USER INSTRUCTIONS

PolyChem M-series Pumps ISO and ANSI

Installation

Operation

Maintenance

Foot mounted, PFA lined , chemical process pumps with magnetic drive

PCN=71569218 07-11 (E) (incorporating P-30-503-E) Original instructions.

These instructions must be read prior to installing,

operating, using and maintaining this equipment.

USER INSTRUCTIONS PolyChem M-SERIES ENGLISH 71569218 07-11

Page 2 of 60

CONTENTS

Page

1 INTRODUCTION AND SAFETY .......................... 4

1.1 General ............................................................ 4

1.2 CE marking and approvals .............................. 4

1.3 Disclaimer ........................................................ 4

1.4 Copyright ......................................................... 4

1.5 Duty conditions ................................................ 4

1.6 Safety .............................................................. 5

1.7 Nameplate and safety labels ........................... 8

1.8 Specific machine performance ........................ 8

1.9 Noise level ....................................................... 9

2 TRANSPORT AND STORAGE .......................... 10

2.1 Consignment receipt and unpacking ............. 10

2.2 Handling ........................................................ 10

2.3 Lifting ............................................................. 10

2.4 Storage .......................................................... 11

2.5 Recycling and end of product life .................. 11

3 DESCRIPTION ................................................... 12

3.1 Configurations ............................................... 12

3.2 Nomenclature ................................................ 12

3.3 Design of major parts .................................... 12

3.4 Performance and operation limits .................. 13

4 INSTALLATION .................................................. 15

4.1 Location ......................................................... 15

4.2 Part assemblies ............................................. 15

4.3 Foundation ..................................................... 15

4.4 Grouting ......................................................... 17

4.5 Initial alignment – Long-coupled.................... 18

4.6 Piping ............................................................. 18

4.7 Electrical connections .................................... 25

4.8 Final shaft alignment check – Long-coupled . 25

4.9 Protection systems ........................................ 25

Page

6 MAINTENANCE ................................................. 31

6.1 Maintenance schedule .................................. 32

6.2 Spare parts .................................................... 33

6.3 Recommended spares and consumable items 33

6.4 Tools required ................................................ 33

6.5 Fastener torques ........................................... 35

6.6 Impeller ......................................................... 35

6.7 Pump removal and disassembly ................... 37

6.8 Examination of parts ..................................... 44

6.9 Assembly of pump ........................................ 47

7 FAULTS; CAUSES AND REMEDIES ................ 52

8 PARTS LIST AND DRAWINGS ......................... 55

8.1 PolyChem Group A and 1 Close Coupled ..... 55

8.2 PolyChem Group A and 1 Long Coupled ...... 55

8.3 PolyChem Group B and 2 Close Coupled .... 56

8.4 PolyChem Group B and 2 Long Coupled ..... 56

8.5 PolyChem Group A and 1 ............................. 57

8.6 PolyChem Group B and 2 ............................. 57

9 CERTIFICATION ................................................ 58

10 OTHER RELEVANT DOCUMENTATION AND

MANUALS .......................................................... 58

10.1 Supplementary User Instructions .......... 58

10.2 Change notes ........................................ 58

10.3 Additional sources of information .......... 58

5 COMMISSIONING, STARTUP, OPERATION

AND SHUTDOWN .............................................. 26

5.1 Pre-commissioning procedure ....................... 26

5.2 Pump lubricants ............................................. 26

5.3 Direction of rotation ....................................... 28

5.4 Guarding ........................................................ 28

5.5 Priming and auxiliary supplies ....................... 29

5.6 Starting the pump .......................................... 29

5.7 Running or operation ..................................... 30

5.8 Stopping and shutdown ................................. 31

5.9 Hydraulic, mechanical and electrical duty ..... 31

flowserve.com

USER INSTRUCTIONS PolyChem M-SERIES ENGLISH 71569218 07-11

Page 3 of 60

INDEX

Page

Additional sources of information (10.3) 58 Assembly of pump (6.9) 47 CE marking and approvals (1.2) 4 Change notes (10.2) 58 Configurations (3.1) 12 Consignment receipt and unpacking (2.1) 10 Copyright (1.4) 4 Design of major parts (3.3) 12 Direction of rotation (5.3) 28 Disclaimer (1.3) 4 Drawing Group A and 1 Close Coupled (8.1) 55 Drawing Group A and 1 Long Coupled (8.2) 55 Drawing Group B and 2 Close Coupled (8.3) 56 Drawing Group B and 2 Long Coupled (8.4) 56 Duty conditions (1.5) 4 Electrical connections (4.7) 25 Examination of parts (6.8) 44 Fastener torques (6.5) 35 Final shaft alignment check (4.8) 25 Foundation (4.3) 15 General (1.1) 4 Grouting (4.4) 17 Guarding (5.4) 28 Handling (2.2) 10 Hydraulic, mechanical and electrical duty (5.9) 31 Impeller (6.6) 35 Initial alignment (4.5) 18

Page

Lifting (2.3) 10 Location (4.1) 15 Maintenance schedule (6.1) 32 Nameplate and safety labels (1.7) 8 Noise level (1.8) 9 Nomenclature (3.2) 12 Part assemblies (4.2) 15 Parts List Group A and 1 (8.5) 57 Parts List Group B and 2 (8.6) 57 Performance and operation limits (3.4) 13 Piping (4.6) 18 Pre-commissioning procedure (5.1) 26 Priming and auxiliary supplies (5.5) 29 Protection systems (4.9) 25 Pump lubricants (5.2) 26 Pump removal and disassembly (6.7) 37 Recommended spares and consumable items (6.3) 33 Recycling and end of product life (2.5) 11 Running or operation (5.7) 30 Safety (1.6) 5 Spare parts (6.2) 33 Starting the pump (5.6) 29 Stopping and shutdown (5.8) 31 Storage (2.4) 11 Supplementary user instructions (10.1) 58 Tools required (6.4) 33

flowserve.com

USER INSTRUCTIONS PolyChem M-SERIES ENGLISH 71569218 07-11

Page 4 of 60

1 INTRODUCTION AND SAFETY

1.1 General

These instructions must always be kept

close to the product's operating location or directly with the product.

Flowserve products are designed, developed and manufactured with state-of-the-art technologies in modern facilities. The unit is produced with great care and commitment to continuous quality control, utilising sophisticated quality techniques and safety requirements.

Flowserve is committed to continuous quality improvement and being at service for any further information about the product in its installation and operation or about its support products, repair and diagnostic services.

These instructions are intended to facilitate familiarization with the product and its permitted use. Operating the product in compliance with these instructions is important to help ensure reliability in service and avoid risks. The instructions may not take into account local regulations; ensure such regulations are observed by all, including those installing the product. Always coordinate repair activity with operations personnel, and follow all plant safety requirements and applicable safety and health laws and regulations.

These instructions must be read prior to installing, operating, using and maintaining the equipment in any region worldwide. The equipment must not be put into service until all the conditions relating to safety, noted in the instructions, have been met. Failure to follow and apply the present user instructions is considered to be misuse. Personal injury, product damage, delay or failure caused by misuse are not covered by the Flowserve warranty.

1.2 CE marking and approvals

It is a legal requirement that machinery and equipment put into service within certain regions of the world shall conform with the applicable CE Marking Directives covering Machinery and, where applicable, Low Voltage Equipment, Electromagnetic Compatibility (EMC), Pressure Equipment Directive (PED) and Equipment for Potentially Explosive Atmospheres (ATEX).

Where applicable, the Directives and any additional Approvals, cover important safety aspects relating to machinery and equipment and the satisfactory provision

of technical documents and safety instructions. Where applicable this document incorporates information relevant to these Directives and Approvals.

To confirm the Approvals applying and if the product is CE marked, check the serial number plate markings and the Certification. (See section 9, Certification.)

1.3 Disclaimer

Flowserve manufactures products to exacting International Quality Management System Standards as certified and audited by external Quality Assurance organisations. Genuine parts and accessories have been designed, tested and incorporated into the products to help ensure their continued product quality and performance in use. As Flowserve cannot test parts and accessories sourced from other vendors the incorrect incorporation of such parts and accessories may adversely affect the performance and safety features of the products. The failure to properly select, install or use authorised Flowserve parts and accessories is considered to be misuse. Damage or failure caused by misuse is not covered by the Flowserve warranty. In addition, any modification of Flowserve products or removal of original components may impair the safety of these products in their use.

1.4 Copyright

1.5 Duty conditions

This product has been selected to meet the specifications of your purchase order. The acknowledgement of these conditions has been sent separately to the Purchaser. A copy should be kept with these instructions.

The product must not be operated beyond

the parameters specified for the application. If there is any doubt as to the suitability of the product for the application intended, contact Flowserve for advice, quoting the serial number.

If the conditions of service on your purchase order are going to be changed (for example liquid pumped, temperature or duty) it is requested that the user seeks the written agreement of Flowserve before start up.

flowserve.com

USER INSTRUCTIONS PolyChem M-SERIES ENGLISH 71569218 07-11

Page 5 of 60

1.6 Safety

1.6.1 Summary of safety markings

These User Instructions contain specific safety markings where non-observance of an instruction would cause hazards. The specific safety markings are:

This symbol indicates electrical safety instructions where non-compliance will involve a high risk to personal safety or the loss of life.

This symbol indicates safety instructions where non-compliance would affect personal safety and could result in loss of life.

This symbol indicates “hazardous and toxic fluid” safety instructions where non-compliance would affect personal safety and could result in loss of life.

This symbol indicates safety instructions where non-compliance will involve some risk to safe operation and personal safety and would damage the equipment or property.

This symbol indicates "strong magnetic field" safety instructions where non-compliance would affect personal safety, pacemakers, instruments or stored data sensitive to magnetic fields.

Always coordinate repair activity with operations and health and safety personnel, and follow all plant safety requirements and applicable safety and health laws and regulations.

1.6.3 Safety action

This is a summary of conditions and actions to help prevent injury to personnel and damage to the environment and to equipment. For products used in potentially explosive atmospheres section 1.6.4 also applies.

MAGNETIC FIELD PRESENT: This equipment may affect electronic equipment or other devices that are influenced by magnetic fields. Because magnetic drive pumps contain powerful magnets, anyone with a heart pacemaker MUST NOT disassemble these pumps. Also, keep all credit cards, bank cards, watches, computer disks and anything else which can be damaged by magnetic fields away from these pumps when disassembled.

NEVER DO MAINTENANCE WORK WHEN THE UNIT IS CONNECTED TO POWER (Lock out.)

GUARDS MUST NOT BE REMOVED WHILE

THE PUMP IS OPERATIONAL

This symbol indicates explosive atmosphere zone marking according to ATEX. It is used in safety instructions where non-compliance in the hazardous area would cause the risk of an explosion.

This symbol is used in safety instructions to remind not to rub non-metallic surfaces with a dry cloth; ensure the cloth is damp. It is used in safety instructions where non-compliance in the hazardous area would cause the risk of an explosion.

This sign is not a safety symbol but indicates

an important instruction in the assembly process.

1.6.2 Personnel qualification and training

All personnel involved in the operation, installation, inspection and maintenance of the unit must be qualified to carry out the work involved. If the personnel in question do not already possess the necessary knowledge and skill, appropriate training and instruction must be provided. If required the operator may commission the manufacturer/supplier to provide applicable training.

DRAIN THE PUMP AND ISOLATE PIPEWORK BEFORE DISMANTLING THE PUMP The appropriate safety precautions should be taken where the pumped liquids are hazardous.

FLUORO-ELASTOMERS (When fitted.) When a pump has experienced temperatures over 250 ºC (482 ºF), partial decomposition of fluoroelastomers (example: Viton) will occur. In this condition these are extremely dangerous and skin contact must be avoided.

HANDLING COMPONENTS Many precision parts have sharp corners and the wearing of appropriate safety gloves and equipment is required when handling these components. To lift heavy pieces above 25 kg (55 lb) use a crane appropriate for the mass and in accordance with current local regulations.

THERMAL SHOCK Rapid changes in the temperature of the liquid within the pump can cause thermal shock, which can result in damage or breakage of components and should be avoided.

NEVER APPLY HEAT TO REMOVE IMPELLER Trapped lubricant or vapour could cause an explosion.

flowserve.com

USER INSTRUCTIONS PolyChem M-SERIES ENGLISH 71569218 07-11

Page 6 of 60

HOT (and cold) PARTS If hot or freezing components or auxiliary heating supplies can present a danger to operators and persons entering the immediate area action must be taken to avoid accidental contact. If complete protection is not possible, the machine access must be limited to maintenance staff only, with clear visual warnings and indicators to those entering the immediate area. Note: bearing housings must not be insulated and drive motors and bearings may be hot.

If the temperature is greater than 80 ºC (175 ºF) or below -5 ºC (23 ºF) in a restricted zone, or exceeds local regulations, action as above shall be taken.

HAZARDOUS LIQUIDS When the pump is handling hazardous liquids care must be taken to avoid exposure to the liquid by appropriate siting of the pump, limiting personnel access and by operator training. If the liquid is flammable and or explosive, strict safety procedures must be applied.

ALWAYS USE THE JACKBOLTS TO SEPARATE THE POWER END FROM THE WET END ASSEMBLIES.

PREVENT EXCESSIVE EXTERNAL PIPE LOAD Do not use pump as a support for piping. Do not mount expansion joints, unless allowed by Flowserve in writing, so that their force, due to internal pressure, acts on the pump flange.

NEVER RUN THE PUMP DRY

Operating the magnetic coupling dry may cause immediate damage to the bearings, magnets, etc..

NEVER OPERATE THE PUMP WITH THE SUCTION VALVE CLOSED It should be fully opened when the pump is running.

NEVER OPERATE THE PUMP AT ZERO FLOW OR FOR EXTENDED PERIODS BELOW THE MINIMUM CONTINUOUS FLOW

DO NOT RUN THE PUMP AT ABNORMALLY HIGH OR LOW FLOW RATES Operating at a flow rate higher than normal or at a flow rate with no back pressure on the pump may overload the motor and cause cavitation. Low flow rates may cause a reduction in pump/bearing life, overheating of the pump, instability and cavitation/vibration.

THE PUMP SHAFT MUST TURN CLOCKWISE WHEN VIEWED FROM THE MOTOR END It is absolutely essential that the rotation of the motor be checked before installation of the coupling spacer and starting the pump.

PolyChem M-series pumps are sized based on a specific application. In the event the user elects to operate this pump in a service other than what it was originally sized for, a Flowserve sales engineer should be contacted to evaluate the new application.

1.6.4 Products used in potentially explosive

atmospheres

ENSURE CORRECT LUBRICATION (See section 5, Commissioning, startup, operation and shutdown.)

NEVER EXCEED THE MAXIMUM DESIGN PRESSURE (MDP) AT THE TEMPERATURE SHOWN ON THE PUMP NAMEPLATE See section 3 for pressure versus temperature ratings based on the material of construction.

NEVER OPERATE THE PUMP WITH THE DISCHARGE VALVE CLOSED (Unless otherwise instructed at a specific point in the User Instructions.) (See section 5, Commissioning start-up, operation and shutdown.)

Measures are required to:

 Avoid excess temperature  Prevent build up of explosive mixtures  Prevent the generation of sparks  Prevent leakages  Maintain the pump to avoid hazard

The following instructions for pumps and pump units when installed in potentially explosive atmospheres must be followed to help ensure explosion protection. For ATEX, both electrical and non-electrical equipment must meet the requirements of European Directive 94/9/EC. Always observe the regional legal Ex requirements eg Ex electrical items outside the EU may be required certified to other than ATEX eg IECEx, UL.

1.6.4.1 Scope of compliance

NEVER RUN THE PUMP DRY OR WITHOUT PROPER PRIME (Pump flooded).

Use equipment only in the zone for which it is appropriate. Always check that the driver, drive coupling assembly and pump equipment are suitably

flowserve.com

USER INSTRUCTIONS PolyChem M-SERIES ENGLISH 71569218 07-11

Page 7 of 60

Temperature class

to EN13463-1

Maximum surface

temperature permitted

Temperature limit of

liquid handled

T6 T5 T4 T3 T2 T1

85 °C (185 °F) 100 °C (212 °F) 135 °C (275 °F) 200 °C (392 °F) 300 °C (572 °F) 450 °C (842 °F)

Consult Flowserve Consult Flowserve

115 °C (239 °F) * 180 °C (356 °F) * 275 °C (527 °F) * 400 °C (752 °F) *

rated and/or certified for the classification of the specific atmosphere in which they are to be installed.

Where Flowserve has supplied only the bare shaft pump, the Ex rating applies only to the pump. The party responsible for assembling the ATEX pump set shall select the coupling, driver and any additional equipment, with the necessary CE Certificate/ Declaration of Conformity establishing it is suitable for the area in which it is to be installed.

The output from a variable frequency drive (VFD) can cause additional heating effects in the motor and so, for pumps sets with a VFD, the ATEX Certification for the motor must state that it is covers the situation where electrical supply is from the VFD. This particular requirement still applies even if the VFD is in a safe area.

1.6.4.2 Marking

An example of ATEX equipment marking is shown below. The actual classification of the pump will be engraved on the nameplate.

II 2 GD c IIC 135 ºC (T4)

Equipment Group I = Mining II = Non-mining

Category 2 or M2 = high level protection 3 = normal level of protection

Gas and/or dust G = Gas D = Dust

c = Constructional safety

(in accordance with EN13463-5)

Gas Group IIA – Propane (typical) IIB – Ethylene (typical) IIC – Hydrogen (typical)

Maximum surface temperature (Temperature Class) (see section 1.6.4.3.)

1.6.4.3 Avoiding excessive surface temperatures

ENSURE THE EQUIPMENT TEMPERATURE

CLASS IS SUITABLE FOR THE HAZARD ZONE Pumps have a temperature class as stated in the

ATEX Ex rating on the nameplate. These are based on a maximum ambient of 40 ºC (104 ºF); refer to Flowserve for higher ambient temperatures.

The surface temperature on the pump is influenced by the temperature of the liquid handled. The maximum permissible liquid temperature depends on the ATEX temperature class and must not exceed the values in the table that follows.

* The table only takes the ATEX temperature class into consideration. Pump

design or material, as well as component design or material, may further limit the maximum working temperature of the liquid.

The temperature rise at the seals and bearings and due to the minimum permitted flow rate is taken into account in the temperatures stated.

The responsibility for compliance with the specified maximum liquid temperature is with the plant operator.

Temperature classification “Tx” is used when the liquid

temperature varies and when the pump is required to be used in differently classified potentially explosive atmospheres. In this case the user is responsible for ensuring that the pump surface temperature does not exceed that permitted in its actual installed location.

Avoid mechanical, hydraulic or electrical overload by using motor overload trips, temperature monitors or a power monitor and make routine vibration monitoring checks.

In dirty or dusty environments, make regular checks and remove dirt from areas around close clearances, bearing housings and motors.

Where there is any risk of the pump being run against a closed valve generating high liquid and casing external surface temperatures fit an external surface temperature protection device.

1.6.4.4 Preventing the build up of explosive mixtures

ENSURE THE PUMP IS PROPERLY FILLED

AND VENTED AND DOES NOT RUN DRY Ensure the pump and relevant suction and discharge

pipeline system is totally filled with liquid at all times during the pump operation, so that an explosive atmosphere is prevented.

flowserve.com

USER INSTRUCTIONS PolyChem M-SERIES ENGLISH 71569218 07-11

Page 8 of 60

If the operation of the system cannot avoid this condition, fit an appropriate dry run protection device (for example liquid detection or a power monitor).

To avoid potential hazards from fugitive emissions of vapour or gas to atmosphere the surrounding area must be well ventilated.

1.6.4.5 Preventing sparks

To prevent a potential hazard from mechanical

contact, the coupling guard must be non-sparking. To avoid the potential hazard from random induced

current generating a spark, the baseplate must be properly grounded.

Avoid electrostatic charge: do not rub non-metallic

surfaces with a dry cloth; ensure cloth is damp. For ATEX the coupling must be selected to comply

with 94/9/EC. Correct coupling alignment must be maintained.

Additional requirement for metallic pumps on non-metallic baseplates

When metallic components are fitted on a nonmetallic baseplate they must be individually earthed.

1.6.4.6 Preventing leakage

To avoid potential explosion hazards during maintenance, the tools, cleaning and painting materials used must not give rise to sparking or adversely affect the ambient conditions. Where there is a risk from such tools or materials, maintenance must be conducted in a safe area.

It is recommended that a maintenance plan and schedule is adopted. (See section 6, Maintenance.)

1.7 Nameplate and safety labels

1.7.1 Nameplate

For details of nameplate, see the Declaration of Conformity and section 3.

1.7.2 Safety labels

The pump must only be used to handle liquids for which it has been approved to have the correct corrosion resistance.

Avoid entrapment of liquid in the pump and associated piping due to closing of suction and discharge valves, which could cause dangerous excessive pressures to occur if there is heat input to the liquid. This can occur if the pump is stationary or running.

Bursting of liquid containing parts due to freezing must be avoided by draining or protecting the pump and ancillary systems.

If leakage of liquid to atmosphere can result in a hazard, install a liquid detection .

1.6.4.7 Maintenance to avoid the hazard

CORRECT MAINTENANCE IS REQUIRED TO AVOID POTENTIAL HAZARDS WHICH GIVE A RISK OF EXPLOSION

The responsibility for compliance with maintenance instructions is with the plant operator.

Oil lubricated units only:

1.8 Specific machine performance

For performance parameters see section 1.5, Duty conditions. Where performance data has been supplied

separately to the purchaser these should be obtained and retained with these User Instructions.

flowserve.com

USER INSTRUCTIONS PolyChem M-SERIES ENGLISH 71569218 07-11

Page 9 of 60

Motor size and speed

kW (hp)

Typical sound pressure level LpA at 1 m reference 20 μPa, dBA

3 550 r/min

2 900 r/min

1 750 r/min

1 450 r/min

Pump

only

Pump and

motor

Pump

only

Pump and

motor

Pump

only

Pump and

motor

Pump

only

Pump and

motor

<0.55(<0.75)

0.75 (1)

1.1 (1.5)

1.5 (2)

2.2 (3)

3 (4)

4 (5)

5.5 (7.5)

7.5 (10)

11(15)

15 (20)

18.5 (25)

22 (30)

30 (40)

37 (50)

45 (60)

55 (75)

75 (100)

1.9 Noise level

Attention must be given to the exposure of personnel to the noise, and local legislation will define when guidance to personnel on noise limitation is required, and when noise exposure reduction is mandatory. This is typically 80 to 85 dBA.

The usual approach is to control the exposure time to the noise or to enclose the machine to reduce emitted sound. You may have already specified a limiting noise level when the equipment was ordered, however if no noise requirements were defined, then attention is drawn to the following table to give an indication of equipment noise level so that you can take the appropriate action in your plant.

Pump noise level is dependent on a number of factors the type of motor fitted, the operating capacity, pipework design and acoustic characteristics of the building.

Typical sound pressure levels measured in dB, and A-weighted are shown in the table below. The figures are indicative only, they are subject to a +3 dB tolerance, and cannot be guaranteed.

The motor noise assumed in the “pump and motor”

noise is that typically expected from standard and high

efficiency motors when on load directly driving the pump.

If a pump unit only has been purchased, for fitting with your own driver, then the "pump only" noise levels from the table should be combined with the level for the driver obtained from the supplier.

If the motor is driven by an inverter it may show an increase in noise level at some speeds. Consult a Noise Specialist for the combined calculation. It is recommended that where exposure approaches the prescribed limit, then site noise measurements should be made.

The values are in sound pressure level LpA at 1 m

(3.3 ft) from the machine, for “free field conditions over a reflecting plane”.

For estimating sound power level LWA (re 1 pW) then add 14 dBA to the sound pressure value.

 For units driven by equipment other than

electric motors or units contained within enclosures, see the accompanying information sheets and manuals.

Note: for 1 180 and 960 r/min reduce 1 450 r/min values by 2 dBA. For 880 and 720 r/min reduce 1 450 r/min values by 3 dBA.

flowserve.com

USER INSTRUCTIONS PolyChem M-SERIES ENGLISH 71569218 07-11

Page 10 of 60

2 TRANSPORT AND STORAGE

2.1 Consignment receipt and unpacking

Immediately after receipt of the equipment it must be checked against the delivery/shipping documents for its completeness and that there has been no damage in transportation. Any shortage and/or damage must be reported immediately to Flowserve Pump Division and must be received in writing within ten days of receipt of the equipment. Later claims cannot be accepted.

Check any crate, boxes or wrappings for any accessories or spare parts that may be packed separately with the equipment or attached to side walls of the box or equipment.

Each product has a unique serial number. Check that this number corresponds with that advised and always quote this number in correspondence as well as when ordering spare parts or further accessories.

2.2 Handling

Boxes, crates, pallets or cartons may be unloaded using fork lift vehicles or slings dependent on their size and construction.

2.3 Lifting

2.3.1.2 Bearing holder [3830]

Group B and 2: Insert an eye hook in the drilled and tapped hole located on the outside diameter of the bearing holder. Use either a sling or hook through the eye bolt.

2.3.1.3 Bearing housing [3200]

Group B and 2: insert either a sling or hook through the lifting lug located on the top of the housing.

2.3.1.4 Power end

Same as bearing housing.

2.3.1.5 Bare pump

Horizontal pumps: sling around the pump discharge nozzle and around the outboard end of the bearing housing with separate slings. Choker hitches must be used at both attachment points and pulled tight. Make sure the completion of the choker hitch on the discharge nozzle is toward the coupling end of the pump shaft as shown in Figure 2-1. The sling lengths should be adjusted to balance the load before attaching the lifting hook.

Figure 2-1

A crane must be used for all pump sets in excess of 25 kg (55 lb). Fully trained personnel must carry out lifting, in accordance with local regulations

Pumps and motors often have integral lifting lugs or eye bolts. These are intended for use in only lifting the individual piece of equipment.

Do not use eye bolts or cast-in lifting lugs to lift pump, motor and baseplate assemblies.

To avoid distortion, the pump unit should be lifted as shown.

Care must be taken to lift components or assemblies above the center of gravity to prevent the unit from flipping.

2.3.1 Lifting pump components

2.3.1.1 Casing [1100]

Use a choker hitch pulled tight around the discharge nozzle.

flowserve.com

USER INSTRUCTIONS PolyChem M-SERIES ENGLISH 71569218 07-11

Page 11 of 60

2.3.2 Lifting pump, motor and baseplate

assembly

If the baseplate has lifting holes cut in the sides at the end (Type D and Type E bases) insert lifting S hooks at the four corners and use slings or chains to connect to the lifting eye. Do not use slings through the lifting holes.

For other baseplates, sling around the pump discharge nozzle, and around the outboard end of the motor frame using choker hitches pulled tight. (Figure 2-1)

The sling should be positioned so the weight is not carried through the motor fan housing. Make sure the completion of the choker hitch on the discharge nozzle is toward the coupling end of the pump shaft as shown in Figure 2-1.

2.4 Storage

Store the pump in a clean, dry location away from vibration. Leave flange covers in place to keep dirt and other foreign material out of pump casing. Turn the pump shaft at regular intervals to prevent brinelling of the bearings.

The pump may be stored as above for up to 6 months. Consult Flowserve for preservative actions when a longer storage period is needed.

2.4.1 Short term storage and packaging

Normal packaging is designed to protect the pump and parts during shipment and for dry, indoor storage for up to six months or less. The following is an overview of our normal packaging:  All loose unmounted items are packaged in a

water proof plastic bag and placed under the coupling guard

 Inner surfaces of the bearing housing, shaft (area

through bearing housing) and bearings are coated with Cortec VCI-329 rust inhibitor, or equal.

2.4.2 Long term storage and packaging

Long term storage is defined as more than six months, but less than 12 months. The procedure Flowserve follows for long term storage of pumps is given below. These procedures are in addition to the short term procedure.  Each assembly is hermetically (heat) sealed from

the atmosphere by means of tack wrap sheeting and rubber bushings (mounting holes)

 Desiccant bags are placed inside the tack

wrapped packaging

 A solid wood box is used to cover the assembly This packaging will provide protection for up to twelve

months from humidity, salt laden air, dust etc. After unpacking, protection will be the responsibility of

the user. Addition of oil to the bearing housing will remove the inhibitor. If units are to be idle for extended periods after addition of lubricants, inhibitor oils and greases should be used. Every three months, the pump shaft should be rotated approximately 10 revolutions.

2.5 Recycling and end of product life

At the end of the service life of the product or its parts, the relevant materials and parts should be recycled or disposed of using an environmentally acceptable method and in accordance with local regulations. If the product contains substances that are harmful to the environment, these should be removed and disposed of in accordance with current local regulations.

Make sure that hazardous substances are disposed of safely and that the correct personal protective equipment is used. The safety specifications must be in accordance with the current local regulations at all times.

shipment

 Regreasable bearings are packed with grease  Exposed shafts are taped with Polywrap

 Flange covers are secured to both the suction  In some cases with assemblies ordered with

 The pump must be stored in a covered, dry

Bearing housings are not filled with oil prior to

(EXXON POLYREX EM)

and discharge flanges external piping, components may be

disassembled for shipment location

flowserve.com

USER INSTRUCTIONS PolyChem M-SERIES ENGLISH 71569218 07-11

Page 12 of 60

Serial No.

Equipment No.

Purchase Order

Model

Size

MDP

Material

Date DD/MMM/YY

PJ 2 X 1 - 10 / 8.25CL

3 DESCRIPTION

3.1 Configurations

The PolyChem M-series chemical process pumps are fluoropolymer lined, magnetically coupled, horizontal, end suction, single stage, centrifugal pumps. The ISO version of this pump conforms dimensionally to ISO 2858/5199 while the ANSI model agrees dimensionally with ASME B73.1, both have centerline discharge.

3.2 Nomenclature

The pump size will be engraved on the nameplate typically as below:

PB 40 – 200 / 190CL (ISO) PJ 2 X 1 - 10 / 8.25CL (ANSI)

P = PolyChem pump line A = Magnetic coupling (small) Group A/1 B = Magnetic coupling (medium) Group A/1 C = Magnetic coupling (large) Group A/1 J = Magnetic coupling (small) Group B/2 K = Magnetic coupling (medium) Group B/2 L = Magnetic coupling (large) Group B/2

ISO Pump:

“40” = Nominal discharge port size (mm) “200” = Nominal (max.) impeller diameter (mm) “190” =Actual impeller diameter (mm)

ANSI Pump:

“2” = Nominal suction port size (inch) “1” = Nominal discharge port size (inch) “10” = Nominal (max) impeller diameter (inch)

“8.25” – Actual impeller diameter (inch)

Impeller style (ISO or ANSI)

CL = closed vane impeller

Pump design variations

Long-coupled Close-coupled

Pump groups

References to Group A and Group B relate to ISO pumps, whilst references to Group 1 and Group 2 relate to ANSI pumps

An example of the nameplate used on the PolyChem pump is shown in Figure 3-1. This nameplate is mounted on either the lantern or the bearing housing.

Figure 3-1: Nameplate

3.3 Design of major parts

3.3.1 Casing

Removal of the casing is not required when performing maintenance of the rotating element. The rotating element is easily removed (back pull out).

3.3.2 Impeller

The impeller is closed vane.

3.3.3 Wetted bearing system

This system is comprised of silicon carbide bearings. It is made up of a shaft, thrust journals and bushings, as well as radial journals and bushings.

3.3.4 Power end bearings and lubrication –

Long-coupled

Ball bearings are fitted as standard and may be either oil or grease lubricated.

3.3.5 Bearing housing – Long-coupled

Large oil bath reservoir.

3.3.6 Bearing holder

Supports the inboard radial pump bearing.

3.3.7 Magnetic coupling

Comprised of an inner and outer magnet assembly. The outer assembly is supported by the power end (long-coupled) or the motor (close-coupled). The inner assembly is encapsulated and mounted on a silicon carbide shaft.

3.3.8 Containment shell

Nonmetallic construction to avoid eddy currents losses.

3.3.9 Lantern

Used to connect the casing to the power end on a long-coupled pump or to the motor on a closedcoupled pump.

flowserve.com

USER INSTRUCTIONS PolyChem M-SERIES ENGLISH 71569218 07-11

Page 13 of 60

MCF % of BEP

Pump Size

3500/2900

rpm

1750/1450

rpm

1180/960

rpm

P_3x2-6

20%

10%

P_3x2-10 P_50-250

30%

10%

P_4x3-10 P_65-250

N/A

10%

All other sizes

10%

3.3.10 Driver

The driver is normally an electric motor. Different drive configurations may be fitted such as internal combustion engines, turbines, hydraulic motors etc driving via couplings, belts, gearboxes, drive shafts etc.

3.3.11 Accessories

Accessories may be fitted when specified by the customer.

3.4 Performance and operation limits

This product has been selected to meet the specification of your purchase order. See section 1.5.

The following data is included as additional information to help with your installation. It is typical, and factors such as liquid being pumped, temperature, and material of construction may influence this data. If required, a definitive statement for your application can be obtained from Flowserve.

3.4.1 Material cross reference chart

Figure 3-3 is the material cross-reference chart for all PolyChem M-series pumps.

3.4.2 Pressure-temperature ratings

PN 16 flanges are standard for the ISO model pump while Class 150 flanges are standard for the ANSI model. Refer to Figure 3-4A and 3-4B for each pump’s pressure-temperature (P-T) rating.

Figure 3-2: Minimum continuous flow

than or equal to the P-T rating. Discharge pressure may be approximated by adding the suction pressure to the differential pressure developed by the pump.

3.4.3 Suction pressure limits

The suction pressure limits for PolyChem M-series pumps is limited by the P-T rating.

3.4.4 Minimum continuous flow

The minimum continuous flow (MCF) is based on a percentage of the best efficiency point (BEP). Figure 3-2 identifies the MCF for all PolyChem M-series pumps.

The maximum discharge pressure must be less

flowserve.com

USER INSTRUCTIONS PolyChem M-SERIES ENGLISH 71569218 07-11

Page 14 of 60

Flowserve

Material Code

Designation

Durco Legacy Codes

Equivalent

wrought

Designation

EN / ASTM

specifications

Nozzle load

material

group

Z0L48

PFA lined Ductile iron (cast)

DIPA

None

Note 1

1.0

E2025

Ductile Iron Casting

7043

None

EN1563, Gr. JS 1025

1.0

E3020

Ductile Iron Casting

DCI

None

A395, Gr. 60-40-18

1.0 A0024

Paper P None N/A

D0005

Carbon Steel

None N/A

D2044

Quenched and Tempered Steel

CK45

None

EN 10083-1

N/A

D3013

1018 Carbon Steel

None N/A

D3058

304 Stainless Steel

304

None

A276, Type 304

N/A

D3277

Carbon Steel

1144

UNS G11440

N/A

D4035

304, 305, 316, Stainless steel

18-8

None N/A

E2008

Ductile Iron Casting

7040

None

EN1563, Gr. JS 1030

N/A

E3006

Cast Iron Casting

None

A48, Gr. 25A

N/A

E3007

Cast Iron Casting

GG25

None

EN1561, Gr. JL 1040

N/A

E3035

Ductile Iron Casting

DCI2

None

A536, Gr. 65-45-12

N/A

E4034

Ductile Iron Casting

DCI4

None

Note 2

N/A

I0003

Bronze

None N/A

J0018

Reaction bonded silicon carbide

SC2

None N/A

J0020

Sintered silicon carbide

SC3

None N/A

L0009

Carbon Filled Teflon

TFEC

None N/A

L1001

Tetrafluoroethylene

TFE

None N/A

L1010

Ethylene Propylene Rubber

EPR

None N/A

L1017

Nitrile Butadiene Rubber

NBR

None N/A

L1103

Polysulphone

None N/A

M1001

ISO 3506 Grade A2 Class 70

A270

None N/A

M1013

ISO 898/1 Class 8.8

None N/A

M3026

Carbon steel

SR5

None

A449, Type 1

N/A

Z0067

Protective Plated Carbon Steel

SRCD

None N/A

Z0L50

PFA lined sintered silicon carbide

S3PA

None N/A

Z0L51

Carbon filled PFA

CFPA

None N/A

Z0L52

Carbon filled fluoropolymer

CFTM

None N/A

Z0L54

Fluoropolymer lined fiberglass

EFP3

None N/A

Z0L64

Teflon lined A193, Gr. B7

B7TF

None N/A

Z0L65

Teflon lined A194, Gr. 2H

SRTF

None N/A

Z0L72

Teflon – Silicon Rubber – Carbon Steel

TSSR

None N/A

Z0M22

Viton – Carbon Steel

VSR

None N/A

Z0M35

PFA lined carbon filled fluoropolymer

CFTM

None N/A

Z0M36

Fluoropolymer lined NdFeB magnets

PFA

None N/A

Z0M37

Carbon steel - NdFeB magnets

None N/A

Temperature ˚C

-29

-18

121

149

BAR

15.5

Temperature ˚F

-20 0 100

200

250

300

PSI

232

225

Temperature ˚C

-29

-18

149

BAR

17.2

16.2

14.8

Temperature ˚F

-20 0 100

200

300

PSI

250

235

215

Figure 3-3: Material cross-reference chart

1. The casting used for ISO pumps is E2025 and for ANSI pumps is E3020

2. Dual Spec. EN1563 Gr. JS1030 & A536 Gr. 65-45-12

Figure 3-4A: Pressure – Temperature Rating ISO Pump with PN 16 Flanges – Material Group No. 1.0

Figure 3-4B: Pressure – Temperature Rating ANSI Pump with Class 150 Flanges – Material Group No. 1.0

flowserve.com

USER INSTRUCTIONS PolyChem M-SERIES ENGLISH 71569218 07-11

Page 15 of 60

4 INSTALLATION

4.1 Location

The pump should be located to allow room for access, ventilation, maintenance, and inspection with ample headroom for lifting and should be as close as practicable to the supply of liquid to be pumped.

Refer to the general arrangement drawing for the pump set.

4.2 Part assemblies

The supply of motors and baseplates are optional. As a result, it is the responsibility of the installer to ensure that the motor is assembled to the pump and aligned as detailed in section 4.5 and 4.8.

4.3 Foundation

4.3.1 Protection of openings and threads

When the pump is shipped, all threads and all openings are covered. This protection/covering should not be removed until installation. If, for any reason, the pump is removed from service, this protection should be reinstalled.

4.3.2 Rigid baseplates - overview

The function of a baseplate is to provide a rigid foundation under a pump and its driver that maintains alignment between the two. Baseplates may be generally classified into two types:

 Foundation-mounted, grouted design. (Figure 4-1)  Stilt mounted, or free standing. (Figure 4-2.)

Figure 4-1

Figure 4-2

Baseplates intended for grouted installation are designed to use the grout as a stiffening member. Stilt mounted baseplates, on the other hand, are

designed to provide their own rigidity. Therefore the designs of the two baseplates are usually different.

Regardless of the type of baseplate used, it must provide certain functions that ensure a reliable installation. Three of these requirements are:

1. The baseplate must provide sufficient rigidity to

assure the assembly can be transported and

installed, given reasonable care in handling,

without damage. It must also be rigid enough

when properly installed to resist operating loads.

2. The baseplate must provide a reasonably flat

mounting surface for the pump and driver.

Uneven surfaces will result in a soft-foot

condition that may make alignment difficult or

impossible. Experience indicates that a

baseplate with a top surface flatness of 1.25

mm/m (0.015 in./ft) across the diagonal corners

of the baseplate provides such a mounting

surface. Therefore, this is the tolerance to which

we supply our standard baseplate. Some users

may desire an even flatter surface, which can

facilitate installation and alignment. Flowserve

will supply flatter baseplates upon request at

extra cost. For example, mounting surface

flatness of 0.17 mm/m (0.002 in./ft) is offered on

the Flowserve Type E “Ten Point” baseplate

shown in Figure 4-1.

3. The baseplate must be designed to allow the

user to final field align the pump and driver to

within their own particular standards and to

compensate for any pump or driver movement

that occurred during handling. Normal industry

practice is to achieve final alignment by moving

the motor to match the pump. Flowserve

practice is to confirm in our shop that the pump

assembly can be accurately aligned. Before

shipment, the factory verifies that there is

enough horizontal movement capability at the

motor to obtain a “perfect” final alignment when

the installer puts the baseplate assembly into its

original, top leveled, unstressed condition.

4.3.3 Stilt and spring mounted baseplates

Flowserve offers stilt and spring mounted baseplates. (See Figure 4-2 for stilt mounted option.) The low vibration levels of PolyChem pumps allow the use of these baseplates - provided they are of a rigid design. The baseplate is set on a flat surface with no tie down bolts or other means of anchoring it to the floor.

General instructions for assembling these baseplates are given below. For dimensional information, please refer to the appropriate Flowserve “Sales print.”

flowserve.com

USER INSTRUCTIONS PolyChem M-SERIES ENGLISH 71569218 07-11

Page 16 of 60

4.3.3.1 Stilt mounted baseplate assembly instructions

Refer to Figure 4-3. a) Raise or block up baseplate/pump above the

floor to allow for the assembly of the stilts.

b) Predetermine or measure the approximate

desired height for the baseplate above the floor.

c) Set the bottom nuts [2] above the stilt bolt head

[1] to the desired height. d) Assemble lock washer [3] down over the stilt bolt. e) Assemble the stilt bolt up through hole in the

bottom plate and hold in place. f) Assemble the lock washer [3] and nut [2] on the

stilt bolt. Tighten the nut down on the lock

washer. g) After all four stilts have been assembled,

position the baseplate in place, over the floor

cups [4] under each stilt location, and lower the

baseplate to the floor. h) Level and make final height adjustments to the

suction and discharge pipe by first loosening the

top nuts and turning the bottom nuts to raise or

lower the baseplate. i) Tighten the top and bottom nuts at the lock

washer [3] first then tighten the other nuts. j) It should be noted that the connecting pipelines

must be individually supported, and that the stilt

mounted baseplate is not intended to support

total static pipe load.

Figure 4-3

d) Assemble the stilt bolt/bottom spring up through

hole in the bottom plate and hold in place.

e) Assemble top spring/cup assembly [3] down

over stilt bolt.

f) Assemble flat washer [5], lock washer [6] and

nuts [4] on the stilt bolt.

g) Tighten down top nuts, compressing the top

spring approximately 13 mm (0.5 in.). Additional compression may be required to stabilize the baseplate.

h) After all four stilts have been assembled,

position the baseplate in place, over the floor cups [7] under each stilt location, and lower the baseplate down to the floor.

i) Level and make final height adjustments to the

suction and discharge pipe by first loosening the top nuts, and turning the bottom nuts to raise or lower the baseplate.

j) Recompress the top spring to the compression

established in step g, and lock the nuts in place.

k) It should be noted that the connecting pipelines

must be individually supported, and that the spring mounted baseplate is not intended to support total static pipe loads.

Figure 4-4

4.3.3.2 Stilt/spring mounted baseplate assembly

Refer to Figure 4-4. a) Raise or block up baseplate/pump above the

b) Set the bottom nuts [4] above the stilt bolt head

c) Assemble the lock washer [6] flat washer [5] and

instructions

floor to allow for the assembly of the stilts.

[1]. This allows for 51 mm (2 in.) upward

movement for the final height adjustment of the

suction/discharge flange.

bottom spring/cup assembly [2] down over the

stilt bolt [1].

4.3.3.3 Stilt/spring mounted baseplates - motor alignment

The procedure for motor alignment on stilt or spring mounted baseplates is similar to grouted baseplates. The difference is primarily in the way the baseplate is leveled. a) Level the baseplate by using the stilt adjusters.

(Shims are not needed as with grouted baseplates.)

b) After the base is level, it is locked in place by

locking the stilt adjusters.

c) Next the initial pump alignment must be

checked. The vertical height adjustment provided by the stilts allows the possibility of

flowserve.com

USER INSTRUCTIONS PolyChem M-SERIES ENGLISH 71569218 07-11

Page 17 of 60

slightly twisting the baseplate. If there has been no transit damage or twisting of the baseplate during stilt height adjustment, the pump and driver should be within 0.38 mm (0.015 in.) parallel, and 0.0025 mm/mm (0.0025 in./in.) angular alignment. If this is not the case, check to see if the driver mounting fasteners are centered in the driver feet holes.

d) If the fasteners are not centered there was likely

shipping damage. Re-center the fasteners and perform a preliminary alignment to the above tolerances by shimming under the motor for vertical alignment, and by moving the pump for horizontal alignment.

e) If the fasteners are centered, then the baseplate

may be twisted. Slightly adjust (one turn of the adjusting nut) the stilts at the driver end of the baseplate and check for alignment to the above tolerances. Repeat as necessary while maintaining a level condition as measured from the pump discharge flange.

f) Lock the stilt adjusters. The remaining steps are as listed for new grouted

baseplates.

4.4 Grouting

a) The pump foundation should be located as close

to the source of the fluid to be pumped as practical.

b) There should be adequate space for workers to

install, operate, and maintain the pump. The foundation should be sufficient to absorb any vibration and should provide a rigid support for the pump and motor.

c) Recommended mass of a concrete foundation

should be three times that of the pump, motor and base. Refer to Figure 4-5.

Foundation bolts are imbedded in the concrete inside a sleeve to allow some movement of the bolt.

Figure 4-5

d) Level the pump baseplate assembly. If the

baseplate has machined coplanar mounting surfaces, these machined surfaces are to be referenced when leveling the baseplate. This may require that the pump and motor be removed from the baseplate in order to reference the machined faces. If the baseplate is without machined coplanar mounting surfaces, the pump and motor are to be left on the baseplate. The proper surfaces to reference when leveling the pump baseplate assembly are the pump suction and discharge flanges. DO NOT stress the baseplate.

e) Do not bolt the suction or discharge flanges of

the pump to the piping until the baseplate foundation is completely installed. If equipped, use leveling jackscrews to level the baseplate. If jackscrews are not provided, shims and wedges should be used. (See Figure 4-5.) Check for levelness in both the longitudinal and lateral directions. Shims should be placed at all base anchor bolt locations, and in the middle edge of the base if the base is more than 1.5 m (5 ft.) long. Do not rely on the bottom of the baseplate to be flat. Standard baseplate bottoms are not machined, and it is not likely that the field mounting surface is flat.

f) After leveling the baseplate, tighten the anchor

bolts. If shims were used, make sure that the baseplate was shimmed near each anchor bolt before tightening. Failure to do this may result in a twist of the baseplate, which could make it impossible to obtain final alignment.

g) Check the level of the baseplate to make sure

that tightening the anchor bolts did not disturb the level of the baseplate. If the anchor bolts did change the level, adjust the jackscrews or shims as needed to level the baseplate.

h) Continue adjusting the jackscrews or shims and

tightening the anchor bolts until the baseplate is level.

i) Check initial alignment. If the pump and motor

were removed from the baseplate proceed with step j) first, then the pump and motor should be

reinstalled onto the baseplate using Flowserve’s

factory preliminary alignment procedure as described in section 4.5, and then continue with the following. As described above, pumps are given a preliminary alignment at the factory. This preliminary alignment is done in a way that ensures that, if the installer duplicates the factory conditions, there will be sufficient clearance between the motor hold down bolts and motor foot holes to move the motor into final alignment. If the pump and motor were properly reinstalled to the baseplate or if they were not removed from the

flowserve.com

USER INSTRUCTIONS PolyChem M-SERIES ENGLISH 71569218 07-11

Page 18 of 60

baseplate and there has been no transit damage, and also if the above steps where done properly, the pump and driver should be within 0.38 mm (0.015 in.) FIM (Full Indicator Movement) parallel, and 0.0025 mm/mm (0.0025 in./in.) FIM angular. If this is not the case, first check to see if the driver mounting fasteners are centered in the driver feet holes. If not, re-center the fasteners and perform a preliminary alignment to the above tolerances by shimming under the motor for vertical alignment, and by moving the pump for horizontal alignment.

j) Grout the baseplate. A non-shrinking grout

should be used. Make sure that the grout fills the area under the baseplate. After the grout has cured, check for voids and repair them. Jackscrews, shims and wedges should be removed from under the baseplate at this time. If they were to be left in place, they could rust, swell, and cause distortion in the baseplate.

k) Run piping to the suction and discharge of the

pump. There should be no piping loads transmitted to the pump after connection is made. Recheck the alignment to verify that there are no significant loads.

4.5 Initial alignment – Long-coupled

4.5.1 Horizontal initial alignment procedure

The purpose of factory alignment is to ensure that the user will have full utilization of the clearance in the motor holes for final job-site alignment. To achieve this, the factory alignment procedure specifies that the pump be aligned in the horizontal plane to the motor, with the motor foot bolts centered in the motor holes. This procedure ensures that there is sufficient clearance in the motor holes for the customer to field align the motor to the pump, to zero tolerance. This philosophy requires that the customer be able to place the base in the same condition as the factory. Thus the factory alignment will be done with the base sitting in an unrestrained condition on a flat and level surface. This standard also emphasizes the need to ensure the shaft spacing is adequate to accept the specified coupling spacer.

The factory alignment procedure is summarized below: a) The baseplate is placed on a flat and level

workbench in a free and unstressed position.

b) The baseplate is leveled as necessary. Leveling

is accomplished by placing shims under the rails of the base at the appropriate anchor bolt hole locations. Levelness is checked in both the longitudinal and lateral directions.

c) The motor and appropriate motor mounting

hardware is placed on the baseplate and the motor is checked for any planar soft-foot condition. If any is present it is eliminated by shimming.

d) The motor feet holes are centered on the motor

mounting fasteners. This is done by using a centering nut as shown in Figure 4-6.

Figure 4-6

e) The motor is fastened in place by tightening the

nuts on two diagonal motor mounting studs.

f) The pump is put onto the baseplate and leveled.

The foot piece under the bearing housing is adjustable. It is used to level the pump, if necessary. If an adjustment is necessary, add or remove shims [3126.1] between the foot piece

and the bearing housing. g) The spacer coupling gap is verified. h) The parallel and angular vertical alignment is

made by shimming under the motor. i) The motor feet holes are again centered on the

motor mounting studs using the centering nut.

At this point the centering nut is removed and

replaced with a standard nut. This gives

maximum potential mobility for the motor to be

horizontally moved during final, field alignment.

All four motor feet are tightened down. j) The pump and motor shafts are then aligned

horizontally, both parallel and angular, by

moving the pump to the fixed motor. The pump

feet are tightened down. k) Both horizontal and vertical alignment is again

final checked as is the coupling spacer gap. See section 4.8, Final shaft alignment.

4.6 Piping

Protective covers are fitted to both the suction and discharge flanges of the casing and must be removed prior to connecting the pump to any pipes.

4.6.1 Suction and discharge piping

All piping must be independently supported, accurately aligned and preferably connected to the pump by a

flowserve.com

USER INSTRUCTIONS PolyChem M-SERIES ENGLISH 71569218 07-11

Page 19 of 60

short length of flexible piping. The pump should not have to support the weight of the pipe or compensate for misalignment. It should be possible to install suction and discharge bolts through mating flanges without pulling or prying either of the flanges. All piping must be tight. Pumps may air-bind if air is allowed to leak into the piping. If the pump flange(s) have tapped holes, select flange fasteners with thread engagement at least equal to the fastener diameter but that do not bottom out in the tapped holes before the joint is tight.

The following is the recommended procedure for attaching piping to the PolyChem M-series pump (see section 6.5 for torque values)

 Check the surface of both flanges (pump/pipe) to

ensure they are clean, flat, and without defects

 Lubricate the fasteners  Hand tighten all of the fasteners in a crisscross

pattern

 The fasteners should be torqued in increments –

based a crisscross pattern

o The first increment should be at 75%

of the full torque

o The second increment should be at the

full torque

o Verify that the torque value of the 1st

fastener is still at the full torque value

 Retorque all fasteners after 24 hours or after the first

thermal cycle

 Retorque all fasteners at least annually

4.6.2 Suction piping

To avoid NPSH and suction problems, suction piping must be at least as large as the pump suction connection. Never use pipe or fittings on the suction that are smaller in diameter than the pump suction size.

Figure 4-7 illustrates the ideal piping configuration with a minimum of 10 pipe diameters between the source and the pump suction. In most cases, horizontal reducers should be eccentric and mounted with the flat side up as shown in Figure 4-8 with a maximum of one pipe size reduction. Never mount eccentric reducers with the flat side down. Horizontally mounted concentric reducers should not be used if there is any possibility of entrained air in the process fluid. Vertically mounted concentric reducers are acceptable. In applications where the fluid is completely de-aerated and free of any vapor or suspended solids, concentric reducers are preferable to eccentric reducers.

Figure 4-7 Figure 4-8

Avoid the use of throttling valves and strainers in the suction line. Start up strainers must be removed shortly before start up. When the pump is installed below the source of supply, a valve should be installed in the suction line to isolate the pump and permit pump inspection and maintenance. However, never place a valve directly on the suction nozzle of the pump.

Refer to the Durco Pump Engineering Manual and the Centrifugal Pump IOM Section of the Hydraulic Institute Standards for additional recommendations on suction piping. (See section 10.)

Refer to section 3.4 for performance and operating limits.

4.6.3 Discharge piping

Install a valve in the discharge line. This valve is required for regulating flow and/or to isolate the pump for inspection and maintenance.

When fluid velocity in the pipe is high, for example, 3 m/s (10 ft/sec) or higher, a rapidly closing discharge valve can cause a damaging pressure surge. A dampening arrangement should be provided in the piping.

4.6.4 ALLOWABLE NOZZLE LOADS Introduction

Never use the pump as a support for piping. Maximum Forces and moments allowed on pump

flanges vary based on the pump size. When these forces and moments are minimized, there is a corresponding reduction in misalignment, hot bearings, worn couplings, vibration and possible failure of the pump casing. The following points should be strictly followed:

 Prevent excessive external pipe load  Never draw piping into place by applying force to

pump flange connections

 Do not mount expansion joints so that their force,

due to internal pressure, acts on the pipe flange

flowserve.com

USER INSTRUCTIONS PolyChem M-SERIES ENGLISH 71569218 07-11

Page 20 of 60

Temp. ˚C

-29

150

Temp. ˚F

-20

100

200

300

Correction Factors

0.89

0.83

0.78

Base Type

Grouted

Bolted

Stilt

Mounted

Type A

1.0

0.7

0.65

Type B - Polybase

1.0

N/A

0.95

Type C

N/A

1.0

Type D

1.0

0.8

0.75

Type E - PIP

1.0

0.95

N/A

Polyshield - Baseplate / Foundation

1.0

N/A

The PolyChem product line is designed to meet the requirements of ISO 5199 and ANSI/HI 9.6.2. Allowable nozzle loads for ISO pumps may be calculated using ISO 5199 or ANSI/HI 9.6.2 by selecting a comparable pump size.

Figure 4-9: Casing Material Correction Factors – Material Group No. 1.0

Figure 4-10: Baseplate Correction Factors

4.6.4.1 PolyChem M-series Pumps

The following steps are based upon ANSI/HI 9.6.2. All information necessary to complete the evaluation is given below. For complete details please review the standard.

a) PolyChem M-series pumps are only

manufactured from Ductile Iron. For reference the “Material Group No.” for this material is 1.0

b) Find the “Casing Material Correction Factor” in

Figure 4-9 based upon the operating temperature. Interpolation may be used to determine the correction factor for a specific temperature.

c) Find the “Baseplate Correction Factor” in

Figure 4-10. The correction factor depends upon how the baseplate is to be installed

d) Locate the pump model being evaluated in

Figure 4-14 and multiply each load rating by the casing correction factor. Record the adjusted Figure 4-14 loads.

e) Locate the pump model being evaluated in

Figures 4-15 and 4-16 and multiply each load rating by the baseplate correction factor. Record the adjusted Figure 4-15 and 4-16 loads.

f) Compare the adjusted Figure 4-14 values (Step

D) to the values shown in Figure 4-13. The lower of these two values should be used as the

adjusted Figure 4-13 values. (The HI standard

also asks that Figure 4-13 loads be reduced if Figure 4-15 or 4-16 values are lower. Flowserve does not follow this step.)

Figure 4-11: Coordinate System

g) Calculate the applied loads at the casing flanges

according to the coordinate system found in Figure 4-11. The 12 forces and moments possible are Fxs, Fys, Fzs, Mxs, Mys, Mzs, Fxd, Fyd, Fzd, Mxd, Myd and Mzd. For example, Fxd designates

Force in the “x” direction on the discharge flange.

Mys designates the Moment about the “y”-axis on

the suction flange.

h) Figure 4-12 gives the acceptance criteria

equations. For long-coupled pumps, equation sets 1 through 5 must be satisfied. For close coupled pumps only equation sets 1 and 2 must be satisfied.

i) Equation set 1: Each applied load is divided by the

corresponding adjusted Figure 4-13 value. The absolute value of each ratio must be less than or equal to one.

j) Equation set 2: The summation of the absolute

values of each ratio must be less than or equal to two. The ratios are the applied load divided by the adjusted Figure 4-14 values.

k) Equation sets 3 and 4: These equations are

checking for coupling misalignment due to nozzle loading in each axis. Each applied load is divided by the corresponding adjusted load from Figure 415 and 4-16. The result of each equation must be between one and negative one.

l) Equation set 5: This equation calculates the total

shaft movement from the results of equations 3 and 4. The result must be less than or equal to one.

flowserve.com

USER INSTRUCTIONS PolyChem M-SERIES ENGLISH 71569218 07-11

Page 21 of 60

Figure 4-12: Acceptance Criteria Equations

Set

Equations

Figure

Remarks

0.1,0.1,0.1,0.1,0.1,0.1

,0.1,0.1,0.1,0.1,0.1,0.1

______



adjzd

adjyd

adjxd

adjzd

adjyd

adjxd

adjzs

adjys

adjxs

adjzs

adjys

adjxs

Adjusted

4-13

Maximum

individual

0.2

______





adjzd

adjyd

adjxd

adjzd

adjyd

adjxd

adjzs

adjys

adjxs

adjzs

adjys

adjxs

Adjusted

4-14

Nozzle

stress, bolt

stress,

pump

slippage

_ _ _ _

ys ys

xs zs

ys adj xs adj ys adj zs adj

yd yd

xd zd

yd adj xd adj yd adj zd adj

F M M M

    

  

0.10.1  A

Adjusted

4-15

y-axis

movement

_ _ _ _ _

_ _ _ _ _ _

xs zs xs zs

xs adj zs adj xs adj ys adj zs adj

yd yd

xd zd xd zd

xd adj yd adj zd adj xd adj yd adj zd adj

F F M M

F F M M M

F F M M

F F F M M M

     

    

0.10.1  B

Adjusted

4-16

z-axis

movement

0.122BA

Combined

axis

movement

Note: All of the above equations are found by dividing the applied piping loads by the adjusted figure values.

flowserve.com

USER INSTRUCTIONS PolyChem M-SERIES ENGLISH 71569218 07-11

Page 22 of 60

Pump Size

Suction

Discharge

Forces (N)

Moments (Nm)

Forces (N)

Moments (Nm)

Fxs

Fys

Fzs

Mxs

Mys

Mzs

Fxd

Fyd

Fzd

Mxd

Myd

Mzd

P_1.5x1-6 P_32-160

4670

3336

976

231

3558

6005

13344

556

P_3x1.5-6

4670

5516

5560

1220

664

3558

6005

13344

678

746

692

P_3x2-6 P_65-160

4670

1220

298

3558

6005

13344

678

1356

692

P_1.5x1-8 P_40-200

4670

5382

976

258

3558

6005

13344

488

P_ 2x1-10 P_32-250

10408

4270

1722

298

6227

6005

14456

895

P_ 3x2-10 P_50-250

12010

6005

6583

1763

420

6227

6005

14456

759

P_ 4x3-10 P_65-250

10230

6005

6672

1763

420

6227

6005

14456

1627

1980

936

Pump Size

Suction

Discharge

Forces (lbf)

Moments (lbf∙ft)

Forces (lbf)

Moments (lbf∙ft)

Fxs

Fys

Fzs

Mxs

Mys

Mzs

Fxd

Fyd

Fzd

Mxd

Myd

Mzd

P_1.5x1-6 P_32-160

1050

750

720

170

800

1350

3000

410

P_3x1.5-6

1050

1240

1250

900

490

800

1350

3000

500

550

510

P_3x2-6 P_65-160

1050

900

220

800

1350

3000

500

1000

510

P_1.5x1-8 P_40-200

1050

1210

720

190

800

1350

3000

360

P_ 2x1-10 P_32-250

2340

960

1270

220

1400

1350

3250

660

P_ 3x2-10 P_50-250

2700

1350

1480

1300

310

1400

1350

3250

560

P_ 4x3-10 P_65-250

2300

1350

1500

1300

310

1400

1350

3250

1200

1460

690

Figure 4-13: Maximum Individual Loading SI Units

US Units

flowserve.com

USER INSTRUCTIONS PolyChem M-SERIES ENGLISH 71569218 07-11

Page 23 of 60

Pump Size

Suction

Discharge

Forces (N)

Moments (Nm)

Forces (N)

Moments (Nm)

Fxs

Fys

Fzs

Mxs

Mys

Mzs

Fxd

Fyd

Fzd

Mxd

Myd

Mzd

P_1.5x1-6 P_32-160

8985

3336

2481

231

8985

6005

27756

556

P_3x1.5-6

8985

5516

9385

3105

664

8985

6005

27756

746

692

P_3x2-6 P_65-160

8985

4670

3105

298

8985

6005

27756

1397

692

P_1.5x1-8 P_40-200

8985

5382

2481

258

8985

6005

27756

488

P_ 2x1-10 P_32-250

10408

4270

4936

298

8985

6005

27756

895

P_ 3x2-10 P_50-250

12010

6005

6583

5058

420

8985

6005

27756

759

P_ 4x3-10 P_65-250

10230

6005

7295

5058

420

8985

6005

27756

1980

936

Pump Size

Suction

Discharge

Forces (lbf)

Moments (lbf∙ft)

Forces (lbf)

Moments (lbf∙ft)

Fxs

Fys

Fzs

Mxs

Mys

Mzs

Fxd

Fyd

Fzd

Mxd

Myd

Mzd

P_1.5x1-6 P_32-160

2020

750

1830

170

2020

1350

6240

410

P_3x1.5-6

2020

1240

2110

2290

490

2020

1350

6240

550

510

P_3x2-6 P_65-160

2020

1050

2290

220

2020

1350

6240

1030

510

P_1.5x1-8 P_40-200

2020

1210

1830

190

2020

1350

6240

360

P_ 2x1-10 P_32-250

2340

960

3640

220

2020

1350

6240

660

P_ 3x2-10 P_50-250

2700

1350

1480

3730

310

2020

1350

6240

560

P_ 4x3-10 P_65-250

2300

1350

1640

3730

310

2020

1350

6240

1460

690

Figure 4-14: Maximum Combined Loading SI Units

US Units

flowserve.com

USER INSTRUCTIONS PolyChem M-SERIES ENGLISH 71569218 07-11

Page 24 of 60

Pump Size

Suction

Discharge

Forces (N)

Moments (Nm)

Forces (N)

Moments (Nm)

Fxs

Fys

Fzs

Mxs

Mys

Mzs

Fxd

Fyd

Fzd

Mxd

Myd

Mzd

Group 1 & A

-8896

1220.4

1627.2

1695 6672 -678

2034

1695

Group 2 & B

-15568

1762.8

4068 11120

-1627

2034

4068

Pump Size

Suction

Discharge

Forces (lbf)

Moments (lbf∙ft)

Forces (lbf)

Moments (lbf∙ft)

Fxs

Fys

Fzs

Mxs

Mys

Mzs

Fxd

Fyd

Fzd

Mxd

Myd

Mzd

Group 1 & A

-2000

900

1200

1250

1500 -500

1500

1250

Group 2 & B

-3500

1300

3000

2500 -1200

1500

3000

Pump Size

Suction

Discharge

Forces (N)

Moments (Nm)

Forces (N)

Moments (Nm)

Fxs

Fys

Fzs

Mxs

Mys

Mzs

Fxd

Fyd

Fzd

Mxd

Myd

Mzd

Group 1 & A

4670

-5560

2034

1627

-3390

3558

8896

-13344

-2034

1356

-3390

Group 2 & B

15568

-6672

2034

1763

-4746

6227

11120

-14456

-2034

2915

-4746

Pump Size

Suction

Discharge

Forces (lbf)

Moments (lbf∙ft)

Forces (lbf)

Moments (lbf∙ft)

Fxs

Fys

Fzs

Mxs

Mys

Mzs

Fxd

Fyd

Fzd

Mxd

Myd

Mzd

Group 1 & A

1050 -1250

1500

1200

-2500

800

2000

-3000

-1500

1000

-2500

Group 2 & B

3500 -1500

1500

1300

-3500

1400

2500

-3250

-1500

2150

-3500

Figure 4-17 Oil Mist Connections – Labyrinth Style Oil Seals (Standard)

Figure 4-15: Maximum Y-Axis Loading for Shaft Deflection SI Units

US Units

Figure 4-16: Maximum Z-Axis Loading for Shaft Deflection SI Units

US Units

4.6.5 Pump and shaft alignment check – Longcoupled

After connecting the piping, rotate the pump drive shaft clockwise (viewed from motor end) by hand several complete revolutions to be sure there is no binding and that all parts are free. Recheck shaft alignment (see section 4.5). If piping caused unit to be out of alignment, correct piping to relieve strain on the pump.

4.6.6 Auxiliary piping

4.6.6.1 Piping connection - Oil mist lubrication

system

The piping connections for an oil mist lubrication system are shown below.

flowserve.com

USER INSTRUCTIONS PolyChem M-SERIES ENGLISH 71569218 07-11

Page 25 of 60

4.7 Electrical connections

Electrical connections must be made by a qualified Electrician in accordance with relevant local national and international regulations.

It is important to be aware of the EUROPEAN DIRECTIVE on potentially explosive areas where compliance with IEC60079-14 is an additional requirement for making electrical connections.

It is important to be aware of the EUROPEAN DIRECTIVE on electromagnetic compatibility when wiring up and installing equipment on site.

Attention must be paid to ensure that the techniques used during wiring/installation do not increase electromagnetic emissions or decrease the electromagnetic immunity of the equipment, wiring or any connected devices. If in any doubt contact Flowserve for advice.

The motor must be wired up in accordance with the motor manufacturer's instructions (normally supplied within the terminal box) including any temperature, earth leakage, current and other protective devices as appropriate. The identification nameplate should be checked to ensure the power supply is appropriate.

See section 5.3, Direction of rotation

before connecting the motor to the electrical supply.

4.8 Final shaft alignment check – Long-

coupled

a) Level baseplate if appropriate. b) Mount and level pump if appropriate. Level the

pump by putting a level on the discharge flange. If not level, adjust the footpiece by adding or removing shims [3126.1] between the footpiece and the bearing housing.

c) Check initial alignment. If pump and driver have

been remounted or the specifications given below are not met, perform an initial alignment as described in section 4.5. This ensures there will be sufficient clearance between the motor hold down bolts and motor foot holes to move the motor into final alignment. The pump and driver should be within 0.38 mm (0.015 in.) FIM (full indicator movement) parallel, and 0.0025 mm/mm (0.0025 in./in.) FIM angular.

Stilt mounted baseplates If initial alignment cannot be achieved with the motor fasteners centered, the baseplate may be twisted. Slightly adjust (one turn of the adjusting nut) the stilts at the driver end of the baseplate and check for alignment to the above tolerances. Repeat as necessary while maintaining a level condition as measured from the pump discharge flange.

d) Run piping to the suction and discharge to the

pump. There should be no piping loads transmitted to the pump after connection is made. Recheck the alignment to verify that there are no significant changes.

e) Perform final alignment. Check for soft-foot under

the driver. An indicator placed on the coupling, reading in the vertical direction, should not indicate more than 0.05 mm (0.002 in.) movement when any driver fastener is loosened. Align the driver first in the vertical direction by shimming underneath its feet.

f) When satisfactory alignment is obtained the

number of shims in the pack should be minimized. It is recommended that no more than five shims be used under any foot. Final horizontal alignment is made by moving the driver. Maximum pump reliability is obtained by having near perfect alignment. Flowserve recommends no more than 0.05 mm (0.002 in.) parallel, and

0.0005 mm/mm (0.0005 in./in.) angular misalignment. (See section 6.8.4.1)

g) Operate the pump for at least an hour or until it

reaches final operating temperature. Shut the pump down and recheck alignment while the pump is hot. Piping thermal expansion may change the alignment. Realign pump as necessary.

4.9 Protection systems

The following protection systems are recommended particularly if the pump is installed in a potentially explosive area or is handling a hazardous liquid. If in doubt consult Flowserve.

If there is any possibility of the system allowing the pump to run against a closed valve or below minimum continuous safe flow a protection device should be installed to ensure the temperature of the liquid does not rise to an unsafe level.

If there are any circumstances in which the system can allow the pump to run dry, or start up empty, a power monitor should be fitted to stop the pump or prevent it from being started. This is particularly

flowserve.com

USER INSTRUCTIONS PolyChem M-SERIES ENGLISH 71569218 07-11

Page 26 of 60

Pump

PolyChem M-series

Group A

458 ml (15.5 fl. oz.)

Group 1

251 ml (8.5 fl. oz.)

Group B

946 ml (32 fl. oz.)

Group 2

946 ml (32 fl. oz.)

Mineral oil

Quality mineral oil with rust and oxidation inhibitors.

Synthetic

Royal Purple or Conoco SYNCON (or equivalent). Some synthetic lubricants require Viton O-rings.

Grease

EXXON POLYREX EM (or compatible)

relevant if the pump is handling a flammable liquid. If leakage of product from the pump can cause a hazard it is recommended that an appropriate leakage detection system is installed.

To prevent excessive surface temperatures at bearings it is recommended that temperature or vibration monitoring is carried out.

5 COMMISSIONING, STARTUP,

OPERATION AND SHUTDOWN

These operations must be carried

out by fully qualified personnel.

NEVER RUN THE PUMP DRY OR WITHOUT PROPER PRIME (Pump flooded). Operating the pump dry may cause immediate damage to the bearings, magnets, etc..

5.1 Pre-commissioning procedure

5.1.1 Pre start-up checks

Prior to starting the pump it is essential that the following checks be made. These checks are all described in detail in the Maintenance section of this manual.

 Pump and motor properly secured to the baseplate  All fasteners tightened to the correct torque  Coupling guard in place and not rubbing  Rotation check, see section 5.3.

This is absolutely essential

 Bearing lubrication  Pump instrumentation is operational  Pump is primed  Rotation of shaft by hand

As a final step in preparation for operation, it is important to rotate the shaft by hand to be certain that all rotating parts move freely, and that there are no foreign objects in the pump casing.

5.2 Pump lubricants

5.2.1 Oil bath

The standard bearing housing bearings are oil bath lubricated and are not lubricated by Flowserve. Before operating the pump, fill the bearing housing to the center of the oil sight glass with the proper type oil. (See Figure 5-1 for approximate amount of oil required - do not overfill.)

The oil level in the bearing housing must be maintained at ±3 mm (±1/8 in.) from the center of the sight glass. The sight glass has a 6 mm (¼ in.) hole in the center of its reflector. The bearing housing oil level must be within the circumference of the center hole to ensure adequate lubrication of the bearings.

See Figure 5-2 for a general description of the lubricants to be used and Figure 5-6 for recommended lubricants. DO NOT USE DETERGENT OILS. The oil must be free of water, sediment, resin, soaps, acid and fillers of any kind. It should contain rust and oxidation inhibitors. The proper oil viscosity is determined by the bearing housing operating temperature as given in Figure 5-3.

To add oil to the housing, clean and then remove the vent plug [6569.2] at the top of the bearing housing, pour in oil until it is visually half way up in the sight glass [3855]. Fill the constant level oiler bottle, if used, and return it to its position. The correct oil level is obtained with the constant level oiler in its lowest position, which results in the oil level being at the top of the oil inlet pipe nipple, or half way up in the sight glass window. Oil must be visible in the bottle at all times.

In many pumping applications lubricating oil becomes contaminated before it loses its lubricating qualities or breaks down. For this reason it is recommended that the first oil change take place after approximately 160 hours of operation, at which time, the used oil should be examined carefully for contaminants. During the initial operating period monitor the bearing housing operating temperature. Record the external bearing housing temperature. See Figure 5-4 for maximum acceptable temperatures. The normal oil change interval is based on temperature and is shown in Figure 5-5.

Figure 5-1: Amount of oil required

Figure 5-2: Lubricant description

flowserve.com

USER INSTRUCTIONS PolyChem M-SERIES ENGLISH 71569218 07-11

Page 27 of 60

Maximum oil temperature

ISO viscosity grade

Minimum viscosity index

Up to 71 °C (160 °F)

71-80 °C (160-175 °F)

80-94 °C (175-200 °F)

100

Lubrication

Temperature

Oil bath

82 °C (180 °F)

Oil mist

82 °C (180 °F)

Grease

94 °C (200 °F)

Lubricant

Under 71 °C (160 °F)

71-80 °C (160-175 °F)

80-94 °C (175-200 °F)

Mineral oil

6 months

3 months

1.5 months

Synthetic oil

18 months

Centrifugal pump

lubrication

Oil

Splash lubrication

Oil mist lubrication

Viscosity

mm²/s 40 ºC

Temp. max. ºC (ºF)

65 (149)

80 (176)

Designation

according to

DIN51502 ISO VG

HL/HLP 32

HL/HLP 68

HL/HLP 46

Oil companies and lubricants

BP Energol HL32

BP Energol HLP32

BP Energol HL68

BP Energol HLP68

BP Energol HL46

BP Energol HLP46

DEA

Anstron HL32

Anstron HLP32

Anstron HL68

Anstron HLP68

Anstron HL46

Anstron HLP46

Elf

OLNA 32

HYDRELEF 32

TURBELF 32

ELFOLNA DS32

TURBELF SA68

ELFOLNA DS68

TURBELF SA46

ELFOLNA DS46

Esso

TERESSO 32

NUTO H32

TERESSO 68

NUTO H68

TERESSO 46

NUTO H46

Mobil

Mobil DTE oil light

Mobil DTE13

MobilDTE24

Mobil DTE oil heavy medium

Mobil DTE26

Mobil DTE oil medium

Mobil DTE15M

Mobil DTE25

Q8 Verdi 32

Q8 Haydn 32

Q8 Verdi 68

Q8 Haydn 68

Q8 Verdi 46

Q8 Haydn 46

Shell

Shell Tellus 32 Shell Tellus 37

Shell Tellus 01 C 68

Shell Tellus 01 68

Shell Tellus 01 C 46

Shell Tellus 01 46

Texaco

Rando Oil HD 32

Rando Oil HD-AZ-32

Rando Oil 68

Rando Oil HD C-68

Rando Oil 46

Rando Oil HD B-46

Wintershall

(BASF Group)

Wiolan HN32 Wiolan HS32

Wiolan HN68 Wiolan HS68

Wiolan HN46 Wiolan HS46

Figure 5-3: Oil viscosity grades

Figure 5-4: Maximum external housing temperatures

The maximum temperature that the bearing can be exposed to is 105 °C (220 °F). Bearing temperatures may be up to 16 °C (30 °F) higher than the housing temperature.

Figure 5-5: Lubrication intervals*

* Assuming good maintenance and operation practices, and no contamination.

Figure 5.6 Recommended oil lubricants

5.2.2 Grease

Do not fill the housing with oil when greased bearings are used. The oil will leach the grease out of the bearings and the life of the bearings may be drastically reduced.

5.2.2.1 Grease for life

Double shielded or double sealed bearings

These bearings are packed with grease by the bearing manufacturer and should not be relubricated. The replacement interval for these bearings is greatly affected by their operating temperature and speed. Shielded bearings typically operate cooler.

5.2.3 Oil mist

The inlet port for all horizontal pumps is the plugged ½ in. NPT located at the top of the bearing housing. A plugged ¼ in. NPT bottom drain is provided on the bearing housing. See section 4.6.6.2, Piping connection - Oil mist lubrication system. Do not allow oil level to remain above the center of the bearing housing sight glass window with purge mist (wet sump) systems.

flowserve.com

USER INSTRUCTIONS PolyChem M-SERIES ENGLISH 71569218 07-11

Page 28 of 60

5.3 Direction of rotation

5.3.1 Rotation check

5.3.1.1 Rotation check, Long-coupled pumps

It is absolutely essential that the rotation of the motor be checked before connecting the shaft coupling. All PolyChem M-series pumps turn clockwise as viewed from the motor end. A direction arrow is cast on the front of the casing as shown in Figure 5-7. Make sure the motor rotates in the same direction.

Figure 5-7

5.3.1.2 Rotation check, Close-coupled pumps

It is absolutely essential that the rotation of the motor be checked. This check will require operating the pump briefly, so the pump must be filled with liquid. Never run a centrifugal pump dry. To check rotation, perform the following steps:

a) Open the suction and discharge valves to allow

the pump to fill with liquid.

b) While watching the motor fan, bump the motor.

The proper direction of rotation for the pump is clockwise as viewed from the motor end. A direction arrow is cast on the front of the casing as shown in Figure 5-7.

NEVER DO MAINTENANCE WORK WHEN THE UNIT IS CONNECTED TO POWER (Lock out.)

c) If the motor rotates in the wrong direction, reverse

any two of the three leads to the motor (3 phase current). Bump the motor again to ensure the proper direction of rotation.

5.3.2 Coupling installation

Pumps are shipped without the spacer installed. If the spacer has been installed to facilitate alignment, then it must be removed prior to checking rotation. Remove all protective material from the coupling and shaft before installing the coupling.

Figure 5-8

5.4 Guarding

Guarding is supplied fitted to the pump set. In member countries of the EU and EFTA, it is a legal requirement that fasteners for guards must remain captive in the guard to comply with the Machinery Directive 2006/42/EC. When releasing such guards, the fasteners must be unscrewed in an appropriate way to ensure that the fasteners remain captive.

Power must never be applied to the

driver when the coupling guard is not installed. Flowserve coupling guards are safety devices intended

to protect workers from inherent dangers of the rotating pump shaft, motor shaft and coupling. It is intended to prevent entry of hands, fingers or other body parts into a point of hazard by reaching through, over, under or around the guard. No standard coupling guard provides complete protection from a disintegrating coupling. Flowserve cannot guarantee their guards will completely contain an exploding coupling.

5.4.1 Clam shell guard - standard

The standard coupling guard for all PolyChem Mseries pumps is the “clam shell” design and is shown in Figure 5-9. It is hinged at the top and it can be removed by loosening one of the foot bolts and sliding the support leg out from under the cap screw (note that the foot is slotted). The leg can then be rotated upward and half of the guard can be disengaged (unhinged) from the other. Only one side of the guard needs to be removed. To reassemble simply reverse the above procedure.

installed as advised by the coupling manufacturer.

The coupling (Figure 5-8) should be

Figure 5-9

flowserve.com

USER INSTRUCTIONS PolyChem M-SERIES ENGLISH 71569218 07-11

Page 29 of 60

REFERENCE CENTER

TRIM THIS END

MEASUREMENT STEP a)

The coupling guard shown in Figure 5-9 conforms to

the USA standard ASME B15.1, “Safety standard for mechanical power transmission apparatus.”

Flowserve manufacturing facilities worldwide conform to local coupling guard regulations.

5.4.2 ClearGuard™ - optional

Flowserve offers as an option a ClearGuard™, which allows you to see the condition of the coupling (see Figure 5-10). This guard can be used in place of the existing clamshell guard described earlier.

Disassembly of the ClearGuard™ is accomplished by

removing the fasteners that hold the two ClearGuard™ halves together followed by removing the foot bolts and rotating the support leg out of the slot on the guard.

Figure 5-10

Figure 5-11

5.4.3 Trimming instructions

In order to correctly fit the pump/motor configuration, each guard must be trimmed to a specific length. This trimming is done on the motor end of the guard.

a) Measure minimum distance from the center of

mounting hole in the baseplate to the motor. If clam shell guard proceed to step c b) Locate a reference center in the slot of the

ClearGuard™ coupling guard flange, see figure 5-

11. Transfer the length measurement to the guard using this reference center.

c) Trim the motor end of the guard according to the

above measurement. Trimming is best done with a band saw, but most other types of manual or power saws give acceptable results. Care must be taken to ensure that there is no gap larger than 6 mm (0.24 in.) between the motor and the coupling guard.

d) If motor diameter is smaller than guard

diameter, trim guard so that it extends over the end of the motor as far as possible.

e) Deburr the trimmed end with a file or a sharp

knife if ClearGuard™. Care must be taken to

eliminate all sharp edges.

5.4.4 Assembly instructions

Clam shell guard a) Mount support leg to each clam shell, figure 5-9. b) Attach one half of the guard to the baseplate. c) Engage the tabs of guard halves together. d) Attach the second support leg to the baseplate.

ClearGuard™ a) Place the bottom and top halves of the guard

around the coupling.

b) Install the support legs by inserting and then

rotating the tab on the leg through the slot in the guard until it comes through and locks the top and bottom halves of the guard together.

c) Attach the support legs to the baseplate using

the fasteners and washers provided.

d) Install fasteners in the holes provided to secure

the guard flanges together.

5.5 Priming and auxiliary supplies

The PolyChem M-series centrifugal pump will not move liquid unless the pump is primed. A pump is said to be “primed” when the casing and the suction piping are completely filled with liquid. Open discharge valves a slight amount. This will allow any entrapped air to escape and will normally allow the pump to prime, if the suction source is above the pump. When a condition exists where the suction pressure may drop below the pump’s capability, it is advisable to add a low-pressure control device to shut the pump down when the pressure drops below a predetermined minimum.

5.6 Starting the pump

a) Open the suction valve to full open position. It is

very important to leave the suction valve open while the pump is operating. Any throttling or adjusting of flow must be done through the discharge valve. Partially closing the suction valve can create serious NPSH and pump performance problems.

flowserve.com

USER INSTRUCTIONS PolyChem M-SERIES ENGLISH 71569218 07-11

Page 30 of 60

Never operate pump with both the suction and discharge valves closed. This could cause an explosion.

b) Ensure the pump is primed. (See section 5.5.) c) All cooling or heating, flush lines must be started

and regulated. d) Start the driver (typically, the electric motor). e) Slowly open the discharge valve until the desired

flow is reached, keeping in mind the minimum

continuous flow listed in section 3.4.4.

It is important that the discharge valve be opened within a short interval after starting the driver. Failure to do this could cause a dangerous build up of heat, and possibly an explosion.

5.7 Running or operation

NEVER RUN THE PUMP DRY OR WITHOUT PROPER PRIME (Pump flooded). Operating the pump dry may cause immediate damage to the bearings, magnets, etc..

5.7.1 Minimum continuous flow

Minimum continuous stable flow is the lowest flow at which the pump should be operated. The minimum continuous flow (capacity) is established as a percentage of the best efficiency point (BEP). (See section 3.4.4.)

5.7.2 Minimum thermal flow

All PolyChem M-series pumps also have a minimum thermal flow. This is defined as the minimum flow

that will not cause an excessive temperature rise. Minimum thermal flow is application dependent.

Do not operate the pump below minimum thermal flow, as this could cause an excessive temperature rise. Contact a Flowserve sales engineer for determination of minimum thermal flow.

Avoid running a centrifugal pump at drastically reduced capacities or with discharge valve closed for extended periods of time. This can cause severe temperature rise and the liquid in the pump may reach its boiling point. If this occurs, the internal process-lubricated bearings may be exposed to vapor, with no lubrication, and may be damaged or fail within a very short period of time. Continued running under these conditions when the suction valve is also closed can create an explosive condition due to the confined vapor at high pressure and temperature.

Thermostats may be used to safeguard against over heating by shutting down the pump at a predetermined temperature.

Safeguards should also be taken against possible operation with a closed discharge valve, such as installing a bypass back to the suction source. The size of the bypass line and the required bypass flow rate is a function of the input horsepower and the allowable temperature rise.

5.7.3 Reduced head

Note that when discharge head drops, the pump’s

flow rate usually increases rapidly. Check motor for temperature rise as this may cause overload. If overloading occurs, throttle the discharge.

5.7.4 Surging condition

A rapidly closing discharge valve can cause a damaging pressure surge. A dampening arrangement should be provided in the piping.

5.7.5 Operation in sub-freezing conditions

When using the pump in sub-freezing conditions where the pump is periodically idle, the pump should be properly drained or protected with thermal devices which will keep the liquid in the pump from freezing.

5.7.6 Bearing monitoring

If the pump is operating in a potentially explosive atmosphere temperature or vibration monitoring of the bearings is recommended.

5.7.6.1 Temperature monitoring

If bearing temperatures are to be monitored it is essential that a benchmark temperature is recorded at the commissioning stage and after the bearing temperature has stabilized.  Record the bearing temperature (t) and the

ambient temperature (ta)

 Estimate the likely maximum ambient

temperature (tb)

 Set the alarm at (t+tb-ta+5) ºC ((t+tb-ta+10) ºF)

and the trip at 100 ºC (212 ºF) for oil lubrication

and 105 ºC (220 ºF) for grease lubrication. It is important, particularly with grease lubrication, to keep a check on bearing temperatures. After start up the temperature rise should be gradual, reaching a maximum after approximately 1.5 to 2 hours. This temperature rise should then remain constant or marginally reduce with time.

flowserve.com

USER INSTRUCTIONS PolyChem M-SERIES ENGLISH 71569218 07-11

Page 31 of 60

Vibration velocity – unfiltered

Horizontal pumps  15 kW (20 hp) mm/s (in./sec) r.m.s.

> 15 kW (20 hp) mm/s (in./sec) r.m.s. Normal N

 3.0 (0.12)

 4.5 (0.18)

Alarm N x 1.25

 3.8 (0.15)

 5.6 (0.22)

Shutdown trip N x 2.0

 6.0 (0.24)

 9.0 (0.35)

5.7.6.2 Normal vibration levels, alarm and trip

For guidance, pumps generally fall under a classification for rigid support machines within the International rotating machinery standards and the recommended maximum levels below are based on those standards.

Alarm and trip values for installed pumps should be based on the actual measurements taken on the pump in the fully commissioned as new condition. Measuring vibration at regular intervals will then show any deterioration in pump or system operating conditions.

5.8 Stopping and shutdown

5.8.1 Shutdown considerations

When the pump is being shutdown, the procedure should be the reverse of the start-up procedure. First, slowly close the discharge valve, shut down the driver, and then close the suction valve. Remember that closing the suction valve while the pump is running is a safety hazard and could seriously damage the pump and other equipment.

5.9 Hydraulic, mechanical and electrical

duty

5.9.1 Net positive suction head (NPSH)

Net positive suction head - available (NPSHA) is the measure of the energy in a liquid above the vapor pressure. It is used to determine the likelihood that a fluid will vaporize in the pump. It is critical because a centrifugal pump is designed to pump a liquid, not a vapor. Vaporization in a pump will result in damage to the pump, deterioration of the Total differential head (TDH), and possibly a complete stopping of pumping. Net positive suction head - required (NPSHR) is the decrease of fluid energy between the inlet of the pump, and the point of lowest pressure in the pump. This decrease occurs because of friction losses and fluid accelerations in the inlet region of the pump and particularly accelerations as the fluid enters the impeller vanes. The value for NPSHR for the specific pump purchased is given in the pump data sheet, and on the pump performance curve.

For a pump to operate properly the NPSHA must be greater than the NPSHR. Good practice dictates that this margin should be at least 1.5 m (5 ft) or 20%, whichever is greater.

Ensuring that NPSHA is larger than NPSHR by the suggested margin will greatly enhance pump performance and reliability. It will also reduce the likelihood of cavitation, which can severely damage the pump.

5.9.2 Specific gravity (SG)

Pump capacity and total head in meters (feet) of liquid do not change with SG, however pressure displayed on a pressure gauge is directly proportional to SG. Power absorbed is also directly proportional to SG. It is therefore important to check that any change in SG will not overload the pump driver or over pressurize the pump.

5.9.3 Viscosity

For a given flow rate the total head reduces with increased viscosity and increases with reduced viscosity. Also for a given flow rate the power absorbed increases with the increased viscosity, and reduces with reduced viscosity. It is important that checks are made with your nearest Flowserve office if changes in viscosity are planned.

5.9.4 Pump speed

Changing the pump speed affects flow, total head, power absorbed, NPSHR, noise and vibration levels. Flow varies in direct proportion to pump speed. Head varies as speed ratio squared. Power varies as speed ratio cubed. If increasing speed, it is important to ensure the maximum pump working pressure is not exceeded, the driver and magnetic coupling is not overloaded, NPSHA > NPSHR and that noise and vibration are within local requirements and regulations.

6 MAINTENANCE

It is the plant operator's responsibility to ensure that all maintenance, inspection and assembly work is carried out by authorized and qualified personnel who have adequately familiarized themselves with the subject matter by studying this manual in detail. (See also section 1.6.)

Any work on the machine must be performed when it is at a standstill. It is imperative that the procedure for shutting down the machine is followed, as described in section 5.8.

flowserve.com

USER INSTRUCTIONS PolyChem M-SERIES ENGLISH 71569218 07-11

Page 32 of 60

On completion of work all guards and safety devices must be re-installed and made operative again.

Before restarting the machine, the relevant instructions listed in section 5, Commissioning, start up, operation and shut down must be observed.

Oil and grease leaks may make the

ground slippery. Machine maintenance must always begin and finish by cleaning the ground and the exterior of the machine.

If platforms, stairs and guard rails are required for maintenance, they must be placed for easy access to areas where maintenance and inspection are to be carried out. The positioning of these accessories must not limit access or hinder the lifting of the part to be serviced.

When air or compressed inert gas is used in the maintenance process, the operator and anyone in the vicinity must be careful and have the appropriate protection.

Do not spray air or compressed inert gas on skin. Do not direct an air or gas jet towards other people. Never use air or compressed inert gas to clean

clothes. Before working on the pump, take measures to

prevent the pump from being accidentally started. Place a warning sign on the starting device:

"Machine under repair: do not start."

With electric drive equipment, lock the main switch open and withdraw any fuses. Put a warning sign on the fuse box or main switch:

"Machine under repair: do not connect."

Never clean equipment with flammable solvents or carbon tetrachloride. Protect yourself against toxic fumes when using cleaning agents.

Refer to the parts list shown in section 8 for item number references used throughout this section.

6.1 Maintenance schedule

It is recommended that a maintenance plan and schedule be implemented, in accordance with these User Instructions, to include the following: a) Any auxiliary systems installed must be monitored,

if necessary, to ensure they function correctly. b) Check for any leaks from gaskets and oil seals. c) Check bearing lubricant level, and the remaining

hours before a lubricant change is required. d) Check that the duty condition is in the safe

operating range for the pump. e) Check vibration, noise level and surface

temperature at the bearings to confirm

satisfactory operation. f) Check dirt and dust is removed from areas

around close clearances, bearing housings and

motors. g) Check coupling alignment and re-align if

necessary.

6.1.1 Preventive maintenance

The following sections of this manual give instructions on how to perform a complete maintenance overhaul. However, it is also important to periodically repeat the Pre start-up checks listed in section 5.1. These checks will help extend pump life as well as the length of time between major overhauls.

6.1.2 Need for maintenance records

A procedure for keeping accurate maintenance records is a critical part of any program to improve pump reliability. There are many variables that can contribute to pump failures. Often long term and repetitive problems can only be solved by analyzing these variables through pump maintenance records.

6.1.3 Cleanliness

One of the major causes of pump failure is the presence of contaminants in the bearing housing. This contamination can be in the form of moisture, dust, dirt and other solid particles such as metal chips. It is very important that proper cleanliness be maintained. Some guidelines are listed below.  After draining the oil from the bearing housing,

periodically send it out for analysis. If it is contaminated, determine the cause and correct.

 The work area should be clean and free from

dust, dirt, oil, grease etc.

 Hands and gloves should be clean.  Only clean towels, rags and tools should be used.

flowserve.com

USER INSTRUCTIONS PolyChem M-SERIES ENGLISH 71569218 07-11

Page 33 of 60

6.2 Spare parts

The decision on what spare parts to stock varies greatly depending on many factors such as the criticality of the application, the time required to buy and receive new spares, the erosive/corrosive nature of the application, and the cost of the spare part. Section 8 identifies all of the components that make up each pump addressed in this manual. Please refer to the Flowserve Durco Pump Parts Catalog for more information. A copy of this book can be obtained from your local Flowserve sales engineer or distributor/representative.

6.2.1 Ordering of spare parts

Flowserve keeps records of all pumps that have been supplied. Spare parts can be ordered from your local Flowserve sales engineer or from a Flowserve distributor or representative. When ordering spare parts the following information should be supplied:

1) Pump serial number

2) Pump size and type

3) Part name – see section 8

4) Part item number – see section 8

5) Material of construction (alloy)

6) Number of parts required

The pump size and serial number can be found on the nameplate located on the bearing housing. See Figure 3-1.

6.3 Recommended spares and consumable items

On critical services where down time is particularly crucial it may be best to stock a spare pump or a rotating assembly allowing service to be quickly restored. The damaged pump or assembly could then be repaired and serve as a back-up.

6.4 Tools required

Do not perform maintenance on a steel workbench. The magnets present in the pump are strongly attracted to ferrous materials. Use a non-metallic (such as wood or plastic) workbench instead. The use of non metallic tools is also recommended. A typical range of tools that will be required to maintain these pumps is listed below.

Standard hand tools

 Hand wrenches (Metric and SAE)  Socket wrenches (Metric and SAE)  Allen wrenches (Metric and SAE)  Torque wrench (Metric and SAE)  Soft mallet  Screwdrivers

Specialized equipment

 Bearing pullers  Bearing induction heaters  Dial indicators  Flowserve Tool Kit (ISO and ANSI)  Arbor or bench press  Eyebolt

 M12x1.75 (Metric)  1/2 -13UNC (SAE)

 Shaft for torque testing (see Figures 6-2 and 6-3)

To simplify maintenance, it is recommended that the Flowserve Tool Kit (shown in Figure 6-1) is used. This tool kit includes a specialized wrench, which simplifies installation and removal of the outer magnet assembly on long-coupled pumps.

This tool kit can be ordered from your local Flowserve sales engineer or from a Flowserve distributor or representative

Figure 6-1

flowserve.com

USER INSTRUCTIONS PolyChem M-SERIES ENGLISH 71569218 07-11

Page 34 of 60

(1.32/1.30)

(3.06/3.04)

(5.11/5.09)

(0.16/0.14)

(0.22/0.20)

(1.52/1.50)

(1.748/1.746Ø)

(1.499/1.497Ø)

(1.55/1.54)

(2.01/1.99Ø)

(0.50/0.49)

Drill and tap for hex head bolt size to be determined by customer fastener size not to exceed M16 (ISO) or 5/8 (ANSI)

12.7

12.4

38.6

38.1

51.1

50.5

5.6

5.1

4.1

3.6

33.5

33.0

77.7

77.2

129.8

129.3

39.4

39.1

44.40

44.35

38.07

38.02

(1.52/1.50)

(0.50/0.49)

(2.30/2.28)

(6.51/6.49)

(0.14/0.12)

(0.32/0.30)

(2.64/2.62Ø)

(1.987/1.985Ø)

(1.78/1.76)

(1.968/1.966Ø)

Drill and tap for hex head bolt size to be determined by customer fastener size not to exceed M16 (ISO) or 5/8 (ANSI)

120°

67.1

66.6

38.6

38.1

12.7

12.4

50.47

50.42

8.1

7.6

3.5

3.0

45.2

44.7

58.4

57.9

165.4

164.9

49.99

49.94

Figure 6-2: Group A and 1

Figure 6-3: Group B and 2

flowserve.com

USER INSTRUCTIONS PolyChem M-SERIES ENGLISH 71569218 07-11

Page 35 of 60

Item #

Comment

Size – Lubricated torque Nm (lbf•ft)

Group 1

Group A

Group 2

Group B

6570.1

Screw – Bearing housing foot

3/8 in. – 20 (15)

12 mm – 34 (25)

3/4 in. – 127 (94)

16 mm – 80 (59)

6570.2

Screw – End cover/brg housing

1/4 in. – 11 (8)

6 mm – 11 (8)

3/8 in. – 41 (30)

10 mm – 41 (30)

6570.3

Screw – Outer magnet flange

1/4 in. – 11 (8)

6570.4

Screw – Adapter/motor

1/2 in. – 11 (8)

5/8" – 20 (15)

6570.5

Screw – Revese rotation

5/16 in. – 7 (5)

3/8 in. – 7 (5)

6570.6

Screw – Lantern/ Brg housing

1/2 in. – 15 (11)

12 mm – 15 (11)

N/A

6570.7

Screw – Retaining ring

N/A

3/8 in. – 34 (25)

10 mm – 34 (25)

6570.8

Screw – Brg housing/Brg holder

N/A

3/8 in. – 15 (11)

10 mm – 15 (11)

6570.9

Screw – Hub

5/16 in. – 24 (18)

5/8" – 20 (15)

6580

Nut – Casing stud

1/2 in. – 34 (25)

5/8 in. – 61 (45)

16 mm – 61 (45)

Flange Size

mm (in.)

Number

Of Bolts

Bolt Dia. mm (in.)

Bolt Torque

Nm (lbf•ft)

32 (1.3)

16 (0.63)

91 (67)

40 (1.6)

16 (0.63)

99 (73)

50 (2.0)

16 (0.63)

124 (91)

65 (2.6)

16 (0.63)

153 (112)

80 (3.1)

16 (0.63)

110 (81)

Flange Size

in. (mm)

Number

Of Bolts

Bolt Dia. in. (mm)

Bolt Torque

Nm (lbf•ft)

1 (25.4)

0.63 (16)

34 (25)

1 ½ (38.1)

0.63 (16)

75 (55)

2 (50.8)

0.63 (16)

102 (75)

3 (76.2)

0.63 (16)

149 (110)

4 (101.6)

0.63 (16)

129 (95)

Non metallic spacer

Impeller [2200]

Thrust Journal [3043]

6.5 Fastener torques

Figure 6-4: Recommended pump fastener torques - SI (US)

Note: 1) For Non-lubricated threads increase the listed value by 25%.

Figure 6-5: Recommended flange fastener torques - SI (US) ISO Pump with PN16 Flanges

ANSI Pump with Class 150 Flanges

6.6 Impeller

6.6.1 Replacement

The impeller could have sharp edges, which could cause an injury. It is very important to wear heavy gloves.

Prior to installing the impeller [2200] onto the shaft [2100.1] the thrust journal [3043] must be installed.

a) Place the impeller [2200] onto a flat surface with

the inlet facing up, refer to figure 6-6.

b) Align the slot on the thrust journal [3043] with the

molded pin on the impeller.

c) Press the thrust journal into the impeller until it is

seated flat.

It may be necessary to utilize an arbor press to aid in the assembly of the thrust journal into the impeller. If an arbor press is utilized a nonmetallic spacer should be placed between the ram of the press and the thrust journal. This spacer must be flat and the entire surface area of the thrust journal should be covered.

Figure 6-6

d) Press the impeller assembly onto the silicon

carbide shaft.

It may be necessary to utilize an arbor press to aid in the assembly of the impeller to the shaft. If an arbor press is utilized a nonmetallic spacer should be placed between the ram of the press and the recently installed thrust journal. This spacer must be flat and the entire surface area of the thrust journal should be covered. See figure 6-7 and 6-8.

6.6.2 Trimming

If a new impeller of maximum diameter has been acquired and needs trimming or if an existing impeller needs trimming this is accomplished by turning (machining). It is recommended that this trimming operation be performed by a Flowserve representative. However, if this cannot be accommodated the following guidelines should be followed.

flowserve.com

USER INSTRUCTIONS PolyChem M-SERIES ENGLISH 71569218 07-11

Page 36 of 60

P_3x1.5-6 & P_3x2-6

Trim Diameter

Front Shroud

Diameter

inch

158.75 (a)

(6.250)

158.75

(6.250)

155.58 (a)

(6.125)

155.58

(6.125)

152.40

(6.000)

158.75

(6.250)

149.23

(5.875)

156.74

(6.171)

146.05

(5.750)

153.61

(6.048)

142.88

(5.625)

150.49

(5.925)

139.70

(5.500)

147.37

(5.802)

136.53

(5.375)

144.25

(5.679)

133.35

(5.250)

141.12

(5.556)

130.18

(5.125)

138.00

(5.433)

127.00

(5.000)

134.87

(5.310)

123.83

(4.875)

131.75

(5.187)

120.65

(4.750)

128.63

(5.064)

117.48

(4.625)

125.51

(4.941)

114.30

(4.500)

122.38

(4.818)

P_3x2-10

Trim Diameter

Front Shroud

Diameter

inch

254.00

(10.000)

10.417

(10.417)

250.83

(9.875)

10.297

(10.297)

247.65

(9.750)

10.176

(10.176)

244.48

(9.625)

10.056

(10.056)

241.30

(9.500)

9.935

(9.935)

238.13

(9.375)

9.815

(9.815)

234.95

(9.250)

9.694

(9.694)

231.78

(9.125)

9.574

(9.574)

228.60

(9.000)

9.453

(9.453)

225.43

(8.875)

9.333

(9.333)

222.25

(8.750)

9.212

(9.212)

219.08

(8.625)

9.092

(9.092)

215.90

(8.500)

8.971

(8.971)

212.73

(8.375)

8.850

(8.850)

209.55

(8.250)

8.730

(8.730)

206.38

(8.125)

8.609

(8.609)

203.20

(8.000)

8.489

(8.489)

200.03

(7.875)

8.368

(8.368)

196.85

(7.750)

8.248

(8.248)

193.68

(7.625)

8.127

(8.127)

190.50

(7.500)

8.007

(8.007)

187.33

(7.375)

7.886

(7.886)

184.15

(7.250)

7.766

(7.766)

180.98

(7.125)

7.645

(7.645)

177.80

(7.000)

7.525

(7.525)

174.63

(6.875)

7.405

(7.405)

171.45

(6.750)

7.294

(7.294)

168.28

(6.625)

7.194

(7.194)

165.10

(6.500)

7.110

(7.110)

Front

Shroud

Diameter

Trim

Diameter

30°

20°

Front

Shroud

Diameter

Trim

Diameter

All impellers are fully trimmable however certain models must be angled trimmed. See the below chart for these exceptions.

a) Obtain a machining arbor from a Flowserve

representative.

b) Carefully mount the arbor into a lathe. Take care

to minimize the runout of the machining arbor.

c) Install the impeller for trimming. Pump Models P_3x1.5-6 and P_3x2-6

Pump Models P_3x2-10 and P_4x3-10

Notes:

(a) Straight cut to be made when impeller trim is greater than

152.40 mm (6.000 in.). (b) Interpolate between shown dimensions for 1.57 mm (0.062 in.) trim increments.

Notes:

(a) Interpolate between shown dimensions for 1.57 mm (0.062 in.) trim increments.

flowserve.com

USER INSTRUCTIONS PolyChem M-SERIES ENGLISH 71569218 07-11

Page 37 of 60

P_4x3-10

Trim Diameter

Front Shroud

Diameter

inch

Inch

254.00

(10.000)

N/A

250.83

(9.875)

N/A

247.65

(9.750)

265.31

(10.445)

244.48

(9.625)

262.27

(10.325)

241.30

(9.500)

259.23

(10.206)

238.13

(9.375)

256.18

(10.086)

234.95

(9.250)

253.14

(9.966)

231.78

(9.125)

250.10

(9.847)

228.60

(9.000)

247.06

(9.727)

225.43

(8.875)

244.02

(9.607)

222.25

(8.750)

240.98

(9.487)

219.08

(8.625)

237.94

(9.368)

215.90

(8.500)

234.90

(9.248)

212.73

(8.375)

231.86

(9.128)

209.55

(8.250)

228.82

(9.009)

206.38

(8.125)

225.78

(8.889)

203.20

(8.000)

222.73

(8.769)

200.03

(7.875)

219.69

(8.649)

196.85

(7.750)

216.65

(8.530)

193.68

(7.625)

213.61

(8.410)

190.50

(7.500)

210.57

(8.290)

187.33

(7.375)

207.53

(8.170)

184.15

(7.250)

204.49

(8.051)

180.98

(7.125)

201.45

(7.931)

177.80

(7.000)

198.40

(7.811)

174.63

(6.875)

195.37

(7.692)

171.45

(6.750)

192.52

(7.580)

168.28

(6.625)

189.96

(7.479)

165.10

(6.500)

187.77

(7.393)

Figure 6-8: Group B and 2 pumps

6.7 Pump removal and disassembly

a) Before performing any maintenance, disconnect

the driver from its power supply and lock it off line.

Lock out power to driver to prevent

personal injury. b) Close the discharge and suction valves, and

drain all liquid from the pump.

c) Close all valves on auxiliary equipment and

piping, then disconnect all auxiliary piping.

d) Decontaminate the pump as necessary.

Notes:

Interpolate between shown dimensions for 1.57 mm (0.062 in.) trim increments.

Figure 6-7: Group A and 1 pumps

If Flowserve PolyChem M-series pumps contain dangerous chemicals, it is important to follow plant safety guidelines to avoid personal injury or death.

Small amounts of liquid may be trapped in the casing and/or containment area. Proper decontamination is the responsibility of the user.

Drain and flush the pump before proceeding. The PolyChem M-series pump is designed to handle corrosive, toxic, and hazardous process fluids and may need to be decontaminated prior to any disassembly

flowserve.com

USER INSTRUCTIONS PolyChem M-SERIES ENGLISH 71569218 07-11

Page 38 of 60

6.7.1 Pump removal

6.7.1.1 Long-coupled PolyChem M-series pumps

a) Remove coupling guard. b) Remove the spacer from the spacer coupling. c) Remove the cap screws holding the bearing

housing and casing feet to the baseplate.

d) Remove the fasteners attaching the suction and

discharge piping to the pump.

e) Attach lifting equipment to the pump, placing it in

light tension to support the pump.

f) Move the pump assembly away from the piping

(towards the motor) and rotate the unit out.

g) The pump can now be moved to the repair shop.

6.7.1.2 Close-coupled PolyChem M-series pumps

a) Remove the fasteners holding the motor and or

lantern and casing feet to the baseplate.

b) Remove the fasteners attaching the suction and

discharge piping to the pump.

c) Attach lifting equipment to the pump, placing it in

light tension to support the pump. d) Move the pump assembly away from the piping. e) The pump can now be moved to the repair shop.

6.7.2 Pump removal – less casing

Group A & 1 pumps are assembled vertically

and the casing is required during the process. Therefore is is strongly recommended that the entire pump is removed as described in 6.7.1. above

Group B & 2 pumps can be removed, leaving the

casing installed in the piping, as described in

6.7.2.1 and 6.7.2.2.

6.7.2.1 Long-coupled PolyChem M-series

pumps

a) Remove coupling guard. b) Remove the spacer from the spacer coupling. c) Remove the cap screw(s) holding the bearing

housing foot to the baseplate. d) Attach lifting equipment to the pump, placing it in

light tension to support the pump when it is

removed from the casing. e) Remove all casing stud nuts [6572]. f) Move the pump assembly away from the casing

(towards the motor) and rotate the unit out,

leaving the casing in place (Figure 6-9).

Figure 6-9

g) Inspect the casing [1100] and the thrust bearing

bushing [3041] located in the casing for wear, corrosion, or defects.

h) The pump less casing [1100] can now be moved

to the repair shop.

6.7.2.2 Close-coupled PolyChem M-series pumps

a) Remove the fasteners holding the motor and or

lantern to the baseplate.

b) Attach lifting equipment to the pump, placing it in

light tension to support the pump when it is

removed from the casing. c) Remove all casing stud nuts [6572]. d) Move the pump assembly away from the casing,

leaving the casing in place (Figure 6-10). Figure 6-10

e) Inspect the casing [1100] and the thrust bearing

bushing [3041] for wear, corrosion, or defects. f) The pump less casing [1100] can now be moved

to the repair shop.

flowserve.com

USER INSTRUCTIONS PolyChem M-SERIES ENGLISH 71569218 07-11

Page 39 of 60

6.7.3 Drive end removal - without breaking process containment

By following the steps in section 6.7.3.1 or

6.7.3.2, the process fluid is contained and the power

end can be completely removed. This procedure does not preclude the use of personal protective gear. Personnel should follow their standard plant safety practices.

The magnetic coupling will remain engaged even after the fasteners that attach the drive end to the wet end have been removed. This is due to the strong radial and axial forces associated with the magnetic coupling. 7

Do not attempt to remove the drive end from the wet end without using the jackbolts. The magnetic force can cause severe personal injury.

Be sure to separate the inner and outer magnet assemblies evenly. Cocking of the two can result in serious damage to the magnets and/or containment shell. It is best to alternatively give each bolt a turn to ensure proper and even separation.

6.7.3.1 Long-coupled PolyChem M-series

pumps

Figure 6-11: Group A and 1 pumps

Figure 6-12: Group B and 2 pumps

a) Remove coupling guard. b) Remove the spacer coupling. c) Loosen the cap screw(s) holding the bearing

housing foot to the baseplate.

d) To remove the power end from the wet end, on

Group A and 1 pumps remove the four (4) bearing housing/lantern fasteners [6570.6]. On Group B and 2 pumps remove the six (6) bearing housing/bearing holder fasteners [6570.8].

e) Screw the two (2) square head jackbolts [6575]

in the lantern (Group A and 1 pumps) or bearing housing (Group B and 2 pumps) through the threaded holes until each comes into contact with its mating part. (see figure 6-11 and 6-12). Continue to screw all jackbolts in evenly to detach the wet end from the power end. (Figure 6-13 and 6-14)

It may be necessary to move the motor to

complete step e). f) The power end can now be moved to the repair

shop.

Figure 6-13: Group A and 1 pumps

flowserve.com

USER INSTRUCTIONS PolyChem M-SERIES ENGLISH 71569218 07-11

Page 40 of 60

Figure 6-14: Group B and 2 pumps

6.7.3.2 Close-coupled PolyChem M-series

pumps

Figure 6-15: Group A and 1 pumps

c) Screw the two (2) square head jackbolts [6575]

in the lantern through the threaded holes until each comes into contact with its mating part. (Figure 6-15 and 6-16) Continue to screw both jackbolts evenly to disengage the motor from the wet end of the pump. (Figure 6-17 and 6-18)

d) The drive end can now be moved to the repair

shop.

Figure 6-17: Group A and 1 pumps

Figure 6-18: Group B and 2 pumps

Figure 6-16: Group B and 2 pumps

a) Loosen the fasteners (if applicable) holding the

motor to the baseplate.

b) To remove the motor from the wet end, on Group

A and 1 pumps remove the four (4) motor flange/lantern fasteners [6570.6]. On Group B and 2 pumps remove the six (6) lantern/bearing holder fasteners [6570.8].

6.7.4 Removal of drive end from the wet end

Do not attempt to remove the drive end from the wet end without using the jackbolts. The magnetic force can cause severe personal injury.

flowserve.com

USER INSTRUCTIONS PolyChem M-SERIES ENGLISH 71569218 07-11

Page 41 of 60

Nonmetallic Material

Key [6700.2]

Holder [3830]

Impeller [2200]

Inner Magnet [0220]

Shaft

2100.1

Nonmetallic Spacer

On Group A and 1 pumps; if the pump being disassembled has been pulled less casing, upon removal of the drive end (outer magnet) the remaining wet end components will no longer be held together by either magnetism or bolting. Care needs to be exercised to prevent damaging the wet end components. On Group B and 2 pumps an eyebolt

should be installed at the 12 o’clock position on the

bearing holder [3830]. An appropriate lifting device should be attached to the eyebolt, placing it in light tension to support the pump.

6.7.4.1 Long-coupled PolyChem M-series

pumps

Refer to section 6.7.3.1 steps d and e.

6.7.4.2 Close-coupled PolyChem M-series

pumps

Refer to section 6.7.3.2 steps b and c.

6.7.5 Disassembly of wet end

c) The assembly comprised of the impeller [2200],

shaft [2100.1], holder [3830], an inner magnet. [0220] should be removed from the lantern.

d) This assembly should be placed on a nonmetallic

surface under an arbor press. See Figure 6-20.

e) Using a nonmetallic spacer, press the square

end of the shaft [2100.1] until it is disengaged from the impeller [2200].

Make sure that the shaft is free to travel downward. Do not allow the shaft to fall as it is being pressed free of the impeller and inner magnet.

Figure 6-20

Take care when handling the internal bearings of the pump - journals, bushings, and shaft. These parts are easily chipped and damaged.

6.7.5.1 Group A and 1 pumps

a) Place the wet end assembly on the face of the

lantern. See Figure 6-19.

Figure 6-19

b) Remove the impeller [2200].

If the impeller remains attached to the shaft it may be necessary to utilize an arbor press to aid in its removal as well as the removal of the inner magnet. If an arbor press is utilized, a nonmetallic spacer should be placed between the ram of the press and the shaft.

f) Remove the impeller [2200] and holder [3830]. g) Continue pressing the end of the shaft [2100.1]

until it disengages from the inner magnet [0220]. h) Remove the key [6700.2] from the shaft. i) Place the holder [3830] under the arbor press

and again using a nonmetallic spacer press the

inboard bushing [3300] until it becomes

disengaged. j) Remove the containment shell [3500] from the

lantern [1340].

6.7.5.2 Group B and 2 pumps

a) The wet end assembly should be supported

horizontally. A tapped hole is located at the 12

o’clock position on the holder [3830] so that an

eyebolt can be engaged. An appropriate lifting

device should be attached to the eyebolt, placing

it in light tension to support the wet end. See

Figure 6-21.

flowserve.com

USER INSTRUCTIONS PolyChem M-SERIES ENGLISH 71569218 07-11

Page 42 of 60

Impeller [2200]

Holder [3830]

Nonmetallic Material

Inner Magnet

Key [6700.2]

Shaft [2100.1]

Nonmetallic Spacer

Figure 6-21

The retainer ring [2530] is manufactured from carbon steel and may attach to the containment shell [3500] upon removal due to the presence of magnets in the inner magnet assembly.

b) Remove the twelve (12) retainer

ring/containment shell cap screws [6570.7]. Remove the retainer ring [2530]. In the event the retainer ring is lodged in place, two (2) tapped holes have been provided on this ring to aid in its removal. The recently removed cap screws can be used for this purpose.

c) Remove the containment shell [3500]. See

Figure 6-22.

Figure 6-22

magnet. If an arbor press is utilized, a nonmetallic spacer should be placed between the ram of the press and the shaft.

e) The assembly comprised of the impeller [2200],

shaft [2100.1], holder [3830], and inner magnet [0220] should be placed on a nonmetallic surface under an arbor press. See Figure 6-23.

f) Using a nonmetallic spacer, press the end of the

shaft [2100.1] until it is disengaged from the impeller [2200].

Make sure that the shaft is free to travel downward. Do not allow the shaft to fall as it is being pressed free of the impeller and inner magnet.

Figure 6-23

g) Remove the impeller [2200] and holder [3830]. h) Continue pressing the end of the shaft [2100.1]

until it disengages from the inner magnet [0220]. i) Remove the keys [6700.2] from the shaft. j) Place the holder [3830] under the arbor press in

the same orientation as shown in Figure 6-23.

Using a nonmetallic spacer press the inboard

bushing [3300] until it becomes disengaged. k) Remove o-ring [4610.2] from holder [3830] and

discard.

6.7.6 Disassembly of drive end

d) Remove the impeller [2200].

it may be necessary to utilize an arbor press to aid in its removal as well as the removal of the inner

If the impeller remains attached to the shaft

Be aware of strong magnetic forces of the outer magnets. Keep magnetic material away from these magnets. Observe previous warnings concerning these magnets.

flowserve.com

USER INSTRUCTIONS PolyChem M-SERIES ENGLISH 71569218 07-11

Page 43 of 60

Bearing Cover [3260]

Bearing Housing [3200]

Outer Magnet [0230]

Shaft [2100.2] & Bearings [3011]

Washer [4260]

6.7.6.1 Long-coupled PolyChem M-series pumps

Figure 6-24

This procedure is necessary if the outer magnet assembly, anti-friction bearings or oil seals must be replaced. See Figure 5-5 for recommendations on ball bearing relubrication intervals.

a) Mount the power end to the work bench. b) Drain the oil in the bearing housing by removing

the bearing housing drain plug [6569.1]. Put the bearing housing drain plug back into place after the bearing housing is drained.

c) Remove the Trico oiler/site gage [3855] (Figure 6-

25) and oil level tag (Figure 6-26) from the bearing housing.

d) Mount the drive shaft/coupling key [6700] and a

Flowserve impeller wrench onto the shaft.

e) Remove reverse rotation screw [6570.5] with an

allen wrench. The threads are right hand.

f) Unscrew the outer magnet/flange assembly

[0230] from the drive shaft [2100.2]. With the impeller wrench handle pointing to the right when viewed from the magnet side of the bearing housing [3200], grasp the magnet firmly. Spin it rapidly in a counterclockwise direction so that the wrench handle makes a solid impact with the work surface to the left of the housing. After several sharp raps, the outer magnet/flange assembly should be free and easily removed. It is recommended that the magnet assemblies be stored in plastic bags to avoid the necessity to clean later.

g) Remove the three (3) bearing cover fasteners

[6570.3] and bearing cover [3260]. Remove the bearing cover/bearing housing O-ring [4610.9] and discard. Pull the drive shaft and bearing assembly out of the bearing housing in one straight motion. Avoid cocking the assembly in the housing. Remove the wavy washer [4260].

h) If lip seals [4310.1] and [4310.2] (see Figure 6-

27) are used, they should be removed from the bearing cover [3260] and bearing housing [3200] and discarded.

Figure 6-25

Figure 6-26

Figure 6-27

i) If bearing isolators are removed from either the

bearing cover [3260] or bearing housing [3200] they must not be reused, discard appropriately.

j) If necessary, remove the bearing housing foot

[3134] by unscrewing the footpiece fastener [6570.4] from the bearing housing. A shim [3126] may also be present.

k) If the ball bearings [3011] need to be replaced,

remove the bearings from the drive shaft. If the bearings are to be replaced and the drive shaft reused, extra care should be taken so as not to damage the drive shaft. Remove the bearings with a bearing puller. Even pressure should be applied. It is recommended that the bearings not be reused if they are removed from the drive shaft.

flowserve.com

USER INSTRUCTIONS PolyChem M-SERIES ENGLISH 71569218 07-11

Page 44 of 60

Jackbolt [6575]

Hub [7200]

Outer Magnet Flange [0231]

Lantern

[1340]

Hub [7200]

Fastener & Lockwasher

Outer Magnet Flange [0231]

Keep contaminants out of the bearing

housing and bearings.

6.7.6.2 Close-coupled PolyChem M-series

pumps

Figure 6-28: Group A and 1 pumps

Figure 6-29: Group B and 2 pumps

c) Remove the fasteners [6570.9] that attach the

outer magnet flange [0231] to the hub [7200].

d) To remove the motor flange [0231], remove the

four (4) motor flange/motor fasteners [6570.4].

e) The outer magnet flange [0231] can be

separated from the outer magnet [0230] by removing fasteners [6570.3].

Group B and 2 pumps: a) Loosen the fasteners [6570.9] that attaches the

outer magnet assembly [0230] to the hub [7200]. See Figure 6-29.

b) To remove the lantern [1340], remove the four

(4) lantern/motor fasteners [6570.4].

c) Loosen the set screws that attaches the hub

[6814] to the motor, pull the hub off the shaft.

d) The outer magnet flange [0231] can be

separated from the outer magnet [0230] by removing fasteners [6570.3].

6.8 Examination of parts

Cleaning/inspection

All parts should be thoroughly cleaned and inspected. New anti-friction bearings, O-rings, gaskets and lip seals should be used (if so equipped). Any parts that show wear or corrosion should be replaced with new genuine Flowserve parts.

This procedure is necessary only if the outer magnet assembly [0230] or motor must be replaced.

Group A and 1 pumps: a) Loosen the set screw that attaches the outer

magnet assembly [0230] to the motor shaft. See Figure 6-28.

b) Remove the outer magnet assembly [0230] from

the motor shaft. As a disassembly aide, a threaded hole has been provided in the center of the outer magnet flange [0231] to enable the outer magnet flange to be jacked off of the motor shaft. One of the square head jackscrews [6575] from the lantern [1340] can be used for this step.

It is important that only non-flammable, non-contaminated cleaning fluids are used. These fluids must comply with plant safety and environmental guidelines.

Critical measurements and tolerances

To maximize reliability of pumps, it is important that certain parameters and dimensions are measured and maintained within specified tolerances. It is important that all parts be checked. Any parts that do not conform to the specifications should be replaced with new Flowserve parts.

Parameters that should be checked by users

Flowserve recommends that the user check the condition of the individual pump components whenever maintenance is performed. It is described in more detail below.

flowserve.com

USER INSTRUCTIONS PolyChem M-SERIES ENGLISH 71569218 07-11

Page 45 of 60

Figure 6-30: Wet end allowable wear

Axial Allowable Bearing Wear (total) 0.38 mm (0.015 in)

Diametrical Allowable Bearing Wear (total) 0.61 mm (0.024 in)

Liner Allowable Wear 25% of thickness

AS NEW DIMENSIONS – NOMIINAL

AXIAL BEARING FEATURES

Group A and 1

Group B and 2

Thrust Journal and Bushing

Thickness

4.78 (0.188)

6.35 (0.250)

Shell Thrust Bushing Depth

95.89 (3.775)

112.27 (4.420)

Shaft Shoulder Thickness

5.21 (0.205)

7.9 (0.31)

Pump Model

Impeller Height

Casing Depth

32-160

49.99 (1.968)

70.79 (2.787)

65-160

50.50 (1.988)

85.24 (3.356)

40-200

51.26 (2.018)

84.89 (3.342)

1.5x1-6

48.97 (1.928)

74.73 (2.942)

3x1.5-6

52.27 (2.058)

78.87 (3.105)

3x2-6

52.27 (2.058)

78.87 (3.105)

1.5x1-8

49.48 (1.948)

75.82 (2.985)

32-250

57.66 (2.270)

92.91 (3.658)

50-250

58.17 (2.290)

93.24 (3.671)

65-250

63.25 (2.490)

98.08 (3.862)

2x1-10

57.66 (2.270)

95.76 (3.770)

3x2-10

56.90 (2.240)

94.92 (3.737)

4x3-10

63.25 (2.490)

101.35 (3.990)

RADIAL BEARING FEATURES

Group A and 1

Group B and 2

Bushing Inside Diameter

38.13 (1.501)

50.04 (1.970)

Shaft Outside Diameter

38.087 (1.4995)

50.000 (1.9685)

ADDITIONAL COMPONENT FEATURES

Group A and 1

Group B and 2

Shell Inside Diameter

124.89 (4.917)

195.83 (7.71)

Inner Magnet

O.D.

121.92 (4.800)

190.04 (7.482)

I.D.

44.450 (1.7500)

50.533 (1.9895)

Width

12.75 (0.502)

Key Width

12.57 (0.495)

Note: Dimensions shown above are in millimeters (inches).

Bushing I.D.

Thrust Bearing Depth

Inside Diameter

Bushing

I.D.

Bearing

Holder

Shoulder Thickness

Outside Diameter

Width

Inside Diameter

Outside Diameter

6.8.1 Wet End

a) Inspect the bushings, thrust journals and shaft

for wear. Total diametrical and axial wear limits are shown in Figure 6-30.

b) Inspect the casing, impeller, holder, inner

magnet and containment shell for wear, corrosion and defects. The nominal liner thickness for all components is 3.18 mm (0.125 inches).

Figures 6-31 through 6-36 have been provided as a guide for identifying the features listed in the table.

Figure 6-31: Shell

Figure 6-32: Shaft

Figure 6-33: Bushing

Figure 6-34: Inner Magnet

flowserve.com

USER INSTRUCTIONS PolyChem M-SERIES ENGLISH 71569218 07-11

Page 46 of 60

Pump

Group

Pump Prefix

Magnet

Torque at 20°C (68°F)

N-m (lbf-in)

Poles

Length

A & 1

PA 8 31.8 (1.25)

18 (160)

31.8 (1.25)

26 (230)

63.5 (2.50)

61 (540)

B & 2

63.5 (2.50)

47 (420)

63.5 (2.50)

77 (680)

86.4 (3.40)

111 (983)

Thrust Bearing

Width

Depth

Thrust Bearing

Height

Figure 6-35: Impeller

Figure 6-36: Casing

6.8.2 Impeller drive

a) The condition of the impeller drive mechanism

should be checked whenever maintenance is performed.

b) Measure the circumferential movement “M” of

the impeller when it is mounted on the shaft. c) Verify the impeller diameter “D”. d) Substitute values “M” and “D” into the equation

and if the answer is less than or equal to 10 then

the impeller can be reused. M ÷ (0.017 x (D ÷ 2)) ≤ 10 Reuse the impeller

> 10 Replace impeller or insert

Figure 6-37: Impeller Drive Check

6.8.3 Magnetic Coupling

MAGNETIC FIELD PRESENT

Do not use the silicon carbide shaft to check the torque rating of the magnetic coupling. If the magnetic coupling must be checked, a metallic shaft similar to that shown in section 6.4 (Tools required) must be substituted.

There are a total of six magnetic couplings. Three for the Group A and 1 pumps and three for the Group B and 2 pumps. It is imperative that the appropriate inner magnet assembly be matched with the corresponding outer magnet.

This test can only be performed on a longcoupled pump, you must have a means to prevent the rotation of the outer magnet.

Figure 6-38: Magnetic Coupling Torques

Note: Length dimensions shown in millimeters (inches).

a) Reassemble the pump (see section 6.9)

substituting a metallic shaft (see section 6.4) for the silicon carbide shaft.

b) Install the Flowserve impeller wrench and key

onto the input shaft of the pump. The wrench handle should be touching the workbench towards the right as you are facing the suction flange of the pump.

c) Utilizing a torque wrench and socket (an

extension may be necessary) place it onto the hex head protruding from the end of the metallic shaft.

d) Rotate the wrench and determine if you can

achieve the torque values shown in Figure 6-37 for the magnetic coupling being evaluated.

Do not exceed the values listed in

Figure 6-38. e) If the noted value is obtained you can reuse the

coupling provided there is no other damage. If on the other hand the value was not reached you

flowserve.com

USER INSTRUCTIONS PolyChem M-SERIES ENGLISH 71569218 07-11

Page 47 of 60

PolyChem M-series

Feature mm (in)

Group A and 1

Group B and 2

Bearing OD

79.992/79.987

(3.1493/3.1491)

110.000/109.985 (43304/43301)

35.000/34.989

(1.3780/1.3775)

50.000/49.987

(1.9685/1.9680)

Shaft OD

35.014/35.004

(1.3785/1.3781)

50.013/50.003

(1.9690/1.9686)

Housing ID

80.020/80.005

(3.1504/3.1498)

110.023/110.007

(4.3316/4.3310)

Fit Bearing/Housing

0.033L/0.013L

(0.0013L/0.0005L)

0.038L/0.008L

(0.0015L/0.0003L)

Fit Bearing/Shaft

0.025T/0.004T

(0.0010T/0.0001T)

0.026T/0.003T

(0.0010T/0.0001T)

will need to replace either the inner (most likely) or outer magnet assembly.

6.8.4 Power End

a) Inspect the outer magnet for wear and condition

of potting compound that exists between the magnet poles.

b) Inspect the anti-friction bearings for scoring,

pitting, scratches or rust. If any of these conditions exists or if the bearings have been removed from the shaft the bearings should be replaced.

c) In order to ensure proper bearing fits, the shaft

(OD), bearings (ID and OD), and bearing housing (ID) should be checked. A micrometer can be used to check the OD dimensions and an inside caliper the ID dimensions. See Figure 6-

39.

Figure 6-39

6.8.4.1 Alignment

Misalignment of the pump and motor shafts can cause the following problems:

 Failure of the motor and/or pump bearings  Failure of the coupling  Excessive vibration/noise

The schematics below show the technique for a typical rim and face alignment using a dial indicator. It is important that this alignment be done after the flanges are loaded, and at typical operating temperatures. If proper alignment cannot be maintained a close coupled arrangement and/or stilt/spring mounting should be considered.

Alignment

Many companies today are using laser alignment which is a more sophisticated and accurate technique. With this method a laser and sensor measure misalignment. This is fed to a computer with a graphic display that shows the required adjustment for each of the motor feet.

See section 4.8 for recommended final shaft alignment limits.

6.8.4.2 Vibration analysis

Vibration analysis is a type of condition monitoring

where a pump’s vibration “signature” is monitored on

a regular, periodic basis. The primary goal of vibration analysis is extension on MTBPM. By using this tool Flowserve can often determine not only the existence of a problem before it becomes serious, but also the root cause and possible solution.

Modern vibration analysis equipment not only detects if a vibration problem exists, but can also suggest the cause of the problem. On a centrifugal pump, these causes can include the following: unbalance, misalignment, defective bearings, resonance, hydraulic forces, cavitation and recirculation. Once identified, the problem can be corrected, leading to increased MTBPM for the pump.

Flowserve does not make vibration analysis equipment; however Flowserve strongly urges customers to work with an equipment supplier or consultant to establish an on-going vibration analysis program.

6.9 Assembly of pump

It is important that all pipe threads be sealed properly. Flowserve does not recommend the use of PTFE tape as a thread sealant.

Flowserve has investigated and tested alternate sealants and has identified two that provide an effective seal and have the same chemical resistance as the tape. These are La-co Slic-Tite and Bakerseal. Both products contain finely ground PTFE particles in

flowserve.com

USER INSTRUCTIONS PolyChem M-SERIES ENGLISH 71569218 07-11

Page 48 of 60

Pump

Group

Type of bearing

Inboard and outboard

single row, deep groove

A & 1

Oil bath / mist –

Open

6307-C3

Greased for life –

double shielded

6307-2ZC3

B & 2

Oil bath / mist –

Open

6310-C3

Greased for life –

double shielded

6310-2ZC3

an oil based carrier. They are supplied in a paste form which is brushed onto the male pipe threads. Flowserve recommends using one of these paste sealants.

Full thread length engagement is required for all fasteners.

Refer to Figure 6-4 for recommended bolt

torques.

6.9.1 Power end assembly – Long Coupled

6.9.1.1 Bearing installation

Mounting of bearings on shafts must be done in a clean environment. Bearing and power end life can be drastically reduced if even very small foreign particles work their way into the bearings. Wear clean gloves.

Bearings should be removed from their protective packaging only immediately before assembly to limit exposure to possible contamination. After removing the packaging they should only come in contact with clean hands, fixtures, tools and work surfaces.

The chart shown in Figure 6-40 gives the part numbers for bearings in Flowserve PolyChem pumps. Note that

the term “inboard bearing” refers to the bearing nearest to the casing. “Outboard bearing” refers to the bearing

nearest to the motor.

Both bearings have a slight interference fit which requires that they be pressed on the shaft with an arbor or hydraulic press. Even force should be applied to only the inner race. Never press on the outer race, as the force will damage the balls and races.

An alternate method of installing bearings is to heat the bearings to 93 °C (200 °F) by means of an oven or induction heater. With this approach the bearing must be quickly positioned on the shaft.

Never heat the bearings above 110°C (230°F). To do so will likely cause the bearing fits to permanently change, leading to early failure.

Figure 6-40: Flowserve PolyChem M-series antifriction bearings

Notes:

1) These bearings are open on both sides. They are lubricated by oil bath or oil mist.

2) These bearings are shielded on both sides. They come pregreased by the bearing manufacturer. The user does not need to regrease these bearings. The shields do not actually contact the bearing race, so no heat is generated.

3) All bearing configurations are supplied only with steel cages

a) Install the inboard bearing [3011.1] on the shaft

[2100.2] until it is positioned against the shoulder.

b) Allow the inboard bearing to cool before installing

the outboard bearing.

c) Install the outboard bearing [3011.2] on the shaft

[2100.2] until it is positioned against the shoulder.

d) Allow the outboard bearing to cool and then check

bearings for ease of rotation.

6.9.1.2 Power end seals

Lip seals

If lip seals were used install new lip seals in the bearing cover [3260] and the housing [3200]. The lip seals [4310.1 and 4310.2] are double lip style, the cavity between these two lips should be 1/2 to 2/3 filled with grease. When installing this part, the large metal face on the lip seal must face away from the bearings.

Labyrinth seals

The following are general installation instructions regarding the VBXX Inpro seal. Follow the instructions provided with the seal by the manufacturer.

The elastomer O-ring located on the OD of the seal has been sized to overfill the groove in which it is located. When installing the seal into its corresponding housing, in addition to compressing the O-ring a certain amount of material may shear off. This sheared material should be removed. An arbor press should be used to install the seal.

Install the inboard seal in the bore of the bearing housing with the single expulsion port positioned at the 6 o’clock position.

flowserve.com

USER INSTRUCTIONS PolyChem M-SERIES ENGLISH 71569218 07-11

Page 49 of 60

Hub [7200]

Installation Studs

Hub and end of motor shaft must be aligned

Motor shaft

Install the outboard seal in the bore of the bearing cover with the single expulsion port positioned at the 6 o’clock position.

Magnetic seals

Follow the installation instructions provided by the manufacturer.

6.9.1.3 Bearing cover/shaft/power end assembly

a) Clean the interior surfaces of the bearing

housing and cover with a non-flammable solvent cleaner.

b) Place the wavy washer [4260] in the bearing

housing [3200]. Slide the shaft [2100.2] with anti-friction bearings installed into the bearing housing [3200] (Figure 6-24).

The axial location of the shaft/anti-friction bearing assembly is accomplished after the bearing cap is installed and the wavy washer is compressed. The compression results in preloading the anti-friction bearings which is essential for proper bearing operation.

c) Install a new O-ring [4610.9] into the bearing

cover [3260] utilizing a small amount of grease to hold it in place.

d) Place the bearing cover [3260] onto the shaft

[2100.2] slide it towards the bearing housing [3200] and then secure it with the three (3) fasteners [6570.3].

e) Reinstall the following items onto the bearing

housing; oil level tag (Figure 6-25 and 6-26) and combination Trico oiler/site gage [3855], vent/breather [6569.2] and drain plug [6569.1].

f) Attach the outer magnet flange [0231] to the

outer magnet [0230] using socket head cap screws [6570.3].

g) Install the Flowserve impeller wrench and key

onto the input shaft of the pump. The wrench handle should be touching the workbench towards the right as you are facing the suction flange of the pump.

h) Screw the outer magnet flange assembly onto

the drive shaft.

i) Using gloves, raise the impeller wrench until it is

parallel with the work bench (but still facing towards the right as you face the suction flange of the pump), spin the outer magnet rapidly in a

clockwise direction to impact the impeller wrench on the work bench. After several sharp raps, the outer magnet assembly should be tight.

The threads are right hand.

j) Insert the flat head cap screw [6570.8] into the

center of the outer magnet flange and tighten. Again the threads are right hand tight.

k) The assembly of the power end is complete.

6.9.2 Power end assembly – Close Coupled

6.9.2.1 Group A and 1

a) Attach a new motor gasket [4590.2] and lantern

gasket [4590.1] to the motor flange [6540].

b) Mount the motor flange [6540] to the motor with

four (4) socket head cap screws [6570.4] see Figure 6-17.

c) Attach the outer magnet flange [0231] to the

outer magnet [0230] using socket head cap screws [6570.3].

d) Attach the hub [7200] to the outer magnet

assembly using the four (4) fasteners [6570.9] supplied with the hub, see Figure 6-28.

e) Place the key supplied with the motor in the

motor keyway and mount the outer magnet assembly onto the motor shaft. Engage the assembly onto the motor shaft till the face of the outer magnet flange [6540] contacts the end of the shaft. This ensures the proper axial location of the magnet poles.

f) Tighten the set screw in the hub to secure the

outer magnet assembly to the motor shaft.

6.9.2.2 Group B and 2

a) Attach a new motor gasket [4590] to the lantern

[1340].

b) Place the key supplied with the motor in the

motor keyway and mount the hub [7200] to the shaft. The end of the hub must be aligned with end of the shaft, see figure 6-41.

Figure 6-41

c) Tighten the set crews in the hub to secure it to

the motor shaft, figure 6-29.

flowserve.com

USER INSTRUCTIONS PolyChem M-SERIES ENGLISH 71569218 07-11

Page 50 of 60

Non metallic spacer

Casing [1100]

Pin [6810.2]

Thrust bushing [3041]

Non metallic spacer

Bushing [3300]

Bearing holder [3830]

Non metallic spacer

Key [6700.2]

Inner Magnet [818/220]

Shaft [2100.1]

Install two (2) 5/8-11UNC-2B studs (180° apart) into the hub to aid in installation of the outer magnet assembly. These two studs will be later removed.

d) Mount lantern [1340] to the motor with four (4)

hex head cap screws [6570.4].

e) Attach the outer magnet flange [0231] to the

outer magnet [0230] using socket head cap screws [6570.3].

f) Place the outer magnet assembly into the lantern

[1340] and use the installation studs as a guide to support the assembly until two (2) of the fasteners [6570.9] and corresponding lock washers can be installed. See Figure 6-29

g) Remove the installation studs and replace them

with the remaining two (2) fasteners [6570.9] and lock washers.

6.9.3 Wet end assembly

The first part of these instructions pertain to both the Group A and 1 plus Group B and 2 pump models.

In the assembly of the wet end it will be necessary to utilize an arbor press to aid in the assembly of the silicon carbide bearings into their mating components. When utilizing an arbor press a nonmetallic spacer must be placed between the ram of the press and corresponding silicon carbide bearing. The spacer must be flat and the entire surface area of the component being pressed must be covered.

a) The casing [1100] should placed on its suction

flange. The surface on which the suction flange is placed must be flat and care must be taken to protect the casing liner, see Figure 6-42.

Figure 6-42

c) Press the inboard bushing [3300] into the

bearing holder [3830], see figure 6-43.

On Group A and 1 pumps take care to align the flat on the bushing with the flat on the bearing holder. On Group B and 2 pumps visually align the key slots in the bushing with the as molded keys in the bearing holder.

Figure 6-43

d) Install key(s) [6700.2] into the key slot(s) located

on the silicon carbide shaft [2100.1].

e) Press the shaft [2100.1] into the inner magnet

[0220], see Figure 6-44.

Figure 6-44

b) Install pin [6810.2] into casing [1100] followed by

the installation of the thrust bushing [3041] taking care to align the slot with the pin.

6.9.3.1 Group A and 1

a) Place the lantern [1340] on a work bench with

the flange incorporating the lifting lug towards the work bench, see Figure 6-45.

b) Install the containment shell [3500] into the

lantern followed by the inner magnet/shaft assembly and then the bearing holder/bushing.

flowserve.com

USER INSTRUCTIONS PolyChem M-SERIES ENGLISH 71569218 07-11

Page 51 of 60

Bearing holder [3830]

Bushing [545.1/212]

Lantern [1340]

Containment shell [817/224]

Shaft [2100.1]

Lifting Lug

O.B. Bushing

Impeller [2200]

Non metallic spacer

Figure 6-45

c) Rotate the bearing holder [3830] so that holes

are located at the 3, 6, 9, and 12 o’clock positions with the flat being forced to be at the 12

o’clock position, which is in line with the lifting

lug. d) See section 6.6 for impeller assembly. e) Install the casing [1100] onto the lantern/bearing

holder with studs and nuts [6572 and 6580].

6.9.3.2 Group B and 2

a) Install gasket [4610.1] into groove on bearing

holder [3830] b) To continue the assembly process the bearing

holder should be support horizontally. A tapped

hole is located at the 12 o’clock position on the

holder [3830] so that an eyebolt can be engaged.

An appropriate lifting device should be attached

to the eyebolt, placing it in light tension to

support the wet end. See Figure 6-45.

Figure 6-45

d) Place the containment shell [3500] over the inner

magnet followed by retaining ring [2530].

The retainer ring [2530] is manufactured from carbon steel and may attach to the containment shell [3500] upon installation due to the presence of magnets in the inner magnet assembly.

e) Install and tighten the twelve (12) retainer

ring/containment shell cap screws [6570.7]. f) See section 6.6 for impeller assembly. g) Install the casing [1100] onto the bearing holder

with studs and nuts [6572 and 6580].

6.9.4 Mounting the wet end to the power end

Do not attempt to assemble the drive end to the wet end without using the jackbolts. The magnetic force can cause severe personal injury.

Be sure to engage the inner and outer magnet assemblies evenly. Cocking of the two can result in serious damage to the magnets and/or containment shell. It is best to alternatively give each bolt a turn to ensure proper and even separation.

Thread the entire length of the square head jackbolts [6575] through the bearing housing or lantern.

a) Slide the wet end towards the power end until

the jackbolts [6575] engage in the recess provided for it.

b) Turn the jackbolts [6575] counterclockwise to

allow the wet end to slowly engage into the power end. Alternate from one bolt to the other to prevent the unit from cocking.

c) Once the mating surfaces are in contact, install

fasteners [6570.6] for Group A and 1 and [6570.8] for Group B and 2.

c) Install the inner magnet/shaft assembly through

the bushing [3300] that is located in the bearing holder [3830].

flowserve.com

USER INSTRUCTIONS PolyChem M-SERIES ENGLISH 71569218 07-11

Page 52 of 60

Pump not reaching design flow rate



Pump not reaching design head (TDH)



No discharge or flow with pump running



Pump operates for short period, then loses prime



Excessive noise from wet end



Excessive noise from power end



Pump exhibits increased or higher than anticipated power consumption



Pump exhibits decreased or lower than anticipated power consumption



PROBABLE CAUSES

POSSIBLE REMEDIES



 



Insufficient NPSH. (Noise may not be present.)

Recalculate NPSH available. It must be greater than the NPSH required by pump at desired flow. If not, redesign suction piping, holding number of elbows and number of planes to a minimum to avoid adverse flow rotation as it approaches the impeller.

  



System head greater than anticipated.

Reduce system head by increasing pipe size and/or reducing number of fittings. Increase impeller diameter. (nb: Increasing impeller diameter may require use of a larger motor.)



 

Entrained air. Air leak from atmosphere on suction side.

1. Check suction line gaskets and threads for tightness.

2. If vortex formation is observed in suction tank, install vortex breaker.

3. Check for minimum submergence



Entrained gas from process.

Process generated gases may require larger pumps.



Speed too low.

Check motor speed against design speed.

  

Direction of rotation wrong.

After confirming wrong rotation, reverse any two of three leads on a three phase motor. The pump should be disassembled and inspected before it is restarted.



Impeller too small.

Replace with proper diameter impeller. (NOTE: Increasing impeller diameter may require use of a larger motor.)

  

Plugged impeller, suction line or casing which may be due to a product or large solids.

1. Reduce length of fiber when possible.

2. Reduce solids in the process fluid when possible.

3. Consider larger pump.



Wet end parts (casing, bearing holder, impeller, containment shell) worn, corroded or missing.

Replace part or parts.



Not properly primed.

Repeat priming operation, recheck instructions. If pump has run dry, disassemble and inspect the pump before operation.

 

Impeller rubbing.

Check wet end bearings for wear.



Damaged bushings pump shaft, thrust bearings or impeller.

Replace damaged parts.



Abnormal fluid rotation due to complex suction piping.

Redesign suction piping, holding the number of elbows and planes to a minimum to avoid adverse fluid rotation as it approaches the impeller.

 



Magnetic coupling decoupled due to excessive temperature or excessive horsepower requirements.

1. Check process temperature to verify it’s within operating limits of pump.

2. Check horsepower required by the process to verify it is within the operating limits of the coupling size.

3. Replacement of the magnet assemblies may be necessary if the magnets overheated and were permanently damaged. A static torque test of the magnetic coupling may be necessary. Contact your Flowserve representative for details.

 

Inner magnet rubbing shell.

Check for damaged or worn pump shaft and bushings.

7 FAULTS; CAUSES AND REMEDIES

The following is a guide to troubleshooting problems with Flowserve PolyChem pumps. Common problems are analyzed and solutions offered. Obviously, it is impossible to cover every possible scenario. If a problem exists that is not covered by one of the examples, then refer to one of the books listed in section 10 Additional sources of information or contact a Flowserve sales engineer or distributor/representative for assistance.

FAULT SYMPTOM

flowserve.com

USER INSTRUCTIONS PolyChem M-SERIES ENGLISH 71569218 07-11

Page 53 of 60

Pump not reaching design flow rate



Pump not reaching design head (TDH)



No discharge or flow with pump running



Pump operates for short period, then loses prime



Excessive noise from wet end



Excessive noise from power end



Pump exhibits increased or higher than anticipated power consumption



Pump exhibits decreased or lower than anticipated power consumption



PROBABLE CAUSES

POSSIBLE REMEDIES



Bearing contamination appearing on the raceways as scoring, pitting, scratching or rusting caused by adverse environment and entrance of abrasive contaminants from atmosphere.

1. Work with clean tools in clean surroundings.

2. Remove all outside dirt from housing before exposing bearings.

3. Handle with clean dry hands.

4. Treat a used bearing as carefully as a new one.

5. Use clean solvent and flushing oil.

6. Protect disassembled bearing from dirt and moisture.

7. Keep bearings wrapped in paper or clean cloth while not in use.

8. Clean inside of housing before replacing bearings.

9. Check oil seals and replace as required.

10. Check all plugs and tapped openings to make sure that they are tight.



Brinelling of bearing identified by indentation on the ball races, usually caused by incorrectly applied forces in assembling the bearing or by shock loading such as hitting the bearing or drive shaft with a hammer.

When mounting the bearing on the drive shaft use a proper size ring and apply the pressure against the inner ring only. Be sure when mounting a bearing to apply the mounting pressure slowly and evenly.



False brinelling of bearing identified again by either axial or circumferential indentations usually caused by vibration of the balls between the races in a stationary bearing.

1. Correct the source of vibration.

2. Where bearings are oil lubricated and employed in units that may be out of service for extended periods, the drive shaft should be turned over periodically to relubricate all bearing surfaces at intervals of one to three months.



Thrust overload on bearing identified by flaking ball path on one side of the outer race or in the case of maximum capacity bearings, may appear as a spalling of the races in the vicinity of the loading slot. (Please note: maximum capacity bearings are not recommended) These thrust failures are caused by improper mounting of the bearing or excessive thrust loads.

Follow correct mounting procedures for bearings.



Misalignment identified by fracture of ball retainer or a wide ball path on the inner race and a narrower cocked ball path on the outer race. Misalignment is caused by poor mounting practices or defective drive shaft. For example, bearing not square with the centerline or possibly a bent shaft due to improper handling.

Handle parts carefully and follow recommended mounting procedures. Check all parts for proper fit and alignment.



Bearing damaged by electric arcing identified as electro- etching of both inner and outer ring as a pitting or cratering. Electrical arcing is caused by a static electrical charge emanating from belt drives, electrical leakage or short circuiting.

1. Where current shunting through the bearing cannot be corrected, a shunt in the form of a slip ring assembly should be incorporated.

2. Check all wiring, insulation and rotor windings to be sure that they are sound and all connections are properly made.

3. Where pumps are belt driven, consider the elimination of static charges by proper grounding or consider belt material that is less generative.

flowserve.com

USER INSTRUCTIONS PolyChem M-SERIES ENGLISH 71569218 07-11

Page 54 of 60

Pump not reaching design flow rate



Pump not reaching design head (TDH)



No discharge or flow with pump running



Pump operates for short period, then loses prime



Excessive noise from wet end



Excessive noise from power end



Pump exhibits increased or higher than anticipated power consumption



Pump exhibits decreased or lower than anticipated power consumption



PROBABLE CAUSES

POSSIBLE REMEDIES



Bearing damage due to improper lubrication, identified by one or more of the following:

1. Abnormal bearing temperature rise.

2. A stiff cracked grease appearance.

3. A brown or bluish discoloration of the bearing races.

1. Be sure the lubricant is clean.

2. Be sure proper amount of lubricant is used. The constant level oiler supplied with Flowserve pumps will maintain the proper oil level if it is installed and operating properly. In the case of greased lubricated bearings, be sure that there is space adjacent to the bearing into which it can rid itself of excessive lubricant, otherwise the bearing may overheat and fail prematurely.

3. Be sure the proper grade of lubricant is used.



Outer magnet assembly rubbing bearing housing or containment shell.

1. Check integrity of ball bearings.

2. Make sure drive shaft is not bent.

3. Make sure outer magnet assembly has not come unscrewed due to incorrect motor rotation.

flowserve.com

USER INSTRUCTIONS PolyChem M-SERIES ENGLISH 71569218 07-11

Page 55 of 60

8 PARTS LIST AND DRAWINGS

8.1 PolyChem Group A and 1 Close Coupled

8.2 PolyChem Group A and 1 Long Coupled

Drawing taken from CY61190-1

Drawing taken from CY61191-0

flowserve.com

USER INSTRUCTIONS PolyChem M-SERIES ENGLISH 71569218 07-11

Page 56 of 60

8.3 PolyChem Group B and 2 Close Coupled

8.4 PolyChem Group B and 2 Long Coupled

Drawing taken from CY61192-1

Drawing taken from CY61193A-0

flowserve.com

USER INSTRUCTIONS PolyChem M-SERIES ENGLISH 71569218 07-11

Page 57 of 60

Item Numbers

Description

0220

Inner Magnet Assembly

0230

Outer Magnet Assembly

0231

Flange-Outer Magnet

1100

Casing

1340

Lantern

2100.1

Power End Shaft

2100.2

Pump Shaft

2200

Impeller

2905

Wave Spring Washer

3011.1

Power End Bearing-Inboard

3011.2

Power End Bearing-Outboard

3041

Thust Bearing-Casing

3043

Thrust Bearing-Impeller

3134

Bearing Housing Foot

3200

Bearing Housing

3260

Bearing Housing End Cover

3300

Bushing

3500

Containment Shell

3830

Bearing Holder

3853

Nipple *

3856

Constant level oiler Oiler *

3858

Oil Sight Glass

3891

Tag-Oil Level *

4310.1

Oil Seal-Inboard

4310.2

Oil Seal-Inboard

4590.1

Gasket-Lantern

4590.2

Gasket-Motor Flange/Motor

4610

0-Ring Bearing End Cover

6540

Motor Flange

6569.1

Plug-Brg Housing Drain

6569.2

Brg Housing Vent

6570.1

Screw-Bearing Housing Foot

6570.2

Screw-End Cover/Brg Housing

6570.3

Screw-Outer Magnet Flange

6570.4

Screw-Motor Flange/Motor

6570.5

Screw-Reverse Rotation

6570.6

Screw-Lantern/Bearing Housing

5670.9

Screw-Hub

6572

Casing Stud

6575

Jack screw *

6580

Casing Stud Nut

6700.1

Coupling Key

6700.2

Key-Pump Shaft

6810.1

Outer Magnet Rub Pins

6810.2

Anti Rotation Pin-Casing

6814

Set Screw-Motor Hub

Item Numbers

Description

0220

Inner Magnet Assembly

0230

Outer Magnet Assembly

0231

Flange-Outer Magnet

1100

Casing

1340

Lantern

2100.1

Power End Shaft

2100.2

Pump Shaft

2200

Impeller

2530

Retaining Ring-Shell

2905

Wave Spring Washer

3011.1

Power End Bearing-Inboard

3011.2

Power End Bearing-Outboard

3041

Thust Bearing-Casing

3043

Thrust Bearing-Impeller

3126

Shim

3134

Bearing Housing Foot

3200

Bearing Housing

3260

Bearing Housing End Cover

3300

Bushing

3500

Containment Shell

3830

Bearing Holder

3853

Grease nipple *

3856

Constant level oiler *

3858

Oil sight glass

3891

Tag-Oil Level *

4310.1

Oil Seal-Inboard

4310.2

Oil Seal-Inboard

4590

Gasket-Motor Flange/Motor

4610.1

0-Ring Bearing End Cover

4610.2

O-Ring Bearing Holder

6569.1

Plug-Brg Housing Drain

6569.2

Brg Housing Vent

6570.1

Screw-Bearing Housing Foot

6570.2

Screw-End Cover/Brg Housing

6570.3

Screw-Outer Magnet Flange

6570.4

Screw-Lantern/Motor

6570.5

Screw-Reverse Rotation

6570.7

Screw-Retaining Ring

6570.8

Screw-Lantern / Bearing holder

6570.9

Screw-Hub

6572

Casing Stud

6575

Jack screw *

6579.4

Screw-Motor Flange/Motor

6580

Casing Stud Nut

6700.1

Coupling Key

6700.2

Key-Pump Shaft

6810.1

Outer Magnet Rub Pins

6810.2

Anti Rotation Pin-Casing

6814

Set Screw-Motor Hub

7200

Motor Hub

8.5 PolyChem Group A and 1

8.6 PolyChem Group B and 2

* Not shown in the drawings

flowserve.com

USER INSTRUCTIONS PolyChem M-SERIES ENGLISH 71569218 07-11

Page 58 of 60

9 CERTIFICATION

Certificates determined from the contract requirements are provided with these instructions where applicable. Examples are certificates for CE marking and ATEX marking etc. If required, copies of other certificates sent separately to the Purchaser should be obtained from Purchaser for retention with these User Instructions.

10 OTHER RELEVANT

DOCUMENTATION AND MANUALS

10.1 Supplementary User Instructions

Supplementary instructions such as for a driver, instrumentation, controller, seals, sealant systems etc are provided as separate documents in their original format. If further copies of these are required they should be obtained from the supplier for retention with these User Instructions.

10.2 Change notes

If any changes, agreed with Flowserve Pump Division, are made to the product after it is supplied, a record of the details should be maintained with these User Instructions.

10.3 Additional sources of information

The following are excellent sources for additional information on Flowserve PolyChem S-series pumps, and centrifugal pumps in general.

Pump Engineering Manual R.E. Syska, J.R. Birk, Flowserve Corporation, Dayton, Ohio, 1980.

Specification for Horizontal End Suction Centrifugal Pumps for Chemical Process, ASME B73.1M

The American Society of Mechanical Engineers, New York, NY.

End-suction centrifugal pumps (rating 16 bar) – Designation, nominal duty point and dimensions, ISO 2858

International Organization for Standardization

American National Standard for Centrifugal Pumps for Nomenclature, Definitions, Design and Application (ANSI/HI 1.1-1.3)

Hydraulic Institute, 9 Sylvan Way, Parsippany, New Jersey 07054-3802.

Technical specification for centrifugal pumps – Class II, ISO 5199

International Organization for Standardization

American National Standard for Centrifugal Pumps for Installation, Operation, and Maintenance (ANSI/HI 1.4)

Hydraulic Institute, 9 Sylvan Way, Parsippany, New Jersey 07054-3802.

Flowserve Durco Pump Parts Catalog. Flowserve PolyChem Sales Bulletin. RESP73H Application of ASME B73.1M-1991,

Specification for Horizontal End Suction Centrifugal Pumps for Chemical Process, Process Industries Practices

Construction Industry Institute, The University of Texas at Austin, 3208 Red River Street, Suite 300, Austin, Texas 78705.

Pump Handbook 2nd edition, Igor J. Karassik et al, McGraw-Hill, Inc., New York, NY, 1986.

Centrifugal Pump Sourcebook John W. Dufour and William E. Nelson, McGraw-Hill, Inc., New York, NY, 1993.

Pumping Manual, 9th edition T.C. Dickenson, Elsevier Advanced Technology, Kidlington, United Kingdom, 1995.

flowserve.com

Page 59 of 60

Notes:

USER INSTRUCTIONS PolyChem M-SERIES ENGLISH 71569218 07-11

flowserve.com

USER INSTRUCTIONS PolyChem M-SERIES ENGLISH 71569218 07-11

Page 60 of 60

Your Flowserve factory contact:

Flowserve Pump Division 3900 Cook Boulevard Chesapeake, VA 23323-1626 USA Telephone +1 757 485 8000 Fax +1 757 485 8149

Flowserve Pumps Flowserve GB Limited Lowfield Works, Balderton Newark, Notts NG24 3BU United Kingdom

Telephone (24 hours): +44 1636 494 600 Sales & Admin Fax: +44 1636 705 991 Repair & Service Fax: +44 1636 494 833

Email: newarksales@flowserve.com

Your local Flowserve representative:

To find your local Flowserve representative please use the Sales Support Locator System found at www.flowserve.com

FLOWSERVE REGIONAL SALES OFFICES:

USA and Canada

Flowserve Corporation 5215 North O’Connor Blvd., Suite 2300 Irving, Texas 75039-5421, USA Telephone +1 972 443 6500 Fax +1 972 443 6800

Europe, Middle East, Africa

Flowserve FSG – Italy Worthing S.P.A. Via Rossini 90/92 20033 Desio (Milan), Italy Telephone +39 0362 6121 Fax +39 0362 628 882

Latin America and Caribbean

Flowserve Corporation 6840 Wynnwood Lane Houston, Texas 77008, USA Telephone +1 713 803 4434 Fax +1 713 803 4497

Asia Pacific

Flowserve Pte. Ltd 10 Tuas Loop Singapore 637345 Telephone +65 6771 0600 Fax +65 6862 2329

flowserve.com

Flowserve M-series User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
