ILME CXF-4/2 Data Sheet

Part number

CXF 4/2

Product description
Model
Version
Series
Product type
Family
Size

N. of poles
Auxiliary poles

Technical data
Current
Voltage
Rated impulse withstand

voltage
Pollution degree
Wire cross-section
AWG size
Operating temperature range

(min, max)
Contact type
Mating cycles

IP degree of protection
Further technical details

Characteristics according to
EN 61984

Insulation resistance
Rated voltage according to

UL/CSA
UL 94 flammability rating
Weight

female insert
screw terminal connections
CX
with female contacts
CLASS inserts
size "77.27"

4 poles +
2 poles (16A max - 400V/6kV/3)

80 A (A.C. and D.C.)
690 V

8kV
3

4,00 mm² - 16,00 mm²
12 - 6

-40°C … +125°C
silver plated

≥ 500
IP20 without enclosure; IP65/IP66/IP67/IP68 with

enclosure

80A 690V 8kV 3 (aux: 16A 400V 6kV 3)
≥ 10 GΩ
600V
V-0

112,00 g

Brief description:

female insert, 4 poles + PE, screw terminal connections, 80A 690V, (2 poles (16A
max - 400V/6kV/3)), 8kV, 3, silver plated, size "77.27", CLASS insert series

Approvals / Standards
Reference standard

Quality mark
Conformity

General ordering information
EAN13 code
Tariff number
Country of origin
ETIM classification
Packaging Information
Packaging length
Packaging height
Packaging width
Packaging weight
Packaging volume
Packaging description
Packaging quantity
Packaging EAN code
Sub-packaging weight
Sub-packaging description
Sub-packaging quantity
Sub-packaging EAN barcode

EN 61984 (2001-11)

EAC

CQC, CE

8015747042338
85369095
Made in EU (IT)
EC000438

245,00 mm
165,00 mm
215,00 mm
3,36 kg
8,69 dm³
Carton box
30 Pcs
8015747191845
0,56 kg
Carton
5 Pcs
8015747042345

Part number

CXF 4/2
