Classic® ElectricFrywareRange
Instruction/Recipe Booklet
This book covers the use and care of the following Sunbeam Electric Fryware:
FP5500P |
Classic® |
28cm (11”) |
Square Aluminium Metal Frypan |
FP5610P |
Classic® Super Deep |
28cm (11”) |
Square Non-stick Deep Frypan |
FP5900P |
Family Banquet |
38cm (15”) |
Rectangle Non-stick Deep Frypan |
FP5910 |
Classic® Banquet |
38cm (15”) |
Rectangle Non-stick Deep Frypan |
SK4200P |
Classic® Skillet |
25cm (10”) |
Round Non-stick Skillet |
Waiting on Front
Please read these instructions carefully and retain for future reference.
Product featured - FP5900P
Contents
Sunbeam’s Safety Precautions |
1 |
Features of your Sunbeam Fryware |
|
Sunbeam Classic® Frypan – FP5500P |
2 |
Sunbeam Classic® Super Deep Frypan – FP5610P |
4 |
Sunbeam Family Banquet Frypan – FP5900P |
6 |
Sunbeam Classic® Banquet Frypan – FP5910 |
8 |
Sunbeam Classic® Skillet – SK4200P |
10 |
Dupont Teflon Platinum Pro non-stick |
12 |
Temperature setting guide |
13 |
Using your Sunbeam Fryware |
14 |
Cooking with your Sunbeam Fryware |
15 |
Care and Cleaning |
17 |
Recipes |
18 |
Skillet Recipes |
30 |
Sunbeam’s Safety Precautions
SAFETY PRECAUTIONS FOR YOUR
SUNBEAM FRYPAN.
• Use your frypan at least 200mm away from |
• Avoid using on metal surfaces e.g. sink, |
||
|
walls and curtains. |
hotplate. |
|
• Do not immerse the control probe in water. |
• Remove the control probe before cleaning the |
||
• If using a plastic spatula do not leave in |
frypan. |
||
|
cooking vessel when hot. |
• After cleaning the frypan ensure that the |
|
• The frypan must only be used with the control |
control probe Inlet area is completely dry |
||
|
probe provided. |
before using again. |
|
|
|
|
|
|
Sunbeam are very safety conscious when |
• Do not use an appliance for any purpose |
|
|
designing and manufacturing consumer products, |
other than its intended use. |
|
|
but it is essential that the product user also |
• Do not place an appliance on or near a hot gas |
|
|
exercise care when using an electrical appliance. |
||
|
Listed below are precautions which are essential |
flame, electric element or on a heated oven. |
|
|
Do not place on top of any other appliance. |
||
|
for the safe use of an electrical appliance: |
||
|
• Do not let the power cord of an appliance hang |
||
• Read carefully and save all the instructions |
|||
over the edge of a table or bench top or touch |
|||
|
provided with an appliance. |
||
|
any hot surface. |
||
|
|
||
• Always turn the power off at the power outlet |
• For safety reasons and to avoid maintenance |
||
|
before you insert or remove a plug. Remove |
||
|
by unskilled persons, some appliances are |
||
|
by grasping the plug - do not pull on the cord. |
||
|
‘sealed’ using tamperproof screws. Such |
||
|
|
||
• Turn the power off and remove the plug |
appliances should always be returned to the |
||
|
when the appliance is not in use and |
nearest Sunbeam Appointed Service Centre |
|
|
before cleaning. |
for adjustment or repair if required. |
|
• Do not use your appliance with an extension |
• Do not operate any electrical appliance with a |
||
|
cord unless this cord has been checked |
damaged cord or after the appliance has been |
|
|
and tested by a qualified technician or |
dropped or damaged in any manner. If damage |
|
|
service person. |
is suspected, return the appliance to the |
|
• Always use your appliance from a power |
nearest Sunbeam Appointed Service Centre |
||
for examination, repair or adjustment. |
|||
|
outlet of the voltage (A.C. only) marked |
||
|
|
||
|
on the appliance. |
• For additional protection, Sunbeam |
|
• This appliance is not intended for use by |
recommend the use of a residual current |
||
device (RCD) with a tripping current not |
|||
|
young children or infirm persons unless |
||
|
exceeding 30mA in the electrical circuit |
||
|
they have been adequately supervised by a |
||
|
supplying power to your appliances. |
||
|
responsible adult to ensure that they can use |
||
|
|
||
|
the appliance safely. |
• Do not immerse the appliance in water |
|
• Never leave an appliance unattended while |
or any other liquid unless recommended. |
||
|
|||
|
in use. |
|
If you have any concerns regarding the performance and use of your appliance, please visit www.sunbeam.com.au or contact the Sunbeam Consumer Service Line.
Ensure the above safety precautions are understood.
1
Features of your Sunbeam Classic® Frypan – FP5500P
Integrated knob and adjustable steam vent
Allows you to accurately control moisture levels during cooking.
Adjustable lid holder
A stepped catch on the side of the lid enables the lid to be tilted above the frypan, to help maintain the temperature
selected. Both hands are then free for stirring casseroles and stews or for turning steaks. When the lid is in position it acts as a splatter shield. The lid can rest on either of the sides without handles.
Aluminium cooking surface
A durable, multi-purpose cooking surface.
2
1 IS |
|
|
|
0 |
2M |
|
|
|
1 |
M |
|
|
|
|
3E |
|
|
|
9 |
R |
|
|
||
4 |
5 |
6 |
7 |
8 |
|
|
Trigger release control probe
The probe is thermostatically controlled and incorporates an indicator light that switches off automatically when the selected temperature has been reached, it then cycles on and off to indicate that the temperature is being maintained.
High domed lid
Turns your frypan into a compact oven. Ideal for roasts, stews and casseroles.
Control probe inlet
Pan tilt lever
When the lever is in the lowered position the cooking pan is tilted, forcing juices to collect at one end of the pan.
Both hands are then free for basting.
3
Features of your Sunbeam Classic® Super Deep Frypan – FP5610P
Integrated knob & adjustable steam vent
Allows you to accurately control moisture levels during cooking.
Adjustable lid holder
A stepped catch on the side of the lid enables the lid to be tilted above the frypan, to help maintain the temperature selected. Both hands are then free for stirring casseroles and stews or for turning steaks. When the lid is in position it acts as a splatter shield.
Teflon® Platinum Pro™ non-stick surface
Teflon® Platinum Pro™ – enables healthy fat-free cooking and simple, wipe-down cleaning. It features 3 layers of premium non-stick coating for superior scratch resistance, making it up to 10 times more scratch resistant than other single layer coatings. It is so tough it is safe to use with metal utensils.
Extra deep cooking vessel (78mm)
Ideal for the largest roasts, family size meals or liquid based dishes.
4
1 IS |
|
|
|
0 |
2M |
|
|
|
1 |
M |
|
|
|
|
3E |
|
|
|
9 |
R |
|
|
||
4 |
5 |
6 |
7 |
8 |
|
|
Trigger release control probe
The probe is thermostatically controlled and incorporates an indicator light that switches off automatically when the selected temperature has been reached, it then cycles on and off to indicate that the temperature is being maintained.
High domed lid
Turns your frypan into a compact oven. Ideal for roasts, stews, and casseroles.
Control probe inlet
Pan tilt lever
When the lever is in the lowered position the cooking pan is tilted, forcing juices to collect at one end of the pan. Both hands are then free for basting.
Cast-in square element
The square element is completely cast into the heavy duty base providing superior heat distribution.
5
Features of your Sunbeam
Family Banquet Frypan – FP5900P
Integrated knob and adjustable steam vent
Allows you to accurately control moisture levels during cooking.
Teflon® Platinum Pro™ non-stick surface
Teflon® Platinum Pro™ – enables healthy fat-free cooking and simple, wipe-down cleaning. It features 3 layers of premium nonstick coating for superior scratch
resistance, making it up to 10 times more scratch resistant than other single layer coatings. It is so tough it is safe to use with metal utensils.
Adjustable lid holder
A stepped catch on the side of the lid enables the lid to be tilted above the frypan, to help maintain temperatures. Both hands are then free for stirring and turning foods. When the lid is in position it acts as a splatter shield. The lid can rest on either of the sides without handles.
Control probe inlet
Pan tilt lever
6
1 IS |
|
|
|
0 |
2M |
|
|
|
1 |
M |
|
|
|
|
3E |
|
|
|
9 |
R |
|
|
||
4 |
5 |
6 |
7 |
8 |
|
|
Trigger release control probe
The probe is thermostatically controlled and incorporates an indicator light that switches off automatically when the selected temperature has been reached, it then cycles on and off to indicate that the temperature is being maintained.
Metal lid
Turns your frypan into a compact oven. Ideal for roasts, stews and casseroles.
Extra large cooking vessel
The large rectangular frypan (380mm x 292mm) is 78mm deep, ideal for cooking 2 chickens, the largest roast or liquid-based dishes.
Cast-in rectangle element
The rectangle element is completely cast into the heavy duty base providing superior heat distribution.
7
Features of your Sunbeam Classic® Banquet Frypan – FP5910
Integrated knob and adjustable steam vent
Allows you to accurately control moisture levels during cooking.
Teflon® Platinum Pro™ non-stick surface
Teflon® Platinum Pro™ – enables healthy fatfree cooking and simple, wipe-down cleaning. It features 3 layers of premium non-
stick coating for superior scratch resistance, making it up to 10 times more scratch resistant than other
single layer coatings. It is so tough it is safe to use with metal utensils.
Control probe inlet
Pan tilt lever
When the lever is in the lowered position the cooking pan is tilted, forcing
juices to collect at one end of the pan. Both hands are then free for basting.
8
1 IS |
|
|
|
0 |
2M |
|
|
|
1 |
M |
|
|
|
|
3E |
|
|
|
9 |
R |
|
|
||
4 |
5 |
6 |
7 |
8 |
|
|
Trigger release control probe
The probe is thermostatically controlled and incorporates an indicator light that switches off automatically when the selected temperature has been reached, it then cycles on and off to indicate that the temperature is being maintained.
Glass lid
The clear glass lid allows you to monitor the cookng process without lifting the lid and allowing the heat to escape, ensuring the selected temperature is maintained.
Extra large cooking vessel
The large rectangular frypan (380mm x 292mm) is 78mm deep, ideal for cooking 2 chickens, roasts or liquidbased dishes.
Cast-in rectangle element
The rectangle element is completely cast into the heavy duty base providing superior heat distribution.
9
