Sharp GL8HS25, GL8PR25, GL8KG25, GL8EG25, GL8HD25 Datasheet

LED Lamp	GL8 25 series

GL8 25 series

2.0 3.2mm, Rectangle Type,

Colored Transparency LED Lamps for Backlight/Indicator

■ Outline Dimensions				(Unit : mm)
				+0 -0.3
			2.0

Protruded resin 0.7MAX		Sunken resin 1.0MAX

3.2		+0
		Colored transparency				2.0-0.3
		4.0

	1.0	(Tie-bar cut)	(5.4)
	0.5±0.1			25.0MIN	0.5±0.1
	(1.0)
					Pin connections
	2.54NOM				1 Anode
					2 Cathode
1	2				Unspecified tolerance:±0.2

■ Absolute Maximum Ratings											(Ta=25˚C)
			Power dissipation	Forward current	Peak forward current	Derating factor		Reverse voltage	Operating temperature	Storage temperature	Soldering temperature
Model No.	Radiation color	Radiation material	P	IF	IFM*1	(mA/˚C)		VR	Topr	Tstg	Tsol*2
			(mW)	(mA)	(mA)	DC	Pulse	(V)	(˚C)	(˚C)	(˚C)
GL8PR25	Red	GaP	48	20	50	0.27	0.67	5	-25 to +85	-25 to +100	260
GL8HD25	Red	GaAsP on GaP	84	30	50	0.40	0.67	5	-25 to +85	-25 to +100	260
GL8HS25	Sunset orange	GaAsP on GaP	84	30	50	0.40	0.67	5	-25 to +85	-25 to +100	260
GL8HY25	Yellow	GaAsP on GaP	84	30	50	0.40	0.67	5	-25 to +85	-25 to +100	260
GL8EG25	Yellow-green	GaP	84	30	50	0.40	0.67	5	-25 to +85	-25 to +100	260
GL8KG25	Green	GaP	84	30	50	0.40	0.67	5	-25 to +85	-25 to +100	260

*1 Duty ratio=1/10, Pulse width=0.1ms

*2 5s or less(At the position of 1.6mm or more from the bottom face of resin package)

■ Electro-optical Characteristics																	(Ta=25˚C)
		Forward voltage		Peak emission wavelength			Luminous intensity		Spectrum radiation bandwidth		Reverse current			Terminal capacitance			Page for
Lens type	Model No.	VF(V)		p	(nm)	IF	V	IF	Δl(nm)	IF	R	(µA)	VR	t	(pF)		characteristics
				l		(mA)	I (mcd)	(mA)		(mA)	I		(V)	C		(MHZ)	diagrams
		TYP	MAX	TYP			TYP		TYP		MAX			TYP
	GL8PR25	2.0	2.4	695		10	1.5	10	100	10	10		4	55		1	®
	GL8HD25	2.0	2.8	635		20	12.0	20	35	20	10		4	20		1	®
Colored	GL8HS25	2.0	2.8	610		20	10.0	20	35	20	10		4	15		1	®
transparency	GL8HY25	2.0	2.8	585		20	12.0	20	30	20	10		4	35		1	®
	GL8EG25	2.1	2.8	565		20	12.0	20	30	20	10		4	35		1	®
	GL8KG25	2.1	2.8	555		20	9.0	20	25	20	10		4	40		1	®

(Notice) ¡In the absence of confirmation by device specification sheets, SHARP takes no responsibility for any defects that may occur in equipment using any SHARP 2 devices shown in catalogs, data books, etc. Contact SHARP in order to obtain the latest device specification sheets before using any SHARP device.

(Internet) ¡Data for sharp's optoelectronic/power device is provided for internet.(Address http://www.sharp.co.jp/ecg/)

LED Lamp Characteristics Diagrams

PR series

Forward Current Derating Curve																Forward Current vs. Forward Voltage(Note)
	60																100																							(Ta=25˚C)
(mA)IF	50															(mA)IF	50
	40																10
Forwardcurrent	20															Forwardcurrent	5.0
																	1.0
	30																0.5
	10
	0																0.1
	-25		0	25		50		75		85	100		125
																	1.0		1.2		1.4				1.6				1.8				2.0			2.2		2.4			2.6
				Ambient temperature Ta(˚C)																						Forward voltage VF(V)
Peak Forward Current Derating Curve																Luminous Intensity vs. Forward Current(Note)
	60																1000																							(Ta=25˚C)
	50																500
(mA)IcurrentforwardPeakFM																intensity(%)luminousRelative	200
	40																100
	30																50
																	20
	20																10
	10																5.0
																	2.0
	0																1.0
																	0.1		0.2		0.5				1				2				5			10		20			50
	-25		0	25		50		75		85	100		125
				Ambient temperature Ta(˚C)																					Forward current IF(mA)

Luminous Intensity vs. Ambient Temperature(Note)

(Ta=25˚C)

1000

	500
intensity(%)	50
	100
luminous
Relative	10
	5.0
	1.0

-20	0	20	40	60	80	100	120
		Ambient temperature Ta(˚C)

Duty Ratio vs. Peak Forward Current

(Ta=25˚C)

		500
	IFM(mA)	200
		100
	current	50
	forward
		20
	Peak	10
		5.0

2.0

1.0

1/50

1/20

1/10

1/5

1/2

1

Duty ratio DR

HD series

Forward Current Derating Curve																Forward Current vs. Forward Voltage(Note)
	60																100															(Ta=25˚C)
(mA)IF	50															(mA)IF	50
																	10
	40
currentForward																currentForward	5.0
	20																1.0
	30																0.5
	10
																	0.1
	0
																	1.0		1.2		1.4		1.6		1.8		2.0		2.2		2.4		2.6
	-25		0	25		50		75		85	100		125
				Ambient temperature Ta(˚C)																			Forward voltage VF(V)

Luminous Intensity vs. Ambient Temperature(Note)

(Ta=25˚C)

1000

	500
intensity(%)	50
	100
luminous
Relative	10
	5.0
	1.0

-20	0	20	40	60	80	100	120
		Ambient temperature Ta(˚C)

Peak Forward Current Derating Curve																Luminous Intensity vs. Forward Current(Note)
	60																1000																						(Ta=25˚C)
	50																500
(mA)IcurrentforwardPeakFM																intensity(%)luminousRelative	200
	40																100
	30																50
																	20
	20																10
	10																5.0
																	2.0
	0																1.0
																	0.1		0.2		0.5			1				2		5			10				20		50
	-25		0	25		50		75		85	100		125
				Ambient temperature Ta(˚C)																					Forward current IF(mA)

Duty Ratio vs. Peak Forward Current

(Ta=25˚C)

		500
	IFM(mA)	200
		100
	current	50
	forward
		20
	Peak	10
		5.0

2.0

1.0

1/50

1/20

1/10

1/5

1/2

1

Duty ratio DR

Note)Characteristics shown in diagrams are typical values. (not assurance value)
