EPILATOR SED 3.7 F2
EPILATOR
Operating instructions
EPILIERER
Bedienungsanleitung
IAN 288645
ΣΥΣΚΕΥΉ ΑΠΟΤΡΊΧΩΣΉΣ
Οδηүίες χρήσης
Before reading, unfold the page containing the illustrations and familiarise
yourself with all functions of the device.
Πριν ξεκινήσετε την ανάγνωση, ανοίξτε τις δυο σελίδες με τις εικόνες και
εξοικειωθείτε με όλες τις λειτουργίες της συσκευής.
Klappen Sie vor dem Lesen die Seite mit den Abbildungen aus und machen
Sie sich anschließend mit allen Funktionen des Gerätes vertraut.
GB / IE / NI /CY Operating instructions Page 1
GR / CY Οδηүίες χρήσης Σελίδα 21
DE / AT / CH Bedienungsanleitung Seite 41
A
1
2
B
3
3
4
5
6
7
9 0
8
Table of Contents
Introduction .................................. 2
Copyright ............................................2
Intended Use ................................. 2
Items supplied ................................ 3
Operating Elements ............................ 4
Technical data ................................ 4
Safety instructions ............................. 6
Mains power operation ........................ 9
Battery operation ............................. 9
Tips and Tricks ...............................10
Epilation ....................................11
Cleaning and Care ............................ 13
Storage .................................... 15
Troubleshooting ............................. 15
Disposal .................................... 16
Ordering spare parts .........................17
Kompernass Handels GmbH warranty ........... 18
Service .............................................20
Importer ............................................20
SED 3.7 F2
GB│IE│NI│CY
│
1 ■
Introduction
Congratulations on the purchase of your new appliance.
You have clearly decided in favour of a quality product. These operating
instructions are a part of this product. They contain important information
in regard to safety, use and disposal. Before using the product,
familiarise yourself with all of these operating and safety instructions.
Use the product only as described and only for the specified areas
of application. In addition, pass these documents on, together with
the product, to any future owner.
Copyright
This documentation is copyright protected.
Any copying or reproduction, including as extracts, as well as the
reproduction of images, also in an altered state, is only permitted
with the written authorisation of the manufacturer.
Intended Use
This appliance is intended exclusively for the epilation of human hair
in domestic households. Do not use it for commercial purposes! This
appliance is not intended for any other use or for uses beyond those
mentioned.
Claims of any kind resulting from damage caused by improper use,
incompetent repairs, unauthorised modifications or the use of nonapproved spare parts will not be acknowledged.
The operator alone bears the risk.
■ 2 │ GB
│IE│NI│
CY
SED 3.7 F2
Items supplied
The appliance is supplied with the following components as standard:
■ Epilator
■ Mains adapter
■ Cleaning brush
■ Storage pouch
■ Operating Instructions
Extract all parts of the appliance from the carton and remove all
packaging material. Check the contents to ensure everything has
been supplied, and for signs of visible damage.
TIPS
► As delivered, the storage pouch is located under the plastic
shell containing the device itself. You must remove the
cardboard under the plastic shell in order to take the storage
pouch out.
► If the delivery is incomplete, or has been damaged due to
defective packaging or transportation, contact the Service
Hotline (see section Service).
SED 3.7 F2
GB│IE│NI│CY
│
3 ■
Operating Elements
Figure A:
Protective cap
Epilator head
Restraint fixtures for epilator head
Travel lock
Speed switch
Control lamps red/green
Socket for mains adapter
Figure B:
Mains power adapter
Storage pouch
Cleaning brush
Technical data
Mains adapter
Type ZDJ045100BS
Input voltage 100 - 240 V ~ (AC), 50/60 Hz
Power consumption 0.2 A Max.
Output voltage 4.5 V
Output current 1000 mA
Protection class
Polarity
■ 4 │ GB
│IE│NI│
CY
(DC)
II/
SED 3.7 F2
Switched-mode power
supply
Efficiency class 5
Short-circuit proof safety
transformer
Nominal ambient temperature (ta)
Protection class
Protected against ingress of solid
foreign objects with a diameter
40°C
IP20
of > 12.5 mm
Device
Input voltage 4.5 V
Power consumption 1000 mA
Batteries 3,7 V
SED 3.7 F2
700mAh Lithium ion battery
GB│IE│NI│CY
│
5 ■
Safety instructions
RISK OF ELECTRIC SHOCK
► Connect the appliance only to correctly
installed mains power sockets supplying a
current rating of 100 - 240 V ~ / 50/60 Hz.
► The power cable on this appliance can-
not be replaced. In the event of it being
damaged the whole appliance must be
disposed of.
► In the event of operational malfunction,
and for cleaning, always remove the plug
from the mains power socket.
► To disconnect the power cable, always
pull the plug itself from the mains power
socket, do not pull on the cable.
► Do not kink or crimp the power cable and
place it in such a way as to prevent anyone
from stepping on or tripping over it.
► Ensure that the power cable cannot
become wet or moist during operation.
Place it such that it cannot be squashed
or damaged.
■ 6 │ GB
│IE│NI│
CY
SED 3.7 F2
RISK OF ELECTRIC SHOCK
► To avoid risks, should the appliance be
damaged discontinue the use of it immediately.
► Do not use the appliance outdoors.
► Do not wrap the power cable around the
appliance and protect it from being damaged.
► NEVER grasp the appliance, power cable
or plug with wet hands.
► TAKE NOTE! Keep the appliance dry.
Never use the appliance near water,
particularly not near sinks, baths or
other vessels. The proximity of moisture
presents a danger, even when the appliance is switched off. After use, always
remove the plug from the mains power
socket. As additional protection, the installation of a faulty-current protection unit
with an activation power rating of not
more than 30 mA is recommended for
the power circuit in the bathroom.
Consult your electrician for advice.
SED 3.7 F2
GB│IE│NI│CY
│
7 ■
WARNING! RISK OF INJURY!
► Do not operate the appliance if it has sus-
tained a fall or is damaged. Arrange for the
appliance to be checked and/or repaired
by qualified technicians.
► Do not open the housing or attempt to
repair the appliance yourself. Should you
do so, appliance safety can no longer be
assured and the warranty will become void.
Permit only authorised technicians to repair
a defective appliance if repairs should be
necessary.
► Use the appliance only with the supplied
power adapter.
► Charge the appliance only with the supplied
power adapter.
► This appliance may be used by children
aged 8 over and by persons with reduced
physical, sensory or mental capabilities or
lack of experience and knowledge, provided
that they are under supervision or have been
told how to use the appliance safely and are
aware of the potential risks.
■ 8 │ GB
│IE│NI│
CY
SED 3.7 F2
WARNING! RISK OF INJURY!
► Children must not play with the appliance.
► Cleaning and user maintenance tasks must
not be carried out by children unless they
are supervised.
WARNING - PROPERTY DAMAGE!
Use the appliance only indoors.
Mains power operation
1) Insert the connector plug of the mains power adapter into the
socket for mains adapter on the appliance. Ensure that the
speed switch is set at “0”.
2) Connect the mains power adapter to a mains power socket.
The control lamp glows red to indicate that the charging
process is active.
The appliance is ready for immediate use.
Battery operation
1) Insert the connector plug of the mains power adapter into the
socket for mains adapter on the appliance. Ensure that the
speed switch is set at “0”.
2) Connect the mains power adapter to a mains power socket.
The control lamp glows red to indicate that the charging
process is active.
As soon as the control lamp glows green the appliance is fully
SED 3.7 F2
GB│IE│NI│CY
│
9 ■
charged and you can disconnect it from the mains power supply.
NOTICE
► For the initial charging, the appliance requires about
80 minutes to fully charge.
► First recharge the appliance when the control lamps indicate,
by alternately flashing red and green, that the battery charge
level is low.
Tips and Tricks
NOTICE
► Do not use the appliance if...
― You have a sunburn on the specific part of the body.
― Skin irritation or redness is extant.
― You have a skin disease such as, for example,
neurodermatitis.
― You have pimples, moles or warts on the specific parts of
the body.
― You have wounds, open sores or raised scars on the
specific parts of the body.
► First test the appliance on a small hidden location to establish
the skin compatibility.
■ The hairs should be between 0.3 cm and 0.5 cm long. Shorter
hairs are not gripped by the tweezers and plucking out longer
hairs is very painful. If needs be, shorten long hair.
■ The skin must be free of grease or cream residues. Otherwise, the
tweezers will stick/soil and the efficiency of the appliance will be
reduced.
■ The skin must be completely dry.
■ 10 │ GB
│IE│NI│
CY
SED 3.7 F2
■ The best time for epilation is in the evening after a shower. Then
the skin is somewhat softened, so that the hairs can be plucked
out easily. In addition, the skin can recover overnight, and any
skin reddening will recede.
■ Before epilation, treat the skin with a peeling or a massage glove.
This helps remove dead skin cells, ingrowing hairs are avoided,
and fine hairs stand proud. This enables the appliance to grip the
hairs better.
■ After epilation, nurture the skin with a moisturising lotion or
cream. Ideally, the cream will contain aloe vera or camomile
extracts to soothe and maintain the skin.
Epilation
When the appliance is charged and the body part to be epilated is
prepared:
1) Rub your hand once more against the growth direction of the
hairs to be removed. Through this the hairs will be raised so that
they can be better captured by the tweezers.
2) Remove the protective cap from the epilator head .
3) Press the travel lock and slide the speed switch upwards to
the desired speed level:
― Level 1: for sensitive areas (armpits and bikini line)
― Level 2: for legs
4) Hold the skin tight with one hand.
SED 3.7 F2
GB│IE│NI│CY
│
11 ■
5) Place the epilator perpendicular to the skin and, without exerting
any pressure, move it against the direction of the hair growth.
Thereby, the side with the speed switch must face towards
you. Do not make back and forth or circular movements.
Always start anew and pass over the body part to be epilated
several times, so that all of the hair is removed.
NOTICE
► It may be that the hair grows back after a few days. The
reason for this is that these hairs were too short to be
removed during the last epilation session.
6) When you are finished with the treatment, place the speed switch
to “0”.
7) Clean the epilator head as described in the section “Cleaning
and Care”.
8) Replace the protective cap on the epilator head .
■ 12 │ GB
│IE│NI│
CY
SED 3.7 F2
NOTICE
► If the epilator head is damaged, discontinue all further use!
To order a new epilator head , please contact the service
department (see chapter “Ordering spare parts”). Please have
the IAN number ready (see operating manual cover).
To replace the epilator head , please proceed as follows:
― Press the two restraint fixtures together and at the same
time pull the epilator head upwards.
― Press the new epilator head onto the appliance.
Ensure that the gears on the epilator head and on the
appliance mesh with each other. The epilator head must
audibly engage.
Cleaning and Care
RISK OF ELECTRIC SHOCK
► Before cleaning, disconnect the appliance from the mains
power adapter and the mains power adapter from the
main power supply.
WARNING - PROPERTY DAMAGE!
► NEVER submerse the appliance in water or other liquids!
■ After every use clean the epilator head with the supplied
cleaning brush to remove loose hairs.
■ Disinfect the epilator head regularly by spraying and cleaning
it with disinfectant spray.
■ To thoroughly clean the epilator head you can remove it from
the appliance:
SED 3.7 F2
GB│IE│NI│CY
│
13 ■
― Press the two restraint fixtures together and at the same
time pull the epilator head upwards.
― Clean the epilator head under running water and then
allow it to dry.
― Place the epilator head back onto the appliance. Ensure
that the gears on the epilator head and on the appliance
mesh with each other. The epilator head must audibly
engage.
■ Clean the appliance housing and the mains power adapter
with a moist cloth. If required, use some mild detergent on the cloth.
Ensure that the appliance is completely dry before the next use.
■ 14 │ GB
│IE│NI│
CY
SED 3.7 F2
Storage
■ Always protect the epilator head with the supplied protective
cap .
■ Store the appliance, the cleaning brush and the mains power
adapter in the storage pouch .
■ Store the appliance at a dry and dustfree location.
Troubleshooting
Problem Cause Solution
The appliance
does not function.
The appliance
only runs slowly.
The plucking of
the hairs is very
painful.
Not all hairs are
plucked.
The battery is
drained.
The appliance
is defective.
The battery is
drained.
The hairs may be
too long.
It is possible that the
hairs are too short.
You are working
too fast.
Recharge the
appliance.
In this case, contact
Customer Services.
Recharge the
appliance.
Shorten the hairs to
about 0.3 - 0.5 cm.
See also the section
"Tips and Tricks".
The hairs should
have a length of
0.3 - 0.5 cm.
Move the appliance
more slowly over your
skin.
SED 3.7 F2
GB│IE│NI│CY
│
15 ■
Disposal
Never dispose of the appliance in your normal
domestic waste. This product is subject
to the provisions of European Directive
2012/19/EU.
Dispose of the appliance through an approved disposal facility or
your municipal waste facility. Please observe the currently applicable
regulations. Please contact your waste disposal facility if you are in
any doubt.
NOTE
► The integrated rechargeable battery in this appliance cannot
be removed for disposal.
To prevent risks, the removal or replacement of the battery may
only be carried out by the manufacturer or the manufacturer’s
customer service department or a similarly qualified person.
When disposing of the appliance, indicate that the appliance
contains batteries.
The packaging is made of environmentally friendly materials
which you can dispose of at your local recycling centre.
Note the labelling on the packaging and separate the
packaging material components for disposal if necessary.
The packaging material is labelled with abbreviations (b)
and numbers (a) with the following meanings:
1–7: Plastics
20–22: Paper and cardboard
80–98: Composites
■ 16 │ GB
│IE│NI│
CY
SED 3.7 F2
Ordering spare parts
You can order the following replacement parts for product
SED 3.7 F2:
► 1 Epilator head
Order the replacement parts via the Service Hotline (see section
„Service“) or simply visit our website at www.kompernass.com.
NOTE
► Have the IAN number of the appliance ready (can be found on
the cover of these operating instructions) when you place your
order.
SED 3.7 F2
GB│IE│NI│CY
│
17 ■
Loading...
