D811512 ver. 03 21-05-07
I QUADRO COMANDO
GB CONTROL PANEL
F CENTRALE DE COMMANDE
D |
STEUERUNG |
8 |
027908 |
297235 |
|
|
|
E CUADRO DE MANDOS
P QUADRO DE COMANDO
LEO MV D
ISTRUZIONI D’USO E DI INSTALLAZIONE |
INSTALLATION AND USER’S MANUAL |
INSTRUCTIONS D’UTILISATION ET D’INSTALLATION |
INSTALLATIONS-UND GEBRAUCHSANLEITUNG |
INSTRUCCIONES DE USO Y DE INSTALACION |
INSTRUÇÕES DE USO E DE INSTALAÇÃO |
Via Lago di Vico, 44 36015 Schio (VI) Tel.naz. 0445 696511 Tel.int. +39 0445 696533 Fax 0445 696522 Internet: www.bft.it E-mail: sales@bft.it
D811512_03
- LEO MV D - Ver. 03
D811512_03
MANUALE D’USO |
ITALIANO |
Nel ringraziarVi per la preferenza accordata a questo prodotto, la ditta è certa che da esso otterrete le prestazioni necessarie al Vostro uso.
Leggete attentamente l’opuscolo ”Libretto istruzioni” che lo accompagna in quanto esso fornisce importanti indicazioni riguardanti la sicurezza, l’installazione, l’uso e la manutenzione. Questo prodotto risponde alle norme riconosciute della tecnica e delle disposizioni relative alla sicurezza. Confermiamo che esso è conforme alle seguenti direttive europee: 89/336/CEE, 73/23/CEE, 98/37/CEE e loro modifiche successive.
1) GENERALITÁ
Il quadro comandi LEO MV D viene fornito dal costruttore con settaggio standard. Qualsiasi variazione, deve essere impostata mediante il programmatore a display incorporato o mediante programmatore palmare universale. La Centralina supporta completamente il protocollo EELINK compresa l’autoalimentazione del programmatore da centralina.
è disponibile in due versioni: per installazione esterna, all’interno della scatola SD, o montata e precablata all’interno dell’attuatore.
Le caratteristiche principali sono:
-Rallentamento della velocità all’accostamento.
-Regolazione elettronica della coppia.
-Frenatura elettrodinamica regolabile.
-Ingressi di fine-corsa chiusura / apertura
-Ingressi separati per le sicurezze.
-Ingresso orologio.
-Ingressso collegamento protocollo seriale (opzionale).
-Ricevitore radio incorporato
2) FUNZIONI
PER L’INSTALLATORE: compilare la tabella con in parametri impostati al fine di facilitare future modifiche e manutenzioni.
Tra parentesi quadre [ ] sono indicati i valori preimpostati.
Menu parametri |
|
_____ |
Tempo Chiusura Automatica |
[10s] |
|
Spazio rallentamento |
[5] |
_____ Impostabile solo con BARRIERA=1 |
Tempo allarme |
[30s] |
_____ |
Zona |
[0] |
_____ |
Coppia rallentamento |
[99%] |
_____ Impostabile solo con BARRIERA=1 |
Coppia apertura |
[70%] |
_____ Impostabile solo con BARRIERA=1 |
Coppia chiusura |
[70%] |
_____ Impostabile solo con BARRIERA=1 |
Freno |
[52%] |
_____ |
Encoder |
[1] |
_____ Impostabile solo con BARRIERA=0 |
Tipo di barriera |
[1] |
_____ |
MENU Logiche |
|
_____ |
TCA |
[ON] |
|
3 Passi |
[ON] |
_____ |
Blocca Impulsi apertura |
[ON] |
_____ |
Blocca Impulsi TCA |
[OFF] |
_____ |
Pre allarme |
[OFF] |
_____ |
Fotocellule in apertura |
[ON] |
_____ |
Chiusura rapida |
[OFF] |
_____ |
Allarme SCA |
[ON] |
_____ |
Master/Slave |
[OFF] |
_____ |
Test fotocellule (PHOT) |
[OFF] |
_____ |
Test costa sensibile (BAR) |
[OFF] |
_____ |
Codice fisso |
[OFF] |
_____ |
Programmazione radiocomandi |
[ON] |
_____ |
3) DEMOLIZIONE
Attenzione: Avvalersi esclusivamente di personale qualificato.
L’eliminazione dei materiali va fatta rispettando le norme vigenti. Nel caso di demolizione, non esistono particolari pericoli o rischi derivanti dal prodotto stesso. È opportuno, in caso di recupero dei materiali, che vengano separati per tipologia (parti elettriche - rame - alluminio - plastica - ecc.).
4) SMANTELLAMENTO
Attenzione: Avvalersi esclusivamente di personale qualificato.
Nel caso la centralina venga smontata per essere poi rimontata in altro sito bisogna:
•Togliere l’alimentazione e scollegare tutto l’impianto elettrico.
•Nel caso alcuni componenti non possano essere rimossi o risultino danneggiati, provvedere alla loro sostituzione.
AVVERTENZE
Il buon funzionamento dell’operatore è garantito solo se vengono rispettati i dati riportatiinquestomanuale.Ladittanonrispondedeidannicausatidall’inosservanza delle norme di installazione e delle indicazioni riportate in questo manuale.
Le descrizioni e le illustrazioni del presente manuale non sono impegnative. Lasciando inalterate le caratteristiche essenziali del prodotto, la Ditta si riserva di apportare in qualunque momento le modifiche che essa ritiene convenienti per migliorare tecnicamente, costruttivamente e commercialmente il prodotto, senza impegnarsi ad aggiornare la presente pubblicazione.
USER’S MANUAL |
ENGLISH |
Thank you for buying this product, our company is sure that you will be more than satisfied with the product’s performance. The product is supplied with a “Warnings” leaflet and an “Instruction booklet”. These should both be read carefully as they provide important information about safety, installation, operation and maintenance. This product complies with the recognised technical standards and safety regulations. We declare that this product is in conformity with the following European Directives: 89/336/EEC and 73/23/EEC, 98/37/EEC (and subsequent amendments).
1) GENERAL OUTLINE
The LEO MV D control panel is supplied by the manufacturer with standard setting. Any alteration must be set by means of the incorporated display programmer or by means of universal palmtop programmer. The Control unit completely supports the EELINK protocol, including the programmer self-supply from the control unit. It is available in two versions: one for external installation, inside the SD box, the other fitted and prewired inside the controller.
Its main characteristics are:
-Slow down of end-of-run speed.
-Electronic torque setting
-Adjustable electrodynamic braking
-Closing / opening limit-switch inputs
-Separate inputs for safety devices
-Clock input
-Serial protocol connection input (Option).
-Incorporated radio receiver
2) FUNCTIONS
FOR THE INSTALLER: Fill in the table with the parameters set, in order to facilitate future modifications and maintenance operations.
The preset values are indicated between square brackets [ ].
parametER MENU |
|
_____ |
Automatic Closing Time (TCA) |
[10s] |
|
Slow-down Distance |
[5] |
_____ Can be set with “Barrier”=1 only. |
Alarm time |
[30s] |
_____ |
Zone |
[0] |
_____ |
Slow-down torque |
[99%] |
_____ Can be set with “Barrier”=1 only. |
Opening torque |
[70%] |
_____ Can be set with “Barrier”=1 only. |
Closing torque |
[70%] |
_____ Can be set with “Barrier”=1 only. |
Brake |
[52%] |
_____ |
Encoder |
[1] |
_____ Can be set with “Barrier”=0 only. |
Type of barrier |
[1] |
_____ |
Logic MENU |
|
_____ |
TCA |
[ON] |
|
3 Steps |
[ON] |
_____ |
Impulse locking |
[ON] |
_____ |
TCA impulse locking |
[OFF] |
_____ |
Pre-alarm |
[OFF] |
_____ |
Photocells on opening |
[ON] |
_____ |
Rapid closing |
[OFF] |
_____ |
SCA alarm |
[ON] |
_____ |
Master/slave |
[OFF] |
_____ |
Photocell test |
[OFF] |
_____ |
Electric edge test |
[OFF] |
_____ |
Fixed code |
[OFF] |
_____ |
Radio transmitter programming |
[ON] |
_____ |
3) SCRAPPING
Warning: This operation should only be carried out by qualified personnel. Materials must be disposed of in conformity with the current regulations. In case of scrapping, the automation devices do not entail any particular risks or danger. In case of materials to be recycled, these should be sorted out by type (electrical components, copper, aluminium, plastic etc.).
4) DISMANTLING
Warning: This operation should only be carried out by qualified personnel.
When the control unit is disassembled to be reassembled on another site, proceed as follows:
•Disconnect the power supply and the entire electrical installation.
•In the case where some of the components cannot be removed or are damaged, they must be replaced.
WARNINGS
Correct controller operation is only ensured when the data contained in the present manual are observed.The company is not to be held responsible for any damage resulting from failure to observe the installation standards and the instructions contained in the present manual.
The descriptions and illustrations contained in the present manual are not binding. The Company reserves the right to make any alterations deemed appropriate for the technical, manufacturing and commercial improvement of the product, while leaving the essential product features unchanged, at any time and without undertaking to update the present publication.
LEO MV D - Ver. 03 -
D811512_03
INSTALLATION MANUAL |
ENGLISH |
||
Thank you for buying this product, our company is sure that you will be more |
- Slow down of end-of-run speed. |
|
|
than satisfied with the product’s performance. The product is supplied with |
- |
Electronic torque setting |
|
a “Warnings” leaflet and an “Instruction booklet”. These should both be |
- |
Adjustable electrodynamic braking |
|
read carefully as they provide important information about safety, installa- |
- Closing / opening limit-switch inputs |
|
|
tion, operation and maintenance. This product complies with the recognised |
- Separate inputs for safety devices |
|
|
technical standards and safety regulations. We declare that this product |
- |
Clock input |
|
is in conformity with the following European Directives: 89/336/EEC and |
- Serial protocol connection input (optional) |
|
|
73/23/EEC, 98/37/EEC (and subsequent amendments). |
- |
Incorporated radio receiver |
|
1) GENERAL SAFETY
WARNING! An incorrect installation or improper use of the product can cause damage to persons, animals or things.
•The “Warnings” leaflet and “Instruction booklet” supplied with this product should be read carefully as they provide important information about safety, installation, use and maintenance.
•Scrap packing materials (plastic, cardboard, polystyrene etc) according to the provisions set out by current standards. Keep nylon or polystyrene bags out of children’s reach.
•Keep the instructions together with the technical brochure for future reference.
•This product was exclusively designed and manufactured for the use specified in the present documentation. Any other use not specified in this documentation could damage the product and be dangerous.
•The Company declines all responsibility for any consequences resulting from improper use of the product, or use which is different from that expected and specified in the present documentation.
•Do not install the product in explosive atmosphere.
•The construction components of this product must comply with the following European Directives: 89/336/CEE, 73/23/EEC, 98/37/EEC and subsequent amendments. As for all non-EEC countries, the abovementioned standards as well as the current national standards should be respected in order to achieve a good safety level.
•The Company declines all responsibility for any consequences resulting from failure to observe Good Technical Practice when constructing closing structures (door, gates etc.), as well as from any deformation which might occur during use.
•The installation must comply with the provisions set out by the following EuropeanDirectives:89/336/CEE,73/23/EEC,98/37/EECandsubsequent amendments.
•Disconnect the electrical power supply before carrying out any work on the installation. Also disconnect any buffer batteries, if fitted.
•Fit an omnipolar or magnetothermal switch on the mains power supply, having a contact opening distance equal to or greater than 3,5 mm.
•Check that a differential switch with a 0.03A threshold is fitted just before the power supply mains.
•Check that earthing is carried out correctly: connect all metal parts for closure (doors, gates etc.) and all system components provided with an earth terminal.
•Fit all the safety devices (photocells, electric edges etc.) which are needed to protect the area from any danger caused by squashing, conveying and shearing.
•Position at least one luminous signal indication device (blinker) where it can be easily seen, and fix a Warning sign to the structure.
•The Company declines all responsibility with respect to the automation safety and correct operation when other manufacturers’ components are used.
•Only use original parts for any maintenance or repair operation.
•Do not modify the automation components, unless explicitly authorised by the company.
•Instruct the product user about the control systems provided and the manual opening operation in case of emergency.
•Do not allow persons or children to remain in the automation operation area.
•Keep radio control or other control devices out of children’s reach, in order to avoid unintentional automation activation.
•The user must avoid any attempt to carry out work or repair on the automation system, and always request the assistance of qualified personnel.
•Anything which is not expressly provided for in the present instructions, is not allowed.
•Installation must be carried out using the safety devices and controls prescribed by the EN 12978 Standard.
2) GENERAL OUTLINE
The LEO MV D control panel is supplied by the manufacturer with standard setting. Any alteration must be set by means of the incorporated display programmer or by means of universal palmtop programmer. The Control unit completely supports the EELINK protocol.
It is available in two versions: one for external installation, inside the SD box, the other fitted and pre-wired inside the controller.
Its main characteristics are:
The board is provided with a terminal board which can be pulled out for easier maintenance or replacement. The board is supplied with a series of pre-wired jumpers to facilitate the installer’s work.
The jumpers relate to the following terminals: 21-23, 21-24 and 21-30. If the above-mentioned terminals are in use, remove their respective jumpers.
3) TECHNICAL SPECIFICATIONS
Power supply: .................................................................. |
230V±10% 50Hz* |
|
Mains/low voltage insulation: ........................................ |
> 2MOhm 500V |
|
|
||
Dielectric strength: ........................ |
mains/low voltage 3750V~ for 1 minute |
|
Motor output current: ..................................................................... |
1.5Amax |
|
Maximum motor power:...................................................................... |
750W |
|
Supply to accessories: ...................................... |
24V~ (1A max absorption) |
|
Gate-open warning light: ...................................................... |
24V~ 3W max |
|
Blinker: ................................................................................ |
230V 40W max |
|
Dimensions: .............................................................................. |
see figure 1 |
|
Fuses: ....................................................................................... |
see figure 2 |
|
(* other voltages available on request) |
4) TERMINAL BOARD CONNECTIONS (Fig.3)
WARNING – During the wiring and installation operations, refer to the current standards as well as principles of good technical practice.
The cables must be tied by additional fastening next to the terminals, by means of clips for example.
All the operator wiring operations must be carried out by qualified personnel.
JP1 |
|
|
|
|
|
|
|
|
|
1 |
|
|
|
|
|
|
|
|
GND terminal |
2-3 |
|
Single-phase mains supply 230V±10% 50Hz (2=N) (3=L) |
|||||||
JP2 |
|
|
|
|
|
|
|
|
|
4-5 |
|
Blinker connection (mains voltage) 40W Max. |
|||||||
6-7-8-9 |
|
Motor connection: |
|||||||
|
6 |
|
|
|
|
operation 1 + capacitor |
|||
|
7 |
|
|
|
|
common (blue) |
|||
|
8 |
|
|
|
|
operation 2 |
|||
|
9 |
|
|
|
|
capacitor |
|||
JP3 |
|
|
|
|
|
|
|
|
|
10-11 |
|
Output 24V~ 1A max – power supply for photocells or other |
|||||||
|
devices. |
||||||||
12-13 |
|
Gate-open warning light output (24V 3W max) |
|||||||
JP4 |
|
Barrier status output |
|||||||
20-18 |
|
Closed Contact with barrier raised |
|||||||
20-19 |
|
Closed Contact with barrier lowered |
|||||||
Contact switching for barrier status control. |
|||||||||
To be used in Parky systems (see paragraph 13) |
|||||||||
JP5 |
|
Encoder connection |
|||||||
|
WARNING! The maximum length of the connection cable of |
||||||||
|
the encoder should not exceed 3.00 mt. |
||||||||
JP8 |
|
|
|
|
|
|
|
|
|
21-22 |
|
Open-Close button (N.O. Start), key selector. |
|||||||
21-23 |
|
Block button (N.C. Stop). If not used, leave jumped. |
|||||||
21-24 |
|
Photocell input (N.C.). If not used, leave jumped. |
|||||||
21-25 |
|
Opening limit switch connection (N.C. SWO). If not used, leave |
|||||||
|
jumped. |
||||||||
21-26 |
|
Closing limit switch connection (N.C. SWC). If not used, leave |
|||||||
|
jumped. |
||||||||
21-27 |
|
Not used |
|||||||
21-28 |
|
Open-Button connection (N.O. Open) |
|||||||
21-29 |
|
Close-Button connection (N.O. Close) |
|||||||
21-30 |
|
Rubber edge connection (N.C.). If not used, leave jumped. |
|||||||
21-31 |
Connection of clock input (N.O.). If the contact connected is |
||||||||
|
open, the barrier closes and gets ready for normal operation. |
||||||||
|
If the contact is closed (N.C.), the barrier opens and remains |
open until contact opening.
JP9
32Photocell check input (PHOT FAULT) (see Fig. 3)
33Electric edge check input (EDGE FAULT) (see Fig. 3)
38-39 Antenna input for radio-receiver (38 signal - 39 braid). Cable RG58.
LEO MV D - Ver. 03 - 11
