L2 SWITCH
SWP1-8 / SWP1-8MMF / SWP1-16MMF
Owner’s Manual Bedienungsanleitung Mode d’emploi
Manual de instrucciones Manual do Proprietário Manuale di istruzioni Руководство пользователя
EN
DE
FR
ES
PT
IT
RU
English
Русский Italiano Português Español Français Deutsch
|
JA |
|
The above warning is located on the top of the unit.
L’avertissement ci-dessus est situé sur le dessus de l’unité.
Explanation of Graphical Symbols
Explication des symboles
The lightning flash with arrowhead symbol within an equilateral triangle is intended to alert the user to the presence of uninsulated “dangerous voltage” within the product’s enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons.
L’éclair avec une flèche à l’intérieur d’un triangle équilatéral est destiné à attirer l’attention de l’utilisateur sur la présence d’une « tension dangereuse » non isolée à l’intérieur de l’appareil, pouvant être suffisamment élevée pour constituer un risque d’électrocution.
The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the product.
Le point d’exclamation à l’intérieur d’un triangle équilatéral est destiné à attirer l’attention de l’utilisateur sur la présence d’instructions importantes sur l’emploi ou la maintenance (réparation) de l’appareil dans la documentation fournie.
IMPORTANT SAFETY |
|
PRÉCAUTIONS CONCER- |
||
INSTRUCTIONS |
|
NANT LA SÉCURITÉ |
||
1 |
Read these instructions. |
1 |
Lire ces instructions. |
|
2 |
Keep these instructions. |
2 |
Conserver ces instructions. |
|
3 |
Heed all warnings. |
3 |
Tenir compte de tous les avertissements. |
|
4 |
Follow all instructions. |
4 |
Suivre toutes les instructions. |
|
5 |
Do not use this apparatus near water. |
5 |
Ne pas utiliser ce produit à proximité d’eau. |
|
6 |
Clean only with dry cloth. |
6 |
Nettoyer uniquement avec un chiffon propre et sec. |
|
7 |
Do not block any ventilation openings. Install in accordance with the |
7 |
Ne pas bloquer les orifices de ventilation. Installer l’appareil conformément |
|
|
manufacturer’s instructions. |
|
|
aux instructions du fabricant. |
8 |
Do not install near any heat sources such as radiators, heat registers, |
8 |
Ne pas installer l’appareil à proximité d’une source de chaleur comme un |
|
|
stoves, or other apparatus (including amplifiers) that produce heat. |
|
|
radiateur, une bouche de chaleur, un poêle ou tout autre appareil (y compris |
9 |
Do not defeat the safety purpose of the polarized or grounding-type |
|
|
un amplificateur) produisant de la chaleur. |
|
plug. A polarized plug has two blades with one wider than the other. A |
9 |
Ne pas modifier le système de sécurité de la fiche polarisée ou de la fiche de |
|
|
grounding type plug has two blades and a third grounding prong. The |
|
|
terre. Une fiche polarisée dispose de deux broches dont une est plus large |
|
wide blade or the third prong are provided for your safety. If the pro- |
|
|
que l’autre. Une fiche de terre dispose de deux broches et d’une troisième |
|
vided plug does not fit into your outlet, consult an electrician for |
|
|
pour le raccordement à la terre. Cette broche plus large ou cette troisième |
|
replacement of the obsolete outlet. |
|
|
broche est destinée à assurer la sécurité de l’utilisateur. Si la fiche équipant |
10 |
Protect the power cord from being walked on or pinched particularly |
|
|
l’appareil n’est pas compatible avec les prises de courant disponibles, faire |
|
at plugs, convenience receptacles, and the point where they exit from |
|
|
remplacer les prises par un électricien. |
|
the apparatus. |
10 |
Acheminer les cordons d’alimentation de sorte qu’ils ne soient pas piétinés |
|
11 |
Only use attachments/accessories specified by the manufacturer. |
|
|
ni coincés, en faisant tout spécialement attention aux fiches, prises de cou- |
12 |
Use only with the cart, stand, tripod, bracket, or |
|
|
rant et au point de sortie de l’appareil. |
|
table specified by the manufacturer, or sold with |
11 |
Utiliser exclusivement les fixations et accessoires spécifiés par le fabricant. |
|
|
the apparatus. When a cart is used, use caution |
12 |
Utiliser exclusivement le chariot, le stand, le trépied, |
|
|
when moving the cart/apparatus combination to |
|
|
le support ou la table recommandés par le fabricant |
|
avoid injury from tip-over. |
|
|
ou vendus avec cet appareil. Si l’appareil est posé |
13 |
Unplug this apparatus during lightning storms |
|
|
sur un chariot, déplacer le chariot avec précaution |
|
or when unused for long periods of time. |
|
|
pour éviter tout risque de chute et de blessure. |
14 |
Refer all servicing to qualified service personnel. Servicing is |
13 |
Débrancher l’appareil en cas d’orage ou lorsqu’il doit |
|
|
required when the apparatus has been damaged in any way, such as |
|
|
rester hors service pendant une période prolongée. |
|
power-supply cord or plug is damaged, liquid has been spilled or |
14 |
Confier toute réparation à un personnel qualifié. Faire réparer l’appareil s’il a |
|
|
objects have fallen into the apparatus, the apparatus has been |
|
|
subi tout dommage, par exemple si la fiche ou le cordon d’alimentation est |
|
exposed to rain or moisture, does not operate normally, or has been |
|
|
endommagé, si du liquide a coulé ou des objets sont tombés à l’intérieur de |
|
dropped. |
|
|
l’appareil, si l’appareil a été exposé à la pluie ou à de l’humidité, si l’appareil |
15 |
[EXT DC INPUT] Connector is intended to be supplied by UL Listed |
|
|
ne fonctionne pas normalement ou est tombé. |
|
Power Supply marked “Limited Power Source”, “LPS” or “Class 2” |
15 |
Le connecteur [EXT DC INPUT] (Entrée CC extérieure) est conçu pour être ali- |
|
|
and rated 24 Vdc. |
|
|
menté par une source d'alimentation à courant continu répertoriée UL, mar- |
|
|
|
|
quée « LPS » à puissance régulée ou de « Classe 2 » et d'une puissance de |
WARNING |
|
|
24 V cc. |
|
TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT |
|
|
|
|
|
AVERTISSEMENT |
|||
EXPOSE THIS APPARATUS TO RAIN OR MOISTURE. |
|
|||
|
|
|
POUR RÉDUIRE LES RISQUES D’INCENDIE OU DE DÉCHARGE |
|
|
|
|||
|
|
|
ÉLECTRIQUE, N’EXPOSEZ PAS CET APPAREIL À LA PLUIE OU À |
|
|
|
|
L’HUMIDITÉ. |
|
|
|
|
|
|
2 |
SWP1 Owner’s Manual |
FCC INFORMATION (for US customers)
1.IMPORTANT NOTICE: DO NOT MODIFY THIS UNIT!
This product, when installed as indicated in the instructions contained in this manual, meets FCC requirements. Modifications not expressly approved by Yamaha may void your authority, granted by the FCC, to use the product.
2.IMPORTANT: When connecting this product to accessories and/ or another product use only high quality shielded cables. Cable/s supplied with this product MUST be used. Follow all installation instructions. Failure to follow instructions could void your FCC authorization to use this product in the USA.
3.NOTE: This product has been tested and found to comply with the requirements listed in FCC Regulations, Part 15 for Class “A” digital devices. Compliance with these requirements provides a reasonable level of assurance that your use of this product, in a commercial environment, will not result in harmful interference with other electronic devices. However, operation of this product in a commercial area is likely to cause interference in some form. In this case you, the user, bear the responsibility of correcting this condition.
This product generates/uses radio frequencies and, if not installed and used according to the instructions found in the users manual,
may cause interference harmful to the operation of other electronic devices. Compliance with FCC regulations does not guarantee that interference will not occur in all installations. If this product is found to be the source of interference, which can be determined by turning the product “OFF” and “ON”, please try to eliminate the problem by using one of the following measures:
Relocate either the product generating the interference or the device that is being affected by the interference.
Utilize power outlets that are on different branch (circuit breaker or fuse) circuits or install AC line filter/s.
In the case of radio or TV interference, relocate/reorient the antenna. If the antenna lead-in is 300 ohm ribbon lead, change the lead-in to co-axial type cable.
If these corrective measures do not produce satisfactory results, please contact the local retailer that is authorized to distribute this type of product. If you can not locate the appropriate retailer, please contact Yamaha Corporation of America, Electronic Service Division, 6600 Orangethorpe Ave, Buena Park, CA90620
The above statements apply ONLY to those products distributed by Yamaha Corporation of America or its subsidiaries.
* This applies only to products distributed by YAMAHA CORPORATION OF AMERICA. |
(class A) |
IMPORTANT NOTICE FOR THE UNITED KINGDOM
Connecting the Plug and Cord
WARNING: THIS APPARATUS MUST BE EARTHED IMPORTANT. The wires in this mains lead are coloured in accordance with the following code:
GREEN-AND-YELLOW : EARTH
BLUE |
: |
NEUTRAL |
BROWN |
: |
LIVE |
As the colours of the wires in the mains lead of this apparatus may not correspond with the coloured markings identifying the terminals in your plug proceed as follows:
The wire which is coloured GREEN-and-YELLOW must be connected to the terminal in the plug which is marked by the letter E or by the safety earth symbol
or colored GREEN or GREEN-and-YELLOW.
The wire which is coloured BLUE must be connected to the terminal which is marked with the letter N or coloured BLACK.
The wire which is coloured BROWN must be connected to the terminal which is marked with the letter L or coloured RED.
(3 wires)
SWP1 Owner’s Manual |
3 |
PRECAUTIONS
PLEASE READ CAREFULLY BEFORE PROCEEDING
Please keep this manual in a safe place for future reference.
WARNING
Always follow the basic precautions listed below to avoid the possibility of serious injury or even death from electrical shock, short-circuiting, damages, fire or other hazards. These precautions include, but are not limited to, the following:
Power supply/power cord
•Do not place the power cord near heat sources such as heaters or radiators, and do not excessively bend or otherwise damage the cord, place heavy objects on it, or place it in a position where anyone could walk on, trip over, or roll anything over it.
•Only use the voltage specified as correct for the device. The required voltage is printed on the name plate of the device.
•Use only the supplied power cord/plug.
If you intend to use the device in an area other than in the one you purchased, the included power cord may not be compatible. Please check with your Yamaha dealer.
•Check the electric plug periodically and remove any dirt or dust which may have accumulated on it.
•When setting up the device, make sure that the AC outlet you are using is easily accessible. If some trouble or malfunction occurs, immediately disconnect the plug from the outlet, and also disconnect the connected power supply from the [EXT DC INPUT] connector.
•Remove the electric plug from the outlet when the device is not to be used for extended periods of time, or during electrical storms.
•Be sure to connect to an appropriate outlet with a protective grounding connection. Improper grounding can result in electrical shock, damage to the device(s), or even fire.
Do not open
•This device contains no user-serviceable parts. Do not open the device or attempt to disassemble the internal parts or modify them in any way. If it should appear to be malfunctioning, discontinue use immediately and have it inspected by qualified Yamaha service personnel.
Water warning
•Do not expose the device to rain, use it near water or in damp or wet conditions, or place on it any containers (such as vases, bottles or glasses) containing liquids which might spill into any openings. If any liquid such as water seeps into the device, turn off the power immediately and unplug the power cord from the AC outlet. Then have the device inspected by qualified Yamaha service personnel.
•Never insert or remove an electric plug with wet hands.
PA_en_6 1/2
Hearing loss
•When turning on the AC power in your audio system, always turn on the power amplifier LAST, to avoid hearing loss and speaker damage. When turning the power off, the power amplifier should be turned off FIRST for the same reason.
Fire warning
•Do not place any burning items or open flames near the device, since they may cause a fire.
If you notice any abnormality
•When one of the following problems occur, immediately disconnect the electric plug from the outlet. Then have the device inspected by Yamaha service personnel.
-The power cord or plug becomes frayed or damaged.
-Unusual smells or smoke are emitted.
-Some object has been dropped into the device.
-There is a sudden loss of sound during use of the device.
-Cracks or other visible damage appear on the device.
•If this device should be dropped or damaged, immediately disconnect the electric plug from the outlet, and have the device inspected by qualified Yamaha service personnel.
Handling
•Do not touch the interior of the ports with your finger or a metal object.
•Doing so may cause electrocution or malfunctions.
If lightning is occurring nearby, do not touch the unit or the power cord. Doing so carries the risk of electrocution.
4 |
SWP1 Owner’s Manual |
CAUTION
Always follow the basic precautions listed below to avoid the possibility of physical injury to you or others, or damage to the device or other property. These precautions include, but are not limited to, the following:
Power supply/power cord
•When removing the electric plug from the device or an outlet, always hold the plug itself and not the cord. Pulling by the cord can damage it.
Location
•Do not place the device in an unstable position where it might accidentally fall over and cause injuries.
•Do not block the vents. This device has ventilation holes at the sides to prevent the internal temperature from becoming too high. In particular, do not place the device on its side or upside down. Inadequate ventilation can result in overheating, possibly causing damage to the device(s), or even fire.
•When attempting to dissipate heat on the device, when installing it:
-Do not cover it with any cloth.
-Do not install it on a carpet or rug.
-Make sure the top surface faces up; do not install on its sides or upside down.
-Do not use the device in a confined, poorly-ventilated location.
Inadequate ventilation can result in overheating, possibly causing damage to the device(s), or even fire.
•Do not place the device in a location where it may come into contact with corrosive gases or salt air. Doing so may result in malfunction.
•Before moving the device, remove all connected cables.
•If the device is mounted in an EIA standard rack, carefully read the section “Precautions for Rack Mounting” on page 9. Inadequate ventilation can result in overheating, possibly causing damage to the device(s), malfunction, or even fire.
Connections
•Before connecting the device to other devices, turn off the power for all devices. Also, before turning the power of all devices on or off, make sure that all volume levels are set to the minimum. Failing to do so may result in electric shock, hearing loss, or equipment damage.
Maintenance
•Remove the power plug from the AC outlet when cleaning the device.
Handling caution
•Do not insert your fingers or hands in any gaps or openings on the device (vents, panel, etc.).
•Avoid inserting or dropping foreign objects (paper, plastic, metal, etc.) into any gaps or openings on the device (vents, panel, etc.) If this happens, unplug the power cord from the outlet. Then have the device inspected by qualified Yamaha service personnel.
PA_en_6 2/2
•Do not rest your weight on the device or place heavy objects on it, and avoid use excessive force on the buttons, switches or connectors to prevent injuries.
•Do not connect any console cable other than an RJ-45/DB-9 console cable to the [CONSOLE (RS232-C)] connector. Doing so may cause fire, electrocution, or malfunction.
•This product (SWP1-8MMF and SWP1-16MMF) uses lasers. Do not look into the tip of an optical fiber or into an optical connector. Doing so may damage your eyes.
Yamaha cannot be held responsible for damage caused by improper use or modifications to the device, or data that is lost or destroyed.
SWP1 Owner’s Manual |
5 |
NOTICE
To avoid the possibility of malfunction/ damage to the product, damage to data, or damage to other property, follow the notices below.
Handling and maintenance
•Do not use the device in the vicinity of a TV, radio, stereo equipment, mobile phone, or other electric devices. Otherwise, the device, TV, or radio may generate noise.
•Do not expose the device to excessive dust or vibration, or extreme cold or heat (such as in direct sunlight, near a heater, or in a car during the day), in order to prevent the possibility of panel disfiguration, unstable operation, or damage to the internal components.
•Do not place vinyl, plastic or rubber objects on the device, since this might discolor the panel.
•When cleaning the device, use a dry and soft cloth. Do not use paint thinners, solvents, cleaning fluids, or chemicalimpregnated wiping cloths.
•Condensation can occur in the device due to rapid, drastic changes in ambient temperature—when the device is moved from one location to another, or air conditioning is turned on or off, for example. Using the device while condensation is present can cause damage. If there is reason to believe that condensation might have occurred, leave the device for several hours without turning on the power until the condensation has completely dried out.
•When you are not using the device for a long time, make sure you unplug the power cord from the wall AC outlet.
Information
About copyrights
•Copying of the software or reproduction of this manual in whole or in part by any means is expressly forbidden without the written consent of the manufacturer.
About functions/data bundled with the device
•This is a class A product. In a domestic environment this product may cause radio interference in which case the user may be required to take adequate measures. (CISPR22)
•This product is a class 1 laser product. It is compliant with IEC60825-1, IEC60825-2, FDA 21 CFR 1002.10, and 1002.12.
•Ensure all the communication cables are kept apart from the power cable, etc. Failure to observe this could result in a large amount of voltage being generated and a subsequent malfunction.
•Ensure to initialize the settings before transferring/disposing of the product.
•Installation of the device must comply with local and national electrical codes.
About this manual
•The illustrations as shown in this manual are for instructional purposes only.
•Yamaha Corporation make no representations or warranties with regard to the use of the software and documentation and cannot be held responsible for the results of the use of this manual and the software.
•Windows is a registered trademark of Microsoft® Corporation in the United States and other countries.
•The company names and product names in this manual are the trademarks or registered trademarks of their respective companies.
•Software may be revised and updated without prior notice.
Open Source Software Used in this Product
•Please refer to Yamaha Pro Audio website for the details of licensing article.
http://www.yamahaproaudio.com/
Information for Users on Collection and Disposal of Old Equipment
This symbol on the products, packaging, and/ or accompanying documents means that used
electrical and electronic products should not be mixed with general household waste.
For proper treatment, recovery and recycling of old products, please take them to applicable
collection points, in accordance with your national legislation and the Directives 2002/96/EC.
By disposing of these products correctly, you will help to save valuable resources and prevent any potential negative effects on human health and the environment which could otherwise arise from inappropriate waste handling.
For more information about collection and recycling of old products, please contact your local municipality, your waste disposal service or the point of sale where you purchased the items.
[For business users in the European Union]
If you wish to discard electrical and electronic equipment, please contact your dealer or supplier for further information.
[Information on Disposal in other Countries outside the European Union]
This symbol is only valid in the European Union. If you wish to discard these items, please contact your local authorities or dealer and ask for the correct method of disposal.
(weee_eu_en_01)
The model number, serial number, power requirements, etc., may be found on or near the name plate, which is at the top of the unit. You should note this serial number in the space provided below and retain this manual as a permanent record of your purchase to aid identification in the event of theft.
Model No.
Serial No.
(rear_en_01)
6 |
SWP1 Owner’s Manual |
SOFTWARE LICENCE
AGREEMENT
This agreement is an agreement between you, the customer, and Yamaha Corporation (hereafter referred to as “Yamaha”) defining the conditions under which Yamaha provides firmware for this Yamaha network product (hereafter referred to as the Product) and related programs, printed material, and electronic files (hereafter referred to as the Software).
The Software may be used only for the purpose of operating it on the Product or on a personal computer or similar device. This agreement applies to the Software provided by Yamaha to the customer and to copies of the Software created by the customer in compliance with section 1 subsection (1) of this agreement.
1. Permission to use
(1)The customer may install and use the Software on a Product or a personal computer or similar device owned by the customer.
(2)With the exceptions that are explicitly defined by this agreement, the customer shall not permit the reuse of, sell, distribute, rent, lease, lend, or transfer the Software, nor upload it to any website or server where it could be accessed by specified or unspecified numbers of people, nor duplicate, translate, adapt it, or rewrite it into any other program language. The customer shall not correct, revise, reverse-assemble, reverse-compile, or perform any reverse engineering of the Software, and may not cause any third party to perform such actions.
(3)The customer shall not modify, erase, or delete the Yamaha copyright indications that are included in the Software.
(4)With the exceptions that are explicitly defined by this agreement, Yamaha does not grant or permit the customer any of Yamaha's intellectual property rights.
2. Property rights
The Software is protected by copyright law and by other laws, and is the property of Yamaha. The customer hereby agrees that no property rights or intellectual property rights related to the Software are granted by Yamaha to the customer by this agreement nor any other means.
3. Export restrictions
The customer shall abide by all applicable export regulations and rules of the relevant countries, and shall not export or reexport the Software, neither in part nor in whole, in violation of any applicable rules and regulations.
4. Support and updates
Yamaha, its subsidiaries, their sales representatives and dealers, and any other party handling or distributing the Software do not accept any responsibility for maintaining the Software nor for supporting the customer's use of the Software. Nor do the aforementioned parties have any responsibility to update the Software, to fix bugs, or to provide support.
5. Limitation of responsibility
(1)The software is licensed for use “in its current state (as-is).” Yamaha, its subsidiaries, their sales representatives and dealers, and any other party handling or distributing the Software make no warranty, neither explicit nor implicit, regarding the merchantability or suitability of the Software for any particular purpose.
(2)Yamaha, its subsidiaries, their sales representatives and dealers, and any other party handling or distributing the
Software shall bear no responsibility for any damages (including but not limited to lost profit and any other consequential or incidental damages) that may arise from the use of or inability to use the Software. This shall be the case even if Yamaha, its subsidiaries, their sales representatives and dealers, or any other party handling or distributing the Software had been informed of the possibility of such damages.
(3)Yamaha, its subsidiaries, their sales representatives and dealers, and any other party handling or distributing the Software shall bear no responsibility for any dispute between the customer and a third party that may arise from or related to the use of the Software.
6. Term of validity
(1)This agreement shall continue in force until it is terminated by the following sub-sections (2) or (3).
(2)The customer may terminate this agreement by deleting all instances of the Software that are installed on the Product or on a personal computer or similar device.
(3)This agreement shall immediately terminate if the customer violates any of the terms of this agreement.
(4)Upon the termination of this agreement due to sub-section
(3) above, the customer shall immediately delete all instances of the Software that are installed on the Product or on a personal computer or similar device.
(5)Regardless of any clauses of this agreement, the provisions of sections 2 through 6 of this agreement shall continue in force even after the termination of this agreement.
7. Separability
Even if any clause of this agreement should become invalid, the remainder of the agreement shall remain in force.
8. U.S. GOVERNMENT RESTRICTED RIGHTS NOTICE:
The Software is a “commercial item,” as that term is defined at 48 C.F.R. 2.101 (Oct 1995), consisting of “commercial computer software” and “commercial computer software documentation,” as such terms are used in 48 C.F.R. 12.212 (Sept 1995). Consistent with 48 C.F.R. 12.212 and 48 C.F.R. 227.7202-1 through 227.72024 (June 1995), all U.S. Government End Users shall acquire the Software with only those rights set forth herein.
9. General articles
The customer agrees that this agreement is the complete and only declaration of agreement between the customer and Yamaha regarding all matters prescribed by this agreement, and that it takes precedence over all proposals, prior agreements, or any other communication between the customer and Yamaha, whether oral or written. No change to this agreement shall have any force unless it is signed by a representative who is duly authorized by Yamaha.
10. Jurisdiction
This agreement shall be under the jurisdiction of the laws of Japan, and shall be interpreted according to those laws.
SWP1 Owner’s Manual |
7 |
Loading...
