Yamaha SC2 operation manual

SC2

Owner’s Manual

Mode d’emploi

Manual de instrucciones

Bedienungsanleitung

Manuale di istruzioni

Before using the instrument, be sure to read “PRECAUTIONS” on pages 7-8.

Avant d’utiliser cet instrument, lisez attentivement la section « PRÉCAUTIONS D’USAGE » aux pages 7-8. Antes de utilizar el instrumento, lea la sección “PRECAUCIONES”, en las páginas 7-8.

Achten Sie darauf, vor Einsatz dieses Instruments die „VORSICHTSMASSNAHMEN“ auf Seiten 7-8 durchzulesen. Prima di utilizzare lo strumento, assicurarsi di leggere la sezione “PRECAUZIONI”, alle pagine 7 - 8.

ˊ

EN

FR

ES

DE

IT

KO

For the instrument

SPECIAL MESSAGE SECTION

This product utilizes batteries or an external power supply (adapter). DO NOT connect this product to any power supply or adapter other than one described in the manual, on the name plate, or specifically recommended by Yamaha.

WARNING: Do not place this product in a position where anyone could walk on, trip over, or roll anything over power or connecting cords of any kind. The use of an extension cord is not recommended! If you must use an extension cord, the minimum wire size for a 25’ cord (or less) is 18 AWG. NOTE: The smaller the AWG number, the larger the current handling capacity. For longer extension cords, consult a local electrician.

This product should be used only with the components supplied or; a cart, rack, or stand that is recommended by Yamaha. If a cart, etc., is used, please observe all safety markings and instructions that accompany the accessory product.

SPECIFICATIONS SUBJECT TO CHANGE:

The information contained in this manual is believed to be correct at the time of printing. However, Yamaha reserves the right to change or modify any of the specifications without notice or obligation to update existing units.

This product, either alone or in combination with an amplifier and headphones or speaker/s, may be capable of producing sound levels that could cause permanent hearing loss. DO NOT operate for long periods of time at a high volume level or at a level that is uncomfortable. If you experience any hearing loss or ringing in the ears, you should consult an audiologist. IMPORTANT: The louder the sound, the shorter the time period before damage occurs.

Some Yamaha products may have benches and / or accessory mounting fixtures that are either supplied with the product or as optional accessories. Some of these items are designed to be dealer assembled or installed. Please make sure that benches are stable and any optional fixtures (where applicable) are well secured BEFORE using.

Benches supplied by Yamaha are designed for seating only. No other uses are recommended.

NOTICE:

Service charges incurred due to a lack of knowledge relating to how a function or effect works (when the unit is operating as designed) are not covered by the manufacturer’s warranty, and are therefore the owners responsibility. Please study this manual carefully and consult your dealer before requesting service.

ENVIRONMENTAL ISSUES:

Yamaha strives to produce products that are both user safe and environmentally friendly. We sincerely believe that our products and the production methods used to produce them, meet these goals. In keeping with both the letter and the spirit of the law, we want you to be aware of the following:

Battery Notice:

This product MAY contain a small non-rechargeable battery which (if applicable) is soldered in place. The average life span of this type of battery is approximately five years. When replacement becomes necessary, contact a qualified service representative to perform the replacement.

This product may also use “household” type batteries. Some of these may be rechargeable. Make sure that the battery being charged is a rechargeable type and that the charger is intended for the battery being charged.

When installing batteries, never mix old batteries with new ones, and never mix different types of batteries. Batteries MUST be installed correctly. Mismatches or incorrect installation may result in overheating and battery case rupture.

Warning:

Do not attempt to disassemble, or incinerate any battery. Keep all batteries away from children. Dispose of used batteries promptly and as regulated by the laws in your area. Note: Check with any retailer of household type batteries in your area for battery disposal information.

Disposal Notice:

Should this product become damaged beyond repair, or for some reason its useful life is considered to be at an end, please observe all local, state, and federal regulations that relate to the disposal of products that contain lead, batteries, plastics, etc. If your dealer is unable to assist you, please contact Yamaha directly.

NAME PLATE LOCATION:

The name plate is located on the bottom of the product. The model number, power requirements, etc., are located on this plate. The serial number is located behind the control unit. You should record the model number, serial number, and the date of purchase in the spaces provided below and retain this manual as a permanent record of your purchase.

Model

Serial No.

Purchase Date

92-BP (bottom_silent) PLEASE KEEP THIS MANUAL

2SC2 Owner’s Manual

For the instrument

COMPLIANCE INFORMATION STATEMENT(DECLARATION OF CONFORMITY PROCEDURE)

Responsible Party: Yamaha Corporation of America

Address: 6600 Orangethorpe Ave., Buena Park, Calif. 90620 Telephone: [phone]

Type of Equipment: Silent Piano

Model Name: B1SC2, B2SC2, B3SC2, GB1KSC2

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: 1)this device may not cause harmful interference, and

2)this device must accept any interference received including interference that may cause undesired operation. See user manual instructions if interference to radio reception is suspected.

* This applies only to products distributed by YAMAHA CORPORATION OF AMERICA.

(FCC DoC)

For the AC adaptor and the instrument

	FCC INFORMATION (U.S.A.)
	1. IMPORTANT NOTICE: DO NOT MODIFY THIS UNIT!	tions does not guarantee that interference will not occur in all
	This product, when installed as indicated in the instructions	installations. If this product is found to be the source of inter-
	contained in this manual, meets FCC requirements. Modifica-	ference, which can be determined by turning the unit “OFF”
	tions not expressly approved by Yamaha may void your	and “ON”, please try to eliminate the problem by using one of
	authority, granted by the FCC, to use the product.	the following measures:
	2. IMPORTANT: When connecting this product to accessories	Relocate either this product or the device that is being
	and/or another product use only high quality shielded cables.	affected by the interference.
	Cable/s supplied with this product MUST be used. Follow all	Utilize power outlets that are on different branch (circuit
	installation instructions. Failure to follow instructions could	breaker or fuse) circuits or install AC line filter/s.
	void your FCC authorization to use this product in the USA.	In the case of radio or TV interference, relocate/reorient the
	3. NOTE: This product has been tested and found to comply
		antenna. If the antenna lead-in is 300 ohm ribbon lead,
	with the requirements listed in FCC Regulations, Part 15 for	change the lead-in to co-axial type cable.
	Class “B” digital devices. Compliance with these require-	If these corrective measures do not produce satisfactory
	ments provides a reasonable level of assurance that your
		results, please contact the local retailer authorized to distrib-
	use of this product in a residential environment will not result
		ute this type of product. If you can not locate the appropriate
	in harmful interference with other electronic devices. This
		retailer, please contact Yamaha Corporation of America,
	equipment generates/uses radio frequencies and, if not
		Electronic Service Division, 6600 Orangethorpe Ave, Buena
	installed and used according to the instructions found in the
		Park, CA90620
	users manual, may cause interference harmful to the opera-
		The above statements apply ONLY to those products distrib-
	tion of other electronic devices. Compliance with FCC regula-
		uted by Yamaha Corporation of America or its subsidiaries.
	* This applies only to products distributed by YAMAHA CORPORATION OF AMERICA.	(class B)

SC2 Owner’s Manual

3

The model number, power requirements, etc., are located on the name plate, which is at the bottom of the control unit. The serial number is located behind the control unit. You should note this serial number in the space provided below and retain this manual as a permanent record of your purchase to aid identification in the event of theft.

Model No.

Serial No.

(bottom_en_silent)

Modellnummer, Leistungsbedarf usw. sind auf dem Namensschild aufgeführt, das sich an der Unterseite der Steuereinheit befindet. Die Seriennummer befindet sich an der Rückseite der Steuereinheit. Für den Fall eines Diebstahls sollten Sie diese Seriennummer im unten vorgesehenen Feld eintragen und diese Anleitung als dauerhaften Kaufnachweis aufbewahren.

Modell Nr.

Seriennr.

(bottom_de_silent)

Le numéro de modèle de l'appareil, ses besoins en alimentation ainsi que d'autres informations le concernant figurent sur sa plaque signalétique, qui se trouve en bas de l'unité de commande. Le numéro de série est indiqué à l’arrière de l’unité de commande. Notez ce numéro de série dans l'espace fourni ci-dessous et conservez le présent manuel comme preuve permanente de votre achat afin de faciliter l'identification du produit en cas de vol.

N° de modèle

N° de série

(bottom_fr_silent)

Il numero del modello, i requisiti di alimentazione, ecc… si trovano sulla piastrina posizionata nella parte inferiore dell'unità di controllo. Il numero di serie si trova dietro l'unità di controllo. Si consiglia di riportare il numero di serie nell'apposito spazio di seguito e di conservare questo manuale come prova di acquisto permanente, al fine di consentire l'identificazione in caso di furto.

Numero del modello

Numero di serie

(bottom_it_silent)

El número de modelo, los requisitos de alimentación, etc. se encuentran en la placa de denominación, que está en la parte inferior de la unidad de control. El número de serie se encuentra detrás de la unidad de control. Debe anotar este número de serie en el espacio que se proporciona a continuación y conservar este manual como un registro permanente de su compra para facilitar la identificación en caso de robo.

Nº de modelo

Nº de serie

(bottom_es_silent)

, ...

(bottom_ko_silent)

The name plate is located on the bottom of the unit.

La plaque signalétique de ce produit se trouve dans le bas de l'unité. La placa del nombre se encuentra en la parte inferior de la unidad. Das Namensschild befindet sich an der Unterseite des Produkts.

La targhetta del nome si trova sul fondo dell'unità.

.

4SC2 Owner’s Manual

English

SC2

Owner’s Manual

Table of Contents

PRECAUTIONS...........................................................	7
NOTICE ........................................................................	9
About the Manuals ....................................................	10
Included Accessories .................................................	10
Features........................................................................	11

Chapter 4 Connecting to Other Devices
.............................................	30
Connecting to external audio devices ([AUX IN]
jack)..............................................................................	30
Connecting to a computer/smart device ................	31

Chapter 1 Getting Started ...................	12
Part names...................................................................	12
Turning the power on/off .........................................	14
Using headphones......................................................	15
Chapter 2 Playing with the Silent Piano™
Function..............................	16
Using the Silent Piano™ function .............................	16
Selecting Voices..........................................................	17
Using the metronome................................................	19
Chapter 3 Recording and Playback.....	22
Recording your performance to internal memory
(MIDI recording) .......................................................	22
Playing back the MIDI Song recorded to internal
memory .......................................................................	23
Recording your performance to a USB flash drive
(Audio recording) ......................................................	24
Playing back an Audio Song recorded to the USB
flash drive ....................................................................	24
Connecting USB devices ...........................................	25
Playing back the Voice Demo Songs .......................	26
Playing back the Preset Songs ..................................	27
Operations during playback .....................................	28
Adjusting the playback tempo..................................	29

Chapter 5 Using Other Functions.......	33
Setting the various convenient functions ...............	33
Backup data and initialization..................................	40
Chapter 6 Appendix ............................	41
Troubleshooting.........................................................	41
Specifications .............................................................	42
Song List ......................................................................	43
Quick Operation Guide.............................................	44
Index ............................................................................	45

SC2 Owner’s Manual

5

Information for users on collection and disposal of old equipment:

This symbol on the products, packaging, and/or accompanying documents means that used electrical and electronic products should not be mixed with general household waste.

For proper treatment, recovery and recycling of old products, please take them to applicable collection points, in accordance with your national legislation.

By disposing of these products correctly, you will help to save valuable resources and prevent any potential negative effects on human health and the environment which could otherwise arise from inappropriate waste handling.

For more information about collection and recycling of old products, please contact your local municipality, your waste disposal service or the point of sale where you purchased the items.

For business users in the European Union:

If you wish to discard electrical and electronic equipment, please contact your dealer or supplier for further information.

Information on Disposal in other Countries outside the European Union:

This symbol is only valid in the European Union. If you wish to discard these items, please contact your local authorities or dealer and ask for the correct method of disposal.

(weee_eu_en_02)

For the AC adaptor

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:

(1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

CAN ICES-3 (B)/NMB-3(B)

(can_b_02)

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.

(fcc_sengen-c)

Explanation of Graphical Symbols

The lightning flash with arrowhead symbol within an equilateral triangle is intended to alert the user to the presence of uninsulated “dangerous voltage” within the product’s enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons.

The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the product.

IMPORTANT SAFETY INSTRUCTIONS

1 Read these instructions.

2 Keep these instructions.

3Heed all warnings.

4Follow all instructions.

5 Do not use this apparatus near water.

6Clean only with dry cloth.

7Do not block any ventilation openings. Install in

accordance with the manufacturer’s instructions.

8Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including

amplifiers) that produce heat.

9Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has two blades with one wider than the other. A grounding type plug has two blades and a third grounding prong. The wide blade or the third prong are provided for your safety. If the

provided plug does not fit into your outlet, consult an electrician for replacement of the obsolete outlet.

10Protect the power cord from being walked on or pinched particularly at plugs, convenience receptacles, and the point where they exit from the apparatus.

11Only use attachments/accessories specified by the manufacturer.

12Use only with the cart, stand, tripod, bracket, or table

specified by the manufacturer, or sold with the apparatus. When a cart is used, use caution when moving the cart/apparatus combination to avoid injury from tip-over.

13Unplug this apparatus during lightning storms or when unused for long periods of time.

14Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been damaged in any way, such as power-supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped.

WARNING

TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS APPARATUS TO RAIN OR MOISTURE.

(UL60065_03)

6SC2 Owner’s Manual

PRECAUTIONS

PLEASE READ CAREFULLY BEFORE PROCEEDING

Please keep this manual in a safe and handy place for future reference.

For the AC adaptor

WARNING

•This AC adaptor is designed for use with only Yamaha electronic devices. Do not use for any other purpose.

•Indoor use only. Do not use in any wet environments.

CAUTION

•When setting up, make sure that the AC outlet is easily accessible. If some trouble or malfunction occurs, immediately turn off the power switch of the instrument and disconnect the AC adaptor from the outlet. When the AC adaptor is connected to the AC outlet, keep in mind that electricity is flowing at the minimum level, even if the power switch is turned off. When you are not using the instrument for a long time, make sure to unplug the power cord from the wall AC outlet.

English

For the instrument

WARNING

Always follow the basic precautions listed below to avoid the possibility of serious injury or even death from electrical shock, short-circuiting, damages, fire or other hazards. These precautions include, but are not limited to, the following:

	Water warning
Power supply/AC adaptor

•Do not place the power cord near heat sources such as heaters or radiators. Also, do not excessively bend or otherwise damage the cord, or place heavy objects on it.

•Only use the voltage specified as correct for the instrument. The required voltage is printed on the name plate of the instrument.

•Use the specified adaptor (page 42) only. Using the wrong adaptor can result in damage to the instrument or overheating.

•Check the electric plug periodically and remove any dirt or dust which may have accumulated on it.

•Unplug the power cord from the AC outlet when cleaning the instrument.

Do not open

•This instrument contains no user-serviceable parts. Do not open the instrument or attempt to disassemble or modify the internal components in any way. If it should appear to be malfunctioning, discontinue use immediately and have it inspected by qualified Yamaha service personnel.

•Do not expose the instrument to rain, use it near water or in damp or wet conditions, or place on it any containers (such as vases, bottles or glasses) containing liquids which might spill into any openings. If any liquid such as water seeps into the instrument, turn off the power immediately and unplug the power cord from the AC outlet. Then have the instrument inspected by qualified Yamaha service personnel.

•Never insert or remove an electric plug with wet hands.

Fire warning

•Do not put burning items, such as candles, on the unit. A burning item may fall over and cause a fire.

If you notice any abnormality

•When one of the following problems occur, immediately turn off the power switch and disconnect the electric plug from the outlet. Then have the device inspected by Yamaha service personnel.

-The power cord or plug becomes frayed or damaged.

-It emits unusual smells or smoke.

-Some object has been dropped into the instrument.

-There is a sudden loss of sound during use of the instrument.

DMI-5 1/2

SC2 Owner’s Manual

7

CAUTION

Always follow the basic precautions listed below to avoid the possibility of physical injury to you or others, or damage to the instrument or other property. These precautions include, but are not limited to, the following:

	Connections
Power supply/AC adaptor

•Do not connect the instrument to an electrical outlet using a multiple-connector. Doing so can result in lower sound quality, or possibly cause overheating in the outlet.

•When removing the electric plug from the instrument or an outlet, always hold the plug itself and not the cord. Pulling by the cord can damage it.

•Remove the electric plug from the outlet when the instrument is not to be used for extended periods of time, or during electrical storms.

Location

•Do not place the instrument in an unstable position where it might accidentally fall over.

•Before moving the instrument, remove all connected cables, to prevent damage to the cables or injury to anyone who might trip over them.

•When moving the instrument, be careful to avoid catching your hands or feet on the instrument.

•Move the instrument slowly with extra care to keep the instrument from falling over, or bumping against the surroundings. We recommend that you consult a qualified carrier to transport or move the instrument.

•When setting up the product, make sure that the AC outlet you are using is easily accessible. If some trouble or malfunction occurs, immediately turn off the power switch and disconnect the plug from the outlet. Even when the power switch is turned off, electricity is still flowing to the product at the minimum level. When you are not using the product for a long time, make sure to unplug the power cord from the wall AC outlet.

•Before connecting the instrument to other electronic components, turn off the power for all components. Before turning the power on or off for all components, set all volume levels to minimum.

•Be sure to set the volumes of all components at their minimum levels and gradually raise the volume controls while playing the instrument to set the desired listening level.

Handling caution

•Do not insert a finger or hand in any gaps on the fallboard or instrument. Also take care that the fallboard does not pinch your finger.

•Never insert or drop paper, metallic, or other objects into the gaps or opening on the main unit, fallboard, or keyboard. This could cause physical injury to you or others, damage to the instrument or other property, or operational failure.

•Do not rest your weight on, or place heavy objects on the instrument, and do not use excessive force on the buttons, switches or connectors.

•Do not use the instrument/device or headphones for a long period of time at a high or uncomfortable volume level, since this can cause permanent hearing loss. If you experience any hearing loss or ringing in the ears, consult a physician.

•Close the fallboard when the instrument is not in use. Hold the fallboard with both hands when opening or closing it. Be careful to avoid catching fingers (yours or others) between the fallboard and the main unit.

•Do not go near the instrument during an earthquake. Strong shaking during an earthquake could cause the instrument to move or tip over, resulting in damage to the instrument or its parts, and possibly causing injury.

Yamaha cannot be held responsible for damage caused by improper use or modifications to the instrument, or data that is lost or destroyed.

Always turn the power off when the instrument is not in use.

Even when the [ ] (Standby/On) switch is in standby status (power lamp is off), electricity is still flowing to the instrument at the minimum level. When you are not using the instrument for a long time, make sure you unplug the power cord from the wall AC outlet.

DMI-5 2/2

8SC2 Owner’s Manual

NOTICE

To avoid the possibility of malfunction/ damage to the product, damage to data, or damage to other property, follow the notices below.

 Handling

•Do not use the instrument in the vicinity of a TV, radio, stereo equipment, mobile phone, or other electric devices. Otherwise, the instrument, TV, or radio may generate noise. When you use the instrument along with a smart device, such as an iPhone, iPad, etc., we recommend that you set that device’s “Airplane Mode” to on and then the Wi-Fi setting to on in order to avoid noise caused by communication.

•Do not expose the instrument to excessive dust or vibrations, or extreme cold or heat (such as in direct sunlight, near a heater, or in a car during the day) to prevent the possibility of panel disfiguration, damage to the internal components or unstable operation.

•Do not place vinyl, plastic or rubber objects on the instrument, since this might discolor the panel or keyboard.

•Bumping the surface of the instrument with metal, porcelain, or other hard objects can cause the finish to crack or peel. Use caution.

•Do not drag the instrument when moving it. Doing so may damage the floor.

 Maintenance

•When cleaning the instrument, use a soft and dry cloth. Do not use paint thinners, solvents, alcohol, cleaning fluids, or chemical-impregnated wiping cloths.

•Gently remove dust and dirt with a soft cloth. Do not wipe too hard since small particles of dirt can scratch the instrument's finish.

•During extreme changes in temperature or humidity, condensation may occur and water may collect on the surface of the instrument. If water is left, the wooden parts may absorb the water and be damaged. Make sure to wipe any water off immediately with a soft cloth.

 Saving data

•The MIDI Song recorded to this instrument (page 22) are retained when the power is turned off. However, the saved data may be lost due to some failure, an operation mistake, etc. Save your important data onto an external device such as a computer (page 31).

•To protect against data loss through USB flash drive damage, we recommend that you save your important data onto spare USB flash drive or an external device such as a computer as backup data.

Information

 About copyrights

•Copying of the commercially available musical data including but not limited to MIDI data and/or audio data is strictly prohibited except for your personal use.

•This product incorporates and bundles contents in which Yamaha owns copyrights or with respect to which Yamaha has license to use others' copyrights. Due to copyright laws and other relevant laws, you are NOT allowed to distribute media in which these contents are saved or recorded and remain virtually the same or very similar to those in the product.

* The contents described above include a computer program, Accompaniment Style data, MIDI data, WAVE data, voice recording data, a score, score data, etc.

*You are allowed to distribute medium in which your performance or music production using these contents is recorded, and the permission of Yamaha Corporation is not required in such cases.

About functions/data bundled with the instrument

•Some of the preset songs have been edited for length or arrangement, and may not be exactly the same as the original.

 About this manual

•The illustrations as shown in this manual are for instructional purposes only, and may appear somewhat different from those on your instrument.

•Windows is a registered trademark of Microsoft® Corporation in the United States and other countries.

•iPhone, iPad and iPod touch are trademarks of Apple Inc., registered in the U.S. and other countries.

•The company names and product names in this manual are the trademarks or registered trademarks of their respective companies.

English

SC2 Owner’s Manual

9

Thank you for choosing the Yamaha Silent Piano™. This instrument is equipped with the same keyboard mechanisms as an acoustic piano. However, you can play with the sound muted, and use various functions not available on an acoustic piano, such as changing Voices or recording your performance. This manual mainly explains these functions as a Silent Piano. In order to make the most of the performance potential and features of the instrument, please read the manuals thoroughly, and keep them in a handy place for later reference.

About the Manuals

This instrument has the following documents and instructional materials.

 Included Documents

Owner’s Manual (this book)

This manual mainly describes how to use the particular functions for the Silent Piano™ which can be used when the power is turned on. For information on handling as an acoustic piano, refer to the separate manual for the piano.

Online Materials (downloadable from the website)

iPhone/iPad Connection Manual

(only in English, French, German

and Spanish)

Explains how to connect the instrument to smart devices, such as an iPhone, iPad, etc.

Quick Operation Guide (page 44)

This a quick reference for operation of the functions assigned to the buttons and keyboard.

Computer-related Operations

Includes instructions on connecting this instrument to a computer, and operations related to transferring data.

MIDI Reference

Contains MIDI related information.

To obtain these manuals, access the Yamaha Downloads, enter the model name for searching the desired files.

Yamaha Downloads

http://download.yamaha.com/

Included Accessories

• Owner’s Manual (this book)	x 1
• AC adaptor	x 1
• Power cord	x 1
• Headphones	x 1
• Headphone hanger	x 1
• Attachment screws for headphone hanger	x 2

10 SC2 Owner’s Manual

Features

• Silencing System enables you play in any situation, at any time you want

Yamaha’s innovative silencing system brings you superior performance, yet with virtually complete silence. Enjoy your performance just as if you were playing an acoustic piano—but without the need to worry about bothering people around you.

• Non-contact sensors for maximum expressiveness

The non-contact optical sensors faithfully detect subtle movement of the keys without affecting the touch of the keys. They catch keystroke information precisely, enabling you to perform with rich nuance and extraordinarily subtle expression.

• Elegant, integrated design

The control unit has been given a graceful design that unobtrusively blends with the piano itself. Moreover, the simple controllers allow you to operate the instrument easily.

• Realistic ambience of the Voices enhances your performance

This instrument puts the sound of ten luxurious, authentic Voices at your fingertips. These include Yamaha’s flagship CFX piano—which delivers dynamic sound, from a brilliant high-range to powerful bass—and the Bösendorfer* Imperial, a world-class piano renowned for its subtle and warm sound. The instrument also features advanced technologies such as Binaural Sampling. Listening with headphones to a piano Voice enhanced through these methods gives the impression of being thoroughly immersed in the sound, as if it was actually emanating from the piano.

Altogether, it delivers real sound faithful to that of an actual acoustic piano, such as the quick attack and the graceful resonance of a sustained piano tone, as well as how the sound responds to your playing strength, and the resonance effect when the damper pedal is pressed.

* Bösendorfer is a subsidiary company of Yamaha.

• Playback and recording functions for aid in learning and practice

You can record your performance to this instrument and a USB flash drive, and improve your performance by listening back to the recording.

Smart Device App “Smart Pianist”

The smart device app “Smart Pianist” (available as a free download) enables you to use the functions such as selecting Voices, controlling the metronome intuitively with the visualized interface, or display the score on your smart device.

For information about this app, access the following web page: https://www.yamaha.com/kbdapps/

The connection wizard of the Smart Pianist helps you to connect this unit to your smart device properly. To start connection wizard, tap [ ] (Menu) located upper left on the Smart Pianist screen to open the menu, then tap “Instrument” followed by “Start Connection Wizard.”

English

SC2 Owner’s Manual 11

Chapter

1Getting Started

Part names

 Piano

Upright Piano

Grand Piano

	2	(on the rear of the piano)
	Control unit	Control unit	1
	(page 13)	(page 13)
	1 Silencing lever	2 DC IN jack (page 14)
	Activates the Silent Piano™ function.	For connecting the supplied AC adaptor.

 Pedals

3			2			1

1	Damper pedal		2	Silencing pedal (upright piano)
	Sustains notes even after you release the keys.			Activates the Silent Piano™ function by pressing
	When the Silent Piano™ function is enabled and			and sliding to the left.
	a piano Voice is selected, pressing this pedal			Sostenuto pedal (grand piano)
	reproduces the complicated interaction of both
				Sustains the notes that are being played at the
	strings and soundboard resonance by the VRM
				time you press and hold the pedal, even after
	technology (page 37), and makes	the sound
				you release the keys, letting you play additional
	more like a real acoustic piano.
				non-sustained notes. Subsequently played
	The damper pedal features an expressive half-
				notes are not affected.
	pedal function, and allows you to set the degree
				NOTE
	to which pressing the damper pedal applies the
				When using the Silent Piano function, there is no
	half-pedal effect (page 35), when	using the
				Sostenuto effect.
	Silent Piano™ function.
				Soft pedal
			3
				Reduces the volume and slightly changes the
				timbre of the notes. The notes played before
				this pedal is pressed are not affected.

12 SC2 Owner’s Manual

 Control unit

Front panel

1		2		8		9

English

	3					4			5			6			7

Bottom panel

These buttons (and switch) are pressed upward from the bottom.

1

2

3

4

5

6

7

	10		11		12		13
[PHONES] jacks (page 15)		8 [VOICE/VALUE] control

For connecting a pair of headphones (stereo mini plug). Up to two headphones can be connected.

USB [TO DEVICE] terminal (page 25)

For connecting a USB flash drive or a USB wireless LAN adaptor.

[P] (Standby/On) switch (page 14)

For turning the power on or setting to standby.

[Rec] button (page 22)

For setting the unit to recording standby status. The lamp indicates the recording status.

[R/J] (Play/Stop) button (page 23)

For alternately playing back and stopping the preset Songs or your recorded performance. The lamp indicates the playback status.

[Metronome] button (page 19)

For controlling the metronome. The lamp indicates the metronome status.

[Func.] button (page 33)

For making settings of various functions.

9

10

11

12

13

Rotating this allows you to select desired Voices or adjust the setting values. Pressing this control resets the Voice or setting values.

[VOLUME] control (page 16)

For adjusting the volume of the entire sound output from the [PHONES] jack.

[DC IN 16V] jack (page 14)

(Upright piano) For connecting the power cord. This is connected to the DC IN jack on the rear of the piano when the instrument is shipped.

(Grand piano) For connecting the supplied AC adaptor.

[SENSOR] jack

(For qualified Yamaha personnel only.) This connects to the sensor. The plug is already connected when the instrument is shipped.

[AUX IN] jack (page 30)

For connecting an audio device such as a portable music player by using an audio cable with stereo mini plugs.

USB [TO HOST] terminal (page 31)

For connecting to a computer or a smart device.

SC2 Owner’s Manual 13

Turning the power on/off

1 Connect the plugs of the AC adaptor in the order shown in the illustration.

Make sure to loop the power cord through the metal hook attached to the rear (for upright pianos) or the bottom (for grand pianos) of the piano.

Upright Piano

Grand Piano

[DC IN 16V] jack

DC IN jack

Hook is located on		1-2
the rear of the piano.
AC outlet		1-3
1-4
	Power cord
		AC
AC plug	1-1	adaptor

		1-2
Hooks are located on
the bottom of the piano,
behind the control unit.
AC outlet		1-3
1-4
	Power cord	AC
AC plug	1-1	adaptor

The shape of the plug and outlet differ depending on your locale.

WARNING

Use the specified adaptor (page 42) only. Use of other adaptors may result in irreparable damage to both the adaptor and the instrument.

CAUTION

When setting up the product, make sure that the AC outlet you are using is easily accessible. If some trouble or malfunction occurs, immediately turn the power off and disconnect the plug from the outlet.

NOTE

When disconnecting the AC adaptor, first turn the power off, and then follow the order shown above in reverse.

2 Press the [P] (Standby/On) switch to turn the power on.

The [P] (Standby/On) lamp lights up.

To turn the power off, press the switch again.

NOTE

The sound will not be properly output if a key was pressed when the power was turned on. Do not touch any keys when turning the power on.

CAUTION

Even when the instrument is turned off, electricity is still flowing to the instrument at the minimum level. When you are not using the instrument for a long time or during electrical storms, make sure you unplug the AC power plug from the wall AC outlet.

14 SC2 Owner’s Manual

Auto Power Off function

To prevent unnecessary power consumption, this unit features an Auto Power Off function that automatically turns the power off if the instrument is not operated for 30 minutes.

NOTICE

When the instrument is communicating with other devices, the power will not be turned off automatically. Make sure to turn off the power by pressing the [P] (Standby/On) switch when the instrument is not in use.

Disabling Auto Power Off

Turn the power on while holding down the lowest key (A-1).
After a brief time, the [Rec] lamp flashes three times and the
unit starts up with the Auto Power Off function disabled.
To turn the Auto Power Off function on or off while the
power is on, refer to page 38.	Lowest key (A-1)

Using headphones

Connect a pair of headphones to the [PHONES] jack. Since this instrument is equipped with two [PHONES] jacks, you can connect two pairs of headphones. If you are using only one pair, insert the plug into either of these jacks.

Even when listening through headphones, you can enjoy exceptionally realistic, natural sound by Yamaha’s advanced technologies, Binaural Sampling and Stereophonic Optimizer. For details, refer to page 18.

CAUTION

•Do not use the headphones for a long period of time at a high or uncomfortable volume level, since this can cause permanent hearing loss.

•Be careful not to catch your foot on the headphone cord.

Phone plug (stereo mini)

NOTICE

Do not pull the cord of the headphones or apply excessive force on the plug. This can damage the headphones and result in sound degradation.

Using an external speaker

The [PHONES] jack can also be used for external output. By connecting a powered speaker to the [PHONES] jack, you can output the sound from this instrument to an external speaker and let other people hear it.

NOTICE

To avoid possible damage to the devices, first turn on the power to the instrument, then to the external device. When turning off the power, first turn off the power to the external device, then to the instrument.

 Attaching the headphone hanger

Attach the headphone hanger to the bottom of the control unit with the supplied two screws.

NOTICE

Do not hang anything other than the headphones on the hanger. Otherwise, the instrument or the hanger may be damaged.

Phillips-head (+) screwdriver

English

SC2 Owner’s Manual 15
