-url | rpm1 file-url}
remote-first Enter the keywords remote-first to attempt to load the boot configuration files from a remote location.
Defaults
Command Modes
Command
History
Usage
Information
rpm0 |
Enter the keywords rpm0 first to specify the local boot configuration file for RPM 0. |
|
rpm1 |
Enter the keywords rpm1 first to specify the local boot configuration file for RPM 1. |
|
|
|
|
file-url |
Enter the location information: |
|
|
• |
For a file on the internal Flash, enter flash:// followed by the filename. |
|
• |
For a file on the external Flash, enter slot0:// followed by the filename. |
Not configured.
CONFIGURATION
Version 7.5.1.0 Introduced on C-Series
E-Series original Command
To display these changes in the show bootvar command output, you must save the running configuration to the startup configuration (copy running-config startup-config or write).
Dell Force10 strongly recommends using local files for configuration (RPM0 or RPM1 flash or slot0).
When you specify a file as the boot config file, it is listed in the boot variables (bootvar) as LOCAL CONFIG FILE. If you do not specify a boot config file, then the startup-configuration is used, although the bootvar shows LOCAL CONFIG FILE = variable does not exist. When you specify a boot config file, the switch reloads with that config file, rather than the startup-config. Note that if you specify a local config file which is not present in the specified location, then the startup-configuration is loaded.
The write memory command always saves the running-configuration to the file labeled startup-configuration. When using a LOCAL CONFIG FILE other than the startup-config, use the copy command to save any running-configuration changes to that local file.
28 |
| |
File Management |
Related
Commands
Output for show bootvar with no boot configuration configured
Force10#show bootvar
PRIMARY IMAGE FILE = flash://FTOS-EF-8.2.1.0.bin
SECONDARY IMAGE FILE = flash://FTOS-EF-7.6.1.0.bin
DEFAULT IMAGE FILE = flash://FTOS-EF-7.5.1.0.bin
LOCAL CONFIG FILE = variable does not exist
PRIMARY HOST CONFIG FILE = variable does not exist
SECONDARY HOST CONFIG FILE = variable does not exist
PRIMARY NETWORK CONFIG FILE = variable does not exist
SECONDARY NETWORK CONFIG FILE = variable does not exist
CURRENT IMAGE FILE = flash://FTOS-EF-8.2.1.0.bin
CURRENT CONFIG FILE 1 = flash://startup-config
CURRENT CONFIG FILE 2 = variable does not exist
CONFIG LOAD PREFERENCE = local first
BOOT INTERFACE GATEWAY IP ADDRESS = variable does not exist
Output for show bootvar with boot configuration configured
Force10#show bootvar
PRIMARY IMAGE FILE = flash://FTOS-EF-8.2.1.0.bin
SECONDARY IMAGE FILE = flash://FTOS-EF-7.6.1.0.bin
DEFAULT IMAGE FILE = flash://FTOS-EF-7.5.1.0.bin
LOCAL CONFIG FILE = variable does not exist
PRIMARY HOST CONFIG FILE = variable does not exist
SECONDARY HOST CONFIG FILE = variable does not exist
PRIMARY NETWORK CONFIG FILE = variable does not exist
SECONDARY NETWORK CONFIG FILE = variable does not exist
CURRENT IMAGE FILE = flash://FTOS-EF-8.2.1.0.bin
CURRENT CONFIG FILE 1 = flash://CustomerA.cfg
CURRENT CONFIG FILE 2 = variable does not exist
CONFIG LOAD PREFERENCE = local first
BOOT INTERFACE GATEWAY IP ADDRESS = variable does not exist
show bootvar |
Display the variable settings for the E-Series boot parameters. |
boot host
ce
Syntax
Parameters
Defaults
Command Modes
Command
History
Usage
Information
Set the location of the configuration file from a remote host.
boot host {primary | secondary} remote-url
primary |
Enter the keywords primary to attempt to load the primary host configuration files. |
secondary |
Enter the keywords secondary to attempt to load the secondary host configuration files. |
remote-url Enter the following location keywords and information:
•For a file on an FTP server, enter ftp://user:password@hostip/filepath
•For a file on a TFTP server, enter tftp://hostip/filepath
Not configured.
CONFIGURATION
Version 7.5.1.0 Introduced on C-Series
E-Series original Command
To display these changes in the show bootvar command output, you must save the running configuration to the startup configuration (using the copy command).
File Management | 29
w w w . d e l l . c o m | s u p p o r t . d e l l . c o m
Related |
|
|
|
show bootvar |
Display the variable settings for the E-Series boot parameters. |
||
Commands |
|||
|
|
boot network
ce
Syntax
Parameters
Set the location of the configuration file in a remote network.
boot network {primary | secondary} remote-url
primary |
Enter the keywords primary to attempt to load the primary network configuration files. |
secondary |
Enter the keywords secondary to attempt to load the secondary network configuration |
|
files. |
Defaults
Command Modes
Command
History
Usage
Information
Related
Commands
remote-url Enter the following location keywords and information:
•For a file on an FTP server, enter ftp://user:password@hostip/filepath
•For a file on a TFTP server, enter tftp://hostip/filepath
None
CONFIGURATION
Version 7.5.1.0 Introduced on C-Series
E-Series original Command
To display these changes in the show bootvar command output, you must save the running configuration to the startup configuration (using the copy command).
show bootvar Display the variable settings for the E-Series boot parameters.
boot system
ce
Syntax
Parameters
Tell the system where to access the FTOS image used to boot the system.
boot system {rpm0 | rpm1} (default | primary | secondary} file-url
rpm0 |
Enter the keyword rpm0 to configure boot parameters for RPM0. |
rpm1 |
Enter the keyword rpm1 to configure boot parameters for RPM1. |
|
|
default |
After entering rpm0 or rpm1, enter the keyword default to specify the parameters to |
|
be used if those specified by primary or secondary fail. The default location should |
|
always be the internal flash device (flash:), so that you can be sure that a verified image is |
|
available there. |
|
|
primary |
After entering rpm0 or rpm1, enter the keyword primary to configure the boot |
|
parameters used in the first attempt to boot FTOS. |
|
|
30 |
| |
File Management |
