ELC-02
ELCU-M02
MIDI Reference
Contents |
|
MIDI Data Format ...................................................... |
2 |
MIDI Implementation Chart ...................................... |
15 |
1 |
|
|
Reference |
EN |
|
|
|||
|
|
|
MIDI Data Format
MIDI Data Format
1. Channel Messages |
|
|
“” indicates “Not available.” |
|
|
|
|
|
|
1.1 EL Mode |
|
|
|
“” indicates “Available.” |
|
|
|
|
|
|
|
|
|
|
Code (Hexadecimal) |
Function |
Receive |
Transmit |
Remarks |
8n, nn, 00-7F |
Note Off |
1ch |
|
UK |
|
|
2ch |
|
LK |
|
|
3ch |
|
PEDAL |
|
|
(4ch)* |
|
LEAD 1 |
|
|
5-14ch |
|
XG |
|
|
15ch |
|
Keyboard Percussion |
|
|
|
|
|
9n, nn, 00 |
Note Off |
1ch |
(1ch)* |
UK |
9n, nn, 01-7F |
Note On |
2ch |
(2ch)* |
LK |
|
|
3ch |
(3ch)* |
PEDAL |
|
|
(4ch)* |
|
LEAD 1 |
|
|
5-14ch |
|
XG |
|
|
15ch |
|
Keyboard Percussion |
|
|
|
|
|
An, nn, 00-7F |
Polyphonic After Touch |
5-14ch |
|
XG |
|
|
|
|
|
Bn, 00, 00-7F |
Bank select |
5-14ch |
|
XG |
Bn, 20, 00-7F |
|
|
|
|
|
|
|
|
|
Bn, 01, 00-7F |
Modulation |
5-14ch |
|
XG |
|
|
|
|
|
Bn, 04, 00-7F |
2nd Expression |
16ch |
16ch |
Control |
|
|
(4ch)* |
(4ch)** |
LEAD 1 |
|
|
|
|
|
Bn, 05, 00-7F |
Portamento Time |
5-14ch |
|
XG |
|
|
|
|
|
Bn, 06, 00-7F |
Data Entry |
5-14ch |
|
XG |
Bn, 26, 00-7F |
|
|
|
|
|
|
|
|
|
Bn, 07, 00-7F |
Volume |
5-14ch |
|
XG |
|
|
|
|
|
Bn, 0A, 00-7F |
Pan |
5-14ch |
|
XG |
|
|
|
|
|
Bn, 0B, 00-7F |
Expression |
16ch |
(16ch)* |
Control |
|
|
5-14ch |
|
XG |
|
|
|
|
|
Bn, 40, 00-7F |
Hold |
5-14ch |
|
XG |
|
|
|
|
|
Bn, 41, 00-7F |
Portamento |
5-14ch |
|
XG |
|
|
|
|
|
Bn, 42, 00-7F |
Sostenuto |
5-14ch |
|
XG |
|
|
|
|
|
Bn, 43, 00-7F |
Soft Pedal |
5-14ch |
|
XG |
|
|
|
|
|
Bn, 47, 00-7F |
Resonance |
5-14ch |
|
XG |
|
|
|
|
|
Bn, 48, 00-7F |
Release Time |
5-14ch |
|
XG |
|
|
|
|
|
Bn, 49, 00-7F |
Attack Time |
5-14ch |
|
XG |
|
|
|
|
|
Bn, 4A, 00-7F |
Brightness |
5-14ch |
|
XG |
|
|
|
|
|
Bn, 4B, 00-7F |
Decay Time |
5-14ch |
|
XG |
|
|
|
|
|
Bn, 4C, 00-7F |
Vibrato Rate |
5-14ch |
|
XG |
|
|
|
|
|
Bn, 4D, 00-7F |
Vibrato Depth |
5-14ch |
|
XG |
|
|
|
|
|
Bn, 4E, 00-7F |
Vibrato Delay |
5-14ch |
|
XG |
|
|
|
|
|
Bn, 54, 00-7F |
Portamento Control |
5-14ch |
|
XG |
|
|
|
|
|
Bn, 5B, 00-7F |
Reverb Send Level |
5-14ch |
|
XG |
|
|
|
|
|
Bn, 5D, 00-7F |
Chorus Send Level |
5-14ch |
|
XG |
|
|
|
|
|
Bn, 5E, 00-7F |
Variation Effect Send Level |
5-14ch |
|
XG |
|
|
|
|
|
Bn, 60, 00-7F |
Data Increment |
5-14ch |
|
XG |
Bn, 61, 00-7F |
Data Decrement |
|
|
|
|
|
|
|
|
Bn, 62, 00-7F |
NRPN LSB |
5-14ch |
|
XG |
Bn, 63, 00-7F |
NRPN MSB |
|
|
|
|
|
|
|
|
Bn, 64, 00-7F |
RPN LSB |
5-14ch |
|
XG |
Bn, 65, 00-7F |
RPN MSB |
|
|
|
|
|
|
|
|
2ELC-02, ELCU-M02 MIDI Reference
|
|
|
|
MIDI Data Format |
|
|
|
|
|
Code (Hexadecimal) |
Function |
Receive |
Transmit |
Remarks |
Bn, 78, 00 |
All Sound Off |
5-14ch |
|
XG |
Bn, 79, 00 |
Reset All Controllers |
|
|
|
Bn, 7B, 00 |
All Note Off |
|
|
|
Bn, 7C, 00 |
Omni Off |
|
|
|
Bn, 7D, 00 |
Omni On |
|
|
|
Bn, 7E, 00 |
Mono |
|
|
|
Bn, 7F, 00 |
Poly |
|
|
|
|
|
|
|
|
Cn, nn |
Program Change |
5-14ch |
|
XG |
|
|
16ch |
16ch |
Control |
|
|
|
|
|
Dn, 00-7F |
After Touch |
1ch |
(1ch)* |
UK |
|
|
2ch |
(2ch)* |
LK |
|
|
3ch |
|
PEDAL |
|
|
(4ch)* |
|
LEAD 1 |
|
|
5-14ch |
|
XG |
|
|
|
|
|
En, 00-7F, 00-7F |
Pitch Bend |
1ch |
|
UK |
|
|
2ch |
|
LK |
|
|
(4ch)* |
|
LEAD 1 |
|
|
|
(1-16ch)* |
2nd Expression |
|
|
5-14ch |
|
XG |
|
|
|
|
|
* Can be changed in the MIDI settings.
** Can be output when assigned to channel 4.
1.2 XG Mode
Code (Hexadecimal) |
Function |
Receive |
Transmit |
Remarks |
8n, nn, 00-7F |
Note Off |
1-16ch |
|
|
|
|
|
|
|
9n, nn, 00 |
Note On |
|
(1ch)* |
UK |
9n, nn, 01-7F |
Note Off |
|
(2ch)* |
LK |
|
|
|
(3ch)* |
PEDAL |
|
|
1-16ch |
|
|
|
|
|
|
|
An, nn, 00-7F |
Polyphonic After Touch |
1-16ch |
|
|
|
|
|
|
|
Bn, 00, 00-7F |
Bank select |
1-16ch |
|
|
Bn, 20, 00-7F |
|
|
|
|
|
|
|
|
|
Bn, 01, 00-7F |
Modulation |
|
|
|
|
|
1-16ch |
|
|
|
|
|
|
|
Bn, 04, 00-7F |
2nd Expression |
|
16ch |
Control |
|
|
|
(4ch)** |
LEAD 1 |
|
|
|
|
|
Bn, 05, 00-7F |
Portamento Time |
1-16ch |
|
|
|
|
|
|
|
Bn, 06, 00-7F |
Data Entry |
1-16ch |
|
|
Bn, 26, 00-7F |
|
|
|
|
|
|
|
|
|
Bn, 07, 00-7F |
Volume |
1-16ch |
|
|
|
|
|
|
|
Bn, 0A, 00-7F |
Pan |
1-16ch |
|
|
|
|
|
|
|
Bn, 0B, 00-7F |
Expression |
|
(16ch)* |
Control |
|
|
1-16ch |
|
|
|
|
|
|
|
Bn, 40, 00-7F |
Hold |
1-16ch |
|
|
|
|
|
|
|
Bn, 41, 00-7F |
Portamento |
1-16ch |
|
|
|
|
|
|
|
Bn, 42, 00-7F |
Sostenuto |
1-16ch |
|
|
|
|
|
|
|
Bn, 43, 00-7F |
Soft Pedal |
1-16ch |
|
|
|
|
|
|
|
Bn, 47, 00-7F |
Resonance |
1-16ch |
|
|
|
|
|
|
|
Bn, 48, 00-7F |
Release Time |
1-16ch |
|
|
|
|
|
|
|
Bn, 49, 00-7F |
Attack Time |
1-16ch |
|
|
|
|
|
|
|
Bn, 4A, 00-7F |
Brightness |
1-16ch |
|
|
|
|
|
|
|
Bn, 4B, 00-7F |
Decay Time |
1-16ch |
|
|
|
|
|
|
|
Bn, 4C, 00-7F |
Vibrato Rate |
1-16ch |
|
|
|
|
|
|
|
Bn, 4D, 00-7F |
Vibrato Depth |
1-16ch |
|
|
|
|
|
|
|
Bn, 4E, 00-7F |
Vibrato Delay |
1-16ch |
|
|
|
|
|
|
|
Bn, 54, 00-7F |
Portamento Control |
1-16ch |
|
|
|
|
|
|
|
Bn, 5B, 00-7F |
Reverb Send Level |
1-16ch |
|
|
|
|
|
|
|
ELC-02, ELCU-M02 MIDI Reference |
3 |
MIDI Data Format
Code (Hexadecimal) |
Function |
Receive |
Transmit |
Remarks |
Bn, 5D, 00-7F |
Chorus Send Level |
1-16ch |
|
|
|
|
|
|
|
Bn, 5E, 00-7F |
Variation Effect Send Level |
1-16ch |
|
|
|
|
|
|
|
Bn, 60, 00-7F |
Data Increment |
1-16ch |
|
|
Bn, 61, 00-7F |
Data Decrement |
|
|
|
|
|
|
|
|
Bn, 62, 00-7F |
NRPN LSB |
1-16ch |
|
|
Bn, 63, 00-7F |
NRPN MSB |
|
|
|
|
|
|
|
|
Bn, 64, 00-7F |
RPN LSB |
1-16ch |
|
|
Bn, 65, 00-7F |
RPN MSB |
|
|
|
|
|
|
|
|
Bn, 78, 00 |
All Sound Off |
1-16ch |
|
|
Bn, 79, 00 |
Reset All Controllers |
|
|
|
Bn, 7B, 00 |
All Note Off |
|
|
|
Bn, 7C, 00 |
Omni Off |
|
|
|
Bn, 7D, 00 |
Omni On |
|
|
|
Bn, 7E, 00 |
Mono |
|
|
|
Bn, 7F, 00 |
Poly |
|
|
|
|
|
|
|
|
Cn, 00-7F |
Program Change |
|
16ch |
Control |
|
|
1-16ch |
|
|
|
|
|
|
|
Dn, 00-7F |
After Touch |
|
(1ch)* |
UK |
|
|
|
(2ch)* |
LK |
|
|
1-16ch |
|
|
|
|
|
|
|
En, 00-7F, 00-7F |
Pitch Bend |
|
(1-16ch)* |
2nd Expression |
|
|
1-16ch |
|
|
|
|
|
|
|
* Can be changed in the MIDI settings.
** Can be output when assigned to channel 4.
2. Realtime Messages
Code (Hexadecimal) |
Function |
Receive |
Transmit |
Remarks |
F8 |
Clock |
* |
|
|
|
|
|
|
|
FA |
Start |
|
|
|
|
|
|
|
|
FC |
Stop |
|
|
|
|
|
|
|
|
FE |
Active Sensing |
|
|
|
|
|
|
|
|
FF |
Reset |
|
|
|
|
|
|
|
|
* Received only when in the Ext. mode
4ELC-02, ELCU-M02 MIDI Reference
|
|
|
MIDI Data Format |
|
3. System Exclusive Messages |
|
|
|
|
3.1 Format |
|
|
|
|
Universal Realtime Messages |
|
|
|
|
|
|
|
|
|
Code (Hexadecimal) |
Message |
Receive |
|
Transmit |
F0, 7F, 7F, 04, 01, SS, TT, F7 |
GM2 Master Volume |
|
|
|
XN |
|
|
|
|
|
|
|
|
|
F0, 7F, 7F, 04, 03, SS, TT, F7 |
GM2 Master Fine Tuning |
|
|
|
XN |
|
|
|
|
|
|
|
|
|
F0, 7F, 7F, 04, 04, 00, TT, F7 |
GM2 Master Coarse Tuning |
|
|
|
XN |
|
|
|
|
|
|
|
|
|
F0, 7F, 7F, 04, 05, 01, 01, 01, 01, 01, PP, VV, ..., F7 |
GM2 Reverb Parameter |
|
|
|
XN |
|
|
|
|
|
|
|
|
|
F0, 7F, 7F, 04, 05, 01, 01, 01, 01, 02, PP, VV, ..., F7 |
GM2 Chorus Parameter |
|
|
|
XN |
|
|
|
|
|
|
|
|
|
F0, 7F, 7F, 09, 01, 0n, PP, VV, ..., F7 |
GM2 After Touch Parameter |
|
|
|
XN |
|
|
|
|
|
|
|
|
|
F0, 7F, 7F, 09, 03, 0n, CC, PP, VV, ..., F7 |
GM2 Control Change Parameter |
|
|
|
XN |
|
|
|
|
|
|
|
|
|
F0, 7F, 7F, 0A, 01, 0n, KK, CC, PP, VV, ..., F7 |
GM2 Key-Based Controller |
|
|
|
XN |
|
|
|
|
|
|
|
|
|
Universal Non-Realtime Messages |
|
|
|
|
|
|
|
|
|
Code (Hexadecimal) |
Message |
Receive |
|
Transmit |
F0, 7E, 7F, 09, 01, F7 |
GM ON |
|
|
|
XN |
|
|
|
|
|
|
|
|
|
F0, 7E, 7F, 09, 03, F7 |
GM2 ON |
|
|
|
XN |
|
|
|
|
|
|
|
|
|
F0, 7E, 7F, 09, 02, F7 |
GM OFF |
|
|
|
XN |
|
|
|
|
|
|
|
|
|
F0, 7E, 7F, 08, 08, JJ, GG, MM, ..data.., F7 |
GM2 Scale/Octave Tuning |
|
|
|
XN |
|
|
|
|
|
|
|
|
|
XG Native |
|
|
|
|
|
|
|
|
|
Code (Hexadecimal) |
Message |
Receive |
|
Transmit |
F0, 43, 1N, 4C, AH, AM, AL, ..data.., F7 |
XG Parameter Change |
|
|
|
|
|
|
|
|
F0, 43, 0N, 4C, BH, BL, AH, AM, AL, ..data.., cc, F7 |
XG Bulk Dump |
|
|
|
|
|
|
|
|
F0, 43, 1N, 27, 30, 00, 00, MM, LL, cc, F7 |
XG Master Tuning |
|
|
|
|
|
|
|
|
Clavinova Exclusive |
|
|
|
|
|
|
|
|
|
Code (Hexadecimal) |
Message |
Receive |
|
Transmit |
F0, 43, 73, 01, 02, F7 |
Request for Internal Sync. Mode |
|
|
|
03 |
Request for External Sync. Mode |
|
|
|
|
|
|
|
|
Message Exclusive |
|
|
|
|
|
|
|
|
|
Code (Hexadecimal) |
Message |
Receive |
|
Transmit |
F0, 43, 60, 7A, F7 |
Rhythm Start |
|
|
|
|
|
|
|
|
F0, 43, 60, 7D, F7 |
Rhythm Stop |
|
|
|
|
|
|
|
|
ELC-02, ELCU-M02 MIDI Reference |
5 |
