Dräger Medizintechnik |
|
|
|
For internal use only. Copyright reserved.
R6150000SM1IVZ.fm
Contents
DrägerService Mode
A |
|
|
|
|
1 |
General notes |
3 |
|
|
|
|
|
|||||
|
|
|
|
|||||
B |
|
|
|
|||||
|
|
|
|
|
|
|||
|
|
|
|
|
|
|
||
C |
|
|
|
|
1.1 |
Overview of possible tests |
4 |
|
|
|
|||||||
|
|
|
|
|||||
|
|
|
|
|
|
|||
|
|
|
|
|
|
|||
|
|
|
|
|
|
1.2 |
Accessing the DrägerService Mode ........................................................................... |
5 |
|
|
|
|
|
|
1.3 |
Exiting the DrägerService Mode .................................................................................. |
6 |
2 |
DrägerService Mode "Information" |
7 |
||
|
2.1 |
O2 sensor ......................................................................................................................... |
8 |
|
|
|
2.1.1 |
Reading out the O2 sensor data ................................................................ |
8 |
|
2.2 |
Software/operating hours .......................................................................................... |
10 |
|
|
2.3 |
Options |
........................................................................................................................... |
11 |
|
2.4 |
Service interval .............................................................................................................. |
13 |
|
3 |
Calibrations |
|
15 |
|
|
3.1 |
O2 sensor ...................................................................................................................... |
16 |
|
|
3.2 |
Scales |
............................................................................................................................. |
18 |
|
3.3 |
Height adjustment ........................................................................................................ |
20 |
|
|
|
3.3.1 |
Adjusting the manual threshold ............................................................... |
20 |
|
|
3.3.2 ........................................................... |
Adjusting the automatic threshold |
21 |
|
3.4 |
Tilt adjustment ............................................................................................................... |
22 |
|
|
|
3.4.1 ............................................................... |
Adjusting the manual threshold |
22 |
|
|
3.4.2 ........................................................... |
Adjusting the automatic threshold |
23 |
4 |
Logs |
|
24 |
|
4.1 |
Error log .......................................................................................................................... |
25 |
|
4.2 |
Error history ................................................................................................................... |
26 |
|
4.3 |
Operation history .......................................................................................................... |
27 |
6150.000 Caleo |
DrägerService Mode |
Page I |
Dräger Medizintechnik |
|
|
|
Contents
|
|
|
|
|
|
|
|
|
|
5 |
Diagnosis |
|
28 |
|
|
|
|
|
|
|
|
|
|
|
|
5.1 |
.......................................................................................................Operating voltages |
29 |
|
|
|
A |
|
|
|
|
|
|
|
|
||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
B |
|
|
|
|
|
|
5.2 |
Keypad |
|
30 |
||
|
|
|
|
|
|
|
|
|||||||
|
|
|
|
|
|
|
|
|
||||||
|
|
C |
|
|
|
|
|
|
............................................................................................................................ |
|||||
|
|
|
|
|
|
|
||||||||
|
|
|
|
|
|
|
|
|
||||||
|
|
|
|
|
|
|
|
|
|
|
|
5.2.1 |
Control keys test |
30 |
|
|
|
|
|
|
|
|
|
|
|
|
|||
|
|
|
|
|
|
|
|
|
|
|
|
|||
|
|
|
|
|
|
|
|
|
|
|
5.3 |
Sensor PCB .................................................................................................................. |
31 |
|
|
|
|
|
|
|
|
|
|
|
|
5.4 |
Actuator PCB ................................................................................................................ |
32 |
|
|
|
|
|
|
|
|
|
|
|
|
5.5 |
Output ...............................................................................................................signals |
34 |
|
|
|
|
|
|
|
|
|
|
|
|
5.6 |
Digital signals ................................................................................................................ |
36 |
|
|
|
|
|
|
|
|
|
|
|
|
5.7 |
Interface ..............................................................................................................board |
37 |
|
|
|
|
|
|
|
|
|
|
|
|
|
5.7.1 ...................................................................................................... |
Nurse call |
37 |
|
|
|
|
|
|
|
|
|
|
|
|
5.7.2 ........................................................................................................ |
Medibus |
39 |
|
|
|
|
|
|
|
|
|
|
|
|
5.7.3 .......................................................................................................... |
Modem |
40 |
For internal use only. Copyright reserved.
R6150000SM1IVZ.fm
6150.000 Caleo |
DrägerService Mode |
Page II |
Dräger Medizintechnik |
|
|
|
DrägerService Mode
A
B
C
1 General notes
The DrägerService Mode has four menu levels.
The first menu level contains the following items:
−Information
−Calibrations
−Logs
−Diagnosis
−Back
Service Mode
Information
Calibrations
Logs
Diagnosis
Back
Fig. 1: Start page of DrägerService Mode
Each menu level has submenus.
DrägerService Mode can be used to read out device data and activate/deactivate optional features.
For internal use only. Copyright reserved.
R6150000SM1.fm 06.02.01
6150.000 Caleo |
Released 01/2001 |
DrägerService Mode Page 3 of 40 |
Dräger Medizintechnik |
|
|
|
1.1Overview of possible tests
A
B
C
Information |
|
|
|
O2 sensor |
O2 sensor |
Software/operating hours |
Software/operating hours |
|
|
Options |
Options |
|
|
Service intervals |
Service interval |
|
|
Calibrations |
|
|
|
O2 sensor |
O2 sensor |
Scales |
Scales |
|
|
Height adjustment (optional) |
Height adjustment (optional) |
|
|
Tilt adjustment |
Tilt adjustment |
|
|
Logs |
|
|
|
Error log |
Error log |
|
|
Error history |
Error history |
|
|
Operation history |
Operation history |
|
|
Diagnosis |
|
|
|
Operating voltages |
Operating voltages |
|
|
Keypad |
Keypad |
|
|
Sensor PCB |
Sensor PCB |
|
|
WT2 Actuator PCB |
Actuator PCB |
|
|
Output signals |
Output signals |
|
|
Digital feedback signals |
Digital signals |
|
|
Interfaces |
|
Nurse call |
Nurse call |
Medibus |
Medibus |
Modem |
Modem |
|
|
|
|
For internal use only. Copyright reserved.
R6150000SM1.fm 06.02.01
6150.000 Caleo |
Released 01/2001 |
DrägerService Mode Page 4 of 40 |
Dräger Medizintechnik |
|
|
|
1.2Accessing the DrägerService Mode
A
B
C
•Plug the power plug of the Caleo into the mains socket.
•Switch on the Caleo at the power switch.
The Caleo runs through its self-test.
• Press the "menu" and "silence" keys (a) simultaneously for 4 seconds.
Dräger
a
Fig. 2: Front view of the display housing
The following menu appears on the EL display:
Service Mode
Information
Calibrations
Logs
Diagnosis
Back
For internal use only. Copyright reserved.
R6150000SM1.fm 06.02.01
Fig. 3: Menu page of DrägerService Mode
•Use the control knob to select the desired menu.
•Press the control knob to activate the desired menu.
The EL display shows the respective submenu.
•Use the control knob to select the desired submenu.
•Press the control knob to activate the desired submenu.
6150.000 Caleo |
Released 01/2001 |
DrägerService Mode Page 5 of 40 |
A
B
C
Dräger Medizintechnik |
|
|
|
If the control knob has additional functions, the required command will be shown directly on the EL display.
If additional functions can be selected using the EL display key, it will be shown on the EL display.
1.3Exiting the DrägerService Mode
•Exit the DrägerService Mode as follows: Switch off the Caleo or select the „Back“ functions in the respective EL display pages until Caleo is in the operating mode.
For internal use only. Copyright reserved.
R6150000SM1.fm 06.02.01
6150.000 Caleo |
Released 01/2001 |
DrägerService Mode Page 6 of 40 |
Dräger Medizintechnik |
|
|
|
2 DrägerService Mode "Information"
DrägerService Mode "Information" has the following submenus:
|
|
|
|
|
− |
O2 sensor |
A |
|
|
|
|
− |
|
B |
|
|
|
Software/operating hours |
||
|
|
|
|
|||
|
|
|
|
|
||
C |
|
|
|
|
|
|
|
|
|
||||
|
|
|
|
|
||
|
|
|
|
|
|
|
−Options
−Service interval
−Back
Service Mode: Information |
O2 sensor |
Software/Operating hours |
Options |
Service interval |
Back |
Fig. 4: DrägerService Mode "Information"
For internal use only. Copyright reserved.
R6150000SM1.fm 06.02.01
6150.000 Caleo |
Released 01/2001 |
DrägerService Mode Page 7 of 40 |
Dräger Medizintechnik |
|
|
|
A
B
C
2.1O2 sensor
DrägerService Mode "O2 sensor" shows the following O2 measurement data on the EL display:
−Serial number of the O2 Module PCB
−Serial version of the O2 Module PCB
−Serial numbers of the O2 sensors: sensor 1 and sensor 2
−Date of manufacture of the O2 sensors
−Last calibration date
−Next calibration
2.1.1Reading out the O2 sensor data
•Switch on the Caleo at the power switch.
•As soon as the device has finished its self-test, press the "menu" and "silence" keys simultaneously for 4 seconds.
The Caleo should now be in DrägerService Mode.
•Use the control knob to select the menu item "Information".
•Press the control knob.
The EL display shows the "Information" menu.
•Use the control knob to select the menu item "O2 Sensor".
•Press the control knob.
The EL display shows the serial numbers, the date of manufacture, and the calibration date.
For internal use only. Copyright reserved.
R6150000SM1.fm 06.02.01
Service Mode: O2 sensor
Sensor 1
PCB serial number:
PCB software version:
Sensor serial number:
Sensor date of manufacture:
Last calibration:
Next calibration:
Sensor 2
Fig. 5: DrägerService Mode, O2 sensor 1
6150.000 Caleo |
Released 01/2001 |
DrägerService Mode Page 8 of 40 |
Dräger Medizintechnik |
|
|
|
•If a second O2 sensor is fitted, press the right-hand display key (sensor 2) in order to switch over to the data of the second O2 sensor.
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Service Mode: O2 sensor |
|
|
A |
|
|
|
|
|
|
|
|
Sensor 2 |
|
|
|
|
|
|
|
|
|
|||
|
|
|
|
|
|
|
|
|
|
||
|
|
B |
|
|
|
|
|
|
|||
|
|
|
|
|
|||||||
|
|
|
|
|
|
||||||
|
|
C |
|
|
|
|
|
|
|
||
|
|
|
|
|
|
|
|||||
|
|
|
|
|
|
|
|
PCB serial number: |
|||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|||
|
|
|
|
|
|
|
|
|
|
|
PCB software version: |
|
|
|
|
|
|
|
|
|
|
|
Sensor serial number: |
|
|
|
|
|
|
|
|
|
|
|
Sensor date of manufacture: |
|
|
|
|
|
|
|
|
|
|
|
Last calibration: |
|
|
|
|
|
|
|
|
|
|
|
Next calibration: |
|
|
|
|
|
|
|
|
|
|
|
|
Sensor 1
Fig. 6: DrägerService Mode, O2 sensor 2
• Exit the DrägerService Mode as follows: Switch off the Caleo.
For internal use only. Copyright reserved.
R6150000SM1.fm 06.02.01
6150.000 Caleo |
Released 01/2001 |
DrägerService Mode Page 9 of 40 |
A
B
C
Dräger Medizintechnik |
|
|
|
2.2Software/operating hours
DrägerService Mode "Software/operating hours" shows the software version and the operating hours on the EL display. The operating hours can be adjusted.
•Switch on the Caleo at the power switch.
•As soon as the device has finished its self-test, press the "menu" and "silence" keys simultaneously for 4 seconds.
The Caleo should now be in DrägerService Mode.
•Use the control knob to select the menu item "Information".
•Press the control knob.
The EL display shows the "Information" menu.
•Use the control knob to select the menu item "Software/operating hours".
•Press the control knob.
The EL display shows the software version and number of operating hours.
|
Service Mode: Software/Operating hours |
|
Caleo |
|
Software version: |
|
Current operating hours |
|
Adjust using control knob |
|
Operating hours: |
Fig. |
7: DrägerService Mode, software version/operating hours |
For internal use only. Copyright reserved.
R6150000SM1.fm 06.02.01
•Press the control knob to activate the operating hours.
•Use the control knob to adjust the desired operating hours.
•Press the control knob to store the desired operating hours (Note: The operating hours should be adjusted within max. 2 minutes. Otherwise the Caleo will return to its normal operating mode.).
•Exit the DrägerService Mode as follows: Switch off the Caleo.
6150.000 Caleo |
Released 01/2001 |
DrägerService Mode Page 10 of 40 |
Dräger Medizintechnik |
|
|
|
For internal use only. Copyright reserved.
R6150000SM1.fm 06.02.01
2.3Options
DrägerService Mode "Options" shows the following options on the EL display:
|
|
|
|
|
|
|
|
|
− |
O2 module |
|
|
|
|
|
|
|
|
|
− |
Humidity module |
|
|
|
|
|
|
|
|
|
||
|
|
A |
|
|
|
|
|
|
||
|
|
B |
|
|
|
|
− |
Mattress module |
||
|
|
|
|
|
||||||
|
|
|
|
|
|
|||||
|
|
C |
|
|
|
|
||||
|
|
|
|
− |
Scales module |
|||||
|
|
|
|
|
|
|||||
|
|
|
|
|
|
|
|
|
||
|
|
|
|
|
|
|
|
|
||
|
|
|
|
|
|
|
|
|
||
|
|
|
|
|
|
|
|
|
− |
Interface board |
Each module can be addressed individually: The individual modules have different control functions which can be selected using the control knob. Activated device options will be tested during the self-test. Device options that are not available/not installed are marked as "not installed" in the status field of the EL display.
Module |
Function |
|
|
|
|
O2 module |
not installed |
|
Monitoring |
|
Closed-loop control |
|
|
Humidity module |
not installed |
|
Closed-loop control |
|
Control |
|
|
Mattress module |
not installed |
|
installed |
|
|
Scales module |
not installed |
|
installed |
|
|
Interface board |
not installed |
|
installed |
|
|
•Switch on the Caleo at the power switch.
•As soon as the device has finished its self-test, press the "menu" and "silence" keys simultaneously for 4 seconds.
The Caleo should now be in DrägerService Mode.
•Use the control knob to select the menu item "Information".
•Press the control knob.
The EL display shows the "Information" menu.
• Use the control knob to select the menu item "Options".
6150.000 Caleo |
Released 01/2001 |
DrägerService Mode Page 11 of 40 |
Dräger Medizintechnik |
|
|
|
• Press the control knob.
Service Mode: Options
A
B
C
O2 module: not installed
Humidity module: not installed
Mattress module: not installed
Scales module: not installed
Interface: not installed
Fig. 8: DrägerService Mode, options
•Use the control knob to select the respective menu item.
•Press the control knob to activate the menu item.
•Use the control knob to select the desired function.
•If necessary, switch the Caleo off and on again in order to enable the desired function.
•Exit the DrägerService Mode as follows: Switch off the Caleo.
For internal use only. Copyright reserved.
R6150000SM1.fm 06.02.01
6150.000 Caleo |
Released 01/2001 |
DrägerService Mode Page 12 of 40 |
Loading...
