ASSEMBLY MANUAL / OWNER’S MANUAL |
TABLE OF CONTENTS
Important Safety Instructions |
3 |
Operations |
19 |
Safety Warning Labels / Serial Number |
5 |
Adjustments |
19 |
Specifications |
6 |
Power Up |
20 |
Before Assembly |
6 |
Edit Mode |
21 |
Parts |
7 |
Changing Unit Measures (English Imperial/Metric) |
21 |
Hardware |
8 |
Maintenance |
22 |
Tools |
8 |
Replacing the Console Batteries |
23 |
Assembly |
9 |
Checking the Belt Tension |
23 |
Installing Shoe Clips (Cleats) |
13 |
Maintenance Parts |
24 |
Leveling the Machine |
14 |
Troubleshooting |
25 |
Moving and Storing the Machine |
14 |
Warranty |
27 |
Features |
15 |
|
|
Emergency Stop |
16 |
|
|
Console Features |
16 |
|
|
Remote Heart Rate Monitor |
17 |
|
|
Shoe Clips (Cleats) |
18 |
|
|
To validate warranty support, keep the original proof of purchase and record the following information:
Serial Number __________________________
Date of Purchase ____________________
To register your product warranty , go to: www.SchwinnFitness.com/register Or call 1 (800) 605–3369.
If you have questions or problems with your product, please call 1 (800) NAUTILUS (628–8458).
Nautilus, Inc., (800) NAUTILUS / (800) 628-8458, www.NautilusInc.com - Customer Service: North America (800) 605-3369, csnls@nautilus.com | outside U.S. www.nautilusinternational.com | Printed in China | © 2017 Nautilus, Inc. | ® indicates trademarks registered in the United States. These marks may be registered in other nations or otherwise protected by common law. Schwinn, the Schwinn Quality logo, IC3, Nautilus, Bowflex, and Universal are trademarks owned by or licensed to Nautilus, Inc. Polar® and
OwnCode® are registered trademarks of their owner.
2
IMPORTANT SAFETY INSTRUCTIONS
When using an electrical appliance, basic precautions should always be followed, including the following:
This icon means a potentially hazardous situation which, if not avoided, could result in death or serious injury.
Obey the following warnings:
Read and understand all warnings on this machine.
Carefully read and understand the Assembly instructions. Read and understand the complete Manual. Keep the Manual for future reference.
•Keep bystanders and children away from the product you are assembling at all times.
•Do not install the batteries into the machine until the time specified in the assembly manual.
•Do not assemble this machine outdoors or in a wet or moist location.
•Make sure assembly is done in an appropriate work space away from foot traffic and exposure to bystanders.
•Some components of the machine can be heavy or awkward. Use a second person when doing the assembly steps involving these parts. Do not do steps that involve heavy lifting or awkward movements on your own.
•Set up this machine on a solid, level, horizontal surface.
•Do not try to change the design or functionality of this machine. This could compromise the safety of this machine and will void the warranty.
•If replacement parts are necessary use only genuine replacement parts and hardware supplied by Nautilus. Failure to use genuine replacement parts can cause a risk to users, keep the machine from operating correctly and void the warranty.
•Do not use or put the machine into service until the machine has been fully assembled and inspected for correct performance in accordance with the Manual.
•Read and understand the complete Manual supplied with this machine before first use. Keep the Manual for future reference.
•Do all assembly steps in the sequence given. Incorrect assembly can lead to injury or incorrect function.
Before using this equipment, obey the following warnings:
Read and understand the complete Manual. Keep the Manual for future reference.
Read and understand all warnings on this machine. If at any time the Warning stickers become loose, unreadable or dislodged, contact Nautilus Customer Service for replacement stickers.
•Children must not be let on or near to this machine. Moving parts and other features of the machine can be dangerous to children.
•Not intended for use by anyone under 14 years of age.
•Consult a physician before you start an exercise program. Stop exercising if you feel pain or tightness in your chest, become short of breath, or feel faint. Contact your doctor before you use the machine again. Use the values calculated or measured by the machine’s computer for reference purposes only.
•Before each use, examine this machine for loose parts or signs of wear. Do not use if found in this condition. Monitor the Seat, Pedals and Crank Arms closely. Contact Nautilus Customer Service for repair information.
•Maximum user weight limit: 300 lbs. (136 kg). Do not use if you are over this weight.
•This machine is for home use only.
•Do not wear loose clothing or jewelry. This machine contains moving parts. Do not put fingers or other objects into moving parts of the exercise equipment.
•Set up and operate this machine on a solid, level, horizontal surface.
•Make the Pedals stable before you step on them. Use caution when you step on and off the machine.
•Disconnect all power before servicing this machine.
3
•Do not operate this machine outdoors or in moist or wet locations. Keep the Pedals clean and dry.
•Keep at least 24” (0.6 m) on each side of the machine clear. This is the recommended safe distance for access and passage around and emergency dismounts from the machine. Keep third parties out of this space when machine is in use.
•Do not over exert yourself during exercise. Operate the machine in the manner described in this manual.
•Perform all regular and periodic maintenance procedures recommended in the Owner’s Manual.
•Do not drop or put objects into any opening of the machine.
•Correctly adjust and safely engage all Positional Adjustment Devices. Make sure that the Adjustment Devices do not hit the user.
•Exercise on this machine requires coordination and balance. Be sure to anticipate that changes in speed and resistance level can occur during workouts, and be attentive in order to avoid loss of balance and possible injury.
•Keep batteries away from heat source and hot surfaces.
•Do not mix old and new batteries. Remove exhausted batteries and dispose of them safely.
•Do not mix alkaline, standard (carbon-zinc), or rechargeable (Ni-Cd, Ni-MH, etc) batteries.
•Do not short-circuit the supply terminals on the batteries.
•This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety.
•Reduce the pace to slow the Pedals to a stop. Do not dismount the bike until the Pedals have come to a complete stop. Be aware that the moving Pedals can strike the backs of the legs.
4
SAFETY WARNING LABELS AND SERIAL NUMBER
WARNING!
• Injury or death is possible if caution is not used while using this machine.
• Keep children and pets away.
• Read and follow all warnings on this machine.
• Refer to the Owner’s Manual for additional warnings and safety information.
• The heart rate displayed is an approximation and should be used for reference only.
• Not intended for use by anyone under 14 years of age.
• The maximum user weight for this machine is 300 lbs (136 kg.).
• This machine is for home use only.
• Consult a physician prior to using any exercise equipment.
Serial number
Product specification
FCC Compliance
!Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment.
This product complies with part 15 of the FCC rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
Note: This product has been tested and found to comply with the limits for a Class B digital device, pursuant to CFR47 Part 15 Subpart B of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. In the unlikely event that this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:
•Reorient or relocate the receiving antenna.
•Increase the separation between the equipment and receiver.
•Consult the dealer or an experienced radio/TV technician for help.
5
SPECIFICATIONS
Specifications
Maximum User Weight: |
300 lbs. (136 kg) |
Machine Weight: |
101 lbs. (46 kg) |
Dimensions: |
48.7” x 21.2” x 49.8” (123.7cm x 53.9cm x 126.6cm) |
Power Requirements: |
2 AA Batteries (SUM3) |
Operating Voltage: |
3VDC |
WARNING! This product, its packaging, and components contain chemicals known to the State of California to cause cancer, birth defects, or reproductive harm. This Notice is provided in accordance with California’s Proposition 65. If you would like additional information, please refer to our website at www.nautilus.com/prop65.
Before Assembly
Select the area where you are going to set up and operate your machine. For safe operation, the location must be on a hard, level surface. Allow a workout area of a minimum 97” x 69” (2.5 m x 1.8 m).
Basic Assembly Tips
Follow these basic points when you assemble your machine:
•Read and understand the “Important Safety Instructions” before assembly.
•Collect all the pieces necessary for each assembly step.
•Using the recommended wrenches, turn the bolts and nuts to the right (clockwise) to tighten, and the left (counterclockwise) to loosen, unless instructed otherwise.
•When attaching 2 pieces, carefully lift and look through the bolt holes to help insert the bolt through the holes.
•The assembly requires 2 people.
6
PARTS
10 |
6 |
9 |
|
||
|
|
11
5
4
1
12
2 8
7
3
Item |
Qty |
Description |
Item |
Qty |
Description |
1 |
1 |
Main Frame |
7 |
1 |
Pedal, Right |
2 |
1 |
Stabilizer, Front |
8 |
1 |
Pedal, Left |
3 |
1 |
Stabilizer, Rear |
9 |
1 |
Water Bottle Holder |
4 |
1 |
Seat Post |
10 |
1 |
Console |
5 |
1 |
Seat |
11 |
2 |
AA-size Batteries |
6 |
1 |
Handlebar |
12 |
2 |
Shoe Clips (Cleats) |
7
HARDWARE / TOOLS
A B C
Item |
Qty |
Description |
A |
2 |
Adjustment Handle, Handlebar / Seat |
B |
2 |
Flat Washer, M10 Wide |
C |
1 |
Adjustment Handle, Handlebar Post |
Tools
Included
6 mm
#2
13 mm
14 mm
15 mm
8
ASSEMBLY
1. Attach Stabilizers to Main Frame
Note: The hardware (*) is pre-installed and not in the Hardware Bag. If a tube is pre-installed in the stabilizer bracket, remove and set it safely aside.
1
* X4
*
*
3
2
2. Attach Seat to Seat Post and Frame
NOTICE: Make sure the adjustment knob (4a) engages the holes in the Seat Post.
5
|
4 |
B |
4a |
|
|
A |
|
9
