Operating and installation instructions

Built-in coffee machine

To avoid the risk of accidents or damage to the appliance it is essential to read these instructions before it is installed and used for the first time.

en-GB

M.-Nr. 11 202 230

Caring for the environment

Disposal of the packing

material

The packaging is designed to protect the appliance from damage during transportation. The packaging materials used are selected from materials which are environmentally friendly for disposal and should be recycled.

Recycling the packaging reduces the use of raw materials in the manufacturing process and also reduces the amount of waste in landfill sites.

Disposing of your old

appliance

Electrical and electronic appliances often contain valuable materials. They also contain specific materials, compounds and components, which were essential for their correct function and safety. These could be hazardous to human health and to the environment if disposed of with your domestic waste or if handled incorrectly. Please do not, therefore, dispose of your old appliance with your household waste.

Please dispose of it at your local community waste collection / recycling centre for electrical and electronic appliances, or contact your dealer or Miele for advice. You are also responsible (by law, depending on country) for deleting any personal data that may be stored on the appliance being disposed of. Please ensure that your old appliance poses no risk to children while being stored prior to disposal.

	Contents
Caring for the environment ..................................................................................	2
Warning and Safety instructions..........................................................................	6
Guide to the machine .........................................................................................	16
Controls and indicators ......................................................................................	18
Operation..............................................................................................................	20
Symbols in the display ..........................................................................................	22
Miele@home.........................................................................................................	23
Before using for the first time ............................................................................	24
Before using for the first time ................................................................................	24
Switching on for the first time ...............................................................................	24
Filling the coffee bean container .......................................................................	26
Filling the water container..................................................................................	27
Switching on and off ...........................................................................................	28
Spout adjustment ................................................................................................	29
Making drinks ......................................................................................................	30
Making coffee with and without milk.....................................................................	30
Preparing milk........................................................................................................	31
Making a coffee.....................................................................................................	32
Cancelling a drink..................................................................................................	32
DoubleShot............................................................................................................	33
Making 2 portions ( sensor)...............................................................................	33
Coffee pot..............................................................................................................	34
Tea.........................................................................................................................	34
TeaTimer...........................................................................................................	35
Making tea........................................................................................................	36
Teapot...............................................................................................................	36
Dispensing warm or hot water ..............................................................................	37
Expert mode.........................................................................................................	38
Grinder setting.....................................................................................................	39
Parameters...........................................................................................................	40
Displaying and changing parameters....................................................................	40
Portion size............................................................................................................	40
Ground quantity.....................................................................................................	41

Contents
Brewing temperature .............................................................................................	41
Pre-brewing the coffee ..........................................................................................	41
Profiles..................................................................................................................	42
Creating a profile ...................................................................................................	42
Changing drinks within a profile ............................................................................	42
Making drinks stored in a profile ...........................................................................	42
Editing profiles.......................................................................................................	42
Setting when the profile should change...........................................................	42
Changing the name ..........................................................................................	43
Deleting a profile ..............................................................................................	43
MobileStart...........................................................................................................	44
Settings ................................................................................................................	45
Displaying and changing Settings.........................................................................	45
Language...............................................................................................................	45
Time.......................................................................................................................	45
Date .......................................................................................................................	45
Timer .....................................................................................................................	45
Switch on at .....................................................................................................	45
Switch off at .....................................................................................................	46
Switch off after .................................................................................................	46
TeaTimer................................................................................................................	46
Volume...................................................................................................................	46
Display brightness.................................................................................................	46
Lighting..................................................................................................................	46
Info (display information) .......................................................................................	46
Fresh water............................................................................................................	46
Altitude ..................................................................................................................	47
Performance mode................................................................................................	47
Eco mode .........................................................................................................	47
Barista mode ....................................................................................................	47
Latte mode .......................................................................................................	47
Party mode .......................................................................................................	47
Water hardness .....................................................................................................	47
System lock ......................................................................................................	48
Miele@home ..........................................................................................................	49
Remote control......................................................................................................	49
RemoteUpdate ......................................................................................................	49
Software version....................................................................................................	50
Showroom programme (Demo mode)...................................................................	50
Factory defaults.....................................................................................................	50

	Contents
Cleaning and care ...............................................................................................	51
Overview of cleaning intervals...............................................................................	51
Cleaning by hand or in the dishwasher .................................................................	52
Unsuitable cleaning agents ...................................................................................	53
Cleaning the drip tray and waste container...........................................................	55
Cleaning the drip tray cover ..................................................................................	57
Water container .....................................................................................................	57
Cleaning the central spout ....................................................................................	57
Cleaning the cup rim sensor .................................................................................	59
Cleaning the milk flask with lid ..............................................................................	60
Cleaning the milk valve..........................................................................................	61
Cleaning the bean containers................................................................................	61
Cleaning the interior, inside of the machine door and drip tray ............................	62
Cleaning the front of the machine .........................................................................	63
Maintenance programmes.....................................................................................	63
Rinse the appliance...............................................................................................	63
Rinse the milk pipework ........................................................................................	63
Degreasing the brew unit and cleaning inside ......................................................	64
Descaling the machine ..........................................................................................	67
Problem solving guide ........................................................................................	69
Messages in the display........................................................................................	69
Unusual performance of the coffee machine ........................................................	72
Unsatisfactory results............................................................................................	74
Cleaning the milk valve..........................................................................................	76
After sales service and warranty .......................................................................	79
Accessories .........................................................................................................	80
Installation............................................................................................................	81
Mains water connection ........................................................................................	81
Electrical connection .............................................................................................	83
Building-in dimensions .........................................................................................	84
Building in the coffee machine..............................................................................	86
Door opening limiters ............................................................................................	87
Conformity declaration .......................................................................................	89

Warning and Safety instructions

This coffee machine complies with all the stipulated safety requirements. Inappropriate use can, however, lead to personal injury and material damage.

Read the operating instructions carefully before using the coffee machine. They contain important information on safety, installation, use and maintenance. This prevents both personal injury and damage to the coffee machine.

In accordance with standard IEC 60335-1, Miele expressly and strongly advises you to read and follow the instructions in the chapter on installing the coffee machine as well as the safety instructions and warnings.

Miele cannot be held liable for injury or damage caused by noncompliance with these instructions.

Keep these operating instructions in a safe place and pass them on to any future owner.

Warning and Safety instructions

Correct application

This coffee machine is intended for home use.

This coffee machine is not intended for outdoor use.

This coffee machine must not be used at altitudes above 2000 m.

It must only be used as a domestic appliance to make espresso, cappuccino, latte macchiato, tea etc. Any other use is not permitted.

This coffee machine can only be used by people with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, if they are supervised whilst using it, or have been shown how to use it in a safe way and recognise and understand the consequences of incorrect operation.

Warning and Safety instructions

Safety with children

Danger of burning and scalding on the dispensing spouts. Children's skin is far more sensitive to high temperatures than that of adults.

Ensure children do not touch hot surfaces of the coffee machine or place parts of their body under the dispensing spouts.

Install the coffee machine where it is out of the reach of children.

Children under 8 years of age must be kept away from the coffee machine unless they are constantly supervised.

Children aged 8 and older may only use the coffee machine without supervision if they have been shown how to use it in a safe manner.

Children aged 8 and older must be aware of the potential dangers caused by incorrect operation.

Please supervise children in the vicinity of the coffee machine and do not allow them to play with it.

Young children must not be allowed to clean the coffee machine at all. Cleaning may only be carried out by children 8 years of age or older under the supervision of an adult.

Remember that coffee and espresso are not suitable drinks for children.

Danger of suffocation! Whilst playing, children may become entangled in packaging material (such as plastic wrapping) or pull it over their head with the risk of suffocation. Keep packaging material away from children.

Warning and Safety instructions

Technical safety

Installation work or repairs should only be carried out by a Miele authorised technician. Unauthorised or incorrect installation work or repairs can pose considerable danger to users.

A damaged coffee machine could be dangerous. Before building in the machine, check it for any externally visible damage. Do not use a damaged machine.

To avoid the risk of damage to the machine, make sure the connection data (voltage and frequency) on the data plate corresponds to the household supply, before connecting the machine to the mains supply. Consult a qualified electrician if in any doubt.

The electrical safety of this coffee machine can only be guaranteed when correctly earthed. It is essential that this standard safety requirement is met. If in any doubt please have the electrical installation tested by a qualified electrician.

Reliable and safe operation of the coffee machine can only be guaranteed if it is connected to the mains electrical supply.

Do not connect the machine to the mains electricity supply by a multi-socket adapter or an extension lead. These are a fire hazard and do not guarantee the required safety of the appliance.

The coffee machine must not be used in a non-stationary location (e.g. on a ship).

For safety reasons, this machine may only be used when it has been built in.

If the coffee machine is to be built in above another appliance, there must be a full-width, closed shelf between them (except when it is combined with a suitable built-in plate/food warming drawer).

Only use the coffee machine in rooms where the ambient temperature is between +16 °C and +38 °C.

Warning and Safety instructions

A minimum installation height of 850 mm must be observed.

This coffee machine must not be installed behind a closed cabinet door because heat and moisture can build up behind it. This can result in damage to the machine and/or furniture unit.

The coffee machine must be disconnected from the electricity supply during repair work.

While the machine is under warranty, repairs should only be undertaken by a Miele authorised service technician. Otherwise the warranty is invalidated.

Miele can only guarantee the safety of the machine when original Miele spare parts are used. Faulty components must only be replaced by genuine Miele original spare parts.

Never open the outer casing of the machine. Tampering with electrical connections or components and mechanical parts is highly dangerous to the user and can cause operational faults or electric shock.

Only use original Miele accessories. If other parts are used, warranty, performance and/or product liability claims will be invalidated.

Warning and Safety instructions

Mains water connection

Do not connect the coffee machine to a hot water supply.

The stopcock must be easily accessible after the coffee machine has been built in.

The protective sleeve of the water inlet hose must not be damaged or become kinked.

The integrated water protection system offers protection from water damage, provided the following conditions are met:

–The coffee machine is correctly installed, connected to the electricity supply and plumbed in.

–If a fault is identified, the coffee machine must be repaired immediately.

–The stopcock is turned off when the machine is not in use for an extended period (e.g. during holidays).

Warning and Safety instructions

Correct use

Danger of burning and scalding on the dispensing spouts. The liquids and steam dispensed are very hot.

Keep well away from the area underneath the spouts when hot liquids and steam are being dispensed.

Do not touch hot components.

Hot liquid or steam could spatter from the nozzles. Ensure that the central spout is clean and fitted correctly.

Before opening the door, remove any containers from the drip tray in the machine door.

Water in the drip tray can also be very hot. Take care when emptying it.

Danger of injury to the eyes.

Never look directly at the lighting or use optical instruments to look at it.

Please note the following regarding water:

–If the water container is filled manually: only use cold, fresh tap water to fill the water container. Hot or warm water or other liquids can damage the coffee machine.

–Change the water every day to prevent a build-up of bacteria.

If the machine is plumbed into the mains water supply: empty the water container once a day.

–Do not use carbonated water.

Only put roasted coffee beans in the bean containers. Do not place coffee beans which have been treated with additives or ground coffee inside the bean containers.

Do not fill the bean containers with any type of liquid.

Warning and Safety instructions

Do not use green (unroasted) coffee beans or mixtures of coffee beans which contain green coffee beans. Green coffee beans are very hard and still contain residual moisture. These can damage the coffee machine grinder as soon as grinding begins.

Do not use coffee beans which have been treated with caramel, sugar or other substances including sugary liquids. Sugar will damage the coffee machine.

Only use milk without additives. Additives in milk usually contain sugar and this will stick to the milk pipework.

If using dairy milk make sure that it has been pasteurised.

When making tea, please follow the instructions on the packaging.

Do not place flaming alcohol mixtures underneath the central spout. The flames could ignite plastic components and cause them to melt.

Do not swing from or hang anything on the machine front when it is open as this could damage the hinges on the coffee machine.

The machine must not be used for cleaning objects.

Warning and Safety instructions

Cleaning and care

Clean the coffee machine and the milk flask daily, particularly before using them for the first time.

All parts of the milk system need to be cleaned thoroughly and regularly. Milk contains bacteria which proliferate rapidly with inadequate cleaning.

Descale the coffee machine regularly depending on the water hardness level in your area. Descale the machine more frequently in areas with very hard water. Miele cannot be held liable for damage arising from insufficient descaling, the use of incorrect descaling agent or the use of descaling agent which is not of the appropriate concentration.

Degrease the brew unit regularly with Miele cleaning tablets. Depending on the natural oil content of the coffee used, the brew unit can become blocked quite quickly.

Do not use a steam cleaner to clean this machine. Steam could reach electrical components and cause a short circuit.

Used coffee grounds should be disposed of with the organic rubbish or on the compost heap. Do not empty them down the sink, as they could block it.

Warning and Safety instructions

For machines with stainless steel surfaces:

Do not use sticky notes, transparent adhesive tape, masking tape or other types of adhesive on the stainless steel surfaces. These will damage the stainless steel surfaces, causing them to lose their dirtrepellent protective coating.

The finish on stainless steel surfaces is susceptible to scratching. Even magnets can cause scratching.

Guide to the machine

Exterior view

	3
6	4
6
	5

a On/Off button

b Control panel

c Door handle

d Height-adjustable central spout with lighting

e Drip tray cover

f Milk flask

Guide to the machine

Interior view

a Bean container b Milk valve

c Height-adjustable central spout with lighting d Grinder setting

e Bean container f Fan outlet

g Water container h Drip tray with lid i Brew unit

j Waste container

k Maintenance container l Drip tray

Controls and indicators

a On/Off button

For switching coffee machine on and off

b Drink buttons

For making drinks

cDisplay

For showing information about the current action or status

dsensor

–For making other drinks, e.g. Ristretto, Cappuccino italiano

–For making a pot of tea or coffee

–Menu: Settings

eProfiles sensor

For creating and managing profiles

fMaintenance sensor

Maintenance programmes, e.g.

Descale

g Parameters sensor

For displaying or changing drink settings

h OK sensor

For confirming display messages and saving settings

i Navigation area with arrow buttons

For scrolling through lists, selecting entries or changing values

j “Back” sensor

For returning to the previous menu and cancelling unwanted actions

k “2 portions” sensor

For dispensing 2 portions of a drink at once

l “DoubleShot” sensor

For making a particularly strong and aromatic coffee by using twice as much ground coffee but the same amount of water

m Optical interface

(For Miele Customer Service Department only)

Controls and indicators

Drink button symbols

Espresso

Coffee

Long coffee

Cappuccino

Latte macchiato

Caffè latte

Hot milk

Milk froth

Tea water

Operation

Sensors

To operate the coffee machine, touch the sensors with your finger.

An audible signal is generated each time a sensor is touched. You can adjust the volume of the signal tones or switch the tones off (see “Settings – Volume”).

Drinks menu

When the following appears in the display, you are in the drinks menu:

Select drink.

Miele

12:00

Select drink

You can find more drinks in the Further menu ( sensor).

As soon as you reach a confirmable value, message or setting, the OK sensor will light up orange.

Touch OK to confirm your selection.

Selecting a menu and

navigating within a menu

To select a menu, touch the relevant

sensor, e.g. the sensor.

Miele

12:00

Settings

Ristretto

Cappuccino Italiano

You will then be able to start an action or change settings in the menu. A bar on the right-hand side of the display indicates that further options or text are available.

The setting which is currently selected in a list will have a tick beside it.

Navigation area

To select a menu option, keep pressing the arrow buttons and until the option you want is highlighted.

To scroll more quickly through the options, swipe your finger right or left in the area between the arrows.

Exiting a menu or cancelling an

action

To exit the current menu, touch the sensor.

Alternatively, touch the lit orange sensor again to return to the drinks menu.

Entering a name

Letters and numbers are entered via the navigation area. You can choose between upper and lower case letters.

Tip: It is best to select short names.

Operation

Name

Z A B C D E F

–To enter a character, highlight the one you want and confirm your choice with OK.

–To delete a character, touch the

sensor.

–To save the name, select the tick and confirm with OK.

Operation

Symbols in the display

The following symbols may also appear in the display in addition to the text:

Symbol Explanation

This symbol indicates the “Settings” menu and the “Language” menu option.

This symbol indicates that there is additional information and advice about using the coffee machine. Select OK to confirm the information.

This symbol appears if the system lock is activated. Operation is locked.

The symbol and the desired switching-on time appear in the display 23:59 hours before the coffee machine is due to switch on if the Switch on at timer and setting for displaying the time are activated (see “Settings – Timer”).

The TeaTimer minute minder has been started (see “Tea – TeaTimer”). The remaining brewing time is shown next to the symbol.

This symbol appears while the appliance is being descaled. (This symbol can also be found on the water container: fill up to this mark).

This symbol appears during the Clean the milk pipework maintenance programme.

(This symbol is also found on the water container: fill up to this mark with water).

If Miele@home has been activated for the coffee machine,

these symbols represent the quality/status of the WiFi

connection, indicating the strength in increments from

strong to not connected.

Miele@home

Your coffee machine is equipped with an integrated WiFi module.

In order to use it, you will need:

–A WiFi network

–The Miele@mobile app

–A Miele user account The user account can be created via the Miele@mobile app.

The Miele@mobile app will guide you through the process of connecting your coffee machine to your home WiFi network.

Once your coffee machine is connected to your WiFi network, you can use the app to carry out activities such as the following:

–Calling up information on the operating status of your coffee machine

–Changing settings on your coffee machine

–Controlling your coffee machine remotely

Connecting your coffee machine to your WiFi network will increase energy consumption, even when the machine is switched off.

Before installing the coffee machine in its final location, ensure that the signal from your WiFi network is strong enough.

Availability of the WiFi

connection

The WiFi connection shares a frequency range with other appliances (including microwave ovens and remote control toys). This can give rise to sporadic or even complete connection failures. Therefore, the availability of featured functions cannot be guaranteed.

Miele@home availability

The ability to use the Miele@mobile app depends on the availability of the Miele@home service in your country.

The Miele@home service is not available in every country.

For information about availability, please visit www.miele.com.

Miele@mobile App

The Miele@mobile App is available to download free of charge from the Apple App Store® or from the Google Play Store™.

Before using for the first time

Connect the coffee machine to the water and electricity supplies.

Install the coffee machine by building it in.

Remove any notices from the machine.

Remove the protective foil from the drip tray cover.

Clean the machine thoroughly (see “Cleaning and care”) before filling it with coffee beans and making drinks.

Clean the coffee machine (see “Cleaning and care”).

Remove the bean containers and fill them with roasted coffee beans.

Switching on for the first time

Touch the On/Off button .

Selecting the display language and country

The choice of country determines how the time is displayed, e.g. in the 12 or 24-hour format, as well as how units are displayed and so on.

Select the desired display language.

Then select the country.

Setting up the network (Miele@home)

You can connect your coffee machine to your home WiFi network.

When you start it up for the first time, it shows the following in the display: Set

up Miele@home

Tip: You can also choose to set up Miele@home for your coffee machine at a later point. In this case, select Skip.

Make sure that your WiFi network signal is sufficiently strong in the place where you want to set up your coffee machine.

Touch Continue.

Select the connection method you wish to use.

Follow the instructions provided in the coffee machine display and in the Miele@mobile app.

Connection successfully established. will

appear in the display.

Touch Continue to proceed with initial set-up.

Setting the date

Set the current date and touch OK.

Setting the time

Set the current time of day and touch OK.

If the coffee machine has been connected to a WiFi network and signed into the Miele@mobile app, the time will be synchronised based on the country setting in the Miele@mobile app.

Setting the water hardness level

Contact your local water supplier to find out your local water hardness range if necessary.

More information can be found under “Settings – Water hardness”.

Before using for the first time

Enter your local water hardness (in °dH) and confirm with OK.

Selecting the water supply (Mains water)

The coffee machine is intended to be plumbed into the mains water supply. You can select one of the following options:

–On: The water container will be filled automatically via the mains water connection.

–Off: You must fill the water container manually. A message appears in the display to inform you of this.

Select the water supply and confirm with OK.

The setting is now saved.

Selecting the Performance mode

You can select the appropriate mode to suit your personal preferences (see “Settings – Performance mode”).

–Eco mode: This is an energy-saving mode.

–Barista mode: This mode has been optimised for unadulterated coffee enjoyment.

–Latte mode: In this mode, milkbased drinks can be prepared within a much shorter space of time.

Select the desired mode and confirm with OK.

Your machine has been successfully set up and is ready for use.

To ensure that any coffee residues from the factory testing process are removed from the brewing system, please throw away the first 2 cups of coffee when using the coffee machine for the first time.

Filling the coffee bean container

Coffee or espresso can be made from whole roasted coffee beans which are freshly ground for each portion. This requires the bean containers to be filled with coffee beans.

Risk of damage to the grinder due to incorrect operation.

The coffee machine will be damaged if the bean container is filled with unsuitable substances such as liquids, ground coffee or coffee beans treated with sugar, caramel or similar.

In addition, green (unroasted) coffee beans or mixtures of coffee beans which contain green coffee beans can damage the grinder. Green coffee beans are very hard and still contain residual moisture. These can damage the coffee machine grinder as soon as grinding begins.

Only put roasted coffee beans in the bean containers.

The coffee machine has 2 bean container drawers on the top left and right. Coffee beans from all 3 bean containers are mixed together during grinding.

Open the machine door.

Pull out the bean containers.

Take the lids off the bean containers and fill them with coffee beans.

Put the lids back on the bean containers to seal them.

Slide the bean container drawers all the way into the coffee machine. Close the machine door.

Filling the water container

Risk to health due to contaminated water.

Bacteria can develop in water which has been sitting in the water container for too long and is a risk to your health. Water that gets left in the inlet hose can also impair the flavour if you do not make any drinks for a long time.

Change the water in the water container every day.

Discard the first full container of water if you have not made any drinks for a while.

If the coffee machine is plumbed into the mains drinking water supply, the water container will fill automatically as soon as the coffee machine is switched on.

You can fill the water container manually at any time.

Risk of damage due to incorrect operation.

Unsuitable liquids such as hot or warm water or other liquids can damage the coffee machine.

Carbonated water leaves too much limescale in the coffee machine.

If filling the water container manually: Only use fresh, cold tap water.

Open the machine door.

Pull the water container forwards to remove it.

Fill the water container with fresh, cold tap water up to the “max.” mark.

Push the water container into the machine and close the machine door.

Switching on and off

Switching the coffee machine

Touch the On/Off button .

The coffee machine heats up and rinses the pipework. Hot water will run out of the central spout.

You can now make drinks.

If the coffee machine is already at operating temperature, rinsing will not take place.

While dispensing a drink or during maintenance processes, moisture builds up in the coffee machine. The fan inside the machine expels moisture from the interior. Once a drink has been dispensed or the machine has been switched off, the fan will continue to run for up

to 30 minutes or so. You will hear an accompanying noise.

Switching the coffee machine

off

Touch the On/Off button .

If coffee has been dispensed, the coffee machine will rinse the coffee pipework automatically before switching off.

Switching off for longer

periods of time

If the coffee machine is not going to be used for a while, e.g. if you are going on holiday, remember to do the following:

Empty the drip tray, the waste container and the water container.

Clean all parts thoroughly, including the brew unit and interior of the machine.

Switch the coffee machine off.

+ 64 hidden pages
