Data Sheet

Cisco 890 Series Integrated Services Routers

Cisco® 890 Series Integrated Services Routers (ISRs) combine Internet access, comprehensive security, and wireless services in a single high-performance device that is easy to deploy and manage. They are well suited for deployment as Customer Premises Equipment (CPE) in enterprise small branch offices and in service provider managed-service environments.

Product Overview

Cisco 890 Series ISRs deliver integrated security and threat defense, protecting networks from both known and new Internet vulnerabilities and attacks. These powerful, fixed-configuration routers provide secure broadband, Metro Ethernet, and Wireless LAN (WLAN) connectivity. Service providers offering managed Ethernet WAN services can deploy them in customer locations as CPE. You get centralized and remote management capabilities through web-based tools and Cisco IOS® Software for full visibility and control of network configurations at the remote site.

The 890 routers simplify the deployment of Ethernet WAN services, with end-to-end Operations, Administration, and Maintenance (OA&M), Service-Level Agreement (SLA) monitoring and verification, and configuration management.

Cisco 890 Series ISRs come with an 8-port managed switch, providing LAN ports to connect multiple devices. An optional Power-over-Ethernet (PoE) capability can also supply power to IP phones and other devices. Eleven Cisco 890 Series models are available: Figure 1 shows the front and back of one, the Cisco 892FSP.

Figure 1. Cisco 892FSP ISR, Front and Back

© 2017 Cisco and/or its affiliates. All rights reserved. This document is Cisco Public Information.

Page 1 of 10

Features and Benefits

Table 1 describes some of the business needs enterprises have in branch offices and other edge networking locations and how the 890 ISR fulfills those requirements.

Table 1.	How the 890 ISR Addresses Edge Networking Challenges
Business Need		890 ISR Feature(s)/Description
High availability and business		● Redundant WAN connections for failover protection and load balancing
continuity		● Dynamic failover protocols such as Virtual Router Redundancy Protocol (VRRP; RFC 2338), Hot
		Standby Router Protocol (HSRP), and Multigroup HSRP (MHSRP)
		● Dial backup with external modem through a virtual auxiliary port
Consistent, high application		● The router can run multiple services simultaneously with no performance degradation
performance levels
Risk mitigation with multilevel security		● Network perimeter security with integrated application inspection firewall
		● Data privacy through high-speed IP Security (IPsec) Triple Data Encryption Standard (3DES) and
		Advanced Encryption Standard (AES) encryption
		● Enforced security policy with intrusion prevention
		● Security hardware acceleration
		● FlexVPN
		● Next-generation encryption for secure network communications systems, reliable for the
		next decade
		● Cisco ISR Web Security with Cisco ScanSafe, designed to prevent zero-day malware from
		reaching corporate networks
Feature consolidation for real estate,		● Supports LAN connections, both Ethernet and Wi-Fi, in one appliance. Contains an integrated
capital expenditures (CapEx), and		802.11n WLAN access point that supports both autonomous and unified modes, as well as an 8-
management savings		port LAN switch. Management of both the wired and wireless environments is integrated
Unified control of wired and wireless		● Simplifies and centralizes configuration and management of wireless and wireline devices.
networks from a common console for		Supports WLAN services without requiring a wireless LAN controller
streamlined operations
Remote configuration and		● Supports separate console, auxiliary, and USB ports
management to keep local IT staff lean		● Provides one USB 2.0 flash memory

Platform Support

Table 2 describes the interfaces, Wi-Fi options, and integrated capabilities supported by each of the Cisco 890 Series ISR models.

	Table 2.	Platform Support for 890 Series ISRs
	Model		WAN Interfaces	LAN Interfaces	802.11a/g/n	Integrated USB	Integrated Dial
					Option	2.0/AUX/Console	Backup
	Cisco 892FSP		1-port GE or	8-port 10-/100-/1000-Mbps managed switch	No	Yes	No
			1-port SFP
			1-port GE
	Cisco 896VA		1-port GE or	8-port 10-/100-/1000-Mbps managed switch	No	Yes	ISDN
			1-port SFP	(4-ports PoE capable with 125W power
			VDSL/ADSL2+	supply adapter)
			Annex B
	Cisco 897VA		1-port GE or	8-port 10-/100-/1000-Mbps managed switch	Yes	Yes	ISDN (only on
			1-port SFP	(4-ports PoE capable with 125W power	Cisco CleanAir®		Cisco 897VA-K9)
			VDSL/ADSL2+	supply adapter)	technology
			Annex A/M
	Cisco 897VAB		1-port GE or	8-port 10-/100-/1000-Mbps managed switch	No	Yes	No
			1-port SFP	(4-ports PoE capable with 125W power
			VDSL/ADSL2+	supply adapter)
			Annex A with
			Bonding
© 2017 Cisco and/or its affiliates. All rights reserved. This document is Cisco Public Information.							Page 2 of 10

	Model	WAN Interfaces	LAN Interfaces	802.11a/g/n	Integrated USB	Integrated Dial
				Option	2.0/AUX/Console	Backup
	Cisco 898EA	1-port GE or	8-port 10-/100-/1000-Mbps managed switch	No	Yes	No
		1-port SFP	(4-ports PoE capable with 125W power
		4 pair Ethernet in	supply adapter)
		the first mile
		(EFM)
	Cisco 891F	1-port GE or	8-port 10-/100-/1000-Mbps managed switch	Yes	Yes	V.92 analog
		1-port SFP	(4-ports PoE capable with 125W power	Cisco CleanAir		modem
			supply adapter)
		1-port FE		technology		ISDN BRI
	Cisco 891-24X	2-port GE or	24-port 10-/100-/1000-Mbps managed switch	No	Yes	No
		2-port SFP	(8-ports PoE capable with integrated power
			supply)

Cisco ONE Software

Cisco ONE™ Software offers a valuable and flexible way to buy software for the WAN, access, and data center domains. At each stage in the product lifecycle, Cisco ONE Software helps make buying, managing, and upgrading your network and infrastructure software easier. Cisco ONE Software provides:

●Flexible licensing models to smoothly distribute customers’ software spending over time

●Investment protection for software purchases through software services–enabled license portability

●Access to updates, upgrades, and new technology from Cisco through Cisco® Software Support Services (SWSS)

Cisco ONE for WAN gives organizations broad capabilities for branch offices and the enterprise edge. Cisco ONE Foundation for WAN connects and secures your branch office while optimizing for cost. Cisco ONE WAN Collaboration integrates voice and video into your branch office and network edge.

Product Specifications

Table 3 shows Cisco IOS Software features, WLAN features, and general system specifications for the 890 Series ISRs.

	Table 3.	890 Series IOS Software Features, WLAN Features, and System Specifications
	Feature		Specification
	Cisco IOS Software: Advanced IP Features Set (Default)
	IP and IP services		● Routing Information Protocol Versions 1 and 2 (RIPv1 and RIPv2)
			● Generic Routing Encapsulation (GRE) and Multipoint GRE (MGRE)
			● Cisco Express Forwarding
			● Standard 802.1d Spanning Tree Protocol
			● Layer 2 Tunneling Protocol (L2TP)
			● Layer 2 Tunneling Protocol Version 3 (L2TPv3)
			● Network Address Translation (NAT)
			● Dynamic Host Configuration Protocol (DHCP) server, relay, and client
			● Dynamic Domain Name System (DNS)
			● DNS Proxy
			● DNS Spoofing
			● Access control Lists (ACLs)
			● IPv4 and IPv6 Multicast
			● Open Shortest Path First (OSPF)
			● Border Gateway Protocol (BGP)
			● Performance Routing (PfR)
			● Enhanced Interior Gateway Routing Protocol (EIGRP)
			● Virtual Route Forwarding (VRF) Lite
			● Next Hop Resolution Protocol (NHRP)
			● Bidirectional Forwarding Detection (BFD)
			● Web Cache Communication Protocol (WCCP)
