Agilent
ENA-L RF Network Analyzers
E5061A, 300 kHz to 1.5 GHz
E5062A, 300 kHz to 3 GHz
Data Sheet
Definitions
All specifications apply over a 5°C to 40°C range (unless otherwise stated) and 90 minutes after the instrument has been turned on.
Specification (spec.):
Warranted performance. Specifications include guardbands to account for the expected statistical performance distribution, measurement uncertainties, and changes in performance due to environmental conditions.
Supplemental information is intended to provide information that is helpful for using the instrument but that is not guaranteed by the product warranty. This information is denoted as either typical or nominal.
Typical (typ.):
Expected performance of an average unit that does not include guardbands. It is not guaranteed by the product warranty.
Nominal (nom.):
A general, descriptive term that does not imply a level of performance. It is not guaranteed by the product warranty.
2
Corrected system performance
The specifications in this section apply for measurements made with the Agilent E5061A/E5062A network analyzer with the following conditions:
•No averaging applied to data
•Environmental temperature of 23°C ± 5°C, with less than 1°C deviation from the calibration temperature
•Response and isolation calibration not omitted
Table 1-1 |
System dynamic range1 |
|
|
Description |
|
Specification |
Supplemental information |
|
|
|
|
System dynamic range |
|
|
|
|
|
|
|
300 kHz to 3 GHz, IF bandwidth = 3 kHz |
90 dB |
95 dB |
|
|
|
|
|
300 kHz to 3 GHz, IF bandwidth = 10 Hz |
115 dB |
120 dB |
|
1.The test port dynamic range is calculated as the difference between the test port rms noise floor and the source maximum output power. The effective dynamic range must take measurement uncertainty and interfering signals into account.
3
Table 1-2 |
Corrected system performance with Type-N device connectors, |
|
|
85032F calibration kit |
|
Network analyzer: E5061A/E5062A, calibration kit: 85032F (Type-N, 50 Ω), calibration: full 2-port
IF bandwidth = 10 Hz, No averaging applied to data, environmental temperature = 23°C ±5°C with < 1°C deviation from calibration temperature, isolation calibration not omitted
Description |
Specification (dB) |
|
|
|
|
|
300 kHz to 1.5 GHz |
1.5 GHz to 3 GHz |
|
|
|
Directivity |
49 |
46 |
|
|
|
Source match |
41 |
40 |
|
|
|
Load match |
49 |
46 |
|
|
|
Reflection tracking |
±0.011 |
±0.021 |
|
|
|
Transmission tracking |
±0.015 |
±0.018 |
Transmission uncertainty (specification) |
|
|
Magnitude |
|
Phase |
Reflection uncertainty (specification) |
|
Magnitude |
Phase |
4
Table 1-3 |
Corrected system performance with Type-N device connectors, |
|
|
85032F calibration kit, enhanced response calibration |
|
Network analyzer: E5061A/E5062A, calibration kit: 85032F (Type-N, 50 Ω) calibration: enhanced response
IF bandwidth = 10 Hz, no averaging applied to data, environmental temperature = 23°C ± 5°C with < 1°C deviation from calibration temperature, isolation calibration not omitted
Description |
Specification (dB) |
|
|
|
|
|
300 kHz to 1.5 GHz |
1.5 GHz to 3 GHz |
|
|
|
Directivity |
49 |
46 |
|
|
|
Source match |
41 |
40 |
|
|
|
Load match |
15 |
15 |
|
|
|
Reflection tracking |
±0.011 |
±0.021 |
|
|
|
Transmission tracking |
±0.015 |
±0.018 |
Transmission uncertainty (specification) |
|
|
Magnitude |
|
Phase |
Reflection uncertainty (specification) |
|
Magnitude |
Phase |
5
Table 1-4 |
Corrected system performance with Type-N 75 Ω device |
|
connectors 85036E calibration kit, full 2-port calibration |
Network analyzer: E5061A/E5062A, calibration kit: 85036E (Type-N, 75 Ω), calibration: full 2-port
IF bandwidth = 10 Hz, no averaging applied to data, environmental temperature = 23°C ± 5°C with < 1°C deviation from calibration temperature, isolation calibration not omitted
Description |
Specification (dB) |
|
|
|
|
|
300 kHz to 1.5 GHz |
1.5 GHz to 3 GHz |
|
|
|
Directivity |
48 |
44 |
|
|
|
Source match |
41 |
35 |
|
|
|
Load match |
48 |
44 |
|
|
|
Reflection tracking |
±0.010 |
±0.019 |
|
|
|
Transmission tracking |
±0.015 |
±0.029 |
Transmission uncertainty (specification) |
|
|
Magnitude |
|
Phase |
Reflection uncertainty (specification) |
|
Magnitude |
Phase |
6
Table 1-5 |
Corrected system performance with Type-N 75 Ω device |
|
|
connectors 85036E calibration kit, enhanced response calibration |
|
|
|
|
Network analyzer: E5061A/E5062A, calibration kit 85036E (Type-N, 75 Ω), calibration: enhanced response
IF bandwidth = 10 Hz, no averaging applied to data, environmental temperature = 23°C ± 5°C with < 1°C deviation from calibration temperature, isolation calibration not omitted
Description |
Specification (dB) |
|
|
|
|
|
300 kHz to 1.5 GHz |
1.5 GHz to 3 GHz |
|
|
|
Directivity |
48 |
44 |
|
|
|
Source match |
41 |
35 |
|
|
|
Load match |
15 |
15 |
|
|
|
Reflection tracking |
±0.010 |
±0.019 |
|
|
|
Transmission tracking |
±0.015 |
±0.029 |
Transmission uncertainty (specification) |
|
|
Magnitude |
|
Phase |
Reflection uncertainty (specification) |
|
Magnitude |
Phase |
7
Uncorrected system performance
Table 1-6 |
Uncorrected system performance |
|
(correction: off, 23°C ± 5°C) |
Description |
Specification |
|
|
|
300 kHz to 3 GHz |
|
|
Directivity |
25 dB |
|
|
Source match |
25 dB |
|
|
Load match |
15 dB |
|
|
Transmission tracking |
±1.0 dB |
|
|
Reflection tracking |
±1.0 dB |
Test port output (source)
Table 1-7 |
Test port output frequency |
|
Description |
Specification |
Supplemental information |
|
|
|
Range |
|
|
|
|
|
E5061A |
300 kHz to 1.5 GHz |
|
|
|
|
E5062A |
300 kHz to 3 GHz |
|
|
|
|
Resolution |
1 Hz |
|
|
|
|
Source stability |
|
|
|
|
|
E5061A/E5062A |
|
±5 ppm (5°C to 40°C, typical) |
|
|
|
CW accuracy |
|
|
|
|
|
E5061A/E5062A |
±5 ppm, 23°C ± 5°C |
|
8
