Before reading, unfold the page containing the illustrations and familiarise
yourself with all functions of the device.
Käännä ennen lukemista kuvallinen sivu esiin ja tutustu seuraavaksi laitteen
kaikkiin toimintoihin.
Vik ut bildsidan och ha den till hands när du läser igenom anvisningarna och
gör dig bekant med apparatens / maskinens funktioner.
Før du læser, vend siden med billeder frem og bliv bekendt med alle apparatets funktioner.
Klappen Sie vor dem Lesen die Seite mit den Abbildungen aus und machen
Sie sich anschließend mit allen Funktionen des Gerätes vertraut.
GB / IE Operating instructions Page 1
FI Käyttöohje Sivu 17
SE Bruksanvisning Sidan 33
DK Betjeningsvejledning Side 49
DE / AT / CH Bedienungsanleitung Seite 65
Congratulations on the purchase of your new appliance.
You have clearly decided in favour of a quality product. These oper-
ating instructions are a part of this product. They contain important
information in regard to safety, use and disposal. Before using the
product, familiarise yourself with all of these operating and safety
instructions. Use the product only as described and only for the
specifi ed areas of application. In addition, pass these documents on,
together with the product, to any future owner.
Copyright
This documentation is copyright protected.
Any copying or reproduction, including as extracts, as well as the
reproduction of images, also in an altered state, is only permitted
with the written authorisation of the manufacturer.
Intended Use
This appliance is intended exclusively for the epilation of human hair
in domestic households. Do not use it for commercial purposes! This
appliance is not intended for any other use or for uses beyond those
mentioned.
Claims of any kind resulting from damage caused by improper use,
incompetent repairs, unauthorised modifi cations or the use of nonapproved spare parts will not be acknowledged.
The operator alone bears the risk.
2
SED 3.7 C2
Items supplied
The appliance is supplied with the following components as standard:
■ Epilator
■ Mains adapter
■ Cleaning brush
■ Storage pouch
■ Operating Instructions
Extr
act all parts of the appliance fr
packaging material. Check the contents to ensure everything has
been supplied, and for signs of visible damage.
TIPS
► As delivered, the storage pouch is located under the plastic
shell containing the device itself. You must r
cardboard under the plastic shell in order to take the storage
pouch out.
► If the delivery is incomplete, or has been damaged due to
defective packaging or transportation, contact the Service
Hotline (see chapter Warranty and Service).
Disposal of packaging
The packaging protects the appliance against transport damage.
The packaging materials are selected from the point of view of
their environmental friendliness and disposal technology and are
therefore recyclable.
The recirculation of packaging into the material circuit
saves on raw material and reduces generated waste.
Dispose of packaging material that is no longer needed
as per the regionally established regulations .
om the carton and remove all
emove the
GB
IE
SED 3.7 C2
3
Operating Elements
GB
IE
Figure A:
1 Protective cap
2 Epilator head
3 Restraint fi xtures for epilator head
4 Travel lock
5 Speed switch
6 Control lamps red/green
7 Socket for mains adapter
Figure B:
8 Mains power adapter
9 Storage pouch
0 Cleaning brush
Technical data
Mains adapter
TypeZDJ045100EU
Input voltage100 - 240 V ~, 50/60 Hz
Power consumption0.2 A Max.
Output voltage4.5 V
Output current1000 mA
Protection class
Polarity
4
II/
SED 3.7 C2
Device
Input voltage4.5 V
Power consumption1000 mA
GB
IE
Protection class
III/
Safety instructions
RISK OF ELECTRIC SHOCK
► Connect the appliance only to correctly in-
stalled mains power sockets supplying a current
rating of 100 - 240 V ~ / 50/60 Hz.
► The power cable on this appliance cannot be
replaced. In the event of it being damaged
the whole appliance must be disposed of.
► In the event of operational malfunction, and
for cleaning, always remove the plug from the
mains power socket.
► To disconnect the power cable, always pull
the plug itself from the mains power socket,
do not pull on the cable.
► Do not kink or crimp the power cable and
place it in such a way as to prevent anyone
from stepping on or tripping over it.
SED 3.7 C2
5
GB
IE
RISK OF ELECTRIC SHOCK
► Ensure that the power cable cannot become
wet or moist during operation. Place it such
that it cannot be squashed or damaged.
► To avoid risks, should the appliance be dam-
aged discontinue the use of it immediately.
► Do not use the appliance outdoors.
► Do not wrap the power cable around the ap-
pliance and protect it from being damaged.
► NEVER grasp the appliance, power cable or
plug with wet hands.
► TAKE NOTE! Keep the appliance dry.
Never use the appliance near water, particularly not near sinks, baths or other vessels.
The proximity of moisture presents a danger,
even when the appliance is switched off .
After use, always remove the plug from the
mains power socket. As additional protection,
the installation of a faulty-current protection
unit with an activation power rating of not
more than 30 mA is recommended for the
power circuit in the bathroom.
Consult your electrician for advice.
6
SED 3.7 C2
WARNING! RISK OF INJURY!
► Do not operate the appliance if it has sustained
a fall or is damaged. Arrange for the appliance
to be checked and/or repaired by qualifi ed
technicians.
► Do not open the housing or attempt to repair
the appliance yourself. Should you do so, appliance safety can no longer be assured and
the warranty will become void. Permit only
authorised technicians to repair a defective
appliance if repairs should be necessary.
► Use the appliance only with the supplied power
adapter.
► Charge the appliance only with the supplied
power adapter.
► This appliance may be used by children aged 8
over and by persons with reduced physical, sensory or mental capabilities or lack of experience and
knowledge, provided that they are under supervision or have been told how to use the appliance
safely and are aware of the potential risks.
► Children must not play with the appliance.
► Cleaning and user maintenance tasks must
not be carried out by children unless they are
supervised.
GB
IE
SED 3.7 C2
7
GB
WARNING - PROPERTY DAMAGE!
IE
► Use the appliance only indoors.
Mains power operation
1) Insert the connector plug of the mains power adapter 8 into the
socket for mains adapter 7 on the appliance. Ensure that the
speed switch 5 is set at “0”.
2) Connect the mains power adapter 8 to a mains power socket.
The control lamp 6 glows red to indicate that the charging
process is active.
The appliance is ready for immediate use.
Battery operation
1) Insert the connector plug of the mains power adapter 8 into the
socket for mains adapter 7 on the appliance. Ensure that the
speed switch 5 is set at “0”.
2) Connect the mains power adapter 8 to a mains power socket.
The control lamp 6 glows red to indicate that the charging
process is active.
As soon as the control lamp 6 glows green the appliance is fully
charged and you can disconnect it from the mains power supply.
NOTICE
► For the initial charging, the appliance requires about
80 minutes to fully charge.
irst recharge the appliance when the control lamps 6 indi-
► F
cate, by alternately fl ashing red and green, that the battery
charge level is low..
8
SED 3.7 C2
Tips and Tricks
NOTICE
► Do not use the appliance if...
― You have a sunburn on the specifi c part of the body.
― Skin irritation or redness is extant.
― You have a skin disease such as, for example,
neurodermatitis.
ou have pimples, moles or warts on the specifi c parts
― Y
of the body.
― You have wounds, open sores or raised scars on the
specifi c parts of the body.
► First test the appliance on a small hidden location to establish
the skin compatibility.
■ The hairs should be between 0.3 cm and 0.5 cm long. Shorter
hairs are not gripped b
hairs is very painful. If needs be, shorten long hair.
■ The skin must be free of grease or cream residues. Otherwise, the
tweezer
s will stick/soil and the effi ciency of the appliance will be
reduced.
■ The skin must be completely dry.
■ The best time for epilation is in the evening after a shower. Then
the skin is some
out easily. In addition, the skin can recover overnight, and any
skin reddening will recede.
y the tweezers and plucking out longer
what softened, so that the hair
s can be plucked
GB
IE
SED 3.7 C2
9
GB
■ Before epilation, treat the skin with a peeling or a massage glove.
IE
This helps remove dead skin cells, ingrowing hairs are avoided,
and fi ne hairs stand proud. This enables the appliance to grip the
hairs better.
■ After epilation, nurture the skin with a moisturising lotion or
cream. Ideally, the cr
extracts to soothe and maintain the skin.
eam will contain aloe vera or camomile
Epilation
When the appliance is charged and the body part to be epilated is
prepared:
1) Rub your hand once more against the growth direction of the
hairs to be removed. Through this the hairs will be raised so that
they can be better captured by the tweezers.
2) Remove the protective cap 1 from the epilator head 2.
3) Press the travel lock 4 and slide the speed switch 5 upwards to
the desired speed level:
― Level 1: for sensitive areas (armpits and bikini line)
― Level 2: for legs
4)
Hold the skin tight with one hand.
5) Place the epilator perpendicular to the skin and, without e
any pressure, move it against the direction of the hair growth.
Thereby, the side with the speed switch 5 must face towards
you. Do not make back and forth or circular movements.
Always start anew and pass over the body part to be epilated
several times, so that all of the hair is removed.
xerting
10
SED 3.7 C2
NOTICE
It may be that the hair grows back after a few days. The
►
reason for this is that these hairs were too short to be
removed during the last epilation session.
6) When you are fi nished with the treatment, place the speed switch 5
to “0”.
7) Clean the epilator head 2 as described in the section “Cleaning
and Care”.
8) Replace the protective cap 1 on the epilator head 2.
NOTICE
► If the epilator head 2 is damaged, discontinue all further use!
o order a new epilator head 2, please contact the service de-
T
partment (see chapter “Guarantee and service”). Please have
the IAM number ready (see operating manual cover).
To replace the epilator head 2, please pr oceed as follows:
― Press the two restraint fi xtures 3 together and at the
same time pull the epilator head 2 upwards.
― Press the new epilator head 2 onto the appliance.
Ensure that the gears on the epilator head 2 and on
the appliance mesh with each other. The epilator head 2
must audibly engage.
GB
IE
SED 3.7 C2
11
Cleaning and Care
GB
IE
RISK OF ELECTRIC SHOCK
► Before cleaning, disconnect the appliance from the mains
power adapter
main power supply.
WARNING - PROPERTY DAMAGE!
► NEVER submerse the appliance in water or other liquids!
■ After every use clean the epilator head 2 with the supplied
cleaning brush 0 to remov
■ Disinfect the epilator head 2 regularly by spr
it with disinfectant spray.
■ To thoroughly clean the epilator head 2 you can remo
the appliance:
― Press the two restraint fi xtures 3 together and at the same
time pull the epilator head 2 upwards.
Clean the epilator head 2 under running water and then
―
allow it to dry.
― Place the epilator head 2 back onto the appliance. Ensure
that the gears on the epilator head 2 and on the appliance
mesh with each other. The epilator head 2 must audibly
engage.
■ Clean the appliance housing and the mains power adapter 8
with a moist cloth. If required, use some mild deter
Ensure that the appliance is completely dry before the next use.
8 and the mains power adapter 8 from the
e loose hairs.
aying and cleaning
ve it from
gent on the cloth.
12
SED 3.7 C2
Storage
■ Always protect the epilator head 2 with the supplied protective
cap 1.
■ Store the appliance, the cleaning brush 0 and the mains power
adapter
8 in the storage pouch 9.
■ Store the appliance at a dry and dustfree location.
Troubleshooting
ProblemCauseSolution
The appliance
does not function.
The appliance
only runs slowly.
The plucking of
the hairs is very
painful.
Not all hairs are
plucked.
The battery is
drained.
The appliance
is defective.
The battery is
drained.
The hairs may be
too long.
It is possible that the
hairs are too short.
You are working
too fast.
Recharge the
appliance.
In this case, contact
Customer Services.
Recharge the
appliance.
Shorten the hairs to
about 0.3 - 0.5 cm.
See also the section
"Tips and Tricks".
The hairs should
have a length of
0.3 - 0.5 cm.
Move the appliance
more slowly over your
skin.
GB
IE
SED 3.7 C2
13
Disposal of the appliance
GB
IE
To dispose of the appliance in an environmentally friendly manner
you must remove the battery from the appliance.
RISK OF ELECTRIC SHOCK
►
Disconnect the appliance from the mains power supply when
you remo
WARNING - PROPERTY DAMAGE!
► Only remove the battery from the appliance if you want to
dispose of/scrap it! The appliance is defective when y
have removed the battery!
1) Take the epilator head 2 from the appliance.
2) Lift the two internal restraints with a small screwdriver or similar to
the top and press them outwards, so that the side elements of the
appliance can be released.
3) Loosen the two now visible screws. You can then take the housing
apart.
4) Snip the red and black cable that connects the circuit board with
the blue-jacketed battery. You can now remove the battery from
the appliance.
5) Dispose of the battery environmentally friendly. Observe the currently
applicable regulations. In case of doubt, please contact your
waste disposal centre.
ve the battery!
ou
14
SED 3.7 C2
Do not dispose of the appliance in your
normal domestic waste. This product is
subject to the provisions of European
Directive 2012/19/EU.
Dispose of the appliance through an approved disposal centre or at your community waste facility. Observe
the currently applicable regulations. In case of doubt,
please contact your waste disposal centre.
Warranty and Service
The warranty for this appliance is for 3 years from the date of
purchase. The appliance has been manufactured with care and
meticulously examined before delivery.
Please retain your receipt as proof of purchase. In the case of a
warranty claim, please make contact by telephone with our service
department. Only in this way can a post-free despatch for your
goods be assured.
NOTICE
► The warranty applies to material or manufacturing faults
only, not for transpor
tear or for damage to fragile parts.
This appliance is intended solely for domestic, not commercial, use.
If this product has been subjected to improper or inappropriate
handling, abuse, or modifi cations not carried out by one of our
authorised service centres, the warranty will be considered void.
Your statutory rights are not restricted in any way by this warranty.
The warranty period is not extended by repairs made under the
warranty. This applies also to replaced and repaired parts.
t damage, parts subject to wear and
GB
IE
SED 3.7 C2
15
Damages and defects extant at the time of purchase must be
GB
reported immediately after unpacking, resp. no later than two days
IE
after the date of purchase.
Repairs carried out after lapse of the warranty period are subject to
Sydämellinen onnittelumme uuden laitteesi johdosta.
Olet valinnut laadukkaan tuotteen. Käyttöohje on osa tätä tuotetta.
FI
Se sisältää tärkeitä turvallisuutta, käyttöä ja hävittämistä koskevia ohjeita. Tutustu kaikkiin käyttö- ja turvaohjeisiin ennen tuotteen käyttöä.
Käytä tuotetta vain kuvatulla tavalla ja vain mainittuihin käyttötarkoituksiin. Anna myös kaikki asiakirjat edelleen luovuttaessasi tuotteen
eteenpäin.
Tekijänoikeus
Tämä asiakirja on suojattu tekijänoikeuslain mukaisesti.
Kaikenlainen monistaminen tai jälkipainatus, myös osittain, sekä
kuvien toistaminen, myös muokatussa tilassa, on sallittua ainoastaan
valmistajan kirjallisella suostumuksella.
Määräystenmukainen käyttö
Tämä laite on tarkoitettu ainoastaan ihmiskarvojen epilointiin yksityistalouksissa. Älä käytä sitä ammattitarkoituksiin! Muuta tai tämän
ylittävää käyttöä pidetään määräystenvastaisena.
Emme vastaa mistään vahingoista, jotka johtuvat muusta kuin määräystenmukaisesta käytöstä, virheellisistä korjauksista, luvattomasti
suoritetuista muutoksista tai muiden kuin hyväksyttyjen varaosien
käytöstä.
Vastuu on yksin käyttäjän.
18
SED 3.7 C2
Toimituslaajuus
Laite toimitetaan vakiona seuraavin osin:
■ Epilaattori
■ Verkkomuuntaja
■ Puhdistusharja
■ Säilytyspussi
■ Käyttöohje
Ota k
aikki laitteen osat laatikosta ja poista k
Tarkasta toimitus puutteiden ja näkyvien vaurioiden varalta.
OHJEITA
► Säilytyspussi sijaitsee toimituksessa laitteen sisältävän muo-
vikuoren alla. P
ottaa säilytyspussin esiin.
► Jos toimitus on puutteellinen tai havaitset puutteellisen pak-
kauksen tai kuljetuksen aiheuttamia vaurioita, käänny huollon
palvelunumeron puoleen (katso luku Takuu ja huolto).
oista muovikuoren alla oleva pahvi, jotta voit
Pakkauksen hävittäminen
Pakkaus suojaa laitetta kuljetusvaurioilta. Pakkausmateriaalit on valittu
ympäristöystävällisyys ja jätehuoltotekniset näkökohdat huomioiden
ja siksi ne voidaan kierrättää.
asennettuun verkkopistorasiaan, jonka verkkojännite on 100 - 240 V ~ / 50/60 Hz.
► Tämän laitteen virtajohtoa ei voida vaihtaa.
Jos johto vahingoittuu, laite on romutettava.
► Irrota verkkomuuntaja verkkopistorasiasta
toimintahäiriöiden sattuessa ja ennen laitteen
puhdistamista.
► Irrota virtajohto verkkopistorasiasta aina verk-
komuuntajasta, älä koskaan vedä itse johdosta.
► Älä taita tai purista virtajohtoa ja vedä virtajohto
niin, ettei kukaan voi astua sen päälle tai kompastua siihen.
SED 3.7 C2
21
SÄHKÖISKUN VAARA
► Varmista, ettei virtajohto pääse kastumaan tai
FI
kostumaan käytössä. Huolehdi siitä, että johto
ei puristu tai vahingoitu.
► Jos laite on vaurioitunut, älä missään tapaukses-
sa käytä sitä enää, jotta vältyttäisiin vaaroilta.
► Älä käytä laitetta ulkona.
► Älä kiedo virtajohtoa laitteen ympärille ja suojaa
virtajohtoa vaurioilta.
► Älä koske laitteeseen, virtajohtoon tai verkko-
pistokkeeseen koskaan märillä käsillä.
► HUOMIO! Pidä laite kuivana.
Älä käytä laitetta koskaan veden, erityisesti
pesualtaiden, kylpyammeiden ja vastaavien
läheisyydessä. Veden läheisyys aiheuttaa
aina vaaran, vaikka laite ei olisikaan päällä.
Irrota siksi verkkomuuntaja pistorasiasta
aina jokaisen käytön jälkeen. Lisäsuojaksi
suosittelemme, että kylpyhuoneen sähköpiiriin
asennetaan vikavirtasuojalaite, jonka mittauslaukaisuvirta ei ole enempää kuin 30 mA.
Kysy neuvoa sähköasentajaltasi.
22
SED 3.7 C2
VAROITUS! LOUKKAANTUMISVAARA!
► Jos laite putoaa tai vahingoittuu, sitä ei saa
ottaa käyttöön. Anna pätevän huoltopisteen
tarkastaa laite ja tarvittaessa korjata se.
► Laitteen koteloa ei saa avata tai korjata itse.
Jos laitteen kotelo avataan itse, turvallisuus ei
ole taattu eikä takuu ole voimassa. Anna viallinen laite ainoastaan valtuutettujen
ammattihenkilöiden korjattavaksi.
► Käytä laitetta vain mukana toimitetun verkko-
adapterin kanssa.
► Lataa laite vain mukana toimitetulla verkko-
adapterilla.
► Kahdeksan vuotta täyttäneet lapset sekä henkilöt,
joiden fyysiset, aistimukselliset tai henkiset kyvyt
ovat rajalliset, tai joilla ei ole riittävää kokemusta tai tietoa laitteen käytöstä, saavat käyttää
laitetta vain valvonnan alaisena, tai
jos heitä on opastettu laitteen turvalliseen käyttöön, ja he ovat ymmärtäneet laitteen käyttöön
liittyvät vaarat.
► Lapset eivät saa leikkiä laitteella.
► Lapset eivät saa suorittaa puhdistusta ja käyttä-
jähuoltoa ilman valvontaa.
FI
SED 3.7 C2
23
Loading...
+ 58 hidden pages
You need points to download manuals.
1 point = 1 manual.
You can buy points or you can get point for every manual you upload.
