BOSCH NITP666SUC, NITP666UC User Manual

Cooktop

Use and Care Manual

NITP666SUC, NITP666UC

1,73 8&

1,73 68&

[

[

[

[

[

[

[

[

() = cm

Table of Contents
Safety Definitions ..........................................................	4
IMPORTANT SAFETY INSTRUCTIONS ........................	5
Fire Safety ..............................................................................	5
Cooking Safety ......................................................................	5
Burn Prevention ....................................................................	6
Child Safety ...........................................................................	6
Cleaning Safety .....................................................................	6
Cookware Safety ..................................................................	6
Proper Installation and Maintenance ................................	7
Electromagnetic interference .............................................	7
Cooling fan ............................................................................	7
State of California Proposition 65 Warnings ...................	7
Causes of damage .........................................................	8
Protecting the environment ..........................................	8
Energy-saving advice ...........................................................	8
Cooking by induction ....................................................	9
Advantages of induction cooking ......................................	9
Cookware ...............................................................................	9
Getting familiar with the appliance ............................	10
Control panel ......................................................................	10
The Elements .....................................................................	10
Residual heat indicator ....................................................	10
Operation ......................................................................	11
Main power switch ............................................................	11
Setting the cooktop ...........................................................	11
Flexible cooking zone .......................................................	12
SpeedBoost function ........................................................	13
Cook time ...........................................................................	14
The timer .............................................................................	14
Panel Lock ..........................................................................	15
Wipe Protection .................................................................	15
Automatic time limitation ..................................................	15
Basic settings .....................................................................	15
Cleaning and Maintenance .........................................	17
Daily Cleaning ....................................................................	17
Cleaning guidelines ..........................................................	17
Cleaning charts ..................................................................	17
Maintenance .......................................................................	18
Service ..........................................................................	18
Fixing Malfunctions ...........................................................	18
Normal operating noises of the cooktop ......................	19
Technical service ...............................................................	19
STATEMENT OF LIMITED PRODUCT WARRANTY ...	20
What this Warranty Covers & Who it Applies to ..........	20
How Long the Warranty Lasts .........................................	20
Repair/Replace as Your Exclusive Remedy ................	20
Out of Warranty Product ..................................................	20
Warranty Exclusions .........................................................	21

Additional information on products, accessories, replacement parts and services can be found at www.bosch-home.com and in the online shop

www.bosch-home.com/us/store

3

Safety Definitions

9WARNING

This indicates that death or serious injuries may occur as a result of non-observance of this warning.

9CAUTION

This indicates that minor or moderate injuries may occur as a result of non-observance of this warning.

NOTICE: This indicates that damage to the appliance or property may occur as a result of non-compliance with this advisory.

Note: This alerts you to important information and/or tips.

4

9 IMPORTANT SAFETY INSTRUCTIONS

READ AND SAVE THESE INSTRUCTIONS

WARNING

When properly cared for, your new appliance has been designed to be safe and reliable. Read all instructions carefully before use. These precautions will reduce the risk of burns, electric shock, fire, and injury to persons.

When using kitchen appliances, basic safety precautions must be followed, including those in the following pages.

Examine the appliance after unpacking it. In the event of transport damage, do not plug it in.

Fire Safety

Do not allow aluminum foil, plastic, paper or cloth to come in contact with a hot surface element, burner or grate. Do not allow pans to boil dry.

If the cooktop is near a window, forced air vent or fan, be certain that flammable materials such as window coverings do not blow over or near the burners or elements. They could catch on fire.

Always have a working smoke detector near the kitchen.

Never leave the cooktop unattended when in use. Boilovers cause smoking and greasy spillovers may ignite.

WARNING

TO REDUCE THE RISK OF A GREASE FIRE:

a.Never leave surface units unattended at high settings. Boilovers cause smoking and greasy spillovers that may ignite. Heat oils slowly on low or medium settings.

b.Always turn hood ON when cooking at high heat or when flambeing food (i.e. Crepes Suzette, Cherries Jubilee, Peppercorn Beef Flambé).

c.Clean ventilating fans frequently. Grease should not be allowed to accumulate on fan or filter.

d.Use proper pan size. Always use cookware appropriate for the size of the surface element.

In the event that personal clothing or hair catches fire, drop and roll immediately to extinguish flames.

Have an appropriate fire extinguisher available, nearby, highly visible and easily accessible near the appliance.

Smother flames from food fires other than grease fires with baking soda. Never use water on cooking fires.

WARNING

TO REDUCE THE RISK OF INJURY TO PERSONS IN THE EVENT OF A GREASE FIRE, OBSERVE THE FOLLOWING:

a.SMOTHER FLAMES with a close-fitting lid, cookie sheet, or metal tray, then turn off the burner. BE CAREFUL TO PREVENT BURNS. If the flames do not go out immediately, EVACUATE AND CALL THE FIRE DEPARTMENT.

b.NEVER PICK UP A FLAMING PAN – You may be burned.

c.DO NOT USE WATER, including wet dishcloths or towels – a violent steam explosion will result.

d.Use an extinguisher ONLY if:

-You know you have a Class ABC extinguisher, and you already know how to operate it.

-The fire is small and contained in the area where it started.

-The fire department is being called.

-You can fight the fire with your back to an exit.

Whenever possible, do not operate the ventilation system during a cooktop fire. However, do not reach through fire to turn it off.

Cooking Safety

WARNING

Use this appliance only for its intended use as described in this manual. NEVER use this appliance as a space heater to heat or warm the room. Doing so may result in overheating the appliance. Never use the appliance for storage.

When using the timer, always supervise the cooktop and do not allow anything to boil over or burn. Boilovers can cause smoke and some foods and oils may catch fire if left on high temperature settings.

Never use the appliance if liquids or foods have spilled around the control panel. Always turn off the cooktop and dry the control panel.

Injury and damage to the appliance may occur if control elements are not used properly.

If the cooktop turns off automatically and can no longer be operated, it may turn itself on unintentionally at a later point. Switch off the circuit breaker in the fuse box.

Contact the after-sales service.

5

9 IMPORTANT SAFETY INSTRUCTIONS

READ AND SAVE THESE INSTRUCTIONS

Burn Prevention

DO NOT TOUCH SURFACE UNITS OR AREAS NEAR UNITS - Surface units may be hot even though they are dark in color. Areas near surface units may become hot enough to cause burns. During and after use, do not touch, or let clothing, potholders, or other flammable materials contact surface units or areas near units until they have had sufficient time to cool. Among these areas are the cooktop and areas facing the cooktop.

Do not heat or warm unopened food containers. Build-up of pressure may cause the container to burst and cause injury.

Always use dry potholders. Moist or damp potholders on hot surfaces may result in burns from steam. Do not let potholder touch hot heating elements. Do not use a towel or other bulky cloth.

Always turn hood ON when cooking at high heat or when flambeing food (i.e. Crêpes Suzette, Cherries Jubilee, Peppercorn Beef Flambe).

Use high heat settings on the cooktop only when necessary. To avoid bubbling and splattering, heat oil slowly on no more than a low-medium setting. Hot oil is capable of causing extreme burns and injury.

Never move a pan of hot oil, especially a deep fat fryer. Wait until it is cool.

Secure all loose garments, etc. before beginning. Tie long hair so that it does not hang loose, and do not wear loose fitting clothing or hanging garments, such as ties, scarves, jewelry, or dangling sleeves.

WARNING

RISK OF BURNS

Metallic objects become hot very quickly on the cooktop. Never set down metallic objects, such as knives, forks, spoons and lids on the cooktop.

WARNING

RISK OF BURNS

The pan detection may potentially fail to turn off the cooking zone due to spilled food or objects placed upon the cooktop. After each use, turn off the cooktop using the main switch.

If the display does not work when a cooking area is heating up, disconnect the circuit breaker from the fuse box. Contact an authorized servicer.

Child Safety

When children become old enough to use the appliance, it is the legal responsibility of the parents or legal guardians to ensure that they are instructed in safe practices by qualified persons.

Do not allow anyone to climb, stand, lean, sit, or hang on any part of an appliance, especially a door, warming drawer, or storage drawer. This can damage the appliance, and the unit may tip over, potentially causing severe injury.

Do not allow children to use this appliance unless closely supervised by an adult. Children and pets should not be left alone or unattended in the area where the appliance is in use. They should never be allowed to play in its vicinity, whether or not the appliance is in use.

CAUTION

Items of interest to children should not be stored in an appliance, in cabinets above an appliance or on the backsplash. Children climbing on an appliance to reach items could be seriously injured.

Cleaning Safety

Do not clean the appliance while it is still hot. Some cleaners produce noxious fumes when applied to a hot surface. Wet clothes and sponges can cause burns from steam.

Do not use steam cleaners to clean the appliance.

Cookware Safety

Hold the handle of the pan when stirring or turning food. This helps prevent spills and movement of the pan.

Use Proper Pan Size.

The use of undersized cookware will expose a portion of the heating element or burner to direct contact and may result in ignition of clothing. Select cookware having flat bottoms large enough to cover the surface heating unit. This appliance is equipped with one or more surface units of different size. Proper relationship of cookware to heating element or burner will also improve efficiency.

Cookware not approved for use with ceramic cooktops may break with sudden temperature changes. Use only pans that are appropriate for ceramic cooktops.

Always position handles of utensils inward so they do not extend over adjacent work areas, burners, or the edge of the cooktop. This reduces the risk of fires, spills and burns.

WARNING

RISK OF INJURY

When cooking with a bain-marie, the cooktop and cooking vessel may crack due to overheating. The cooking vessel in the bain-marie must not come in direct contact with the bottom of the pot filled with water. Use only heat-resistant cookware.

6

9 IMPORTANT SAFETY INSTRUCTIONS

READ AND SAVE THESE INSTRUCTIONS

WARNING

DANGER OF INJURY

Cookware may jump upward due to fluid trapped between the cookware bottom and cooking zone. Always keep cooking zone and cookware bottom dry.

Proper Installation and Maintenance

Have the installer show you the location of the circuit breaker or fuse. Mark it for easy reference.

This appliance must be properly installed and grounded by a qualified technician. Connect only to properly grounded outlet. Refer to Installation Instructions for details.

This appliance is intended for normal family household use only. It is not approved for outdoor use. See the Warranty. If you have any questions, contact the manufacturer.

Do not store or use corrosive chemicals, vapors, flammables or nonfood products on or near this appliance. It is specifically designed for use when heating or cooking food. The use of corrosive chemicals in heating or cleaning will damage the appliance and could result in injury.

Do not operate this appliance if it is not working properly, or if it has been damaged. Contact an authorized servicer.

Do not cook on a broken cooktop. Cleaning solutions and spillovers may create a risk of electric shock.

Do not repair or replace any part of the appliance unless specifically recommended in this manual. Refer all servicing to a factory authorized service center.

To avoid electrical shock hazard, before servicing the appliance, switch power off at the service panel and lock the panel to prevent the power from being switched on accidentally.

Electromagnetic interference

WARNING

This induction cooktop generates and uses ISM frequency energy that heats cookware by using an electromagnetic field. It has been tested and complies with Part 18 of the FCC Rules for ISM equipment. This induction cooktop meets the FCC requirements to minimize interference with other devices in residential installation. Induction cooktops may cause interference with television or radio reception. If interference occurs, the user should try to correctthe interference by:

Relocating the receiving antenna of the radio or television.

It is the user’s responsibility to correct any interference.

CAUTION

Persons with a pacemaker or similar medical device should exercise caution when standing near an induction cooktop while it is in use. Consult your doctor or the manufacturer of the pacemaker or similar medical device for additional information about its effects with electromagnetic fields from an induction cooktop.

Cooling fan

The cooktop is equipped with a cooling fan on its underside. Should the cooktop lie above a drawer, there must be no objects or paper in it. They may be sucked in and compromise the cooling of the appliance or damage the fan.

There must be a minimum distance of ¾" (20mm) between the content of the drawer and the fan input.

State of California Proposition 65 Warnings

WARNING

This product contains chemicals known to the State of California to cause cancer, birth defects or other reproductive harm.

Increasing the distance between the cooktop and the receiver.

Connecting the receiver into an outlet different than the receiver.

7

Causes of damage

Scratches on glass ceramic surface: Cookware with rough bottoms will scratch the glass ceramic surface.

Salt, sugar and sand: Salt, sugar or grains of sand will scratch the glass ceramic surface. Never use the cooktop as a working surface or for setting things down.

Overheated cookware: Avoid heating pots or pans that are empty.

Hot cookware: Never set down hot pans and pots on the control panel or frame. This may cause damage.

Hard and sharp objects: Hard or sharp objects falling on the cooktop may damage it.

Boiled-over food: Sugar and products containing sugar may damage the cooktop. Immediately eliminate spills of these products with a glass scraper.

Foils and plastics: Aluminum foil and plastic will melt on the hot cooking zones. Stove protective film isn't suitable for your cooktop.

Unsuitable cleaning agent: Shimmering metallic discolorations on the glass ceramic surface result from the use of inappropriate cleaning agents and abrasion from cookware.

Protecting the environment

Energy-saving advice

Always place a fitting lid on cookware. Cooking with an uncovered pan will result in a four-fold increase in energy use. Use a glass lid to provide visibility and avoid having to lift the lid.

Use cookware equipped with a solid, flat bottom. Curved pan bases increase energy consumption.

The diameter of the pan base must match the size of the element. If not, energy may be wasted. Note: The manufacturer normally indicates the pan's upper diameter. This is normally greater than the diameter of the pan's base.

Choose cookware of a size suited to the amount of food you are going to cook. A large pan that is only half full will use a lot of energy.

Use a small amount of water when cooking. This saves energy, and vegetables retain a larger percentage of their vitamins and minerals.

Select a lower power level.

8

Cooking by induction

Advantages of induction cooking

When cooking with induction, heat is generated directly in the base of the pan. This provides many benefits for you:

Time saving when boiling and frying. Cookware is heated directly.

Less energy is consumed.

Easy cleaning and maintenance. Spilled food does not burn onto the cooktop so quickly.

Controlled supply of heat and increased safety. The burner reacts immediately to any power change, so heating can be dosed precisely. Heating is interrupted when you remove the cookware from the burner even if the burner is still switched on.

Cookware

Only ferromagnetic cookware made of the following materials is suitable for induction cooktops:

Enameled steel

Cast iron

Induction-capable cookware of stainless steel.

To determine whether the cookware is suitable, check whether the base of the pot or pan attracts a magnet.

There are other induction-capable pots and pans whose bases are not completely ferromagnetic.

If the base of the cookware it

not completely ferromagnetic, only the area that is magnetizable will get hot.

Thus it can happen that the heat is not distributed evenly.

If the base of the cookware is

made from aluminum, among other things, the ferromagnetic area is also

reduced. It can be that this

cookware will not become

truly hot or it may not be

detected at all.

To get good cooking results, we recommend that the diameter of the ferromagnetic area of the cookware match the size of the burner. If a pot or pan is not detected on a burner, try it again on a burner with a smaller diameter.

Unsuitable cookware

Do not ever use adapter plates for induction or cookware made of:

Traditional stainless steel

Glass

Clay

Copper

Aluminum

Characteristics of the pan base

The characteristics of the pan base can influence the evenness of the cooking results. Pans made from materials which help diffuse heat, such as stainless steel sandwich pans, distribute heat uniformly, saving time and energy.

No pan or improper size

If no pan is placed on the selected element, or if it is made of unsuitable material or is not the correct size, the power level displayed on the element indicator will flash. Place a suitable pan on the element to stop the flashing. If you take longer than 90 seconds to place a suitable pan on the element, it will automatically turn off.

Empty pans or pans with a thin base

Do not heat up empty pans, or use pans with a thin base. The cooktop is equipped with an internal safety system. However, an empty pan may heat up so quickly that the "automatic switch off" function may not have time to react and the pan may reach very high temperatures. The pan base could melt and damage the cooktop glass. In this case, do not touch the pan and switch the cooktop off. If the cooktop fails to work after it has cooled down, please contact the technical service.

Pan detection

Each element has a minimum limit for detecting pans, which varies depending on the material of the pan you are using. You should therefore use the element that best matches the diameter of your pan.

Automatic detection on double or triple cooking elements

These elements can detect different pan sizes. Depending on the material and properties of the pan, the element will adapt automatically, and will turn on single zone or the entire element, supplying the proper power to obtain good cooking results.

9

Getting familiar with the appliance

In this section we describe the control panel, elements and displays.

Page 2 contains a list of models and dimensions.

Control panel

Display symbols

> Wipe protection on D Child lock on

UKitchen timer on

‰‰.	Timer value
q min	Cook time function

ÄFlex zone

‰.‰ Power level ‚-Š Ready ‹

Residual heat •/œ SpeedBoost function ›

The Elements

Touch keys

On/Off Main power switch

Á / $ Select cooking element

1û2û...8û9 Temperature levels with intermediate levels û

Panel Lock Panel lock for child safety/wipe protection

Speed Boost Speed Boost function for rapid heating

Timer	Timer functions
Flex Off/On	Turn flex zone on/off

Touch control zone

When you touch a symbol, the corresponding function will be activated.

NOTICE: Always keep the touch control zones clean and dry. Moisture and dirt can affect proper functioning.

Elements
ò Triple element	This element is turned on automatically when using cookware with a
	base that matches the size of the outer area (ð or ò) selected for
	use.
û Flexible cooking zone	See section Flexible Cooking Zone

Use only cookware suitable for induction cooking; see the section on suitable cookware.

Residual heat indicator

The cooktop is equipped with a residual heat indicator for each element. Avoid touching the indicated elements.

Even when turned off, the indicator •/œ will stay lit while the cooktop is hot.

If the pan is removed but the element is not turned off, the indicator •/œ and the selected power level will flash alternately.

10

Operation

Main power switch

Use the main switch to turn on the electronic circuitry for the control panel. The cooktop is now ready to use.

Turning the cooktop on

Touch the On/Off touch key until the indicator above the main switch and the symbols $for the heating elements turn on.

Turning the cooktop off

Touch the On/Off touch key. The __ indicator goes out. The cooktop is switched off. The residual heat indicators will remain on until the elements have cooled off sufficiently.

Note: The cooktop switches off automatically when all the elements have been switched off for more than 15 seconds.

If residual heat is still present when the cooktop is turned on, •/œ will appear in the heating element display.

Setting the cooktop

This section will show you how to set the elements. The table contains details on the heat settings for a variety of dishes.

Setting the element

Select the desired heat level using the number keys 1 to 9.

Heat level 1 = minimum power Heat level 9 = maximum power

Each heat setting has an intermediate level. This level is indicated by .5 in the element display and is set by touching the û symbols between the number keys.

Settings table

The following table provides some examples. Cooking times may vary depending on the type of food, its weight and quality. Deviations are therefore possible.

Selecting the heat level

The cooktop must be turned on.

The cooktop has to be turned on.

1.Select the desired element with by touching the  or $ symbol of the desired element. In the element display ‹.‹ and the __ indicator light up.

2.Within the following 10 seconds, set the desired power level using the number keys.

3.To change the power level, select the element and set the desired power level using the number keys. To set an intermediate level touch the û symbols between the number keys.

Turning off the element

Select the element and set the heat level to 0. The element is turned off and the residual heat indicator is displayed.

Note: The selected power level will flash if no pan is placed on the induction element. After a certain time, the element turns itself off.

Note: . During cooking, stews or liquid meals such as soups, sauces or drinks can heat up too quickly unnoticed and overflow or spatter. For this reason we recommend that you stir continuously, gradually heating the food at a suitable power level.

	Power levels
Melting
chocolate	1.5
butter	1.0 - 2.0
Heating
frozen vegetables, e.g. spinach	2.5 - 3.5
broth	7.0 - 8.0
thick soup	1.5 - 2.5
milk**	1.0 - 2.0
Simmering
delicate sauce e.g. Béchamel sauce	4.0 - 5.0
spaghetti sauce	2.0 - 3.0
pot roast	4.0 - 5.0
fish**	4.0 - 5.0

11

	Power levels
Cooking
rice (with double amount of water)	2.0 - 3.0
potatoes bolied in thier skins (with 1-2 cups of water)	4.0 - 5.0
boiled potatoes (with 1-2 cups of water)	4.0 - 5.0
fresh vegetables (with 1-2 cups of water)	2.0 - 3.5
frozen vegetables (with 1-2 cups of water)	3.5 - 4.5
pasta (with 2-4 qt. water)*	6.0 - 7.0
pudding**	1.0 - 2.0
cereals	2.0 - 3.0
Frying
pork chop	5.5 - 6.5
chicken breast	5.0 - 6.0
bacon	6.0 - 7.0
eggs	5.0 - 6.0
fish	5.0 - 6.0
pancakes	6.0 - 7.0
Deep fat frying** (in 1-2 qt. oil)
deepfrozen foods, e.g. chicken nuggets (0.5 lb per serving)	8.0 - 9.0
other, e.g. doughnuts (0.5 lb per serving)	4.5 - 5.5
Keep warm
tomato sauce	1.5
* ongoing cooking without lid
** without lid

	Flexible cooking zone	Flexible cooking zone - two independent burners
	You can combine the cooking zone into a large burner	The front and rear burners with two
	as needed or use two burners that are independent of	inductors apiece can be used inde-
	one another.	pendently. The heat setting is set
	The cooking zone consists of 4 inductors, which are	individually for each burner. Use only
	controlled independently of one another. If the flexible	one piece of cookware on each
	cooking zone is in use, only the area is activated that is	burner.
	covered by cookware.	Notes
	Cookware use recommendations
		Using two pots of different sizes or made of different
	Place the cookware in the middle. This guarantees
		materials may cause noises or vibrations. The function of
	optimal pot detection and heat distribution.	the cooking zone is not restricted by this.
	Flexible cooking zone - as an individual burner	Powerboost function: if the
		flexible cooking zone is used as
	Diameter of the cookware max. 13 cm	a single burner, place the
		cookware in the middle of the
	Place the cookware on one of the
		cooking zone to achieve
	4 positions visible in the figure.
		maximum power.
		For cooktops with two flexible
	Diameter larger than 13 cm	cooking zones, do not use both
		cooking zones for a single large
	Place the cookware on one of the
		piece of cookware.
	3 positions visible in the figure.

If the cookware takes up more than one burner, place it on the upper or lower edge of the flexible cooking zone.

12

As a conventional burner

By default, the flexible cooking zone can be used as a single burner.

Activate this function

The cooktop must be turned on.

1.Select the flexible cooking zone with the symbols Á or Â. ‹.‹ lights up in the element display.

2.Set the desired power level with the number keys. The flexible cooking zone is activated.

Changing the heat setting

Change the heat setting on the control panel.

Add another piece of cookware

Select the flexible cooking zone and touch the

Flex ON symbol. The element will detect the new piece of cookware.

The previously set power level will be maintained.

Note: When you lift or remove cookware from an activated element the element will automatically try to detect the cookware. The previously set power level is maintained.

Turning off this function

Select the cooking zone and touch the Flex OFF symbol.

As two burners

The flexible cooking zone can be used as two independent burners.

Activating this function

1.Select the flexible cooking zone and touch the Flex OFF symbol. The indicator b lights up between the Á and  symbols.

2.Select one of the flexible cooking zones. ‹.‹ lights up in the element display.

3.Set the power level with the number keys.

The function is switched off by:

selecting the burner and pressing the 0 symbol. The burner switches off.

Note: If the cooktop is switched off and on again, the flexible cooking zone is switched to operation as a single burner again.

SpeedBoost function

The SpeedBoost function can be used to heat large amounts of water faster than by using heat level Š.

Limitation on use

This function is available on all elements, provided that no other element in the same group is operating, (see picture). If this is not the case, the › and Š symbols will flash on the selected element display; then it will automatically set the power level Š.

*URXS *URXS

*URXS

Note: You can achieve maximum power on the flexible cooking zone by placing just one piece of cookware in the middle of the cooking zone as described in the

Flexible Cooking Zone chapter.

Setting SpeedBoost

1.Select an element.

2.Touch Speed Boost. The function is set.

Turning SpeedBoost off

1.Select an element on which SpeedBoost is set.

2.Touch Speed Boost. The function is deactivated.

Note: In certain circumstances, the function may be deactivated automatically to protect the internal electronic components of the cooktop.

13

Cook time

You can use the timer function to set a cook time for any element. The element will turn off automatically once the set time has elapsed.

9CAUTION

When using the timer, always keep an eye on the cooktop and do not allow anything to boil over or burn. Boilovers can cause smoke and foods and oils may catch on fire if left on high temperature settings.

This function should not be used for long periods of time, especially at high heat settings.

Make sure the cooktop is turned off with the main power switch after each use.

Setting the cook time

1.Select the desired element and power level.

2.Touch the Timer key twice. The ‹‹, min and __ indicators light up on the timer display. The cook time indicator for the desired element lights up.

3.Within the next 10 seconds, set the required time using the number keys 1 to 9.

After a few seconds, the timer will start to count down.

The last programmed cook time will appear in the display.

Once the cook time has elapsed

The element turnes off once the set cook time has elapsed. You will hear a beep. The indicator ‹.‹ appears in the element display and the timer display shows ‹‹. Once you touch the Timer key, the indicators and the beep are turned off.

Changing or cancelling cook time

1.Select the desired element.

2.Touch the Timer key twice. The r__ indicators light up.

3.Adjust the cook time using the number keys. To cancel cook time set the timer to ‹‹ by touching the 0 key twice.

Notes

If a cook time has been set the display always shows the time for this function. To check the remaining cook time for an element, select the element and touch the Timer key twice.

If a cook time has been set for more than one element, the display shows the time for the selected element.

You can set a cook time of up to 99 minutes.

Automatic timer

With this function you may select a cook time for all elements. Once an element is turned on, the selected time will begin to count down. The element will automatically turn off when the cook time has elapsed.

Instructions on activating the automatic timer are found in the chapter "Basic settings".

Note: The cook time can be changed or cancelled for any element:

Select the desired element and touch the Timer key twice. The remaining cook time for the element is displayed. Adjust the cook time using the number keys, or deactivate it by setting the the timer value to ‹‹.

The timer

The timer can be set for periods of up to 99 minutes. It is independent of the other settings. This function does not automatically switch off an element.

Setting the kitchen timer

1.Touch the Timer key. ‹‹ appears in the timer display. The __, min and U indicators light up.

2.Set the required time using the number keys 0 to 9.

After a few seconds, the __ indicator goes out and the programmed time starts to count down.

Once the time has elapsed

A beep sounds. ‹‹ and U indicators light up. Touch the Timer key. The indicators go out and the beep stops.

Changing the time

Touch the Timer key. The __ and U indicators light up. Change the time using the number keys 0 to 9.

14

Clearing the time

Touch the Timer key. The __ and U indicators light up. Touch the 0 key until ‹‹ appears on the timer display. The U indicator goes out.

Notes

If the set time is not displayed, touch the Timer key several times until the U indicator lights up on the timer display.

The timer will be deactivated after a power outage.

The automatic off function for an element and the timer function can both be operated simultaneously.

Panel Lock

You can use the panel lock to prevent children from accidentally turning the appliance on.

Turning the panel lock on

The cooktop must be turned off.

Touch Panel Lock for 4 seconds. The Dindicator lights up for 4 seconds.

Turning the panel lock off

Touch Panel Lock for 4 seconds. The panel lock is now deactivated.

9CAUTION

The panel lock may be accidentally turned on and off due to:

water spilled during cleaning

food that has overflowed

objects being placed on the Panel Lock key.

Automatic panel lock

With this function, the panel lock is automatically activated whenever you turn off the cooktop.

Turning on and off

See "Basic settings" section.

Wipe Protection

Cleaning the control panel while the cooktop is on may change the settings. In order to avoid this the cooktop has a wipe protection function.

Touch Panel Lock. The > indicator appears. The control panel is locked for approximately 35 seconds. You can now clean the surface of the control panel without risk of changing the settings.

After the time has elapsed a beep will sound. The Panel Lock is deactivated.

Note: The wipe protection does not affect the main switch. You can turn off the cooktop at any time.

Automatic time limitation

If the element is used for prolonged periods of time without changes in the settings being made, the automatic time limitation function is triggered.

The element stops heating. ”‰and the residual heat indicator •/œ flash alternately in the display.

The indicator goes out when any symbol is pressed. The element can now be reset.

When the automatic time limitation is activated depends on the selected heat level (from 1 to 10 hours).

Basic settings

The appliance has various basic settings. You can adjust these settings to the way you usually cook.

Display	Function
™‚	Automatic child lock/panel lock
	‹ Off*
	‚ On
™ƒ	Audible signals
	‹Confirmation and error signals deactivated
	‚ Only confirmation signal deactivated
	ƒ All signals activated*
™†	Automatic timer
	‹ Off*
	‚-ŠŠ Automatic shut-off time
™‡	Length of timer end signal
	‚ 10 seconds*
	ƒ 30 seconds
	„ 1 minute

15

™ˆ	Power Management function
	‹ = Off*
	‚ = 1.000 W. minimum power
	‚.= 1.500 W
	ƒ= 2.000 W
	etc.
	Š or Š. = maximum power of the element
™Š	Selection time for heating element
	‹Unlimited*: You can adjust the settings of the last heating element used at any time without
	having to select it again.
	‚Restricted: You can adjust the settings for the last heating element used within 10 seconds after
	selecting it. After that you will have to reselect the heating element before setting it.
™‹	Reset to basic settings
	‹ Off*
	‚ Reset the appliance to basic settings
*factory settings

Changing the basic settings

The cooktop must be turned off.

1.Turn on the cooktop with the main switch.

2.Within the next 10 seconds, touch the Timer key for about 4 seconds.

™ ‚ lights up in the timer display and ‹‹ lights up in the element display.

3.Touch Timer repeatedly until the indicator for the desired function appears in the element display.

4. Set the desired value with the number keys.

5.Touch Timer again for 4 seconds. The setting is stored.

Quit basic settings

Turn the cooktop off with the main switch.

16

Cleaning and Maintenance

Daily Cleaning

Note: Recommended cleaners indicate a type of cleaner and do not constitute an endorsement of a specific brand.

Glass ceramic cooktop

9CAUTION

Do not use any kind of cleaner on the glass while the surface is hot, use only the razor blade scraper. The resulting fumes can be hazardous to your health. Heating the cleaner can chemically attack and damage the surface.

Clean the surface when it is completely cool with the following exception: remove dry sugar, sugar syrup, tomato products and milk immediately with the razor blade scraper (see special care chart).

Wipe off spatters with a clean, damp sponge or a paper towel. Rinse and dry. Use white vinegar if smudge remains; rinse.

Apply a small amount of the glass ceramic cooktop cleaner. When dry, buff surface with a clean paper towel or cloth.

Cleaning guidelines

When using a cleaner, use only a small amount; apply to a clean paper towel or cloth. Wipe on the surface and buff with a clean dry towel.

For best results, use cleaners such as glass ceramic cooktop cleaner, BonAmi®, Soft Scrub® (without bleach), and white vinegar.

Avoid these cleaners

Glass cleaners which contain ammonia or chlorine bleach. These ingredients may damage or permanently stain the cooktop.

Caustic cleaners - cleaners such as Easy Off® may stain the cooktop surface.

Abrasive cleaners.

Metal scouring pads and scrub sponges such as Scotch Brite® can scratch and/or leave metal marks.

Soap-filled scouring pads such as SOS® can scratch the surface.

Powdery cleaners containing chlorine bleach can permanently stain the cooktop.

Flammable cleaners such as lighter fluid or WD-40.

Cleaning charts

Type of Soil	Possible Solution
Dry sugar, sugar syrup, milk or tomato spills. Melted	Remove these types of spills while the surface is hot
plastic film or foil. All these items REQUIRE IMMEDIATE	using the razor blade scraper. Use a new, sharp razor in
REMOVAL. Failure to remove these immediatly can	the scraper. Remove pan and turn off the element.
permanently damage the surface.	Wearing an oven mitt, hold scraper at 30° angle, using
	care not to gouge or scratch the glass. Push soil off the
	heated area. After the surface has cooled, remove the
	residue and apply the glass ceramic cooktop cleaner.
	9 WARNING
		RISK OF INJURY
		The blade is extremely sharp. Risk of cuts. Protect
		the blade when not in use. Replace the blade
		immediately when any imperfections are found.
		Follow manufacturer’s instructions.
Burned-on food soil, dark streaks, and specks	Soften by laying a damp paper towel or sponge on top of
	soil for 30 minutes. Use a plastic scrubber and glass
	ceramic cooktop cleaner or use the razor blade scraper.
	Rinse and dry.
Greasy spatters	Use a soapy sponge or cloth to remove grease; rinse
	thoroughly and dry. Apply glass ceramic cooktop
	cleaner.

17

Type of Soil	Possible Solution
Metal marks: Iridescent stain	Pans with aluminum, copper or stainless steel bases may
	leave marks. Treat immediately after surface has cooled
	with glass ceramic cooktop cleaner. If this does not
	remove the marks, try a mild abrasive (Bon Ami®, Soft
	Scrub® without bleach) with a damp paper towel. Rinse
	and reapply glass ceramic cooktop cleaner. Failure to
	remove metal marks before the next heating makes
	removal very difficult.

Hard water spots:

Hot cooking liquids dripped on surface

Minerals in some water can be transferred onto the surface and cause stains. Use undiluted white vinegar, rinse and dry. Recondition with glass ceramic cooktop cleaner. Remove boilovers and stains before using the cooktop again.

Surface scratches:

Small scratches are common and do not affect cooking. They become smoother and less noticeable with daily use of the glass ceramic cooktop cleaner.

Apply glass ceramic cooktop cleaner before using to remove sand-like grains and grit such as salt and seasoning. Scratches can be reduced by using pans with bases that are smooth, clean, and dry before use. Use recommended glass ceramic cooktop cleaner daily.

NOTICE: Diamond rings may scratch the surface.

Maintenance

This appliance requires no maintenance other than daily cleaning. For best results, apply cooktop cleaning cream daily.

Service

Fixing Malfunctions

Malfunctions are usually due to small details. Before calling the Technical Assistance Service, you should consider the following advice and warnings.

9CAUTION

Repairs should only be done by a trained servicer.

Improper repair of your appliance may result in risk of severe physical injury or death.

Indicator	Malfunction	Solution
none	The electric power supply has been	Use other electrical appliances to check whether there has
	cut off.	been a power cut.
	The appliance has not been correctly	Check that the appliance has been connected correctly
	connected following the connection	according to the connection diagram.
	diagram.
	Electronic system malfunction.	If the measures above cannot resolve the malfunction, contact
		the Technical Assistance Service.

“ flashes	The control panel is damp or an
	object is resting on it.

Dry the control panel area or remove the object.

Ҥ+ number	Electronic system malfunction.	Unplug the cooktop from the mains. Wait about 30 seconds
/ š + number		before plugging it in again. *
/ ¡ + number
”‹ / ”Š	There is an internal operating error.	Unplug the cooktop from the mains. Wait about 30 seconds
		before plugging it in again. *

* If the warning persists call the Technical Assistance Service.

Do not rest hot pans on the control panel.

18

Indicator	Malfunction	Solution
”ƒ / ”†	The electronic system has overheated	Wait until the electronic system has cooled down completely.
	and the corresponding burner has	Then touch any symbol on the cooktop.*
	been turned off.
”…	The electronic system has overheated
	and all burners have been turned off.
—‚	Incorrect supply voltage, outside nor-	Please contact your electricity distributor.
	mal operating limits.
—ƒ / —„	The burner has overheated and has	Wait until the electronic system has cooled down sufficiently
	turned off in order to protect its cook-	before turning it back on.
	ing surface.

* If the warning persists call the Technical Assistance Service.

Do not rest hot pans on the control panel.

Normal operating noises of the cooktop

Induction technology is based on the creation of electromagnetic fields. They may generate heat directly on the bottom of the cookware. Pots and pans may cause a variety of noises or vibrations depending on the way they've been manufactured. These noises are described as follows:

Low humming (like a transformer)

This noise is produced when cooking at a high heat level. It is based on the amount of energy transferred from the cooktop to the cookware. The noise ceases or quiets down when the heat level is reduced.

Quiet whistling

This noise is produced when the cooking vessel is empty. It ceases once water or food is placed in the vessel.

Crackling

This noise occurs with cookware comprised of various materials layered one upon the other. It's caused by the vibrations of the surfaces where different materials meet. The noise occurs on the cookware and can vary depending on the amount and method of preparation of the food.

Loud whistling

This noise occurs with cookware comprised of different materials layered one upon the other, and when they are additionally used at maximum output and also on two cooking zones. The noise ceases or quiets down when the heat level is reduced.

Fan noises

For proper operation of the electronic system, it is necessary to regulate the temperature of the cooktop. For this purpose, the cooktop is equipped with a cooling fan, which is activated to reduce and regulate the temperature of the electronic system. The fan may also continue to run after the appliance is turned off if the detected temperature of the cooktop is still too hot after turning it off.

The noises described are a normal element of the described induction technology and shouldn't be regarded as defects.

Technical service

Contact our Technical Service Department if your appliance needs repair. Our central Customer Service Center (see below) will also be happy to supply you with details on a center close to you.

E number and FD number:

When you contact our service, please have the Model(E) number and the FD number for your appliance available. You can find the identification plate with these numbers on the underside of the appliance and in the appliance booklet.

Questions? Please contact us. We look forward to hearing from you!

ZZZ ERVFK KRPH FRP

0DLQ 6WUHHW 6XLWH ,UYLQH &$

19

STATEMENT OF LIMITED PRODUCT WARRANTY

What this Warranty Covers & Who it Applies to

The limited warranty provided by BSH Home Appliances Corporations (“BSH“) in this Statement of Limited Product Warranty applies only to the Bosch appliance (“Product“) sold to you, the first using purchaser, provided that the Product was purchased:

For your normal, household (non-commercial) use, and has in fact at all times only been used for normal household purposes.

New at retail (not a display, "as is", or previously returned model), and not for resale, or commercial use.

Within the United States or Canada, and has at all times remained within the country of original purchase.

The warranties stated herein apply only to the first purchaser of the Product and are not transferable.

BSH reserves the right to request proof of purchase at the time any warranty claim is submitted to confirm that the Product falls within the scope of this limited product warranty.

Please make sure to return your registration card; while not necessary to effectuate warranty coverage, it is the best way for BSH to notify you in the unlikely event of a safety notice or product recall.

How Long the Warranty Lasts

BSH warrants that the Product is free from defects in materials and workmanship for a period of three hundred sixty-five (365) days from the date of purchase. The foregoing timeline begins to run upon the date of purchase, and shall not be stalled, tolled, extended, or suspended, for any reason whatsoever.

This Product is also warranted to be free from cosmetic defects in material and workmanship (such as scratches of stainless steel, paint/porcelain blemishes, chip, dents, or other damage to the finish of the Product), for a period of thirty (30) days from the date of purchase or closing date for new construction. This cosmetic warranty excludes slight color variations due to inherent differences in painted and porcelain parts, as well as differences caused by kitchen lighting, product location, or other similar factors. This cosmetic warranty specifically excludes any display, floor, “As Is”, or “B” stock appliances.

Repair/Replace as Your Exclusive Remedy

During this warranty period, BSH or one of its authorized service providers will repair your Product without charge to you (subject to certain limitations stated herein) if your Product proves to have been manufactured with a defect in materials or workmanship. If reasonable attempts to repair the Product have been made without success, then BSH will replace your Product (upgraded models may be available to you, in BSH’s sole discretion, for an additional charge). All removed parts and components shall become the property of BSH at its sole option. All replaced and/or repaired parts shall assume the identity of the original part for purposes of this warranty and this warranty shall not be extended with respect to such parts. BSH's sole liability and responsibility hereunder is to repair manufacturer-defective Product only, using a BSH-authorized service provider during normal business hours. For safety and property damage concerns, BSH highly recommends that you do not attempt to repair the Product yourself, or use an un-authorized servicer; BSH will have no responsibility or liability for repairs or work performed by a non-authorized servicer. If you choose to have someone other than an authorized service provider work on your Product, THIS WARRANTY WILL AUTOMATICALLY BECOME NULL AND VOID. Authorized service providers are those persons or companies that have been specially trained on BSH products, and who possess, in BSH's opinion, a superior reputation for customer service and technical ability (note that they are independent entities and are not agents, partners, affiliates or representatives of BSH). Notwithstanding the foregoing, BSH will not incur any liability, or have responsibility, for the Product if it is located in a remote area (more than 100 miles from an authorized service provider) or is reasonably inaccessible, hazardous, threatening, or treacherous locale, surroundings, or environment; in any such event, if you request, BSH would still pay for labor and parts and ship the parts to the nearest authorized service provider, but you would still be fully liable and responsible for any travel time or other special charges by the service company, assuming they agree to make the service call.

Out of Warranty Product

BSH is under no obligation, at law or otherwise, to provide you with any concessions, including repairs, pro-rates, or Product replacement, once this warranty has expired.

20
