User
Refrigerator-Freezer
HB16FMAA
HB16FBAA
HB16FMAAA
HB16FBAAA
GB
Thank You |
GB |
Thank you for purchasing a Haier Product.
Please read these instructions carefully before using this appliance. The instructions contain important information which will help you get the best out of the appliance and ensure safe and proper installation, use and maintenance.
Keep this manual in a convenient place so you can always refer to it for the safe and proper use of the appliance.
If you sell the appliance, give it away, or leave it behind when you move house, make sure you also pass this manual so that the new owner can become familiar with the appliance and safety warnings.
Legend
Warning – Important Safety information
General information and tips
Environmental information
Disposal
Help protect the environment and human health. Put the packaging in applicable containers to recycle it. Help to recycle waste of electrical and electronic appliances. Do not dispose appliances marked with this symbol with the household waste. Return the product to your local recycling facility or contact your municipal office.
WARNING!
Riskofinjuryorsuffocation!
Refrigerants and gases must be disposed of professionally. Ensure that the tubing of the refrigerant circuit is not damaged before being properly disposed of. Disconnect theappliancefromthemainssupply.Cutoffthemainscableanddisposeofit.Remove the trays and drawers as well as the door catch and seals, to prevent children and pets to get closed in the appliance.
2
GB
Content
1- Safety information..................................................................................................................... |
.4 |
2- Intended use................................................................................................................................ |
.8 |
3- Product description................................................................................................................... |
.9 |
4- Control panel.............................................................................................................................. |
10 |
5- Use................................................................................................................................................ |
11 |
6- Energy saving tips...................................................................................................................... |
19 |
7- Equipment................................................................................................................................... |
20 |
8- Care and Cleaning..................................................................................................................... |
23 |
9- Troubleshooting......................................................................................................................... |
25 |
10Installation................................................................................................................................. |
28 |
11Technical Data......................................................................................................................... |
31 |
12Customer Service................................................................................................................... |
32 |
3
1- Safety information
GB
Beforeswitchingontheapplianceforthefirsttimereadthefollowing safety hints!:
WARNING!
Beforefirstuse
Make sure there is no transport damage.
Remove all packaging and keep out of children´s reach.
Wait at least two hours before installing the appliance in order to ensuretherefrigerantcircuitisfullyefficient.
Handle the appliance always with at least two persons because it is heavy.
Installation
The appliance should be placed in a well-ventilated place. Ensure a space of at least 20 cm above and 10 cm around the appliance.
Never place the appliance in a damp area or location where it might be splashed with water. Clean and dry water splashes and stains with a soft clean cloth.
Do not install the appliance in direct sunlight or in the near of heat sources(e.g. stoves, heaters).
Install and level the appliance in an area suitable for its size and use.
Keep ventilation openings in the appliance or in the in-built structure clear of obstruction.
Make sure that the electrical information on the rating plate agrees with the power supply. If it does not, contact an electrician.
The appliance is operated by a 220-240 VAC/50 Hz power supply. Abnormal voltage fluctuation may cause the appliance to fail to start, or damage to the temperature control or compressor, or there may be an abnormal noise when operating. In such case, an automatic regulator shall be mounted.
Use a separate earthed socket for the power supply which is easy accessible. The appliance must be earthed.
Only for UK: The appliance’s power cable is fitted with 3-cord (grounding) plug that fits a standard 3-cord (grounded) socket. Never cut off or dismount the third pin (grounding). After the appliance is installed, the plug should be accessible.
Do not use multi-plug adapters and extension cables.
Ensure that the power cable is not trapped by the refrigerator. Do not step on the power cable.
Do not damage the refrigerant circuit.
4
GB
1- Safety information
WARNING!
Daily use
This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved.
Keep away children under 3 years of age from the appliance unless they are constantly supervised.
Children shall not play with the appliance.
Ifcoolgasorotherinflammablegasisleakinginthevicinityofthe appliance, turn off the valve of the leaking gas, open the doors and windows and do not unplug a plug in the power cable of the refrigerator or any other appliance.
Notice that the appliance is set for operation at a specific ambient range between 10 and 43°C. The appliance may not work properly if it is left for a long period at a temperature above or below the indicated range.
Do not place unstable articles (heavy objects, containers filled with water) on top of the refrigerator, to ovoid personal injury caused by falling or electric shock caused by contact with water.
Do not pull on the door shelves. The door may be pulled slant, the bottle rack, may be pulled away, or the appliance may topple.
Open and close the doors only with the handles. The gap between the doors and between the doors and the cabinet is very narrow. Do not extend your hands in these areas to avoid pinching your fingers. Open or close the refrigerator doors only when there are no children standing within the range of door movement.
Donotstoreoruseinflammable,explosiveorcorrosivematerials in the appliance or in the vicinity.
Do not store medicines, bacteria or chemical agents in the appliance. This appliance is a household appliance. It is not recommended to store materials that require strict temperatures.
Never store liquids in bottles or cans (besides high percentage spirits) especially carbonated beverages in the freezer, as these will burst during freezing.
Checktheconditionoffoodifawarminginthefreezerhastakenplace.
5
1- Safety information
GB
WARNING!
Daily use
Do not set unnecessarily low temperature in the refrigerator compartment. Minus temperatures may occur at high settings. Attention: Bottles can burst.
Do not touch frozen goods with wet hands (wear gloves). Especially do not eat ice lollies immediately after removal from the freezer compartment. There is the risk to freeze or the formation of frost blisters. FIRST aid: keep immediately under running cold water. Do not pull away!
Do not touch the inside surface of the freezer storage compartment when in operation, especially with wet hands, as your hands may freeze onto the surface.
Unplug the appliance in the event of a power interruption or before cleaning. Allow at least 5 minutes before restarting the appliance, as frequent starting may damage the compressor.
Do not use electrical devices inside the food storage compartments of the appliance, unless they are of the type recommended by the manufacturer.
Maintenance / cleaning
Make sure children are supervised if they carry out cleaning and maintenance.
Disconnect the appliance from the electrical supply before undertaking any routine maintenance. Allow at least 5 minutes before restarting the appliance, as frequent starting may damage the compressor.
Hold the plug, not the cable, when unplugging the appliance.
Do not scrape off frost and ice with sharp objects. Do not use sprays, electric heaters like heater, hair dryer, steam cleaners or other sources of heat in order to avoid damage to the plastic parts.
Do not use mechanical devices or other means to accelerate the defrosting process, other than those recommended by the manufacturer.
If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or similarly qualified persons in order to avoid a hazard.
Do not try to repair, disassemble or modify the appliance by yourself. In case of repair please contact our customer service.
6
GB
1- Safety information
WARNING!
Maintenance / cleaning
Eliminate the dust on the back of the unit at least once in the year toavoidhazardbyfire,aswellasincreasedenergyconsumption.
Donotsprayorflushtheapplianceduringcleaning.
Do not use water spray or steam to clean the appliance.
Do not clean the cold glass shelves with hot water. Sudden temperature change may cause the glass to break.
Refrigerant gas information
WARNING!
The appliance contains the flammable refrigerant ISOBUTANE
(R600a). Make sure the refrigerant circuit is not damaged during transportation or installation. Leaking refrigerant may cause eye injuries or ignite. If a damage has occurred, keep away open fire sources, thoroughly ventilate the room, do not plug or unplug the power cords of the appliance or any other appliance. Inform the customer service.
In case of eyes get into contact with the refrigerant, rinse immediately it under running water and call immediately the eye specialist.
CAUTION!
When you close the door, the vertical door beam on the left door should be bent inside (1).
If you try to close the left door and the vertical door beam is unbent (2), you should bend it firstly, otherwise the door beam will hit the fixing shaft or right door. Thus a damage to the door beam or a leak will occur.
There is a heating thread inside the vertical door beam. The temperature of the surface will rise a little, which is normal and won´t affect the function of refrigerator.
1 |
2 |
7
2- Intended use |
GB |
2.1 Intended use
This appliance is intended for cooling and freezing food. It has been designed exclusively for use in dry-interior house-holds. It is not intended for commercial or industrial use.
Changes or modifications to the device are not allowed. Unintended use may cause hazards and loss of warranty claims.
2.2 Accessories
Check the accessories and literature in accordance with this list (Fig.:2.2):
2.2
|
|
|
|
3 spacers |
Energy- |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
||
|
|
|
|
|
|
|
|
|
||
|
|
|
|
|
|
|
|
|
||
|
|
|
|
|
|
|
|
|
||
|
|
|
|
|
|
|
|
|
||
|
|
|
|
|
|
|
|
|
||
|
|
|
|
|
|
|
|
|
||
|
|
|
|
|
|
|
|
|
||
|
|
|
|
|
|
|
|
|
||
|
|
|
|
|
|
|
|
|
||
Ice cube tray |
Egg tray |
Warranty |
User |
|||||||
|
|
|
|
|
lable |
card |
manual |
|||
8
GB
3- Product description
Notice:Differences
Due to technical changes and different models, some of the illustrations in this manual maydifferfromyourmodel.
Picture of appliance (Fig. 3)
|
1 |
3 |
|
|
|
2 |
|
|
3 |
|
|
4 |
|
4 |
A |
|
7 |
|
8 |
|
|
|
|
5 |
|
|
6 |
|
|
|
|
9 |
B |
|
|
|
|
10 |
|
|
11 |
A: Refrigerator compartment
1Refrigerator LED lamp
2Door beam
3Rating plate
4Door rack
5My Zone drawer glass cover
6My Zone drawer
7Glass shelf
8O.K.-temperature indicator (optional)
B: Freezer compartment
9Upper freezer storage drawer
10Lower freezer storage drawer
11Adjustable feet
9
4- Control panel
Control panel (Fig. 4)
4 |
|
|
|
|
a |
A |
|
|
|
|
b |
B |
|
|
|
|
c |
C |
|
|
|
|
d1 |
D |
3 Sec. Holiday |
d2 |
|
||
E |
|
|
Super-Cool |
e |
|
|
|
|
F |
Super-Frz. |
f |
|
|
|
|
|
g |
G |
|
|
10 |
|
|
GB
Keys:
AFridge temperature setting
BFreezer temperature setting
CMyZone setting
D FuzzymodeandHolidayfunctionon/off E Super-Coolfunctionon/off
F Super-Freezefunctionon/off
G Panel lock/unlock
Indicators:
aTemperature fridge compartment
bTemperature freezer compartment
cMy Zone function
d1 Holiday function
d2 Fuzzy mode
eSuper-Cool function
fSuper-Freeze function
gPanel lock
GB
5- Use
5.1Beforefirstuse
Remove all packaging materials, keep them out of children`s reach and dispose them in an environmentally friendly manner.
Clean the inside and outside of the appliance with water and a mild detergent before putting any food in it.
After the appliance has been levelled and cleaned, wait for at least 2 hours before connecting it to the power supply. See Section INSTALLATION.
Precool the compartments at high settings before loading with food. The function Super-Freeze helps to cool down the freezer compartment quickly.
The refrigerator temperature and freezer temperature are automatically set to 5° C and -18° C respectively. These are the recommended settings. If desired, you can change these temperatures manually. Please see MANUAL ADJUSTING MODE.
5.2 Sensor keys
The buttons on the control panel are sensor keys, which already respond when lightly touchedwiththefinger.
5.3Switchon/offtheappliance
The appliance is in operation as soon as it is connected to the power supply.
When the appliance is powered on for the first time, the actual refrigerator and freezer temperatures(“a”and“b”)aredisplayed.Thedisplaywillflash.Ifthedoorsarecloseditwill switchoffafter30seconds.Maybethepanellockisactive.
Notice: Presettings
The appliance is preset to the recommended temperature of 5°C (refrigerator) and - 18°C (freezer). Under normal ambient condition you need not to set a temperature.
The presetting function for the My Zone drawer is 0°C Fresh.
When the appliance is switched on after disconnection from the main power supply, it may take up to 12 hours for the correct temperatures to be reached.
Empty the appliance before switching off. To switch off the appliance,pull the power cord outoffthepowersocket.
5.4 Standby-mode
The display screen turns off automatically 30 seconds after pressing a key. The display will be automatically locked. It lights up automatically by touching any key or opening the door/ drawer .
11
5- Use
GB
5.5 |
5.5 Lock/unlock panel
Notice: Panel lock
The control panel is automatically blocked against activation if 30 seconds no key is touched. For any settings the control panel must be unlocked.
Touch key “G” for 3 seconds to block all panel elements against activation (Fig. 5.5). The related indicator “d” is now displayed.
For unlocking touch again the key.
5.6 Door opening alarm
When one of the refrigerator doors is opened for more than 1 minute, the door opening alarm will sound. The alarm can be silenced by closing the door. If the door is left open for more than 7 minutes, the light inside the refrigerator and control panel illumination will automaticallyswitchoff.
5.7 Select the working mode
You may need to select one of the following two ways to set the appliance:
5.7.1-1 |
5.7.1-2 |
|
3 Sec. Holiday |
3 Sec. Holiday |
|
5.7.1 Fuzzy mode
If you do not have any special requirements, we recommend that you use fuzzy mode :
In the Fuzzy mode, the appliance can automatically adjust the temperature setting according to the ambient temperature and temperature change in the appliance. This function is totally hand free.
1.Unlock the panel by touching key “G” if it is locked (Fig. 5.5).
2.Touch key “D” (Fuzzy) (Fig. 5.7.1-1).
3.Indicator “d2” illuminates and the function is activated (Fig. 5.7.1-2).
By repeating the above steps or selecting an other functionthisfunctioncanbeswitchedoffagain.
5.7.2 Manual adjusting mode
If you want to manually adjust the temperature of the appliance in order to store a particular food, you can set the temperature via a temperature adjusting key:
Notice:Conflictwithotherfunctions
The temperature cannot be adjusted, if any other function (Super-Cool, Super-Freeze, Hoilday or Fuzzy) is activated or the display is locked. The corresponding indicator will flashaccompanyingwithabuzzer.
12
GB
5- Use
5.7.2.1 Adjust the temperature for fridge
1.Unlock the panel by touching key “G” if it is locked (Fig. 5.5).
2.Touch key “A” (Fridge) to select the fridge compartment. The actual temperature in the fridge compartment is displayed (Fig. 5.7.2-1).
3.Touch sequentially key “A” (Fridge) until the desired value of temperature is flashing (Fig. 5.7.2-2).
A signal will sound at each key touch. The temperature increases in sequences of 1°C from a minimum of 1°C to a maximum of 9°C. The optimum temperature in the fridge is 5 °C. Colder temperatures mean unnecessary energy consumption.
4.Touch any key except „A“ (Fridge) to confirm, or the settingconfirmsautomaticallyafter5seconds.Displayedtemperaturestopsflashing.
5.7.2-2 |
5.7.2-1 |
Fridge |
Fridge |
5.7.2.2 Adjust the temperature for freezer
1.Unlock the panel by touching key “G” if it is locked (Fig. 5.5).
2.Touch key “B” (Freezer) to select the freezer compartment. The actual temperature in the freezer compartment is displayed (Fig. 5.7.2-3).
3.Touch sequentially key“B” (Freezer) until the desired valueoftemperatureisflashing(Fig.5.7.2-4).
A signal will sound at each key press. The temperature increases in sequences of 1°C from -15°C to -24°C. The optimum temperature in the freezer is -18°C. Colder temperatures mean unnecessary energy consumption.
4.Touch any key except „B“ (Freezer) to confirm, or the setting confirms automatically after 5 seconds. Displayedtemperaturestopsflashing.
5.7.2-4 |
5.7.2-3 |
Freezer |
Freezer |
Notice:Influencesontemperatures
Theindoortemperaturesareinfluencedbythefollowingfactors:
|
Ambient temperature |
|
Amount of stored foods |
|
Frequency of door opening |
|
Installation of the appliance |
13
5- Use
GB
5.8-1 |
5.8-2 |
Super-Cool |
Super-Cool |
|
5.8 Super-Cool function
Switch on the Super-Cool function if larger quantity of food should be stored (for example after the purchase). The Super-Cool function accelerates the cooling of fresh food and protects the goods already stored from undesirable warming. The factory setting temperature is 0 to +1°C.
1.Unlock the panel by touching key “G” if it is locked (Fig. 5.5).
2.Touch key “E” (Super-Cool) (Fig. 5.8.-1).
3.Indicator “e” illuminates and the function is activated (Fig. 5.8.-2).
By repeating the above steps or selecting an other functionthisfunctioncanbeswitchedoffagain.
Notice:Automaticallyswitchoff
This function will be automatically disabled when the temperature from + 2 ° C is reached or the function has lasted for more than 3 hours.
5.9-1 |
5.9-2 |
Super-Frz. |
Super-Frz. |
|
5.9 Super-Freeze function
Fresh food should be frozen as quickly as possible to the core. This preserved the best nutritional value, appearance and taste. The Super-Freeze function accelerates the freezing of fresh food and protects the goods already stored from undesirable warming. If you need to freeze a large amount of food once, it is recommended to set the Super-Freeze function on ahead for 24h before the usage of frozen room. The factory setting temperature is -24 °C.
1.Unlock the panel by touching key “G” if it is locked (Fig. 5.5).
2.Touch key “F” (Super-Freeze) (Fig. 5.9.-1).
3.Indicator “f” illuminates and the function is activated (Fig. 5.9.-2).
By repeating the above steps or selecting an other functionthisfunctioncanbeswitchedoffagain.
Notice:Automaticallyswitchoff
The Super-Freeze function will automatically switch off after 50 hours. The appliance is then operated at the previously set temperature.
14
GB |
|
5- Use |
|
5.10 Holiday function |
5.10 |
||
This function sets the fridge temperature permanently |
|
||
to 17°C. |
|
||
This allows to keep the door of the empty fridge closed |
|
||
without causing an odour or mold - during a long ab- |
|
||
sence (e.g. during holiday). The freezer compartment |
|
||
is free for your setting. |
|
||
1. |
Unlock the panel by touching key “G” if it is locked |
|
|
|
|
(Fig. 5.5). |
|
2. |
|
Touch key “D” (Fuzzy) for 3 seconds Fig. 5.10). Indi- |
|
|
|
cator “d1” illuminates .and the function is activated. |
3 Sec. Holiday |
By repeating the above steps or selecting an other |
|||
functionthisfunctioncanbeswitchedoffagain. |
|
||
WARNING!
During the Holiday function no goods must be stored in the refrigerator compartment. The temperature of + 17 ° C is too high for storing food.
5.11 My Zone drawer
The fridge compartment is equipped with a My Zone drawer (Fig. 5.11). Following functions are available:
5.11.1 Function Fruit & Veg.
5.11 |
This function is suitable to store fresh fruits and vegetables.
Notice: Fruit & Veg. function
Cold-sensitive fruits like pineapple, avocado, bananas, grapefruits and vegetables such as potatoes, aubergines, beans, cucumbers, zucchini and tomatoes and cheese should not be stored in the My Zone drawer .
5.11.2 Function 0°C Fresh
This function sets the temperature in the MyZone drawer to 0 °C. Suitable to store of fresh food such as meat or instant products. . Most foods stay fresh at 0 ° C, but not frozen.
Notice: 0°C Fresh function
Due to different water contents of meat, some meat with more moisture will be frozen at temperatures lower than 0 °C. So “immediately cut” meat should be stored in My-Zone box, with temperatures min. 0°C.
15
5- Use
GB
5.11.3 Q-Cool (Quick-Cool)
This function allows to quick cool canned beverages in a short time. The temperature in MyZone compartment is set to +2 ° C.
Notice: MyZone drawer
One of the three functions of the My Zone compartment must always be activated
To reduce the refrigerator compartment temperature use the Q-Cool function. To increase it, use the Fruit & Veg. function.
5.11.4 |
My Zone |
5.11.4 Select function for MyZone box
1.Unlock the panel by touching key “G” if it is locked (Fig. 5.5)
2.Touch sequentially “C” (MyZone) until the desired function“c”isflashing(Fig.5.11.4).
3.After a few seconds indicator “c” will shine permanentlyandthesettingisconfirmed.
16
GB
5.12 Tips on storing fresh food
5.12.1Storingintotherefrigeratorcompartment
5- Use
Keep your fridge temperature below 5°C.
Hot food must be cooled to room temperature before storing in the appliance.Foods stored in the refrigerator should be washed and dried before storing
Food to be stored should be properly sealed to avoid odour or taste alterations.
Do not store excessive quantities of food. Leave spaces between foods to allow cold airflowingaroundthem,forabetterandmorehomogeneouscooling.
Foods eaten daily should be stored at the front of the shelf.
Leave a gap between foods and the inner walls, allowing air flowing. In special way don’t store foods against the rear wall: foods could freeze against rear wall. Avoid direct contact of food (especially oily or acidic food) with the inner liner, as oil/acid can erode the inner liner. Clean away oily/acid dirt whenever it is found.
Frozen food can be gently thawed in the refrigerator compartment. This saves energy.
The ageing process of fruit and vegetables such as courgettes, melons, papaya, banana, pineapple, etc. can be accelerated in the refrigerator. Therefore, it is not advisable to store them in the refrigerator. However, the ripening of strongly green fruits can be promoted for a certain period. Onions, garlic, ginger and other root vegetables should also be stored at room temperature.
Unpleasant odours inside the fridge are a sign that something has spilled and cleaning is required. See CARE AND CLEANING.
Differentfoodsshouldbeplacedindifferentareasaccordingtotheirproperties(Fig.:
5.12.1).
1Butter, cheese, eggs, spices, etc.
2Eggs, canned food, spices, etc
3Drinks and bottled foods.
4Pickled foods, canned food, etc.
5Meat products, snack foods, etc. 6/7 Pasta, milk, tofu, dairy, etc.
8Moist Zone drawer:
Fruit, vegetables, salad (Fruit & Veg.) canned beverages (Q-Cool)
Rraw fresh food (0°C Fresh)
|
5.12.1 |
1 |
4 |
1 |
|
2 |
5 |
2 |
|
|
6 |
3 |
7 |
3 |
|
8 |
|
17
5- Use
GB
5.12.2Storageintothefreezercompartment
Keep the freezer temperature at18°C.
24 hours before freezing switch on the Super-Freeze function; -for small quantities offood4-6hoursaresufficient.
Hot food must be cooled to room temperature before storing in the freezer compartment.
Food cut into small portions will freeze faster and be easier to defrost and cook. The recommended weight for each portion is less than 2.5 kg
It is better to pack food before putting it into the freezer. The outside of the packaging must be dry to avoid bags sticking together. Packaging materials should be odour-free, airtight, non-poisonous and nontoxic.
In order to avoid expiration of storage periods, please note the freezing date, time limit and name of the food on the packaging according to the storage periods of different foods.
WARNING!: Acid, alkali and salt etc. could erode the internal surface of the freezer.
Donotplacethefoodhavingthesesubstances(e.g.seafish)directlyontheinternal surface. Salt water in the freezer should be cleaned up immediately.
Do not exceed the food storage times recommended by the manufacturers. Only take the required amount of food out of the freezer.
Consume defrosted food quickly. Defrosted food cannot be re-frozen unless it is firstcooked,otherwiseitmayblessedible.
Do not load excessive quantities of fresh food in the freezer compartment. Refer to the freezing capacity of the freezer – See TECHNICAL DATA or data at the type plate.
Food can be stored in the freezer at a temperature of at least -18°C for 2 to 12 months, depending on its properties (e.g., meat: 3-12 months, vegetables: 6-12 months)
When freezing fresh food, avoid bringing it in contact with already frozen food. Risk of thawing!
5.12.3 When storing commercially frozen foods, please follow these guidelines:
Always follow manufacturers’ guidelines for the length of time you should store food for. Do not exceed these guidelines!
Try to keep the length of time between purchase and storage as short as possible to preserve food quality.
Buy frozen foods, which have been stored at a temperature of –18 °C or below.
Avoid buying food which has ice or frost on the packaging – This indicates that the products might have been partially defrosted and refrozen at some point – temperaturerisesaffectthequalityoffood.
18
GB
6- Energy saving tips
Energy saving tips
Make sure the appliance is properly ventilated (see INSTALLATION).
Do not install the appliance in direct sunlight or in the near of heat sources(e.g. stoves, heaters).
Avoid unnecessarily low temperature in the appliance. The energy consumption increases the lower the temperature in the appliance is set.
Functions like SUPER-FREEZE consume more energy.
Allow warm food to cool down before placing it in the appliance.
Opentheappliancedooraslittleandasbrieflyaspossible.
Donotoverfilltheappliancetoavoidobstructingtheairflow.
Avoid air within the food packaging.
Keep door seals clean so that the door always closes correctly.Defreeze frozen food in the fridge storage compartment.
19
7- Equipment
GB
Notice:Differencesdependingonmodel
Duetodifferentmodels,yourproductmaynothaveallofthefollowingfeatures.Please refer to chapter PRODUCT DESCRIPTION.
7.1
7.1Multi-air-flow
The refrigerator is equipped with a multi-air-flow system, with which cool air flows are located on every shelf level (Fig. 7.1). This helps to maintain a uniform temperature to ensure that your food is kept fresher for longer.
7.2 |
7.2 Adjustable shelves
The height of the shelves can be adjusted to fit your storage needs.
1.To relocate a shelf, remove it first by uplifting its hind edge (1) and pulling it out (2) (Fig. 7.2).
2.To reinstall it, put it on the lugs on both sides and push it to the most rearward position until the rear oftheshelfisfixedinsidetheslotsinthesides
Notice: Shelves
Ensure that all ends of a shelf are level.
7.3 |
|
1 |
1 |
|
2 |
7.4 |
|
7.3 Removable door racks
The door racks can be removed for cleaning:
Place hands on each side of the rack, lift it upwards (1) and pull it out (2) (Fig. 7.3).
In order to insert the door rack, the above steps are carried out in reverse order.
7.4 My Zone drawer
For use and setting of the My Zone compartment (Fig. 7.4) please check section USE (My Zone drawer).
20
GB
7- Equipment
7.5 OPTIONAL: OK-temperature indicator
The OK-temperature (Fig. 7.5) indicator can be used to determine temperatures below +4°C. Gradually reduce the temperature if the sign does not indicate “OK”.
7.5 |
Notice: OK-sticker
When the appliance is switched on, it may take up to 12 hours for the correct temperatures to be reached.
7.6 Removable freezer drawer
To remove the drawer out, pull out to the maximum extent (1), lift and remove (2) (Fig. 7.6).
In order to insert the drawer, the above steps are carried out in reverse order.
7.7 Removable connection rod
The rod can be removed after removing the top freezer drawer (Fig. 7.7):
1.Press the bucket (1) of plastic holder (A) and move out (2).
2.Repeat step 1 on the other side.
3.Remove (3) the connecting rod (B).
In order to insert the connection rod, the above steps are carried out in reverse order.
2 |
2 |
7.6 |
|
||
|
1 |
|
|
|
7.7 |
7.8 3D-freezer drawer
The freezer drawers (Fig. 7.8) can be extended straightly and completely. They are mounted on easy-roll telescopic runners, so that you can store and remove the freezing good comfortable. Because of the automatic door closing mechanism the handling is easy and you save energy.
7.8 |
WARNING!
Do not overload the drawers: Max. load of each drawer: 35 kg!.
21
7- Equipment
GB
7.9-1 |
7.9-2 |
7.9 Ice cube tray
1.Fill the ice cube tray 3/4 full of water and put it into one of the freezer storage drawer (Fig. 7.9-1).
2.Twisttheicecubetrayslightlyorholditunderflowing water to loosen the ice cubes (Fig. 7.9-2).
7.10 The Light
The LED interior light comes on when the door is opened. The performance of the lights isnotaffectedbyanyoftheappliancesothersettings.
22
GB
WARNING!
8- Care and Cleaning
Disconnect the appliance from the power supply before cleaning.
8.1 General
Clean the appliance when only little or no food is stored.
The appliance should be cleaned every four weeks for good maintenance and to prevent bad stored food odours.
WARNING!
Do not clean the appliance with hard brushes, wire brushes, detergent powder, petrol, amyl acetate, acetone and similar organic solutions, acid or alkaline solutions. Please clean with special refrigerator detergent to avoid damage.
Donotsprayorflushtheapplianceduringcleaning.
Do not use water spray or steam to clean the appliance.
Do not clean the cold glass shelves with hot water. Sudden temperature change may cause the glass to break .
Do not touch the inside surface of the freezer storage compartment, especially with wet hands, as your hands may freeze onto the surface.
In case of heating check the condition of frozen goods.
Always keep the door gasket clean. |
|
|
|
8.1 |
|
|
||
Clean the inside and housing of the appliance |
|
|
|
|
|
with a sponge dampened in warm water and |
|
|
neutral detergent (Fig. 8.1). |
|
|
Rinse and dry with soft cloth. |
|
|
Do not clean any of the parts of the appliance in a |
|
|
dishwasher. |
|
|
Clean the accessory only with warm water and mild |
|
|
neutral detergent. |
|
|
Allow at least 5 minutes before restarting the |
|
|
appliance as frequent starting may damage the |
|
|
compressor. |
|
|
8.2 Defrosting
The defrosting of the refrigerator and the freezer compartment are done automatically; no manual operation is needed.
8.3 Replacing the LED-lamp
lamp adopts LED as its light source, featuring low energy consumption and long ser-
.WARNING!If there is any abnormality, please contact the customer service . See CUSTOMER .
Do not replace the LED lamp yourself, it must only be replaced by either the manufacturer or the authorised service agent.
23
8- Care and Cleaning
GB
The lamp adopts LED as its light source, featuring low energy consumption and long service life. If there is any abnormality, please contact the customer service . See CUSTOMER SERVICE.
Parameters of the lamp:
Voltage 12V; Max Power: 2 W
8.4 |
|
1. |
2. |
3. |
4. |
8.4 Removable auxiliary door gaskets
There are six auxiliary door gaskets on the upper and lower freezer drawer.
1.Locate the five indicated door gaskets on the upper and lower freezer drawer (Fig. 8.4-1.).
2.Make sure the bent slices of the gaskets point inwards when attaching (Fig. 8.4-2.).
3.Locate the lower gasket of the upper drawer as indicated (Fig. 8.4-3.).
4.Make sure the bent slice of this gasket points downwards when attaching (Fig. 8.4-4.).
You get these gaskets as well as the revolving door / drawer gaskets via the customer service (see warranty card).
8.5 Non-use for a longer period
If the appliance is not used for an extended period of time, and you will not use the Holi- day-function for the refrigerator:
Take out the food.
Unplug the power cord.
Clean the appliance as described above.
Keep the door and freezer drawers/door open to prevent the creation of bad odours inside.
Notice:Switchoff
Turntheapplianceoffonlyifstrictlynecessary.
8.6 Moving the appliance
1.Remove all food and unplug the appliance.
2.Secure shelves and other moveable parts in the fridge and the freezer with adhesive tape.
3.Do not tilt the refrigerator more than 45° to avoid damaging the refrigerating system.
WARNING!
Do not lift the appliance by its handles.
Never place the appliance horizontally on the ground.
24
GB
9- Troubleshooting
Many occuring problems could be solved by yourself without specific expertise. In case of a problem please check all shown possibilities and follow below instructions before you contact an after sales service. See CUSTOMER SERVICE.
WARNING!
Before maintenance, deactivate the appliance and disconnect the mains plug from the mains socket.
Electrical equipment should be serviced only by qualified electrical experts, because improper repairs can cause considerable consequential damages.
A damaged supply should only be replaced by the manufacturer, its service agent or similarlyqualifiedpersonsinordertoavoidahazard.
9.1 Troubleshooting table
Problem |
PossibleCause |
PossibleSolution |
||
The compressor |
• |
Mains plug is not connected in the |
• Connect the mains plug. |
|
does not work. |
|
mains socket. |
|
|
|
• The appliance is in the defrosting |
• |
This is normal for an automatic |
|
|
|
cycle. |
|
defrosting. |
The appliance runs |
• |
The indoor or outdoor tempera- |
• In this case, it is normal for the ap- |
|
frequently or runs |
|
ture is too high. |
|
pliance to run longer. |
for a too long pe- |
• |
The appliance has been off power |
• Normally, it takes 8 to 12 hours for |
|
riod of time. |
|
for a period of time. |
|
the appliance to cool down com- |
|
|
|
|
pletely. |
|
• A door/drawer of the appliance is |
• Close the door/drawer and ensure |
||
|
|
not tightly closed. |
|
the appliance is located on a level |
|
|
|
|
ground and there is no food or |
|
|
|
|
container jarring the door. |
|
• The door/drawer has been opened |
• Do not open the door/drawer too |
||
|
|
too frequently or for too long. |
|
frequently. |
|
• |
The temperature setting for the |
• Set the temperature higher until a |
|
|
|
freezer compartment is too low. |
|
satisfactory refrigerator tempera- |
|
|
|
|
ture is obtained. It takes 24 hours |
|
|
|
|
for the refrigerator temperature |
|
|
|
|
to become stable. |
|
• |
The door/drawer gasket is dirty, |
• Clean the door/drawer gasket or |
|
|
|
worn, cracked or mismatched. |
|
replace them by the customer |
|
|
|
|
service. |
|
• The required air circulation is not |
• |
Ensure adequate ventilation. |
|
|
|
guaranteed. |
|
|
The inside of the |
• |
The inside of the refrigerator |
• Clean the inside of the refrigera- |
|
refrigerator is dirty |
|
needs cleaning. |
|
tor. |
and/or smells. |
• |
Food of strong odour is stored in |
• Wrap the food thoroughly. |
|
|
|
the refrigerator. |
|
|
25
9- Troubleshooting
GB
Problem |
|
|
PossibleCause |
PossibleSolution |
|
|
||||
It is not cold enough |
• The temperature is set too high. |
• |
Reset the temperature. |
|||||||
inside |
the |
appli- |
• Too warm goods has been stored. |
• |
Always cool down goods before |
|||||
ance. |
|
|
|
|
|
|
storing them. |
|
||
|
|
|
|
|
|
|
|
|||
|
|
|
|
• Too much food has been stored at |
• |
Always store small quantities of |
||||
|
|
|
|
|
one time. |
|
food. |
|
|
|
|
|
|
|
• The goods are too close to each |
• |
Leave a gap between several |
||||
|
|
|
|
|
other. |
|
foodsallowingairflowing. |
|||
|
|
|
|
• A door/drawer of the appliance is |
• |
Close the door/drawer. |
||||
|
|
|
|
|
not tightly closed. |
|
|
|
|
|
|
|
|
|
• The door/drawer has been opened |
• Do not open the door/drawer too |
|||||
|
|
|
|
|
too frequently or for too long. |
|
frequently. |
|
|
|
It is too cold in- |
• The temperature is set too low. |
• |
Reset the temperature. |
|||||||
side |
the |
appli- |
• The Power-Freezer function is ac- |
• |
Switch |
off |
the |
Power-Freezer |
||
ance. |
|
|
|
|
tivated or is running too long. |
|
function. |
|
|
|
|
|
|
|
|
|
|
|
|||
Moisture |
forma- |
• The climate is too warm and too |
• |
Increase the temperature. |
||||||
tion on the inside |
|
damp. |
|
|
|
|
|
|||
of the refrigerator |
• A door/drawer of the appliance is |
• |
Close the door/drawer. |
|||||||
compartment. |
|
not tightly closed. |
|
|
|
|
|
|||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
• The door/drawer has been opened |
• Do not open the door/drawer too |
|||||
|
|
|
|
|
too frequently or for too long. |
|
frequently. |
|
|
|
|
|
|
|
• Food containers or liquids are left |
• Let hot foods cool to room tem- |
|||||
|
|
|
|
|
open. |
|
perature and cover foods and li- |
|||
|
|
|
|
|
|
|
quids. |
|
|
|
Moisture |
|
accu- |
• The climate is too warm and too |
• This is normal in damp climate and |
||||||
mulates |
on the |
|
damp. |
|
will change when the humidity de- |
|||||
refrigerators |
out- |
|
|
|
creases. |
|
|
|
||
side surface or be- |
• |
The door/drawer is not closed |
• |
Ensure |
that |
he |
door/drawer is |
|||
tween the doors/ |
|
tightly. The cold air in the appliance |
|
tightly shut. |
|
|
||||
door and drawer. |
|
|
|
|
||||||
|
and the warm air outside it con- |
|
|
|
|
|
||||
|
|
|
|
|
densates. |
|
|
|
|
|
Strong |
ice |
and |
• |
The goods were not adequately |
• Always pack the goods well. |
|||||
frost in the freez- |
|
packaged. |
|
|
|
|
|
|||
er compartment. |
• A door/drawer of the appliance is |
• |
Close the door/drawer. |
|||||||
|
|
|
|
|
not tightly closed. |
|
|
|
|
|
|
|
|
|
• The door/drawer has been opened |
• Do not open the door/drawer too |
|||||
|
|
|
|
|
too frequently or for too long. |
|
frequently. |
|
|
|
|
|
|
|
• |
The door/drawer gasket is dirty, |
• Clean the door/drawer gasket or |
||||
|
|
|
|
|
worn, cracked or mismatched. |
|
replace them by new ones. |
|||
|
|
|
|
• Something on the inside prevents |
• Reposition |
the |
shelves, door |
|||
|
|
|
|
|
the door/drawer to close properly. |
|
racks, or internal containers to al- |
|||
|
|
|
|
|
|
|
low the door/drawer to close. |
|||
The appliance |
• |
The appliance is not located on |
• Adjust the feet to level the appli- |
|||||||
makes abnormal |
|
level ground. |
|
ance. |
|
|
|
|||
sounds. |
|
|
• The appliance touches some ob- |
• Remove objects around the appli- |
||||||
|
|
|
|
|||||||
|
|
|
|
|
ject around it. |
|
ance. |
|
|
|
26
GB
9- Troubleshooting
Problem |
|
PossibleCause |
PossibleSolution |
||
A slight sound is |
• |
This is normal. |
• |
- |
|
to be heard simi- |
|
|
|
|
|
lartothatofflow- |
|
|
|
|
|
ing water. |
|
|
|
|
|
You will hear |
an |
• The fridge storage compartment |
• |
Close the door or silence the |
|
alarm beep. |
|
|
door is open. |
|
alarm manually. |
You will hear |
a |
• The anti-condensation system is |
• This prevents condensation and is |
||
faint hum. |
|
|
working. |
|
normal. |
The interior lighting |
• Mains plug is not connected in the |
• Connect the mains plug. |
|||
or cooling system |
|
mains socket. |
|
|
|
does not work. |
|
• The power supply is not intact. |
• |
Check the electrical supply to |
|
|
|
|
|
|
the room. Call the local electricity |
|
|
|
|
|
company! |
|
|
• The LED-lamp is out of order. |
• Please call the service for chang- |
||
|
|
|
|
|
ing the lamp. |
The sides of the |
• |
This is normal. |
• |
- |
|
cabinet and door |
|
|
|
|
|
strip get warm. |
|
|
|
|
|
9.2 Power interruption
In the event of a power cut, food should remain safely cold for about 20 hours. Follow these tips during a prolonged power interruption, especially in summer:
Open the door/drawer as few times as possible.
Do not put additional food into the appliance during a power interruption.
If prior notice of a power interruption is given and the interruption duration is longer than 20 hours, make some ice and put it in a container in the top of the refrigerator compartment.
An inspection of the goods is required immediately after the interruption.
As temperature in the refrigerator will rise during a power interruption or other failure, the storage period and edible quality of food will be reduced. Any food that defrosts should be either consumed, or cooked and refrozen (where suitable) soon afterwards in order to prevent health risks.
Notice: Memory function during power interruption
After restoration of power the appliance continues with the settings that were set before the power failure.
27
10Installation |
GB |
10.1 Unpacking
WARNING!
The appliance is heavy. Always handle with at least two persons.
Keep all packaging materials out of children´s reach and dispose them in an environmentally friendly manner.
Take the appliance out of the packaging.Remove all packaging materials.
10.2 Environmental conditions
The room temperature should always be between 10° C and 43° C, since it can influence the temperature inside the appliance and its energy consumption. Do not install the appliance near other heat-emitting appliances (ovens, refrigerators) without isolation.
10.3 |
|
|
|
|
|
|
D4 |
|
D1 |
D2 |
D3 |
|
W2 |
|
|
10.4 |
>10 cm |
|
|
|
>10cm |
|
|
>10 cm cm190
70 cm
10.3 Space requirement
Required space when door is opened (Fig. 10.3):
Width |
|
Depth |
|
Distance to wall |
|
in mm |
|
in mm |
|
in mm |
|
W1 |
W2 |
D1 |
D2 |
D3 |
D4 |
700 |
1188 |
600 |
887 |
966 |
100 |
10.4 Ventilaton cross-section
To achieve sufficient ventilation of the appliance for safety reasons, the information of the required ventilation cross sections must be observed (Fig. 10.5).
28
GB
10Installation
10.5 Aligning the appliance |
|
10.5 |
|
||
|
|
The appliance should be placed on a fllat and solid surface.
1. Tilt the appliance slightly backwards (Fig. 10.5).
2. Set the feet to the desired level. |
1. |
3. |
The stability can be checked by alternately bump- |
max 45° |
|
|
ing on the diagonals. The slightly swaying should |
2. |
|
|
be the same in both directions. Otherwise the |
||
|
|
||
|
frame can warp; possible leaking door seals are |
|
|
|
the result. A low tendency to the rear facilitates |
|
|
|
the closing of the door. |
3. |
|
|
|
||
10.6 Fine tuning of the doors |
10.6-1 |
||
If the doors are not in one level, this mismatch can be |
|||
|
|||
remedied by following: |
|
||
10.6.1 Using adjustable foot |
|
||
Rotate the adjustable foot according to the direction of |
|
||
arrow i(Fig. 10.6-1) to turn up or down the foot. |
|
||
10.6.2 Using spacers |
|
||
|
Open the upper door and lift it. |
10.6-2 |
|
|
Carefully clip the spacer (enclosed in the accessory |
|
|
|
bag) in the white plastic ring of the middle hinge by |
|
|
|
hand or using tools like pliers (Fig. 10.6-2). Do not |
|
|
|
scratch or bruise the door. |
|
|
Notice: Levelling
In the future use of refrigerator, doors uneven phenomenon may occur to the weight of stored food. Then please adjust according to the above methods.
29
10Installation
GB
10.7 |
2 h |
10.7 Waiting time
To the maintenance-free lubrication oil is located in the capsule of the compressor. This oil can get through the closed pipe system during slanting transport. Before connecting the appliance to the power supply you have to wait 2 hours (Fig. 10.7) so that the oil runs back into the capsule.
10.8 Electrical connection
Before each connection check if:
power supply, socket and fusing are appropriate to the rating plate.the power socket is earthed and no multi-plug or extension.
the power plug and socket are strictly according. Connect the plug to a properly installed household socket.
WARNING!
To avoid risks a damaged power cord must be replaced by the customer service (see warranty card).
30
Loading...
