MX9600ZP
MX9600ZW
MX9600ZM
Contents
Sunbeam’s Safety Precautions |
2 |
Features of your Zumbo Limited Edition Mixmaster® |
3 |
Using your Zumbo Limited Edition Mixmaster® |
5 |
Using your Power Drive |
10 |
Safety Mechanisms |
11 |
Care & Cleaning |
12 |
Mixing Guide |
13 |
Oven Temperature Guide |
14 |
Troubleshooting Guide |
15 |
Ingredients |
16 |
Cookery Tips for Best Results |
17 |
Making a Successful Dough |
18 |
Important instructions – retain for future use.
1
Sunbeam’s Safety Precautions
|
SAFETY PRECAUTIONS FOR YOUR SUNBEAM |
• |
Ensure that the bowl is secured and locked onto |
|
Zumbo Limited Edition® PLANETARY |
|
the base of the Bench Mixer before commencing |
|
MIXMASTER® BENCH MIXER. |
|
mixing. |
• |
Switch off the appliance and disconnect from |
• |
Do not unlock or remove the mixing bowl from the |
|
supply before changing accessories or approaching |
|
base of the Power Drive Bench Mixer whilst in use. |
|
parts that move in use. |
• |
Never tilt back the head of the Power Drive Bench |
• |
Never remove any attachment or accessory when |
|
Mixer whilst the appliance is in operation. |
|
the appliance is in operation; including the beater, |
• |
When using extremely heavy loads the appliance |
|
Scrapemaster™ spatula beater, whisk, dough hook, |
|
should not be operated for more than 1 and a half |
|
pasta roller, pasta cutter. |
|
minutes. This does not apply to the recipes detailed |
• |
Ensure fingers are kept well away from moving |
|
in this booklet. |
|
beater, Scrapemaster™ spatula beater, pasta roller, |
• |
Ensure long hair is tied back and young children |
|
pasta cutter, whisk or dough hook. |
|
are not near the bowl. |
|
|
|
|
|
Sunbeam are very safety conscious when designing |
|
Do not place on top of any other appliance. |
|
and manufacturing consumer products, but it is |
• |
Do not let the power cord of an appliance hang over |
|
essential that the product user also exercise care |
|
the edge of a table or bench top or touch any hot |
|
when using an electrical appliance. Listed below are |
|
surface. |
|
precautions which are essential for the safe use of an |
• |
Do not operate any electrical appliance with a |
|
electrical appliance: |
||
|
|
damaged cord or after the appliance has been |
|
• |
Read carefully and save all the instructions |
|
|
|
damaged in any manner. If damage is suspected, |
||
|
provided with an appliance. |
|
return the appliance to the nearest Sunbeam |
• |
Always turn the power off at the power outlet before |
|
Appointed Service Centre for examination, repair or |
|
you insert or remove a plug. Remove by grasping |
|
adjustment. |
|
the plug - do not pull on the cord. |
• |
For additional protection, Sunbeam recommend |
• |
Turn the power off and remove the plug when the |
|
the use of a residual current device (RCD) |
|
appliance is not in use and before cleaning. |
|
with a tripping current not exceeding 30mA in |
• |
Do not use your appliance with an extension cord |
|
the electrical circuit supplying power to your |
|
unless this cord has been checked and tested by a |
|
appliances. |
|
qualified technician or service person. |
• |
In order to avoid a hazard due to inadvertent |
• |
Always use your appliance from a power outlet of |
|
resetting of the thermal cut-out, this appliance |
|
the voltage (A.C. only) marked on the appliance. |
|
must not be supplied through an external switching |
• |
This appliance is not intended for use by young |
|
device, such as a time, or connected to a circuit |
|
that is regularly switched on and off by the utility. |
||
|
children or infirm persons unless they have been |
|
|
|
• |
Do not immerse the appliance in water or any other |
|
|
adequately supervised by a responsible adult to |
||
|
ensure that they can use the appliance safely. |
|
liquid unless recommended. |
• |
Young children should be supervised to ensure that |
• |
This appliance is intended to be used in household |
|
they do not play with the appliance. |
|
and similar applications such as: staff kitchen areas |
• |
Never leave an appliance unattended while in use. |
|
in shops, offices and other working environments; |
|
farm houses; by clients in hotels, motels and other |
||
• |
Do not use an appliance for any purpose other than |
|
|
|
residential type environments; bed and breakfast |
||
|
its intended use. |
|
|
|
|
type environments. |
|
• |
Do not place an appliance on or near a hot gas |
|
|
|
|
||
|
flame, electric element or on a heated oven. |
|
|
If you have any concerns regarding the performance and use of your appliance, please visit www.sunbeam.com.au or contact the Sunbeam Consumer Service Line.
Ensure the above safety precautions are understood.
2
Features of your Zumbo Limited Edition Mixmaster® Bench Mixer
Drive Outlet
The drive outlet allows for the attachment of a range of accessories including pasta rollers and pasta cutters.
1200W motor
Powerful motor achieves thorough mixing results.
Full die-cast metal body with sintered metal gears
The heavy duty die-cast metal body combined with sintered metal gears deliver quality, style and superior performance.
Planetary mixing action
Enables the mixing attachment (beater, Scrapemaster™ spatula beater, whisk or dough hook) to rotate whilst travelling around the inside of the bowl, and reach all
areas of the bowl ensuring ingredients are completely mixed.
Splashguard with pouring chute
Splashguard prevents ingredients from spilling out of the mixing bowl. The pouring chute allows adding ingredients directly into the mixing bowl without having to stop the mixer and lifting the mixer head.
Overmould Handle
The handle on the mixing bowl allows for ease of use during operation and the overmould handle provides comfort for your hand.
Slow start
The mixing speed is gradually increased to prevent ingredients splashing out of the mixing bowl.
Stainless steel mixing bowl
The 4.5L mixing bowl is ideal for mixing large or small quantities of ingredients.
Cord storage
For added convenience the unused cord length can easily be pushed into the base of the mixer for storage.
Pause / Start button
Allows you to instantly stop the mixer to assess the mixing progress and/or add additional ingredients without affecting
the timer.
Carrying grips
Grips at both sides of the mixer base allow for easy carrying.
3
Buttons |
'' and '' buttons can be used to choose the desired mixing duration, or to set the kitchen timer.
Die-cast alloy dough hook
Takes the hard work out of kneading dough and other heavy mixtures.
Super Scraper Whisk
The unique design of the whisk allows more air to be added to ingredients when whisking, providing faster results.
Head release with in-built safety feature
The mixer head can be easily released and lifted with one hand. It tilts upwards and locks securely into position to allow easy insertion and removal of the mixing bowl and attachments. The in-built safety feature ensures that the mixer only starts when the mixer head is tilted downwards and securely locked in. Lifting the mixer head during the mixing process will automatically cut power to the motor.
Scrapemaster™ spatula beater
Excels at combining ingredients and simultaneously scrapes the sides and the bottom of the mixing bowl, virtually eliminating hand-scraping and batter build-up on the blade. Superior bowl clearance also makes this attachment ideal for smaller mixing quantities.
Die-cast alloy beater
Provides maximum aeration for creaming butter and sugar, and is also ideal for mixing heavy cake mixes.
LCD screen with timer
LCD screen displays mixing time and speed setting. Timer function can be set to count up or down as required.
Speed control dial with 12 variable settings
The combination of 12 electronic speeds and a powerful torque control motor ensures superior mixing control and maintains speed, regardless of the mixing load.
4
Using your Zumbo Limited Edition Mixmaster® Bench Mixer
Before using your Power Drive Bench Mixer
Before using your Power Drive Bench Mixer for the first time, remove any packaging material and promotional labels or tags. Please also remove the plastic plug pin cover before using the mixer. It is recommended to wash the mixing bowl, beater, Scrapemaster™ spatula beater, whisk and dough hook in warm soapy water with a soft cloth. Rinse and dry thoroughly.
Set-up of your bench mixer
Before assembling your Power Drive Bench Mixer, be sure the power cord is unplugged from the power outlet. Position the mixer on a level, dry surface such as a bench top.
1.Press the ‘head release’ button, located at the rear of the mixer head. This will release the mixer head out of its locked position. Ease the mixer head backwards until it locks into its tilt position (Fig. 1).
2.Select the desired attachment depending
Figure 1
on the mixing task to be performed:
–Beater for creaming butter and
sugar, plus mixing heavy cake mixes.
–Scrapemaster™ spatula beater for smaller amounts of mixture or for faster creaming of butter and sugar and heavy cake mixes. Also great for folding ingredients
–Whisk for whisking cream, egg whites, light batters and packet cake mixes.
– Dough hook for kneading dough and other heavy mixtures.
3.Attach the selected attachment onto the drive outlet using the bayonet attachment. Place the attachment into position with the feeder roll at the back. Simply push the roller back and down, to lock into position.
2.
1.
Figure 2
Note: Be sure the attachment is locked firmly in place.
Figure 3
5
Using your Zumbo Limited Edition Mixmaster® Bench Mixer continued
Figure 4
4.Place the bowl on the base with the handle facing you. Then gently rotate the bowl
in a clockwise direction until it locks into position (Fig 3). The bowl should feel firm with no movement.
5.Lower the mixer head with the selected mixing attachment in place into the mixing bowl. Press the ‘head release’ button to un-lock it from its position and ease the mixer head down (Fig. 4).
Figure 5
6.The splashguard can now be placed over the bowl if desired (Fig 5).
Using your Planetary Mixmaster® Bench Mixer
1.Position the mixer on a level, dry surface such as a bench top. Ensure the mixing bowl is in place and the desired attachment is inserted.
2.Plug the power cord into a 230/240 Volt AC power outlet.
3.A beep will sound and the LCD screen will light up to inform you that the mixer is now switched on. The LCD screen will flash three times and the timer will display “00:00”. The screen will also display the speed setting. If the LCD displays a speed setting other than “0” and continues to flash, you may turn the speed control dial anti-clockwise to the “0” position to re-set the speed setting.
4a. If using the splashguard, add ingredients to the mixing bowl through the pouring shoot.
4b. If using the mixer without the splashguard, release the mixer head out of its locked position and ease it backwards until it locks into its tilt position. Add ingredients to the mixing bowl. Then, un-lock the mixer head and lower it forward into the mixing bowl.
5.Turn the speed control dial clockwise to commence mixing (Fig. 6), or, if a speed is already set, press the button.
Figure 6
6
Using your Zumbo Limited Edition Mixmaster® Bench Mixer continued
The LCD screen will display the chosen speed setting. Instructions for mixing speeds for each type of mixture are shown in the ‘Mixing Guide’ on page 15.
6.When mixing is complete, turn the speed control dial anti-clockwise to the ‘0’ position (Fig. 7) and unplug the cord from the power outlet.
9.To remove the particular mixing attachment, push it upwards, turn it anticlockwise, then pull it downwards (Fig 8).
2.
1.
3.
Figure 8
Figure 7
7.Remove the splashguard if positioned on the bowl.
8.Press the ‘head release’ button and ease the mixer head back until it is locked into the tilt back position
(see Figure 1 on page 6).
7
