NETGEAR Wireless-N
150 USB Adapter
WNA1000 User Manual
NETGEAR, Inc.
350 E. Plumeria Drive
San Jose, CA 95134 USA
202-10575-01 August 2009
Technical Support
Please refer to the support information card that shipped with your product. By registering your product at http://www.netgear.com/register, we can provide you with faster expert technical support and timely notices of product and software upgrades.
NETGEAR, INC. Support Information
Phone: 1-888-NETGEAR, for US & Canada only. For other countries, see your Support information card. E-mail: support@netgear.com
North American NETGEAR website: http://www.netgear.com
Trademarks
NETGEAR, the NETGEAR logo, ProSafe, and Auto Uplink are trademarks or registered trademarks of NETGEAR, Inc. Microsoft, Windows, Windows NT and Vista are registered trademarks of Microsoft Corporation.Other brand and product names are registered trademarks or trademarks of their respective holders.
Statement of Conditions
In the interest of improving internal design, operational function, and/or reliability, NETGEAR reserves the right to make changes to the products described in this document without notice.
NETGEAR does not assume any liability that may occur due to the use or application of the product(s) or circuit layout(s) described herein.
Maximum Wireless Signal Rate Derived from IEEE Standard 802.11 Specifications
Actual data throughput will vary. Network conditions and environmental factors, including volume of network traffic, building materials and construction, and network overhead, lower actual data throughput rate.
Safety and Regulatory Notices
FCC Statement
The WNA1000 has been tested and complies with the specifications for a Class B digital device, pursuant to Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1)This device may not cause harmful interference, and
(2)This device must accept any interference received, including interference that may cause undesired operation.
These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used according to the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which is found by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:
•Reorient or relocate the receiving antenna
•Increase the separation between the equipment or devices
•Connect the equipment to an outlet other than the receiver’s
•Consult a dealer or an experienced radio/TV technician for assistance
ii
v1.0, August 2009
FCC Caution: Any change or modification to the product not expressly approved by Netgear could void the user’s authority to operate the device.
FCC RF Radiation Exposure and SAR Statements
SAR Statement
The NETGEAR WNA1000 has been tested for body-worn Specific Absorption Rate (SAR) compliance. The FCC has established detailed SAR requirements and has established that these requirements have been met while installed in host notebook computer.
RF Exposure Information
The radio module has been evaluated under FCC Bulletin OET 65C (01-01) and found to be compliant to the requirements as set forth in CFR 47 Sections, 2.1093, and 15.247 (b) (4) addressing RF Exposure from radio frequency devices. This model meets the applicable government requirements for exposure to radio frequency waves. The highest SAR level measured for this device was 1.380 W/kg.
Canadian Department of Communications Industry Canada (IC) Notice
This Class B digital apparatus complies with Canadian ICES-003 and RSS-210. Cet appareil numérique de la classe B est conforme à la norme NMB-003 et CNR-210 du Canada.
Industry Canada Statement
This device complies with RSS-210 of the Industry Canada Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
IMPORTANT NOTE: Radiation Exposure Statement
This equipment complies with IC radiation exposure limits set forth for an uncontrolled environment. End users must follow the specific operating instructions for satisfying RF exposure compliance. To maintain compliance with IC RF exposure compliance requirements, please follow operation instruction as documented in this manual.
Europe - EU Declaration of Conformity
A printed copy of the EU Declaration of Conformity certificate for this product is provided in the WNA1000 product package.
Èesky |
NETGEAR, Inc. tímto prohlašuje, že tento NETGEAR Wireless-N 150 USB Adapter |
|
[Czech] |
WNA1000 je ve shodì se základními požadavky a dalšími pøíslušnými ustanoveními |
|
|
smìrnice 1999/5/ES. |
|
Dansk |
Undertegnede NETGEAR, Inc. erklærer herved, at følgende udstyr NETGEAR Wireless- |
|
[Danish] |
N 150 USB Adapter WNA1000 overholder de væsentlige krav og øvrige relevante krav i |
|
|
direktiv 1999/5/EF. |
|
|
|
|
|
|
|
|
iii |
v1.0, August 2009
Deutsch |
Hiermit erklärt NETGEAR, Inc., dass sich das Gerät NETGEAR Wireless-N 150 USB |
[German] |
Adapter WNA1000 in Übereinstimmung mit den grundlegenden Anforderungen und den |
|
übrigen einschlägigen Bestimmungen der Richtlinie 1999/5/EG befindet. |
Eesti |
Käesolevaga kinnitab NETGEAR, Inc. seadme NETGEAR Wireless-N 150 USB Adapter |
[Estonian] |
WNA1000 vastavust direktiivi 1999/5/EÜ põhinõuetele ja nimetatud direktiivist |
|
tulenevatele teistele asjakohastele sätetele. |
|
|
English |
Hereby, NETGEAR, Inc., declares that this NETGEAR Wireless-N 150 USB Adapter |
|
WNA1000 is in compliance with the essential requirements and other relevant provisions |
|
of Directive 1999/5/EC. |
|
|
Español |
Por medio de la presente NETGEAR, Inc. declara que el NETGEAR Wireless-N 150 |
[Spanish] |
USB Adapter WNA1000 cumple con los requisitos esenciales y cualesquiera otras |
|
disposiciones aplicables o exigibles de la Directiva 1999/5/CE. |
Ελληνική |
ΜΕ ΤΗΝ ΠΑΡΟΥΣΑ NETGEAR, Inc. ΔΗΛΩΝΕΙ ΟΤΙ NETGEAR Wireless-N 150 USB |
[Greek] |
Adapter WNA1000 ΣΥΜΜΟΡΦΩΝΕΤΑΙ ΠΡΟΣ ΤΙΣ ΟΥΣΙΩΔΕΙΣ ΑΠΑΙΤΗΣΕΙΣ ΚΑΙ ΤΙΣ |
|
ΛΟΙΠΕΣ ΣΧΕΤΙΚΕΣ ΔΙΑΤΑΞΕΙΣ ΤΗΣ ΟΔΗΓΙΑΣ 1999/5/ΕΚ. |
|
|
Français |
Par la présente NETGEAR, Inc. déclare que l'appareil NETGEAR Wireless-N 150 USB |
[French] |
Adapter WNA1000 est conforme aux exigences essentielles et aux autres dispositions |
|
pertinentes de la directive 1999/5/CE. |
|
|
Italiano |
Con la presente NETGEAR, Inc. dichiara che questo NETGEAR Wireless-N 150 USB |
[Italian] |
Adapter WNA1000 è conforme ai requisiti essenziali ed alle altre disposizioni pertinenti |
|
stabilite dalla direttiva 1999/5/CE. |
Latviski |
Ar šo NETGEAR, Inc. deklarç, ka NETGEAR Wireless-N 150 USB Adapter WNA1000 |
[Latvian] |
atbilst Direktîvas 1999/5/EK bûtiskajâm prasîbâm un citiem ar to saistîtajiem noteikumiem. |
Lietuviø |
Šiuo NETGEAR, Inc. deklaruoja, kad šis NETGEAR Wireless-N 150 USB Adapter |
[Lithuanian] |
WNA1000 atitinka esminius reikalavimus ir kitas 1999/5/EB Direktyvos nuostatas. |
Nederlands |
Hierbij verklaart NETGEAR, Inc. dat het toestel NETGEAR Wireless-N 150 USB Adapter |
[Dutch] |
WNA1000 in overeenstemming is met de essentiële eisen en de andere relevante |
|
bepalingen van richtlijn 1999/5/EG. |
|
|
Malti |
Hawnhekk, NETGEAR, Inc., jiddikjara li dan NETGEAR Wireless-N 150 USB Adapter |
[Maltese] |
WNA1000 jikkonforma mal-tiijiet essenzjali u ma provvedimenti orajn relevanti li hemm fid- |
|
Dirrettiva 1999/5/EC. |
|
|
Magyar |
Alulírott, NETGEAR, Inc. nyilatkozom, hogy a NETGEAR Wireless-N 150 USB Adapter |
[Hungarian] |
WNA1000 megfelel a vonatkozó alapvetõ követelményeknek és az 1999/5/EC irányelv |
|
egyéb elõírásainak. |
Polski [Polish] |
Niniejszym NETGEAR, Inc. oœwiadcza, ¿e NETGEAR Wireless-N 150 USB Adapter |
|
WNA1000 jest zgodny z zasadniczymi wymogami oraz pozosta³ymi stosownymi |
|
postanowieniami Dyrektywy 1999/5/EC. |
|
|
Português |
NETGEAR, Inc. declara que este NETGEAR Wireless-N 150 USB Adapter WNA1000 |
[Portuguese] |
está conforme com os requisitos essenciais e outras disposições da Directiva 1999/5/CE. |
|
|
Slovensko |
NETGEAR, Inc. izjavlja, da je ta NETGEAR Wireless-N 150 USB Adapter WNA1000 v |
[Slovenian] |
skladu z bistvenimi zahtevami in ostalimi relevantnimi doloèili direktive 1999/5/ES. |
|
|
iv
v1.0, August 2009
Slovensky |
NETGEAR, Inc. týmto vyhlasuje, že NETGEAR Wireless-N 150 USB Adapter |
[Slovak] |
WNA1000 spåòa základné požiadavky a všetky príslušné ustanovenia Smernice 1999/5/ |
|
ES. |
Suomi |
NETGEAR, Inc. vakuuttaa täten että NETGEAR Wireless-N 150 USB Adapter |
[Finnish] |
WNA1000 tyyppinen laite on direktiivin 1999/5/EY oleellisten vaatimusten ja sitä |
|
koskevien direktiivin muiden ehtojen mukainen. |
|
|
Svenska |
Härmed intygar NETGEAR, Inc. att denna [utrustningstyp] står I överensstämmelse med |
[Swedish] |
de väsentliga egenskapskrav och övriga relevanta bestämmelser som framgår av direktiv |
|
1999/5/EG. |
|
|
Product and Publication Details
Model Number: |
WNA1000 |
Publication Date: |
August 2009 |
Product Family: |
Wireless-N USB Adapter |
Product Name: |
NETGEAR Wireless-N 150 USB Adapter WNA1000 |
Home or Business Product: |
Home |
Language: |
English |
Publication Part Number: |
202-10575-01 |
Publication Version Number: |
1.0 |
v
v1.0, August 2009
vi
v1.0, August 2009
About This Manual |
|
Conventions, Formats, and Scope ................................................................................... |
ix |
How to Use This Manual ................................................................................................... |
x |
How to Print This Manual .................................................................................................. |
x |
Revision History ................................................................................................................ |
xi |
Chapter 1 |
|
Basic Setup |
|
What Is in the Box ............................................................................................................. |
1 |
What You Need Before You Begin .................................................................................... |
2 |
Verify System Requirements ....................................................................................... |
2 |
Observe Wireless Location and Range Guidelines ..................................................... |
2 |
Installation with Custom Setup .......................................................................................... |
3 |
Installing the Software and Adapter ............................................................................ |
3 |
Connecting to a Wireless Network .............................................................................. |
5 |
Using the USB Adapter Cradle ................................................................................... |
6 |
Monitoring Your Wireless Network and the Internet Connections ..................................... |
8 |
WNA1000 Icon ............................................................................................................ |
8 |
Smart Wizard Status Bar ............................................................................................. |
9 |
Wireless-N USB Adapter LED ................................................................................... |
10 |
Removing the WNA1000 Software .................................................................................. |
10 |
Upgrading the WNA1000 Software ................................................................................. |
11 |
Chapter 2 |
|
Network Connections and Wireless Security |
|
Viewing Wireless Networks in Your Area .......................................................................... |
1 |
Joining a Network .............................................................................................................. |
2 |
Using Push 'N' Connect (WPS) to Connect to a Wireless Network ................................... |
3 |
Using a WPS Push Button to Connect to a Wireless Access Point or Router ............ |
5 |
Generating a PIN to Connect to a Wireless Access Point or Router .......................... |
6 |
vii
v1.0, August 2009
NETGEAR Wireless-N 150 USB Adapter WNA1000 User Manual |
|
Creating a Profile ............................................................................................................... |
8 |
Access Point Profiles .................................................................................................. |
9 |
Setting up a Computer-to-Computer (Ad Hoc) Profile ............................................... |
10 |
Starting a Computer-to-Computer (Ad Hoc) Network Connection ............................ |
12 |
About Wireless Security .................................................................................................. |
13 |
Wireless Network Name (SSID) and Security Settings ............................................. |
14 |
Setting Up WPA-PSK [TKIP] or WPA2-PSK [AES] Security ..................................... |
15 |
Setting Up WEP Encryption Security ........................................................................ |
16 |
Monitoring Statistics ........................................................................................................ |
18 |
About Your Smart Wizard ................................................................................................ |
19 |
Advanced Settings ........................................................................................................... |
20 |
Chapter 3 Wireless Network Performance |
|
Optimizing Wireless Performance ..................................................................................... |
1 |
Optimizing Your Network Bandwidth ................................................................................. |
2 |
SOHO Networking Technologies ................................................................................ |
3 |
Assessing Your Network Speed Requirements .......................................................... |
4 |
Chapter 4 Troubleshooting |
|
Troubleshooting Tips ......................................................................................................... |
1 |
Ad Hoc Mode Is Not Working Correctly ............................................................................. |
4 |
Windows XP Occasional Connection Problems ................................................................ |
4 |
Appendix A Technical Specifications and Factory Default Settings |
|
Technical Specifications .................................................................................................... |
1 |
Factory Default Settings .................................................................................................... |
2 |
Appendix B Related Documents |
|
viii
v1.0, August 2009
The NETGEAR Wireless-N 150 USB Adapter WNA1000 User Manual describes how to installthe NETGEAR Wireless-N 150 USB Adapter WNA1000 with custom setup, configuration, and troubleshooting. The information in this manual is intended for readers with intermediate computer and Internet skills.
The conventions, formats, and scope of this manual are described in the following paragraphs:
•Typographical Conventions. This manual uses the following typographical conventions:
Italic |
Emphasis, books, CDs, file and server names, extensions |
|
|
Bold |
User input, IP addresses, GUI screen text |
|
|
Fixed |
Command prompt, CLI text, code |
italic |
URL links |
|
|
•Formats. This manual uses the following formats to highlight special messages:
Note: This format is used to highlight information of importance or special interest.
Tip: This format is used to highlight a procedure that will save time or resources.
Warning: Ignoring this type of note may result in a malfunction or damage to the equipment.
ix
v1.0, August 2009
NETGEAR Wireless-N 150 USB Adapter WNA1000 User Manual
•Scope. This manual is written for the Wireless-N 150 USB Adapter WNA1000 according to these specifications:
Product Version |
NETGEAR Wireless-N 150 USB Adapter WNA1000 |
|
|
Manual Publication Date |
August 2009 |
|
|
For more information about network, Internet, firewall, and VPN technologies, see the links to the NETGEAR website in Appendix B, “Related Documents.
Note: Product updates are available on the NETGEAR, Inc. website at
http://www.netgear.com/support.
The HTML version of this manual includes the following:
•Buttons, and , for browsing forwards or backwards through the manual one page at a time
•A button that displays the table of contents and an button. Double-click on a link in the table of contents or index to navigate directly to where the topic is described in the manual.
•A button to access the full NETGEAR, Inc. online knowledge base for the product model.
•Links to PDF versions of the full manual and individual chapters.
To print this manual, your computer must have the free Adobe Acrobat reader installed in order to view and print PDF files. The Acrobat reader is available on the Adobe Web site at http://www.adobe.com.
Tip: If your printer supports printing two pages on a single sheet of paper, you can save paper and printer ink by selecting this feature.
x
v1.0, August 2009
NETGEAR Wireless-N 150 USB Adapter WNA1000 User Manual
NETGEAR, Inc. is constantly searching for ways to improve its products and documentation. The following table indicates any changes that might have been made since the Wireless-N 150 USB Adapter WNA1000 was introduced.
Table 1-1. Publication Revision History
Part Number |
Version |
Date |
Description |
|
Number |
||||
|
|
|
||
|
|
|
|
|
202-10575-01 |
v1.0 |
August 2009 |
First publication. |
|
|
|
|
|
xi
v1.0, August 2009
NETGEAR Wireless-N 150 USB Adapter WNA1000 User Manual
xii
v1.0, August 2009
Chapter 1
Basic Setup
This chapter includes instructions for custom installation of your Wireless-N 150 USB Adapter WNA1000 and basic configuration. There are two methods that you can use to install the wireless- N USB adapter:
•Express Installation uses the NETGEAR Smart Wizard configures your adapter automatically. This method is explained in the NETGEAR Wireless-N 150 USB Adapter WNA1000 Installation Guide.
•InstallationwithCustomSetupletsyouspecifywherethesoftwareisinstalled,andselect eithertheNETGEARSmartWizardortheWindowsUtilitytoconfigureyourwireless-N USB adapter. See “Installation with Custom Setup” on page 1-3.
NETGEAR strongly recommends that you implement wireless security to protect your network from unauthorized access. See Chapter 2, “Network Connections and Wireless Security.”
The product package should contain the following items:
•NETGEAR Wireless-N 150 USB Adapter WNA1000
•USB cable and adapter cradle
•NETGEAR Wireless-N 150 USB Adapter WNA1000 Installation Guide
•Resource CD, including:
–The Smart Wizard Installation Assistant
–This manual
–NETGEAR Wireless-N 150 USB Adapter WNA1000 Installation Guide
•Warranty and Support information card
If any of the parts are incorrect, missing, or damaged, contact your NETGEAR dealer. Keep the carton, including the original packing materials, in case you need to return the product for repair.
1-1
v1.0, August 2009
NETGEAR Wireless-N 150 USB Adapter WNA1000 User Manual
Verify that your computer meets the minimum system requirements and identify the wireless network settings of the wireless local area network (WLAN) where you will connect before you install and connect your wireless-N USB adapter.
Before installing the wireless-N USB adapter, make sure that these minimum requirements have been met:
•You must have a PC with a Pentium 300 MHz or higher compatible processor with an available USB 2.0 or 1.1 port.
Note: The maximum speed of a USB v2.0 port is 480 Mbps. If your computer has a USB v1.1 port, the wireless-N USB adapter is limited to that port’s maximum
speed, which is 14 Mbps.
•A CD drive.
•10 Mbytes of free hard disk space.
•Vista, Windows XP Home, Windows XP Professional, or Windows 2000. Some versions of Windows ask for the original Windows operating system installation files to complete the installation of the WNA1000 driver software.
Note: Windows XP users must install SP2 or install the KB822603 hot fix (update), which fixes the USB 2.0 host controller driver. Go to the following link to
install the hot fix: http://www.microsoft.com/downloads/ details.aspx?displaylang=en&FamilyID= 733dd867-56a0-4956-b7fe-e85b688b7f86
For best performance, place the wireless-N USB adapter at least 4 feet (over 1 meter) away from the wireless router or access point.
Computers can connect over wireless networks indoors at a range that varies significantly based on the physical location of the computer with the wireless-N USB adapter. For best results, avoid
1-2
v1.0, August 2009
NETGEAR Wireless-N 150 USB Adapter WNA1000 User Manual
potential sources of interference, such as the following:
•Large metal surfaces
•Microwave ovens
•2.4 GHz cordless phones
In general, wireless devices can communicate through walls. However, if the walls are constructed with concrete, or have metal, or metal mesh, the effective range decreases if such materials are between the devices.
Note: For Express installation, see the NETGEAR Wireless-N 150 USB Adapter WNA1000 Installation Guide.
With Custom setup you can specify where the files are installed. You can also choose whether or not you want to install the Smart Wizard.
•CustominstallationwiththeSmartWizard.SelecteitherConfigureManuallyorConfigure Automatically. The Smart Wizard provides a complete and easy-to-use set of tools to:
–View details about wireless networks in your area.
–Manage your network connections and connect securely using Push 'N' Connect (WPS).
–Configure wireless settings for your wireless-N USB adapter.
–Save your wireless network settings in profiles.
•Custom installation excluding the Smart Wizard. You can choose not to install the Smart wizard and to use only the Windows Utility to install and manage your wireless network. If you choose to do this, you will not be able to use the Smart Wizard to configure your wireless- N USB adapter or to connect to a wireless network.
To install the wireless-N USB adapter with custom setup:
1.InserttheResourceCD.IftheCDmainpagedoesnotdisplay,browsethefilesontheCD and double-click Autorun.exe.
2.Click Install the Software. The Software Update Check screen displays.
1-3
v1.0, August 2009
NETGEAR Wireless-N 150 USB Adapter WNA1000 User Manual
3.If you are connected to the Internet, click Check for Updates. If not, click Install from CD.
4.TheNETGEARSmartWizardWelcomescreendisplays.ClickIAgreetoacceptthe license agreement and click Next.
5.For the Setup Type, select Custom, and then click Next:
Figure 1-1
6. Browse to select the destination folder for your wireless adapter software, and then click Next.
Figure 1-2
7.Select one of the following methods to configure and manage your wireless network:
•SmartWizard.AllowsyoutomanageyourwirelessnetworkswiththeNETGEAR WNA1000 software and to connect securely using Push 'N' Connect.
1-4
v1.0, August 2009
NETGEAR Wireless-N 150 USB Adapter WNA1000 User Manual
–Configure network manually. Specify the settings for your wireless-N USB adapter in the Settings screen.
–Configure automatically. Allow the Smart Wizard to automatically configure the settings for your wireless-N USB adapter.
•Windows Utility. Connect to and manage your wireless networks using only the Windows configuration utility. For more information about Windows utilities, see the Windows documentation or the NETGEAR application note at: http://documentation.netgear.com/reference/enu/winzerocfg/index.htm.
8.When prompted, locate an available USB port on your PC. Connect the wireless adapter to the USB port. You can attach the wireless USB adapter directly to the USB port or use the USB cable (see “Using the USB Adapter Cradle” on page 1-7)
9.Followthepromptstocompletetheinstallation.IfyouselectedSmartWizard,thenclick
Next and continue with “Connecting to a Wireless Network” on page 1-5.
If you installed the Smart Wizard, you can use the WNA1000 software to connect to a wireless network.
Smart Wizard, Configure Network Manually
The Settings screen displays. See “Wireless Network Name (SSID) and Security Settings” on page 2-14 and “Joining a Network” on page 2-2.
1-5
v1.0, August 2009
NETGEAR Wireless-N 150 USB Adapter WNA1000 User Manual
Smart Wizard, Configure Automatically
You are prompted to connect wirelessly with one of the following screens:
Hidden network
WPS-capable networks in your area |
No WPS-capable networks in your area |
Figure 1-3
Note: If you are not sure if your router supports WPS, select No to connect. If your router does not support WPS and you select Yes, the router or access point connection
will time out and no wireless network connection will be established.
1.Follow the on-screen prompts to connect to a wireless network:
•If your router supports WPS and you want to use WPS to create a secure connection, leavetheradiobuttonselected,andclickNexttocontinue.FollowtheSmartWizard steps to connect using WPS.
•If your router does not support WPS, select your wireless network name from the list of wireless networks and click Next to continue. (If your wireless network has implemented security, you need to know which type of security (WEP, WPA-PSK, or WPA2-PSK) and you need the passphrase to complete your setup.
2.Create a wireless settings Profile.
a.If your wireless network has implemented security, and you did not use Push N' Connect, select the radio button for the security type and enter the security passphrase in the Passphrase field.
b.In the Profile field, create a unique name for your settings. If you do not select a profile name, your settings will be saved using the default name Profile.
1-6
v1.0, August 2009
