EPILATOR SED 3.7 G3
EPILATOR
Operating instructions
EPILIERER
Bedienungsanleitung
IAN 331147_1907
ΣΥΣΚΕΥΗ ΑΠΟΤΡΙΧΩΣΗΣ
Οδηүίες χρήσης
Before reading, unfold the page containing the illustrations and familiarise
yourself with all functions of the device.
Πριν ξεκινήσετε την ανάγνωση, ανοίξτε τη σελίδα με τις εικόνες και εξοικειωθείτε
με όλες τις λειτουργίες της συσκευής.
Klappen Sie vor dem Lesen die Seite mit den Abbildungen aus und machen
Sie sich anschließend mit allen Funktionen des Gerätes vertraut.
GB / IE / NI /CY Operating instructions Page 1
GR / CY Οδηүίες χρήσης Σελίδα 23
DE / AT / CH Bedienungsanleitung Seite 45
A
9
8
7
1
2
3
4
5
6
B
qw
0
Table of Contents
Introduction ...................................2
Copyright ............................................ 2
Intended Use ..................................2
Items supplied .................................3
Operating Elements .............................4
Technical data .................................5
Safety instructions ..............................7
Mains power operation ....................... 11
Battery operation ............................ 11
Tips and Tricks ............................... 12
Epilation .................................... 13
Cleaning and Care ............................ 15
Storage ..................................... 16
Troubleshooting .............................. 16
Disposal .................................... 17
Ordering spare parts .......................... 18
Kompernass Handels GmbH warranty ........... 19
Service .............................................21
Importer ............................................21
SED 3.7 G3
GB│IE│NI│CY
│
1 ■
Introduction
Congratulations on the purchase of your new appliance.
You have clearly decided in favour of a quality product. These
operating instructions are a part of this product. They contain
important information in regard to safety, use and disposal. Before
using the product, familiarise yourself with all of these operating and
safety instructions. Use the product only as described and only for the
specified areas of application. In addition, pass these documents on,
together with the product, to any future owner.
Copyright
This documentation is copyright protected.
Any copying or reproduction, including as extracts, as well as the
reproduction of images, also in an altered state, is only permitted with
the written authorisation of the manufacturer.
Intended Use
This appliance is intended exclusively for the epilation of human hair
in domestic households. Do not use it for commercial purposes! This
appliance is not intended for any other use or for uses beyond those
mentioned.
Claims of any kind resulting from damage caused by improper
use, incompetent repairs, unauthorised modifications or the use of
non-approved spare parts will not be acknowledged.
The operator alone bears the risk.
■ 2 │ GB
│IE│NI│
CY
SED 3.7 G3
Items supplied
The appliance is supplied with the following components as standard:
■ Epilator
■ Protective cap
■ Massage roller attachment
■ Mains adapter
■ Cleaning brush
■ Storage pouch
■ Operating Instructions
Extract all parts of the appliance from the carton and remove all
packaging material. Check the contents to ensure everything has
been supplied, and for signs of visible damage.
TIPS
► As delivered, the storage pouch is located under the plastic shell
containing the device itself.
► If the delivery is incomplete, or has been damaged due to
defective packaging or transportation, contact the Service
Hotline (see section Service).
SED 3.7 G3
GB│IE│NI│CY
│
3 ■
Operating Elements
Figure A:
Protective cap
Epilator head
Restraint fixtures for epilator head
Travel lock
Speed switch
Control lamps red/green
Socket for mains adapter
LED light
Massage roller attachment
Figure B:
Mains power adapter
- Storage pouch
3 Cleaning brush
■ 4 │ GB
│IE│NI│
CY
SED 3.7 G3
Technical data
Mains adapter
Type ZDM045100BS
E-TEK Electronics Manufactory
Co., Ltd.
Commercial register number:
91440300755667743W
Address:
Manufacturer
Input voltage 100–240 V ∼ (AC), 50/60 Hz
Power consumption 0.2 A
Output voltage 4.5 V
Output current 1.0 A
Output power 4.5 W
Average operating efficiency ≥ 72.81%
Low load efficiency (10%) ≥ 63.77% (reference data)
No-load power consumption 0.1 W max.
Protection class
Polarity
B, 3 Bldg, Tangwupu Industrial
Park, Yanchuan, Songgang
Subdistrict
Bao'an District
Shenzhen, Guangdong 518105
P.R. China
(DC)
(double insulation)
II /
Switched-mode power supply
SED 3.7 G3
GB│IE│NI│CY
│
5 ■
Efficiency class 6
VI
Short-circuit proof safety
transformer
Nominal ambient temperature
(ta)
40°C
IP 20: Protected against ingress
Protection class
of solid foreign objects with a
diameter of > 12.5 mm
Appliance
Input voltage 4.5 V
Power consumption 1.0 A
Rechargeable battery 3.7 V
TIPS
The product is equipped with or
UN 34811
Tel. ____________
supplied with a lithium-ion battery.
700 mAh Li-ion battery
■ 6 │ GB
│IE│NI│
CY
SED 3.7 G3
Safety instructions
RISK OF ELECTRIC SHOCK
► Connect the appliance only to correctly
installed mains power sockets supplying a
current rating of 100 – 240 V ∼, 50/60 Hz.
► In the event of operational malfunction, and
for cleaning, always remove the plug from
the mains power socket.
► To disconnect the power cable, always pull
the plug itself from the mains power socket,
do not pull on the cable.
► Do not kink or crimp the power cable and
place it in such a way as to prevent anyone
from stepping on or tripping over it.
► Ensure that the power cable cannot become
wet or moist during operation. Place it such
that it cannot be squashed or damaged.
► To avoid risks, should the appliance
be damaged discontinue the use of it
immediately.
► Do not use the appliance outdoors.
SED 3.7 G3
GB│IE│NI│CY
│
7 ■
RISK OF ELECTRIC SHOCK
► Do not wrap the power cable around
the appliance and protect it from being
damaged.
► NEVER grasp the appliance, power cable or
plug with wet hands.
► TAKE NOTE! Keep the appliance dry.
► Never use the appliance near water, parti-
cularly not near sinks, baths or other vessels.
The proximity of moisture presents a danger,
even when the appliance is switched off.
After use, always remove the plug from the
mains power socket. As additional protection, the installation of a faulty-current protection unit with an activation power rating
of not more than 30 mA is recommended for
the power circuit in the bathroom. Consult
your electrician for advice.
■ 8 │ GB
│IE│NI│
CY
SED 3.7 G3
WARNING! RISK OF INJURY!
► Do not operate the appliance if it has
sustained a fall or is damaged. Arrange
for the appliance to be checked and/or
repaired by qualified technicians.
► Do not open the housing or attempt to
repair the appliance yourself. Should you
do so, appliance safety can no longer be
assured and the warranty will become void.
Permit only authorised technicians to repair
a defective appliance if repairs should be
necessary.
► Use the appliance only with the supplied
power adapter.
► Charge the appliance only with the supplied
power adapter.
► This appliance may be used by children
aged 8 over and by persons with reduced
physical, sensory or mental capabilities or
lack of experience and knowledge, provided
that they are under supervision or have been
told how to use the appliance safely and are
aware of the potential risks.
SED 3.7 G3
GB│IE│NI│CY
│
9 ■
WARNING! RISK OF INJURY!
► Children must not play with the appliance.
► Cleaning and user maintenance tasks must
not be carried out by children unless they
are supervised.
WARNING! PROPERTY DAMAGE!
Use the appliance only indoors.
■ 10 │ GB
│IE│NI│
CY
SED 3.7 G3
Mains power operation
1) Insert the connector plug of the mains power adapter into the
socket for mains adapter on the appliance. Ensure that the
speed switch is set at “0”.
2) Connect the mains power adapter to a mains power socket.
The control lamp glows red to indicate that the charging
process is active.
The appliance is ready for immediate use.
Battery operation
1) Insert the connector plug of the mains power adapter into the
socket for mains adapter on the appliance. Ensure that the
speed switch is set at “0”.
2) Connect the mains power adapter to a mains power socket.
The control lamp glows red to indicate that the charging
process is active.
As soon as the control lamp glows green the appliance is fully
charged and you can disconnect it from the mains power supply.
NOTICE
► For the initial charging, the appliance requires about 80 minutes
to fully charge.
► First recharge the appliance when the control lamps indicate,
by alternately flashing red and green, that the battery charge
level is low.
SED 3.7 G3
GB│IE│NI│CY
│
11 ■
Tips and Tricks
NOTICE
► Do not use the appliance if …
― You have a sunburn on the specific part of the body.
― Skin irritation or redness is extant.
― You have a skin disease such as, for example, neurodermatitis.
― You have pimples, moles or warts on the specific parts of the
body.
― You have wounds, open sores or raised scars on the specific
parts of the body.
► First test the appliance on a small hidden location to establish the
skin compatibility.
■ The hairs should be between 0.3 cm and 0.5 cm long. Shorter
hairs are not gripped by the tweezers and plucking out longer
hairs is very painful. If needs be, shorten long hair.
■ The skin must be free of grease or cream residues. Otherwise,
the tweezers will stick/soil and the efficiency of the appliance
will be reduced.
■ The skin must be completely dry.
■ The best time for epilation is in the evening after a shower. Then
the skin is somewhat softened, so that the hairs can be plucked
out easily. In addition, the skin can recover overnight, and any
skin reddening will recede.
■ Before epilation, treat the skin with a peeling or a massage
glove. This helps remove dead skin cells, ingrowing hairs
are avoided, and fine hairs stand proud. This enables the
appliance to grip the hairs better.
■ After epilation, nurture the skin with a moisturising lotion or
cream. Ideally, the cream will contain aloe vera or camomile
extracts to soothe and maintain the skin.
■ 12 │ GB
│IE│NI│
CY
SED 3.7 G3
Epilation
If the body parts to be epilated are prepared:
1) Rub your hand once more against the growth direction of the
hairs to be removed. Through this the hairs will be raised so that
they can be better captured by the tweezers.
2) Remove the protective cap from the epilator head .
3) If necessary, fit the massage roller attachment onto the epilator
head . The massage rollers stimulate the skin and thus ensure
a gentler epilation experience.
4) Press the travel lock and slide the speed switch upwards
to the desired speed level:
― Level 1: for sensitive areas (armpits and bikini line)
― Level 2: for legs
During operation, the LED light illuminates the skin area being
depilated.
5) Hold the skin tight with one hand.
6) Place the epilator perpendicular to the skin and, without exerting
any pressure, move it against the direction of the hair growth.
Thereby, the side with the speed switch must face towards you.
Do not make back and forth or circular movements.
Always start anew and pass over the body part to be epilated
several times, so that all of the hair is removed.
NOTICE
► It may be that the hair grows back after a few days. The reason
for this is that these hairs were too short to be removed during
the last epilation session.
SED 3.7 G3
GB│IE│NI│CY
│
13 ■
7) When you are finished with the treatment, place the speed
switch to “0”.
8) Clean the epilator head as described in the section
“Cleaning and Care”.
9) If necessary, remove the massage roller attachment and place
the protective cap on the epilator head .
NOTICE
► Stop using the epilator head immediately if it is damaged!
To order a new epilator head , please contact the Service
Department (see section “Ordering replacement parts”).
To replace the epilator head , please proceed as follows:
― Press the two restraint fixtures together, and at the same
time pull the epilator head upwards.
― Press the new epilator head onto the appliance.
The epilator head must click into place.
■ 14 │ GB
│IE│NI│
CY
SED 3.7 G3
Cleaning and Care
RISK OF ELECTRIC SHOCK
► Before cleaning, disconnect the appliance from the mains power
adapter and the mains power adapter from the main power
supply.
WARNING! PROPERTY DAMAGE!
► NEVER submerse the appliance in water or other liquids!
■ After every use clean the epilator head with the supplied
cleaning brush 3to remove loose hairs.
■ Disinfect the epilator head regularly by spraying and
cleaning it with disinfectant spray.
■ To thoroughly clean the epilator head you can remove it
from the appliance:
― Press the two restraint fixtures together and at the same
time pull the epilator head upwards.
― Clean the epilator head under running water and then allow
it to dry.
― Place the epilator head back onto the appliance. The epila-
tor head must audibly engage.
■ Clean the appliance housing and the mains power adapter
with a moist cloth. If required, use some mild detergent on the
cloth. Ensure that the appliance is completely dry before the
next use.
SED 3.7 G3
GB│IE│NI│CY
│
15 ■
Storage
■ Always protect the epilator head with the supplied
protective cap .
■ Store the appliance, the cleaning brush 3 and the mains
power adapter in the storage pouch -.
■ Store the appliance at a dry and dustfree location.
Troubleshooting
Problem Cause Solution
The appliance
does not function.
The appliance
only runs slowly.
The plucking of
the hairs is very
painful.
Not all hairs are
plucked.
The battery is
drained.
The appliance is defective.
The battery is
drained.
The hairs may be
too long.
It is possible that the
hairs are too short.
You are working
too fast.
Recharge the appliance.
In this case, contact
Customer Services.
Recharge the appliance.
Shorten the hairs to about
0.3 – 0.5 cm. See also the
section "Tips and Tricks".
The hairs should have a
length of 0.3 – 0.5 cm.
Move the appliance more
slowly over your skin.
■ 16 │ GB
│IE│NI│
CY
SED 3.7 G3
Disposal
Never dispose of the appliance or the mains
adapter in your normal domestic waste. This
product is subject to the provision of European
Directive 2012/19/EU WEEE (Waste Electrical
and Electronic Equipment).
Dispose of the appliance and the mains adapter via an
approved disposal company or your municipal waste facility. Observe the currently applicable regulations. In case of
doubt, please contact your waste disposal centre.
NOTE
► The integrated rechargeable battery in this appliance cannot be
removed for disposal. To prevent risks, the removal or replacement of the battery may only be carried out by the manufacturer
or the manufacturer’s customer service department or a similarly
qualified person. When disposing of the appliance, indicate that
the appliance contains batteries.
Your local community or municipal authorities can provide
information on how to dispose of the worn-out product.
The packaging is made of environmentally friendly
materials which you can dispose of at your local recycling
centre.
Dispose of the packaging in an environmentally friendly
manner. Note the labelling on the packaging and separate
the packaging material components for disposal if necessary.
The packaging material is labelled with abbreviations (a)
and numbers (b) with the following meanings: 1–7: Plastics,
20–22: Paper and cardboard, 80–98: Composites.
SED 3.7 G3
GB│IE│NI│CY
│
17 ■
Ordering spare parts
You can order the following replacement parts for product
SED 3.7 G3:
► 1 epilator head
Order the replacement parts via the Service Hotline (see section
„Service“) or simply visit our website at www.kompernass.com.
NOTE
► Have the IAN number of the appliance ready (can be found on
the cover of these operating instructions) when you place your
order.
■ 18 │ GB
│IE│NI│
CY
► 1 massage roller attach-
ment
SED 3.7 G3
Loading...
