JLG 80SL Operator Manual

Download

Operation, Safety, and

Maintenance Manual

Keep this manual with the machine at all times.

Model

80SL

ANSI

P/N - 3121324

June 1, 2009

FOREWORD

This manual is a very important tool! Keep it with the machine at all times.

The purpose of this manual is to provide owners, users, operators, lessors, and lessees with the precautions and operating procedures essential for the safe and proper machine operation for its intended purpose.

Due to continuous product improvements, JLG Industries, Inc. reserves the right to make specification changes without prior notification. Contact JLG Industries, Inc. for updated information.

3121324 – JLG Lift – a

FOREWORD

SAFETY ALERT SYMBOLS AND SAFETY SIGNAL WORDS

This is the Safety Alert Symbol. It is used to alert you to the potential personal injury hazards. Obey all safety messages that follow this symbol to avoid possible injury or death

INDICATES AN IMMINENTLY HAZARDOUS SITUATION. IF NOT AVOIDED, WILL RESULT IN SERIOUS INJURY OR DEATH. THIS DECAL WILL HAVE A RED BACKGROUND.

INDICATES A POTENTIALITY HAZARDOUS SITUATION. IF NOT AVOIDED, COULD DECAL WILL HAVE AN ORANGE BACKGROUND.

RESULT IN SERIOUS INJURY OR DEATH. THIS

INDICATES A POTENTIALITY HAZARDOUS SITUATION. IF NOT AVOIDED, MAY RESULT IN MINOR OR MODERATE INJURY. IT MAY ALSO ALERT AGAINST UNSAFE PRACTICES. THIS DECAL WILL HAVE A YELLOW BACKGROUND.

b – JLG Lift – 3121324

THIS PRODUCT MUST COMPLY WITH ALL SAFETY RELATED BULLETINS. CONTACT JLG INDUSTRIES, INC. OR THE LOCAL AUTHORIZED JLG REPRESENTATIVE FOR INFORMATION REGARDING SAFETYRELATED BULLETINS WHICH MAY HAVE BEEN ISSUED FOR THIS PRODUCT.

NOTICE

JLG INDUSTRIES, INC. SENDS SAFETY RELATED BULLETINS TO THE OWNER OF RECORD OF THIS MACHINE. CONTACT JLG INDUSTRIES, INC. TO ENSURE THAT THE CURRENT OWNER RECORDS ARE UPDATED AND ACCURATE.

NOTICE

JLG INDUSTRIES, INC. MUST BE NOTIFIED IMMEDIATELY IN ALL INSTANCES WHERE JLG PRODUCTS HAVE BEEN INVOLVED IN AN ACCIDENT INVOLVING BODILY INJURY OR DEATH OF PERSONNEL OR WHEN SUBSTANTIAL DAMAGE HAS OCCURRED TO PERSONAL PROPERTY OR THE JLG PRODUCT.

For:

• Accident Reporting

• Product Safety Publications

• Current Owner Updates

• Questions Regarding Product Safety

• Standards and Regulations Compliance Information

• Questions Regarding Special Product Applications

• Questions Regarding Product Modifications

Contact:

Product Safety and Reliability Department JLG Industries, Inc. 13224 Fountainhead Plaza Hagerstown, MD 21742

or Your Local JLG Office (See addresses on manual rear cover)

In USA:

Toll Free: 877-JLG-SAFE (877-554-7233)

Outside USA:

Phone: 240-420-2661 E-mail: ProductSafety@JLG.com

FOREWORD

3121324 – JLG Lift – c

FOREWORD

REVISION LOG

Original Issue . . . . . .. . . . . . . . . . . . . . . September 29, 2006

Revised. . . . . . . . . . .. . . . . . . . . . . . . . . October 25, 2006

Revised. . . . . . . . . . .. . . . . . . . . . . . . . . December 21, 2006

Revised. . . . . . . . . . .. . . . . . . . . . . . . . . February 22, 2007

Revised. . . . . . . . . . .. . . . . . . . . . . . . . . March 28, 2007

Revised. . . . . . . . . . .. . . . . . . . . . . . . . . May 13, 2008

Revised. . . . . . . . . . .. . . . . . . . . . . . . . . October 23, 2008

Revised. . . . . . . . . . .. . . . . . . . . . . . . . . June 1, 2009

d – JLG Lift – 3121324

TABLE OF CONTENTS

SECTION - PARAGRAPH, SUBJECT PAGE SECTION - PARAGRAPH, SUBJECT PAGE

SECTION - 1 - SAFETY PRECAUTIONS

1.1 GENERAL . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-1

1.2 PRE-OPERATION . . . . . . . . . . . . . . . . . . . . . . . . . . .1-1

Operator Training and Knowledge. . . . . . . . . . . 1-1

Workplace Inspection. . . . . . . . . . . . . . . . . . . . . 1-2

Machine Inspection . . . . . . . . . . . . . . . . . . . . . . 1-3

1.3 OPERATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-3

General . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-3

Trip and Fall Hazards . . . . . . . . . . . . . . . . . . . . . 1-4

Electrocution Hazards . . . . . . . . . . . . . . . . . . . . 1-5

Tipping Hazards . . . . . . . . . . . . . . . . . . . . . . . . . 1-7

Crushing and Collision Hazards. . . . . . . . . . . . . 1-8

1.4 TOWING, LIFTING, AND HAULING . . . . . . . . . . . . .1-9

1.5 MAINTENANCE . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-9

General . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-9

Maintenance Hazards. . . . . . . . . . . . . . . . . . . . 1-10

Battery Hazards . . . . . . . . . . . . . . . . . . . . . . . . 1-10

SECTION - 2 - USER RESPONSIBILITIES, MACHINE PREPARATION AND INSPECTION

2.1 PERSONNEL TRAINING . . . . . . . . . . . . . . . . . . . . .2-1

Operator Training . . . . . . . . . . . . . . . . . . . . . . . . 2-1

Training Supervision. . . . . . . . . . . . . . . . . . . . . . 2-1

Operator Responsibility . . . . . . . . . . . . . . . . . . . 2-1

2.2 PREPARATION, INSPECTION, AND

MAINTENANCE . . . . . . . . . . . . . . . . . . . . . . . . . . .2-2

2.3 PRE-START INSPECTION. . . . . . . . . . . . . . . . . . . . 2-4

Function Check . . . . . . . . . . . . . . . . . . . . . . . . . . 2-5

Limit Switch Checks . . . . . . . . . . . . . . . . . . . . . . 2-6

General . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-10

SECTION - 3 - USER RESPONSIBILITIES AND MACHINE CONTROL

3.1 GENERAL . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-1

3.2 OPERATING CHARACTERISTICS AND

LIMITATIONS. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-1

General . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-1

Placards. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-1

Capacities . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-2

3.3 CONTROLS AND INDICATORS . . . . . . . . . . . . . . . 3-2

Ground Control Station . . . . . . . . . . . . . . . . . . . . 3-2

Engine Control. . . . . . . . . . . . . . . . . . . . . . . . . . . 3-3

Main Terminal Box. . . . . . . . . . . . . . . . . . . . . . . . 3-5

Ground Control Console . . . . . . . . . . . . . . . . . . . 3-7

3.4 PLATFORM CONTROL CONSOLE. . . . . . . . . . . . . 3-9

SECTION - 4 - MACHINE OPERATION

4.1 DESCRIPTION. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-1

General Description of the Functions and

Components. . . . . . . . . . . . . . . . . . . . . . . . . . . 4-1

4.2 STARTING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-1

4.3 LIFTING AND LOWERING . . . . . . . . . . . . . . . . . . . 4-2

3121324 – JLG Lift – i

TABLE OF CONTENTS

SECTION - PARAGRAPH, SUBJECT PAGE SECTION - PARAGRAPH, SUBJECT PAGE

4.4 AUTOMATIC SELF LEVELING CHASSIS . . . . . . . . 4-3

4.5 DRIVING THE MACHINE FROM THE PLATFORM . 4-4

4.6 STEERING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-6

4.7 HYDRAULIC PLATFORM EXTENSION . . . . . . . . . . 4-6

4.8 EMERGENCY LOWERING - MANUAL DESCENT . 4-6

4.9 PARKING AND STOWING . . . . . . . . . . . . . . . . . . . . 4-6

4.10 TIE DOWN/LIFT LUGS. . . . . . . . . . . . . . . . . . . . . . . 4-7

Tie Down . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-7

4.11 TRANSPORT AND STORAGE OF THE MACHINE . 4-8

Platform Rail Lowering Procedure . . . . . . . . . . . 4-9

Rail Raising Procedure . . . . . . . . . . . . . . . . . . 4-14

SECTION - 5 - EMERGENCY PROCEDURES

5.1 GENERAL . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-1

Emergency Stop Switch . . . . . . . . . . . . . . . . . . 5-1

Platform Caught Overhead . . . . . . . . . . . . . . . . 5-1

Righting of Tipped Machine. . . . . . . . . . . . . . . . 5-1

Post-Incident Inspection . . . . . . . . . . . . . . . . . . 5-1

5.2 EMERGENCY OPERATION. . . . . . . . . . . . . . . . . . . 5-2

Use of Ground Controls. . . . . . . . . . . . . . . . . . . 5-2

Operator Unable to Control Machine . . . . . . . . 5-2

Incident Notification . . . . . . . . . . . . . . . . . . . . . . 5-2

5.3 MANUAL PROCEDURES. . . . . . . . . . . . . . . . . . . . . 5-3

Manual Platform Deck Retraction . . . . . . . . . . . 5-3

Manual Descent . . . . . . . . . . . . . . . . . . . . . . . . . 5-4

5.4 EMERGENCY TOWING . . . . . . . . . . . . . . . . . . . . . .5-6

Prior to Towing . . . . . . . . . . . . . . . . . . . . . . . . . . 5-6

SECTION - 6 - GENERAL SPECIFICATIONS AND OPERATOR MAINTENANCE

6.1 INTRODUCTION. . . . . . . . . . . . . . . . . . . . . . . . . . . .6-1

6.2 OPERATING SPECIFICATIONS . . . . . . . . . . . . . . .6-2

Dimensional Data . . . . . . . . . . . . . . . . . . . . . . . 6-3

Capacities . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-3

Tires . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-3

Engine . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-4

Batteries . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-4

Component Weights. . . . . . . . . . . . . . . . . . . . . . 6-4

Lubrication . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-7

6.3 OPERATOR MAINTENANCE . . . . . . . . . . . . . . . . . .6-8

6.4 TIRES AND WHEELS . . . . . . . . . . . . . . . . . . . . . . .6-13

Tire Damage . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-13

Tire Replacement . . . . . . . . . . . . . . . . . . . . . . . 6-14

Wheel Replacement . . . . . . . . . . . . . . . . . . . . . 6-14

Wheel Installation . . . . . . . . . . . . . . . . . . . . . . . 6-15

SECTION - 7 - INSPECTION AND REPAIR LOG

ii – JLG Lift – 3121324

TABLE OF CONTENTS

SECTION - PARAGRAPH, SUBJECT PAGE SECTION - PARAGRAPH, SUBJECT PAGE

LIST OF FIGURES

2-1. Limit Switch Locations . . . . . . . . . . . . . . . . . . . . . . .2-8

2-2. Walk - Around Inspection Diagram . . . . . . . . . . . . .2-9

2-3. Walk - Around Inspection Points (Sheet 1) . . . . . .2-10

2-4. Walk - Around Inspection Points (Sheet 2) . . . . . .2-11

3-1. Ground Control Stations . . . . . . . . . . . . . . . . . . . . .3-2

3-2. Engine Control Box . . . . . . . . . . . . . . . . . . . . . . . . .3-3

3-3. Main Terminal Box . . . . . . . . . . . . . . . . . . . . . . . . . .3-5

3-4. Ground Control Console . . . . . . . . . . . . . . . . . . . . .3-7

3-5. Platform Control Console. . . . . . . . . . . . . . . . . . . . .3-9

3-6. Decal Location (ANSI) - Sheet 1 of 2 . . . . . . . . . . .3-12

3-7. Decal Location (ANSI) - Sheet 2 of 2 . . . . . . . . . . .3-13

3-8. Decal Location (CSA) - Sheet 1 of 2 . . . . . . . . . . .3-14

3-9. Decal Location (CSA) - Sheet 2 of 2 . . . . . . . . . . .3-15

4-1. Grade and Sideslope . . . . . . . . . . . . . . . . . . . . . . . .4-5

4-2. Lifting and Tie Down Points . . . . . . . . . . . . . . . . . . .4-7

4-3. Rail Lowering Tool . . . . . . . . . . . . . . . . . . . . . . . . . .4-9

5-1. Drive Disconnect Hub . . . . . . . . . . . . . . . . . . . . . . .5-6

6-1. Engine Operating Temperature Specifications

(Deutz) - Sheet 1 of 2 . . . . . . . . . . . . . . . . . . . . . .6-5

6-2. Engine Operating Temperature Specifications

(Deutz) - Sheet 2 of 2 . . . . . . . . . . . . . . . . . . . . . .6-6

6-3. Operator Maintenance and Lubrication Diagram . .6-8

LIST OF TABLES

1-1 Minimum Approach Distances (M.A.D.) . . . . . . . . . 1-6

2-1 Inspection and Maintenance Table. . . . . . . . . . . . . 2-3

2-2 Cutout Switch Limits . . . . . . . . . . . . . . . . . . . . . . . . 2-7

3-1 Decal Legend . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-16

6-1 Operating Specifications. . . . . . . . . . . . . . . . . . . . . 6-2

6-2 Dimensional Data . . . . . . . . . . . . . . . . . . . . . . . . . . 6-3

6-3 Capacities . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-3

6-4 Tire Specifications. . . . . . . . . . . . . . . . . . . . . . . . . . 6-3

6-5 Engine Specifications . . . . . . . . . . . . . . . . . . . . . . . 6-4

6-6 Engine Battery Specifications. . . . . . . . . . . . . . . . . 6-4

6-7 Component Weights . . . . . . . . . . . . . . . . . . . . . . . . 6-4

6-8 Hydraulic Oil . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-7

6-9 Lubrication Specifications. . . . . . . . . . . . . . . . . . . . 6-7

7-1 Inspection and Repair Log . . . . . . . . . . . . . . . . . . . 7-1

3121324 – JLG Lift – iii

TABLE OF CONTENTS

SECTION - PARAGRAPH, SUBJECT PAGE SECTION - PARAGRAPH, SUBJECT PAGE

This page left blank intentionally.

iv – JLG Lift – 3121324

1.1 GENERAL

SECTION 1 - SAFETY PRECAUTIONS

SECTION 1. SAFETY PRECAUTIONS

This section outlines the necessary precautions for proper and safe machine usage and maintenance. In order to promote proper machine usage, it is mandatory that a daily routine is established based on the content of this manual. A maintenance program, using the information provided in this manual and the Service and Maintenance Manual, must also be established by a qualified person and must be followed to ensure that the machine is safe to operate.

The owner/user/operator/lessor/lessee of the machine should not accept operating responsibility until this manual has been read, training is accomplished, and operation of the machine has been completed under the supervision of an experienced and qualified operator.

These sections contain the responsibilities of the owner, user, operator, lessor, and lessee concerning safety, training, inspection, maintenance, application, and operation.If there are any questions with regard to safety, training, inspection, maintenance, application, and operation, please contact JLG Industries, Inc. (“JLG”).

FAILURE TO COMPLY WITH THE SAFETY PRECAUTIONS LISTED IN THIS MANUAL COULD RESULT IN MACHINE DAMAGE, PROPERTY DAMAGE, PERSONAL INJURY OR DEATH.

1.2 PRE-OPERATION

Operator Training and Knowledge

• The Operators and Safety Manual must be read in its entirety before operating the machine. For clarification, questions, or additional information regarding any portions of this manual, contact JLG Industries, Inc.

3121324 – JLG Lift – 1-1

SECTION 1 - SAFETY PRECAUTIONS

• An operator must not accept operating responsibilities until adequate training has been given by competent and authorized persons.

• Allow only those authorized and qualified personnel to operate the machine who have demonstrated that they understand the safe and proper operation and maintenance of the unit.

• Read, understand, and obey all DANGERS, WARNINGS, CAUTIONS, and operating instructions on the machine and in this manual.

• Ensure that the machine is to be used in a manner which is within the scope of its intended application as determined by JLG.

• All operating personnel must be familiar with the emergency controls and emergency operation of the machine as specified in this manual.

• Read, understand, and obey all applicable employer, local, and governmental regulations as they pertain to your utilization and application of the machine.

Workplace Inspection

• Precautions to avoid all hazards in the work area must be taken by the user before operation of the machine.

• Do not operate or raise the platform from a position on trucks, trailers, railway cars, floating vessels, scaffolds or other equipment unless the application is approved in writing by JLG.

• Before operation, check work area for overhead hazards such as electric lines, bridge cranes, and other potential overhead obstructions.

• Check floor surfaces for holes, bumps, drop-offs, obstructions, debris, concealed holes, and other potential hazards.

• Check the work area for hazardous locations. Do not operate the machine in hazardous environments unless approved for that purpose by JLG.

• Ensure that the ground conditions are adequate to support the maximum tire load indicated on the tire load decals located on the chassis adjacent to each wheel.

• Do not operate the machine when wind conditions exceed 28 mph (12.5 m/s).

• This machine can be operated in nominal ambient tem-

peratures of 5 optimize operation outside of this temperature range.

F to 113oF (-15oC to 45oC). Consult JLG to

1-2 – JLG Lift – 3121324

SECTION 1 - SAFETY PRECAUTIONS

Machine Inspection

• Do not operate this machine until the inspections and functional checks have been performed as specified in Section 2 of this manual.

• Do not operate this machine until it has been serviced and maintained according to the maintenance and inspection requirements as specified in the machine’s Service and Maintenance Manual.

• Ensure all safety devices are operating properly. Modification of these devices is a safety violation.

MODIFICATION OR ALTERATION OF AN AERIAL WORK PLATFORM SHALL BE MADE ONLY WITH PRIOR WRITTEN PERMISSION FROM THE MANUFACTURER

• Do not operate any machine on which the safety or instruction placards or decals are missing or illegible.

• Check the machine for modifications to original components. Ensure that any modifications have been approved by JLG.

• Avoid accumulation of debris on platform deck. Keep mud, oil, grease, and other slippery substances from footwear and platform deck.

1.3 OPERATION

General

• Do not use the machine for any purpose other than positioning personnel, their tools, and equipment.

• Before operation, the user must be familiar with the machine capabilities and operating characteristics of all functions.

• Never operate a malfunctioning machine. If a malfunction occurs, shut down the machine. Remove the unit from service and notify the proper authorities.

• Do not remove, modify, or disable any safety devices.

• Never slam a control switch or lever through neutral to an opposite direction. Always return switch to neutral and stop before moving the switch to the next function. Operate controls with slow and even pressure.

• Do not allow personnel to tamper with or operate the machine from the ground with personnel in the platform, except in an emergency.

• Do not carry materials directly on platform railing unless approved by JLG.

• When two or more persons are in the platform, the operator shall be responsible for all machine operations.

3121324 – JLG Lift – 1-3

SECTION 1 - SAFETY PRECAUTIONS

• Always ensure that power tools are properly stowed and never left hanging by their cord from the platform work area.

• Do not assist a stuck or disabled machine by pushing or pulling except by pulling at the chassis tie-down lugs.

• Stow scissor arm assembly and shut off all power before leaving machine.

Trip and Fall Hazards

• JLG Industries, Inc. recommends that all persons in the platform wear a full body harness with a lanyard attached to an authorized lanyard anchorage point while operating this machine. For further information regarding fall protection requirements on JLG products, contact JLG Industries, Inc.

• Prior to operation, ensure all gates and rails are fastened and secured in their proper position. Identify the designated lanyard anchorage point(s) at the platform and securely attach the lanyard. Attach only one (1) lanyard per lanyard anchorage point.

1-4 – JLG Lift – 3121324

SECTION 1 - SAFETY PRECAUTIONS

• Keep both feet firmly positioned on the platform floor at all times. Never position ladders, boxes, steps, planks, or similar items on unit to provide additional reach for any purpose.

• Never use the scissor arm assembly to gain access to or leave the platform.

• Use extreme caution when entering or leaving platform. Ensure that the scissor arm assembly is fully lowered. Face the machine when entering or leaving the platform. Always maintain “three point contact” with the machine, using two hands and one foot or two feet and one hand at all times during entry and exit.

• Keep oil, mud, and slippery substances cleaned from footwear and the platform floor.

Electrocution Hazards

• This machine is not insulated and does not provide protection from contact or proximity to electrical current.

3121324 – JLG Lift – 1-5

SECTION 1 - SAFETY PRECAUTIONS

Table 1-1.Minimum Approach Distances (M.A.D.)

• Maintain safe clearance from electrical lines, apparatus, or any energized (exposed or insulated) parts in accordance with the Minimum Approach Distance (M.A.D.) as specified in Table 1-1, Minimum Approach Distances (M.A.D.).

• Allow for machine movement and electrical line swaying.

Voltage Range

(Phase to Phase)

0 to 50KV 10 (3)

Over 50 KV to 200 KV 15 (5)

Over 200 KV to 350 KV 20 (6)

Over 350 KV to 500 KV 25 (8)

Over 500 KV to 750 KV 35 (11)

Over 750 KV to 1000 KV 45 (14)

NOTE: This requirement shall apply except where

employer, local or governmental regulations are more stringent.

• Maintain a clearance of at least 10 ft (3 m) between any part of the machine and its occupants, their tools, and their equipment from any electrical line or apparatus carrying up to 50,000 volts. One foot additional clearance is required for every additional 30,000 volts or less.

• The minimum approach distance may be reduced if insulating barriers are installed to prevent contact, and the barriers are rated for the voltage of the line being guarded. These barriers shall not be part of (or attached to) the machine. The minimum approach distance shall be

MINIMUM APPROACH DISTANCE

in Feet (Meters)

1-6 – JLG Lift – 3121324

SECTION 1 - SAFETY PRECAUTIONS

reduced to a distance within the designed working dimensions of the insulating barrier. This determination shall be made by a qualified person in accordance with the employer, local, or governmental requirements for work practices near energized equipment.

DO NOT MANEUVER MACHINE OR PERSONNEL INSIDE PROHIBITED ZONE (MAD). ASSUME ALL ELECTRICAL PARTS AND WIRING ARE ENERGIZED UNLESS KNOWN OTHERWISE.

Tipping Hazards

• Ensure that the ground conditions are adequate to support the maximum tire load indicated on the tire load decals located on the chassis adjacent to each wheel. Do not travel on unsupported surfaces.

• The user should be familiar with the driving surface before driving. Do not exceed the allowable sideslope and grade while driving.

• Do not elevate platform or drive with platform elevated while on or near a sloping, uneven, or soft surface. Ensure machine is positioned on a firm, level and uniformly supported surface before elevating platform or driving with the platform in the elevated position.

• Before driving on floors, bridges, trucks, and other surfaces, check allowable capacity of the surfaces.

• Never exceed the maximum work load as specified on the platform. Keep all loads within the confines of the platform, unless authorized by JLG.

3121324 – JLG Lift – 1-7

SECTION 1 - SAFETY PRECAUTIONS

• Keep the chassis of the machine a minimum of 2 ft (0.6 m) from holes, bumps, drop-offs, obstructions, debris, concealed holes, and other potential hazards at the ground level.

• Never attempt to use the machine as a crane. Do not tieoff machine to any adjacent structure. Never attach wire, cable, or any similar items to platform.

• Do not operate the machine when wind conditions exceed the maximum allowable wind speed.

• Do not cover the platform sides or carry large surface-area items in the platform when operating outdoors. The addition of such items increases the exposed wind area of the machine.

• Do not increase the platform size with unauthorized deck extensions or attachments.

• If scissor arm assembly or platform is caught so that one or more wheels are off the ground, all persons must be removed before attempting to free the machine. Use cranes, forklift trucks, or other appropriate equipment to stabilize machine and remove personnel.

Crushing and Collision Hazards

• Approved head gear must be worn by all operating and ground personnel.

• Keep hands and limbs out of the scissor arm assembly during operation.

• Watch for obstructions around machine and overhead when driving. Check clearances above, on sides, and bottom of platform when lifting or lowering platform.

• During operation, keep all body parts inside platform railing.

• Always post a lookout when driving in areas where vision is obstructed.

• Keep non-operating personnel at least 6 ft (1.8 m) away from machine during all driving operations.

• Under all travel conditions, the operator must limit travel speed according to conditions of ground surface, conges-

1-8 – JLG Lift – 3121324

SECTION 1 - SAFETY PRECAUTIONS

tion, visibility, slope, location of personnel, and other factors causing hazards of collision or injury to personnel.

• Be aware of stopping distances in all drive speeds. When driving in high speed, switch to low speed before stopping. Travel grades in low speed only.

• Do not use high speed drive in restricted or close quarters or when driving in reverse.

• Exercise extreme caution at all times to prevent obstacles from striking or interfering with operating controls and persons in the platform.

• Ensure that operators of other overhead and floor level machines are aware of the aerial work platform’s presence. Disconnect power to overhead cranes. Barricade floor area if necessary.

• Avoid operating over ground personnel. Warn personnel not to work, stand, or walk under a raised platform. Position barricades on floor as necessary.

1.4 TOWING, LIFTING, AND HAULING

• Never allow personnel in platform while towing, lifting, or hauling.

• This machine should not be towed, except in the event of emergency, malfunction, power failure, or loading/unloading. Refer to emergency towing procedures.

• Ensure platform is fully retracted and completely empty of tools prior to towing, lifting or hauling.

• Refer to Section 4 for lifting information.

1.5 MAINTENANCE

General

This section contains general safety precautions which must be observed during maintenance of this machine. Additional precautions to be observed during machine maintenance are inserted at the appropriate points in this maunual and in the Service and Maintenance Manual. It is of utmost importance that maintenance personnel pay strict attention to these precautions to avoid possible injury to personnel or damage to the machine or property. A maintenance program must be established by a qualified person and must be followed to ensure that the machine is safe.

3121324 – JLG Lift – 1-9

SECTION 1 - SAFETY PRECAUTIONS

Maintenance Hazards

• Shut off power to all controls and ensure that all operating systems are secured from inadvertent motion prior to performing any adjustments or repairs.

• Never work under an elevated platform until it has been fully lowered to the full down position, if possible, or otherwise supported and restrained from movement with appropriate safety props, blocking, or overhead supports.

• Always relieve hydraulic pressure from all hydraulic circuits before loosening or removing hydraulic components.

• Always disconnect batteries when servicing electrical components or when performing welding on the machine.

• Shut down the engine (if equipped) while fuel tanks are being filled.

• Ensure replacement parts or components are identical or equivalent to original parts or components.

• Never attempt to move heavy parts without the aid of a mechanical device. Do not allow heavy objects to rest in an unstable position. Ensure adequate support is provided when raising components of the machine.

• Remove all rings, watches, and jewelry when performing any maintenance. Do not wear loose fitting clothing or

long hair unrestrained which may become caught or entangled in equipment.

• Use only clean approved non-flammable cleaing solvents.

• Never alter, remove, or substitute any items such as counterweights, tires, batteries, platforms or other items that may reduce or affect the overall weight or stability of the machine.

• Reference the Service and Maintenance Manual for the weights of critical stability items.

MODIFICATION OR ALTERATION OF AN AERIAL WORK PLATFORM SHALL BE MADE ONLY WITH PRIOR WRITTEN PERMISSION FROM THE MANUFACTURER.

Battery Hazards

• Always disconnect batteries when servicing electrical components or when performing welding on the machine.

• Do not allow smoking, open flame, or sparks near battery during charging or servicing.

• Do not contact tools or other metal objects across the battery terminals.

1-10 – JLG Lift – 3121324

• Always wear hand, eye, and face protection when servicing batteries. Ensure that battery acid does not come in contact with skin or clothing.

BATTERY FLUID IS HIGHLY CORROSIVE. AVOID CONTACT WITH SKIN AND CLOTHING AT ALL TIMES. IMMEDIATELY RINSE ANY CONTACTED AREA WITH CLEAN WATER AND SEEK MEDICAL ATTENTION.

• Charge batteries only in a well ventilated area.

• Avoid overfilling the battery fluid level. Add distilled water to batteries only after the batteries are fully charged.

SECTION 1 - SAFETY PRECAUTIONS

3121324 – JLG Lift – 1-11

SECTION 1 - SAFETY PRECAUTIONS

NOTES:

1-12 – JLG Lift – 3121324

SECTION 2 - USER RESPONSIBILITIES, MACHINE PREPARATION AND INSPECTION

SECTION 2. USER RESPONSIBILITIES, MACHINE PREPARATION AND INSPECTION

2.1 PERSONNEL TRAINING

The aerial platform is a personnel handling device; so it is necessary that it be operated and maintained only by trained personnel.

Persons under the influence of drugs or alcohol or who are subject to seizures, dizziness or loss of physical control must not operate this machine.

Operator Training

Operator training must cover:

1. Use and limitations of the controls in the platform and at

the ground, emergency controls and safety systems.

2. Control labels, instructions, and warnings on the

machine.

3. Rules of the employer and government regulations.

4. Use of approved fall protection equipment.

5. Enough knowledge of the mechanical operation of the

machine to recognize a malfunction or potential malfunction.

6. The safest means to operate the machine where over-

head obstructions, other moving equipment, and obstacles, depressions, holes, drop-offs.

7. Means to avoid the hazards of unprotected electrical

conductors.

8. Specific job requirements or machine application.

Training Supervision

Training must be done under the supervision of a qualified person in an open area free of obstructions until the trainee has developed the ability to safely control and operate the machine.

Operator Responsibility

The operator must be instructed that he/she has the responsibility and authority to shut down the machine in case of a malfunction or other unsafe condition of either the machine or the job site.

3121324 – JLG Lift – 2-1

SECTION 2 - USER RESPONSIBILITIES, MACHINE PREPARATION AND INSPECTION

2.2 PREPARATION, INSPECTION, AND MAINTENANCE

The following table covers the periodic machine inspections and maintenance recommended by JLG Industries, Inc. Consult local regulations for further requirements for aerial work platforms. The frequency of inspections and maintenance must be increased as necessary when the machine is used in a harsh or hostile environment, if the machine is used with increased frequency, or if the machine is used in a severe manner.

NOTICE

JLG INDUSTRIES, INC. RECOGNIZES A FACTORY-CERTIFIED SERVICE TECHNICIAN AS A PERSON WHO HAS SUCCESSFULLY COMPLETED THE JLG SERVICE TRAINING SCHOOL FOR THE SPECIFIC JLG PRODUCT MODEL.

2-2 – JLG Lift – 3121324

SECTION 2 - USER RESPONSIBILITIES, MACHINE PREPARATION AND INSPECTION

Table 2-1. Inspection and Maintenance Table

Typ e Frequency

Pre-Start Inspection

Pre-Deliver y

Inspection (See Note)

Frequent Inspection

(See Note)

Annual Machine

Inspection (See Note)

Preventative

Maintenance

NOTE: Inspection forms are available from JLG. Use the Service and Maintenance Manual to perform inspections.

Before using each day; or whenever there’s an Operator change.

Before each sale, lease, or rental delivery. Owner, Dealer, or User Qualified JLG Mechanic Service and Maintenance

In service for 3 months or 1 50 hours, whichever comes first; or

Out of service for a period of more than 3 months; or

Purchased used.

Annually, no later than 13 months from the date of prior inspection.

At intervals as specified in the Ser vice and Maintenance Manual.

User or Operator User or Operator Operator and Safety Manual

Owner, Dealer, or User Qualified JLG Mechanic Service and Maintenance

Owner, Dealer, or User Factory Cer tified Service

Owner, Dealer, or User Qualified JLG Mechanic Service and Maintenance

Primary

Responsibility

Service

Qualification

Te ch ni c ia n (Recommended)

Reference

Manual and applicable JLG inspection form

Service and Maintenance Manual and applicable JLG inspection form

Manual

3121324 – JLG Lift – 2-3

SECTION 2 - USER RESPONSIBILITIES, MACHINE PREPARATION AND INSPECTION

2.3 PRE-START INSPECTION

The Pre-Start Inspection should include each of the following:

1. Cleanliness – Check all surfaces for leakage (oil, fuel,

or battery fluid) or foreign objects. Report any leakage to the proper maintenance personnel.

2. Structure - Inspect the machine structure for dents,

damage, weld or parent metal cracks or other discrepencies.

Parent Metal Crack

3. Decals and Placards – Check all for cleanliness and

legibility. Make sure none of the decals and placards are missing. Make sure all illegible decals and placards are cleaned or replaced.

Weld Crack

4. Operators and Safety Manuals – Make sure a copy of

the Operator and Safety Manual is enclosed in the weather resistant storage container.

5. “Walk-Around” Inspection – Refer to Figure 2-2., Walk -

Around Inspection Diagram.

6. Battery – Charge as required.

7. Fuel - (Combustion Engine Powered Machines) – Add

the proper fuel as necessary.

8. Engine Oil Supply - Ensure that the engine oil level is at

the full mark on the dipstick and the filler cap is secure

9. Fluid Levels - Be sure to check the engine oil and the

hydraulic oil levels.

10. Accessories/Attachments - Reference the Operator

and Safety Manual of each attachment or accessory installed upon the machine for specific inspection, operation, and maintenance instructions.

11. Function Check – Once the “Walk-Around” Inspection

is complete, perform a functional check of all systems in an area free of overhead and ground level obstructions. Refer to Section 4 for more specific instructions on the operation of each function.

2-4 – JLG Lift – 3121324

SECTION 2 - USER RESPONSIBILITIES, MACHINE PREPARATION AND INSPECTION

IF THE MACHINE DOES NOT OPERATE PROPERLY, TURN OFF THE MACHINE IMMEDIATELY! REPORT THE PROBLEM TO THE PROPER MAINTENANCE PERSONNEL. DO NOT OPERATE THE MACHINE UNTIL IT IS DECLARED SAFE FOR OPERATION.

Function Check

Perform the Function Check as follows:

1. From the ground control panel with no load in the plat-

form:

a. Check that all function control switches and locks

are in place.

b. Operate all functions and check all limiting and cut-

out switches.

c. Check for proper lifting and lowering of the plat-

form.

d. If the platform extension is extended, check that the

extension retracts.

NOTE: Be sure the platform extension is retracted before lower-

ing.

e. Ensure that all machine functions are disabled

when the Emergency Stop Button is activated.

f. Check manual descent.

g. Check for proper lifting and lowering of the plat-

form.

2. From the platform control console:

a. Ensure that the control console is firmly secured in

the proper location.

b. Check that all guards protecting the switches are in

place.

c. Operate all functions

d. Ensure that all machine functions are disabled

when the Emergency Stop Button is pushed in.

e. Ensure that all LED’s in the control box are working

properly.

f. Check that the platform extension extends and

retracts properly.

g. With the platform in the transport (stowed) position

and with outriggers not selected:

i. Drive the machine on a level grade and stop to

ensure the brakes hold.

ii. To ensure proper operation of the tilt sensor, drive

the machine onto a tilt greater than the preset 3° and attempt to lift.

3121324 – JLG Lift – 2-5

SECTION 2 - USER RESPONSIBILITIES, MACHINE PREPARATION AND INSPECTION

Limit Switch Checks

Check that the following limit switches function properly by attempting to exceed the preset limits.

1. Lowered Position Limit Switch - Outriggers cannot be

deployed beyond the height of 9.8 ft (3m).

2. Limit Switches for Drive Mode

a. High Drive Speed Limit Switch - high drive speed is

possible up to a platform height of 12.14 ft (3.7 m). When the platform exceeds this limit, only low drive speed is possible.

b. Maximum Drive Height/Maximum Height without

Outriggers Limit Switch - The driving function is permitted up to a platform height of 65 ft (20 m). Once the limit is exceeded driving will be disabled. The lifting function, without the outriggers deployed, is only permitted up to a platform height of 65 ft (20 m) as well.

3. Maximum Height Limit Switch - The Maximum Height

Limit Switch cuts out the lifting function once the platform reaches 80.4 ft (24.5 m). This maximum height is only achieved when the outriggers are selected and deployed.

4. Tilt Switch - If the machine is exceeding a tilt angle of 3°,

the platform cannot be elevated beyond 12.14 ft (3.7 m), or if driving while elevated, the drive function will be cut out.

5. Outrigger Interlocks - These switches allow the machine

to be driven when all outriggers are completely retracted. The switch also prevents the platform from being lifted until the machine is level.

6. Oscillating Axle Limit Switch - When the platform is

raised above 12.8 ft (3.9 m) and the axle inclination is >1°, the drive function is cutout. When the platform is below 3.9 m, the inclination of the axle is ignored and driving is possible.

2-6 – JLG Lift – 3121324

SECTION 2 - USER RESPONSIBILITIES, MACHINE PREPARATION AND INSPECTION

Table 2-2. Cutout Switch Limits

Limit and Cutout Switch Limit

Lowered Position 9.8 ft (3.2 m)

High Drive Speed Cutout * 12.14 ft (3.7 m)

Maximum Drive Height/Maximum Height without Outriggers *

Maximum Height:* 80.4 ft (24 .5 m)

Tilt * 3°

Outrigger Interlock drive cut out when outriggers activated;

Oscillating Axle >1° and 12.8 ft (3.9 m)

NOTE: * - these limit switches have corresponding LED’s on

the platform control console (refer to Figure 3-5., Platform Control Console). See pages 3-9 and 3-10 for LED functionality.

65 ft (20 m)

lift cut out when not level

3121324 – JLG Lift – 2-7

SECTION 2 - USER RESPONSIBILITIES, MACHINE PREPARATION AND INSPECTION

1. Lowered Position Limit Switch

2. High Drive Speed Limit Switch

3. Max Drive Height/Max Height without

Outriggers Limit Switch

4. Max Height Limit Switch

5. Tilt Sensor

6. Outrigger Interlocks (all 4 outriggers)

7. Oscillating Axle Limit Switches (rear

axle)

Figure 2-1. Limit Switch Locations

2-8 – JLG Lift – 3121324

SECTION 2 - USER RESPONSIBILITIES, MACHINE PREPARATION AND INSPECTION

Figure 2-2. Walk - Around Inspection Diagram

3121324 – JLG Lift – 2-9

SECTION 2 - USER RESPONSIBILITIES, MACHINE PREPARATION AND INSPECTION

utrigger - (right front) - See Note

enera

Begin the “Walk-Around Inspection” at Item 1, as noted on the diagram. Continue to the right (counterclockwise viewed from top) checking each item in sequence for the conditions listed in the “Walk-Around Inspection Checklist.”

TO AVOID POSSIBLE INJURY, BE SURE MACHINE POWER IS “OFF” DURING “WALK-AROUND INSPECTION”.

NOTICE

DO NOT OVERLOOK VISUAL INSPECTION OF CHASSIS UNDERSIDE. CHECKING THIS AREA OFTEN RESULTS IN DISCOVERY OF CONDITIONS WHICH COULD CAUSE EXTENSIVE MACHINE DAMAGE.

NOTE: On each item, make sure there are no loose or missing

parts, that they are securely fastened, and that no visible damage exists in addition to any other criteria mentioned.

1. Steer Linkage - See Note.

2. Steer Cylinder - See Note

Figure 2-3. Walk - Around Inspection Points (Sheet 1)

4. Wheel and Tire Assembly - Properly secured, no miss-

ing lug nuts. Refer to Section 6. Inspect wheels for damage and corrosion.

5. Tie Rod and Spindle - (right front) - See Note

6. Lift Cylinder - See Note

7. Drive Hub, Right Rear - See Note

8. Outrigger - (right rear) - See Note

9. Outrigger - (left rear) - See Note

10. Fuel Tank - See Note

11. Drive Hub, Left Rear - See Note

12. Motor and Hydraulic Pump Assembly - Check engine

oil level. See Note

2-10 – JLG Lift – 3121324

SECTION 2 - USER RESPONSIBILITIES, MACHINE PREPARATION AND INSPECTION

13. Hydraulic Reservoir - Recommended hydraulic fluid

level on level indicator on tank. Breather cap secure and working.

14. Tie Rod and Spindle - (left front) - See Note

15. Outrigger - (left front) - See Note

16. Scissor Arms and Sliding Wear Pads (Not Shown) -

See Note

17. Control Valve - No unsupported wires or hoses; no

damaged or broken wires.

Figure 2-4. Walk - Around Inspection Points (Sheet 2)

18. Ground Controls - Placard secure and legible, control

switches return to neutral position, emergency stop switch functions properly.

19. Platform Control Console (mounted on platform rail) -

Placard secure and legible, control lever and switches return to neutral, trigger switch and emergency stop switch function properly, operation and safety manual in storage box.

20. Platform/Handrail Installation (Not Shown) - See Note.

Ensure all rails and hardware are properly installed.

3121324 – JLG Lift – 2-11

SECTION 2 - USER RESPONSIBILITIES, MACHINE PREPARATION AND INSPECTION

NOTES:

2-12 – JLG Lift – 3121324

SECTION 3 - USER RESPONSIBILITIES AND MACHINE CONTROL

SECTION 3. USER RESPONSIBILITIES AND MACHINE CONTROL

3.1 GENERAL

NOTICE

SINCE THE MANUFACTURER HAS NO DIRECT CONTROL OVER MACHINE APPLICATION AND OPERATION, CONFORMANCE WITH GOOD SAFETY PRACTICES IN THESE AREAS IT IS THE RESPONSIBILITY OF THE USER AND HIS OPERATING PERSONNEL.

This section provides the necessary information needed to understand control functions. Included in this section are the operating characteristics and limitations, and functions and purposes of controls and indicators. It is important that the user read and understand the proper procedures before operating the machine. These procedures will aid in obtaining optimum service life and safe operation.

3.2 OPERATING CHARACTERISTICS AND LIMITATIONS

General

A thorough knowledge of the operating characteristics and limitations of the machine is always the first requirement for any user, regardless of user’s experience with similar types of equipment.

Placards

Important points to remember during operation are provided at the control stations by DANGER, WARNING, CAUTION, IMPORTANT and INSTRUCTION placards. This information is placed at various locations for the express purpose of alerting personnel of potential hazards constituted by the operating characteristics and load limitations of the machine. See foreword for definitions of the above placards.

3121324 – JLG Lift – 3-1

SECTION 3 - USER RESPONSIBILITIES AND MACHINE CONTROL

Capacities

Raising the platform above the stowed position with or without any load on the platform, is based on the following criteria:

1. Machine is level and positioned on a firm supporting

surface.

2. Load is within manufacturer’s rated capacity.

3. All machine systems are functioning properly.

3.3 CONTROLS AND INDICATORS

Ground Control Station

1. Engine Control Box

2. Main Terminal Box

3. Ground Control Console

Figure 3-1. Ground Control Stations

3-2 – JLG Lift – 3121324

SECTION 3 - USER RESPONSIBILITIES AND MACHINE CONTROL

Engine Control

DO NOT OPERATE FROM GROUND CONTROL STATION WITH PERSONNEL IN THE PLATFORM EXCEPT IN AN EMERGENCY. PERFORM AS MANY PRE-OPERATIONAL CHECKS AND INSPECTIONS FROM THE GROUND CONTROL STATION AS POSSIBLE.

ehbelectronics

Vertragshandler

Start

1. Start Assist 2. Engine Start 3. Hourmeter 4. Glow Plug LED

Figure 3-2. Engine Control Box

3121324 – JLG Lift – 3-3

Vert ragsha ndler

Air

Glow

Tem p .

Oil

Alt.

Start

SECTION 3 - USER RESPONSIBILITIES AND MACHINE CONTROL

1. Start Assist - This push button is used to help assist

starting the machine in cold temperatures.

2. Engine Start - A push button switch that, when

depressed, will start the engine

3. Hourmeter - A meter used to measure the amount of

time the machine is in use.

4. Glow Plug LED - This Yellow LED is off under normal

operating conditions. The LED is illuminated when the ignition is on and the temperature sensing requires preglow.

NOTE: Do not start machine when Glow Plug LED is illuminated.

Once the LED goes out, machine starting is permitted.

3-4 – JLG Lift – 3121324

Main Terminal Box

SECTION 3 - USER RESPONSIBILITIES AND MACHINE CONTROL

1. Tilt Right LED

E900057 A

-X

-Y

2. Tilt Left LED

3. Tilt Forward LED

4. Tilt Backward LED

5. Drive Cutout LED

Figure 3-3. Main Terminal Box

3121324 – JLG Lift – 3-5

SECTION 3 - USER RESPONSIBILITIES AND MACHINE CONTROL

NOTE: The following LED’s are part of the self leveling system

and illuminate as the machine self levels.

1. Tilt Right LED - This LED will illuminate any time the

machine is tilted to the right.

2. Tilt Left LED - This LED will illuminate any time the

machine is tilted to the left.

3. Tilt Front LED - This LED will illuminate any time the

machine is tilted toward the machine front.

4. Tilt Rear LED - This LED will illuminate any time the

machine is tilted toward the machine rear.

5. Drive Cutout LED - This LED is illuminated when the out-

riggers are used and the lift function is operated.

3-6 – JLG Lift – 3121324

Ground Control Console

SECTION 3 - USER RESPONSIBILITIES AND MACHINE CONTROL

1. Platform/ Ground Select (Key Switch)

2. Engine Start Switch

3. Emergency Stop Button

4. Outrigger Select Switch

5. Platform Lift/Lower Switch

6. Deck Extend/Retract Switch

7. Glow Plug LED

8. Battery Disconnect Switch

E900034A

Figure 3-4. Ground Control Console

3121324 – JLG Lift – 3-7

SECTION 3 - USER RESPONSIBILITIES AND MACHINE CONTROL

Ground Control Descriptions:

1. Platform/Ground Select - This three way keyswitch is

used to select between platform controls or ground controls. When in the center position, the machine is disabled.

2. Engine Start Switch - Toggle Switch used to start engine.

3. Emergency Stop Button - Button, when depressed, will

immediately shut the machine off. Cuts out all functions except emergency platform lowering.

4. Outrigger Select Switch - Toggle Switch used to select if

outriggers auto leveling function is active or not.

5. Platform Lift/Lower Switch - Toggle switch that raises

and lowers platform.

6. Deck Extend/Retract Switch - Toggle switch that extends

and retracts platform deck extension.

NOTE: The platform deck extension should be retracted before

lowering the platform.

7. Glow Plug LED - This Yellow LED is off under normal

operating conditions. The LED is illuminated when the ignition is on and the temperature sensing requires preglow.

NOTE: Do not start machine when Glow Plug LED is illuminated.

Once the LED goes out, machine starting is permitted.

8. Battery Disconnect Switch - Disconnects ground control

panel from the battery.

3-8 – JLG Lift – 3121324

3.4 PLATFORM CONTROL CONSOLE

SECTION 3 - USER RESPONSIBILITIES AND MACHINE CONTROL

1. Engine Start Switch

2. Emergency Stop Button

E900036A

3. Deck Extension/Drive/Lift Select Switch

4. Drive Speed Switch

5. Lift/Drive/Deck/Steer Controller

6. Horn Button

7. Drive Enabled LED

8. Glow Plug Active or Enabled LED

9. Lift Enabled LED

10. High Drive Speed Enabled LED

E900030C

11. Tilt LED

Figure 3-5. Platform Control Console

3121324 – JLG Lift – 3-9

SECTION 3 - USER RESPONSIBILITIES AND MACHINE CONTROL

Platform Control Descriptions:

When platform/ground control select switch is switched to platform all movements and operations are controlled via the platform control panel. The controls are activated through either push-buttons or toggle switches, whose functions are marked with symbols and / or written text.

1. Engine Start Switch - Toggle switch that turns the diesel

engine on and off. Up for on, down for off.

2. Emergency Stop Button - Button, when depressed, will

immediately shut the machine off. Cuts out all functions except emergency platform lowering.

3. Deck Extension/Drive/Lift Select Switch -3 position tog-

gle switch that selects the functions of platform extension, drive or lift. Up for platform extension, middle for drive, and down for lift. Works in conjunction with the joystick controller.

4. Drive Speed Switch - 3 position toggle switch that

selects between fast drive, slow drive or posi-traction. Posi-traction evenly distributes the torque between all four wheels to provide better traction in situations that require it.

5. Lift/Drive/Deck/Steer Controller - The Controller works in

conjunction with the platform extension, drive and the lift switch depending upon which function is selected. The

button on the front of the joystick is the enable button. This button must be held in to work all joystick controlled functions. When the Drive function is selected, moving the joystick forward and backwards operates the forward and reverse movement of the machine. The switch on top of the joystick controls the steering of the machine when the Drive function is selected. When the Deck function is selected, moving the joystick forward and backward extends and retracts the platform deck extension. When the Lift function is selected, moving the joystick forward and backwards raises and lowers the platform.

6. Horn - Button, when depressed, activates the horn.

7. Drive Enabled LED - This Green LED is illuminated when

drive is enabled. The LED goes out when the platform is above the maximum drive height of 69 ft (21 m), or with outriggers selected and deployed.

8. Glow Plug Enabled or Active LED - This Yellow LED is off

under normal operating conditions. The LED is illuminated when the ignition is on and the temperature sensing requires pre-glow.

NOTE: Do not start machine when Glow Plug LED is illuminated.

Once the LED goes out, machine starting is permitted.

3-10 – JLG Lift – 3121324

SECTION 3 - USER RESPONSIBILITIES AND MACHINE CONTROL

9. Lift Enabled LED - This Green LED is illuminated when

the lift function is enabled. The light goes out when tilted above 12.14 ft (3.7 m), or when at maximum height

80.4 ft (24.5 m) with the outriggers deployed, or 65 ft (20 m) with the outriggers not deployed.

10. High Drive Speed Enabled LED - This Green LED is illu-

minated when high drive speed is enabled. The light goes out when the platform is above the high drive speed limit of 12.14 ft (3.7 m).

11. Tilt (slope) LED - This Red LED will illuminate when the

machine is driven on a slope greater than the allowable 3°. The LED remains off under normal operating conditions.

3121324 – JLG Lift – 3-11

SECTION 3 - USER RESPONSIBILITIES AND MACHINE CONTROL

Figure 3-6. Decal Location (ANSI) - Sheet 1 of 2

3-12 – JLG Lift – 3121324

SECTION 3 - USER RESPONSIBILITIES AND MACHINE CONTROL

Figure 3-7. Decal Location (ANSI) - Sheet 2 of 2

3121324 – JLG Lift – 3-13

SECTION 3 - USER RESPONSIBILITIES AND MACHINE CONTROL

9 8

Figure 3-8. Decal Location (CSA) - Sheet 1 of 2

3-14 – JLG Lift – 3121324

SECTION 3 - USER RESPONSIBILITIES AND MACHINE CONTROL

Figure 3-9. Decal Location (CSA) - Sheet 2 of 2

3121324 – JLG Lift – 3-15

SECTION 3 - USER RESPONSIBILITIES AND MACHINE CONTROL

Table 3-1. Decal Legend

Item #

1 1701214 1701505

2 1701505 1701640

3 1701640 17012773

4 1702773 1703687

5 1703687 1703811

6 1703811 1703812

7 1703812 1703814

8 1703814 1703819

9 1703816 1704277

10 1703819 1704412

11 1704277 1704684

12 1704412 1704690

13 1704885 1704885

14 1705694 1705040

15 1705695 1705303

16 1706482 1705694

17 1706485 1706482

ANSI

(0275933-G)

CSA English/French

(1001092750-F)

Item #

18 1706487 1706485

19 1001103747 1706487

20 1706507 1001103747

21 1706508 1706507

22 1707184 1706508

23 1707185 1707184

24 1707188 1707188

25 - 28 -- --

29 1703464 1001092736

30 1706098 --

31 -- --

32 -- 1705717

33 -- 1703464

34 -- 1706098

Table 3-1. Decal Legend

ANSI

(0275933-G)

CSA English/French

(1001092750-F)

3-16 – JLG Lift – 3121324

SECTION 4 - MACHINE OPERATION

SECTION 4. MACHINE OPERATION

4.1 DESCRIPTION

General Description of the Functions and Components

The normal location to operate the machine is on the platform. However, the platformcontrol box can be disconnected from the platform location and plugged in (for emergency use, and loading onto a transport vehicle) at the distribution terminal inside the valve compartment of the machine.

4.2 STARTING

Ensure Battery Disconnect Switch is not cutting off the battery power. On the Ground Control Console, select the operating position (platform vs. ground).

NOTE: If Glow Plug LED illuminates, wait until the LED goes out

before attempting to start the engine.

ENGINE EXPLOSION HAZARD. MACHINE IS EQUIPPED WITH A COLD START AID. DO NOT USE ADDITIONAL ETHER. FAILURE TO COMPLY COULD RESULT IN DEATH OR SERIOUS INJURY.

On the selected Operating Console, press the Engine Start Switch up and hold to start the engine. Release the switch once engine starts. On the ground control console, select Outriggers active or disabled.

The Engine Start Switch can also be used to shut the engine off when the switch is pressed down.

NOTE: The Start Button on the Engine Control box can also be

used to start the engine (refer to Figure 3-2.).

3121324 – JLG Lift – 4-1

SECTION 4 - MACHINE OPERATION

4.3 LIFTING AND LOWERING

DO NOT RAISE PLATFORM EXCEPT ON A FIRM UNIFORM SURFACE FREE OF OBSTRUCTIONS AND HOLES.

ENSURE SCISSOR ARM AREA IS FREE OF PERSONNEL PRIOR TO LOWERING PLATFORM.

DO NOT LOWER THE PLATFORM WITHOUT COMPLETELY RETRACTING THE PLATFORM EXTENSION.

Lifting:

1. If operating from the ground control console:

a. Lift up on the Platform Lift/Lower Switch to achieve

desired elevation.

2. If operating from the platform control console:

a. Position the Drive/Lift Select Switch to the "Lift" posi-

tion. Press and hold the enable trigger on the front of the joystick while moving the joystick forward to raise the platform to desired elevation. Once the

trigger is released or the joystick is returned to the neutral position, the movement will stop.

Lowering:

1. If operating from the ground control console:

a. Press down on the Platform Lift/Lower Switch to

achieve desired elevation.

2. If operating from the platform control console:

a. Position the Drive/Lift Select Switch to the "Lift" posi-

tion. Press and hold the enable trigger on the front of the joystick while moving the joystick backward to lower the platform to desired elevation. Once the trigger is released or the joystick is returned to the neutral position, the movement will stop.

NOTE: When the machine is in "Drive Mode," the lifting and low-

ering functions are deactivated. Manual descent is the only allowable platform movement when in "Drive Mode."

The machine is equipped with gravity descent. The engine does not need to be running to lower the platform.

4-2 – JLG Lift – 3121324

4.4 AUTOMATIC SELF LEVELING CHASSIS

SECTION 4 - MACHINE OPERATION

The machine is equipped with an auto leveling feature that allows the operator to automatically level the machine. When the machine is leveled, the lift function is automatically enabled. The indicator LED’s on the Main Terminal Box will also indicate when the machine is level (See Figure 3-3 on page 3-4 and page 3-5 for an explanation of the LED’s). This function can be turned on or off at the ground control station.

With the auto leveling function selected, the outriggers are deployed by using the lift controller. Joystick forward will extend the outriggers and joystick back will retract the outriggers.

All outriggers must be extended and in contact with the support surface before the platform is lifted from the stowed position. If one or more outriggers, despite being fully extended, is not in contact with the support surface the outriggers must be retracted and the machine moved to a more appropriate position.

To retract the outriggers, activate the lowering function with the joystick. When the platform is completely lowered, the outriggers will begin to retract. Once all outriggers are completely retracted, the drive function will be enabled.

IF THE MACHINE BECOMES UNLEVEL, CAREFULLY LOWER THE PLATFORM AND REPOSITION THE MACHINE.

NOTICE

ALWAYS BE SURE THAT THE OPERATING SURFACE THE MACHINE IS TO BE USED ON IS FIRM AND FREE OF ANY VOIDS OR OBSTRUCTIONS THAT MAY PROHIBIT THE OUTRIGGERS FROM PERFORMING PROPERLY.

3121324 – JLG Lift – 4-3

SECTION 4 - MACHINE OPERATION

4.5 DRIVING THE MACHINE FROM THE PLATFORM

To activate the drive function, the controller (joystick) has to be moved forward for forward-drive and back for reversedrive. The controller has a neutral zone of about ± 7% of the total possible moving distance. After reaching the end of the neutral zone, the drive, brake and motion alarm valves will be activated and the machine starts to move.

DO NOT DRIVE WITH PLATFORM RAISED EXCEPT ON A SMOOTH, FIRM AND LEVEL SURFACE FREE OF OBSTRUCTIONS AND HOLES.

TO AVOID LOSS OF TRAVEL CONTROL OR UPSET ON GRADES AND SIDESLOPES, DO NOT DRIVE MACHINE ON GRADES OR SIDESLOPES EXCEEDING THOSE SPECIFIED. REFERENCE FIGURE 4-1., GRADE AND SIDESLOPE.

4-4 – JLG Lift – 3121324

SECTION 4 - MACHINE OPERATION

HORIZONTAL

Figure 4-1. Grade and Sideslope

3121324 – JLG Lift – 4-5

SECTION 4 - MACHINE OPERATION

4.6 STEERING

The steer function is operated by depressing the two positioned button on top of the joystick. Pressing and holding the button to the right will turn the wheels to the right. Release the button when desired direction is achieved. When the button is released, the wheels will remain in the turned position. To straighten and/or turn to the left, the button must be pushed and held in the opposite direction (left in this case). The same procedure applies for straightening or turning right when wheels are in left turn position.

4.7 HYDRAULIC PLATFORM EXTENSION

With the lift/drive/extension switch in the extension position, the platform can be hydraulically extended.The function is activated by moving the controller forward to extend and backwards to retract.

4.8 EMERGENCY LOWERING - MANUAL DESCENT

All control switches have to be set to the neutral position. Next, the emergency lowering valve, which is located on the lift cylinder, can be opened hydraulically by a hand pump located inside the hydraulic compartment. Once the lowering is completed, all levers of the emergency lowering function have to be put into the neutral position. Refer to Section 5, Emergency Procedures, for instructions on manual lowering.

4.9 PARKING AND STOWING

When machine use is completed, the machine has to be fully lowered and the battery isolator switch should be turned off.

NOTICE

THE MACHINE SHOULD BE LOCKED BY THE KEYSWITCH ON THE GROUND CONTROL PANEL TO AVOID THE USE BY ANY UNAUTHORIZED PERSONNEL.

In case the machine is not used for a longer period of time, the batteries should be charged once every two weeks due to the self discharge and power consumption of the machine at rest.

4-6 – JLG Lift – 3121324

4.10 TIE DOWN/LIFT LUGS

Tie Down

When transporting the machine, the platform extension must be fully retracted and the platform fully lowered in the stowed position with the machine securely tied down to the truck or trailer deck. Refer to the tie down lugs in Figure 4-2., Lifting and Tie Down Points.

If it becomes necessary to lift the machine, it is possible to do so from the lifting lugs located at the four corners of the machine. These lugs enable the machine to be lifted using cranes or suitable lifting devices.

NOTE: If lifting becomes necessary from the lifting lugs, JLG

Industries Inc. recommends the use of a proper spreader bar and straps/chains to avoid damage to the machine. Cranes or other lifting devices must be capable of handling the weights listed in the Operating Specifications table in section 6 of this manual.

Tie Down

SECTION 4 - MACHINE OPERATION

Tie Down

Lift Lugs

Figure 4-2. Lifting and Tie Down Points

3121324 – JLG Lift – 4-7

SECTION 4 - MACHINE OPERATION

4.11 TRANSPORT AND STORAGE OF THE MACHINE

NOTICE

DURING TRANSPORT THE BATTERY DISCONNECT SWITCH SHOULD BE DISCONNECTED.

E900034A

1. Battery Disconnect Switch

The control box must be unplugged during the transport of the machine. The socket at the platform must be closed, whenever the control box is not plugged in. This is the best way to prevent any damages due to moisture and transport to the electrical components of the machine.

• Ensure that the control box is stored in a safe and dry location and the main joystick controller is not affected by any harsh forces.

4-8 – JLG Lift – 3121324

SECTION 4 - MACHINE OPERATION

Platform Rail Lowering Tool Procedure

NOTE: Prior to lowering/raising rails, ensure deck surface is

clean, dry, and free of debris. Maintain good footing during procedure.

WHEN STANDING ON THE MAIN PLATFORM SURFACE LOWERING OR RAISING THE MAIN PLATFORM RAILS, JLG INDUSTRIES, INC. RECOMMENDS THE USE OF A FALL RESTRAINT DEVICE ATTACHED TO THE CENTER RAIL LANYARD ATTACH POINT ON THE PLATFORM EXTENSION RAIL ADJACENT TO THE MAIN RAIL YOU ARE LOWERING/RAISING.

When transporting the machine, it may be necessary to lower the platform rails to meet traveling height requirements. A Rail Lowering Tool (Optional) is available to assist the operator with this procedure.

1. Rope (Top)

2. Rope (Bottom)

Figure 4-3. Rail Lowering Tool (Optional)

3. Rail Clamp

4. Rubber Stopper

3121324 – JLG Lift – 4-9

SECTION 4 - MACHINE OPERATION

Main Platform Side Rails and Extension End Rail

NOTE: The following procedures apply to the Main Platform Side

Rails and the Platform Extension End Rail. These rails fold outward. Stow these rails prior to stowing the extension side rails.

1. Remove the Rail/Platform Attach Pins from each rail leg

(located on the sides of the platform where rails attach to platform).

a. Remove the Safety Pin.

b. Remove the Attach Pin.

4-10 – JLG Lift – 3121324

SECTION 4 - MACHINE OPERATION

2. While standing on the platform, place the Rail Lowering

Tool on the Rail. (reference the illustration following)

a. Place the Rail Clamp on the underside of the top rail

near the center post.

b. Lower the Tool handle so that the Rubber Stopper

rests on the top of the rail locking the Tool in place on the rail.

1. Rail Lowering Tool

3. Let the Rail Lowering Tool rest on the rail.

4. Attach your fall restraint device to the extension platform

rail - center lanyard attach point before lowering the main rails.

5. Remove the Rail Corner Pin where the side rail connects

to the end rail. While holding onto the side rail, remove the Safety Pin and pull out the Corner Pin.

1. Corner Pin

2. Safety Pin

6. While continuing to hold onto the rail, walk back to the

Rail Lowering Tool.

3. Top View of Side Rail

3121324 – JLG Lift – 4-11

SECTION 4 - MACHINE OPERATION

7. Tightly grasp the top portion of the rope and begin to

slowly lower the railing using hand-over-hand motions.

FALL HAZARD. EXERCISE EXTREME CAUTION WHEN LOWERING RAILS, USER SHOULD STAND CLEAR OF THE PLATFORM EDGE AND MAINTAIN A STABLE FOOTING DURING THE LOWERING PROCEDURE.

NOTE: The extension side rails, in the upright position, can be

used for extra footing support.

8. When rail is fully lowered, pull the bottom portion of the

rope tight to release the Tool’s Rail Clamp from the machine.

9. Repeat the previous steps on the opposite side rail and

platform extension end rail.

10. Once the main platform side rails and platform extension

end rail are lowered, secure them in place by inserting all of the Pins into the lower holes of the Rail/Platform Attach Brackets.

4-12 – JLG Lift – 3121324

SECTION 4 - MACHINE OPERATION

11. Secure Pins in place with Safety Pins.

Main Platform End Rails/Gate and Extension Side Rails

NOTE: The following procedures apply only to the Main Platform

End Rails/Gate and Extension Side Rails.

12. Remove the Rail/Platform Attach Pins from each rail leg

(located on the sides of the platform where rails attach to platform).

a. Remove Safety Pin and pull out Main Pin.

1. Main Pin 2. Safety Pin

3121324 – JLG Lift – 4-13

SECTION 4 - MACHINE OPERATION

2. Carefully lower rails inward to the platform deck.

3. Secure rails by inserting Main Pins back into brackets

and securing pin with Safety Pins.

1. Safety Pin 2. Main Pin

Rail Raising Procedure

NOTE: Follow the Platform Rail Lowering Procedures in reverse

order to raise rails to the working positions. Make certain to secure all rails with all pins and all safety pins.

4-14 – JLG Lift – 3121324

FALL HAZARD. FAILURE TO PROPERLY SECURE ALL RAIL SECTIONS COULD RESULT IN RAIL COLLAPSE RESULTING IN DEATH OR SERIOUS INJURY.

1. Raise Main Platform End Rails/Gate and Extension Side

Rails to the up-right position. Secure rails with all of the pins and all of the safety pins.

2. Attach the Rail Tool to raise Main Platform Side Rails to

the up-right position. Secure with pins and safety pins.

3. Before attempting to raise the main side rails, attach

your fall restraint device to the extension platform rail center lanyard attach point.

4. Once main side rails are raised into place, secure Side

Rails to End Rails with all pins and secure all pins with safety pins.

SECTION 4 - MACHINE OPERATION

3121324 – JLG Lift – 4-15

SECTION 4 - MACHINE OPERATION

This page intentionally left blank.

4-16 – JLG Lift – 3121324

SECTION 5 - EMERGENCY PROCEDURES

SECTION 5. EMERGENCY PROCEDURES

5.1 GENERAL

This section provides information on the procedures to be followed and on the systems and controls to be used in the event an emergency situation is encountered during machine operation. Prior to operation of the machine and periodically thereafter, the entire operating manual, including this section, should be reviewed by all personnel whose responsibilities include any work or contact with the machine.

Emergency Stop Switch

These large red buttons, one located outside the valve compartment and one at the Platform Control Station, will immediately stop the machine when depressed.

NOTICE

CHECK MACHINE DAILY TO MAKE SURE EMERGENCY STOP BUTTON IS IN PLACE AND THAT GROUND CONTROL INSTRUCTIONS ARE IN PLACE AND LEGIBLE.

Platform Caught Overhead

If the platform becomes jammed or snagged in overhead structures or equipment, do not continue operation of the machine from either the platform or the ground until the operator and all personnel are safely moved to a secure location. Only then should an attempt be made to free the platform using any necessary equipment and personnel. Do not operate controls to cause one or more wheels to leave the ground.

Righting of Tipped Machine

A forktruck of suitable capacity or equivalent equipment should be placed under the elevated side of the chassis, with a crane or other suitable lifting equipment used to lift the platform while the chassis is lowered by the forklift or other equipment.

Post-Incident Inspection

Following any incident, thoroughly inspect the machine and test all functions first from the ground controls, then from the platform controls. Do not lift above 10 feet (3 meters) until you are sure that all damage has been repaired, and that all controls are operating correctly.

3121324 – JLG Lift – 5-1

SECTION 5 - EMERGENCY PROCEDURES

5.2 EMERGENCY OPERATION

Use of Ground Controls

NOTICE

KNOW HOW TO USE THE GROUND CONTROLS IN AN EMERGENCY SITUATION.

Ground personnel must be thoroughly familiar with the machine operating characteristics and the ground control functions. Training should include operation of the machine, review and understanding of this section and hands-on operation of the controls in simulated emergencies.

Operator Unable to Control Machine

1. Operate the machine from ground controls ONLY with

the assistance of other personnel and equipment (cranes, overhead hoists, etc.) as may be required to safely remove the danger or emergency condition.

2. Other qualified personnel on the platform may use the

platform controls. DO NOT CONTINUE OPERATION IF CONTROLS DO NOT FUNCTION NORMALLY.

3. Cranes, forklift trucks or other equipment, which may be

available, are to be used to stabilize motion of the machine in case machine controls are inadequate or

malfunction when used prior to removing platform occupants.

Incident Notification

It is imperative that JLG Industries, Inc. be notified immediately of any incident involving a JLG product. Even if no injury or property damage is evident, JLG should be contacted by telephone and provided with all necessary details at:

877-554-7233 or 240-420-2661

It should be noted that failure to notify the Manufacturer of an incident involving a JLG Industries product within 48 hours of such an occurrence may void any warranty consideration on that particular machine.

5-2 – JLG Lift – 3121324

SECTION 5 - EMERGENCY PROCEDURES

5.3 MANUAL PROCEDURES

Manual Platform Deck Retraction

NOTE: The platform deck extension should be retracted before

the platform lowering begins.

1. Locate the valve block and handpump inside the

hydraulic cover on the right side of the machine.

2. Turn valve knob on the manual handpump clockwise

until tight.

3. Locate the lever at the end of the valve bank near the

back. Push lever down to engage valve.

NOTE: Step 2 applies only to machines prior to S/N 1200021263.

3121324 – JLG Lift – 5-3

SECTION 5 - EMERGENCY PROCEDURES

4. Locate separate valve handle and place handle on the

valve as shown (first section from the left).

NOTE: Valve handles are located in plastic storage bag within

valve compartment.

5. Open valve by pulling handle down.

6. While continuing to hold the valve open, activate the

manual pump by pumping back and forth.

7. After manual platform deck retraction is complete,

release valve on the valve bank and remove handle from valve. Return the valve lever at the end of the valve bank near the back to it’s original position. Turn the valve on

the manual hand pump counterclockwise until fully open (if applicable). Push pump handle forward.

Manual Descent

NOTE: The manual descent system is provided as an emergency

means to lower personnel from the platform.

1. Locate the valve block and hand pump inside the

hydraulic cover on the right side of the machine.

2. Turn valve knob on the manual handpump clockwise

until tight.

NOTE: Step 2 applies only to machines prior to S/N 1200021263.

5-4 – JLG Lift – 3121324

SECTION 5 - EMERGENCY PROCEDURES

3. Locate the lever at the end of the valve bank near the

back. Lift lever to engage valve.

4. Locate handle and place it on the third valve from the

left. Press handle downward while activating the manual pump.

NOTE: Valve handles are located in plastic storage bag within

valve compartment.

PLATFORM WILL CONTINUE TO DESCEND ONCE MOVEMENT IS STARTED. TO STOP PLATFORM DESCENT, RELEASE THE HANDLE ON THE MAIN VALVE.

5. After manual lowering is complete, release valve on the

valve bank and remove handle from valve. Return the valve lever at the end of the valve bank near the back to it’s original position. Turn the valve on the manual hand pump counterclockwise until fully open (if applicable). Push pump handle forward.

3121324 – JLG Lift – 5-5

SECTION 5 - EMERGENCY PROCEDURES

5.4 EMERGENCY TOWING

RUNAWAY VEHICLE/MACHINE HAZARD. MACHINE HAS NO TOWING BRAKES. TOWING VEHICLE MUST BE ABLE TO CONTROL MACHINE AT ALL TIMES. ON-HIGHWAY TOWING NOT PERMITTED. FAILURE TO FOLLOW INSTRUCTIONS COULD CAUSE SERIOUS INJURY OR DEATH.

MAXIMUM TOWING SPEED 5 M.P.H. (8 K.M.H.) FOR NO LONGER THAN 30-45 MINUTES.

MAXIMUM TOWING GRADE 25%.

Prior to Towing

Prior to towing the machine, complete the following:

DO NOT TOW MACHINE WITH ENGINE OPERATING OR DRIVE HUBS ENGAGED.

1. Completely lower platform.

2. Disconnect drive hubs by inverting disconnect cap.

(See Figure 5-1.) After towing the machine, complete the following:

a. Reconnect drive hubs by inverting disconnect cap.

(See Figure 5-1.)

1. Hub Connected

2. Disconnect Cap

3. Hub Disconnected

Figure 5-1. Drive Disconnect Hub

5-6 – JLG Lift – 3121324

SECTION 6 - GENERAL SPECIFICATIONS AND OPERATOR MAINTENANCE

SECTION 6. GENERAL SPECIFICATIONS AND OPERATOR MAINTENANCE

6.1 INTRODUCTION

This section of the manual provides additional necessary information to the operator for proper operation and maintenance of this machine.

The maintenance portion of this section is intended as information to assist the machine operator to perform daily maintenance tasks only, and does not replace the more thorough Preventive Maintenance and Inspection Schedule included in the Service and Maintenance Manual.

Other Publications Available Specific to this Machine:

Service and Maintenance Manual ..................... 3121325

Illustrated Parts Manual ..................................... 3121326

3121324 – JLG Lift – 6-1

SECTION 6 - GENERAL SPECIFICATIONS AND OPERATOR MAINTENANCE

6.2 OPERATING SPECIFICATIONS

Table 6-1. Operating Specifications

Maximum Working Height: with outriggers deployed with outriggers stowed

Maximum Platform Height: with outriggers deployed with outriggers stowed

Tu rn in g R ad iu s: I ns id e O ut si d e

Wheelbase 12.8 ft (3.9 m)

Maximum Work Load (Capacity) - Main Platform/ Platform Extension

Maximum Number ofPersons 2

To ol s an d E q ui p me nt

Maximum Horizontal Manual Side Force

Tilt Sensor Setting 3°

Sideslope (Machine Stowed) 5°

Gradeability (Machine Stowed) 25%

87 ft (26.5 m)

72 ft (22 m)

80 ft (24.5 m) 65 ft (19.8 m)

14.5 ft (4.4 m)

20.3 ft (6.1 M)

1650 lbs (750 kg)

1300 lbs (590 kg)

200 lb force

(890 N)

Table 6-1. Operating Specifications

Maximum Operating Wind Speed

Gross Machine Weight (Approximate)

Drive Speed (slow)

Drive Speed (fast)

Lift Speed (platform empty)

Lowering Speed (platform empty)

Maximum Operating Hydraulic Pressure

Power Supply Diesel Engine

Maximum Ground Bearing Pressure

Maximum Outrigger Pad Load

Maximum Tire Load Rating

28 mph

(12.5 m/s)

35,935 lbs

(16,300 kg)

0.4 mph (0.6 f t/sec) (0.2 m/s)

1.9 mph (2.8 f t/sec)

(0.86 m/s)

0.89 ft/s

(0.27 m/s)

1 ft/s

(0.3 m/s)

2756 psi

(185 bar)

152 psi

(1.05 N/mm²)

17,020 lbs

(7720 kg)

14,595 lbs

(6620 kg)

6-2 – JLG Lift – 3121324

SECTION 6 - GENERAL SPECIFICATIONS AND OPERATOR MAINTENANCE

Table 6-1. Operating Specifications

Electrical System Voltage 24 V

Ground Clearance

(27.4 cm)

Dimensional Data

Table 6-2. Dimensional Data

Tr an sp or t He ig h t (rails up)

Platform Height (Stowed)

Platform dimensions (extension retracted)

Platform dimensions (extension extended)

Transpor t Dimensions

14 ft

(4.24 m)

10.3 ft

(3.14 m)

8 x 18 f t

(2.45 x 5.4 m)

8 x 26 ft

(2.45 x 7.8 m)

19 x 8.2 x 10.3 f t

(5.77 x 2.51 x 3.14 m)

10.8 in.

Capacities

Fuel Tank 23.8 gal (90 L)

Hydraulic Tank 68.7 gal (260 L)

Engine Crankcase w it h F i lt er without Filter

Tires

Size 315/80R 22.5

Pressure 101.5 psi (7.0 bar)

Table 6-3. Capacities

11 qt (10.5 L)

10.6 qt (10 L)

Table 6-4. Tire Specifications

3121324 – JLG Lift – 6-3

SECTION 6 - GENERAL SPECIFICATIONS AND OPERATOR MAINTENANCE

Engine

Table 6-5. Engine Specifications

Type Deutz F4L 2011 Deutz D2011 L04 i

# of Cylinders 4

Displacement 3108 cm³

Bore 3.7 in (94 mm)

Stroke 4.4 in (112 mm)

Fuel Type Diesel

Batteries

Table 6-6. Engine Battery Specifications

Voltage 12V

Amp Hour 100

Amp 880

Component Weights

Table 6-7. Component Weights

Component Weight

Fixed Platform 2425 lbs

(1100 kg)

Chassis with Foam Filled Tires 12,787 lbs

(5800 kg)

Arm Assembly 15,653 lbs

(7100 kg)

6-4 – JLG Lift – 3121324

SECTION 6 - GENERAL SPECIFICATIONS AND OPERATOR MAINTENANCE

AMBIENT AIR TEMPERATURE

NO OPERATION ABOVE THIS AMBIENT TEMPERATURE

120°F (49°C)

110°F (43°C)

100°F (38°C)

90°F (32°C)

SAE 20W-50

80°F (27°C)

70°F (21°C)

60°F (16°C)

50°F (10°C)

ENGINE SPECIFICATIONS

SUMMER GRADE FUEL

SAE OW-30

SAE 5W-30

SAE OW-40

SAE 5W-40

SAE 10W-40

SAE 10W-30

SAE 15W-40

40°F (4°C)

30°F (-1°C)

ENGINE WILL START AND OPERATE UNAIDED AT THIS TEMPERATURE WITH THE RECOMMENDED FLUIDS AND A FULLY CHARGED BATTERY

ENGINE WILL START AND OPERATE AT THIS TEMPERATURE WITH THE RECOMMENDED FLUIDS, A FULLY CHARGED BATTERY AND THE AID OF A COMPLETE JLG SPECIFIED COLD WEATHER PACKAGE (IE. ENGINE BLOCK HEATER, ETHER INJECTION OR GLOW PLUGS, BATTERY WARMER AND HYDRAULIC OIL TANK HEATER)

NO OPERATION BELOW THIS AMBIENT TEMPERATURE

4150548 C

WINTER GRADE FUEL

WINTER GRADE FUEL WITH KEROSENE ADDED

20°F (-7°C)

10°F (-12°C)

0°F (-18°C)

-10°F (-23°C)

-20°F (-29°C)

-30°F (-34°C)

-40°F (-40°C)

Figure 6-1. Engine Operating Temperature Specifications (Deutz) - Sheet 1 of 2

3121324 – JLG Lift – 6-5

SECTION 6 - GENERAL SPECIFICATIONS AND OPERATOR MAINTENANCE

EXTENDED DRIVING WITH HYDRAULIC OIL TANK TEMPERATURES OF 180°F (82°C) OR ABOVE

IF EITHER OR BOTH CONDITIONS EXIST JLG HIGHLY RECOMMENDS THE ADDITION OF A HYDRAULIC OIL COOLER (CONSULT JLG SERVICE)

AMBIENT AIR TEMPERATURE

180°F (82°C) (HYD. OIL TANK TEMP.

120°F (49°C)

110°F (43°C)

100°F (38°C)

90°F (32°C)

NO OPERATION ABOVE THIS AMBIENT TEMPERATURE

PROLONGED OPERATION IN AMBIENT AIR TEMPERATURES OF 100°F (38°C) OR ABOVE

NOTE:

1) RECOMMENDATIONS ARE FOR AMBIENT TEMPERATURES CONSISTANTLY WITHIN SHOWN LIMITS

2) ALL VALUES ARE ASSUMED TO BE AT SEA LEVEL

80°F (27°C)

70°F (21°C)

60°F (16°C)

50°F (10°C)

40°F (4°C)

30°F (-1°C)

20°F (-7°C)

10°F (-12°C)

0°F (-18°C)

-10°F (-23°C)

-20°F (-29°C)

-30°F (-34°C)

-40°F (-40°C)

MOBIL DTE 13

MOBIL 424 10W-30

EXXON UNIVIS HVI 26

NO OPERATION BELOW THIS AMBIENT TEMPERATURE

DO NOT START UP HYDRAULIC SYSTEM WITHOUT HEATING AIDS WITH MOBILE 424 HYDRAULIC OIL BELOW THIS TEMPERATURE

DO NOT START UP HYDRAULIC SYSTEM WITHOUT HEATING AIDS AND COLD WEATHER HYDRAULIC OIL BELOW THIS TEMPERATURE

HYDRAULIC SPECIFICATIONS

°F °C

+32 0

+23 -5

+14 -10

+5 -15

-4 -20

-13 -25

AMBIENT TEMPERATURE

-22 -30

0 10 20 30 40 50 60

% OF ADDED KEROSENE

SUMMER - GRADE FUEL

WINTER - GRAD FUEL

Figure 6-2. Engine Operating Temperature Specifications (Deutz) - Sheet 2 of 2

6-6 – JLG Lift – 3121324

SECTION 6 - GENERAL SPECIFICATIONS AND OPERATOR MAINTENANCE

Lubrication

Hydraulic Oil

Table 6-8. Hydraulic Oil

HYDRAULIC SYSTEM OPERATING

TEMPERATURE RANGE

0° to +23°F

(-18° to -5°C)

0° to +210°F

(-18° to +100°C)

+50° to +210°F

(+10° to +100°C)

NOTE: Hydraulic oils must have anti-wear qualities at least to API

Service Classification GL-3, and sufficient chemical stability for mobile hydraulic system service. JLG Industries recommends Mobilfluid 424 hydraulic oil, which has an SAE viscosity index of 152.

When temperatures remain below 20°F (-7°C), JLG Industries recommends the use of Mobil DTE13.

SAE VISCOSITY GRADE

10W

10W-20, 10W-30

20W-20

NOTE: Aside from JLG recommendations, it is not advisable to

mix oils of different brands or types, as they may not contain the same required additives or be of comparable viscosities. If use of hydraulic oil other than Mobilfluid 424 is desired, contact JLG Industries for proper recommendations.

Lubrication Specifications

Table 6-9. Lubrication Specifications

KEY SPECIFICATIONS

Multipurpose Grease having a minimum dripping

MPG

EPGL

point of 350°F (176.7°C). Excellent water resistance and adhesive qualities, and being of extreme pressure type. (Timken OK 40 pounds minimum.)

Extreme Pressure Gear Lube (oil) meeting API service classification GL-5 or MIL-Spec MIL-L-2105.

Engine (crankcase) Oil. Gas - API SF/SG class, MIL-

L- 21 04 . D i es el - A PI C C/ CD cl a ss , M IL- L-2 1 04 B/ MIL-L-2104C.

Hydraulic Oil. API service classification GL-3, e.g.

Mobil 424.

3121324 – JLG Lift – 6-7

SECTION 6 - GENERAL SPECIFICATIONS AND OPERATOR MAINTENANCE

6.3 OPERATOR MAINTENANCE

1. Arm Pins

2. Outrigger Cylinders

3. Engine Compartment

4. Tie Rod End

5. Spindles

6. Oscillating Axle

7. Fuel Tank (electrical/hydraulic compart-

ment) (not shown)

Figure 6-3. Operator Maintenance and Lubrication Diagram

6-8 – JLG Lift – 3121324

SECTION 6 - GENERAL SPECIFICATIONS AND OPERATOR MAINTENANCE

NOTE: The following numbers correspond with those in Figure 6-

3., Operator Maintenance and Lubrication Diagram.

NOTE: Be sure to grease all like items on the opposite side of

machine.

1. Arm Pin

• Lube Points - 36 Grease Fittings

• Capacity - As Required

•Lube - MPG

• Interval - As Required

2. Outrigger Cylinders

• Lube Points - 4 Grease Fittings

• Capacity - As Required

•Lube - MPG

• Interval - As Required

3121324 – JLG Lift – 6-9

SECTION 6 - GENERAL SPECIFICATIONS AND OPERATOR MAINTENANCE

3. Engine Compartment

a. Engine Oil Check/Fill

• Lube Points - Fill Cap and Dip Stick

• Capacity - See Engine Manual

•Lube - EO SAE 20W20

• Interval - Every 3 months or 150 hours of operation

b. Air Filter

• Lube Points - Replaceable Element

• Interval - Every 6 months or 300 hours of operation

6-10 – JLG Lift – 3121324

SECTION 6 - GENERAL SPECIFICATIONS AND OPERATOR MAINTENANCE

c. Hydraulic Oil Check/Fill

• Lube Points - Fill Cap and Site Gage

• Capacity - 68.7 gal (260 L)

•Lube - HO

• Interval - Check oil daily, change every 1200 hours of operation

4. Tie Rod End

• Lube Points - 2 Grease Fittings

• Capacity - As Required

•Lube - MPG

• Interval - As Required

3121324 – JLG Lift – 6-11

SECTION 6 - GENERAL SPECIFICATIONS AND OPERATOR MAINTENANCE

5. Spindles

• Lube Points - 2 Grease Fittings

• Capacity - As Required

•Lube - MPG

• Interval - As Required

6. Oscillating Axle

• Lube Points - 3 Grease Fittings

• Capacity - As Required

•Lube - MPG

• Interval - As Required

6-12 – JLG Lift – 3121324

SECTION 6 - GENERAL SPECIFICATIONS AND OPERATOR MAINTENANCE

7. Fuel Tank (Opposite Engine Compartment)

• Capacity - 90 L (23.8 gal)

• Lube - Diesel Fuel

• Interval - Check fuel periodically during each use

6.4 TIRES AND WHEELS

Tire Damage

For pneumatic tires, JLG Industries, Inc. recommends that when any cut, rip, or tear is discovered that exposes sidewall or tread area cords in the tire, measures must be taken to remove the JLG product from service immediately. Arrangements must be made for replacement of the tire or tire assembly.

For polyurethane foam filled tires, JLG Industries, Inc. recommends that when any of the conditions listed below are discovered, measures must be taken to remove the JLG product from service immediately and arrangements must be made for replacement of the tire or tire assembly.

• a smooth, even cut through the cord plies which exceeds 3 inches (7.5 cm) in total length

• any tears or rips (ragged edges) in the cord plies which exceeds 1 inch (2.5 cm) in any direction

• any punctures which exceed 1 inch (2.5 cm) in diameter

• any damage to the bead area cords of the tire

If a tire is damaged but is within the above noted criteria, the tire must be inspected on a daily basis to insure the damage has not propagated beyond the allowable criteria.

3121324 – JLG Lift – 6-13

SECTION 6 - GENERAL SPECIFICATIONS AND OPERATOR MAINTENANCE

Tire Replacement

JLG recommends a replacement tire be the same size, ply and brand as originally installed on the machine. Please refer to the JLG Parts Manual for the part number of the approved tires for a particular machine and model. If not using a JLG approved replacement tire, it is recommended that replacement tires have the following characteristics:

• Equal or greater ply/load rating and size of original.

• Tire tread contact width equal or greater than original.

• Wheel diameter, width, and offset dimensions equal to the original.

Unless specifically approved by JLG Industries, Inc. do not replace a foam filled tire assembly with a pneumatic tire. When selecting and installing a replacement tire, ensure that all tires are inflated to the pressure recommended by JLG. Due to size variations between tire brands, both tires on the same axle should be the same.

Wheel Replacement

The rims installed on each product model have been designed for stability requirements which consist of track width, tire pressure, and load capacity. Size changes such as rim width, center piece location, larger or smaller diameter, etc., without written factory recommendations, may result in an unsafe condition regarding stability.

6-14 – JLG Lift – 3121324

SECTION 6 - GENERAL SPECIFICATIONS AND OPERATOR MAINTENANCE

Wheel Installation

It is extremely important to apply and maintain proper wheel mounting torque.

WHEEL NUTS MUST BE INSTALLED AND MAINTAINED AT THE PROPER TORQUE TO PREVENT LOOSE WHEELS, BROKEN STUDS, AND POSSIBLE DANGEROUS SEPARATION OF WHEEL FROM THE AXLE. BE SURE TO USE ONLY THE NUTS MATCHED TO THE CONE ANGLE OF THE WHEEL.

Tighten the lug nuts to the proper torque to prevent wheels from coming loose. Use a torque wrench to tighten the fasteners. If you do not have a torque wrench, tighten the fasteners with a lug wrench, then immediately have a service garage or dealer tighten the lug nuts to the proper torque. Over-tightening will result in breaking the studs or permanently deforming the mounting stud holes in the wheels. The proper procedure for attaching wheels is as follows:

1. Start all nuts by hand to prevent cross threading. DO NOT use a lubricant on threads or nuts.

2. Tighten nuts in the following sequence:

6 Lug Pattern

3. The tightening of the nuts should be done in stages. Fol-

lowing the recommended sequence, tighten the nuts per wheel torque chart.

TORQUE SEQUENCE

1st Stage 2nd Stage 3rd Stage

150-190 ft lb s

(210 - 270 Nm)

230 - 270 ft lbs (320-380 Nm)

305 - 343 ft lbs

( 440 - 480 Nm)

4. Wheel nuts should be torqued after the first 50 hours of

operation and after each wheel removal. Check torque every 3 months or 150 hours of operation.

3121324 – JLG Lift – 6-15

SECTION 6 - GENERAL SPECIFICATIONS AND OPERATOR MAINTENANCE

NOTES:

6-16 – JLG Lift – 3121324

SECTION 7 - INSPECTION AND REPAIR LOG

SECTION 7. INSPECTION AND REPAIR LOG

Table 7-1. Inspection and Repair Log

Date Comments

3121324 – JLG Lift – 7-1

SECTION 7 - INSPECTION AND REPAIR LOG

Table 7-1. Inspection and Repair Log

Date Comments

7-2 – JLG Lift – 3121324

TRANSFER OF OWNERSHIP

) ____________________

Thank You,

Product Safety & Reliability Department

JLG Industries, Inc.

13224 Fountainhead Plaza

Hagerstown, MD 21742

USA

Telephone: +1-717-485-6591

Fax: +1-301-745-3713

) ____________________

__________________________________________________

If you now own but ARE NOT the original purchaser of the product covered by this

An Oshkosh Corporation Company

To Product Owner:

manual, we would like to know who you are. For the purpose of receiving safety-related

bulletins, it is very important to keep JLG Industries, Inc. updated with the current

ownership of all JLG products. JLG maintains owner information for each JLG product

Please use this form to provide JLG with updated information with regard to the

and uses this information in cases where owner notification is necessary.

current ownership of JLG products. Please return completed form to the JLG Product

Safety & Reliability Department via facsimile or mail to address as specified below.

NOTE: Leased or rented units should not be included on this form.

Mfg. Model: _____________

Serial Number: ____________________________________________________________

Previous Owner: ___________________________________________________________

Address: _________________________________________________________________

_________________________________________________________________________

Country: _________________________ Telephone: (_______

Date of Transfer: _________________________________

Current Owner: ____________________________________________________________

__________________________________________________

_________________________________________________________________________

Address: _______________

Country: _________________________ Telephone: (_______

Who in your organization should we notify?

Name: ___________________________________________________________________

Title:____________________________________________________________________

Corporate Office JLG Industries, Inc. 1 JLG Drive McConnellsburg PA. 17233-9533 USA

JLG Worldwide Locations

JLG Industries (Australia) P.O. Box 5119 11 Bolwarra Road Por t Macq ua rie N.S.W. 2444 Australia

+61 2 65 811111

+61 2 65 810122

JLG Deutschland GmbH Max-Planck-Str. 21 D - 27721 Ritterhude - Ihlpohl Germany

+49 (0)421 69 350 20

+49 (0)421 69 350 45

JLG Polska UI. Krolewska 00-060 Warsawa Poland

+48 (0)914 320 245

+48 (0)914 358 200

JLG Latino Americana Ltda. Rua Eng. Carlos Stevenson, 80-Suite 71 13092-310 Campinas-SP Brazil

+55 19 3295 0407

+55 19 3295 1025

JLG Equipment Services Ltd. Rm 1107 Landmark North 39 Lung Sum Avenue Sheung Shui N. T. Hong Kong

(852) 2639 5783

(852) 2639 5797

JLG Industries (Scotland) Wright Business Centre 1 Lonmay Road Queenslie, Glasgow G33 4EL Scotland

+44 (0)141 781 6700

+44 (0)141 773 1907

(717) 485-5161

(717) 485-6417

JLG Industries (UK) Ltd Bentley House Bentley Avenue Middleton Greater Manchester M24 2GP - England

+44 (0)161 654 1000

+44 (0)161 654 1001

JLG Industries (Italia) s.r.l. Via Po. 22 20010 Pregnana Milanese - MI Italy

+39 029 359 5210

+39 029 359 5845

Plataformas Elevadoras JLG Iberica, S.L. Trapadella, 2 P.I. Castellbisbal Sur 08755 Castellbisbal, Barcelona Spain

+34 93 772 4700

+34 93 771 1762

3121324

JLG France SAS Z.I. de Baulieu 47400 Fauillet France

+33 (0)5 53 88 31 70

+33 (0)5 53 88 31 79

JLG Europe B.V. Polaris Avenue 63 2132 JH Hoofddorp The Netherlands

+31 (0)23 565 5665

+31 (0)23 557 2493

JLG Sverige AB Enkopingsvagen 150 Box 704 SE - 176 27 Jarfalla Sweden

+46 (0)850 659 500

+46 (0)850 659 534

www.jlg.com

JLG 80SL Operator Manual

Specifications and Main Features

Frequently Asked Questions

User Manual

1.1 GENERAL

SECTION 1. SAFETY PRECAUTIONS

1.2 PRE-OPERATION

Operator Training and Knowledge

Workplace Inspection

Machine Inspection

1.3 OPERATION

General

Trip and Fall Hazards

Electrocution Hazards

Tipping Hazards

Crushing and Collision Hazards

1.4 TOWING, LIFTING, AND HAULING

1.5 MAINTENANCE

General

Maintenance Hazards

Battery Hazards

SECTION 2. USER RESPONSIBILITIES, MACHINE PREPARATION AND INSPECTION

2.1 PERSONNEL TRAINING

Operator Training

Training Supervision

Operator Responsibility

2.2 PREPARATION, INSPECTION, AND MAINTENANCE

2.3 PRE-START INSPECTION

Function Check

Limit Switch Checks

SECTION 3. USER RESPONSIBILITIES AND MACHINE CONTROL

3.1 GENERAL

3.2 OPERATING CHARACTERISTICS AND LIMITATIONS

General

Placards

Capacities

3.3 CONTROLS AND INDICATORS

Ground Control Station

Engine Control

Main Terminal Box

Ground Control Console

3.4 PLATFORM CONTROL CONSOLE

SECTION 4. MACHINE OPERATION

4.1 DESCRIPTION

General Description of the Functions and Components

4.2 STARTING

4.3 LIFTING AND LOWERING

4.4 AUTOMATIC SELF LEVELING CHASSIS

4.5 DRIVING THE MACHINE FROM THE PLATFORM

4.6 STEERING

4.7 HYDRAULIC PLATFORM EXTENSION

4.8 EMERGENCY LOWERING - MANUAL DESCENT

4.9 PARKING AND STOWING

4.10 TIE DOWN/LIFT LUGS

Tie Down

4.11 TRANSPORT AND STORAGE OF THE MACHINE

Platform Rail Lowering Tool Procedure

Main Platform Side Rails and Extension End Rail

Main Platform End Rails/Gate and Extension Side Rails

Rail Raising Procedure

SECTION 5. EMERGENCY PROCEDURES

5.1 GENERAL

Emergency Stop Switch

Platform Caught Overhead

Righting of Tipped Machine

Post-Incident Inspection

5.2 EMERGENCY OPERATION

Use of Ground Controls

Operator Unable to Control Machine

Incident Notification

5.3 MANUAL PROCEDURES

Manual Platform Deck Retraction

Manual Descent

5.4 EMERGENCY TOWING

Prior to Towing

SECTION 6. GENERAL SPECIFICATIONS AND OPERATOR MAINTENANCE

6.1 INTRODUCTION

6.2 OPERATING SPECIFICATIONS

Dimensional Data

Capacities
