Schwinn 230 User Manual

230

Manual en Español Latino Americano:	ASSEMBLY MANUAL / OWNER’S MANUAL
http://www.schwinnfitness.com

TABLE OF CONTENTS

Important Safety Instructions	3
Safety Warning Labels / Serial Number	5
Specifications	6
Before Assembly	6
Parts	7
Hardware	8
Tools	8
Assembly	9
Moving the Machine	19
Leveling the Machine	20
Features	21
Console Features	22
Operations	27
Adjustments	27

Power Up / Idle Mode	27
Initial Setup	28
Quick Start Program	28
User Profiles	28
Profile Programs	30
Pausing or Stopping	33
Results / Cool Down Mode	33
GOAL TRACK Statistics	33
Console Service Mode	35
Maintenance	36
Maintenance Parts	37
Troubleshooting	39
Warranty	41

To validate warranty support, keep the original proof of purchase and record the following information:

Serial Number __________________________

Date of Purchase ____________________

To register your product warranty , go to: www.SchwinnFitness.com/register Or call 1 (800) 605–3369.

If you have questions or problems with your product, please call 1 (800) NAUTILUS (628–8458) Or go to: www.SchwinnFitness.com

Nautilus, Inc., (800) NAUTILUS / [phone], www.NautilusInc.com - Customer Service: North America [phone], [e-mail] | outside U.S. +01-360-859-5180, [e-mail] | © 2016 Nautilus, Inc. | ® indicates trademarks registered in the United States. These marks may be registered in other nations or otherwise protected by common law. Schwinn, the Schwinn Quality logo, Schwinn 230, Schwinn Connect, Bowflex, Nautilus, and Universal are trademarks owned by or licensed to Nautilus, Inc. MyFitnessPal® is a trademark of its owner.

2

IMPORTANT SAFETY INSTRUCTIONS

!This icon means a potentially hazardous situation which, if not avoided, could result in death or serious injury.

Obey the following warnings:

!Read and understand all warnings on this machine. Carefully read and understand the Assembly instructions.

•Keep bystanders and children away from the product you are assembling at all times.

•Do not connect power supply to the machine until instructed to do so.

•Do not assemble this machine outdoors or in a wet or moist location.

•Make sure assembly is done in an appropriate work space away from foot traffic and exposure to bystanders.

•Some components of the machine can be heavy or awkward. Use a second person when doing the assembly steps involving these parts. Do not do steps that involve heavy lifting or awkward movements on your own.

•Set up this machine on a solid, level, horizontal surface.

•Do not try to change the design or functionality of this machine. This could compromise the safety of this machine and will void the warranty.

•If replacement parts are necessary, use only genuine Nautilus replacement parts and hardware. Failure to use genuine replacement parts can cause a risk to users, keep the machine from operating correctly and void the warranty.

•Do not use until the machine has been fully assembled and inspected for correct performance in accordance with the Manual.

•Read and understand the complete Manual supplied with this machine before first use. Keep the Manual for future reference.

•Do all assembly steps in the sequence given. Incorrect assembly can lead to injury or incorrect function.

•This product contains magnets. Magnetic fields can interfere with the normal use of certain medical devices at a close range. Users may come into proximity of the magnets in the assembly, maintenance, and/or use of the

product. Given the obvious importance of these devices, such as a pacemaker, it is important that you consult with your medical provider in connection with the use of this equipment. Please consult the “Safety Warning Labels and Serial Number” section to determine the location of the magnets on this product.

Before using this equipment, obey the following warnings:

!Read and understand the complete Manual. Keep the Manual for future reference.

Read and understand all warnings on this machine. If at any time the Warning labels become loose, unreadable or dislodged, contact Nautilus Customer Service for replacement labels.

•Children must not be let on or near to this machine. Moving parts and other features of the machine can be dangerous to children.

•Not intended for use by anyone under 14 years of age.

•Consult a physician before you start an exercise program. Stop exercising if you feel pain or tightness in your chest, become short of breath, or feel faint. Contact your doctor before you use the machine again. Use the values calculated or measured by the machine’s computer for reference purposes only.

•Before each use, examine this machine for loose parts or signs of wear. Do not use if found in this condition.

Monitor the Seat, Pedals, and Crank Arms closely. Contact Nautilus Customer Service for repair information.

•Maximum user weight limit: 300 lbs. (136 kg). Do not use if you are over this weight.

•This machine is for home use only.

•Do not wear loose clothing or jewelry. This machine contains moving parts. Do not put fingers or other objects into moving parts of the exercise equipment.

3

•Set up and operate this machine on a solid, level, horizontal surface.

•Make the Pedals stable before you step on them. Use caution when you step on and off the machine.

•Disconnect all power before servicing this machine.

•Do not operate this machine outdoors or in moist or wet locations. Keep the foot pedals clean and dry.

•Keep at least 24” (0.6 m) on each side of the machine clear. This is the recommended safe distance for access and passage around and emergency dismounts from the machine. Keep third parties out of this space when machine is in use.

•Do not over exert yourself during exercise. Operate the machine in the manner described in this manual.

•Correctly adjust and safely engage all Positional Adjustment Devices. Make sure that the Adjustment Devices do not hit the user.

•Exercise on this machine requires coordination and balance. Be sure to anticipate that changes in speed and resistance level can occur during workouts, and be attentive in order to avoid loss of balance and possible injury.

•Prior to use, read and understand the owner’s manual. The appliance is not to be used by persons with functional limitations and impairments, reduced physical, sensory or mental capabilities, or lack of experience and knowledge.

4

SAFETY WARNING LABELS AND SERIAL NUMBER

WARNING!

•Injury or death is possible if caution is not used while using this machine.

•Keep children and pets away.

•Read and follow all warnings on this machine.

•Refer to the Owner’s Manual for additional warnings and safety information.

•The heart rate displayed is an approximation and should be used for reference only.

•Not intended for use by anyone under 14 years of age.

•The maximum user weight for this machine is 300 lbs

( 136kg ).

•This machine is for home use only.

WARNING!

• Keep hands and feet away.

Serial Number

Product specification

FCC Compliance

!Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment.

The machine and power supply comply with part 15 of the FCC rules. Operation is subject to the following two conditions:

(1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

Note: This machine and power supply have been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.

However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

•Reorient or relocate the receiving antenna.

•Increase the separation between the equipment and receiver.

•Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

•Consult the dealer or an experienced radio/TV technician for help.

5

SPECIFICATIONS

		Maximum User Weight:	300 lbs. (136 kg)
	49.9”	Power Requirements:
		Operational Voltage:	9VDC
	(126.8 cm)
		Operating Current:	1500 mA

Regulatory Approvals:

AC Power Adapter: UL listed, CSA certified (or equivalent),

Rated 120V 60Hz Input, 9VDC, 1500mA

Output. Class 2.

64”

(162.5 cm)

27.7” (70.3 cm)

WARNING: This product, its packaging, and components contain chemicals known to the State of California to cause cancer, birth defects, or reproductive harm. This Notice is provided in accordance with California’s Proposition 65. If you would like additional information, please refer to our website at www.nautilus.com/prop65.

Before Assembly

Select the area where you are going to set up and operate your machine. For safe operation, the location must be on a hard, level surface. Allow a workout area of a minimum 74.6” x 110.5” (189.5 cm x 280.5 cm).

Basic Assembly Tips

Follow these basic points when you assemble your machine:

•Read and understand the “Important Safety Instructions” before assembly.

•Collect all the pieces necessary for each assembly step.

•Using the recommended wrenches, turn the bolts and nuts to the right (clockwise) to tighten, and the left (counterclockwise) to loosen, unless instructed otherwise.

•When attaching 2 pieces, lightly lift and look through the bolt holes to help insert the bolt through the holes.

•The assembly can require 2 people.

6

PARTS

17

	1
	5	3
16	4	2
	6

15 14

7

13

8

9	10

12

11

Item	Qty	Description	Item	Qty	Description
1	1	Console	10	1	AC Adapter
2	1	Water Bottle Holder	11	1	Left Pedal
3	1	Seat Back	12	1	Front Stabilizer
4	1	Cover	13	1	Right Pedal
5	1	Seat Frame Assembly	14	1	Upper Shroud
6	1	Seat Bottom	15	1	Shroud Cap
7	1	Seat Adjustment Handle	16	1	Console Mast
8	1	Rear Stabilizer	17	1	MP3 Cord
9	1	Frame

7

HARDWARE / TOOLS

A

B

C

D

E

F

G

H

I

J

Item	Qty	Description	Item	Qty	Description
A	8	Button Head Hex Screw, M8x20	F	2	Phillips Head Screw, M5x12
B	10	Button Head Hex Screw, M6x12	G	14	Lock Washer, M6
C	4	Flat Washer, M8	H	4	Curved Washer, M6
D	8	Lock Washer, M8	I	4	Phillips Head Screw, M6x25
E	10	Flat Washer, M6	J	4	Curved Washer, M8

Note: Select pieces of Hardware have been provided as spares on the Hardware Card. Be aware that there may be remaining Hardware after the proper assembly of your machine.

Tools

Included Not Included

(recommended)

4 mm

6 mm

8

1. Attach Stabilizers to Frame

Note: Hardware is pre-installed and not on the Hardware Card. *

6mm

X2

*

*

*

9

12

ASSEMBLY

6mm

X2

*

*

*

8

9

2. Attach the Seat Frame Assembly to the Seat Rail

NOTICE: Do not crimp the Heart Rate Cable. Once all hardware has been inserted, be sure to fully tighten it.

6mm	X4

A

D

C

5

X2

B G E

4mm

10

3. Attach Seat Pads to Seat Frame Assembly

3

6

X8

E

G

B

4mm

X4

H

G

I

#2

11

4. Attach Cover to Frame Assembly

4

12

5. Attach Seat Adjustment Handle to Frame Assembly

7

13
