Sogo SS-8445R, SS-8445W User guide

manual de instrucciones
instructions for use
Altavoz portátil Bluetooth
Portable Bluetooth Speaker
Precaución: lea y conserve estas importantes instrucciones
Caution: please read and preserve these important instructions
ref. SS-8445R ref. SS-8445W
Manual del usuario
III. Descripción general
Estimado usuario: Muchas Gracias por elegir SS-8445 altavoz Bluetooth. Por
favor, lea atentamente este manual de usuario para utilizar este dispositivo correctamente y llevar su excelente actuación.
I. Aviso
Por favor, almacene y use este producto a temperatura normal.
NO exponga este producto a la lluvia o la humedad.
NO jugar con este producto ni tirarlo hacia arriba como
una pelota y así evitar que se caiga y se dañe.
• NO desmontar, reparar o modicar el producto.
Como es con batería de litio incorporada, no lo coloque
en el fuego para evitar el peligro.
II. Tipo Recordatorio
1 Para ampliar la vida de servicio del altavoz, y su salud
física y mental, por favor, no escuchar música en gran volumen durante un largo tiempo para evitar daños en los oídos.
2 Cuando algo va mal con el altavoz, por favor, apague
inmediatamente el interruptor de alimentación, desenchufar la USB, para evitar el daño a la altavoz y las demás partes de altavoz.
3 Escasez de energía afectará la distancia de Bluetooth o
Bluetooth puede desconectarse fácilmente, para evitar eso cargue en el tiempo.
español english
III. Descripción general
Encendido apagado
USB 5V3.5mm
Aux in
IV. Características
Modelo: SS-8445
1. Altavoz portátil Bluetooth para reproducir música desde su ordenador, smartphone, tablet o cualquier otro dispositivo compatible con Bluetooth.
2. Entrada auxiliar para conectar los altavoces a los ordenadores y reproductores de mp3 que no tienen Bluetooth
3. Bluetooth V3.0 + EDR (A2DP) HFP
4. Alta calidad de sonido con bajos potentes.
5. Potencia de salida: 3W
6. Impedancia: 4Ω
7. R. frecuencia: 90Hz-20kHz
8. S / N Ratio: 80dB
9. Batería recargable de Li-polímero 300mAh – 5 horas de música sin parar - se puede cargar mediante USB conectándose al ordenador o adaptador de corriente.
10. Dimensión: 55 * 58 * 58 mm – Peso: 130 gm
11. Accesorios: 2 en 1 Cable del USB con AUX y Manual de instrucciones.
V. Lista de embalaje
1. 1* Altavoces
2. 2 en 1 Cable del USB con AUX
3. Instrucciones
VI. Funciones común
Inicio: Al encender, la luz azul comienza a parpadear.
Conexión Bluetooth: Cuando se arranca el altavoz,
la luz azul comienza a parpadear al mismo tiempo. En ese momento, encienda el dispositivo Bluetooth y, a continuación, empareja los dos dispositivos Bluetooth. SS-8445 se detendrá automáticamente si no se encuentra ningún dispositivo Bluetooth en menos de 5 minutos, con
el n de ahorrar energía.
Sugerencia: Si la conexión falla, por favor, apague
el altavoz y reiniciar o cargue, ya que tal vez no tiene
suciente potencia.
AUX fuente: Inserte el cable (2 en 1) al puerto USB del
SS-8445 y el otro extremo al PC o reproductor de mp3/ mp4. La musica suena en el altavoz. El volumen está controlado por el reproductor y no por los altavoces.
Carga rápida: En estado apagado, inserte el cable micro USB en la ranura correspondiente del aparato y el otro extremo en el puerto USB del PC o del cargador USB para iniciar la carga. Cuando está totalmente cargada la
español english
batería, el indicador rojo se apaga.
VII. Compatibilidad
Dispositivo equipado con Bluetooth 3.0 o una versión superior, tales como el IPAD, IPHONE (la segunda generación y el IPHONE con IPHONE 3.1 software actualizado), el IPOD TOUCH, MAC con BLUETOOTH, y la mayoría de teléfonos inteligentes o equipo compatible con BLUETOOTH.
• Bluetooth 3.0 incluye: A2DP y AVRCP, HFP
VIII. Solución de Problemas
Fenómeno Problema
Fallo en la conexión y en el emparejamiento
El sonido es bajo o distorsio­nada
Música discon­tinua
El indicador de modo de Blue­tooth no está encendido
español english
Solución de Problemas
1.Compruebe si la caja acústica está en estado de búsqueda, o bien, reinicie.
2.Los alrededores son muchos equipos
Bluetooth, que hace que la dicultad de
la búsqueda. Por lo tanto, cierre el otro equipo Bluetooth.
1.Compruebe el volumen del equipo Bluetooth y ajustar el volumen.
2.La potencia de la batería es insu­ciente, cargue.
Si la distancia de la conexión del sonido es superado, o, si hay algun obstáculo eléctrico entre el sonido y el equipo Bluetooth.
1.Indica que la energía de la batería
no es suciente. Por favor, inténtelo de
nuevo después de la carga.
2.Reinicie la caja acústica.
Instruction Manual
Dear user, Thank you very much for choosing SS-8445 Bluetooth speaker.
Please read this user manual carefully in order to operate this device correctly and bring its excellent performance.
I. Notice
Please store and use this product at normal temperature;
DO NOT expose this product to rain or damp;
DO NOT toss this product and prevent it from falling and being
damaged;
DO NOT disassemble, repair and modify this product;
As it is inbuilt with lithium battery, DO NOT place it in the re to
avoid danger.
II. Kind Reminder
1, To extend the speaker‘s service life, and your physical
and mental health, please don't listen to music under big volume for a long time to avoid hearing damage.
2, When something goes wrong with the speaker, please
immediately shut off the power switch, plug off the USB, to prevent the speaker and its other parts from getting damaged.
3, Power shortage will affect Bluetooth distance or Bluetooth
can get disconnected easily, please charge in time.
music – can be charged using USB connected to computer or power adaptor.
10. Dimension: 55*58*58 mm - Unit net weight: 130g
11. Accessories: 2 in 1 USB cable with Aux and Instruction manual.
V. Packing List
1. Speaker *1
2. 2 in 1 USB cable with Aux
3. IM*1 piece
VI. Common Functions
Start: Turn on the sound box. It would enter the bluetooth
mode and the blue light begins to icker.
Bluetooth connection: When the power is switched
on, the blue light begins to icker at the same time, the
speaker give off “du-du”. At this moment, turn on the Bluetooth device and pair both the Bluetooth devices. SS- 8445 will automatically stop if no Bluetooth device is found within 5 minutes, to save the power. Tip: If the connection fails, please turn off the speaker and
restart it or please charge it as there maybe no sufcient
power. AUX source: Insert 2 in 1 cable into the USB port on SS- 8445 and the other side audio port on PC or mp3/mp4 player. The player begins to play. The sound box will start the music. The volume, the songs are freely controlled by the player and not by the speakers. Quick charge: Charge in power-off state. Insert the attached USB power cable with the micro USB end into the USB power port of SS-8445 and the other end into the USB port of PC or the USB charger to start charging. When the charging is over, the red indicator will be off.
III. General Description
Switch On / Off
USB 5V3.5mm
Aux in
IV. Features
• Model: SS-8445
1. Portable Bluetooth Speaker to play music from your computer, smartphone, tablet or any other Bluetooth enabled device.
2. Aux in jack to connect the speakers to Non-Bluetooth computers and mp3 players.
3. Bluetooth V3.0 + EDR (A2DP) HFP
4. Clear sound with powerful bass.
5. Power Output 3W
6. Impedence: 4Ω
7. R. Frequency 90HZ-20KHZ
8. S/N Ratio 80db
9. Built in Li-polymer battery 300mAh – 5 hours of nonstop
español english
music – can be charged using USB connected to computer or power adaptor.
10. Dimension: 55*58*58 mm - Unit net weight: 130g
11. Accessories: 2 in 1 USB cable with Aux and Instruction manual.
V. Packing List
1. Speaker *1
2. 2 in 1 USB cable with Aux
3. IM*1 piece
VI. Common Functions
Start: Turn on the sound box. It would enter the bluetooth
mode and the blue light begins to icker.
Bluetooth connection: When the power is switched
on, the blue light begins to icker at the same time, the
speaker give off “du-du”. At this moment, turn on the Bluetooth device and pair both the Bluetooth devices. SS­8445 will automatically stop if no Bluetooth device is found within 5 minutes, to save the power.
Tip: If the connection fails, please turn off the speaker and
restart it or please charge it as there maybe no sufcient
power.
AUX source: Insert 2 in 1 cable into the USB port on SS-
8445 and the other side audio port on PC or mp3/mp4 player. The player begins to play. The sound box will start the music. The volume, the songs are freely controlled by the player and not by the speakers.
Quick charge: Charge in power-off state. Insert the
attached USB power cable with the micro USB end into the USB power port of SS-8445 and the other end into the USB port of PC or the USB charger to start charging. When the charging is over, the red indicator will be off.
VII. Compatibility
• Device equipped with BLUETOOTH 3.0 or higher version,
such as the IPAD, IPHONE (the second generation and IPHONE with updated IPHONE 3.1 software), IPOD TOUCH, MAC with BLUETOOTH, and majority of smart phone or computer support BLUETOOTH.
• Bluetooth 3.0 including agreements as A2DP, AVRCP,
HFP
10
español english
VIII. Troubleshooting
Phenomenon Problem
Failure in connection and pairing
The sound is low or distorted
Discontinuous music
The indicator for Bluetooth mode is not on
VIII. Troubleshooting
Phenomenon Problem
Failure in connection and pairing
The sound is low or distorted
Discontinuous music
The indicator for Bluetooth mode is not on
Troubleshooting
1. Inspect whether the sound box is in the status of searching, or, restart it.
2. The surrounding Bluetooth equi­pments are many, which causes the
difculty in searching. So, please close
the other Bluetooth equipments.
1. Inspect the volume of the Bluetooth equipment and adjust the volume.
2. The power of battery is insufcient,
please charge it.
See whether the effective connection distance of sound is exceeded, or, whether there is electrical obstacle bet­ween the sound box and the Bluetooth equipment.
1. It indicates that the power of the
battery is not sufcient. Please try again
after charging it.
2. Restart the sound box.
11
“Eliminacion de Residuos de Equipos Eléctricos y Electrónicos por Parte de Usuarios Particulares en la Union Europea”
Este símbolo en el producto o en su envase indica que no debe eliminarse junto con los desperdicios generales de la casa. Es responsabilidad del usuario eliminar los residuos de este tipo depositándolos en un “punto limpio” para el reciclado de residuos eléctricos y electrónicos. La recogida y el reciclado selectivos de los residuos de aparatos eléctricos en el momento de su eliminación contribuirán a conservar los recursos naturales y a garantizar el reciclado de estos residuos de forma que se proteja el medio ambiente y la salud. Para obtener más información sobre los puntos de recogida de residuos eléctricos y electrónicos para reciclado, póngase en contacto con su ayuntamiento, con el servicio de eliminación de residuos domésticos o con el establecimiento en el que adquirió el producto.
“The Disposal of Electrical and Electronic Equipment Waste Products on the part of Final users in The European Union”
This symbol on the product or on the container indicates that this product cannot be eliminated with the general waste. The user is responsible for eliminating this kind of waste by throwing them away
at a “recycling point” specically for electrical and electronic waste.
Selective collection and electrical equipment recycling contribute to preserve natural resources and warrant waste recycling to protect environment and health. In order to receive further information about electrical and electronic waste collecting and recycling, contact your Local Council, the service of household waste or the establishment where the product was acquired.”
ref. SS-8445R ref. SS-8445W
