Sunbeam LC7900 User Manual

Food Processor

1100 watt processor with wide chute

Instruction Booklet

LC7900

Please read these instructions carefully and retain for future reference.

Contents

Sunbeam’s Safety Precautions	3
Features of your Food Processor	4
Attachments for your Food Processor	6
Using your Food Processor	7
Fitting/using the tools on your Food Processor	9
Storing your Food Processor	11
Handy hints for processing	13
Care and cleaning	15
Recipes	16

Important instructions – retain for future use.

Sunbeam’s Safety Precautions

		SAFETY PRECAUTIONS FOR YOUR SUNBEAM	•	Avoid contacting moving parts at all times.
		FOOD PROCESSOR LC7900.	•	Place the processing bowl onto the base of the
	•	Always use extreme care when handling blades and		processor before fitting any attachments.
		cutting discs. These are extremely sharp and may	•	All blades and attachments should be removed
		cause injury if handled incorrectly. Always store
				with care before cleaning.
		blades and cutting discs in their respective covers
			•	Do not over fill the processor.
		or processing containers.
			•	Do not process for longer than the time periods
	•	Unplug from power outlet when not in use, before
				recommended in the operating chart.
		putting on or taking off attachments, and before
			•	Always remove the blade before emptying the
		cleaning.
	•	Do not put hot liquids into the processing bowl.		processing bowl of its contents.
			•	Take care when removing the bowl from the base,
		Cool to room temperature before placing in
		processing bowl.		emptying the bowl or during fitting and removal of
				blade system, as blades are extremely sharp.
		Sunbeam is very safety conscious when designing and	•	Do not use an appliance for any purpose
		manufacturing consumer products, but it is essential		other than its intended use.
		that the product user also exercise care when using	•	Do not place an appliance on or near a hot gas
		an electrical appliance. Listed below are precautions		flame, electric element or on a heated oven.
		which are essential for the safe use of an electrical	•	Do not place on top of any other appliance.
		appliance:	•	Do not let the power cord of an appliance hang over
	•	Read carefully and save all the instructions provided		the edge of a table or bench top or touch any hot
		with an appliance.		surface.
	•	Always turn the power off at the power outlet before	•	Do not operate any electrical appliance with a
		you insert or remove a plug. Remove by grasping the		damaged cord or after the appliance has been
		plug - do not pull on the cord.		damaged in any manner. If damage is suspected,
	•	Turn the power off and remove the plug when the		return the appliance to the nearest Sunbeam
		appliance is not in use and before cleaning.		Appointed Service Centre for examination, repair
	•	Do not use your appliance with an extension cord		or adjustment.
		unless this cord has been checked and tested by a	•	For additional protection, Sunbeam recommend the
		qualified technician or service person.		use of a residual current device (RCD) with a tripping
	•	Always use your appliance from a power outlet of the		current not exceeding 30mA in the electrical circuit
		voltage (A.C. only) marked on the appliance.		supplying power to your appliances.
	•	This appliance is not intended for use by persons	•	Do not immerse the appliance in water or any other
		(including children) with reduced physical, sensory		liquid unless recommended.
		or mental capabilities, or lack of experience and	•	Appliances are not intended to be operated
		knowledge, unless they have been given supervision		by means of an external timer or separate remote
		or instruction concerning use of the appliance by a		control system.
		person responsible for their safety.	•	This appliance is intended to be used in household
	•	Children should be supervised to ensure that they do		and similar applications such as: staff kitchen areas
		not play with the appliance.		in shops, offices and other working environments;
	•	The temperature of accessible surfaces may be high		farm houses; by clients in hotels, motels and other
		when the appliance is operating.		residential type environments; bed and breakfast
	•	Never leave an appliance unattended while in use.		type environments.

If you have any concerns regarding the performance and use of your appliance, please visit www.sunbeam.com.au or contact the Sunbeam Consumer Service Line.

Ensure the above safety precautions are understood.

3

Features of your Food Processor

Processing cover

The processing cover or lid of bowl provides a safety feature to the appliance. The appliance will not operate unless the bowl, cover and large feed pusher are correctly positioned and locked into place.

1,100 watt induction motor

The heavy base houses a powerful 1,100 watt motor. This motor is ideal for high load applications during processing, and provides a

greater starting strength whilst maintaining speed throughout.

START/STOP button

For easy use the START/STOP button starts and stops the operation of the food processor.

Pulse

The control panel includes a Pulse function.

Storage drawer

The unique drawer design enables attachments to be stored conveniently, and safely, within the appliance when not in use.

Non-slip feet

Keeps the food processor secure on the bench top during use.

4

Food Pushers

The food pushers assist in guiding the food through the chute to ensure ingredients hit the blade vertically for best processing results. Three food pushers are included, depending on the size of the chute being used and the size of foods. For thinner foods, use the smaller internal pusher for consistent even slicing. This pusher also doubles as a measuring cup.

Wide Chute

At 14cm’s wide, the extra wide chute eliminates the need to cut most ingredients, to fit into the chute. Guide ingredients through the chute into the selected blades. Additional ingredients can be added during other processing tasks.

Chute Safety Feature

The wide chute pusher provides a safety interlock feature to the appliance. The motor will not operate unless the bowl and lid are correctly locked in position, and the large feed pusher is inserted.

Spindle

Drives all the food processing attachments. The spindle must be in place to operate the food processor.

Processing bowl with handle

Large 2 litre capacity processing bowl.

The handle of the processing bowl includes a patent-pending robust stainless steel interlock that prevents food catching and building up, ensuring easy cleaning.

Cord storage facility

For added convenience the unused cord length can easily be pushed into the base of the processor for storage.

5

Attachments for your Food Processor

1. Universal 's' blade

Stainless steel smooth edged processing blade is designed for cutting, kneading, whisking and emulsifying.

4. Reversible shredding disc - fine and coarse

Ideal control, the reversible stainless steel shredding blades allow for the choice of fine or coarse results.

2. Variable slicing blade

The variable stainless steel slicing blade allows foods to be sliced to a variety of thicknesses, up to 7mm.

5. Reversible grating and shaving disc

Unique to processing is the shaving blade. It does lovely thin flakes, great for parmesan and sweet potato crisps. The alternate side is ideal for hard cheeses and chocolate.

3. Julienne disc

The stainless steel julienne blade is perfect for achieving consistent julienne cut food, perfect for salad, stir fry or garnishing.

6

Using your Food Processor

•Before using your food processor, familiarise yourself with all parts, remove all promotional and packaging materials. Use caution when handling blades, as blades are sharp.

•Wash the processing bowl, processing cover and all attachments in warm water using a mild detergent. Dry each part thoroughly before use.

•Before you assemble the food processor, ensure that the power cord is unplugged.

1.Place the motor base facing you on a dry, level surface.

2.Place the processing bowl onto the motor base, the bowl will only sit correctly on the base when the handle is positioned to the right, see figure 1.

3.Rotate the handle clockwise to lock, as indicated by the graphics on the left side of the motorbase, see figure 2.

Fig 2

4.Position the lid onto the processing bowl. You will notice a marking on the holding lip on the lid, when placing the lid onto the bowl this marking needs to align with the marking on the handle of the bowl. To lock, turn the lid clockwise, as indicated by the arrow, see figure 3.

Fig 1

Fig 3

7

Using your Food Processor continued

Important: If the processing bowl, processing cover and large pusher are not correctly assembled, the food processor will not operate. This is a safety feature.

Using your Food Processor

1.Plug the power cord into a 230-240V AC power outlet and turn the power ‘ON’.

2.Using the START/STOP button on the control panel, press once to start processing.

The Pulse function remains on as long as the Pulse button is pressed down.

Further ingredients can be added whilst the appliance is running by pouring through the medium or small feed tube once the food pusher/s have been removed. Removing the large pusher will stop the motor running.

3.After you have completed processing, press the START/STOP button to stop processing.

Note: For maximum control, load the feed tube before turning on your food processor. Always use the food pusher for more evenly processed foods and never push with your fingers.

Important: The food processor is fitted with a safety thermal cut-out device and will shut off in the event of overload. If this occurs, switch the appliance off and it will automatically reset when cool.

8

Fitting/Using the tools on your Food Processor

Note: All attachments must be firmly attached to the spindle. Always adjust the attachments until you are sure that they are correctly fitted.

Placing the spindle

1.Fit the spindle onto the drive shaft, see figure 4.

3.Place food into the processing bowl.

4.Fit the processing cover to the processing bowl, see figure 3 and place the food pusher in the feed chute.

5.Plug the power cord into a 230-240V AC power outlet and turn the power ‘ON’.

6.Start processing using the START/STOP or Pulse buttons.

7.When processing is complete, remove the spindle and blade from the processing bowl before removing the processed food.

Fig 4

Universal 's' Blade

1.Fit the processing bowl and spindle as detailed previously in figures 1, 2 & 4.

2.Fit the universal 's' blade over the spindle and press firmly into place, see figure 5.

Warning: Use caution, as blades are sharp. Always handle the processing blade by its central plastic section.

Fig 5

9

Fitting/Using the tools on your Food Processor continued

Reversible grating/shaving, shredding and julienne discs

1.Fit the processing bowl and spindle as detailed previously, in figures 1, 2 and 4.

2.Select the 'reversible' disc of your choice – shredding (fine or coarse), grating/shaving or the dedicated julienne disc.

3.Fit the disc over the spindle and press firmly into place, see figure 6.

Warning: Use caution as the blades are sharp.

Variable slicing blade

1.Fit the processing bowl and spindle as detailed previously in figures 1, 2 and 4.

2.Fit the slicing disc over the spindle and press firmly into place, see figure 7.

Fig 7

Fig 6

4.Fit the processing cover to the processing bowl as previously shown in figure 3 and place the food pusher in the feed chute.

5.Plug the power cord into a 230-240V AC power outlet and turn the power ‘ON’.

6.Start processing using the START/STOP button.

7.When processing is complete, remove the disc and spindle from the processing bowl before removing the processed food.

Warning: Use caution as the blades are sharp.

3.Fit the processing cover to the processing bowl as previously shown in figure 3 and place the food pusher in the feed tube.

4.Plug the power cord into 230-240V AC power outlet and turn the power 'ON'.

5.Start processing using the START/STOP button.

6.When processing is complete, remove the disc and spindle from the processing bowl before removing the processed food.
