OWNER’S MANUAL
LED LCD TV / LCD TV
Please read this manual carefully before operating your set and retain it for future reference.
LED LCD TV MODELS |
|
|
LCD TV MODELS |
||
32LM3400 |
32LS3400 |
32LS3450 |
22LS3500 |
32CS460 |
32CS560 |
42LM3400 |
42LS3400 |
42LS3450 |
32LS3500 |
42CS460 |
42CS560 |
P/NO : MFL67468023 (1206-REV03) |
www.lg.com |
ENGLISH
2 IMPORTANT SAFETY INSTRUCTIONS
IMPORTANT SAFETY INSTRUCTIONS
Always comply with the following precautions to avoid dangerous situations and ensure peak performance of your product.
WARNING/CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
TO REDUCE THE RISK OF ELECTRIC SHOCK DO NOT REMOVE COVER (OR BACK). NO USER SERVICEABLE PARTS INSIDE. REFER TO QUALIFIED SERVICE PERSONNEL.
The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the
presence of uninsulated “dangerous voltage” within the product’s enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons.
The exclamation point within an equilateral triangle is intended to alert the user to the presence of important
operating and maintenance (servicing) instructions in the literature accompanying the appliance.
WARNING/CAUTION
- TO REDUCE THE RISK OF FIRE AND ELECTRIC SHOCK, DO NOT EXPOSE THIS PRODUCT TO RAIN OR MOISTURE.
Read these instructions.
Keep these instructions.
Heed all warnings.
Follow all instructions.
yyDo not use this apparatus near water.
yyClean only with a dry cloth.
yyDo not block any ventilation openings. Install in accordance with the manufacturer’s instructions.
yyDo not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers) that produce heat.
yyDo not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has two blades with one wider than the other. A grounding type plug has two blades and a third grounding prong. The wide blade or the third prong are provided for your safety. If the provided plug does not fit into your outlet, consult an electrician for replacement of the obsolete outlet (Can differ by country).
IMPORTANT SAFETY INSTRUCTIONS 3
yyProtect the power cord from being walked on |
yyKeep the packing anti-moisture material or |
||||||||||||||||||
or pinched particularly at plugs, convenience |
vinyl packing out of the reach of children. |
||||||||||||||||||
receptacles, and the point where they exit |
Anti-moisture material is harmful if |
||||||||||||||||||
from the apparatus. |
swallowed. If swallowed by mistake, force |
||||||||||||||||||
|
|
|
|
|
|
|
|
|
|
|
|
the patient to vomit and visit the nearest |
|||||||
|
|
|
|
|
|
|
|
|
|
|
|
hospital. Additionally, vinyl packing can |
|||||||
|
|
|
|
|
|
|
|
|
|
|
|
||||||||
|
|
|
|
|
|
|
|
|
|
|
|
cause suffocation. Keep it out of the reach of |
|||||||
|
|
|
|
|
|
|
|
|
|
|
|
children. |
|||||||
|
|
|
|
|
|
|
|
|
|
|
|
||||||||
yyOnly use attachments/accessories specified |
yyCAUTION concerning the Power Cord |
||||||||||||||||||
by the manufacturer. |
(Can differ by country): |
||||||||||||||||||
|
|
|
|
|
|
|
|
|
|
|
|
It is recommended that appliances be |
|||||||
|
|
|
|
|
|
|
|
|
|
|
|
||||||||
|
|
|
|
|
|
|
|
|
|
|
|
placed upon a dedicated circuit; that is, a |
|||||||
|
|
|
|
|
|
|
|
|
|
|
|
single outlet circuit which powers only that |
|||||||
|
|
|
|
|
|
|
|
|
|
|
|
||||||||
|
|
|
|
|
|
|
|
|
|
|
|
||||||||
yyUse only with a cart, stand, tripod, bracket, |
appliance and has no additional outlets or |
||||||||||||||||||
or table specified by the manufacturer, or |
branch circuits. Check the specification page |
||||||||||||||||||
sold with the apparatus. When a cart is used, |
of this owner’s manual to be certain. Do not |
||||||||||||||||||
use caution when moving the cart/apparatus |
connect too many appliances to the same |
||||||||||||||||||
combination to avoid injury from tip-over. |
AC power outlet as this could result in fire or |
||||||||||||||||||
|
|
|
|
|
|
|
|
|
|
|
|
electric shock. Do not overload wall outlets. |
|||||||
|
|
|
|
|
|
|
|
|
|
|
|
Overloaded wall outlets, loose or damaged |
|||||||
|
|
|
|
|
|
|
|
|
|
|
|
wall outlets, extension cords, frayed power |
|||||||
|
|
|
|
|
|
|
|
|
|
|
|
cords, or damaged or cracked wire insulation |
|||||||
yyUnplug this apparatus during lightning |
are dangerous. Any of these conditions could |
||||||||||||||||||
storms or when unused for long periods of |
result in electric shock or fire. Periodically |
||||||||||||||||||
time. |
examine the cord of your appliance, and |
||||||||||||||||||
|
|
|
|
|
|
|
|
|
|
|
|
if its appearance indicates damage or |
|||||||
|
|
|
|
|
|
|
|
|
|
|
|
||||||||
|
|
|
|
|
|
|
|
|
|
|
|
deterioration, unplug it, discontinue use of |
|||||||
|
|
|
|
|
|
|
|
|
|
|
|
the appliance, and have the cord replaced |
|||||||
|
|
|
|
|
|
|
|
|
|
|
|
||||||||
|
|
|
|
|
|
|
|
|
|
|
|
||||||||
|
|
|
|
|
|
|
|
|
|
|
|
with an exact replacement part by an |
|||||||
yyRefer all servicing to qualified service |
authorized service. Protect the power cord |
||||||||||||||||||
personnel. Servicing is required when |
from physical or mechanical abuse, such as |
||||||||||||||||||
the apparatus has been damaged in any |
being twisted, kinked, pinched, closed in a |
||||||||||||||||||
way, such as power-supply cord or plug is |
door, or walked upon. Pay particular attention |
||||||||||||||||||
damaged, liquid has been spilled or objects |
to plugs, wall outlets, and the point where |
||||||||||||||||||
have fallen into the apparatus, the apparatus |
the cord exits the appliance. Do not move |
||||||||||||||||||
has been exposed to rain or moisture, does |
the TV with the power cord plugged in. Do |
||||||||||||||||||
not operate normally, or has been dropped. |
not use a damaged or loose power cord. Be |
||||||||||||||||||
|
|
|
|
|
|
|
|
|
|
|
|
sure do grasp the plug when unplugging the |
|||||||
|
|
|
|
|
|
|
|
|
|
|
|
power cord. Do not pull on the power cord |
|||||||
|
|
|
|
|
|
|
|
|
|
|
|
to unplug the TV. |
|||||||
|
|
|
|
|
|
|
|
|
|
|
|
||||||||
yyDo not stick metal objects or any other |
|
|
|
|
|
|
|
|
|||||||||||
|
|
|
|
|
|
|
|
||||||||||||
conductive material into the power cord. Do |
|
|
|
|
|
|
|
|
|||||||||||
not touch the end of the power cord while it |
|
|
|
|
|
|
|
|
|||||||||||
is plugged in. |
|
|
|
|
|
|
|
|
ENGLISH
ENGLISH
4 IMPORTANT SAFETY INSTRUCTIONS
yyWarning - To reduce the risk of fire or electrical shock, do not expose this product to rain, moisture or other liquids. Do not touch the TV with wet hands. Do not install this product near flammable objects such as gasoline or candles, or expose the TV to direct air conditioning.
yyDo not expose to dripping or splashing and do not place objects filled with liquids, such as vases, cups, etc. on or over the apparatus (e.g. on shelves above the unit).
yyGrounding
(Except for devices which are not grounded.) Ensure that you connect the earth ground wire to prevent possible electric shock
(i.e. a TV with a three-prong grounded AC plug must be connected to a three-prong grounded AC outlet). If grounding methods are not possible, have a qualified electrician install a separate circuit breaker. Do not try to ground the unit by connecting it to telephone wires, lightening rods, or gas pipes.
Power Supply
Short-circuit
Breaker
yyDISCONNECTING DEVICE FROM THE MAIN POWER
Mains plug is the disconnecting device. The plug must remain readily operable.
yyAs long as this unit is connected to the AC wall outlet, it is not disconnected from the AC power source even if the unit is turned off.
yyDo not attempt to modify this product in any way without written authorization from LG Electronics. Unauthorized modification could void the user’s authority to operate this product.
yyANTENNAS Outdoor antenna grounding
(Can differ by country):
If an outdoor antenna is installed, follow the precautions below. An outdoor antenna system should not be located in the vicinity
of overhead power lines or other electric light or power circuits, or where it can come in contact with such power lines or circuits as death or serious injury can occur. Be sure the antenna system is grounded so as to provide some protection against voltage surges
and built-up static charges. Section 810 of the National Electrical Code (NEC) in the U.S.A. provides information with respect to proper grounding of the mast and supporting structure, grounding of the lead-in wire to an antenna discharge unit, size of grounding conductors, location of antenna discharge unit, connection to grounding electrodes and requirements for the grounding electrode.
Antenna grounding according to the National Electrical Code, ANSI/NFPA 70
Ground Clamp |
|
|
|
|
|
|
|
|
|
|
Antenna Lead in Wire |
||
|
|
|
|
|
|
|
|
|
|
||||
|
|
|
|
|
Antenna Discharge Unit |
||||||||
|
|
|
|
||||||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Electric Service |
|
|
|
|
|
|
|
|
|
|
|
|
(NEC Section 810-20) |
Equipment |
|
|
|
|
|
|
|
|
|
Grounding Conductor |
|||
Ground Clamp |
|
|
|
|
|
|
|
|
|
|
|
(NEC Section 810-21) |
|
|
|
|
|
|
|
|
|
|
Power Service Grounding
NEC: National Electrical Code Electrode System
(NEC Art 250, Part H)
|
|
|
|
|
IMPORTANT SAFETY INSTRUCTIONS 5 |
|
yyCleaning |
yyDot Defect |
|
||||
When cleaning, unplug the power cord and |
The Plasma or LCD panel is a high |
|||||
wipe gently with a soft cloth to prevent |
technology product with resolution of two |
|||||
scratching. Do not spray water or other |
million to six million pixels. In a very few |
|||||
liquids directly on the TV as electric shock |
cases, you could see fine dots on the screen |
|||||
may occur. Do not clean with chemicals |
while you’re viewing the TV. Those dots |
|||||
such as alcohol, thinners or benzine. |
are deactivated pixels and do not affect the |
|||||
yyMoving |
performance and reliability of the TV. |
|||||
Make sure the product is turned off, |
yyGenerated Sound |
|||||
unplugged and all cables have been |
“Cracking” noise: A cracking noise that |
|||||
removed. It may take 2 or more people to |
occurs when watching or turning off the TV |
|||||
carry larger TVs. Do not press or put stress |
is generated by plastic thermal contraction |
|||||
on the front panel of the TV. |
due to temperature and humidity. This noise |
|||||
yyVentilation |
is common for products where thermal |
|||||
Install your TV where there is proper |
deformation is required. |
|||||
ventilation. Do not install in a confined |
Electrical circuit humming/panel buzzing: A |
|||||
space such as a bookcase. Do not cover the |
low level noise is generated from a high- |
|||||
product with cloth or other materials while |
speed switching circuit, which supplies a |
|||||
plugged. Do not install in excessively dusty |
large amount of current to operate a product. |
|||||
places. |
It varies depending on the product. |
|||||
yyIf you smell smoke or other odors coming |
This generated sound does not affect the |
|||||
from the TV, unplug the power cord and |
performance and reliability of the product. |
|||||
contact an authorized service center. |
yyTake care not to touch the ventilation |
|||||
yyDo not press strongly upon the panel with a |
openings. When watching the TV for a long |
|||||
hand or a sharp object such as a nail, pencil |
period, the ventilation openings may become |
|||||
or pen, or make a scratch on it. |
hot. This does not affect the performance of |
|||||
yyKeep the product away from direct sunlight. |
the product or cause defects in the product. |
|||||
|
|
|
|
|
yyIf the TV feels cold to the touch, there may |
|
|
|
|
|
|
||
|
|
|
|
|
be a small “flicker” when it is turned on. This |
|
|
|
|
|
|
is normal, there is nothing wrong with TV. |
|
|
|
|
|
|
||
|
|
|
|
|
||
|
|
|
|
|
Some minute dot defects may be visible on |
|
yyNever touch this apparatus or antenna during |
the screen, appearing as tiny red, green, or |
|||||
a thunder or lightning storm. |
blue spots. However, they have no adverse |
|||||
yyWhen mounting a TV on the wall, make sure |
effect on the TV’s performance. Avoid |
|||||
not to install the TV by hanging the power |
touching the LCD screen or holding your |
|||||
and signal cables on the back of the TV. |
finger(s) against it for long periods of time. |
|||||
yyDo not allow an impact shock or any objects |
Doing so may produce some temporary |
|||||
to fall into the product, and do not drop |
distortion effects on the screen. |
|||||
anything onto the screen. |
|
|
ENGLISH
ENGLISH
6 IMPORTANT SAFETY INSTRUCTIONS
DISPOSAL (Hg lamp only used in LCD TVs)
The fluorescent lamp used in this product contains a small amount of mercury. Do not dispose of this product with general household waste. Disposal of this product must be carried out in accordance to the regulations of your local authority.
Preventing “Image burn” or “Burn-in” on your TV screen
yyIf a fixed image displays on the TV screen for a long period of time, it will be imprinted and become a permanent disfigurement on the screen. This is “image burn” or “burn-in” and not covered by the warranty.
yyIf the aspect ratio of the TV is set to 4:3 for a long period of time, image burn may occur on the letterboxed area of the screen.
yyAvoid displaying a fixed image on the TV screen for a long period of time (2 or more hours for LCD, 1 or more hours for the Plasma TV) to prevent image burn.
IMPORTANT SAFETY INSTRUCTIONS 7
Viewing 3D Imaging (For 3D models)
WARNING
Viewing Environment
yyViewing Time
-When watching 3D contents, take 5 - 15 minute breaks every hour. Viewing 3D contents for a long period of time may cause headache, dizziness, fatigue or eye strain.
Those that have a photosensitive seizure or chronic illness
yySome users may experience a seizure or other abnormal symptoms when they are exposed to a flashing light or particular pattern from 3D contents.
yyDo not watch 3D videos if you feel nausea, are pregnant and/ or have a chronic illness such as epilepsy, cardiac disorder, or blood pressure disease, etc.
yy3D Contents are not recommended to those who suffer from stereo blindness or stereo anomaly. Double images or discomfort in viewing may be experienced.
yyIf you have strabismus (cross-eyed), amblyopia (weak eyesight) or astigmatism, you may have trouble sensing depth and easily feel fatigue due to double images. It is advised to take frequent breaks than the average adult.
yyIf your eyesight varies between your right and left eye, revise your eyesight prior to watching 3D contents.
Symptoms which require discontinuation or refraining from watching 3D contents
yyDo not watch 3D contents when you feel fatigue from lack of sleep, overwork or drinking.
yyWhen these symptoms are experienced, stop using/watching 3D contents and get enough rest until the symptom subsides.
-Consult your doctor when the symptoms persist. Symptoms may include headache, eyeball pain, dizziness, nausea, palpitation, blurriness, discomfort, double image, visual inconvenience or fatigue.
ENGLISH
ENGLISH
8 IMPORTANT SAFETY INSTRUCTIONS
CAUTION
Viewing Environment
yyViewing Distance
-Maintain a distance of at least twice the screen diagonal length when watching 3D contents. If you feel discomfort in viewing 3D contents, move further away from the TV.
Viewing Age
yyInfants / Children
-Usage/ Viewing 3D contents for children under the age of 5 are prohibited.
-Children under the age of 10 may overreact and become overly excited because their vision is in development (for example: trying to touch the screen or trying to jump into it. Special monitoring and extra attention is required for children watching 3D contents.
-Children have greater binocular disparity of 3D presentations than adults because the distance between the eyes is shorter than one of adults. Therefore they will perceive more stereoscopic depth compared to adults for the same 3D image.
yyTeenagers
-Teenagers under the age of 19 may be stimulated to light coming from 3D videos. Advise them not to watch 3D videos for a long time when they are tired.
yyElderly
-The elderly may perceive less of a 3D effect than the youth. Do not sit closer to the TV than the recommended distance.
Cautions when using the 3D glasses
yyMake sure to use LG 3D glasses. Otherwise, you may not be able to view 3D videos properly. yyDo not use 3D glasses instead of your normal glasses, sunglasses or protective goggles. yyUsing modified 3D glasses may cause eye strain or image distortion.
yyDo not keep your 3D glasses in extremely high or low temperatures. It will cause deformation. yyThe 3D glasses are fragile and are easy to be scratched. Always use a soft, clean piece of cloth when
wiping the lenses. Do not scratch the lenses of the 3D glasses with sharp objects or clean/wipe them with chemicals.
LICENSES / OPEN SOURCE SOFTWARE NOTICE 9
LICENSES
Supported licenses may differ by model. For more information about licenses, visit www.lg.com.
Manufactured under license from Dolby Laboratories. “Dolby” and the double-D symbol are trademarks of Dolby Laboratories.
HDMI, the HDMI logo and High-Definition Multimedia Interface are trademarks or registered trademarks of HDMI Licensing LLC.
ABOUT DIVX VIDEO: DivX® is a digital video format created by DivX, LLC, a subsidiary of Rovi Corporation. This is an official DivX Certified® device that plays DivX video. Visit divx.com for more information and software tools to convert your files into DivX video.
ABOUT DIVX VIDEO-ON-DEMAND: This DivX Certified® device must be registered in order to play purchased DivX Video-on-Demand (VOD) movies. To obtain your registration code, locate the DivX VOD section in your device setup menu. Go to vod.divx.com for more information on how to complete your registration.
“DivX Certified® to play DivX® video up to HD 1080p, including premium content.”
“DivX®, DivX Certified® and associated logos are trademarks of Rovi Corporation or its subsidiaries and are used under license.”
“Covered by one or more of the following U.S. patents: 7,295,673; 7,460,668; 7,515,710; 7,519,274”
ENGLISH
OPEN SOURCE SOFTWARE NOTICE
To obtain the source code under GPL, LGPL, MPL and other open source licenses, that is contained in this product, please visit http://opensource.lge.com.
In addition to the source code, all referred license terms, warranty disclaimers and copyright notices are available for download.
LG Electronics will also provide open source code to you on CD-ROM for a charge covering the cost of performing such distribution (such as the cost of media, shipping and handling) upon email request to opensource@lge.com. This offer is valid for three (3) years from the date on which you purchased the product.
ENGLISH
10 TABLE OF CONTENTS
TABLE OF CONTENTS
2 IMPORTANT SAFETY INSTRUCTIONS
7 Viewing 3D Imaging (For 3D models)
9 LICENSES
9OPEN SOURCE SOFTWARE NOTICE
10TABLE OF CONTENTS
11INSTALLATION PROCEDURE
11 ASSEMBLING AND PREPARING
11 Unpacking
17Optional Extras
18Parts and buttons
19Parts and buttons
21Lifting and moving the TV
22Setting up the TV
22 - Attaching the stand
29 - Mounting on a table
31- Mounting on a wall
32- Tidying cables
33MAKING CONNECTIONS
33Connecting to an antenna or cable
34Connecting to a HD receiver, DVD, or VCR player
34- HDMI Connection
35- Component Connection
36- Composite Connection
37Connecting to a PC
37 - HDMI Connection
37 Connecting to a USB
38 REMOTE CONTROL
42 WATCHING TV
42Connecting to the AC/DC adapter
42Turning the TV on for the first time
43USING THE USER GUIDE
44SPECIFICATIONS
47 MAINTENANCE
47 Cleaning Your TV
47 - Screen, frame, cabinet and stand
47 - Power cord
47 TROUBLESHOOTING
NOTE
yyImage shown may differ from your TV. yyYour TV’s OSD (On Screen Display) may differ slightly from that shown in this
manual.
yyThe available menus and options may differ from the input source or product model that you are using.
yyNew features may be added to this TV in the future.
ASSEMBLING AND PREPARING 11
INSTALLATION PROCEDURE
1 Open the package and make sure all the accessories are included.
2 Attach the stand to the TV set.
3 Connect an external device to the TV set.
ASSEMBLING AND PREPARING
Unpacking
Check your product box for the following items. If there are any missing accessories, contact the local dealer where you purchased your product. The illustrations in this manual may differ from the actual product and item.
NOTE
yyThe items supplied with your product may vary depending on the model.
yyProduct specifications or contents of this manual may be changed without prior notice due to upgrade of product functions.
yyFor an optimal connection, HDMI cables and USB devices should have bezels less than 10 mm (0.39 inches) thick and 18 mm (0.7 inches) width.
yyUse an extension cable that supports USB 2.0 if the USB cable or USB memory stick does not fit into your TV's USB port.
AA
*A 10 mm (0.39 inches) *B 18 mm (0.7 inches)
CAUTION
ENGLISH
yyDo not use any unapproved items to ensure the safety and product life span.
yyAny damages or injuries by using unapproved items are not covered by the warranty. yyIn case of some model, the thin film on screen is a part of TV, So don’t take it off.
ENGLISH
12 ASSEMBLING AND PREPARING
For 22LS3500
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Remote control, |
|
Owner’s manual |
|
Polishing cloth |
|||||
Batteries (AAA) |
|
|
|
|
|
(Depending on model) |
|||
(See p.38) |
|
|
|
|
|
Use this to remove dust |
|||
|
|
|
|
|
|
|
|
|
from the cabinet. |
|
|
|
|
|
|
|
|
|
|
Stand Body |
Stand Base |
|
Stand Screws |
|
(See p.22) |
(See p.22) |
|
2 EA, P4 x 16 |
|
|
|
|
|
(See p.22) |
|
|
|
|
|
Cable holder |
|
Power Cord |
|
AC/DC Adapter |
(See p.32) |
|
|
|
(See p.42) |
|
|
|
|
|
ASSEMBLING AND PREPARING 13
For 32LS3500
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Remote control, |
Owner’s manual |
|
Polishing cloth |
||||||
Batteries (AAA) |
|
|
|
|
(Depending on model) |
||||
(See p.38) |
|
|
|
|
Use this to remove dust |
||||
|
|
|
|
|
|
|
|
|
from the cabinet. |
|
|
|
|
|
|
|
|
|
|
Stand Body |
|
Stand Base |
|
Stand Screws |
(See p.23) |
|
(See p.23) |
|
4 EA, P4 x 16 |
|
|
|
|
4 EA, M4 x 14 |
|
|
|
|
(See p.23) |
|
|
|
|
|
Desk-mount Screw |
|
Cable holder |
|
Power Cord |
(See p.29) |
|
(See p.32) |
|
|
|
|
|
|
|
ENGLISH
ENGLISH
14 ASSEMBLING AND PREPARING
For CS460, LM3400, LS3400 series
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Remote control, |
|
Owner’s manual |
|
Polishing cloth |
|||||
Batteries (AAA) |
|
|
|
|
|
(Depending on model) |
|||
(See p.38, p.40) |
|
|
|
|
|
Use this to remove dust |
|||
|
|
|
|
|
|
|
|
|
from the cabinet. |
|
|
|
|
|
|
|
|
|
|
Stand Body |
|
Stand Base |
|
Stand Screws |
||||
(See p.24) |
|
(See p.24) |
|
8 EA, M4 x 20 |
||||
|
|
|
|
|
|
|
|
(See p.24) |
|
|
|
|
|
|
|
|
|
(For 32CS460, 32LM3400 |
|
(For 42CS460, 42LM3400 |
|
|
||||
32LS3400) |
|
42LS3400) |
|
|
||||
|
|
|
|
|
|
|
|
|
Protection cover |
|
Protection cover |
|
Desk-mount Screw |
(See p.28) |
|
(See p.28) |
|
(See p.29) |
|
|
|
|
|
|
|
(For 32/42LM3400) |
|
|
Power Cord |
|
Cinema 3D Glasses |
|
|
The number of 3D glasses |
|
|
may differ depending on the |
|
|
model or country. |
|
|
|
ASSEMBLING AND PREPARING 15
For LS3450 series
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Remote control, |
|
Owner’s manual |
|
Polishing cloth |
|||||||
Batteries (AAA) |
|
|
|
|
|
(Depending on model) |
|||||
(See p.38) |
|
|
|
|
|
Use this to remove dust |
|||||
|
|
|
|
|
|
|
|
|
|
|
from the cabinet. |
|
|
|
|
|
|
|
|
|
|
|
|
(for 32LS3450) |
|
(for 42LS3450) |
|
|
|||||||
|
|
|
|
|
|
|
|
|
|
|
|
Stand Body / Stand Base |
|
Stand Body / Stand Base |
|
Desk-mount Screw |
(See p.25) |
|
(See p.26) |
|
(See p.29) |
|
|
|
|
|
(for 32LS3450) |
|
(for 42LS3450) |
|
|
Stand Screws |
|
Stand Screws |
Power Cord |
|
2 EA, P4 x 16 |
|
4 EA, P4 x 16 |
|
|
4 EA, M4 x 20 |
|
4 EA, M4 x 14 |
|
|
(See p.25) |
|
(See p.26) |
|
|
|
|
|
|
|
(for 32LS3450) |
|
|
|
|
Protection cover |
|
Cable holder |
(See p.28) |
|
(See p.32) |
|
|
|
ENGLISH
ENGLISH
16 ASSEMBLING AND PREPARING
For CS560 series
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Remote control, |
|
Owner’s manual |
|
Polishing cloth |
|||||
Batteries (AAA) |
|
|
|
|
|
(Depending on model) |
|||
(See p.38) |
|
|
|
|
|
Use this to remove dust |
|||
|
|
|
|
|
|
|
|
|
from the cabinet. |
|
|
|
|
|
|
|
|
|
|
Stand Body |
|
Stand Base |
Stand Screws |
|||||
(See p.27) |
|
(See p.27) |
8 EA, M4 x 20 |
|||||
|
|
|
|
|
|
|
|
(See p.27) |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Protection cover |
|
Desk-mount Screw |
Power Cord |
|
(See p.28) |
|
(See p.29) |
|
|
|
|
|
|
|
ASSEMBLING AND PREPARING 17
Optional Extras
Optional extras can be changed or modified for quality improvement without any notification. Contact your dealer for buying these items.
These devices only work with certain models.
AG-F3**
Cinema 3D Glasses
The model name or design may be changed manufacturer’s circumstances or policies.
Compatibility |
CS460 |
CS560 |
LM3400 |
LS3400 |
|
|
|
|
|
AG-F3** Cinema 3D Glasses |
|
|
• |
|
ENGLISH
ENGLISH
18 ASSEMBLING AND PREPARING
Parts and buttons
For CS460, CS560, LS3400, LM3400 series
Screen
Remote control and intelligent1 sensors
Power indicator
Speakers
OK |
SETTINGS |
INPUT |
|
|
For CS460, LM3400, |
|
|
|
LS3400 series |
||||
|
||||||
|
||||||
|
|
|
|
|
Touch buttons2 |
|
|
|
|
|
|
||
|
|
|
|
|
For CS560 series |
|
|
|
|
|
|
||
OK |
SETTINGS |
INPUT |
||||
|
||||||
|
|
|
|
|
|
|
Touch button2 |
Description |
/ I |
Turns the power on or off. |
|
|
|
|
INPUT |
Changes the input source. |
|
|
|
|
SETTINGS |
Accesses the Home menu, or saves your input and exits the menus. |
|
|
|
|
OK |
Selects the highlighted menu option or confirms an input |
|
|
|
|
- |
+ |
Adjusts the volume level. |
|
|
|
v |
^ |
Scrolls through the saved channels. |
1Intelligent sensor - Adjusts the image quality and brightness based on the surrounding environment.
2All of the buttons are touch sensitive and can be operated through simple touch with your finger.
ASSEMBLING AND PREPARING 19
Parts and buttons
For LS3450 series
Screen |
buttons |
OK
SETTINGS
INPUT
Speakers
Remote control and intelligent sensors1
Power indicator
ENGLISH
Touch button2 |
Description |
Turns the power on or off.
INPUT |
Changes the input source. |
|
|
|
|
SETTINGS S |
Accesses the main menus, or saves your input and exits the menus. |
|
|
|
|
OK |
|
Selects the highlighted menu option or confirms an input. |
|
|
|
- |
+ |
Adjusts the volume level. |
|
|
|
v |
^ |
Scrolls through the saved channels. |
1 Intelligent sensor - Adjusts the image quality and brightness based on the surrounding environment. 2 All of the buttons are touch sensitive and can be operated through simple touch with your finger.
20 ASSEMBLING AND PREPARING
For LS3500 series
ENGLISH
Screen
Remote control and intelligent1 sensors
Power indicator
Speakers
OK |
SETTINGS INPUT |
Touch buttons2 |
|
Touch button2 |
Description |
/ I |
Turns the power on or off. |
|
|
|
|
INPUT |
Changes the input source. |
|
|
|
|
SETTINGS |
Accesses the Home menu, or saves your input and exits the menus. |
|
|
|
|
OK |
Selects the highlighted menu option or confirms an input |
|
|
|
|
- |
+ |
Adjusts the volume level. |
|
|
|
v |
^ |
Scrolls through the saved channels. |
1Intelligent sensor - Adjusts the image quality and brightness based on the surrounding environment.
2All of the buttons are touch sensitive and can be operated through simple touch with your finger.
ASSEMBLING AND PREPARING 21
Lifting and moving the TV
When moving or lifting the TV, read the following to prevent the TV from being scratched or damaged and for safe transportation regardless of its type and size.
CAUTION
yyAvoid touching the screen at all times, as this may result in damage to the screen.
yyIt is recommended to move the TV in the box or packing material that the TV originally came in.
yyBefore moving or lifting the TV, disconnect the power cord and all cables.
yyWhen holding the TV, the screen should face away from you to avoid damage.
yyHold the top and bottom of the TV frame firmly. Make sure not to hold the transparent part, speaker, or speaker grill area.
yyWhen transporting a large TV, there should be at least 2 people.
yyWhen transporting the TV by hand, hold the TV as shown in the following illustration.
yyWhen transporting the TV, do not expose the TV to jolts or excessive vibration.
yyWhen transporting the TV, keep the TV upright, never turn the TV on its side or tilt towards the left or right.
ENGLISH
ENGLISH
22 ASSEMBLING AND PREPARING
Setting up the TV
Put your TV on a pedestal stand and mount the TV on a table or wall.
Attaching the stand
If you are not mounting the TV to a wall, use the following instructions to attach the stand.
For 22LS3500
1 |
|
2 |
|
|
|
Stand Body
Stand Base
3
NOTE
yyRemove the stand before installing the TV on a wall mount by performing the stand attachment in reverse.
CAUTION
yyWhen attaching the stand to the TV set, place the screen facing down on a cushioned table or flat surface to protect the screen from scratches.
2 EA
P4 x 16
CAUTION
yyMake sure that the screws are fastened completely. (If they are not fastened securely enough, the TV may tilt forward after being installed.)
yyDo not fasten the screws with too much force; otherwise they may be worn out and get loosened.
ASSEMBLING AND PREPARING 23
For 32LS3500
1 |
|
2 |
|
|
|
Stand Body
4 EA
P4 x 16
|
CAUTION |
|
|
yyWhen attaching the stand to the TV |
|
Stand Base |
set, place the screen facing down on a |
|
cushioned table or flat surface to protect |
||
|
||
Front |
the screen from scratches. |
3
4 EA
M4 x 14
ENGLISH
NOTE
yyRemove the stand before installing the TV on a wall mount by performing the stand attachment in reverse.
CAUTION
yyMake sure that the screws are fastened completely. (If they are not fastened securely enough, the TV may tilt forward after being installed.)
yyDo not fasten the screws with too much force; otherwise they may be worn out and get loosened.
ENGLISH
24 ASSEMBLING AND PREPARING
For CS460, LM3400, LS3400 series
1 |
|
2 |
|
|
|
4 EA
M4 x 20
Stand Body
Front
Stand Base
3
CAUTION
yyWhen attaching the stand to the TV set, place the screen facing down on a cushioned table or flat surface to protect the screen from scratches.
4 EA
M4 x 20
CAUTION
yyMake sure that the screws are fastened completely. (If they are not fastened securely enough, the TV may tilt forward after being installed.)
yyDo not fasten the screws with too much force; otherwise they may be worn out and get loosened.
ASSEMBLING AND PREPARING 25
For 32LS3450
1
2EA
P4 x 16
Stand Body
Stand Base
3
NOTE
yyRemove the stand before installing the TV on a wall mount by performing the stand attachment in reverse.
2
CAUTION
yyWhen attaching the stand to the TV set, place the screen facing down on a cushioned table or flat surface to protect the screen from scratches.
4 EA
M4 x 20
CAUTION
yyMake sure that the screws are fastened completely. (If they are not fastened securely enough, the TV may tilt forward after being installed.)
yyDo not fasten the screws with too much force; otherwise they may be worn out and get loosened.
ENGLISH
ENGLISH
26 ASSEMBLING AND PREPARING
For 42LS3450
1
4EA
P4 x 16
Stand Body
Stand Base
3
NOTE
yyRemove the stand before installing the TV on a wall mount by performing the stand attachment in reverse.
2
CAUTION
yyWhen attaching the stand to the TV set, place the screen facing down on a cushioned table or flat surface to protect the screen from scratches.
4EA
M4 x 14
CAUTION
yyMake sure that the screws are fastened completely. (If they are not fastened securely enough, the TV may tilt forward after being installed.)
yyDo not fasten the screws with too much force; otherwise they may be worn out and get loosened.
ASSEMBLING AND PREPARING 27
For CS560 series
1
4 EA
M4 x 20
Stand Body
Front
Stand Base
3
2
CAUTION
yyWhen attaching the stand to the TV set, place the screen facing down on a cushioned table or flat surface to protect the screen from scratches.
4 EA
M4 x 20
CAUTION
yyMake sure that the screws are fastened completely. (If they are not fastened securely enough, the TV may tilt forward after being installed.)
yyDo not fasten the screws with too much force; otherwise they may be worn out and get loosened.
ENGLISH
28 ASSEMBLING AND PREPARING
To detach the stand,
(Depending on model)
4 EA
M4 x 20
CAUTION
yyWhen attaching the stand to the TV set, place the screen facing down on a cushioned table or flat surface to protect the screen from scratches.
ENGLISH
NOTE
yyThis will protect the opening from accumulating dust and dirt.
yyWhen installing the wall mounting bracket, use the Protection cover.
Protection cover
|
|
ASSEMBLING AND PREPARING 29 |
|||
Mounting on a table |
|
|
|
|
|
|
Securing the TV to a table |
|
|
||
|
(For 32/42CS460, 32/42CS560, 32/42LM3400, |
||||
1 Lift and tilt the TV into its upright position on a |
32/42LS3400, 32/42LS3450, 32LS3500) |
||||
table. |
Fix the TV to a table to prevent from tilting |
||||
- Leave a 10 cm (minimum) space from the |
forward, damage, and potential injury. |
||||
Mount the TV on a table, and then insert and |
|||||
wall for proper ventilation. |
|||||
tighten the supplied screw on the rear of the |
|||||
|
|||||
|
stand. |
|
10 cm |
|
10 cm |
10 |
cm |
|
||
|
|
|
|
10 cm |
2 Connect the power cord to a wall outlet.
CAUTION
y not place the TV near or on sources of heat, as this may result in fire or other damage.
Adjusting the angle of the TV to suit view
(Depending on model)
Swivel 20 degrees to the left or right and adjust the angle of the TV to suit your view.
WARNING
yyTo prevent TV from falling over, the TV should be securely attached to the floor/ wall per installation instructions. Tipping, shaking, or rocking the TV may cause injury.
20 |
20 |
CAUTION
yyWhen adjusting the angle of the TV, watch out for your fingers.
-Personal injury may occur if hands or fingers are pinched. If the product is tilted too much, it may fall, causing damage or injury.
ENGLISH
