F6A
F8A
T8A
OWNER’S MANUAL
U.S.A.Edition
LIT-18626-04-81
E
EMU01449
TO THE OWNER
Thank you for choosing a Yamaha outboard motor. This Owner’s manual contains information needed for proper operation, maintenance and care. A thorough understanding of these simple instructions will help you obtain maximum enjoyment from your new Yamaha. If you have any question about the operation or maintenance of your outboard motor, please consult a Yamaha dealer.
In this Owner’s Manual particularly important information is distinguished in the following ways.
The Safety Alert Symbol means ATTENTION! BECOME ALERT! YOUR SAFETY IS INVOLVED!
CAUTION:
A CAUTION indicates special precautions that must be taken to avoid damage to the outboard motor.
NOTE:
A NOTE provides key information to make procedures easier or clearer.
*Yamaha continually seeks advancements in product design and quality. Therefore, while this manual contains the most current product information available at the time of printing, there may be minor discrepancies between your machine and this manual. If there is any question concerning this manual, please consult your Yamaha dealer.
WARNING
Failure to follow WARNING instructions could result in severe injury or death to the machine operator, a bystander, or a person inspecting or repairing the outboard motor.
NOTE:
The F8MH, T8PR and their standard accessories are used as a base for the explanations and illustrations in this manual. Therefore, some items may not apply to every model.
EMU01446
F6A/F8A/T8A
OWNER’S MANUAL
©2001 by Yamaha Motor Corporation, USA 1st Edition, June 2001
All rights reserved.
Any reprinting or unauthorized use without the written permission of Yamaha Motor Corporation, USA is expressly prohibited.
Printed in Japan
P/N LIT-18626-04-81
EMU00003
CONTENTS |
E |
GENERAL INFORMATION
BASIC COMPONENTS
OPERATION
MAINTENANCE
TROUBLE RECOVERY
INDEX
1
2
3
4
5
6
READ THIS OWNER’S MANUAL CAREFULLY BEFORE OPERATING YOUR OUTBOARD MOTOR.
|
|
|
|
|
E |
|
|
|
|
|
|
EMU00004 |
|
|
|
|
|
|
|
|
|
|
|
|
|
Chapter 1 |
1 |
|
|
|
|
|
GENERAL |
|
|
|
|
|
|
|
|
|
|
|
|
|
INFORMATION |
|
|
|
|
|
|
IDENTIFICATION NUMBERS RECORD |
1-1 |
|
|
|
|
|
||
|
|
|
|
|
Outboard motor serial number ................ |
1-1 |
|
|
|
|
|
Key number ............................................. |
1-1 |
|
|
|
|
|
EMISSION CONTROL INFORMATION .... |
1-2 |
|
|
|
|
|
||
|
|
|
|
|
North american models............................ |
1-2 |
|
|
|
|
|
Star labels................................................. |
1-3 |
|
|
|
|
|
SAFETY INFORMATION ........................... |
1-4 |
|
|
|
|
|
IMPORTANT LABELS ............................... |
1-6 |
|
|
|
|
|
Warning labels ......................................... |
1-6 |
|
|
|
|
|
Caution labels........................................... |
1-6 |
|
|
|
|
|
BASIC BOATING RULES |
|
|
|
|
|
|
(Rules of the road)..................................... |
1-7 |
|
|
|
|
|
Steering and sailing rules and sound |
|
|
|
|
|
|
signals ...................................................... |
1-7 |
|
|
|
|
|
Rules when encountering vessels........... |
1-8 |
|
|
|
|
|
Other special situations............................ |
1-9 |
|
|
|
|
|
FUELING INSTRUCTIONS...................... |
1-11 |
|
|
|
|
|
Gasoline (petrol)..................................... |
1-12 |
|
|
|
|
|
ENGINE OIL.............................................. |
1-13 |
|
|
|
|
|
BATTERY REQUIREMENT ..................... |
1-14 |
|
|
|
|
|
PROPELLER SELECTION ...................... |
1-15 |
|
|
|
|
|
START-IN-GEAR PROTECTION |
1-16 |
|
|
|
|
|
||
|
|
|
|
|
|
|
E
EMU00005
IDENTIFICATION NUMBERS
RECORD
EMU00007
OUTBOARD MOTOR SERIAL NUMBER
The outboard motor serial number is stamped on the label attached to the port side of the clamp-bracket.
Record your outboard motor serial number in the spaces provided to assist you in ordering spare parts from your Yamaha dealer or for reference in case your outboard motor is stolen.
1 Outboard motor serial number
EMU00008
KEY NUMBER
If a main key switch is equipped with the motor, the key identification number is stamped on your key as shown in the illustration. Record this number in the space provided for reference in case you need a new key.
1 Key number
1-1
E
EMU01385
EMISSION CONTROL
INFORMATION
EMU01444
NORTH AMERICAN MODELS
This engine conforms to U.S. Environmental Protection Agency (EPA) regulations for marine SI engines. See the label affixed to your engine for details.
Approval label of Emission control certificate
This label is attached to the bottom cowling.
1 Emission control information label
New Technology ; (4-stroke/HPDI) EM
Manufactured date label
This label is attached to the clamp bracket.
2 Manufactured date label
1-2
E
EMU01389
STAR LABELS
Your outboard motor is labeled with a California Air Resources Board (CARB) star label. See below for a description of your particular label.
1 Star label
One Star - Low Emission
The one-star label identifies engines that meet the Air Resources Board’s 2001 exhaust emission standards. Engines meeting these standards have 75% lower emissions than conventional carbureted twostroke engines. These engines are equivalent to the U.S. EPA’s 2006 standards for marine engines.
Two Stars - Very Low Emission
The two-star label identifies engines that meet the Air Resources Board’s 2004 exhaust emission standards. Engines meeting these standards have 20% lower emissions than One Star-Low-Emission engines.
Three Stars - Ultra Low Emission
The three-star label identifies engines that meet the Air Resources Board’s 2008 exhaust emission standards. Engines meeting these standards have 65% lower emissions than One Star-Low-Emission engines.
1-3
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
E |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|||||||||
|
|
|
|
|
|
|
|
|
|
|
|
● This product emits exhaust gases which |
|||||||||
EMU00917 |
|
|
|
|
|
|
|
|
|
|
|||||||||||
|
|
|
|
SAFETY |
|
|
|
|
contain carbon monoxide, a colorless, |
||||||||||||
|
|
INFORMATION |
|
|
|
odorless gas which may cause brain |
|||||||||||||||
|
|
|
|
|
|
|
|
|
|
|
|
damage or death when inhaled. Symp- |
|||||||||
● Before |
mounting or |
operating |
the |
out- |
toms |
include |
nausea, |
dizziness, |
and |
||||||||||||
drowsiness. Keep cockpit and cabin areas |
|||||||||||||||||||||
board |
motor, |
|
read |
this |
entire |
manual. |
|||||||||||||||
|
well ventilated. Avoid |
blocking exhaust |
|||||||||||||||||||
Reading it should give |
you |
an under- |
|||||||||||||||||||
outlets. |
|
|
|
|
|
|
|
||||||||||||||
standing of the motor and its operation. |
|
|
|
|
|
|
|
||||||||||||||
● Check throttle, shift, and steering for |
|||||||||||||||||||||
● Before |
operating the |
boat, |
read |
any |
|||||||||||||||||
owner’s or operator’s |
manuals |
supplied |
proper |
operation |
before |
starting |
the |
||||||||||||||
engine. |
|
|
|
|
|
|
|
||||||||||||||
with it and all labels. Be sure you under- |
|
|
|
|
|
|
|
||||||||||||||
● Attach the engine stop switch lanyard to a |
|||||||||||||||||||||
stand each item before operating. |
|
||||||||||||||||||||
|
secure |
place |
on |
your |
clothing, or |
your |
|||||||||||||||
● Do not overpower the boat with this out- |
|||||||||||||||||||||
arm or leg while operating. If you acciden- |
|||||||||||||||||||||
board |
motor. |
Overpowering |
the |
boat |
|||||||||||||||||
tally leave the helm, the lanyard will pull |
|||||||||||||||||||||
could result in loss of control. The rated |
|||||||||||||||||||||
from the switch, stopping the engine. |
|||||||||||||||||||||
power of the outboard should be equal to |
|||||||||||||||||||||
● Know the marine laws and regulations |
|||||||||||||||||||||
or less than the rated horsepower capac- |
|||||||||||||||||||||
ity of the boat. If the |
rated horsepower |
where |
you will |
be boating |
- |
and |
obey |
||||||||||||||
them. Refer |
to |
the “RULES |
OF |
THE |
|||||||||||||||||
capacity of the boat is unknown, consult |
|||||||||||||||||||||
ROAD” section for basic boating rules. |
|||||||||||||||||||||
the dealer or boat manufacturer. |
|
|
|||||||||||||||||||
|
|
● Stay informed about the weather. Check |
|||||||||||||||||||
● Do not modify the outboard. Modifications |
|||||||||||||||||||||
could make the motor unfit or unsafe to |
weather forecasts |
before boating. Avoid |
|||||||||||||||||||
boating in hazardous weather. |
|
|
|||||||||||||||||||
use. |
|
|
|
|
|
|
|
|
|
|
|
|
|||||||||
|
|
|
|
|
|
|
|
|
|
● Tell someone where you are going: leave |
|||||||||||
● Never |
operate |
after |
drinking |
alcohol or |
|||||||||||||||||
taking |
drugs. About |
50% of |
all |
boating |
a Float Plan with a responsible person. |
||||||||||||||||
Be sure to cancel the Float Plan when |
|||||||||||||||||||||
fatalities involve intoxication. |
|
|
|
||||||||||||||||||
|
|
|
you return. |
|
|
|
|
|
|
|
|||||||||||
● Have an approved personal flotation |
|
|
|
|
|
|
|
||||||||||||||
● Use common sense and good judgment |
|||||||||||||||||||||
device (PFD) on board for every occu- |
|||||||||||||||||||||
pant. It is a good idea to wear a PFD |
when boating. Know your abilities, and be |
||||||||||||||||||||
sure you understand how your boat han- |
|||||||||||||||||||||
whenever boating. At a minimum, children |
|||||||||||||||||||||
dles under the different boating conditions |
|||||||||||||||||||||
and non-swimmers should always wear |
|||||||||||||||||||||
you may encounter. Operate within your |
|||||||||||||||||||||
PFDs, and everyone should wear PFDs |
|||||||||||||||||||||
limits, and the limits of your boat. Always |
|||||||||||||||||||||
when |
there |
are potentially |
hazardous |
||||||||||||||||||
operate at safe speeds, and keep a care- |
|||||||||||||||||||||
boating conditions. |
|
|
|
|
|
|
|||||||||||||||
|
|
|
|
|
|
ful watch for obstacles and other traffic. |
|||||||||||||||
● Gasoline is highly flammable, and its |
|||||||||||||||||||||
● Always watch carefully for swimmers dur- |
|||||||||||||||||||||
vapors |
are |
flammable |
and |
explosive. |
|||||||||||||||||
Handle and store gasoline carefully. Make |
ing the engine operation. |
|
|
|
|||||||||||||||||
● Stay away from swimming areas. |
|
||||||||||||||||||||
sure there are no gas fumes or leaking |
|
fuel before starting the engine.
1-4
E
●When a swimmer is in the water near you shift into neutral and shut off the engine.
●Be informed about boating safety. Additional publications and information can be obtained from many organizations, including the following:
United States Coast Guard
Consumer Affairs Staff (G-BC)
Office of Boating, Public, and Consumer
Affairs
U.S. Coast Guard Headquarters
Washington, D.C. 20593-0001
Boating Safety Hotline: 1-800-368-5647
National Marine Manufacturers Association (NMMA)
401 N. Michigan Ave. Chicago, Il 60611
Marine Retailers Association of America
155 N. Michigan Ave.
Chicago, Il 60601
1-5
E
EMU00014
IMPORTANT LABELS
WARNING LABELS
1
2
CAUTION LABELS
3
1-6
E
EMU00015
BASIC BOATING RULES (Rules of the road)
Just as there are rules which apply when you are driving on streets and high ways, there are waterway rules which apply when you are driving your boat. These rules are used internationally, and are also enforced by the United States Coast Guard and local agencies. You should be aware of these rules, and follow them whenever you encounter another vessel on the water.
Several sets of rules prevail according to geographic location, but are all basically the same as the International Rules of the Road. The rules presented here in your Owner’s Manual are condensed, and have been provided for your convenience only. Consult your local U.S. Coast Guard Auxiliary or Department of Motor Vehicles for a complete set of rules governing the waters in which you will be using your boat.
STEERING AND SAILING RULES AND SOUND SIGNALS
Whenever two vessels on the water meet one another, one vessel has the right-of- way; it is called the “stand-on” vessel. The vessel which does not have the right-of-way is called the “give-way” or “burdened” vessel. These rules determine which vessel has the right-of-way, and what each vessel should do.
Stand-on vessel
The vessel with the right-of-way has the duty to continue its course and speed, except to avoid an immediate collision. When you maintain your direction and speed, the other vessel will be able to determine how best to avoid you.
Give-way vessel
The vessel which does not have the right-of- way has the duty to take positive and timely action to stay out of the way of the Stand-On vessel. Normally, you should not cross in front of the vessel with the right-of-way. You should slow down or change directions briefly and pass behind the other vessel. You should always move in such a way that the operator of the other vessel can see what you are doing.
“The general prudential rule”
This rule is called Rule 2 in the International Rules and says,
‘In obeying and construing these rules due regard shall be had to all dangers of navigation and collision, and to any special circumstances, which may render a departure from the above rules necessary in order to avoid immediate danger.’
In other words, follow the standard rules except when a collision will occur unless both vessels try to avoid each other. If that is the case, both vessels become “Give-Way” vessels.
1-7
E
RULES WHEN ENCOUNTERING VESSELS
There are three main situations which you may encounter with other vessels which could lead to a collision unless the Steering Rules are followed:
Meeting
(you are approaching another vessel head-on)
Crossing
(you are traveling across the other vessel’s path)
Overtaking
(you are passing or being passed by another vessel)
In the following illustration, your boat is in the center. You should give the right-of-way to any vessels shown in white area (you are the Give-Way vessel). Any vessels in the shaded area must yield to you (they are the Give-Way vessels). Both you and the meeting vessel must alter course to avoid each other.
avoid an accident. You should keep the other vessel on your port (left) side. This rule doesn’t apply if both of you will clear one another if you continue on your set course and speed.
Crossing
When two power driven vessels are crossing each other’s path close enough to run the risk of collision, the vessel which has the other on the starboard (right) side must keep out of the way of the other. If the other vessel is on your right, you must keep out of its way; you are the Give-Way vessel. If the other vessel is on your port (left) side, remember that you should maintain course and direction, provided the other vessel gives you the right-of-way as it should.
Meeting
If you are meeting another power vessel head on, and are close enough to run the risk of collision, neither of you has the right- of-way! Both of you should alter course to
Overtaking
If you are passing another vessel, you are the “Give-Way” vessel. This means that the
1-8
E
other vessel is expected to maintain its course and speed. You must stay out of its way until you are clear of it. Likewise, if another vessel is passing you, you should maintain your speed and direction so that the other vessel can steer itself around you.
OTHER SPECIAL SITUATIONS
There are three other rules you should be aware of when driving your boat around other vessels.
Narrow channels and bends
When navigating in narrow channels, you should keep to the right when it is safe and practical to do so. If the operator of a powerdriven vessel is preparing to go around a bend that may obstruct the view of other water vessels, the operator should sound a prolonged blast on the whistle (4 to 6 seconds). If another vessel is around the bend, it too should sound the whistle. Even if no reply is heard, however, the vessel should still proceed around the bend with caution. If you navigate such waters with your boat, you will need to carry a portable air horn, available from local marine supply stores.
Fishing vessel right-of-way
All vessels which are fishing with nets, lines or trawls are considered to be “fishing vessels” under the International Rules. Vessels with trolling lines are not considered fishing vessels. Fishing vessels have the right-of- way regardless of position. Fishing vessels cannot, however, impede the passage of other vessels in narrow channels.
Sailing vessel right-of-way
Sailing vessels should normally be given the right-of-way. The exceptions to this are:
1.When the sailing vessel is overtaking the power-driven vessel, the powerdriven vessel has the right-of-way.
2.Sailing vessels should keep clear of any fishing vessel.
3.In a narrow channel, a sailing vessel should not hamper the safe passage of a power-driven vessel which can navigate only in such a channel.
Reading buoys and other markers
The waters of the United states are marked for safe navigation by the lateral system of buoyage. Simply put, buoys and markers have an arrangement of shapes, colors, numbers and lights to show which side of the buoy a boater should pass on when navigating in a particular direction. The markings on these buoys are oriented from the perspective of being entered from seaward (the boater is going towards the port). This means that red buoys are passed on the starboard (right) side when proceeding from open water into port, and black buoys are to port (left) side. When navigating out of port, your position with respect to the buoys should be reversed; red buoys should be to port and black buoys to starboard.
Many bodies of water used by boaters are entirely within the boundaries of a particular state. The Uniform State Waterway Marking System has been devised for these waters. This system uses buoys and signs with distinctive shapes and colors to show regulatory or advisory information. These markers are white with black letters and orange boarders. They signify speed zones, restricted areas, danger areas, and general information.
1-9
E
Remember, markings may vary by geographic location. Always consult local boating authorities before driving your boat in unfamiliar waters.
1-10
E
EMU00016
FUELING INSTRUCTIONS
WARNING
GASOLINE AND ITS VAPORS ARE HIGHLY FLAMMABLE AND EXPLOSIVE!
●Do not smoke when refueling, and keep away from sparks, flames, or other sources of ignition.
●Stop engine before refueling.
●Refuel in a well-ventilated area. Refuel portable fuel tanks off the boat.
●Take care not to spill gasoline. If gasoline spills, wipe it up immediately with dry rags.
●Do not overfill the fuel tank.
●Tighten the filler cap securely after refueling.
●If you should swallow some gasoline inhale a lot of gasoline vapor, or get gasoline in your eyes, get immediate medical attention.
●If any gasoline spills onto your skin, immediately wash with soap and water. Change clothing if gasoline spills on it.
●Touch the fuel nozzle to the filler opening or funnel to help prevent electrostatic sparks.
CAUTION:
Use only new clean gasoline which has been stored in clean containers and is not contaminated with water or foreign matter.
1-11
E
EMU00025
GASOLINE (PETROL)
Recommended gasoline: Regular unleaded gasoline with a minimum octane rating of 86
(Pump Octane Number) = (R+M)/2
If knocking or pinging occurs, use a different brand of gasoline or premium unleaded fuel. If unleaded gasoline is not available, then leaded regular gasoline can be used.
If leaded gasoline is usually used, engine valves and related parts should be inspected after every 300 hours of operation.
EMU00027
Gasohol
There are two types of gasohol: gasohol containing ethanol and that containing methanol. Gasohol containing ethanol can be used if ethanol content does not exceed 10% and the fuel meets minimum octane ratings. Gasohol containing methanol is not recommended by Yamaha because it can cause fuel system damage or engine performance problems.
1-12
E
EMU01149
ENGINE OIL
Recommended engine oil; Use a combination of corresponding SAE and API shown in the chart below;
Engine oil quantity:
Refer to “SPECIFICATIONS”, Page 4-1.
CAUTION:
All four-stroke engines are shipped from the factory without engine oil.
NOTE:
If the recommended engine oil is not available, then a multigrade type engine oil such as SF-CC/CD,SG-CC/CD or SH-CD can be used.
1-13
E
EMU01430¯
BATTERY REQUIREMENT
CAUTION:
Do not use a battery that does not meet the specified capacity. If a battery which differs from the specification is used, the electrical system may perform poorly or be overloaded, causing electrical system damage.
CAUTION:
●A battery cannot be connected to models which do not have a rectifier or rec-
tifier regulator.
Models without a rectifier or rectifier regulator: F6MHA/F8MHA
●If you wish to use a battery with the above models, install an optional rectifier regulator.
Choose a battery for electric start models which meets the following specifications.
Minimum cold crank performance 380 Amps at –17.8 °C (0 °F) Minimum reserve capacity
124 minutes at 26.7 °C (80 °F)
1-14
E
EMU01395
PROPELLER SELECTION
The performance of your outboard motor will be critically affected by your choice of propeller, as an incorrect choice could adversely affect performance and could also seriously damage the motor. Engine speed depends on the propeller size and boat load. If engine speed is too high or too low for good engine performance, this will have an adverse effect on the engine.
Yamaha outboard motors are fitted with propellers chosen to perform well over a range of applications, but there may be uses where a propeller with a different pitch would be more appropriate. For a greater operating load, a smaller-pitch propeller is more suitable as it enables the correct engine speed to be maintained. Conversely, a larger-pitch propeller is more suitable for a smaller operating load.
Yamaha dealers stock a range of propellers, and can advise you and install a propeller on your outboard that is best suited to your application.
NOTE:
At full throttle and under a maximum boat load, the engine’s rpm should be within the upper half of the full throttle operating range, as listed in “SPECIFICATIONS” on page 4-1. Select a propeller which fulfills this requirement.
If operating under conditions which allow the engine’s rpm to rise above the maximum recommended range (such as light boat loads), reduce the throttle setting to maintain the rpm in the proper operating range.
1-15
E
1Propeller diameter (in inches)
2Propeller pitch (in inches)
3Type of propeller (propeller mark)
Refer to the section “CHECKING PROPELLER” for instructions on propeller removal and installation.
EMU01209¯
START-IN-GEAR PROTECTION
Yamaha outboard motors or Yamaha approved remote control units are equipped with start-in-gear protection device(s). This feature permits the engine to be started only when it is Neutral. Always select Neutral before starting the engine.
1-16
E
-MEMO-
1-17
E
EMU00037
Chapter 2
|
MAIN COMPONENTS................................ |
2-1 2 |
|
OPERATIONS OF CONTROLS AND |
|
|
OTHER FUNCTIONS.................................. |
2-3 |
|
Fuel tank................................................... |
2-3 |
|
||
|
Choke knob .............................................. |
2-3 |
|
Recoil starter handle |
|
|
(if equipped) ............................................. |
2-4 |
|
Starter button (for tiller control model)..... |
2-4 |
|
Multifunction tiller handle ......................... |
2-4 |
|
Remote control......................................... |
2-8 |
|
Steering friction adjusting lever.............. |
2-13 |
|
Trim angle adjusting rod ........................ |
2-13 |
|
Power trim/tilt switch .............................. |
2-14 |
|
Tilt lock mechanism |
|
|
(for manual tilt model) ............................ |
2-14 |
|
Tilt support knob..................................... |
2-15 |
|
Tilt support bar ....................................... |
2-15 |
|
Power tilt unit.......................................... |
2-15 |
|
Top cowling lock lever............................ |
2-16 |
|
Flushing device ...................................... |
2-16 |
|
Warning indicator(s)............................... |
2-16 |
|
WARNING SYSTEM................................. |
2-17 |
|
Low oil pressure warning....................... |
2-17 |
|
|
|
E
EMU01206
MAIN COMPONENTS
F6A/F8A
1 Top cowling |
B Gear shift lever |
2 Top cowling lock lever |
C Tiller handle |
3 Anti-cavitation plate |
D Steering friction adjusting lever |
* 4 Propeller |
E Tilt lock lever |
5 Cooling water inlet |
F Clamp screw |
6 Oil drain bolt |
G Rope attachment |
7 Trim angle adjusting rod |
H Flushing device |
8 Clamp bracket |
I Choke knob |
9 Recoil starter handle |
|
0 Warning indicator |
* May not be exactly as shown; also may not be in- |
A Engine stop lanyard switch/ |
cluded as standard equipment on all models. |
Engine stop button |
|
|
2-1 |
E
T8A
1 Top cowling |
* D Gear shift lever |
2 Top cowling lock lever |
* E Tiller handle |
3 Anti-cavitation plate |
* F Steering friction adjusting lever |
4 Propeller |
* G Tilt lock lever |
5 Cooling water inlet |
H Clamp screw |
6 Oil drain bolt |
I Rope attachment |
7 Trim angle adjusting rod |
J Flushing device |
8 Clamp bracket |
K Choke knob |
* 9 Power tilt switch |
* L Remote control box |
* 0 Recoil starter handle |
|
A Warning indicator |
* May not be exactly as shown; also may not be in- |
* B Starter button |
cluded as standard equipment on all models. |
* C Engine stop layard switch/ |
|
Engine stop button |
2-2 |
|
E
EMU00039
OPERATIONS OF CONTROLS
AND
OTHER FUNCTIONS
EMU01465
FUEL TANK
If your model included a portable fuel tank, its parts and functions are as follows.
1Fuel hose joint
2Fuel meter (if equipped)
3Fuel tank cap
4Air vent screw (if equipped)
EMU00042
Fuel Hose Joint
This connector is provided for connecting or disconnecting fuel hose.
EMU00044
Fuel Meter
This meter is on the fuel tank cap. It shows current fuel quantity in the fuel tank approximately.
EMU00045
Fuel Tank Cap
This cap is for filling fuel. To remove it, turn it counterclockwise.
EMU00046
Air Vent Screw
This screw is on the fuel tank cap. To loosen it, turn it counterclockwise.
2-3
E
EMU00057
Tiller control model
CHOKE KNOB
Pulling out this knob (setting it to ON) supplies a rich mixture required to start the engine.
EMU00059
RECOIL STARTER HANDLE (If equipped)
Pull the handle gently until resistance is felt. Then vigorously pull the handle straight out to crank the engine to start it.
EMU00060
STARTER BUTTON (for Tiller control model) (T8PH)
When you push the starter button, the electric starter motor cranks the engine to start it.
2-4
E
EMU01122¯
MULTIFUNCTION TILLER HANDLE
The tiller handle centralized most of functions for the outboard motor operation.
1Tiller handle
2Gear shift lever
3Throttle control grip
4Throttle indicator
5Throttle friction adjusting knob
6Engine stop lanyard switch / Engine stop button (If equipped)
7Main switch (if equipped)
8Power tilt switch (if equipped)
EMU00079
Tiller handle
Moving the tiller handle sideways to adjust the steering direction.
EMU00080
Gear shift lever
Turning the gear-shift lever forward (bow side) engages the clutch with the forward gear so that the boat moves ahead. Turning the lever backward (stern side) engages the reverse gear so that the boat moves astern.
1Neutral
2Forward
3Reverse
2-5
