ICE CREAM MAKER SECM 12 B5
ICE CREAM MAKER
Operating instructions
EISMASCHINE
Bedienungsanleitung
IAN 311099
IAN 330911_1907
ΠΑΓΩΤΟΜΗΧΑΝΗ
Οδηүίες χρήσης
Before reading, unfold the page containing the illustrations and familiarise yourself with all functions of
the device.
Πριν ξεκινήσετε την ανάγνωση, ανοίξτε τη σελίδα με τις εικόνες και εξοικειωθείτε με όλες τις λειτουργίες
της συσκευής.
Klappen Sie vor dem Lesen die Seite mit den Abbildungen aus und machen Sie sich anschließend mit allen
Funktionen des Gerätes vertraut.
GB / IE / NI / CY Operating instructions Page 1
GR / CY Οδηүίες χρήσης Σελίδα 11
DE / AT / CH Bedienungsanleitung Seite 21
Contents
Introduction ...........................................................2
Intended use ..........................................................2
Package contents. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
Appliance description ...................................................2
Technical data .........................................................2
Safety information .....................................................3
Assembly .............................................................5
Preparation ...........................................................5
Making ice cream ......................................................5
Cleaning and care ......................................................6
Storage ...............................................................6
Disposal ..............................................................7
Kompernass Handels GmbH warranty .....................................7
Service ..........................................................................8
Importer .........................................................................8
Recipes ...............................................................9
Vanilla ice cream ...................................................................9
Strawberry ice cream ...............................................................9
Banana ice cream ..................................................................9
Mango ice cream .................................................................10
Nut ice cream ....................................................................10
Kiwi sorbet ......................................................................10
SECM 12 B5
GB│IE│NI│CY
│
1 ■
Introduction
Congratulations on the purchase of your new
appliance.
You have selected a high-quality product.
The operating instructions are part of this product.
They contain important information about safety,
usage and disposal. Before using the product,
please familiarise yourself with all operating and
safety instructions. Use the product only as described and for the range of applications specified.
Please also pass these operating instructions on to
any future owner.
Intended use
This appliance is intended for making ice cream
and sorbet. This appliance is intended solely for
use in private households. Do not use it for commercial purposes.
Appliance description
ON/OFF switch
Motor unit
Drive shaft socket
Filler opening
Lid
Drive shaft
Ice scraper
Freezer bowl
Technical data
Nominal voltage: 220 – 240 V ∼
(alternating current), 50 Hz
Power consumption: 12 W
Protection class: II /
(double insulation)
Package contents
Ice cream maker
Operating instructions
All of the parts of this appliance that come
into contact with food are food-safe.
│IE│NI│
CY
SECM 12 B5■ 2 │ GB
Safety information
RISK OF ELECTRIC SHOCK
► Connect the appliance only to mains power sockets supplying a
mains power voltage of 220 – 240V∼, 50 Hz.
► Arrange for defective power plugs and/or cables to be replaced
as soon as possible by a qualified technician or by our Customer
Service Department to avoid the risk of injury.
► In event of operating malfunctions and before cleaning the
appliance, remove the power plug from the mains power socket.
► Always remove the power cable from the socket by pulling on the
plug, not on the power cable itself.
► Do not kink or crush the power cable, and route the cable so that it
cannot be stepped on or tripped over.
► Do not expose the appliance to humidity and do not use it outdoors.
If any liquid gets into the housing, disconnect the appliance from the
mains power socket immediately and have it repaired by a qualified
technician.
► Never handle the power cable or the power plug with wet hands.
► Do not open the appliance motor unit. This can lead to risks and
also invalidates the warranty.
► Disconnect the appliance from the mains power source immediately
after use. The appliance is completely free of electrical power only
when unplugged.
► The appliance is for indoor use only.
Never immerse the appliance motor unit in liquid and do not
allow any liquids to enter the motor unit casing.
SECM 12 B5
GB│IE│NI│CY
│
3 ■
WARNING! RISK OF INJURY!
► This appliance may be used by children aged 8years or over, if
they are supervised or have been told how to use the appliance
safely and are aware of the potential risks.
► Cleaning and user maintenance tasks must not be carried out by
children unless they are aged 8 years or over and are supervised.
► The appliance and its connecting cable must be kept away from
children younger than 8 years old.
► This appliance may be used by persons with limited physical,
sensory or mental capabilities or lack of experience and knowledge,
provided that they are under supervision or have been told how to
use the appliance safely and are aware of the potential risks.
► Do not allow children to use the appliance as a plaything.
► The appliance must always be disconnected from the mains when
left unsupervised and before assembly, disassembly or cleaning.
► Before changing accessories or additional parts that are in motion
during operation, the appliance must be switched off and
disconnected from mains power.
► There is a risk of injury if the appliance is misused! Use the
appliance only for its intended purpose.
│IE│NI│
CY
SECM 12 B5■ 4 │ GB
Assembly
Use the diagrams on the fold-out page as a guide
for assembly!
1) Remove all packaging materials and any
stickers from the appliance.
2) Clean the appliance as described in the
section "Cleaning and Care".
3) Place the
4) Insert the drive shaft into the corresponding
recess on the ice scraper until the ice
scraper clicks into place.
5) Insert the other end of the drive shaft into
the corresponding drive shaft socket .
6) Put the lid on the freezer bowl . Ensure
that the ▼ arrow on the lid is pointing to the
in either direction until the ▼ arrow on the
lid is pointing to one of the
the freezer bowl
7) Insert the plug into a mains power socket.
The appliance is now ready for use.
freezer bowl
symbol on the freezer bowl
on a flat surface.
.
. Turn the lid
symbols on
Preparation
♦ Place the freezer bowl in the deep freeze
for about 24 hours at a temperature of no more
than –18 °C.
TIPS
► Make sure that the freezer bowl is com-
pletely dry before you place it in the freezer.
► Place a plastic bag, for instance a freezer
bag, in the freezer bowl before freezing.
► Keep the freezer bowl upright in the
freezer.
► Store the fruit, milk and cream in the refrigera-
tor before processing. This ensures that they
are already cold and thus the ice cream
mixture will not require so long to cool down
the ingredients.
♦ Puree the fruit with a hand blender and mix all
the ingredients as described in the recipe.
♦ Allow the mixture to cool down for approx.
4 hours.
Making ice cream
CAUTION! PROPERTY DAMAGE!
► Start the appliance first and then add ingre-
dients. Otherwise, the ice mixture will freeze
onto the sides of the freezer bowl and
block the ice scraper . This will cause the
motor to overheat!
► Do not stop the appliance during processing!
Otherwise, the ice mixture will freeze onto
the sides of the freezer bowl and the ice
scraper will be blocked when you switch
the appliance back on. This will cause the
motor to overheat!
1) Remove the freezer bowl from the freezer.
2) Assemble the appliance as described in the
chapter titled "Assembly”.
3) Switch the appliance on by moving the On/
Off switch to the position I. The whisk
starts to turn.
4) Now, fill the prepared ice mixture into the
freezer bowl through the filling opening .
Ideally, use a bowl with a spout. Never add
more than 1000 ml. During processing, the
mixture increases in volume!
5) Allow the appliance to continue running until
you are satisfied with the consistency of the
mixture. The ice cream is ready after 40 minutes at the most.
6) Switch the appliance off at the On/Off switch
and pull the mains power plug out of the
socket.
7) Turn the lid until you can take it off.
8) Pull the ice scraper out of the ice cream.
If the ice cream sticks to it, scrape it off with a
plastic spoon or similar tool.
SECM 12 B5
GB│IE│NI│CY
│
5 ■
9) Remove the ice cream from the freezer bowl .
Use only plastic or wooden implements to do
this.
CAUTION! PROPERTY DAMAGE!
► Do not use metal utensils to remove the ice
cream from the freezer bowl . They can
scratch the freezer bowl .
Cleaning and care
RISK OF ELECTRIC SHOCK
► Always remove the plug from the mains
power socket before you clean the appliance.
Ensure you never submerse the motor
unit in liquid, and never allow liquid
to enter the motor unit housing .
CAUTION! PROPERTY DAMAGE!
► Do not use abrasive, chemical or caustic
cleaning agents to clean this appliance.
They can cause damage to the surfaces.
♦ If assembled, take the appliance apart to clean it.
– Turn the lid until you can take it off.
– Pull the drive shaft out of the drive shaft
socket .
– Disconnect the ice scraper from the drive
shaft .
– Rotate the lid together with the motor
unit . Gently press the two catches which
project through the lid inwards and push
them out of the lid at the same time. The
motor unit will now detach from the lid .
♦ Clean the motor unit with a moist cloth after
every use. If there is heavy soiling, add mild
detergent to the cloth. Rinse detergent residues
off with clear water. Ensure that there are no
detergent residues on the appliance, and that the
appliance is completely dry before renewed use.
♦ Allow the freezer bowl to warm up to room
temperature before cleaning it.
Wash the freezer bowl , ice scraper , the
drive shaft and the lid in lukewarm water
with a little washing-up liquid. Afterwards, rinse
these parts with plenty of clean water to remove
all detergent residues.
NOTE
You can also wash the ice scraper ,
the drive shaft and the lid in your
dishwasher. Place the parts in the upper
dishwasher basket if possible and do not jam
them in.
♦ Ensure that all parts are completely dry before
re-use.
Storage
♦ Always clean the appliance thoroughly before
storing.
♦ Store the appliance in a clean, dry location.
│IE│NI│
CY
SECM 12 B5■ 6 │ GB
Disposal
Never dispose of the appliance
in your normal domestic waste.
This product is subject to the
provisions of European
Directive 2012/19/EU.
Dispose of the appliance via an approved waste
disposal company or your municipal waste
disposal facility. Please comply with all applicable
regulations. Please contact your waste disposal
centre if you are in any doubt.
Your local community or municipal
authorities can provide information
on how to dispose of the worn-out
product.
The packaging for this product is made
from environmentally friendly material
and can be disposed of at your local
recycling plant.
Note the labelling on the packaging
and separate the packaging material
components for disposal if necessary.
The packaging material is labelled
with abbreviations (a) and numbers (b) with the
following meanings: 1–7: Plastics, 20–22: Paper
and cardboard, 80–98: Composites.
Kompernass Handels GmbH
warranty
Dear Customer,
This appliance has a 3-year warranty valid from
the date of purchase. If this product has any faults,
you, the buyer, have certain statutory rights. Your
statutory rights are not restricted in any way by the
warranty described below.
Warranty conditions
The warranty period starts on the date of purchase.
Please keep your receipt in a safe place. This will
be required as proof of purchase.
If any material or manufacturing fault occurs within
three years of the date of purchase of the product,
we will either repair or replace the product for you
or refund the purchase price (at our discretion).
This warranty service requires that you present the
defective appliance and the proof of purchase (receipt) within the three-year warranty period, along
with a brief written description of the fault and of
when it occurred.
If the defect is covered by the warranty, your product will either be repaired or replaced by us. The
repair or replacement of a product does not signify
the beginning of a new warranty period.
Warranty period and statutory claims for
defects
The warranty period is not prolonged by repairs
effected under the warranty. This also applies to
replaced and repaired components. Any damage
and defects present at the time of purchase must
be reported immediately after unpacking. Repairs
carried out after expiry of the warranty period shall
be subject to a fee.
SECM 12 B5
Scope of the warranty
This appliance has been manufactured in accordance with strict quality guidelines and inspected
meticulously prior to delivery.
GB│IE│NI│CY
│
7 ■
The warranty covers material faults or production
faults. The warranty does not extend to product
parts subject to normal wear and tear or to fragile
parts which could be considered as consumable
parts such as switches, batteries or parts made of
glass.
The warranty does not apply if the product has
been damaged, improperly used or improperly maintained. The directions in the operating
instructions for the product regarding proper use
of the product are to be strictly followed. Uses
and actions that are discouraged in the operating
instructions or which are warned against must be
avoided.
This product is intended solely for private use and
not for commercial purposes. The warranty shall
be deemed void in cases of misuse or improper
handling, use of force and modifications / repairs
which have not been carried out by one of our
authorised Service centres.
Warranty claim procedure
To ensure quick processing of your case, please
observe the following instructions:
■ Please have the till receipt and the item number
(e.g.IAN12345) available as proof of purchase.
■ You will find the item number on the type plate
on the product, an engraving on the product,
on the front page of the operating instructions
(below left) or on the sticker on the rear or bottom of the product.
■ If functional or other defects occur, please
contact the service department listed either by
telephone or by e-mail.
■ You can return a defective product to us free of
charge to the service address that will be provided to you. Ensure that you enclose the proof
of purchase (till receipt) and information about
what the defect is and when it occurred.
You can download these instructions
along with many other manuals,
product videos and installation
software at www.lidl-service.com.
This QR code will take you directly to
the Lidl service page (www.lidl-service.com) where
you can open your operating instructions by entering the item number (IAN) 123456.
Service
Service Great Britain
Tel.: 0800 404 7657
E-Mail: kompernass@lidl.co.uk
Service Ireland
Tel.: 1890 930 034
(0,08 EUR/Min., (peak))
(0,06 EUR/Min., (off peak))
E-Mail: kompernass@lidl.ie
CY
Service Cyprus
Tel.: 8009 4409
E-Mail: kompernass@lidl.com.cy
IAN 330911_1907
Importer
Please note that the following address is not the
service address. Please use the service address
provided in the operating instructions.
KOMPERNASS HANDELS GMBH
BURGSTRASSE 21
44867 BOCHUM
GERMANY
www.kompernass.com
│IE│NI│
CY
SECM 12 B5■ 8 │ GB
Loading...
