INDUCTION HOB SIKP 2000 E2
INDUCTION HOB
Operating instructions
INDUKTIONSKOCHPLATTE
Bedienungsanleitung
IAN 288324
ΕΠΑΓΩΓΙΚΗ ΜΑΓΕΙΡΙΚΗ ΕΣΤΙΑ
Οδηүίες χρήσης
Before reading, unfold the page containing the illustrations and familiarise yourself with all functions of
the device.
Πριν ξεκινήσετε την ανάγνωση, ανοίξτε τη σελίδα με τις εικόνες και εξοικειωθείτε με όλες τις λειτουργίες
της συσκευής.
Klappen Sie vor dem Lesen die Seite mit den Abbildungen aus und machen Sie sich anschließend mit allen
Funktionen des Gerätes vertraut.
GB / IE / NI / CY Operating instructions Page 1
GR / CY Οδηүίες χρήσης Σελίδα 19
DE / AT / CH Bedienungsanleitung Seite 37
Contents
Introduction ...................................................2
Intended use ..................................................2
Package contents ..............................................3
Disposal of the packaging ..................................................3
Description of the appliance/accessories ...........................4
Technical data .................................................4
Safety information .............................................5
Function ......................................................8
Suitable cookware .............................................8
Energy-efficient cooking .........................................9
Setting up .....................................................9
Operation ....................................................9
The hob ................................................................ 9
Use. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Safety cut-off ........................................................... 11
Timer ................................................................. 12
Child lock .............................................................. 12
Cleaning .....................................................13
Storage .....................................................13
Troubleshooting ..............................................14
Disposal of the appliance .......................................15
Notes concerning the EC Declaration of Conformity .................15
Information on this hotplate ....................................16
Kompernass Handels GmbH warranty ............................17
Service ................................................................18
Importer ............................................................... 18
SIKP 2000 E2
GB│IE│NI│CY │ 1 ■
Introduction
Congratulations on the purchase of your new appliance!
You have chosen a modern, high-quality product. These operating instructions are
part of the product. They contain important information about safety, usage and
disposal. Before using the product, please familiarise yourself with all operating
and safety instructions. This appliance may only be used as described and for the
purposes indicated. Please also pass these operating instructions on to any future
owner.
Intended use
This appliance is intended exclusively for heating up foodstuffs and keeping them
warm. This appliance is intended solely for use in private households. Do not use
it for commercial purposes.
Use the appliance only in dry places and never use it outdoors.
WARNING
Danger if not used as intended!
The appliance may be hazardous if used for any other purpose and/or in any
manner than the one intended.
► Use the appliance only for its intended purpose.
► Observe the procedures described in these operating instructions.
NOTE
► Failure to use the appliance for its intended purpose and/or for an alterna-
tive purpose can be dangerous. Use the appliance only for its intended
purpose. Observe the procedures described in these operating instructions.
Claims of any kind for damage resulting from misuse, incompetent repairs,
unauthorised modification or the use of unauthorised spare parts will not
be accepted. The risk shall be borne solely by the user.
■ 2 │ GB│IE│NI│CY
SIKP 2000 E2
Package contents
The appliance is supplied with the following components as standard:
▯ induction hob
▯ operating instructions
1) Remove all parts of the appliance and the operating instructions from the box.
2) Remove all packaging material.
NOTE
► Check the package for completeness and signs of visible damage.
► If the delivery is incomplete or damage has occurred as a result of defec-
tive packaging or during transport, contact the Service hotline (see section
Service).
Disposal of the packaging
The packaging protects the appliance from damage during transport. The packaging materials have been selected for aspects of environmental friendliness and
disposal, and they are therefore recyclable.
Returning the packaging to the material cycle conserves raw materials and
reduces the amount of waste that is generated. Dispose of packaging materials
that are no longer needed in accordance with applicable local regulations.
NOTE
► If possible, preserve the appliance's original packaging during the war-
ranty period so that, in the event of a warranty claim, you can repackage
the appliance properly for return.
SIKP 2000 E2
GB│IE│NI│CY │ 3 ■
Description of the appliance/accessories
Illustrations see fold-out page
Hob
Child lock indicator lamp
On/Off indicator lamp
On/Off button
Child lock button
"+" button
"-" button
TIMER button
MODE button
Display
- "P" indicator lamp
3 "°C" indicator lamp
! Indicator lamp
. MODE indicator lamp button
0 TIMER indicator lamp button
Technical data
Mains voltage 220 - 240 V ~ (AC current), 50/60 Hz
Rated power 2000 W
Protection class
Noise emission level <70 dB (A)
■ 4 │ GB│IE│NI│CY
II
SIKP 2000 E2
Safety information
RISK OF ELECTRIC SHOCK
► Ensure that the power cable never becomes wet or damp
when the appliance is in use. Route the cable so that it
cannot be trapped or damaged in any way.
► Ensure that the mains plug is connected exclusively to a
properly installed, easily accessible mains socket that has
a voltage corresponding to the specifications on the rating
plate. The mains socket must remain easily accessible even
following connection.
► After use, always disconnect the plug from the mains power
socket. When doing so, always take hold of the plug, not the
mains cable.
► Just switching off the appliance is not sufficient, as the appli-
ance is subject to mains voltage as long as the plug is connected to the mains power socket.
► Protect the hob from damage: Do not load it unevenly and
do not allow objects to fall onto it. Do not continue to use
the appliance if either the hob or the housing is damaged. If
this is the case, immediately remove the plug from the mains
power socket and arrange for the appliance to be repaired.
► Arrange for defective power plugs and/or cables to be
replaced as soon as possible by a qualified technician or by
our Customer Service Department to avoid the risk of injury.
► If the surface of the hob is cracked, disconnect the plug from
the mains power socket to avoid receiving an electric shock.
Ensure that the appliance, the power cable and the
power plug are never immersed in water or other fluids.
SIKP 2000 E2
GB│IE│NI│CY │ 5 ■
WARNING! RISK OF INJURY!
► Do not touch the area where a hot cooking pot has just been
standing. Directly after cooking, this area can be very hot.
► This appliance may be used by children of the age of
8 years or more and by persons with reduced physical,
sensory or mental capabilities or lack of experience and/
or knowledge if they are being supervised or have been
instructed with regard to the safe use of the appliance and
have understood the potential risks.
► Children must not play with the appliance.
► Cleaning and user maintenance must not be performed by
children unless they are older than 8 years of age and are
supervised.
► Children younger than 8 years must be kept away from the
appliance and the power cable.
► Do not heat sealed cans or other sealed containers.
Caution! Hot surface!
This symbol warns you not to touch the hob directly
after use. Risk of burns!
HAZARD for and through livestock and pets
► Electrical appliances can cause hazards to livestock and
pets. Furthermore, animals can also damage the appliance
itself. You should therefore keep animals generally away
from electrical appliances.
■ 6 │ GB│IE│NI│CY
SIKP 2000 E2
WARNING! RISK OF FIRE!
► Overheated foodstuffs can start burning! Never leave the
appliance unsupervised while it is in use.
► Additionally, never position the appliance below flammable
objects, especially not below curtains.
► Never heat a securely closed container. Heat expansion can
quickly cause an explosion.
► Never heat an empty container. This would overheat very
quickly, leading to a risk of fire and serious damage to the
hob.
► Do not place any metallic objects, such as kitchen utensils or
cutlery, on the hob. They can become very hot in the induction field.
► Be careful when heating small amounts of oil! Do not use a
high power or temperature level. Otherwise, the oil can burn
and catch fire! Never use water to extinguish burning oil!
Smother the flames by covering them with a suitable lid or
plate.
► Never operate the appliance on a metal table or other
metallic surface. This may heat up and thus cause a fire.
Or the appliance could become irreparably damaged.
► Never operate the appliance on a textile surface such as a
tablecloth.
► Do not operate the appliance using an external time switch
or a separate remote control system.
► The appliance is fitted with a ventilation fan on the bottom.
Always ensure that a free air intake is guaranteed. Leave at
least 10 cm space free around the appliance and 60 cm
above it.
SIKP 2000 E2
GB│IE│NI│CY │ 7 ■
To avoid hazards caused
by electromagnetic fields:
► Maintain a minimum distance of 1 m from appliances that
are sensitive to electromagnetic fields (e.g. screens, clocks,
magnetic storage media, electronic appliances, etc.).
► Medical devices such as pacemakers, hearing aids and
other devices may need to be kept at a greater distance. If
in doubt, consult the manufacturer of the medical device!
Function
Whilst standard hotplates heat up themselves, in an induction hotplate the heat
is created in the base of the cookware. The hob itself does not heat up – it
becomes hot when food is heated up on it in a pan and the heat from the pan
reflects onto the hob (reverse heating).
This is caused by an energy field that generates heat only in magnetically
conductive materials, for example, pans made of iron. In other materials, such as
porcelain, glass or ceramic, the energy field cannot generate any heating effect.
Suitable cookware
Only use cookware that is suitable for induction hobs:
■ Suitable cookware consists of pots and pans with a base made of steel or
cast iron. You can identify these either by means of the markings on the pan
or by ascertaining whether a magnet clings to the base of the pan.
■ Unsuitable cookware is made from any kind of non-magnetic metals, such as
aluminium, copper and stainless steel, as well as non-metallic pots made of
porcelain, glass, ceramic, plastics, etc. If unsuitable cookware is placed on
the hob , "E0" is shown on the display .
■ Thin pan bases are better suited to induction cooking than thick sandwich
bases. The very short response times to modifications in the settings (short
preheating period, rapid and controllable browning) cannot be kept when
pans with thick bases are used.
Only use cookware that is suitable for the size of the hob . This the only way
to ensure the fault-free functioning of the induction hob. The base of the pan may
not be uneven, rather, it must sit flat.
The diameter may not be less than 12 cm to ensure that the energy field has an
effect. Do not use pans with a diameter larger than 26 cm.
■ 8 │ GB│IE│NI│CY
SIKP 2000 E2
Energy-efficient cooking
■ In order to use the energy that is needed for heating food in the most envi-
ronmentally friendly way, we recommend using a pan with a wide diameter
and low height instead of a deep pan with a small diameter. The food is
heated more quickly since the surface area of the pan being heated is greater
with a large diameter. Never use pans with a diameter greater than 26 cm.
■ If you want to heat food quickly, place a lid on the pan. This ensures that less
heat escapes.
Setting up
The appliance requires unrestricted ventilation to prevent overheating. Therefore,
set up the appliance so that ...
– there is an all-round clearance of at least 10 cm, e.g. to the nearest wall,
– at least 60 cm clearance above, e.g. to a suspended wall cabinet.
■ For cooling purposes, the appliance draws in air through openings on the
base. Do not place it on textiles or fleecy surfaces, such as tablecloths.
Operate it only on smooth surfaces.
■ Do not place it adjacent to curtains or other textiles which, due to the airflow,
could cling to the appliance.
■ Do not place it on surfaces which may contain ferric or steel materials. These
may become very hot.
■ Maintain a minimum distance of 1 m from appliances that are sensitive to
electromagnetic fields (e.g. screens, clocks, magnetic storage media, electronic appliances, etc.).
■ Wipe the hobs with a damp cloth to remove soiling sustained during trans-
portation.
Operation
The hob
Power
levels in
watts
SIKP 2000 E2
The hob is provided with 10 power levels:
200 400 600 800 1000 1200 1400 1600 1800 2000
GB│IE│NI│CY │ 9 ■
Use
The hob is provided with 10 temperature levels:
Temperature levels
in °C
NOTE
► Please note that a tone sounds every time you make an entry.
1) Place the cooking pot with contents in the middle of the hob .
CAUTION – PROPERTY DAMAGE!
► The weight of the pan including contents may not be more than 10 kg, as
the hob might be damaged otherwise.
2) Insert the plug into the mains power socket. All indicator lamps illuminate
briefly. "L" is shown on the display if the temperature of the hob is less
than 60 °C.
NOTE
► If cooking has already taken place and the hob still has a temperature
above 60 °C, the display shows "- H -".
3) Press the "on/off" button . The display shows the power level "0"
and the indicator lamp "P" - lights up.
60 80 100 120 140 160 180 200 220 240
NOTES
You may select between cooking with power levels or cooking with temperature settings:
► When you are cooking in the temperature mode, the appliance heats the
cooking pot to the set temperature. If the temperature falls below the set
temperature, the appliance heats up again. The temperature is thus maintained at the desired level.
► By adjusting the "power level", the cooking pot is heated at varying
speeds. The higher the selected power level, the faster the cooking pot is
heated.
► If you do not place a suitable cooking pot on the hob within 60 sec-
onds or if you make some settings, the appliance will switch itself off and
emit a signal tone.
4) Press the "+" or "-" buttons repeatedly until the required power stage is
shown on the display . The MODE indicator lamp .lights up.
■ 10 │ GB│IE│NI│CY
SIKP 2000 E2
NOTE
► Press the MODE button
stage modes. The MODE indicator lamp button .lights up.
– In the temperature stage mode, the preset temperature of 120°C
appears on the display . The "°C" indicator lamp 3lights up.
– In the power stage mode, the preset power level of 1000 watts
appears on the display . The "P" indicator lamp -lights up.
5) To switch the hob off, press the On/Off button
tor lamp goes out.
NOTE
► If no button is pressed within a 2-hour period, the appliance will switch
itself off even if the hob is still working. If you wish to cook a dish for
more than two hours, or to keep food warm for more than two hours, adjust
the desired time using the timer (see the "Timer" section). In this way, times
of up to three hours can be set.
► After switching off in standby mode, the appliance's fans continue to run
for a while to discharge the heat. As long as the hob has a temperature
of more than 60°C, "- H -" will be shown on the display .
6) Pull the mains plug out of the mains socket if you no longer wish to use the
appliance.
CAUTION – PROPERTY DAMAGE!
► Only pull the mains plug out of the mains socket once the fans have
stopped working, as the appliance might be damaged otherwise.
to switch between the temperature or power
. The On/Off indica-
Safety cut-off
SIKP 2000 E2
■ For safety reasons, the pan detection automatically switches the appliance
off (into standby mode) if you remove the cooking pot from the hob or fail
to place a cooking pot on it.
■ If you remove the cooking pot from the hob , a signal tone will sound for
approx. one minute. The appliance will then switch off. If you place the cooking pot back on the hob within 1 minute, the previously defined settings
will be retained.
GB│IE│NI│CY │ 11 ■
Timer
You can preselect a time period between 1 and 180 min., after which the hob
will switch off.
1) Begin the cooking procedure (in power or temperature mode) as explained
2) Press the TIMER
3) Set the desired time.
The display now alternately shows the set power level/temperature and the
time remaining until switch-off.
After the expiration of the time, the cooking area switches off automatically.
You will hear a beep.
Child lock
To prevent unauthorised switching on or setting modification, for instance by
children, this appliance is fitted with a child safety lock.
NOTE
► As soon as you remove the cooking pot from the hob , "E0" will be
shown on the display. After approx. one minute, the "E0" disappears and
the appliance switches itself off. If the hob is still at a temperature
higher than 60°C, "- H -" will appear on the respective display until the
temperature drops below 60°C.
above.
button. "0" appears on the display .
The indicator lamp
If you press the button "+" , the time is increased by 10 minutes. If you
press the button "-" , the time is decreased by 1 minute. The timer will start,
if no entries are made within 5 seconds.
! and the TIMER indicator lamp button 0 light up.
NOTE
► You can also the child safety lock as a safe-wipe function:
Before you wipe the buttons with a damp cloth, activate the child safety
lock. This helps avoid any inadvertent activation of buttons.
■ Press the child lockbutton
hear a signal tone and the child lock indicator lamp will light up.
■ To switch the child lock off press and hold the child lockbutton
for approx. 2 seconds. You will hear a signal tone and the child lock indicator
lamp will go out.
NOTE
► If you activate the child lock while the appliance is working, the appliance
can be switched off but not switched on again.
■ 12 │ GB│IE│NI│CY
to switch the child lock on. You will
SIKP 2000 E2
Cleaning
WARNING – RISK OF ELECTRIC SHOCK!
WARNING – RISK OF INJURY!
CAUTION – PROPERTY DAMAGE!
► Always remove the plug from the mains power socket before cleaning the
appliance.
► Under no circumstances should the appliance or any parts thereof be
immersed in liquids! This could result in a potentially fatal electric shock,
and the appliance could be damaged.
► Never open the appliance housing! Otherwise there is a risk of an electric
shock.
► Allow the appliance to cool down completely before cleaning it.
Risk of burns!
► Do not use solvents or abrasive cleaners. This could damage the hob of
the appliance.
► Do not use aggressive, chemical or abrasive cleaning agents! They could
irreparably damage the surface!
■ Use only a lightly moistened cloth to clean all surfaces and the power cable.
■ Always dry the appliance properly before using it again.
■ You can remove burnt-on soiling on the hob using a scraper specifically
designed for ceramic hobs (available in most shops selling household
equipment).
■ If there is any soiling in the area of the ventilation slots on the base of the
appliance, you can attempt to remove this from the outside using a vacuum
cleaner.
Storage
SIKP 2000 E2
■ Store the cleaned and dried appliance in a dust-free and clean location.
GB│IE│NI│CY │ 13 ■
Troubleshooting
PROBLEM
The appliance is not working. The On/Off indicator
lamp does not light up.
The appliance does not
start the cooking process.
E0 is shown on the
display .
E2 is shown on the
display .
E3 is shown on the
display .
E4 is shown on the
display .
POSSIBLE
CAUSE
The plug is not connected.
The appliance is damaged.
There is no pot on the hob .
The pot is not suitable for
induction hobs.
The child lock is activated.
There is no pot on the hob .
The pot is not suitable for
induction hobs.
The temperature sensor beneath the hob is defective
or there is a short circuit.
The appliance is being supplied with too much voltage
(>270 V).
The appliance is not being
supplied with enough voltage
(<150 V).
POSSIBLE
SOLUTIONS
Connect the appliance to
a mains power socket.
Contact the Customer
Service department.
Place a suitable pot on the
hob .
Use a suitable pot (see
the "Suitable cookware"
section).
Press and hold the child
lock button
approx. 2 seconds.
Place a suitable pot on
the hob .
Disconnect the plug from
the mains power socket
and contact the Customer
Service department.
Check and ensure that the
appliance is connected
to a properly installed
mains power socket with
220–240 V ~, 50/60 Hz.
Check and ensure that the
appliance is connected
to a properly installed
mains power socket with
220–240 V ~, 50/60 Hz.
for
■ 14 │ GB│IE│NI│CY
SIKP 2000 E2
PROBLEM
E5 is shown on the
display .
E6 is shown on the
display .
POSSIBLE
CAUSE
The appliance has overheated.
The electronics have
overheated.
Disposal of the appliance
Never dispose of the appliance in your normal domestic waste.
This product is subject to the provisions of European Directive
2012/19/EU.
Dispose of the appliance through an approved disposal facility or your municipal
waste facility. Please observe the currently applicable regulations. Please contact
your waste disposal centre if you are in any doubt.
POSSIBLE
SOLUTIONS
Disconnect the plug from
the mains power socket
and wait until the appliance has cooled down. If
the problem should persist,
please contact Customer
Services and specify the
error code.
Check to see whether the
fans on the bottom of the
appliance are working
correctly and whether they
can take in a sufficient
volume of air.
Notes concerning the EC Declaration of
Conformity
This appliance complies with the essential requirements and
other relevant provisions of the European Electromagnetic
Compatibility Directive 2014/30/EU, the Low Voltage Directive 2014/35/EU as well as the ErP Directive 2009/125/EC,
Regulation No. 66/2014 Annex I, Sections 2 and 2.2.
The complete original Declaration of Conformity is available
from the importer.
SIKP 2000 E2
GB│IE│NI│CY │ 15 ■
Loading...
