DATA SHEET > ESD 30N > 20091019
ESD 30N
ELECTROSTATIC DISCHARGE SIMULATOR UP TO 30KV
FOR TESTS ACCORDING TO ...
> Renault 36.00.808/--K > SAE J1113-13
> SAE J1455
> Smart DE1005B
> VW TL 824 66
ESD 30N - GENERATES ESD PULSES ABOVE EN/IEC 61000-4-2 TEST LEVELS
Electrostatic discharges either from a human body to any other part or between two different objects can cause persistent disturbances or even destruction to sensitive electronics or controls.
ESD 30N is an ESD tester to simulate ESD pulses at higher voltages up to 30kV in both air and contact discharge mode. It therefore satisifies requirements exceeding the EN/IEC 61000-4-2 test levels and complies to automotive test applications.
HIGHLIGHTS
>Test voltage up to 30kV for air and contact discharge
>Discharges up to 20Hz
>Easy-to-change R/C-networks and tips
>Bleed-Off function
>Measurement of temperature and humidity
>AC mains supply and DC supply
>Battery operated
>External trigger function
APPLICATION AREAS
AUTOMOTIVE |
COMPONENTS |
INDUSTRY |
TELECOM |
MEDICAL |
RENEWABLE ENERGY |
BROADCAST |
MILITARY |
RESIDENTIAL |
AVIONICS |
www.emtest.com |
© EM TEST > PAGE 1/4 |
DATA SHEET > ESD 30N > 20091019
TECHNICAL DETAILS
TEST LEVEL
Test voltage |
200V - 30,000V ± 5% for contact |
|
discharge |
|
|
|
200V - 30,000V ± 5% for |
|
air discharge |
|
|
Resolution |
100V steps |
|
|
Holding time (AD) |
More than 5s |
|
|
|
|
MAINFRAME ESD 30N |
|
|
|
HV power supply |
Up to 30kV DC |
|
|
Power supply |
88V - 250V AC |
|
12V - 18V DC |
|
|
Battery |
Approx. 1 hour operation; |
|
Buffer battery is automatically |
|
recharged when connected to AC |
|
mains supply |
|
|
Interface |
USB to control the ESD generator |
|
and to download pre-programmed |
|
test routines from esd.control |
|
|
|
|
DISCHARGE UNIT P 30N |
|
|
|
|
Hand held discharge unit |
|
|
Controls |
2 function keys and one control |
|
wheel |
|
|
Display |
Graphic LCD display |
|
|
Test level |
200V to 30,000V |
|
|
Polarity |
Positive, negative; selectable |
|
|
Discharge mode |
Air or Contact discharge, selectable |
|
|
Discharge tip |
Point and ball type |
|
|
Indicators |
Integrated sensor to measure |
|
temperature and rel. humidity |
|
|
|
|
TRIGGER |
|
|
|
Single pulse |
Release of a single pulse |
|
|
Multiple pulses |
Continuous discharge up to 20Hz |
|
|
Counter |
0 - 9,999 for discharge pre-selection |
|
|
OUTPUT
Contact Discharge |
As per EN/IEC 61000-4-2; |
Pulse |
150pF/330ohm |
|
|
Rise time |
As per EN/IEC 61000-4-2 Ed.2 |
|
0.8ns +/- 25% |
|
|
First peak current |
As per EN/IEC 61000-4-2 Ed.2 |
value |
7.5A ± 15% @2kV |
|
15A ± 15% @4kV |
|
22.5A ± 15% @6kV |
|
30A ± 15% @8kV |
|
|
Current value at |
As per EN/IEC 61000-4-2 Ed.2 |
30ns |
4.0A ± 30% @2kV |
|
8.0A ± 30% @4kV |
|
12.0A ± 30% @6kV |
|
16.0A ± 30% @8kV |
|
|
Current value at |
As per EN/IEC 61000-4-2 Ed.2 |
60ns |
2.0A ± 30% @2kV |
|
4.0A ± 30% @4kV |
|
6.0A ± 30% @6kV |
|
8.0A ± 30% @8kV |
|
|
|
|
GENERAL |
|
|
|
Weight |
Approx. 5.1kg (ESD 30N control unit) |
|
|
Weight |
Approx. 1,250g (P 30N discharge |
|
gun) |
|
|
Supply voltage |
AC: 88V - 264V, 50/60Hz |
|
DC: 11V - 16VDC |
|
|
Fuses |
2x 0.5A T |
|
|
ACCESSORIES (INCLUDED)
Discharge tips for AD and CD
Grounding lead 2m
Test certificate and instruction manual
